OMEGA PRODUCTS, INC.
3355 ENTERPRISE AVENUE, SUITE 160
FORT LAUDERDALE, FL 33331
PHONE: 877.368.2797
FAX: 954.202.7337
May 2013
INSTRUCTION
MANUAL
Eat well, drink well and live well with Omega www.omegajuicers.com
BL400 SERIES BLENDER
English, May 3013
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USE
BLENDER SAFETY
DANGER Electricity GENERAL Caution
DANGER Risk of Electrical Shock DANGER Keep Hands Clear
WARNING WARNING
Electrical Shock Hazard
Plug into a grounded outlet.
Do not remove ground.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can
result in death, re or electrical shock.
FAILURE TO ADHERE TO THESE WARNINGS CAN RESULT IN FIRE,
SERIOUS INJURY, ELECTRICAL SHOCK AND/OR DEATH
TECHNICAL SERVICES
For assistance or replacement parts, call
Technical Service
24 Hours a Day, 7 Days a Week at
Toll Free: #1.800.633.3401
Moving Parts!
Always cover the lid on the container
when blending.
Do not put hands, spoons or other
utensils container when blending.
Failure to follow these instructions
can result in broken bones, cuts or
other injuries.
2
TABLE OF CONTENTS
Specications 3
Important Safeguards 4
Blender Operation 5
Care and Cleaning 6-7
Control Panel 8
Blade Agitator Assembly 8
Troubleshooting 9
Maintenance 10
3
SPECIFICATIONS
BL420 BL440 BL460 BL480
Shipping Dimensions:
17.5” W x 10” D x 13.75” H
440mm W x 250mm D x 350mm H
Shipping Weight:
15 lb
6.8 kg
4
Power Requirements:
Volts: 120 VAC
Amps: 11.5 Amp
Hz: 50-60
Container:
64 Oz. / 1800ml
82 Oz. / 2300ml
IMPORTANT SAFEGUARDS
When using electrical appliances, basic
safety precautions should always be
followed, including the following:
1. Read all the instructions before using
the blender.
2. Plug into a grounded outlet.
3. Do not remove ground.
4. Do not use an adapter.
5. Do not use an extension cord.
6. To protect against risk of electrical
shock,do not put the blender in water
or other liquid.
7. Close supervision is necessary when
any appliance is used near children.
8. Unplug from outlet when not in use,
before putting on or taking off parts,
and before cleaning.
9. Avoid contact with moving parts,
especially blades.
10. Do not operate any appliance
with a damaged cord or plug or
after the appliance malfunctions,
or is dropped or damaged in any
manner. Return appliance to the
nearest authorized service facility
for examination /repair/electrical or
mechanical adjustment, or contact
your distributor.
11. Caution: Keep hands and utensils
out of container while blending to
reduce the risk of severe injury to
persons or damage to the blender.
If scraping, folding, etc. is necessary,
turn off and unplug the blender, and
use a rubber spatula only.
12. Warning: Blades are sharp.
Handle carefully.
13. To reduce the personal injury,
never place cutting blades on base
without jar properly attached.
14. Screw on locking ring rmly.
Injury can result if moving blades
accidentally become exposed.
15. Always operate blender with lid
in place.
16. When blending hot liquids, place
a hand towel over the cover. Do
not ll blender container beyond
2/3 full. Always begin processing
at the lowest speed setting. Keep
hands, arms and face away from
the feeder cup opening to prevent
possible burns.
17. Do not use outdoors.
18. Do not let cord hang over edge
of table or counter, or touch
hot surfaces.
19. Do not leave blender unattended
while it is operating.
20. The use of unapproved attachments
may cause injuries.
21. The capacity can be substantially
less than normal with thick mixtures.
22. Inspect the container assembly
daily. Do not use a broken, chipped
or cracked container. Check cutter
for wear, nicks or broken blades.
23. This appliance is intended for
short period of operation, with a
average rated operating time of
approximately 3 minutes.
24. This appliance is not intended for
use by persons (including Children)
with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge, unless
they have been given supervision or
instruction concerning the use of the
appliance by a person responsible
for their safety. Children should be
supervised to ensure they do not
play with the appliance.
