USER MANUAL
2014 JUNE
BL400 Blender Series
MODEL
HIGH/LOW CONTROLS & VARIABLE SPEEDS
www.OmegaJuicers.com
Congratulations!
CONGRATULATIONS on the purchase of your new Omega.
At Omega, we strive to develop technologically advanced machines that help deliver
nutrition and avor of the highest kind and closest to nature’s purest form. We are
driven by you, our brand supporters. Your enthusiasm helps us continue to reinvent
and renew our line of juicers, high speed blenders and beverage equipment. Our
team at Omega thanks you for supporting us for over 50 years!
Join us on Twitter @OmegaAppliances &/or on Facebook @OmegaJuicers
PRODUCT REGISTRATION, VISIT:
www.omegajuicers.com/omega-warranty-registration
RECIPES, VISIT: www.omegajuicers.com/recipes
CUSTOMER SERVICE: Call 1-800-633-3401 or
visit: www.omegajuicers.com/contact-omega-juicers
After using your Omega, we kindly ask you to rate the machine on
www.OmegaJuicers.com
TABLE OF CONTENTS
02 - 03 Safety First
04 - 05 Know Your Omega
06 - 07 Operating Instructions
08 - 09 Using your Omega Blender
10 - 11 Easy Cleaning & Caring Tips
12 - 13 Additional Uses
14 - 15 Control Panel
16 - 17 Blade Agitator Assembly
18 - 19 Maintenance
20 - 21 Troubleshooting
22 - 23 Product Specications
24 - 29 Recipes & Notes
SAFETY FIRST
SAFETY FIRST
When using electrical appliances, basic safety precautions should always be followed
including the following.
1. READ ALL INSTRUCTIONS BEFORE USING.
1. To protect against electrical shock, do not immerse cord, plug or motor base in water or
any other liquid.
2. Always use the appliance on a dry, level surface.
3. The use of attachments not sold or recommended by the manufacturer may cause re,
electric shock or injury.
4. Do not remove the container from the motor base while blender is in operation.
5. Do not place hands in container unless the unit is disconnected from the power outlet.
A scraper may be used but must be used only when the blender is not running.
6. Disconnect the blender from the power outlet before removing container from base.
Blades are sharp - handle carefully.
7. To reduce risk of injury, never place blade assembly on base without jar properly attached.
8. Always operate the blender with cover in place.
9. Do not use this blender for any purpose other than food or beverage preparation.
10. Do not blend a dry, thick or heavy mixture for more than 10 seconds without turning the
blender off. Then, stir ingredients before continuing to blend.
11. Do not process boiling liquids. Let cool before placing in pitcher.
12. Do not leave the appliance unattended when in use. Young children should be supervised
when near the appliance.
13. Do not place appliance on or near a hot gas or electric burner, or where it could touch
any other source of heat.
14. Unplug appliance from the power outlet when not is use, before puttcing on or taking off
parts, and before cleaning.
15. This appliance is for household use only. Do not use this appliance for anything other than
its intended use. Do not use outdoors.
16. Fully unwind the cord before use.
17. To protect against electric shock, do not immerse the cord, plug or motor base in water
or any other liquid.
18. Do not allow the cord to hang over the edge of a table or counter, touch hot surfaces or
become knotted.
19. This appliance is not intended for use by young children or inrm persons unless they
have been adequately supervised by a responsible person to ensure they can use the
appliance safely.
20. It is recommended to regularly inspect the appliance. Do not use the appliance if the
power supply cord, plug or appliance becomes damaged in any way. Return the entire
appliance to the nearest authorized Omega Service Center for examination and/or repair.
21. Any maintenance other than cleaning should be performed at an authorized
Omega Service Center.
22. This appliance is for household use only. Do not use this appliance for anything other than
its intended use. Do not use in moving vehicles or boats. Do not use outdoors.
SAVE THESE INSTRUCTIONS
3
KNOW YOUR OMEGA
KNOW YOUR OMEGA
A
B
C
D
E
F
G
H
A Feeder Cap
B Lid
C Eastman Tritan™ Copolyester Container BPA-Free (64oz.-82oz)
D Blade Assembly
E Control Panel (controls vary based on model)
F Blender Base
G High Performance Motor
H Sturdy Nonslip Feet
5
OpERATING
INSTRUCTIONS
5
OpERATING INSTRUCTIONS
BEFORE FIRST USE
Before using your Omega Blender for the rst time, remove any packaging material and
promotional labels. Ensure the appliance is switched off at the power outlet and the
power cord is unplugged. Wash the lid, inner lid, Eastman Tritan™ Container and blade
assembly in warm, soapy water with a soft cloth. Rinse and dry thoroughly. Do not
place parts in the dishwasher (with the exception of the container, lid and inner lid). The
container lid and inner lid may be washed in the dishwasher. Ensure the blade assembly
has been removed from the container before placing the blender into the dishwasher.
