Omcan RS-CN-0044, RS-CN-0064, RS-CN-0104, RS-CN-0084 Service Manual

Refrigerated Sushi Showcases

Models RS-CN-0044*, 0064, 0084, 0104

Items 43492*, 44393, 44394, 44395

Instruction Manual

Revised - 06/29/2018

Toll Free: 1-800-465-0234

Fax: 905-607-0234

Email: service@omcan.com

www.omcan.com

*

Table of Contents

Model RS-CN-0044 / Model RS-CN-0064 Model RS-CN-0084 / Model RS-CN-0104

Section

General Information

Safety and Warranty

Technical Specications

Operation

Maintenance

Troubleshooting

----------------------------------------------------------------------------------------- 7 - 8

----------------------------------------------------------------------------------------- 9

--------------------------------------------------------------------------- 3 - 4

--------------------------------------------------------------------------- 4 - 6

------------------------------------------------------------------------------- 9 - 10

Page

-------------------------------------------------------------------------- 7

Parts Breakdown

Electrical Schematics

Notes

Warranty Registration

------------------------------------------------------------------------------------------- 20 - 22

---------------------------------------------------------------------------- 11 - 18

---------------------------------------------------------------------------- 19

---------------------------------------------------------------------------- 23

2

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the external packaging, open carton to ensure all ordered items are within the box, and there is no concealed

damage to the machine. If the package has su󰀨ered rough handling, bumps or damage (visible or concealed),

please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Before operating any equipment, always read and familiarize yourself with all operation and safety

instructions.

Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save these instructions for future reference. Also save the original box and packaging for shipping the

equipment if servicing or returning of the machine is required.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises

manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

3

General Information

Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations et les consignes de sécurité.

Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces

instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour

l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada. Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de

funcionamiento y seguridad.

Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el

envío del equipo si servicio técnico o devolución de la máquina que se requiere.

Safety and Warranty

1. A high quality, fully enclosed compressor is used in this product and utilises the R134a or R600a refrigerant which is an environmentally friendly gas. A forced air refrigeration system is used which ensures that the temperature is very even throughout the ease.

2. Glazing is used throughout the product for maximum visibility and two rear mounted sliding doors allow easy access.

3. The horizontal showcase has a wide range of uses including convenience stores, bakery outlets and other food service establishments as well as o󰀩ces and even homes.

4

Safety and Warranty

4. Always allow a time of around 2 hours between moving the unit and restarting it.

HANDLING AND PLACEMENT

• Handle with care.

Unplug the wall socket rst. Never tilt it over 45 degree during handling.

• Dry place. Always locate the refrigerator at a dry place.

• Su󰀩cient space.

The distance from both sides and back of refrigerator to wall or other substance must not less than 10cm.

The refrigeration capability might be decreased if its surround space is too small to circulate air.

• Well ventilation.

Always locate the refrigerator at a place with ne ventilation. For the rst time use, wait for 2 hours after

handling and then plug the wall socket and start it.

• Far from heat source.

Never place the refrigerator directly under the sunshine. Never locate it nearby any heat source or heater

to prevent it from reducing refrigeration capability.

• No heavy load.

Never put any heavy load on the top of the refrigerator.

• No hole making.

Never make hole on the refrigerator. Never install other matter on the refrigerator.

• Stable location.

Unpacking and locate the refrigerator on a at and solid place.

• Exclusive power socket.

Normally, the power supply should be 220-240V, single phase AC with exclusive single phase three pin receptacle (250V 10A) and fuse (6A). The power receptacle must have a reliable earth connection.

• No share on socket.

Never let the refrigerator share the common socket with other appliance, otherwise the cable becomes hot and re might be resulted.

• Protect cables.

Never break or damage the cables otherwise current leakage and re might be resulted.

• No water ushing.

Never give the refrigerator surface a ush otherwise current leakage might be resulted.

• Prevent from ammables and explosive.

Never put any ammable or explosive inside the refrigerator such as ether, gasoline, alcohol, adhesive and explosive. Never put dangerous product nearby the refrigerator.

• No spray.

