Page 1

Slush Machines

Models DI-IT-0010-S, 0020-S, 0030-S

Items 39677, 39678, 39679

Instruction Manual

Revised - 04/05/2017

Toll Free: 1-800-465-0234

Fax: 905-607-0234

Email: service@omcan.com

www.omcan.com

Page 2

Table of Contents

Model DI-IT-0010-S / Model DI-IT-0020-S / Model DI-IT-0030-S

Section

General Information

Safety and Warranty

--------------------------------------------------------------------------- 3 - 4

--------------------------------------------------------------------------- 4 - 5

Technical Specications

Installation

Operation

Maintenance

-------------------------------------------------------------------------------------------- 6

----------------------------------------------------------------------------------------- 6 - 7

----------------------------------------------------------------------------------------- 8

Page

---------------------------------------------------------------------- 5 - 6

Figure Drawings

Parts Breakdown

Electrical Schematics

Warranty Registration

------------------------------------------------------------------------------------ 9

---------------------------------------------------------------------------- 10 - 13

---------------------------------------------------------------------------- 14

---------------------------------------------------------------------------- 15

Page 3

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the external packaging, open carton to ensure all ordered items are within the box, and there is no concealed damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Before operating any equipment, always read and familiarize yourself with all operation and safety

instructions.

Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save these instructions for future reference. Also save the original box and packaging for shipping the

equipment if servicing or returning of the machine is required.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant

d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

Page 4

General Information

Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations et les consignes de sécurité.

Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces

instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour

l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada. Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes

o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro

de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de

funcionamiento y seguridad.

Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el

envío del equipo si servicio técnico o devolución de la máquina que se requiere.

Safety and Warranty

USEFUL INFORMATION

• Do not pour hot mixture into the containers.

• To increase slurry production, top up with fresh mixture as opposed to leaving the evaporator uncovered

during operation.

• During operation, it is normal that the machine emits heat. Should this heat appear excessive, check that the condenser is not obstructed by dust (see relative condenser cleaning section), or that the machine is

Page 5

Safety and Warranty

not positioned close to a heat source (see installation section).

• Ensure that the product sugar content is within the 15% – 25% limit when preparing the mixture. Lower levels will inhibit slurry production due to the reduction motor protection system, while higher levels will result in delays due to the higher sugar content corresponding to a lower freezing point.

• To ensure that avours remain unaltered, clean all components that are in direct contact with the product at

least every two days.

• Should the type of product be changed, empty the container(s) and pour in hot water and leave to stand. Wait 15 minutes before emptying. Do not use the refrigeration cycle during this period.

PRINCIPAL RULES

• Do not touch the machine with wet hands.

• Do not use the equipment barefoot.

• Do not permit incapable persons or children to operate the machine.

• Do not leave the equipment outdoors or otherwise exposed to the elements.

1 YEAR PARTS AND LABOUR BENCH WARRANTY

Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized

service technician to repair the equipment locally.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not

improper use.

Please see www.omcan.com/warranty.html for complete info.

WARNING:

The packaging components are classied as normal solid urban waste and can therefore be disposed of without difculty.

In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms.

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

Technical Specications

Model DI-IT-0010-S DI-IT-0020-S DI-IT-0030-S Capacity 10 L / 10.6 QT 2 x 10 L / 2 x 10.6 QT 3 x 10 L / 3 x 10.6 QT Max. Temperature -6°C / 21.2°F

Page 6

Technical Specications

Electrical 115V / 60 Hz Refrigerant R404 Current 8A 10A 11.3A

Dimensions

Packaging Dimensions

Weight 66.1 lbs. / 30 kgs. 110.2 lbs. / 50 kgs. 148.8 lbs. / 67.5 kgs.

Packaging Weight 75 lbs. / 34 kgs. 121.3 lbs. / 55 kgs. 160.9 lbs. / 73 kgs.