The motor base can be wiped with a damp cloth. Dry thoroughly.
ASSEMBLING ThE BLENdER
1. To assemble the Eastman Tritan™ Container, place the silicon seal onto the blade assembly.
2. Insert the blade assembly into the container base.
3. Place the motor base on a at, dry surface. Ensure that the motor base is switched off
and the power cord is unplugged. Turn the blender container upright and insert on to
the motor base.
4. Plug the power cord into a power outlet. The handle of the container can be positioned
to the left or right hand side of the appliance.
dISASSEMBLING ThE BLENdER
1. Always ensure your Omega Blender is switched off. Then unplug the power cord.
2. Remove the container from the motor base by grasping the handle and lifting the
container in an upward direction. Remove the blade assembly by upturning the
container and twisting the blade removal clockwise, then lift upwards and away from
the base of the blender.
3. Remove the silicon seal from the blade assembly.
AUTOMATIC OvERLOAd pROTECTION
Your Omega motor is designed to protect itself from overheating. If the motor shuts OFF, turn
OFF the power switch for up to 45 minutes to reset. To reduce reset time unplug the machine,
remove the container and blow air into the center section.
7
USING YOUR
OMEGA BLENdER
5
USING YOUR OMEGA BLENdER
1. To turn the Omega blender on, switch to ON position.
NOTE: When using your Omega Blender for the rst time, you may notice an odor coming
from the motor. This is normal and will dissipate with use.
2. Add food or liquid into the Eastman Tritan™ Container ensuring not to exceed the
‘MAX’ mark.
3. Place the blender lid rmly into position on the top of the container. If not already in place,
insert the clear inner lid into the blender lid and turn clockwise or counterclockwise to
lock into position.
4. Turn your blender ON, or select a speed, depending on model. The blender will start to
operate. The speed can be changed at any time during the blending process.
5. To stop blending at any time, turn switch to OFF position or switch ‘OFF’.
6. At the end of use, always ensure your Omega Blender is turned off by pressing or
switching ‘OFF’. Then unplug the cord. Ensure the motor and blades have completely
stopped before attempting to move. Disassemble, clean, and store the appliance.
NOTE: During the blending process, ingredients may stick to the sides of the container.
To push the food back onto the blades, switch ‘OFF’ and remove the power cord.
Remove the lid and use a rubber spatula to scrape down the sides of the container.
Replace the lid before blending.
NOTE: If any moisture or liquid appears on top of the motor base during blending, switch
‘OFF’. Remove the Eastman Tritan™ Container. Wipe the motor base immediately with a
dry cloth or paper towelling. Check that the container is correctly assembled.
AdApTERS
1
2
On most models, the power cord comes
equipped with a three-prong (grounding)
plug which mates with a standard
three-prong wall outlet (Figure 1).
Please use approved 2 prong adapters
(Figure 2) when a ground is not available.
Do not cut or remove the round grounding
prong from the power cord.
9
EASY CLEANING
& CARING TIpS
5
EASY CLEANING & CARING TIpS
CLEANING
Do not put the container assembly & blender base assembly in the dishwasher.
1. Before rst use and after every use, separate container parts from the base.
2. Add cleaning solution to the container. Use water (less than 115°F/46°C) and a
non-sudsing detergent.
3. Scrub and ush out the container interior lid and feeder cap to remove food residue.
4. Empty container.
5. Fill container 1/4 full with fresh washing solution and place it on the base.
6. Replace the lid on the container and run the blender on high speed for 2 minutes.
7. Repeat step 5 using clean rinse water.
8. Wipe down the container, feeder cap, and lid with a soft cloth or sponge.
9. Wipe the exterior of the base with a damp cloth or sponge then dry thoroughly.
The base contains electrical components: do not immerse, use a high-pressure washer,
or use a dishwasher to clean the base.
10. Wipe any excess food particles from the power cord.
CARING TIpS
To care for your blender, please read the tips as follows:
1. Periodically check all parts before reassembly, as use of damaged or
non-recommended parts could result in a severe personal injury and/or damage to
the blender.