5
BLENDER OPERATION
To operate the blender, proceed as follows
1. For the rst time user, wash the container assembly, including the lid, before use.
(Refer to “Cleaning Instruction”) Do not put the container assembly & blender base
assembly in the dishwasher.
2. Place the blender on a dry, clean, level surface, and be sure it is set to off.
3. Place the container onto the blender base. Make sure it rests securely on the base.
4. Plug the blender into an electric outlet.
5. Place the ingredients into the container.
6. Place the lid and feeder cap tightly on the container.
7. Set desired speed by switching the knob to Low or High.
8. The pulse feature can also be used by pressing the pulse switch.
PROFESSIONAL BLENDER TIPS
To operate the blender, proceed as follows
1. Processing hot liquid
• Always cover the lid and feeder cap before blending hot liquid or mixture.
• Use the feeder cap to add liquids to the container while the unit is running.
• Never stand with your face directly over the container when you are putting
ingredient through the feeder cap.
2. Blending Icy mixtures
• Steps for blending ice:
— Pour in liquid, and then add ice.
— Place the lid on the container.
— Set to desired speed.
— Chunks of frozen fruit can be added to milk or fruit juice to
— Use the feeder cap to add liquids or ingredients to the container
produce a sherbet or slush.
while the unit is running.
6
CLEANING OPERATION
Omega blender container parts are corrosion resistant, sanitary and easily cleaned.
Do not put the container assembly & blender base assembly in the dishwasher.
1. Before rst use and after every use, separate container parts from the base
2. Add cleaning solution to the container. Use washing solution of tepid water
(less than 115°F/46°C) and a non-sudsing detergent. Use the recommended
amount of detergent.
3. Scrub and ush out the container interior lid and feeder cap to remove food residue.
Empty container.
4. Fill container 1 /4 full with fresh washing solution and place it on the base.
5. Replace the lid on the container and run the blender on high speed for 2 minutes.
6. Repeat step 4 using clean rinse water (95°F/35°C).
7. Wipe down the container, feeder cap, and lid with a soft cloth or sponge,
dampened with fresh washing solution.
8. Wipe the exterior of the base with a damp cloth or sponge. The base contains
electrical components: do not immerse, use a high-pressure washer, or use a
dishwasher to clean the base.
CARING TIPS
To care for your blender, please read the tips as follows:
1. Periodically check all parts before reassembly, as use of damaged or
non-recommended parts could result in a severe personal injury and/or damage
to the blender.
2. Blades:
If the processing blades are stuck or difcult to turn, DO NOT USE BLENDER
(Check by carefully turning the blades in a counterclockwise direction,
where the opposite edges are sharp. Blades should turn freely.)
3. Container:
If the EASTMAN TRITAN container is cracked, DO NOT USE BLENDER, further use
could result in the container breakage during use.
4. Blender Base:
Never immerse the blender base in water. Unplug unit. The housing can be cleaned
with a damp cloth.
5. Motor:
The motor is permanently lubricated and does not require any additional lubrication.
7
CAUTION & SAFEGUARDS
1. To protect against risk of electrical shock, do not put motor base in water or
other liquid.
2. Unplug the power cord from the wall outlet when the unit is not in use,
before putting on or taking off parts, and before cleaning other than
washing the container.
3. Never contact moving parts.
4. Do not use outdoors.
5. Do not let the power cord hang over edge of table or counter, or
touch hot surfaces.
6. Keep hands and utensils out of the container while the motor is running to
prevent the possibility of severe personal injury and/or damage to the unit.
A rubber scraper may be used, but only when the unit is not running.
7. The blade is very sharp and requires careful handling. Never try to remove
blade while container is sitting on the motor base. Do not operate with loose
or damaged blades. To reduce the risk of personal injury, never place blade
assembly on motor base without blender container properly attached.
8. Always operate with the lid in place.
9. NEVER bang the container against a surface to loosen the ingredients.
Remove the container from the base and use a rubber spatula to remove
thick mixtures from the bottom of your container.
