Omcan MX-CN-0060 Operators Manual

Heavy Duty Baking Mixers

Model MX-CN-0020, 0030, 0040, 0060, 0080

Item 43560, 44388, 44389, 44390, 44391

Instruction Manual

Revised - 01/22/2020

Toll Free: 1-800-465-0234

Fax: 905-607-0234

Email: service@omcan.com

www.omcan.com

Table of Contents

Model MX-CN-0020 / Model MX-CN-0030 / Model MX-CN-0040

Model MX-CN-0060 / Model MX-CN-0080

Section

General Information

Safety and Warranty

Technical Specications

Operation

Maintenance

Troubleshooting

Parts Breakdown

------------------------------------------------------------------------------------------------------ 6 - 8

-------------------------------------------------------------------------------------------------- 8 - 9

----------------------------------------------------------------------------------------- 3 - 4

---------------------------------------------------------------------------------------- 4 - 5

-------------------------------------------------------------------------------------------- 9 - 10

------------------------------------------------------------------------------------------ 11 - 28

Page

---------------------------------------------------------------------------------------- 6

Electrical Schematics

Notes

Warranty Registration

-------------------------------------------------------------------------------------------------------- 32 - 34

------------------------------------------------------------------------------------ 29 - 31

----------------------------------------------------------------------------------------- 35

2

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the external packaging, open carton to ensure all ordered items are within the box, and there is no concealed damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Before operating any equipment, always read and familiarize yourself with all operation and safety

instructions.

Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save these instructions for future reference. Also save the original box and packaging for shipping the

equipment if servicing or returning of the machine is required.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant

d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

3

General Information

Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations et les consignes de sécurité.

Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces

instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour

l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada. Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes

o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro

de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de

funcionamiento y seguridad.

Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el

envío del equipo si servicio técnico o devolución de la máquina que se requiere.

Safety and Warranty

PRECAUTIONS

• If any item is missing or damaged, please contact the dealer and keep all the packing materials.

• Keep the space on top of the mixer >30cm. Keep the distance between each side/back and the wall

>10cm.

• Do not place the machine in a damp place close to heat sources or with direct sunlight.

• Floor or counter must be stable and level.

4

Safety and Warranty

• Connect or plug the machine power cord to an electrical outlet. Do not share the power socket with other machines.

• Do not use the machine continuously, or its service life may be reduced.

• Do not place the machine in an operating environment where room temperature is a too low (<5°C) or too

high (>40°C).

Warning: Do not knead dough at a high speed, do not use sticky ingredients.

CAUTION

• Disconnect or unplug electrical power before cleaning, repairing or moving the machine.

• Keep hands away from moving parts especially the bowl and the safety guard when the mixer is in

operation.

• Disconnect or unplug electrical power before changing agitator to avoid personal injury.

• Owners should not permit kids to touch this equipment. Owners should also ensure that no other unauthorized personnel come in contact with this equipment. Unless the operator is adequately trained and

supervised there is a possibility of serious injury.

• Do not rinse the entire mixer. Do not use a steel wool or abrasive material to clean the mixer.

1 YEAR PARTS AND LABOUR WARRANTY

Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized

service technician to repair the equipment locally.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures not

improper use.

Please see https://omcan.com/disclaimer for complete info.

WARNING:

The packaging components are classied as normal solid urban waste and can therefore be disposed of without difculty.

In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms.

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

5

Technical Specications

Model MX-CN-0020 MX-CN-0030 MX-CN-0040 MX-CN-0060 MX-CN-0080 Capacity

Power

Shaft Speed

(RPM)

Electrical

Dimensions

Weight Item Number

20 QT / 5 Gal 30 QT / 7.5 Gal 40 QT / 10 Gal 60 QT / 15 Gal 80 QT / 20 Gal

1500W 1800W 2200W 3000W 4000W

1st - 120

2nd - 272

3rd - 390

110V / 60Hz / 1Ph 220V / 60Hz / 3Ph

24” x 23.6” x 36.1”

610 x 600 x 918mm

260.1 lbs. / 118 kgs. 385.8 lbs. / 175 kgs. 496 lbs. / 225 kgs. 1040.6 lbs. / 472 kgs. 1080.3 lbs. / 490 kgs.

43560 44388 44389 44390 44391

1st - 112

2nd - 206

3rd - 351

27.1” x 25.2” x 45.1”

688 x 641 x 1145mm

1st - 120

2nd - 268

3rd - 372

29.3” x 25.2” x 48.2”

744 x 640 x 1225mm

1st - 119

2nd - 275

3rd - 396

976 x 882 x 1525mm

Operation

MACHINE STARTUP

FOR MX-CN-0020, 0030, 0040

Press the (ON button) to start mixing. Press the (OFF button) to stop mixing. Rotate the (Timer) for timing. In case of emergency, press the (OFF button) to stop mixing immediately. Replace the beater after shutdown.

FOR MX-CN-0060, 0080

Press the (ON button) to start mixing. Press the (OFF button) to stop mixing. Rotate the (Timer) for timing. In case of emergency, press the (EMERGENCY button) to stop mixing immediately. Replace the beater after shutdown. Press RISE button (or bowl lift button) before you start the machine. Press FALL button (or bowl lower down button) before you stop the machine.

Use the Speed Control handle to adjust speed.

6

Operation

Lift the bowl and slowly position the locking pin into the hole 1 in the cradle, lower the bowl (hole 3 on the bowl) onto the pins located on either of the bowl cradle(hole 2 in the cradle), secure the bowl by pulling each bowl clamp.

To attach the agitator (i.e., beater, hook, whip) to the mixer, slide the agitator

slowly upwards onto the mixer shaft tting the shaft pin through the slot in

the agitator, rotate the agitator 45 degree clockwise to secure it onto the mixer shaft, rotate the agitator 45 degree counterclockwise to remove the agitator.

ONLY FOR MX-CN-0020, 0030, 0040

Before starting the mixer, rotate the bowl lift lever up 190 degree counterclockwise. After stopping the mixer, rotate the bowl lift lever down 190 degree clockwise.

INSTRUCTIONS FOR THE AGITATOR

• Flat Beater: for mashing potatoes, mixing cake batter and frostings.

• Wire whip: For uffy whipped cream, egg whites and frostings.

• Hook: For mixing bread dough and pizza dough.