2. Blades: If the processing blades are stuck or difcult to turn, DO NOT USE BLENDER.
Unplug the blender. Check the blades by carefully turning in a counterclockwise
direction, where the opposite edges are sharp. Blades should turn freely.
3. Container: If the Eastman Tritan™ Container is cracked, DO NOT USE BLENDER, further
use could result in the container breakage during use.
4. Blender Base: Never immerse the blender base in water. Unplug unit. The housing can
be cleaned with a damp cloth.
5. Motor: The motor is permanently lubricated and does not require any additional
lubrication.
11
AddITIONAL USES
5
AddITIONAL USES
• Use for drinks or cocktail making, emulsions such as mayonnaise, dressings, marinades
and foods that require mixing until just combined, such as batters, also for pureeing
soups and aerating liquids.
• Use to blend fruits, ice cream and yoghurts into thick smoothies, whips and milkshakes.
• Use the Pulse function for foods that only require short bursts of power such as chopping
nuts and crushing ice.
• Use the Pulse function with short bursts of power, when blending drinks containing ice
cubes or frozen fruit.
• Ensure all foods are cut into cubes (approx. 1 inch square) where appropriate to
achieve an even result.
• Do not put more than 2 cups of warm ingredients into the Omega Blender before
blending commences. After the blending process has begun and the blades are
turning you may slowly add another 1½ cups of ingredients through the opening in the
lid if desired.
• Thick mixtures puree more efciently if the Omega Blender is ¼ to ½ full.
When using several ingredients, place liquid ingredients in the Eastman Tritan™ Container
•
before solid ingredients, unless specied in the recipe. When blending thick or dry mixtures it
may be necessary to stop your Omega blender and scrape down the sides of the container
with a plastic or rubber spatula, once or twice during blending. Do not use metal utensils as
they may damage the blades or blender.
13
CONTROL pANEL
5
CONTROL pANEL
OFF
LOW
HIGH
ON
OFF
HIGH
LOW
BL420
1
3
TIME
0
1
2
3
5
BL440
OFF
LOW
HIGH
PULSE
BL440
LOW
HIGH
64 & 82 oz – ON/OFF Switch – High/Low Switch
MOdELS: BL420/430
HIGH
LOW
ON
OFF
MOdELS: BL440/442/450/452
64 oz – OFF/LOW/HIGH Knob – Pulse Switch
LOW
OFF
MOdELS: BL460/470
64 & 82 oz – ON/OFF Switch – Variable Speed Knob – Pulse Switch
PULSE
HIGH
3
1
4
0
SPEED
PULSE
5
6
10
ON
7
8
9
OFF
MOdELS: BL480/490
64 & 82 oz – ON/OFF Switch – Variable Speed Knob – Timer Knob
5
2
1
0
TIME
4
0
SPEED
6
10
ON
7
8
9
OFF
3
3
1
5
15
BLAdE AGITATOR
ASSEMBLY
5
BLAdE AGITATOR ASSEMBLY
Use caution when handling the blade; it is sharp. Use a soft cloth to grab the blade when
inserting the blade assembly through the container.
1
The retainer nut is easily removed
using the disassembling tool (DT), sold
seperatly. Turn container upside down
and insert the disassembling tool on
the holes of the nut. Push the tool
counterclockwise to loosen nut (Step 1).
Once loosened, remove by hand.
2
To release the blade use the other end of
the DT while grabbing the gear backup
pliers and turn counterclockwise (Step 2)
17
MAINTENANCE
5
MAINTENANCE
Inspect the blender and its various parts and replace as follows:
dAILY
1. Unplug the blender and remove the container from the base.
2. Inspect the container blades for wear, nicks, and broken or loose blades.
Replace if necessary.
WEEKLY
1. Unplug the blender.
2. Inspect the power cord insulation and power plug for cracks.
QUARTERLY
1. Review the condition of the container assembly at least every 90 days.
2. Replace if necessary.
REpLACEMENT pARTS
For replacement parts call Customer Service: 1-800-633-3401
19
TROUBLEShOOTING
5
TROUBLEShOOTING
LOUd NOISE FROM ThE EASTMAN TRITAN™ CONTAINER
PROBLEM: Container blades do not spin.
SOLUTION: Broken or worn drive socket. Replace dive socket.
PROBLEM: Increased Vibration.
