Omcan MX-CN-0007-HG, MX-CN-0007-HW Operators Manual

Bakery 7 QT Mixers

Models MX-CN-0007-HW, 0007-HG

Items 44306, 44475

Instruction Manual

Revised - 09/19/2018

Toll Free: 1-800-465-0234

Fax: 905-607-0234

Email: service@omcan.com

www.omcan.com

Table of Contents

Model MX-CN-0007-HW / Model MX-CN-0007-HG

Section

General Information

Safety and Warranty

Technical Specications

Installation

Operation

Maintenance

-------------------------------------------------------------------------------------------- 7

----------------------------------------------------------------------------------------- 7 - 8

----------------------------------------------------------------------------------------- 8

--------------------------------------------------------------------------- 3 - 4

--------------------------------------------------------------------------- 4 - 6

Page

-------------------------------------------------------------------------- 6

Troubleshooting

Parts Breakdown

Electrical Schematics

Notes

Warranty Registration

------------------------------------------------------------------------------------------- 13 - 14

------------------------------------------------------------------------------------- 9

---------------------------------------------------------------------------- 10 - 11

---------------------------------------------------------------------------- 12

---------------------------------------------------------------------------- 15

2

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the external packaging, open carton to ensure all ordered items are within the box, and there is no concealed

damage to the machine. If the package has su󰀨ered rough handling, bumps or damage (visible or concealed),

please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Before operating any equipment, always read and familiarize yourself with all operation and safety

instructions.

Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save these instructions for future reference. Also save the original box and packaging for shipping the

equipment if servicing or returning of the machine is required.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises

manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

3

General Information

Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations et les consignes de sécurité.

Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces

instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour

l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada. Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de

funcionamiento y seguridad.

Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el

envío del equipo si servicio técnico o devolución de la máquina que se requiere.

Safety and Warranty

WARNING

These precautions should be followed at all times. Failure to follow these precautions could result in

injury to yourself and others or damage the equipment.

• Plug only into grounded electrical outlets matching the nameplate rated voltage.

• Do not modify or tamper with safety switches.

• Do not operate unattended.

• Do not operate equipment in public areas and/or around children.

4

Safety and Warranty

• Do not use an extension cord with this equipment. Do not plug this equipment into a power strip or multi-

outlet power cord.

• Non-Omcan attachments are not recommended. They will not work properly and will void the warranty.

• Check equipment before each use to insure the equipment is clean.

• Do not use a hose to clean mixer. Use a damp cloth to wipe down the exterior of the mixer.

• Wear proper apparel! Do not wear loose tting or hanging garments while operating this equipment.

• Have equipment installed by a qualied personnel in accordance with local codes and ordinances.

• Use equipment in a at, level position.

• Unplug equipment, turn o󰀨 and let it cool before cleaning or moving.

• Do not spray controls or outside of equipment with liquids or cleaning agents.

• Do not clean the equipment with steel wool.

• Keep equipment and power cord away from open ames, electric burners or excessive heat.

• Do not operate if equipment has been damaged or is malfunctioning in any way.

• Do not use the attachments on hub while mixing.

SAFETY TIPS The planetary mixer is a dangerous appliance and must only be used by trained personnel in

accordance with these instructions.

• Position on a at, stable surface.

• A service agent/qualied technician should carry out installation and any repairs if required. Do not remove

any components on this product.

• Consult Local and National Standards to comply with the following:

- Health and Safety at Word Legislation.

- Fire Precautions.

- IEE Wiring Regulations.

- Building Regulations.

• Always stand BEHIND the safety guard when operating the appliance.

• DO NOT place hands near the rotating attachments when in use. This can result in severe injury.

• DO NOT remove food from the appliance until the mixing attachments have come to a complete stop.

• DO NOT immerse the appliance in water.

• DO NOT attempt to mix items that this machine is not designed for. This can damage the mixing

attachments.

• DO NOT use with a damaged mixing attachment.

• DO NOT bypass the safety interlocks.