To spray the ammables such as paint or coating nearby the refrigerator is not allowed, otherwise re might

be resulted.

• After power break.

After power break or unplugging the refrigerator, always wail at least 5 minutes and then you may plug the

refrigerator and start it again.

• No medicine.

No medicine is allowed to keep inside the refrigerator.

5

Safety and Warranty

1 YEAR PARTS AND LABOUR BENCH WARRANTY

Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop o󰀨 to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the

equipment.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not

improper use.

Please see www.omcan.com/warranty.html for complete info.

WARNING:

The packaging components are classied as normal solid urban waste and can therefore be disposed of without di󰀩culty.

In any case, for suitable recycling, we suggest disposing of the products separately (di󰀨erentiated waste) according to the current norms.

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

6

Technical Specications

Model RS-CN-0044 RS-CN-0064 RS-CN-0084 RS-CN-0104 Capacity 44 L / 1.55 cu. ft. 64 L / 2.26 cu. ft. 84 L / 2.96 cu. ft. 104 L / 3.67 cu. ft. Number of Pans 4 x 1/3 GN 5 x 1/3 GN 6 x 1/3 GN 5 x 1/2 GN Coolant and

Injection Quantity General Rated Input

Power

Rated Current 1.2A Refrigeration

Temperature

Electric Shock

Protection Class Type of Climate 3

Lamp Power 3W (LED)

Net Weight 86 lbs. / 39 kgs. 94.8 lbs. / 43 kgs. 103.6 lbs. / 47 kgs. 116.8 lbs. / 53 kgs. Rated Voltage 110V~ 60Hz Foaming Agent C5H10

Overall Dimensions

Item Number 43492 44393 44394 44395

44.5” x 15.6” x 14.8”

1131 x 395 x 375mm

51.5” x 15.6” x 14.8”

1307 x 395 x 375mm

R134a (70g)

160W

0 - 12°C / 32 - 53.6°F

I

58.4” x 15.6” x 14.8”

1483 x 395 x 375mm

69.1” x 15.6” x 14.8”

1754 x 395 x 375mm

Operation

BEFORE USE

Plug the fridge in to an exclusive 110V~ socket. Once the fridge has been running place your hand on the air extractor to conrm that it is su󰀩ciently cold once you are happy then you may put food inside.

DIGITAL TEMPERATURE CONTROLLER

FEATURES OF FUNCTION

- It is a mini-sized and integrated intelligent controller and applicable to the compressor of one HP. The

main functions are: Temperature Display, Temperature Control, Manual/Automatic Defrost by Burning O󰀨, Illumination Control, Value Storing, Self Testing, Parameter Locking.

7

Operation

FRONT PANEL OPERATION

1. Set temperature: Press the “SET” button, the set temperature is displayed. Press or button to modify and store the displayed value.

Press the “SET” button to exit the adjustment and display the cold-room temperature.

2. If no more button is pressed within 10 seconds, the cold-room temperature will be displayed.

3. Illumination: Press the button, it lights; Press again, it stops. Manual Start/Stop Defrost: Press the button and hold for 6 seconds to defrost or stop defrost.

4. Refrigerant LED: During refrigeration, the LED is on; When the cold room temp. is constant, the LED is o󰀨; During the delay start, the LED ashes.

5. Defrost LED: during defrosting, the LED is on; When is stops defrosting, the LED is o󰀨, During the delay display of defrost, the LED ashes.

SAFETY WARNINGS

• When opening the door try to reduce the length of time that it is open for in order to keep the temperature

inside cold.

• Do not overload the unit food as it will a󰀨ect the cooling ability.

• Always cool hot food down to room temperature before placing it in the fridge.

• The unit should only be maintained by a professional engineer.

• Never touch the compressor as it may be hot and burn you.

• If the power cord is damaged it must be replaced by the manufacturer or a professional engineer.

• Children should be supervised at all times to ensure they are not hurt by the unit.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

WARNING: Keep ventilation openings clear of obstruction at all times. WARNING: Do not use mechanical devices or any other means of accelerated defrosting unless recommended by the manufacturer. WARNING: Do not damage or modify the refrigeration circuit. WARNING: Do not use electrical appliances inside the food storage areas unless they are recommended by the manufacturer.