APPLICABLE SPEEDS OF THE AGITATOR

1st SPEED 2nd SPEED 3rd SPEED WIRE WHIP FLAT BEATER HOOK

     

7

Operation

USAGE OF ATTACHMENTS

PRODUCT WIRE WHIP FLAT BEATER HOOK

Raised Donut Dough (65%AR)

Pizza Dough

Wafe or Hot Cake Batter

Whipped Cream

Mashed Potato

Egg Whites

Meringue

Heavy Bread Dough (55%AR)

Bread and Roll Dough (60%AR)

Pizza Dough - Thin (40%AR)

Pizza Dough - Medium (50%AR)

Pizza Dough - Thick (60%AR)

Fondant Icing

Cake

Pie Dough

Pasta, Basic Egg Noodle (5 minutes maximum mix time)

* AR = Absorption Ratio

 



   



   



The above data is for reference only, variances may occur in dough consistency.

Maintenance

CLEANING INSTRUCTIONS

• Clean the mixer prior to using it. Bowl and agitator must be thoroughly cleaned.

• Disconnect or unplug electrical power before cleaning.

• It is important to clean the mixer on a regular basis. Use soft cloth or damp sponge. Do not use a steel

wool or abrasive material to clean the mixer. Do not use bleach (sodium hypochlorite) or bleached based cleaner.

• When cleaning the ON/OFF button, power cord or other electrical parts, wipe with dry cloth, do not rinse.

• The factory has applied a generous amount of grease in and on the machine before delivery; generally

it can be used for half a year. If you want to add or reapply grease, please open the top cover and inject grease into the grease hole directly.

8

Maintenance

TRANSPORT AND STORAGE

• Our food mixers are all xed with bolts in packing cases. During transport, do not place the mixers upside down or horizontal, no squeezing, bumping, rainwater or vibration. During mixer loading and unloading, the

angle of inclination cannot exceed 45°.

• The machine should be stored in a ventilated dry warehouse. And must be separated from toxic or corrosive materials.

• When storing and stacking the mixers, read the storage and transport symbols on the packing cases carefully and follow these symbols for stacking.

Troubleshooting

PROBLEM POSSIBLE CAUSES ACTION REQUIRED

Mixer will not run. Power is not connected properly. Check power connections.

Test the power socket with another

item. Oil leak. The sealing ring is damaged. Replace the sealing ring.

Motor temperature is abnormally high, and rotation speed decreases.

Mixer is noisy and runs too hot. Mixer gear needs more grease. Reapply grease.

Agitators touching bottom or sides of bowl.

Note: Omcan reserves the right to modify the product at any time without prior notice. The product

pictures are for reference only. Actual product may vary due to product enhancement.

Incorrect or low voltage. Electrician to check voltage.

Unit is over loaded. Reduce the batch size.

Incorrect mixing speed or incorrect agitator installed.

Defective or dented bowl/agitator. Replace the bowl/agitator.

Follow the instructions to switch

the agitator or use the correct

speed setting.

9

Troubleshooting

REFERENCE

Item Number Model Number Description Manufacturer Model Number

Mixer Heavy Duty 20 QT / 5 Gal

43560 MX-CN-0020

44388 MX-CN-0030

2.7 HP / 2000 W 110V/60/1 cETLus

44389 MX-CN-0040

2.9 HP / 2200 W 220V/60/3 cETLus

44390 MX-CN-0060

44391 MX-CN-0080

with Guard with Timer

2 HP / 1500 W 110V/60/1 cETLus

Mixer Heavy Duty 30 QT / 7.5 Gal

with Guard with Timer

Mixer Heavy Duty 40 QT / 10 Gal

with Guard with Timer

Mixer Heavy Duty 60 QT / 15 Gal

with Guard with Timer

4 HP / 3000 W 220V/60/3 cETLus

Mixer Heavy Duty 80 QT / 20 Gal

with Guard with Timer

5 HP / 4000 W 220V/60/3 cETLus

MC20

MC30

MC40

MC60

MC80

10

Model MX-CN-0020 43560

Parts Breakdown

11

Parts Breakdown

Model MX-CN-0020 43560

Item No. Description Position Item No. Description Position Item No. Description Position