• Always switch o󰀨 and disconnect the power supply to the appliance when not in use.

• NEVER leave the appliance unattended when in use.

• The appliance is heavy. Take care when moving.

• This appliance must only be used in accordance with these instructions and by persons trained to do so.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

• Keep all packaging away from children. Dispose of the packaging in accordance to the regulations of local

authorities.

5

Safety and Warranty

• If the power cord is damaged, it must be replaced by an Omcan authorized agent or recommended qualied technician in order to avoid a hazard.

• Never use accessories which are not recommended by the manufacturer. They could pose a safety risk to

the user and might damage the appliance. Only use original parts and accessories.

• DO NOT use jet/pressure washers to clean the appliance.

1 YEAR PARTS AND LABOUR BENCH WARRANTY

Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop o󰀨 to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the

equipment.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not

improper use.

Please see www.omcan.com/warranty.html for complete info.

WARNING:

The packaging components are classied as normal solid urban waste and can therefore be disposed of without di󰀩culty.

In any case, for suitable recycling, we suggest disposing of the products separately (di󰀨erentiated waste) according to the current norms.

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

Technical Specications

Model MX-CN-0007-HW MX-CN-0007-HG Mixer Color White Grey

Bowl Volume 7 L / 7.4 QT

Electrical 110V / 60Hz

Power 280W

Current 3.6A Dimensions 16.1” x 16.5” x 9.1” / 410 x 420 x 230mm Weight 33.1 lbs. / 15 kgs. Item Number 44306 44475

6

Installation

• Remove the appliance from all packaging.

• While positioning on a work top, ensure the appliance is secured in position.

Note: Ensure the feet are level to reduce vibration during operation.

ASSEMBLY

WARNING

• Ensure the appliance is switched o󰀨 and disconnected from power supply before assembly/disassembly.

• Omcan accepts no responsibility for any injury caused by incorrect assembly of this appliance.

• The bowl must be attached into position prior to starting the Planetary Mixer.

1. Lift the handle clockwise ( position) until the mixer head rises and rests stably.

2. Select the desired mixer attachment and x onto the mixer head. Turn right to x it into place.

3. Attach the bowl to the bowl seat. Turn clockwise to lock it into place.

Note: Reverse the procedure to remove the bowl.

4. Lift and hold the handle ( position) while lowering the mixer head fully. Then lower the handle counterclockwise ( position) and release to lock the mixer head in place.

NOTE: Ensure the mixer head is locked in place or the mixer will not work.

CHANGING THE MIXER ATTACHMENT

1. Turn O󰀨 the appliance.

2. Raise the mixer head as instructed previously.

3. Push the mixer attachment up and to the left to release.

4. Insert the desired attachment. Push up and to the right to lock it into place.

5. Lower the mixer head in place.

Mixer Attachments Intended Use Suitable Speed

Spiral Dough Hook Heavy mixes; dough, pie pastry, etc. Slow Beater Firm mixes; light pastry, cake/biscuit mix, icing, llings

and mashed vegetables.

Whisk Light mixes; whipped cream, mayonnaise, egg

whites, pancakes and sou󰀪és.

Medium

Fast

Operation

WARNING

• Ensure that these instructions have been read thoroughly and the operation of the appliance is fully understood before use.

• All personnel must be fully trained on the operation and safety precautions of the Planetary Mixer.

7

Operation

LAYOUT OF CONTROLS

1. START button: Press to start the mixer.

2. STOP button: Press to stop the mixer.

3. Speed control knob: Use to set the speed of the mixer.

MIXING

WARNING: Always ensure the appliance is turned o󰀨

before placing hands in the mixing bowl.

1. Raise the mixer head.

2. Fill the bowl.

3. Lower the mixer head and lock it in place.

4. Select the desired speed.

Warning: Recommend that you start with the slowest speed and increase the speed gradually as necessary. Ensure the mixer head and bowl are fully locked in place or the mixer will not work.