SOLUTION: Check blade assembly for damaged components and replace.
PROBLEM: Leaking from bottom of container.
SOLUTION: Tighten retainer nut on the bottom of the container.
MAChINE STARTS ThEN ShUTS OFF
PROBLEM: Motor
SOLUTION: Depress reset button.
PROBLEM: Reset button.
SOLUTION: Call Customer Service: 1-800-633-3401
PROBLEM: Power Failure.
SOLUTION: Check to make sure there is power to the machine.
PROBLEM: Power supply cord damage.
SOLUTION: Check the power supply cord and the connection to the power outlet.
pOSSIBLE pROBLEMS ANd EASY SOLUTIONS
POSSIBLE PROBLEM: Motor doesn’t start or blade doesn’t rotate.
EASY SOLUTION:
• Check that the container and lid are securely locked into position.
• Check that the blade assembly is correctly attached to the base of the container.
• Check that the ‘Power’ switch and selected function or speed setting is ‘ON’.
• Check that the power plug is securely inserted into the power outlet.
POSSIBLE PROBLEM: Food is unevenly chopped
EASY SOLUTION: Either too much food is being blended at one time or the pieces
are too large. Try cutting food into smaller pieces of even size and
processing a smaller amount per batch. For best results, the food
should be chopped into pieces no larger than ¾ inch.
POSSIBLE PROBLEM: Food is chopped too ne or is watery.
EASY SOLUTION: The food is over processed. Try using the Pulse function or process
for a shorter time.
POSSIBLE PROBLEM: Food sticks to blades and container.
EASY SOLUTION: The mixture may be too thick. Try adding more liquid to the mixture
and/or use another function.
CONTACT US:
Customer Service: 1-800-633-3401
Online: www.OmegaJuicers.com/contact-omega-juicers
21
pROdUCT SpECIFICATIONS
5
pROdUCT SpECIFICATIONS
Product Name BL400 Series
Model Name USA BL420/BL440/BL460/BL480/BL490
Rated Voltage 120 V
Rated Frequency 50-60 Hz
Amps 11.5
Motor 3 Peak Horsepower
Weight 15 lb. (6.8kg)
Outward Dimension 17.55” Width (440 mm)
9” Depth (250 mm)
(BL420/BL480/BL460) 18.25” Height (350 mm)
(BL430/BL490/BL492/BL470) 20.25” Height (513 mm)
Also Available International 220 V / 50-60 Hz
BL482/BL492
BL420/430 BL460/470 BL480/490
23
NOTES & RECIpES
NOTES
For Recipes, visit www.OmegaJuicers.com/recipes
25
RECIpES
Strawberry Daiquiry
What You’ll Need:
How To Prepare:
:
5-10 strawberries (to taste)
2 oz light rum
1/2 oz triple sec
1 oz lime juice
1/2 tsp sugar
BLEND
2 minutes 2 minutes 2 minutes
PREP
1 cup ice
CHILL
1
Blend all ingredients in Omega Blender at
speed 9, setting the timer for 2 minutes.
2
Pour into a chilled glass. Serve.
Fruity Ice Cream
What You’ll Need:
How To Prepare:
2 cups frozen fruit
(bananas, strawberries,
blueberries, etc.)
1/2 cup of sugar
1 cup heavy cream
BLEND
5 minutes 5 minutes 30 minutesPREP
CHILL
1
Start by adding the fruit to the blender.
Add the sugar and 1/4 cup of the cream.
Blend all ingredients at speed 7, setting
the timer for 4 to 5 minutes
2
While blending, slowly add more of the
cream through the removeable cap on
the lid. Add more cream if the mixture
doesn’t meet your desired consistency.
3
Freeze the mixture for at least 30 minutes.
HINT: For banana ice cream, use overripe bananas
that are about to go bad, slice them, put them in the
freezer and use them for banana ice cream!
Coco-Nilla Ice “Cream”
What You’ll Need:
2 cups Coconut Milk (canned or fresh)
2 tbsp maple syrup, honey or agave
How To Prepare:
1
Blend all ingredients at speed 7, setting
the timer for 4 to 6 minutes.
2 tsp vanilla extract
2
Fruit (optional)
Freeze the mixture for at least 2 hours,
stirring every 20 to 30 minutes.
Dairy-free recipe!
