OMAX Material Holding Kits User Manual

PRECISION ABRASIVE WATERJET ACCESSORIES

Accessory Specifications

Material
Holding Kits

Standard Features

• Each kit is customized to fit your

specific OMAX JetMachining® Center

• Clamps apply pressure to hold stock

in place

• Easy to adjust vertical load clamps

can be positioned anywhere on tracks

• Y-axis tracks can be placed in infinite

locations along the X-axis tracks

• Track components are made from

anodized aluminum

Benefits

• Prevents unwanted work piece move-

ment and scrapped parts

• No machine modifications required

• Reduces material setup time

• Expandable design can incorporate

additional clamps or Y-axis tracks

• Track components are built for

long life in the abrasive waterjet
environment

OMAX® Material Holding Kits

Secure material in place as you accurately cut
parts on your abrasive waterjet.

Designed specifically for your machine size, each
Material Holding Kit includes track assemblies
and vertical load clamping arms. The kit mounts
into the waterjet slat bed with two X-axis tracks,
two Y-axis tracks, four short vertical load clamps,
and four long vertical load clamps.

Material Holding Kits