5. Press the START button to begin mixing.

Note: If the appliance is straining to mix then turn the appliance O󰀨 and remove some of the contents from the bowl before restarting.

6. After use, slowing turn the speed control knob to MIN, then press the STOP button and disconnect the mixer from power supply.

OVERLOAD PROTECTION

The appliance is featured with overload protection. In case of overload, the appliance will beep then stop working automatically.

1. Turn O󰀨 the mixer.

2. Reduce the load in the mixing bowl.

3. Press the START button to re-start.

Maintenance

• Always turn o󰀨 the mixer and disconnect from the power supply before cleaning.

• Use warm soap water to clean the bowl and mixing attachments. Do not use abrasive cleaning chemicals

as these can leave harmful residues.

• Clean the exterior of the appliance with a damp cloth.

• Dry all parts thoroughly after cleaning.

• Do not use jet/pressure washers to clean the appliance.

• Clean the appliance regularly.

• Do not submerge in water or any other liquid.

8

Troubleshooting

Problem Possible Causes Action Required

The appliance is not working. The unit is not switched on. Check the unit is plugged in

correctly and switched on.

Plug and lead are damaged. Call Omcan or a qualied Omcan

Technician. Fuse in the plug has blown. Replace the fuse. Problem with the power supply. Check power supply. Internal wiring fault. Call Omcan or a qualied Omcan

Technician. The overload protection has

activated. Safety guard is not closed. Close safety guard fully.

The mixer slows down. The mixing bowl is overloaded. Turn o󰀨 the appliance and empty

Mixing speed too high or a wrong mixing attachment used.

The appliance is noisy. Bowl or mixing attachment not

correctly tted.

Bowl or mixing attachment is deformed.

See overload protection

instructions.

some of the contents.

Select the suitable speed and

mixing attachment.

Remove and ret bowl/mixing

attachment.

Call Omcan or a qualied Omcan

Technician.

REFERENCE

Item Number Model Number Description

44306 MX-CN-0007-HW

44475 MX-CN-0007-HG

Mixer Bakery 7 QT/2 Gal White with Guard

0.37 HP/270 W 110V/60/1 cETLus/ETL

Mixer Bakery 7 QT/2 Gal Grey with Guard

0.37 HP/270 W 110V/60/1 cETLus/ETL

Manufacturer Model

Number

HL-7C-WHITE

HL-7C-GRAY

9

Parts Breakdown

Model MX-CN-0007-HW 44306 Model MX-CN-0007-HG 44475

10

Model MX-CN-0007-HW 44306 Model MX-CN-0007-HG 44475

Parts Breakdown

Item No.

