Omega 657 User guide

5/16 [7.925]

[3.81]

2-15/32 [62.60]

[88.90]

1-11/32 [34.15]

SERIES 657

5-1/8

[67.07]

RELATIVE HUMIDITY/TEMPERATURE TRANSMITTERS

Dual Channel Design for Simultaneous 4-20 mA Output Signals

CALIBRATION SERVICES AVAILABLE

2-13/32

[60.96]

2-23/32

1/2 [12.70]

[68.88]

7/8

[22.23]

SPECIFICATIONS
Service: Drycleanair.

Range: Relativehumidity:0to100%;Temperature:32to212°F(0to100°C).
Accuracy: Relativehumidity:±2%(10to90%RH),±3%(0to10%and90to100%

RH);Temperature±1°F(0.5°C).

Temperature Limits: 32to140°F(0to60°C).
Pressure Limits: 1psi(.07bar).
Compensated Temperature Range: 32to140°F(0to60°C).
Power Requirements:10-35VDC.
Output Signal:2channelseach4-20mA.LooppoweredontheRHchannel.
Electrical Connections: 4 screw type terminals.
Mounting Orientation: Mount in any position.
Probe: 657-1:SS5/16˝x10˝(0.8x25.4cm);657C-1:5/16˝x9-1/10˝(0.8x23.1

cm).

Weight: 657-1:5.5oz(156g);657C-1:10oz(284g).

ACCESSORIES
Model Description
A-158

Splitange

A-159

Mounting gland

657 657C

The Series 657 Relative Humidity/Temperature Transmitters provide two
4-20 mA channels to produce separate output signals for both relative humidity
and temperature. These devices deliver ±2% accuracy for humidity and ±1°F for
temperature measurements. Stainless steel probe can be easily mounted to most
ductwork using either of the two optional kits below.

BENEFITS/FEATURES

• PolymerlmhumidityandthinlmRTDtemperaturesensorsofferhighlyreliableand

stable measurements.

• Remotemounthousingoffersinstallationexibility(657-1)

• Ruggeddie-castaluminumhousingisgreatforindustrialapplications(657C-1)

APPLICATIONS

• Cleanroommonitoring

•HVAC/buildingcontrolmonitoring

MODEL CHART
Model Description
657-1

RH/temperaturetransmitter

657C-1

RH/temperaturetransmitter-conduithousing

OPTIONS
To order add sufx: Description

-NIST NISTtraceablehumiditycalibrationcerticate

Example: 657C-1-NIST

5/32

1-1/2

[38.10]

2-1/4 [57.15]

11-7/8 [302]

4-13/32

3-1/2

1-5/32 [29.35]

[112.0]

3-5/8
[92.4]

A-158 A-159

9-1/10 [231]

1/2 NPT

DWYERINSTRUMENTS,LLC|dwyer-inst.com

Humidity/Temperature

Transmitters

225