64973 Flat Beater for MC20 1 24929 Shaft Worm Gear for MC20 27 64982 Clamp Screw for MC20 53

64974 Wire Whipper for MC20 2 24930 Gear for MC20 28 24908 Press Board for MC20 54

43523 Hook Stainless Steel 304 for MC20 3 64976 Main Shaft for MC20 29 25781 Support for MC20 55

25726 Safety Guard for MC20 4 64977 Thumb Screw for MC20 30 24872 Tapered Gear Wheel for MC20 56

25157 Bowl for MC20 5 24869 Attachment Hub for MC20 31 25773 Red Button for MC20 57

24912 Bearing 6201 for MC20 6 24985 Plug Cover (Steel) for MC20 32 24922 Green Button Round for MC20 58

24913 Mid-Gear Wheel for MC20 7 24895 Transmission Shaft Support for MC20 33 64983 Front Plate for MC20 59

24916 Gear for MC20 8 64978 Gearbox for MC20 34 64984 Top Cover for MC20 60

24917 Bushing for MC20 9 24886 Internal Gear for MC20 35 64985 Hub Ring for MC20 61

24918 Gear for MC20 10 24887 Gear for MC20 36 24921 Oil Seal for MC20 62

24919 Plug Cover for MC20 11 64810 Shaft Holder for MC20 37 25013 Worm Wheel-New for MC20 63

25088 Bearing 6203 for MC20 12 64811 Planetary Shaft for MC20 38 25771 Side Plate for MC20 64

24897 Spacer-Lower for MC20 13 25070 Bearing 6204 for MC20 39 25770 Cover Board for MC20 65

24879 Roller 8x15 for MC20 14 24890 Oil Seal for MC20 40 25785 Cover Board for MC20

64975 Spring for MC20 15 64979 Agitator Joint Shaft for MC20 41 25775 Leak Board for MC20 67

24878 Gear for MC20 16 24957 Screw for MC20 42 64986 Motor for MC20 68

24877 Big Gear for MC20 17 24959 Pin Shaft for MC20 43 25799 Connecting Rod for MC20 69

25814 Taper Gear Wheel for MC20 18 24958 Spring for MC20 44 25779 Back Cover Plate for MC20 70

24900 Gear for MC20 19 64980 Fork for MC20 45 64987 Crank Lever for MC20 71

24902 Sleeve for MC20 20 24881 Declutch Shift Shaft for MC20 46 64988 Guide Plate for MC20 72

24901 Bushing for MC20 21 64981 Shaft Bias for MC20 47 64989 Bowl Lift Arm for MC20 73

24903 Claw Type Gear Wheel for MC20 22 24864 Plate-Shifter Index for MC20 48 64990 Rubber Grip for MC20 74

24904 Gasket for MC20 23 25790 Handle-Shifter for MC20 49 64991 Mixer Base for MC20 75

24905 Bearing 6205 for MC20 24 25793 Link Rod for MC20 50 65253 Timer for MC20 76

24907 Oil Seal for MC20 25 25797 Speed Handle for MC20 51

24906 Bushing for MC20 26 25796 Handle Sleeve M8x58 for MC20 52

66

12

Parts Breakdown

Model MX-CN-0030 44388 General Assembly

13

Parts Breakdown

Model MX-CN-0030 44388

Head

14

Parts Breakdown

Model MX-CN-0030 44388

Item No. Description Position Item No. Description Position Item No. Description Position

67774 Sticker for MC30 1 67809 Support for MC30 45 67828 Bolt M8x20 for MC30 101

67775 Emergency Stop Button for MC30 2 67875 Travel Device Assembly for MC30 46 25096 Spring Washer Φ8 for MC30 102

67776 Hook for MC30 3 24947 Micro Switch for MC30 47 67836 Shaft Retaining Ring for MC30 103

64985 Scraper Seal for MC30 4 61185 Bolt M3x14 for MC30 48 25070 Bearing 6204 for MC30 104

64977 Peg Handle for MC30 5 67810 Flat Washer Φ3 for MC30 49 24987 Spacer-Lower for MC30 105

67777 Elastic Cylindrical Pin 4x20 for MC30 6 67811 Press Board 2 for MC30 50 24989 Gear for MC30 106

67778 Plug for MC30 7 67812 Cover Plate-Down for MC30 51 67837 Coil Spring for MC30 107

67779 Screw Nut M6 for MC30 8 67813 Side Guard Left/Right for MC30 52 24990 Pin Roller for MC30 108

67780 Bolt M6x16 for MC30 9 67814 Davit for MC30 53 24988 Super Machine Parts for MC30 109

67781 Bolt M6x35 for MC30 10 67815 Water Joint for MC30 54 67838 Gear for MC30 110

65370 Stainless Steel Flat Washer Φ6 for MC30 11 67816 Travel Cover for MC30 55 25010 Sleeve for MC30 111

67782 Bolt M8x35 for MC30 12 67817 Crank Lever for MC30 56 67839 Key C6x32 for MC30 11 2

67783 Stainless Steel Flat Washer Φ8 for MC30 13 67818 Running Capacitor for MC30 57 24901 Bushing for MC30 113

67784 Bolt M6x10 for MC30 14 67819 Start Capacitor for MC30 58 67840 Key 5x36 for MC30

67785 Bracket Plate for MC30 15 67820 Handle-Shifter for MC30 59 24994 Sleeve for MC30 115

67786 Stainless Steel Screw Nut M8 for MC30 16 67821 Plastic Block for MC30 60 67841 Main Shaft for MC30 11 6

67787 Spring for MC30 17 67822 Bolt M5x10 for MC30 61 25011 Bushing for MC30 11 7

65366 Stainless Steel Flat Washer Φ8 for MC30 18 67823 Bolt M4x6 for MC30 62 24995 Sleeve for MC30 118

67788 Side Guard Left/Right for MC30 19 25775 Drafty Plate for MC30 63 24996 Washer for MC30 11 9

67789 Swerve Sticker for MC30 20 67824 Bolt M4x14 for MC30 64 24997 Bearing 6206 for MC30 120

67790 Cover Plate Assembly for MC30 21 65378 Flat Washer Φ4 for MC30 65 24998 Bushing for MC30 121

67791 Bowl Locating Pin for MC30 22 64990 Handle Sleeve M12 for MC30 66 67842 Shifting Yoke for MC30 122

67792 Safety Grid for MC30 23 25778 Timer for MC30 67 24999 Oil Seal 40x62x8 for MC30 123

67793 Bowl for MC30 24 67825 Wire Whip for MC30 68 67843 Key 6x25 for MC30 124

67794 Electrical Bafe for MC30 25 67826 Bolt M8x40 for MC30 69 67844 Washer for MC30 125

67795 Press Board 1 for MC30 26 25068 Screw Nut M8 for MC30 70 24905 Bearing 6205 for MC30 126

67796 Safety Grid Positioning Block for MC30 27 67827 Back Cover for MC30 71 25004 Nut M18x1.5 for MC30 127

67797 Body Assembly for MC30 29 65374 Flat Washer Φ8 for MC30 72 67845 Working Shaft for MC30 128

25796 Handle Sleeve for MC30 30 25096 Spring Washer Φ8 for MC30 73 67846

67798 Safety Grid Positioning Block for MC30 31 67828 Bolt M8x20 for MC30 74 39316 Spring Washer Φ6 for MC30 130

67799 Speed Handle for MC30 32 67829 Guide Rail Plate for MC30 75 67847 Attachment Hub for MC30 131

67800 Connecting Rod for MC30 33 67830 Beater for MC30 76 67848 Fixed Sleeve for MC30 132

67801 Bolt M5x50 for MC30 34 67831 Bolt M5x8 for MC30 78 67849 Paper Washer for MC30 133

67802 Bolt ST4.8x12 for MC30 35 67832 Cotter 3x30 for MC30 79 24871 Check Ring for MC30 134

24922 Start Button for MC30 36 31569 Elastic Cylindrical Pin for MC30 80 67850 Gear for MC30 135

67803 Timer Knob for MC30 37 67833 Parameters Brand for MC30 81 25810 Cylindrical Gears Stuffy Board for MC30 136

67804 Bolt M5x30 for MC30 38 65322 Bolt M8x20 for MC30 82 67851 Bolt M5x16 for MC30 137

67805 Stainless Steel Flat Washer Φ5 for MC30 39 67834 Connecting Rod for MC30 83 67852 Convex Head Cap for MC30 138

65357 Stainless Steel Flat Washer Φ5 for MC30 40 67835 Overload Switch for MC30 84 67853 Pad for MC30 139

67806 Bolt for MC30 41 24938 Flat Washer Φ14 for MC30 85 67854 Pad for MC30 140

25720 Elastic Cylindrical Pin 4x25 for MC30 42 25047 Flat Washer Φ12 for MC30 86 67855 Circlips 18 for MC30 141

67807 Bolt M3x6 for MC30 43 25046 Spring for MC30 87 24985 Plug Cover for MC30 142

67808 Top Cover for MC30 44 25029 Nut M12 for MC30 88 67856 Pin 6x20 for MC30 143

Bolt M6x20 for MC30 129

114

15

Parts Breakdown

Model MX-CN-0030 44388

Item No. Description Position Item No. Description Position Item No. Description Position