67126 Cover for HL-7C 1 67153 Circlip for Hole for HL-7C 28 67180 Switch Base for HL-7C 55

67127 Band for HL-7C 2 67154 Screw for HL-7C 29 67181 Speed Control for HL-7C 56

67128 Screw for HL-7C 3 67155 Spring Washer for HL-7C 30 67182 Handle Spindle for HL-7C 57

67129 Wire Whip for HL-7C 4 67156 Support Cover for HL-7C 31 67183 Handle for HL-7C 58

67130 Flat Beater for HL-7C 5 67157 Gear for HL-7C 32 67184 Arc Slide Block for HL-7C 59

67131 Hook for HL-7C 6 67158 Gear Shaft for HL-7C 33 67185 Torsion Spring for HL-7C 60

67132 Metal Ring for HL-7C 7 67159 Oil Seal for HL-7C 34 67186 Support Sleeve for HL-7C 61

67133 Safety Guard for HL-7C 8 67160 Axle for HL-7C 35 67187 Base for HL-7C 62

67134 Bowl For HL-7C 9 67161 Gear for Axle for HL-7C 36 67188 Waterproof Joint for HL-7C 63

67135 Deep Groove Ball Bearing for HL-7C 10 67162 Bushing for HL-7C 37 67189 Power Switch for HL-7C 64

67136 Circlip for Shaft for HL-7C 11 67163 Synchronous Belt for HL-7C 38 67190 Bowl Seat for HL-7C 65

67137 Gear for HL-7C 12 67164 Nut for HL-7C 39 67191 Travel Switch for HL-7C 66

67138 Woodruff Key for HL-7C 13 67165 Large Synchronous Pulley for HL-7C 40 67192 Screw for HL-7C 67

67139 Main Shaft for HL-7C 14 67166 Circlip for Shaft for HL-7C 41 67193 Nut for HL-7C 68

67140 Deep Groove Ball Bearing for HL-7C 15 67167 Small Synchronous Pulley for HL-7C 42 67194 Screw for HL-7C 69

67141 Oil Seal for HL-7C 16 67168 Screw for HL-7C 43 67195 Distance Switch Support for HL-7C 70

67142 Operation Frame for HL-7C 17 67169 Motor (110V 60Hz) for HL-7C 44 67196 Distance Switch for HL-7C 71

67143 Circlip for Shaft for HL-7C 18 67170 Rotating Base for HL-7C 45 67197 Screw for HL-7C 72

67144 Planet Gear for HL-7C 19 67171 Screw for HL-7C 46 67198 PCB for HL-7C 73

67145 Planet Gear Pad for HL-7C 20 67172 Inner Gear for HL-7C 47 67199 Screw for HL-7C 74

67146 Deep Groove Ball Bearing for HL-7C 21 67173 Screw for HL-7C 48 67200 Base Plate for HL-7C 75

67147 Oil Seal for HL-7C 22 67174 Nut for HL-7C 49 67201 Rubber Pads for HL-7C 76

67148 Planet Shaft for HL-7C 23 67175 Locating Pin for HL-7C 50 67202 Screw for HL-7C 77

67149 Pin for HL-7C 24 67176 Screw for HL-7C 51 67203 Plug for HL-7C 78

67150 Flat Washer for HL-7C 25 67177 Double Torsion Spring for HL-7C 52 67204 PCB Guard for HL-7C 79

67151 Spring Washer for HL-7C 26 67178 Rotating Shaft for HL-7C 53

67152 Nut for HL-7C 27 67179 Speed Mark for HL-7C 54

Description Position

Item No.

Description Position

Item No.

Description Position

11

Electrical Schematics

Model MX-CN-0007-HW 44306 Model MX-CN-0007-HG 44475

12

Notes

________________________________________________________________________________________

13

Notes

________________________________________________________________________________________

14

Warranty Registration

Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear o󰀨 the card at the perforation and then send to the address specied below. You can also register online by visiting:

Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la

carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:

Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación, cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:

www.omcan.com/warrantyregistration.html

For mailing in Canada

Pour postale au Canada

Por correo en Canadá

OMCAN

PRODUCT WARRANTY REGISTRATION

3115 Pepper Mill Court,

Mississauga, Ontario

Canada, L5L 4X5

PRODUCT WARRANTY REGISTRATION

4450 Witmer Industrial Estates, Unit 4,

For mailing in the US

Pour di󰀨usion aux États-Unis

Por correo en los EE.UU.

OMCAN

Niagara Falls, New York

USA, 14305

or email to: service@omcan.com



Purchaser’s Information

Name: Company Name:

Address:

Telephone:

City: Province or State: Postal or Zip: Email Address:

Country: Type of Company:

Restaurant Bakery Deli

Dealer from which Purchased: Butcher Supermarket Caterer

Dealer City: Dealer Province or State: Institution (specify):

Invoice: Other (specify):

Model Name: Model Number: Serial Number:

Machine Description:

Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):

Would you like to extend the warranty? Yes No

Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

15

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers. Today with partners in North America, Europe, Asia and South America, we continually work to improve

and grow the company. We strive to offer customers exceptional value through our qualied local sales

and service representatives who provide convenient access to over 5,000 globally sourced products.

Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à

nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 5000

produits provenant du monde entier.

Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un fácil acceso a más de 5,000 productos con origen a nivel mundial.

Omcan MX-CN-0007-HG, MX-CN-0007-HW Operators Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
