Non-Fraying Fiberglass
Sleeving
Braided Sleeving
for High
Temperature and Abrasive
Applications
FBGS Series
High Temperature Rating
to 316 ºC (601 ºF)
Continuous Duty and
616 ºC (1141 ºF) for
Short Periods
Good Resistance to
Most Alkalies
Fair Resistance to Acids
Unaffected by Bleaches
and Solvents
Flame Resistance,
Will Not Burn
FBGS-R-20-25, red 20 gage
fiberglass sleeving
Blue
Black
FBGS-Y-20-25, yellow
20 gage fiberglass
sleeving
FBGS Series non-fray fiberglass
sleeving is a flexible, high
temperature primary or secondary
insulation made from closely braided,
continuous filament fiberglass which
has been heat-cleaned to remove
impurities in the yarn. Acrylic resin
binders are applied for color coding
and to further retard fraying and to
hold sleeving round for cutting. This
fiberglass insulation is unaffected
indefinitely through a temperature
range from -60 °C to 316 °C (-76 ºF
to 601 ºF) and withstand up to 616 °C
(1141 ºF) for shorter periods. Colors
will be less vivid after exposure to
150 °C (302 ºF).
FBGS Series fiberglass sleeving is
used for thermal and mechanical
protection in consumer, commercial
and industrial applications where
flexibility, abrasion resistance or
insulation is required and
particularly when temperature
extremes prohibit the use of
other materials.
Both models
shown actual size.
Purple
Natural
Enlarged view
Also Available in Red, Yellow, Green,
and Brown
To Order (Specify Model Number)
Model Number Length of Spool m (ft)
FBGS-(*)-(**)-25 7.6 (25)
FBGS-(*)-(**)-50 15.2 (50)
FBGS-(*)-(**)-100 30.5 (100)
FBGS-(*)-(**)-200 61 (200)
FBGS-(*)-(**)-500 152.4 (500)
(*) Select color, “B” = Blue, “BK” = Black, “R” = Red, “N” = Natural, “Y” = Yellow
“P” = Purple, "BR" = Brown, or "GR" = Green.
(**) Select gage; 20, 24, 26, 28 or 30.
Note: All gage and color combinations may not be available - see DwyerOmega.com or contact
customer service for available options.
Ordering
FBGS-B-20-200, 61 m (200 ft) spool of 20 gage, blue fiberglass sleeving.
Examples: FBGS-R-24-25, 7.6 m (25 ft) spool of 24 gage, red fiberglass sleeving
,
.
DS-FBGS