25007 Cover Gear Housing for MC30 144 67865 Spring Washer 5 for MC30 162 25024 Worm Gear for MC30 182

67857 Gearbox for MC30 145 67866 Circlips for MC30 163 25034 Circlips for Shaft 20 for MC30 183

24973 Shaft Circlips 19 for MC30 146 25088 Bearing 6203 for MC30 164 65371 Spring Washer 6 for MC30 184

24974 Planetary Gear for MC30 147 25022 Gear for MC30 165 25084 Bearing 6202 for MC30 185

67858 Key C6x50 for MC30 148 25013 Worm Wheel for MC30 166 25035 Circlips for Shaft 15 for MC30 186

24977 Oil Seal for MC30 149 24921 Oil Seal for MC30 167 25008 Flat Key 5x16 for MC30 187

67859 Shaft Holder for MC30 150 25719 Pin 4x30 for MC30 168 25009 Circlips for Shaft 17 for MC30 188

67860 Hexagon Screw M8x30 for MC30 151 25794 Steel Ball 6 for MC30 170 25765 Pin 6x30 for MC30 189

25018 Internal Gear for MC30 152 25718 Spring for MC30 171 67870 Motor for MC30 190

67861 Circlips 35 for MC30 153 67867 Handle Seat for MC30 172 67871 O-Ring Seal for MC30 191

65394 Phillips Screw M6x20 for MC30 154 67868 Handle Shaft for MC30 173 67872 O-Ring Seal for MC30 192

67862 Phillips Screw M5x10 for MC30 155 67869 Phillips Screw M5x12 for MC30 174 24980 Fork Shaft for MC30 193

67863 Cover for MC30 156 24959 Pin Shaft for MC30 175 67873 Fork for MC30 194

25023 Bushing for MC30 157 24958 Spring for MC30 176 24882 Spring Washer 10 for MC30

25021 Mid-Gear Wheel for MC30 158 24957 Adjusting Screw for MC30 177 25141 Nut M10 for MC30 196

25026 Gear for MC30 159 25029 Nut M12 for MC30 178 67874 Hexagon Screws M6x8 for MC30 197

25027 Gasket for MC30 160 25030 Spring Washer 12 for MC30 179

67864 Bolt M5x14 for MC30 161 25032 Gear Wheel for MC30 181

195

16

Parts Breakdown

Model MX-CN-0040 44389 General Assembly

17

Parts Breakdown

HeadModel MX-CN-0040 44389

18

Parts Breakdown

Model MX-CN-0040 44389 General Assembly

Item No. Description Position Item No. Description Position Item No. Description Position

67885 Body for MC40 1 67894 Crank Lever for MC40 31 67775 Emergency Stop Button for MC40 59

67886 Bowl for MC40 3 67895 Crash Pad for MC40 32 67910 Thermal Relay for MC40 60

67887 Support for MC40 4 67896 Davit for MC40 33 67815 Water Joint M20x1.5 for MC40 61

67783 Stainless Steel Flat Washer Φ8 for MC40 6 67897 Connecting Rod for MC40 34 67821 Plastic Block for MC40 62

67888 Bolt M8x40 for MC40 7 24938 Flat Washer Φ14 for MC40 35 67816 Travel Cover for MC40 63

64977 Handle for MC40 8 67898 Hook for MC40 36 24947 Micro Switch for MC40 64

67800 Connecting Rod for MC40 9 67899 Spring for MC40 37 67810 Flat Washer Φ3 for MC40 65

67799 Speed Handle for MC40 10 25003 Flat Washer Φ16 for MC40 38 67911 Bolt M3x20 for MC40 66

25796 Handle Sleeve M8x58 for MC40 11 67900 Screw Nut M14 for MC40 39 65378 Flat Washer Φ4 for MC40 67

67777 Elastic Cylindrical Pin Φ4x20 for MC40 12 65326 Bolt M10x30 for MC40 40 67912 Bolt M4x12 for MC40 68

67801 Bolt M5x50 for MC40 13 25141 Screw Nut M10 for MC40 41 67913 Bolt M6x35 for MC40 69

64985 Scraper Seal for MC40 14 67901 Cover Plate-Down for MC40 42 67914 Nut M6 for MC40 70

67889 Safety Grid for MC40 15 67902 Guide Rail Plate for MC40 43 67784 Screw M6x10 for MC40 71

67796 Safety Grid Positioning Block 1 for MC40 16 25096 Flat Washer Φ5 for MC40 44 67915 Back Cover for MC40

67798 Safety Grid Positioning Block 2 for MC40 17 67828 Bolt M8x20 for MC40 45 67916 Handle Sleeve M16x80 for MC40 73

67890 Side Guard Left / Right for MC40 18, 77 65374 Flat Washer Φ8 for MC40 46 65370

67877 Stroke Hit Head for MC40 19 67903 Bolt M10x25 for MC40 47 67917 Screw M6x35 for MC40 75

65366 Stainless Steel Flat Washer Φ8 for MC40 20 24882 Spring Washer Φ10 for MC40 48 67823 Screw M4x6 for MC40 76

67804 Bolt M5x30 for MC40 22 67904 Elastic Cylindrical Pin Φ5x30 for MC40 49 67918 Handle-Shifter for MC40 78

67805 Stainless Steel Flat Washer Φ5 for MC40 23 67807 Bolt M3x6 for MC40 50 67803 Black Knob for MC40 79

65357 Flat Washer Φ5 for MC40 24 67905 Drafty Plate for MC40 51 67822 Screw M5x10 for MC40 80

67891 Cover Plate Assembly for MC40 25 67906 Elastic Cylindrical Pin Φ6x40 for MC40 52 67778 Plug for MC40 81

67892 Bowl Locating Pin for MC40 26 67907 Elastic Cylindrical Pin Φ4x40 for MC40 53 67919 Electrical Bafe for MC40 82

67786 Screw Nut M8 for MC40 27 67908 Cotter 3x25 for MC40 54 67920 Screw M5x8 for MC40 85

67795 Press Board 1/2 for MC40 28, 83 67909 Top Cover for MC40 55 67921 Sticker for MC40 86

67893 Clamp Screw for MC40 29 65253 Timer for MC40 56 67922 Beater for MC40 87

67787 Stainless Steel Spring for MC40 30 24922 Start Button for MC40 57 67923 Wire Whip for MC40 88

Stainless Steel Flat Washer Φ6 for

MC40

72

74

19

Parts Breakdown

HeadModel MX-CN-0040 44389

Item No. Description Position Item No. Description Position Item No. Description Position