ADDITIONAL WARNING:

Caution: Risk of re. The height of the triangle in the symbol shall be at least 15mm.

8

Maintenance

- Often keep the refrigerator clean and periodical maintenance is necessary.

- Always unplug the socket before maintenance.

- Never use damaged plug or loose socket to prevent from electric shock or short circuit.

- Never ush the refrigerator. Never use alkali detergent, soap, gasoline, acetone or brush.

CLEANING

1. Clean outside

- Moisten soft cloth in a mild detergent solution to clean the outside, and then wipe o󰀨 with a dry soft cloth.

2. Clean inside

- Remove the tray and clean with water.

- Use a soft, damn cloth to wipe the interior.

3. Turning o󰀨 for prolonged periods

- Take out all food and unplug the unit from the wall.

- Clean both the inside and outside of the fridge thoroughly and open the door to allow it to dry.

- Be careful as the glass can easily be broken.

4. Replacement of the light

- If the LED is damaged it must be replaced by the manufacturer or their service agent.

Troubleshooting

Trouble Cause Remedy

Unit not cooling. Is the plug in the socket correctly? Check the plug.

Is the fuse blown? Check fuse and replace if needed. Is there no power from the socket? Plug another unit into the socket to

check if it works.

Unit not cooling enough. Is it in direct sunlight or near a heat

source? Is the surrounding area bad for

ventilation? Does the door close correctly? Is

the door left open? Is the unit too full? Remove some food. Is the temperature controller set

correctly?

Move away from the heat source.

Move to an area with improved

ventilation.

Check the door.

Check the controller.

9

Troubleshooting

Loud operation noise. The fridge is not sitting level. Move to a at surface.

The fridge is vibrating against something else.

There is loose part in the refrigerator.

Contact your local Omcan Service Agent for help if simple trouble shooting does not solve the problems.

REFERENCE

Item Number Model Number Description Manufacturer Model Number

43492 RS-CN-0044

44393 RS-CN-0064

44394 RS-CN-0084

44395 RS-CN-0104

Refrigerated Showcase Sushi with Square

Glass 44 L / 1.55 cu ft 110V/60/1 QPS

Refrigerated Showcase Sushi with Square

Glass 64 L / 2.26 cu ft 110V/60/1

Refrigerated Showcase Sushi with Square

Glass 84 L / 2.96 cu ft 110V/60/1

Refrigerated Showcase Sushi with Square

Glass 104 L / 3.67 cu ft 110V/60/1

Move the unit so it is not touching

anything.

Check the interior for loose parts

and tighten.

RTS-44L

RTS-64L

RTS-84L

RTS-104L

10

Model RS-CN-0044 43492

Parts Breakdown

11

Parts Breakdown

Model RS-CN-0044 43492

Item No. Description Position Item No. Description Position Item No. Description Position

