Series
4-9/16
[115.8]
17/32
[13.5]
3-25/32
[95.9]
3-19/32
[91.3]
3-25/32
[95.9]
1/4 [6.53] MAXIMUM PANEL
THICKNESS
2600
Temperature/Process Controller
1/4 DIN Self-Tune PID, Fuzzy Logic Software
Series 2600 Temperature/Process Controllers set a new standard for
quality, versatility, ease-of-use and value. While they include a high level of
standard features, many function setup
only when the function is
unnecessary items.
K, E, T, L, N, B, C, S & R; RTDs 100Ω Plt. NIST, 100Ω Plt. DIN,
Industrial, 1000Ω Plt. DIN; differential input (-10 to +10 mV
(0 to 20 mA DC, 0 to 10 VDC). A standard 24 Volt isolated, regulated power supply
is included to operate most standard 4-20 mA transmitters.
Standard features include Self-Tune, Fuzzy Logic, fully adjustable
Auto/Manual control with bumpless transfer and front panel activation key,
percent output indication, peak and valley indication, loop break protection and
indication. For process inputs, the display is fully programmable from -1999 to
+9999 with selectable decimal point location. Most thermocouple and RTD
inputs can show whole or tenth degree displays. The Series 2600 is available
with single or dual setpoint outputs and can be programmed for
heat/cool or latching alarm. All outputs are isolated from the inputs. Outputs
include 10 Amp relay, and 0-20 mA DC (scalable).
Alarm
Model
TEMPERATURE
OPTIONS (Add to end of model number)
-924, Remote Set Point 0 to 10 VDC
-926, Remote Set Point 0 to 20 mA
-928, Remote Set Point 0 to 10 K Ohms
-934, Process Signal Output, Non-Isolated 0 to 20 mADC
-936, Process Signal Output, Non-Isolated 0 to 10 VDC
Controllers
-992, RS-XXX Serial Communications Love Link™ Protocol
-993, RS-XXX Serial Communications Love Link™ Protocol
Temperature/Process
-995, RS-XXX Serial Communications Modbus®RTV Protocol
-996, RS-XXX Serial Communications Modbus®RTV Protocol
26130
26150
26133
Yes
Yes
Yes
Units feature a universal input for thermocouple types J,
Output A
Relay
Current
Relay
selected, so you don’t have to wade through
items appear in the control menu
DC) and process input
on-off, PID or
Output B
None
None
Relay
120Ω Ni
PID,
MORE STANDARD FEATURES
• NEMA 4X (IP65) front panel resists dust and moisture
• Four password protected security levels
• Front panel programmability
• 16 segments of ramp/soak with program end control
• Operates on 100-240 VAC, 132-240 VDC
SPECIFICATIONS
Selectable Inputs: Thermocouple, RTD, DC voltage or DC current.
Input Impedance:
Thermocouple: 3 Megohms minimum;
Voltage: 5000 ohms;
Current: 10 ohms;
RTD current: 200 µA maximum.
Display: Two 4 digit, 7 segment, 0.56˝ (14.2 mm) high LED.
Accuracy: ±0.25% of span, ±1 least significant digit.
Supply Voltage: 100 to 240 VAC nominal, +10%-15%, 50 to 400 Hz,
single phase; 132 to 240 VDC +10% -20%.
Operating Temperature: 14 to 131°F (-10 to 55°C).
Control Output Ratings: Relay: SPDT,10A @ 240 VAC resistive, 1/2
hp @ 120 VAC, 1/3 hp @ 240 VAC; Alarm relay: SPST, 3A @ 240 VAC
resistive; Proportional current: 0-20 mA DC, scalable into 600 ohms
maximum.
Weight: 13 oz (369 g).
Front Panel Rating: NEMA 4X (IP66).
ACCESSORIES
MN-1, Mini-Node
LoveLinks III, Configuration software
A-600, R/C snubber
™
USB/RS-485 converter
262
Modbus® is a registered trademark of Schnieder Automation, Inc.
VISIT OUR WEBSITES: www.dwyer-inst.com • www.dwyer-inst.co.uk • www.dwyer-inst.com.au