67924 Gearbox for MC40 1 24905 Bearing 6205-Z for MC40 5 24997 Bearing 6206-Z for MC40 17

67925 Key A=10mm x 45mm for MC40 2 25070 Bearing 6204-Z for MC40 6 24905 Bearing 6205-Z for MC40 17

67926 Spacer-Lower-2 for MC40 2 25088 Bearing 6203-Z for MC40 7 67966 Shaft Holder for MC40 17

67927 Bearing 6207-Z for MC40 2 67950 Cover, Gear Housing for MC40 8 67967 Screw M8x25 for MC40 18

67928 Spacer-Lower-1 for MC40 2 67872 O-Ring 9x1.8 for MC40 9 25096 Spring Washer Φ8 for MC40 19

67929 Clutch Gear for MC40 2 67871 O-Ring 33.5x1.8 for MC40 9 67968 PinΦ8x20 for MC40 20

67930 Sleeve Clutch for MC40 2 25719 Elastic Cylindrical Pin Φ4x30 for MC40 9 24893 Spring Washer Φ14 for MC40 21

67931 Key A=10mm x 35mm for MC40 2 25794 Steel Ball Φ6 for MC40 9 67969 Bolt M14x30 for MC40 22

67932 Bushing for MC40 2 25718 Spring for MC40 9 67970 Shift Rail for MC40 23

67933 Clutch Gear for MC40 2 67951 Handle-Shifter for MC40 9 67971 Spring Washer Φ16 for MC40 24

67934 Gear for MC40 2 67952 Cam-Gear Shifter for MC40 9 67972 Spring Washer Φ4 for MC40 26

67935 Super Machine Parts for MC40 2 67867 Plate-Shifter Index for MC40 9 67824 Screw M4x14 for MC40 27

67936 Gear for MC40 2 24957 Adjusting Screw for MC40 10 67860 Screw M8x30 for MC40 28

67937 Roller 12x27 for MC40 2 67953 Pin Shaft for MC40 10 39316 Spring Washer Φ6 for MC40

67938 Main Shaft for MC40 2 67954 Spring for MC40 10 67846 Screw M6x20 for MC40 30

67939 Key C=8mm x 28mm for MC40 3 67955 Shifting Yoke for MC40 10 25004 Nut M18x1.5 for MC40 32

67940 Key A=8mm x 28mm for MC40 3 67956 Internal Gear for MC40 11 25714 Nut M14x1.5 for MC40 33

25070 Bearing 6204-Z for MC40 3 67957 Motor for MC40 12 67973 Nut M22x1.5 for MC40 34

25034 Shaft Circlips 20 for MC40 3 67958 Worm Wheel for MC40 13 67974 Spring Washer Φ22 for MC40 35

67941 Bushing for MC40 3 24977 Oil seal 28x52x7 for MC40 14 67975 Running Clamp for MC40 36

67942 Bushing for MC40 3 67959 Gear for MC40 15 67976 Bolt M10x25 for MC40 38

67943 Gear for MC40 3 67960 Attachment Hub for MC40 16 25028 Plug Cover for MC40 39

67944 Gear for MC40 3 39316 Spring Washer Φ6 for MC40 17 67977 Plug Cover for MC40 40

67945 Mid-Gear Wheel for MC40 3 67874 Screw M6x8 for MC40 17 24871 Ring for MC40 41

25088 Bearing 6203-Z for MC40 4 67961 Fixed Sleeve for MC40 17 67978 O-Ring for MC40 43

25009 Shaft Circlips 17 for MC40 4 67946 Shaft Circlips 24 for MC40 17 25765 Pin Φ6x30 for MC40 44

67946 Shaft Circlips 24 for MC40 4 67962 Planetary Gear for MC40 17 24985 Plug Cover for MC40 45

67947 Key A=6mm x 22mm for MC40 4 67963 Key A=6mm x 30mm for MC40 17 67979 Oil Seal 50x72x8 for MC40 46

67948 Worm Gear for MC40 4 67964 Oil Seal 35x62x7 for MC40 17 67980

67949 Worm-Wheel Shaft for MC40 4 67965 Run Bearing for MC40 17 67981 Key C=10mm x 75mm for MC40 48

Spacer-Lower-3 for MC40 47

29

20

Parts Breakdown

Model MX-CN-0060 44390 General Assembly

21

Parts Breakdown

HeadModel MX-CN-0060 44390

22

Parts Breakdown

Model MX-CN-0060 44390 General Assembly

Item No. Description Position Item No. Description Position Item No. Description Position

