HOUSEHOLD
BL600 SERIES BLENDER
CITRUS JUICER
PLEASE READ THESE INTRUCTIONS CAREFULLY BEFORE USING YOUR JUICER
JUICER SAFETY
DANGER Electricity
DANGER Risk of Electrical Schock
WARNING
Electrical Shock Hazard
Plug into a grounded outlet.
Do not remove ground.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can
result in death, fire or electrical shock.
FAILURE TO ADHERE TO THESE WARNINGS CAN RESULT IN FIRE,
SERIOUS INJURY, ELECTRICAL SCHOCK AND/OR DEATH
GENERAL Caution
DANGER Keep Hands Clear
WARNING
Moving Parts!
Do not put spoons or other utensils in container when jucing. Use extreme caution not
to contact moving parts with hands during
operation.
Failure to follow these instructions can result
in broken bones, cuts or other injuries.
WARNING
JUICING CONES ROTATE WITH SUBSTANTIAL FORCE. USE EXTREME CAUTION WHEN
PRESSING FRUIT ON TO CONES. NEVER CONTACT MOVING PARTS DIRECTLY WITH
HANDS.
Technical Services
For assistance or replacement parts, call
Technical Service at
Toll Free: 1-800-633-3401
IMPORTANT SAFEGUARDS
a) Read all instructions
b) To protect against risk of electrical shock
do nol put body or supply cord in water or
other liquid.
c) Close supervision is necessary when any
appliance is used by or near children
d) Unplug from outlet when not in use, be-
fore putting on or taking off parts, and before
cleaning.
e) Avoid contacting moving parts
f) Do not operate any appliance with a dam-
aged cord or plug or after the appliance
malfunctions, or is dropped or damaged in
any manner. Return appliance to the nearest
authorized service facility for examination,
repair or electrical or mechanical adjustment
g) The use of attachments not recommended
or sold by the manufacturer may cause fire,
electric shock or injury.
h) Do not use outdoors
i) Do not let cord hang over edge of table or
counter.
J) Always make sure the juicing cones are
free of obstructions before turning the unit
on.
k) Be sure to turn switch to OFF position
after each use. Make sure the motor stops
completely before disassembling.
l) Do not put your fingers or other objects on
to the juicer opening while it is in operation.
Turn the motor off and disassemble juicer to
remove any pulp.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
GROUNDING INSTRUCTIONS
This appliance must be grounded while
in use to protect the operator from electri-
cal shock The appliance is equipped with a
3-conductor cord and a 3-prong grounding-
type plug to fit the proper grounding-type
receptacle
EXTENSION CORDS
Use only 3-wire extension cords which have
3-prong grounding-type plugs and 3-pole
cord connectors that accept the plug from
the appliance. Use only extension cords
having an electrical rating not less than the
rating of the appliance Do not use damaged
extension cords. Examine extension cord
before using and replace if damaged. Do not
abuse extension cord and do not yank on
any cord to disconnect Keep cord away from
heat and sharp edges.
JUICER OPERATION
To operate the juicer, proceed as follows
Step 1. Ensure the household citrus juicer is correctly assembled with
a container placed under the juice spout before juicing.
Step 2. Cut the citrus fruit in half by cutting across the diameter, and
not tip to tip, to ensure more efficient juicing. For the best contact with
the fruit cone, smooth the outside of the fruit by triming any tip ends
such as the ends of a lemon or tangelo.
Step 3. Plug the power cord into a properly grounded power outlet
and then switch the on/off butlon to ON. This begins operation of the
citrus juicer.
Step 4. Place citrus fruit half with the cut side down onto the juice cone.
Be careful not to press too hard. Use caution not to contact moving
parts with your hands.
Step 5. The motor will automatically start and the juicing cone will begin
to rotate. The juicer will be extracted from the fruit and flow through the
juice spout into the container. The pulp and seeds will collect in the
stainless steel filter.
Step 6. The household citrus juicer juices very quickly so each fruit
half will be juiced in a few seconds. To automatically stop the motor,
lift the fruit up.
Step 7. Remove the used fruit from the juicing cone. Empty excess
pulp and seeds from stainless steel filter as required. Repeat steps 4-7
to continue juicing.
NOTE: the stainless steel filter should be emptied when full
with pulp and seeds. The filter can be emptied during juicing by
switching the citrus juicer “OFF” and carefully removing the juic-
ing cone and filter. Clean and replace stainless steel filter and
juicing cone before continuing to juice. Do not allow the stain-
less steel filter to overfill as this may prevent correct operation
or damage the unit.
CARE, CLEANING AND STORAGE
• Always ensure that the juicer is switched OFF and the plug is removed from the power outlet
before cleaning, disassembling, assembling and storing the appliance
• Follow these instructions to clean all surfaces or parts that come into contact with food
during juicing:
1 Immediately after each use rinse removable parts under warm water
to remove wet pulp allow parts to air dry before reassembling.
2 For thorough cleaning-after disassembling the appliance, all removable parts should
be washed in tepid soapy water or on the top shelf of the dishwasher. The motor base
should be wiped with a soft, damp cloth. All parts should be dried thoroughly before
reassembling. Do not place base of unit in the dishwasher.
3 Store the cleaned and reassembled citrus juicer in an upright position in a cool, dry place
Never place any items on the top oft the citrus juicer.
4 Any other servicing should be performed by an authorized service representalive.
NOTES: 1 Rinse or wash all removable parts immediatley after use. Dried citrus pulp
is difficult to remove and may stain. If any staining does occur, wipe the affected parts
with undiluted dishwashing liquid, rinse and dry thoroughly.
2 Do not soak the stainless steel filter or other removable parts in bleach. Never
immerse the motor base in water or any other liquid. Do not use harsh abrasives.
TROUBLESHOOTING
Possible Problem Easy Solution
Machine will not work Switch not “ON”
Machine will not work Hand not lowered
Machine will not work
Motor stalls, the juicing cone
will not spin.
Cone or dome not assembled properly
Raise hand, re-lower hand slowly
for the first few seconds then press
down firmly.
Replacement Parts
For replacement parts, call toll free: 1-800-633-3401
NOTES
NOTES
OMEGA C10 9 2011 Rev A
