HIGH TEMPERATURE HEATING TAPES
FGS, FGH, FWH Series
U Maximum Exposure
Temperature up to 480°C (900°F)
U Reliable
U Fiberglass Insulated
U Fast Thermal Response
U Integral Molded Separable Plug
U Available with Leads Same End
†
APPLICATIONS
Wide and heavy-duty insulated tapes are good for
direct contact on a conductive surface.
Standard tapes are made from fine gage stranded
resistance wires that are double insulated with braided
fiberglass and knitted into flat tapes for maximum flexibility.
A heavy insulated tape is made by taking a standard tape
and braiding it between layers of fiberglass yarn. Wide
tapes are made from two or more standard tapes that are
sewn between two layers of fiberglass cloth.
Beaker Not
Included.
Standard insulated tape shown.
SPECIFICATIONS
Heating Elements: 36-40 gage resistance wire.
Lead Wires: Emerge from opposite ends into separate sides
of an integrally molded separable plug
Heating Element Insulation: Double-braided fiberglass
Dielectric Strength: In excess of 2000 V
†
To order heaters with power leads exiting the same end of the tape,
add suffix “-LSE” to model number. To order 240 V version change
the “1” in the part no. prior to the “-” to “2” for 240 V. All 240 V versions
are not supplied with plugs. Consult Sales for prices.
Fire and electrical shock may result if products are used improperly
or installed or used by non-qualified personnel. See inside back
cover for additional warnings.
Wide Heavy Insulated Tapes
To Order
Watts W/in2 Volts Size Model No.
209 4.9 120 1
418 4.9 120 1
622 4.9 120 1
836 4.9 120 1
1045 4.9 120
313 5.2 120 2
627 5.2 120 2
940 5.2 120 2
1254 5.2 120 2
1567 5.2 120
418 5.3 120 3
836 5.3 120 3
1254 5.3 120 3
1672 5.3 120 3
2090 5.3 120
Does not come with plug. Comes complete with instruction sheet.
*
CAUTION AND WARNING!
3
"
⁄
x 2' FWH171-020
4
3
"
⁄
x 4' FWH171-040
4
3
"
⁄
x 6' FWH171-060
4
3
⁄
x 8' FWH171-080
4
3
"
'
⁄
1
x 10
4
1
"
⁄
x 2' FWH251-020
2
1
"
⁄
x 4' FWH251-040
2
1
"
⁄
x 6' FWH251-060
2
1
"
⁄
x 8' FWH251-080
2
1
"
⁄
2
x 10' FWH251-100
2
1
"
⁄
x 2' FWH321-020
4
1
"
⁄
x 4' FWH321-040
4
1
"
⁄
x 6' FWH321-060
4
1
"
⁄
x 8' FWH321-080*
4
1
"
⁄
3
x 10' FWH321-100*
4
FWH171-100
FGS051A Series version.
Standard Insulated Tapes
To Order
Watts W/in2 Volts Size Model No.
46 8.6 120 3⁄8" x 12" FGS0031-010
105 8.6 120
210 8.6 120
310 8.6 120
420 8.6 120
520 8.6 120
210 8.6 120 1" x 2' FGS101-020
420 8.6 120 1" x 4' FGS101-040
627 8.6 120 1" x 6' FGS101-060
830 8.6 120 1" x 8' FGS101-080
1045 8.6 240 1" x 10' FGS102-100*
1
⁄2" x 2' FGS051A-020
1
⁄2" x 4' FGS051A-040
1
⁄2" x 6' FGS051A-060
1
⁄2" x 8' FGS051A-080
1
⁄2" x 10' FGS051A-100
Heavy Insulated Tapes
To Order
Watts W/in2 Volts Size Model No.
105 8.6 120 1⁄2" x 2' FGH051-020
210 8.6 120
310 8.6 120
420 8.6 120
520 8.6 120
1
⁄2" x 4' FGH051-040
1
⁄2" x 6' FGH051-060
1
⁄2" x 8' FGH051-080
1
⁄2" x 10' FGH051-100
210 8.6 120 1" x 2' FGH101-020
420 8.6 120 1" x 4' FGH101-040
620 8.6 120 1" x 6' FGH101-060
830 8.6 120 1" x 8' FGH101-080
1045 8.6 120 1" x 10' FGH101-100