BLEND
3 minutes 6 minutesPREP
FREEZE
2 hours
Cinnamon Apple Sauce
What You’ll Need:
How To Prepare:
6 apples, cored, peeled, quartered
2 tbsp lemon juice
2 tbsp cinnamon
BLEND
5 minutes 3 minutes
PREP
1
Blend all ingredients in the Omega
blender until it meets your desired
consistency.
2
Omega recommends setting the blender
at speed 7 for 3 minutes.
27
RECIpES
Pumpkin Spice Soup
What You’ll Need:
4 tbsp olive oil
2 medium yellow onions,
(sliced in quarters)
2 tsp garlic
6 cups of sliced roasted pumpkin
5 cups chicken stock
2 cups milk
1/2 cup heavy (35%) cream
1/4 tsp cayenne pepper to taste
2 tsp curry powder
1/2 tsp ground coriander
salt (if desired)
brown sugar (if desired for sweetness)
BLEND COOK
20 minutes 8-10 minutes 15 minutesPREP
How To Prepare:
1
Add oil, onions, garlic and salt to the Omega
blender. Set the blender on speed 6 and the
timer for 2 to 3 minutes, until they are nely
chopped. Transfer to stovetop and cook on
low until onions are soft.
2
In the meantime, blend pumpkin and chicken
stock. Pour into pot with oil, onions, garlic and
salt. Bring to a low boil. Simmer for 10 minutes.
3
Pour the mixture into the blender while warm.
Set the blender on speed 7 for 5 minutes.
Add the remaining ingredients through the
removeable cap on the lid. The mixture should
be close to a puree texture.
4
Pour the mixture into the stovetop pot. Heat
and allow to simmer for 5 minutes as avors mix.
Serve hot or cold.
Chocolate Mousse
What You’ll Need:
How To Prepare:
1/2 cup milk
1 cup heavy cream
2 tps butter
1/2 tsp instant coffee
2 eggs
6 oz chocolate chips
2 tps rum, cognac or brandy
1 tsp powdered sugar
BLEND
10 minutes 5 minutesPREP
1
Beat 1/2 cup milk and 1/2 cup cream
on stove top until it bubbles. Do not let
it burn.
2
In your Omega blender add butter,
eggs, coffee, chocolate chips, and
liquor. Blend until creamy. While
blending, slowly add hot milk and
cream.
3
Blend until smooth, setting the timer at
1 to 2 minutes and the speed at 4. Pour
into a pan. Chill for at least an hour.
4
Beat remaning cream and powedered
sugar into smooth mixture and chill.
Serve on top.
Chili Salsa
What You’ll Need:
1 (14.5 oz can) whole canned tomatoes
4 tsp jalapeños (diced, not pickled)
2 chili peppers
1/4 cup yellow onions (diced)
1/2-3/4 tsp garlic salt
1/2 tsp cumin
1/4 tsp sugar
How To Prepare:
1
In the Omega blender, place jalapeños, chili
peppers and onions. Remember, the heat of
chili peppers comes from the seeds, the veins
where the seeds are attached, as well as,
the parts nearest the veins. For milder dishes,
the veins and seeds should be removed and
discarded.
2
Blend for a few seconds on speed 6.
Add both cans of tomatoes, salt, sugar,
and cumin.
3
Blend all ingredients on speed 4 or 5, setting
the timer for 1 to 2 minutes. Do not pure.
4
Place in covered container and chill for 1
BLEND
2 minutes 4 minutes 60 minutesPREP
CHILL
hour and serve.
Honey Wheat Pancakes
What You’ll Need:
How To Prepare:
1-1/3 cups buttermilk (low-fat)
2 eggs
2 tbsp honey
1-1/2 cups buttermilk baking mix
1/2 cup whole-wheat our
1/4 cup honey-crunch wheat gem
1 tsp baking powder
butter and syrup for serving
BLEND COOK
3 minutes 6 minutes 4 minutesPREP
1
Place the buttermilk, eggs and honey
in the Omega blender. Set the speed
to 6, and the timer to 6 minutes. Then
begin adding the remaining ingredients
into the Omega blender in the order
given through the removable cap on
the container lid.
2
Once the mixture is blended to your
desired consistency, shut off the
blender.
3
For each pancake, pour about 1/4 cup
batter onto a skillet.
29
Nourish Your Body
Enrich Your Soul
Discover the complete line of Omega brand professional products at
www.OmegaJuicers.com
6291 Lyters Lane • Harrisburg, PA 17111, USA • T: 1.800.633.3401 • F: 717.561.1298
Loading...