67982 Flat Washer 10 for MC60 101 68002 O-Ring 250x5.3G for MC60 137 68019 Hexagon Screw M6x16 for MC60 176

67983 Wire Whipper for MC60 102 68003 Top Cover for MC60 139 68025 Back Cover Plate for MC60 177

67984 Slotted Screws M8x15 for MC60 103 68004 Pin 5x25 for MC60 140 24938 Flat Washer 14 for MC60 178

67985 Spiral Hook for MC60 104 68005 Gear Shift Lever for MC60 141 68026 Tour Guide for MC60 179

67986 Shaft for MC60 106 68006 Press Board for MC60 142 67851 Phillips Screw M5x16 for MC60 180

67987 Phillips Screw M6x60 for MC60 107 67784 Hexagon Screws M6x10 for MC60 143 68027 Clamp Screw for MC60 181

25796 Rubber Grip for MC60 108 68007 Hexagon Screw M8x40 for MC60 144 68028 Phillips Screw M4x10 for MC60 182

67988 Flat Beater for MC60 109 68008 Shaft for MC60 146 39316 Spring Washer 6 for MC60 183

67989 Side Guard for MC60 110 68009 Spring Washer 10 for MC60 147 68029 Bowl Roller Seat for MC60 184

65319 Bolt M12x50 for MC60 111 67984 Slotted Screws M8x15 for MC60 149 68030 Bracket Block 2 for MC60 185

65321 Spring Washer 12 for MC60 112 68010 D4C Switch for MC60 150 68031 Support for MC60 186

67990 Subplate for MC60 11 3 68011 Body Assembly for MC60 152 68032 Bottom Cover for MC60 187

67865 Spring Washer 5 for MC60 114 68012 Hexagon Screws M8x12 for MC60 153 68033 Spring for MC60 188

67991 Hexagon Screw M5x25 for MC60 115 68013 Stop Switch-1 for MC60 154 67828 Bolt M8x20 for MC60

67846 Hexagon Screw M6x20 for MC60 116 68014 Stop Switch-1 for MC60 154 68034 Wheel Plate for MC60 190

39316 Spring Washer 6 for MC60 117 67833 Parameter Plate for MC60 156 68035 Wheel for MC60 191

67914 Nut M6 for MC60 118 25778 Timer for MC60 157 68036 Belt 10PJ 570 for MC60 192

67992 Gasket for MC60 119 68015 Sticker for MC60 158 68037 Shaft Sleeve for MC60 193

67796 Located Bloc for MC60 120 68016 Sticker for MC60 158 68038 Bearing 6304 for MC60 194

67798 Located Bloc for MC60 121 67823 Hexagon Screws M4x6 for MC60 160 25141 Nut M10 for MC60 195

67993 Hexagon Screws M6x40 for MC60 122 68017 Handle-Shifter Seat for MC60 161 68039 Bolt M10x100 for MC60 196

67994 Safety Guard for MC60 123 68018 Key C6x35 for MC60 162 68040 Shaft Block for MC60 197

67995 Bowl for MC60 124 68019 Hexagon Screw M6x15 for MC60 163 68041 Hexagon Screw M10x40 for MC60 198

67996 Bolt M6x16 for MC60 125 68020 Small Pulley for MC60 164 24882 Spring Washer 10 for MC60 199

67997 Angle Iron for MC60 126 68021 Lifting Motor for MC60 165 67947 Flat Key 6x22 for MC60 200

25720 Pin 4x25 for MC60 127 67779 Nut M6 for MC60 166 68042 Screw Rod for MC60 201

25046 Spring for MC60 128 25096 Spring Washer 8 for MC60 168 68043 Feed Screw Nut for MC60 202

67998 Top Cover Assembly for MC60 129 68022 Bolt M8x30 for MC60 167 68044 Nut Clamp for MC60 203

67999 Bracket Block 1 for MC60 130 65326 Bolt M10x30 for MC60 169 68045

25141 Nut M10 for MC60 131 67803 Speed Control for MC60 170 68046 Limit Switch for MC60 205

68000 Ventilation Plate for MC60 132 24924 Stop Button for MC60 171 68047 Strut for MC60 206

68001 O-Ring 55x5G for MC60 133 25030 Spring Washer 12 for MC60 172 68048 Electrical Bafe for MC60 207

24922 Start Button for MC60 134 68023 Lifting Clamp for MC60 173 68049 Heavy Duty Connector for MC60 208

67775 Emergency Stop Button for MC60 135 65303 Bolt M12x35 for MC60 174 67802 Screw ST4.8x12 for MC60 209

24924 Stop Button for MC60 136 68024 Block for MC60 175

Hexagon Screw M10x25 for MC60 204

189

23

Parts Breakdown

HeadModel MX-CN-0060 44390

Item No. Description Position Item No. Description Position Item No. Description Position