66232 Handle for RTS-44L 1 66245 Left Side Glass for RTS-44L 19 66255 Median Septum for RTS-44L 38

66233 Door Glass for RTS-44L 2 60105 Water Discharge Pipe for RTS-44L 20 60756 14mm Protecting Coil for RTS-44L 39

66234 A-Type Sealing Strip for RTS-44L 3 60106 Bottom Panel for RTS-44L 21 66256

66235 Upper Pillar for RTS-44L 4 66246 Front Pillar for RTS-44L 23 66257 Right Side Glass for RTS-44L 41

66236 LED for RTS-44L 5 66247

60101 Decorating Gasket of Nut for RTS-44L 6 66248 Back Board for RTS-44L 25 66259 12mm Protective Ring for RTS-44L 43

60102 Nut Decorating Parts for RTS-44L 7 60125 Digital Controller Holder for RTS-44L 26 60138 Compressor for RTS-44L 44

60103 Big Gasket of Nut for RTS-44L 8 70105 Switch for RTS-44L 27 66260 Compressor Base Board for RTS-44L 45

66237 Upper Glass for RTS-44L 9 60126 Fan Motor for RTS-44L 28 60115 Power Cord for RTS-44L 46

66238 Fixed Angle for RTS-44L 10 66249 Condenser Backplate for RTS-44L 29 60117 Base of Cable Clip for RTS-44L 47

66239 Glass Bracket for RTS-44L 11 60135 Condenser for RTS-44L 30 60116 Cover of Cable Clip for RTS-44L 48

66240 Front Glass for RTS-44L 12 60134 Square Gasket for RTS-44L 31 60144 Dry Filter for RTS-44L 49

66241 Glass Shelf for RTS-44L 13 66250 Joint Pipe for RTS-44L 32 60143 Filling Pipe for RTS-44L 50

66242 Back Pillar for RTS-44L 14 66251 Right Support for Glass Shelf for RTS-44L 33 60145 #6 Driver for RTS-44L 51

60098 1/3 GN Pan for RTS-44L 15 60114 5mm Protective Ring for RTS-44L 34 60137 Controller Box for RTS-44L 52

60104 Foam Material for RTS-44L 16 66252 Cover of Median Septum for RTS-44L 35 60136 Controller Panel for RTS-44L 53

66243 Left Side Plate for RTS-44L 17 66253

66244 Left Support for Glass Shelf for RTS-44L 18 66254 Support of Median Septum for RTS-44L 37

Temperature Controller Assembly for RTS-44L

EVA Cotton of Median Septum for RTS-44L

24 66258 Right Side Plate for RTS-44L 42

36

Fixed Plate of Median Septum for RTS-44L

40

12

Model RS-CN-0064 44393

Parts Breakdown

13

Parts Breakdown

Model RS-CN-0064 44393

Item No. Description Position Item No. Description Position Item No. Description Position

66232 Handle for RTS-64L 1 66245 Left Side Glass for RTS-64L 19 66255 Median Septum for RTS-64L 38

66261 Door Glass for RTS-64L 2 60105 Water Discharge Pipe for RTS-64L 20 60756 14mm Protecting Coil for RTS-64L 39

66234 A-Type Sealing Strip for RTS-64L 3 60154 Bottom Panel for RTS-64L 21 66256

66262 Upper Pillar for RTS-64L 4 66267 Front Pillar for RTS-64L 23 66257 Right Side Glass for RTS-64L 41

66236 LED for RTS-64L 5 66247

60101 Decorating Gasket of Nut for RTS-64L 6 66248 Back Board for RTS-64L 25 66259 12mm Protective Ring for RTS-64L 43

60102 Nut Decorating Parts for RTS-64L 7 60125 Digital Controller Holder for RTS-64L 26 60138 Compressor for RTS-64L 44

60103 Big Gasket of Nut for RTS-64L 8 70105 Switch for RTS-64L 27 66260 Compressor Base Board for RTS-64L 45

66263 Upper Glass for RTS-64L 9 60126 Fan Motor for RTS-64L 28 60115 Power Cord for RTS-64L 46

66238 Fixed Angle for RTS-64L 10 66249 Condenser Backplate for RTS-64L 29 60117 Base of Cable Clip for RTS-64L 47

66239 Glass Bracket for RTS-64L 11 60135 Condenser for RTS-64L 30 60116 Cover of Cable Clip for RTS-64L 48

66264 Front Glass for RTS-64L 12 60134 Square Gasket for RTS-64L 31 60144 Dry Filter for RTS-64L 49

66265 Glass Shelf for RTS-64L 13 66250 Joint Pipe for RTS-64L 32 60143 Filling Pipe for RTS-64L 50

66266 Back Pillar for RTS-64L 14 66251 Right Support for Glass Shelf for RTS-64L 33 60145 #6 Driver for RTS-64L 51

60098 1/3 GN Pan for RTS-64L 15 60114 5mm Protective Ring for RTS-64L 34 60137 Controller Box for RTS-64L 52