Item Number 39677 39678 39679

7.1” x 24.4” x 32.3”

180 x 620 x 820mm

11” x 24” x 33”

279 x 610 x 838mm

14.2” x 24.4” x 32.3” 360 x 620 x 820mm

15.7” x 24.4” x 34.3” 400 x 620 x 870mm

20.5” x 24.4” x 32.3” 520 x 620 x 820mm

23.6” x 24.4” x 34.3” 600 x 620 x 870mm

Installation

INSTRUCTIONS AND WARNINGS

Remove the machine from the packing, and check for any visible signs of damage that may have occurred during shipping. Remove the protective coverings (plastic bags, etc.) and ensure that they are stored out of

the reach of children. The equipment must never be lifted by the glass or plastic components when being

moved; the company shall not be held responsible for damage caused by improper handling. Check that the

power supply is adequately grounded as required by law, and corresponds to the power specications printed on the equipment placard situated on the front panel or printed in the manual. Do not use multiple adapters: the equipment must be connected to a single outlet. If in doubt, have the machine installed by a qualied

technician. The company declines any responsibility for accidents due to an incorrect installation resulting in

damage to persons or property. Before operating the equipment, clean as per the instructions in the Cleaning and Maintenance section. Install the equipment away from heat sources and leave sufcient space around the machine to ensure adequate cooling by air circulation.

CAUTION: If the containers remain full overnight, blocks of ice may form. Before switching the

machine on, clear any ice from inside the containers to avoid damage to the paddles.

Operation

Before lling the containers, carefully clean and rinse all surfaces that will be exposed to the drinks. Fill the

containers up to the maximum level and replace the illuminated covers.

CAUTION The equipment is not designed for sugar-free liquids. If natural products are used, the sugar content must be between 15% and 25%. If commercial mixes are used for slurries, sorbets, yoghurt or

Page 7

Operation

milk-based drinks, follow the manufacturer’s instructions.

• Move Power Switch (8) to ON.

• Press the reduction motor button (6).

• Press the Bibita (Drinks) button (4) for cold drinks, or the Granita (Slurry) button (5) for slurries.

• Drink temperature or Slurry density may be raised or lowered by using buttons (1) or (2) accordingly. The

density reference or the temperature in degrees C may be read from the display.

• Cover lights are operated by button (7).

EQUIPMENT FUNCTIONS

KEYPAD LEGEND

1. Decrease slurry density. Decrease drink temperature.

2. Increase slurry density. Increase drink temperature.

3. Display:

Slurry function: 1- 3 - 5 - 7 - 9 indicates slurry density, indicates valve open. Drinks function: 4°C - 9°C drink temperature, H° drink temperature higher than 9°C, L° drink

temperature lower than 4°C

4. Cold drink function.

5. Slurry function.

6. Reduction motor (press ON/OFF).

7. Cover lights (press ON/OFF).

The machine memorizes the last selected settings when switched off for any length of time. Raising a cover will cause the relative container paddle to stop and the display will go out to indicate a stopped condition. The cover lights may be switched on or off

as required by using the appropriate button. If sugar content is insufcient, or foreign bodies or blocks

of ice are detected in a container, a sensor will halt paddle rotation so as not to overload the reduction motor. The display will show an error symbol ( ).

Once the cause of the stoppage has been rectied,

replace the cover, press reduction motor button (6), and either the drinks (4) or slurry (5) button, and the machine will restart.

Page 8

Maintenance

CLEANING AND MAINTENANCE

CAUTION: Before attempting any cleaning or maintenance, ensure that the power switch is OFF, and that the plug is removed from the mains. Never remove the plug by pulling the power cable (Fig. A).

It is imperative that machine components having direct contact with the products are cleaned thoroughly. Carry out cleaning as per the illustration.

• Remove the illuminated cover.

• Empty the containers.

• Fill containers to remove product residue and rinse out.

• After extracting the base-container pin (Fig. C), Remove containers as shown in Fig. B.

• Remove paddle, internal shaft, and the lower sprocket (Fig. D), and then remove the container gasket (Fig.

E).

• Disassemble the tap (Fig. F) by pulling the two pins from the lever (Fig. G) and turning the locking ring anti- clockwise (Fig. H).

• Unscrew the threaded knob and extract the upper sprocket (Fig. I – L).

• Extract the main gear rack by pulling upwards (Fig. M).

• Wash all components using a suitable detergent and rinse. Do not use abrasive cleaning products.

• Assemble all the previously removed components in reverse order as per the illustrations, and check for

correct operation.

Illuminated covers must be in position before the machine will operate. The containers may now be relled.

CLEANING THE CONDENSER (RADIATOR)

All equipment of this type tends to ingest airborne dust when operating. This dust accumulates on the

condenser inlet surfaces, and should be removed with a soft, dry brush (Fig. N). A condenser clogged by

dust will compromise efcient refrigeration system operation, increase power consumption, and may be the

precursor of serious damage.