68050 Gear for MC60 1 68071 Cover, Gear Housing for MC60 31 68093 Steel Ball 8 for MC60 61

68051 Coil Spring for MC60 2 68072 Nut M24x2 for MC60 32 68094 Gasket for MC60 62

68052 Roller for MC60 3 68073 Spring Washer 24 for MC60 33 39316 Spring Washer 6 for MC60 63

68053 Super Machine Parts for MC60 4 68074 Mid-Gear Wheel for MC60 34 68095 Declutch Shift Shaft for MC60 64

68054 Level Drive Gear for MC60 5 67940 Flat Key 8x28 for MC60 35 25141 Nut M10 for MC60 65

68055 Clutch Gear for MC60 6 68075 Flat Key 8x32 for MC60 36 68096 Cam-Gear Shifter for MC60 66

68056 Bushing for MC60 7 68076 Circlips for Shaft 25 for MC60 37 68097 Elastic Cylindrical Pin 4x45 for MC60 67

68057 Sleeve Clutch for MC60 8 68077 Plug 1 for MC60 38 68098 Spring for MC60 68

68058 Clutch Gear for MC60 9 24882 Spring Washer 10 for MC60 39 68099 Plate-Shifter Index for MC60 69

68059 Shaft Bushing for MC60 10 68078 Circlips 62 for MC60 40 68100 Handle-Shifter for MC60 70

28665 Bearing 6209 for MC60 11 68038 Bearing 6304 for MC60 41 65394 Phillips Screw M6x20 for MC60 71

68060 Oil Seal for MC60 12 68079 Circlips 52 for MC60 42 68101 Gear Box for MC60 72

68061 Bushing for MC60 13 68080 Circlips 72 for MC60 43 68102 Internal Gear for MC60 73

68062 Nut M27x2 for MC60 14 68081 Bushing for MC60 44 68041 Hexagon Screw M10x40 for MC60

68063 Spring Washer 27 for MC60 15 68082 Gear for MC60 45 68103 Worm Wheel for MC60 75

68059 Shaft Bushing for MC60 16 68083 Gasket for MC60 46 25765 Elastic Cylindrical Pin 6x30 for MC60 76

65338 Flat Key 10x50 for MC60 17 68084 Pin 8x26 for MC60 47 68104 Motor for MC60 77

68064 Flat Key 10x40 for MC60 18 65348 Nut M20x1.5 for MC60 48 25030 Spring Washer 12 for MC60 78

68065 Main Shaft for MC60 19 68085 Gear for MC60 49 65303 Bolt M12x35 for MC60 79

68066 Key C10x60 for MC60 20 68086 Spring Washer 20 for MC60 50 68105 Flat Key 8x40 for MC60 80

64977 Thumb Screw for MC60 21 68087 Gear Wheel for MC60 51 68070 Bearing 6306 for MC60 81

24967 Attachment Hole Plug for MC60 22 68088 Worm Gear for MC60 52 68106 Bearing 6007 for MC60 82

67846 Hexagon Screw M6x20 for MC60 23 68089 Flat Key 8x25 for MC60 53 24999 Oil Seal for MC60 83

68067 Attachment Hub for MC60 24 68090 Circlips for Shaft 34 for MC60 54 68107 Planetary Gear for MC60 84

67849 Gasket for MC60 25 25034 Circlips for Shaft 20 for MC60 55 68108 Circlips for Shaft 30 for MC60 85

68068 Bevel Gear Unit for MC60 26 68091 Plug 2 for MC60 56 68109 Working Shaft for MC60 86

68045 Hexagon Screw M10x35 for MC60 27 24957 Plunger-Shifter Yoke for MC60 57 68110 Operating Shaft for MC60 87

68069 Bearing 6305 for MC60 28 67954 Spring for MC60 58 68111 Running Clamp for MC60 88

68070 Bearing 6306 for MC60 29 67953 Pin Shaft for MC60 59 68112

24985 Plug Cover for MC60 30 68092 Shifting Yoke for MC60 60 68113 Agitator Joint Shaft for MC60 90

Bolt M10x25 for MC60 89

74

24

Parts Breakdown

Model MX-CN-0080 44391 General Assembly

25

Parts Breakdown

Model MX-CN-0080 44391 Head

26

Parts Breakdown

Model MX-CN-0080 44391 General Assembly

Item No. Description Position Item No. Description Position Item No. Description Position

67982 Flat Washer 10 for MC80 101 68002 O-Ring 250x5.3G for MC80 137 68024 Block for MC80 175

68114 Wire Whipper for MC80 102 68003 Top Cover for MC80 139 68019 Hexagon Screw M6x16 for MC80 176

67984 Slotted Screws M8x15 for MC80 103 68004 Pin 5x25 for MC80 140 68025 Back Cover Plate for MC80 177

68115 Spiral Hook for MC80 104 68005 Gear Shift Lever for MC80 141 24938 Flat Washer 14 for MC80 178

67986 Shaft for MC80 106 68006 Press Board for MC80 142 68026 Tour Guide for MC80 179

67987 Phillips Screw M6x60 for MC80 107 67784 Hexagon Screws M6x10 for MC80 143 67851 Phillips Screw M5x16 for MC80 180

25796 Rubber Grip for MC80 108 68007 Hexagon Screw M8x40 for MC80 144 68027 Clamp Screw for MC80 181

68116 Flat Beater for MC80 109 68008 Shaft for MC80 146 68028 Phillips Screw M4x10 for MC80 182

67989 Side Guard for MC80 110 68009 Spring Washer 10 for MC80 147 39316 Spring Washer 6 for MC80 183

65319 Bolt M12x50 for MC80 111 68118 Slotted Screws M8x15 for MC80 149 68029 Bowl Roller Seat for MC80 184

65321 Spring Washer 12 for MC80 112 68010 D4C Switch for MC80 150 68030 Bracket Block 2 for MC80 185

67990 Subplate for MC80 11 3 67989 Body Assembly for MC80 151 68031 Support for MC80 186

67865 Spring Washer 5 for MC80 114 68011 Hexagon Screws M8x12 for MC80 152 68032 Bottom Cover for MC80 187

67991 Hexagon Screw M5x25 for MC80 115 68012 Hexagon Screws M8x12 for MC80 153 68033 Spring for MC80

67846 Hexagon Screw M6x20 for MC80 116 68013 Stop Switch-1 for MC80 154 67828 Bolt M8x20 for MC80 189

39316 Spring Washer 6 for MC80 117 68014 Stop Switch-1 for MC80 154 68034 Wheel Plate for MC80 190

67914 Nut M6 for MC80 118 67833 Parameter Plate for MC80 156 68035 Wheel for MC80 191

67992 Gasket for MC80 119 25778 Timer for MC80 157 68036 Belt 10PJ 570 for MC80 192

67796 Located Bloc for MC80 120 68015 Sticker for MC80 158 68037 Shaft Sleeve for MC80 193

67798 Located Bloc for MC80 121 68016 Sticker for MC80 158 68038 Bearing 6304 for MC80 194

67993 Hexagon Screws M6x40 for MC80 122 67823 Hexagon Screws M4x6 for MC80 160 25141 Nut M10 for MC80 195

67994 Safety Guard for MC80 123 68017 Handle-Shifter Seat for MC80 161 68039 Bolt M10x100 for MC80 196

68117 Bowl for MC80 124 68018 Key C6x35 for MC80 162 68040 Shaft Block for MC80 197

67996 Bolt M6x16 for MC80 125 68019 Hexagon Screw M6x15 for MC80 163 68041 Hexagon Screw M10x40 for MC80 198

67997 Angle Iron for MC80 126 68020 Small Pulley for MC80 164 24882 Spring Washer 10 for MC80 199

25720 Pin 4x25 for MC80 127 68021 Lifting Motor for MC80 165 67947 Flat Key 6x22 for MC80 200

25046 Spring for MC80 128 67779 Nut M6 for MC80 166 68042 Screw Rod for MC80 201

67998 Top Cover Assembly for MC80 129 25096 Spring Washer 8 for MC80 168 68043 Feed Screw Nut for MC80 202

67999 Bracket Block 1 for MC80 130 68022 Bolt M8x30 for MC80 167 68044

25141 Nut M10 for MC80 131 65326 Bolt M10x30 for MC80 169 68045 Hexagon Screw M10x25 for MC80 204

68000 Ventilation Plate for MC80 132 67803 Speed Control for MC80 170 68046 Limit Switch for MC80 205

68001 O-Ring 55x5G for MC80 133 24924 Stop Button for MC80 171 68047 Strut for MC80 206

24922 Start Button for MC80 134 25030 Spring Washer 12 for MC80 172 68048 Electrical Bafe for MC80 207

67775 Emergency Stop Button for MC80 135 68023 Lifting Clamp for MC80 173 68049 Heavy Duty Connector for MC80 208

24924 Stop Button for MC80 136 65303 Bolt M12x35 for MC80 174 67802 Screw ST4.8x12 for MC80 209

Nut Clamp for MC80 203

188

27

Parts Breakdown

HeadModel MX-CN-0080 44391

Item No. Description Position Item No. Description Position Item No. Description Position

