Omega CT-100 Specification

®

CHART-TEMP

Temperature Recorders

CT-100 Series

Comes with

Extra Charts!

CT-300F-1H shown smaller
than actual size.

U From -40 to 260°C

(-40 to 500°F)

U Low-Temperature

Recorders with Ranges
Up to 104°C (220°F) and
Either 1- or 7-Day Charts
and 2% Accuracy

U Oven Recorders with

Ranges Up to 260°C
(500°F) and Either
1- or 24-Hour Charts
with 3% Accuracy

OMEGA® CHART-TEMP
recorders are dry-stylus, spring­wound, clock-driven circular chart
recorders. Simply rewind the
drive when replacing the chart.
These recorders are excellent for
recording temperatures inside
buildings, refrigerators, or ovens.
Units with ranges up to 260°C
(500°F) are available.

Extended Warranty

Program

OMEGACARESM extended warranty program
is available for models shown on this page.
Ask your sales representative for full details
when placing an order. OMEGACARE
covers parts, labor and equivalent loaners.

®

SM

SM

Specifications

Dimensions: 82.5 H x 100 mm diameter

(3.26 x 3.94")

Low-Temperature Recorders
To Order

Weight:
High-Temp Models: 397 g (14 oz)
Low-Temp Models: 600 g (21 oz)

Temperature Charts

Model No. Range Model No.
CT-100AF-(*) 0 to 100°F (*)-100F
CT-120AF-(*) 20 to 120°F (*)-120F
CT-160AF-(*) -40 to 160°F (*)-160F
CT-220AF-(*) 20 to 220°F (*)-220F
CT-70AF-(*) -30 to 70°F (*)-70F

Insert “1” for 1-day or “7” for 7-day recorder. Units with “-7” suffix are 7-day recorders.

*

Ordering Examples: CT-100AF-1, 1 hr recorder with 0 to 100°F temperature range.
OCW-3, OMEGACARESM extends standard 1-year warranty to a total of 4 years.

High-Temperature Recorders

Temperature Charts

Model No. Range Model No.
CT-300F-(*) 70 to 300°F (*)-300F-CHART
CT-400F-1H 70 to 400°F (*)-400F-CHART
CT-500F-(*) 70 to 500°F (*)-500F-CHART
CT-150C-1H 20 to 150°F 1H-150C-CHART
CT-200C-1H 20 to 200°C 1H-200C-CHART
CT-260C-1H 20 to 260°C 1H-260C-CHART

Insert “1H” for 1-hour or “24H” for 24-hour recorder. Units with “-1H” suffix are 1-hour

*

recorders.

Ordering Example: CT-500F-1, 1-hour recorder with 70 to 500°F temperature range.
OCW-3, OMEGACARE

SM

extends standard 1-year warranty to a total of 4 years.

S-57