60153 Foam Material for RTS-64L 16 66252 Cover of Median Septum for RTS-64L 35 60136 Controller Panel for RTS-64L 53

66243 Left Side Plate for RTS-64L 17 66253

66244 Left Support for Glass Shelf for RTS-64L 18 66254 Support of Median Septum for RTS-64L 37

Temperature Controller Assembly for RTS-64L

EVA Cotton of Median Septum for RTS-64L

24 66258 Right Side Plate for RTS-64L 42

36

Fixed Plate of Median Septum for RTS-64L

40

14

Model RS-CN-0084 44394

Parts Breakdown

15

Parts Breakdown

Model RS-CN-0084 44394

Item No. Description Position Item No. Description Position Item No. Description Position

66232 Handle for RTS-84L 1 66245 Left Side Glass for RTS-84L 19 66255 Median Septum for RTS-84L 38

66268 Door Glass for RTS-84L 2 60105 Water Discharge Pipe for RTS-84L 20 60756 14mm Protecting Coil for RTS-84L 39

66234 A-Type Sealing Strip for RTS-84L 3 60167 Bottom Panel for RTS-84L 21 66256

66269 Upper Pillar for RTS-84L 4 66275 Front Pillar for RTS-84L 23 66257 Right Side Glass for RTS-84L 41

66270 LED for RTS-84L 5 66247

60101 Decorating Gasket of Nut for RTS-84L 6 66248 Back Board for RTS-84L 25 66259 12mm Protective Ring for RTS-84L 43

60102 Nut Decorating Parts for RTS-84L 7 60125 Digital Controller Holder for RTS-84L 26 60138 Compressor for RTS-84L 44

60103 Big Gasket of Nut for RTS-84L 8 70105 Switch for RTS-84L 27 66260 Compressor Base Board for RTS-84L 45

66271 Upper Glass for RTS-84L 9 60126 Fan Motor for RTS-84L 28 60115 Power Cord for RTS-84L 46

66238 Fixed Angle for RTS-84L 10 66249 Condenser Backplate for RTS-84L 29 60117 Base of Cable Clip for RTS-84L 47

66239 Glass Bracket for RTS-84L 11 60135 Condenser for RTS-84L 30 60116 Cover of Cable Clip for RTS-84L 48

66272 Front Glass for RTS-84L 12 60134 Square Gasket for RTS-84L 31 60144 Dry Filter for RTS-84L 49

66273 Glass Shelf for RTS-84L 13 66250 Joint Pipe for RTS-84L 32 60143 Filling Pipe for RTS-84L 50

66274 Back Pillar for RTS-84L 14 66251 Right Support for Glass Shelf for RTS-84L 33 60145 #6 Driver for RTS-84L 51

60098 1/3 GN Pan for RTS-84L 15 60114 5mm Protective Ring for RTS-84L 34 60137 Controller Box for RTS-84L 52

60166 Foam Material for RTS-84L 16 66252 Cover of Median Septum for RTS-84L 35 60136 Controller Panel for RTS-84L 53

66243 Left Side Plate for RTS-84L 17 66253

66244 Left Support for Glass Shelf for RTS-84L 18 66254 Support of Median Septum for RTS-84L 37

Temperature Controller Assembly for RTS-84L

EVA Cotton of Median Septum for RTS-84L

24 66258 Right Side Plate for RTS-84L 42

36

Fixed Plate of Median Septum for RTS-84L

40

16

Model RS-CN-0104 44395

Parts Breakdown

17

Parts Breakdown

Model RS-CN-0104 44395

Item No. Description Position Item No. Description Position Item No. Description Position