10. NEVER shake or rattle a container in use while seated on the motor base.
11. NEVER remove the container before the machine has come to a
complete stop.
12. NEVER start the motor before the container is in place.
13. Keep children away when the blender is in use.
On most models, the power cord comes equipped with a three-prong
(grounding) plug which mates with a standard three-prong wall outlet
(Figure A). Please use approved 2 prong adapters(Figure B) when a
ground is not available. Do not cut or remove the round grounding prong
from the power cord.
Figure A Figure B
8
CONTROL PANEL
MODEL CONTAINER CONTROLS
BL420/422 64 Oz. / 1800ml On/Off Switch High/Low Switch
BL430/432 82 Oz. / 2300ml On/Off Switch High/Low Switch
BL440/442 64 Oz. / 1800ml Off/Low/High Knob Pulse Switch
BL450/452 82 Oz. / 2300ml Off/Low/High Knob Pulse Switch
BL460/462 64 Oz. / 1800ml On/Off Switch Variable Speed Knob Pulse Switch
BL470/472 82 Oz. / 2300ml On/Off Switch Variable Speed Knob Pulse Switch
BL480/482 64 Oz. / 1800ml On/Off Switch Variable Speed Knob Timer Knob
BL490/492 82 Oz. / 2300ml On/Off Switch Variable Speed Knob Timer Knob
Blade Agitator Assembly
Use caution when handling the blade; it is sharp. Use a soft cloth to grab
the blade when inserting the blade assembly through the container.
Retainer Nut and Blade Removal
• The retainer nut is easily removed using the disassembling tool (DT).
Turn container upside down and insert the disassembling tool on the
holes of the nut. Push the tool counterclockwise to loosen nut (Step 1).
Once loosened, remove by hand.(Disassembly tool sold separately)
• To release the blade use the other end of the DT while grabbing the
gear with backup pliers and turn counterclockwise (Step 2)
CARE AND CLEANING
Motor Base
1. Unplug the power cord.
2. Wipe outside surface with a damp soft cloth or sponge, which has
been rinsed in a mild solution of liquid dish soap and warm water.
NEVER IMMERSE MOTOR BASE IN WATER OR OTHER LIQUID.
3. Wipe dry with a clean, soft cloth.
Control Panel
Gently wash the front panel with a soft cloth and low pH balance soap.
NOTE: Be sure to wring excess water out of cloth or sponge when cleaning
around the controls, drive socket or any electrical part.
9
Lid
Separate the lid and plug, then wash in warm soapy water. Rinse clean
under running water and dry. Reassemble before use.
Container
1. To clean: Fill pitcher 1/4 full with warm water and add 2-3 drops of dish soap.
Return container to motor base and rmly position the two part lid.
Run machine for 30 seconds. Empty container. Repeat this step.
TROUBLESHOOTING
PROBLEM PROBLEM CAUSE PROBLEM SOLUTION
Loud noise from
the container
Machine starts
then shuts off
Machine starts
then shuts off
• Container blades
do not spin
• Increased vibration
• Leaking from bottom
of container.
• Motor
• Reset button
• Power failure
• Power supply
cord damage
• Broken or worn drive socket.
Replace drive socket.
• Check blade assembly
for damaged components
and replace.
• Tighten retainer nut the on
the bottom of the container.
• Depress reset button
• Call Customer Service
• Check to make sure there is
power to the machine.
• Check the power supply cord
and the connection to the
power outlet.
10
MAINTENANCE
INSPECT THE BLENDER AND ITS VARIOUS PARTS AND
REPLACE AS FOLLOWS:
1. Unplug the blender and remove the container from
Daily
the base.
2. Inspect the container blades for wear, nicks, and
broken or loose blades. Replace if necessary.
1. Unplug the blender.
Weekly
Quarterly
2. Inspect the power cord insulation and power plug
for cracks. Refer to “Technical Service” for repair
or replacement.
1. Review the condition of the container assembly
and Mushroom Clutch Set at least every 90 days.
2. Replace if necessary.
REPLACEMENT PARTS
For replacement parts, call toll free: #1.800.633.3401
11
Loading...