REFERENCE

Item Number Model Number Description Manufacturer Model Number

39677 DI-IT-0010-S Slush Machine Grani 10 L / 1 Bowl 115/60 GR1 39678 DI-IT-0020-S Slush Machine Grani 10 L / 2 Bowl 115/60 GR2 39679 DI-IT-0030-S Slush Machine Grani 10 L / 3 Bowl 115/60 GR3

Page 9

Figure Drawings

Page 10

Parts Breakdown

Model DI-IT-0010-S 39677 Model DI-IT-0020-S 39678 Model DI-IT-0030-S 39679

Page 11

Parts Breakdown

Model DI-IT-0010-S 39677

Item No. Description Position Item No. Description Position Item No. Description Position

70748 Lid for GR1, 2, 3 1 70766 Evaporator for GR1, 2, 3 22 70781 Upper Sprocket for GR1, 2, 3 43

70749 Front Glass for GR1, 2, 3 2 70767 Base for GR1, 2, 3 23 70782 Threaded Knob for GR1, 2, 3 44

70750 Rear Glass for GR1, 2, 3 3 70768 Gasket Front Evaporator for GR1, 2, 3 24 70783 Lower Sprocket for GR1, 2, 3 45

70751 Inner Cover for GR1, 2, 3 4 70769 Gasket Rear Evaporator for GR1, 2, 3 25 42901 Propeller Shaft for GR1, 2, 3 46

70752 Light-Bulb Holder for GR1, 2, 3 5 70770 Reduction Motor for GR1, 2, 3 26 42902 Spiral for GR1, 2, 3 47

70753 Light-Bulb for GR1, 2, 3 6 70771 Bakelite Gear for GR1, 2, 3 27 42903 Tank Basket for GR1, 2, 3 48

70754 Lid Electrical Contacts for GR1, 2, 3 7 70772 Sinterizate Gear for GR1, 2, 3 28 70784

42897 Container for GR1, 2, 3 8 70773 Base Plug for GR1, 2, 3 29 70785 Electrical Contact Cover for GR1, 2, 3 50

70755 Tap Piston for GR1, 2, 3 9 70774 Metal Hook Tank Safety Pin for GR1, 2, 3 30 70786 Shoulder Cover for GR1, 2, 3 51

42898 Basket with Lip for GR1, 2, 3 10 70775 Evaporator Swab for GR1, 2, 3 31 70787 Tank Safety Pin for GR1, 2, 3 52

42899 Or Tap for GR1, 2, 3 11 70776 Gear Slide Pin for GR1, 2, 3 32 70800 Fan for GR1 53

70756 Piston Spring for GR1, 2, 3 12 70777 Cable Lock for GR1, 2, 3 33 70788 Electrical Circuit Board for GR1, 2, 3 54

70757 Tap Plug for GR1, 2, 3 13 42900 Reduction Motor Sensor for GR1, 2, 3 34 70789 Circuit Board Cover for GR1, 2, 3 55

70758 Lever Tap for GR1, 2, 3 14 70778 Electrical Cable for GR1, 2, 3 35 70790 Controls for GR1, 2, 3 56

70759 Lever Safety Pin (Lower) for GR1, 2, 3 15 70795 Condenser for GR1 36 70791 Drip Tray for GR1, 2, 3 57

70760 Lever Safety Pin (Upper) for GR1, 2, 3 16 70796 P.M. Electric Valve for GR1 37 70792 Drip-Tray Grille in Plastic for GR1, 2, 3 58

70761 Shoulder for GR1, 2, 3 17 70797 Valve Coil for GR1 38 70801 Front Panel for GR1 59

70762 Thermostat for GR1, 2, 3 18 70798 Transformer for GR1 39 70793 Power Switch for GR1, 2, 3 60

70763 Return for GR1, 2, 3 19 70799 Compressor for GR1 40 70802 Rear Panel for GR1 61

70764 Gear Slide for GR1, 2, 3 20 70779 Charge Valve for GR1, 2, 3 41 70794 Side Panel for GR1, 2, 3 62

70765 Main Gears for GR1, 2, 3 21 70780 Feet for GR1, 2, 3 42 61396 Fuse for GR1, 2, 3

Shoulder Electrical Contacts for GR1, 2, 3

Page 12

Parts Breakdown

Model DI-IT-0020-S 39678