68050 Gear for MC80 1 68071 Cover, Gear Housing for MC80 31 68093 Steel Ball 8 for MC80 61

68051 Coil Spring for MC80 2 68072 Nut M24x2 for MC80 32 68094 Gasket for MC80 62

68052 Roller for MC80 3 68073 Spring Washer 24 for MC80 33 39316 Spring Washer 6 for MC80 63

68053 Super Machine Parts for MC80 4 68074 Mid-Gear Wheel for MC80 34 68095 Declutch Shift Shaft for MC80 64

68054 Level Drive Gear for MC80 5 67940 Flat Key 8x28 for MC80 35 25141 Nut M10 for MC80 65

68055 Clutch Gear for MC80 6 68075 Flat Key 8x32 for MC80 36 68096 Cam-Gear Shifter for MC80 66

68056 Bushing for MC80 7 68076 Circlips for Shaft 25 for MC80 37 68097 Elastic Cylindrical Pin 4x45 for MC80 67

68057 Sleeve Clutch for MC80 8 68077 Plug 1 for MC80 38 68098 Spring for MC80 68

68058 Clutch Gear for MC80 9 24882 Spring Washer 10 for MC80 39 68099 Plate-Shifter Index for MC80 69

68059 Shaft Bushing for MC80 10 68078 Circlips 62 for MC80 40 68100 Handle-Shifter for MC80 70

28665 Bearing 6209 for MC80 11 68038 Bearing 6304 for MC80 41 65394 Phillips Screw M6x20 for MC80 71

68060 Oil Seal for MC80 12 68079 Circlips 52 for MC80 42 68101 Gear Box for MC80 72

68061 Bushing for MC80 13 68080 Circlips 72 for MC80 43 68102 Internal Gear for MC80 73

68062 Nut M27x2 for MC80 14 68081 Bushing for MC80 44 68041 Hexagon Screw M10x40 for MC80

68063 Spring Washer 27 for MC80 15 68082 Gear for MC80 45 68103 Worm Wheel for MC80 75

68059 Shaft Bushing for MC80 16 68083 Gasket for MC80 46 25765 Elastic Cylindrical Pin 6x30 for MC80 76

65338 Flat Key 10x50 for MC80 17 68084 Pin 8x26 for MC80 47 68104 Motor for MC80 77

68064 Flat Key 10x40 for MC80 18 65348 Nut M20x1.5 for MC80 48 25030 Spring Washer 12 for MC80 78

68065 Main Shaft for MC80 19 68085 Gear for MC80 49 65303 Bolt M12x35 for MC80 79

68066 Key C10x60 for MC80 20 68086 Spring Washer 20 for MC80 50 68105 Flat Key 8x40 for MC80 80

64977 Thumb Screw for MC80 21 68087 Gear Wheel for MC80 51 68070 Bearing 6306 for MC80 81

24967 Attachment Hole Plug for MC80 22 68088 Worm Gear for MC80 52 68106 Bearing 6007 for MC80 82

67846 Hexagon Screw M6x20 for MC80 23 68089 Flat Key 8x25 for MC80 53 24999 Oil Seal for MC80 83

68067 Attachment Hub for MC80 24 68090 Circlips for Shaft 34 for MC80 54 68107 Planetary Gear for MC80 84

67849 Gasket for MC80 25 25034 Circlips for Shaft 20 for MC80 55 68108 Circlips for Shaft 30 for MC80 85

68068 Bevel Gear Unit for MC80 26 68091 Plug 2 for MC80 56 68109 Working Shaft for MC80 86

68045 Hexagon Screw M10x35 for MC80 27 24957 Plunger-Shifter Yoke for MC80 57 68110 Operating Shaft for MC80 87

68069 Bearing 6305 for MC80 28 67954 Spring for MC80 58 68111 Running Clamp for MC80 88

68070 Bearing 6306 for MC80 29 67953 Pin Shaft for MC80 59 68112

24985 Plug Cover for MC80 30 68092 Shifting Yoke for MC80 60 68113 Agitator Joint Shaft for MC80 90

Bolt M10x25 for MC80 89

74

28

Model MX-CN-0020 43560

Electrical Schematics

29

Electrical Schematics

Model MX-CN-0030 44388 Model MX-CN-0040 44389

CODE DESCRIPTION CODE DESCRIPTION

C1 START CAPACITOR LS OVERFLOW PROTECT SWITCH C2 WORKING CAPACITOR M1 MAIN MOTOR CT1 MICROSWITCH SB1 STOP BUTTON CT2 MICROSWITCH SB2 START BUTTON KM1 AC CONTACTOR T1 TIMER

30

Model MX-CN-0060 44390 Model MX-CN-0080 44391

Electrical Schematics

CODE DESCRIPTION CODE DESCRIPTION

BT1 Transformer QF1 Breaker CT1 Microswitch QF2 Breaker CT2-3 Microswitch QF3 Breaker FU1-2 Fuse SB1 Stop Button FU3 Fuse SB2-4 Start Button KM1 Contactor T1 Timer KM2-3 Contactor

31

Notes

________________________________________________________________________________________

32

Notes

________________________________________________________________________________________

33

Notes

________________________________________________________________________________________

34

Warranty Registration

Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at

the perforation and then send to the address specied below. You can also register online by visiting:

Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la

carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:

Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación, cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:

https://omcan.com/warranty-registration/

For mailing in Canada

Pour postale au Canada

Por correo en Canadá

OMCAN

PRODUCT WARRANTY REGISTRATION

3115 Pepper Mill Court,

Mississauga, Ontario

Canada, L5L 4X5

PRODUCT WARRANTY REGISTRATION

4450 Witmer Industrial Estates, Unit 4,

For mailing in the US

Pour diffusion aux États-Unis

Por correo en los EE.UU.

OMCAN

Niagara Falls, New York

USA, 14305

or email to: service@omcan.com



Purchaser’s Information

Name: Company Name:

Address:

Telephone:

City: Province or State: Postal or Zip: Email Address:

Country: Type of Company:

Restaurant Bakery Deli

Dealer from which Purchased: Butcher Supermarket Caterer

Dealer City: Dealer Province or State: Institution (specify):

Invoice: Other (specify):

Model Name: Model Number: Serial Number:

Machine Description:

Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):

Would you like to extend the warranty? Yes No

Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

35

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers. Today with partners in North America, Europe, Asia and South America, we continually work to improve

and grow the company. We strive to offer customers exceptional value through our qualied local sales

and service representatives who provide convenient access to over 5,000 globally sourced products.

Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à

nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 5000

produits provenant du monde entier.

Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un fácil acceso a más de 5,000 productos con origen a nivel mundial.

Omcan MX-CN-0060 Operators Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