66232 Handle for RTS-104L 1 66245 Left Side Glass for RTS-104L 19 66254 Support of Median Septum for RTS-104L 37

66276 Door Glass for RTS-104L 2 60105 Water Discharge Pipe for RTS-104L 20 66255 Median Septum for RTS-104L 38

66234 A-Type Sealing Strip for RTS-104L 3 60180 Bottom Panel for RTS-104L 21 60756 14mm Protecting Coil for RTS-104L 39

66277 Upper Pillar for RTS-104L 4 60181 Adjustable Feet for RTS-104L 22 66256

66278 LED for RTS-104L 5 66283 Front Pillar for RTS-104L 23 66257 Right Side Glass for RTS-104L 41

60101 Decorating Gasket of Nut for RTS-104L 6 66247

60102 Nut Decorating Parts for RTS-104L 7 66248 Back Board for RTS-104L 25 66259 12mm Protective Ring for RTS-104L 43

60103 Big Gasket of Nut for RTS-104L 8 60125 Digital Controller Holder for RTS-104L 26 60138 Compressor for RTS-104L 44

66279 Upper Glass for RTS-104L 9 70105 Switch for RTS-104L 27 66260 Compressor Base Board for RTS-104L 45

66238 Fixed Angle for RTS-104L 10 60126 Fan Motor for RTS-104L 28 60115 Power Cord for RTS-104L 46

66239 Glass Bracket for RTS-104L 11 66249 Condenser Backplate for RTS-104L 29 60117 Base of Cable Clip for RTS-104L 47

66280 Front Glass for RTS-104L 12 60135 Condenser for RTS-104L 30 60116 Cover of Cable Clip for RTS-104L 48

66281 Glass Shelf for RTS-104L 13 60134 Square Gasket for RTS-104L 31 60144 Dry Filter for RTS-104L 49

66282 Back Pillar for RTS-104L 14 66250 Joint Pipe for RTS-104L 32 60143 Filling Pipe for RTS-104L 50

60178 1/2 GN Pan for RTS-104L 15 66251

60179 Foam Material for RTS-104L 16 60114 5mm Protective Ring for RTS-104L 34 60137 Controller Box for RTS-104L 52

66243 Left Side Plate for RTS-104L 17 66252 Cover of Median Septum for RTS-104L 35 60136 Controller Panel for RTS-104L 53

66244

Left Support for Glass Shelf for RTS104L

18 66253

Temperature Controller Assembly for RTS-104L

Right Support for Glass Shelf for RTS-104L

EVA Cotton of Median Septum for RTS-104L

24 66258 Right Side Plate for RTS-104L 42

33 66284 #5 Driver for RTS-104L 51

36

Fixed Plate of Median Septum for RTS-104L

40

18

Model RS-CN-0044 43492 Model RS-CN-0064 44393 Model RS-CN-0084 44394 Model RS-CN-0104 44395

Electrical Schematics

19

Notes

________________________________________________________________________________________

20

Notes

________________________________________________________________________________________

21

Notes

________________________________________________________________________________________

22

Warranty Registration

Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear o󰀨 the card at the perforation and then send to the address specied below. You can also register online by visiting:

Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:

Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación, cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:

www.omcan.com/warrantyregistration.html

For mailing in Canada

Pour postale au Canada

Por correo en Canadá

OMCAN

PRODUCT WARRANTY REGISTRATION

3115 Pepper Mill Court,

Mississauga, Ontario

Canada, L5L 4X5

PRODUCT WARRANTY REGISTRATION

4450 Witmer Industrial Estates, Unit 4,

For mailing in the US

Pour di󰀨usion aux États-Unis

Por correo en los EE.UU.

OMCAN

Niagara Falls, New York

USA, 14305

or email to: service@omcan.com



Purchaser’s Information

Name: Company Name:

Address:

Telephone:

City: Province or State: Postal or Zip: Email Address:

Country: Type of Company:

Restaurant Bakery Deli

Dealer from which Purchased: Butcher Supermarket Caterer

Dealer City: Dealer Province or State: Institution (specify):

Invoice: Other (specify):

Model Name: Model Number: Serial Number:

Machine Description:

Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):

Would you like to extend the warranty? Yes No

Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

23

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers. Today with partners in North America, Europe, Asia and South America, we continually work to improve

and grow the company. We strive to offer customers exceptional value through our qualied local sales

and service representatives who provide convenient access to over 3,500 globally sourced products.

Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à

nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 3500

produits provenant du monde entier.

Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un fácil acceso a más de 3,500 productos con origen a nivel mundial.

Omcan RS-CN-0044, RS-CN-0064, RS-CN-0104, RS-CN-0084 Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
