Convection Heaters
FCH-FGC3 Series
C
U High Power to Size Ratio
U Lightweight
U Easy to Fit
U Three Power Settings
U Independent Fan Circuit to Aid
Climate Cooling
Applications
U ATM’s, Ticket Machines, Parking
Ticket Terminals, Access Systems,
Fuel Dispensers, Energy Ports,
Building-Safety Systems,
Building-Management Systems,
and Landscaping Systems
This range of fan heaters uses Positive Temperature
Coefficient (PTC) ceramic heating technology
to provide the user with a product ideally suited
to climate control. The heater can be controlled
independently to the fan, allowing a ‘fan-only’ mode
for air circulation.
The product has been designed, and approved for
many applications. Use of high-quality components
guarantees the highest possible operating safety in
the respective application. Self-regulation through
PTC features.
Specifications
Model No.
Nominal Power at 10°C (50°F): Watt
Nominal Input Voltage: V
Nominal Input Frequency: Hz
Operating Temperature Range: °C (°F)
Storage Temperature Range: °C (°F)
Fan Lifetime [MTTF at 30°C (68°F)]: Hours
3
Fan Volumetric Flow, Approximate m
Weight, Add 35 g (1.23 oz) for Bracket: g (oz)
Dimensions, Cross Section: mm (inch)
Length: mm (inch)
Harness Length: mm (inch)
Ingress Rating, EN60529
Electrical Protection Class
/h
FCH-FGC3111 shown
smaller than actual size.
The heater’s proven safety through given temperature
limitation have high reliability without additional switching
elements. The compact design through high power
density provides specific air flow for desired climate.
FCH-FGC3111 FCH-FGC3116
200/300/400
230 Vac 115 Vac
50 60
-10 to 70 (14 to 158)
-40 to 70 (-40 to 158)
329,447
10 (5.89) 13 (7.65)
275 (9.69)
71 x 70 (2.79 x 2.75)
96.5 (3.79)
240 (9.44)
IP20
II
H
T
To Order Visit omega.com/fch-fgc3 for Pricing and Details
FCH-FGC3116
FCH-FGC3111
Comes complete with operator’s manual.
Ordering Example: FCH-FGC3116, 200/300/400W, 115V, 240 mm (9.4") lead with DIN clip.
200/300/400W, 115V, 240 mm (9.4") lead with DIN clip
200/300/400W, 230V, 240 mm (9.4") lead with DIN clip
HT-1
