Olympus Stylus 150 User Manual

CS1374000000–

EN INSTRUCTIONS 2
FR MODE D’EMPLOI
ES INSTRUCCIONES
PO INSTRUÇÕES
CH



A1103

KR

73

97

121

25
49

2 3

WARNING

CONTENTS

Read this manual carefully before using your camera.

Indicates circumstances which could result in
personal injury or property damage.

KEEP THE BATTERIES AWAY FROM FIRE. NEVER TRY TO
DISASSEMBLE, RECHARGE, OR SHORT-CIRCUIT BATTERIES.

KEEP THE BATTERIES OUT OF THE REACH OF CHILDREN. IF A
CHILD SWALLOWS A BATTERY, CONTACT A DOCTOR
IMMEDIATELY.

NEVER ATTEMPT TO DISASSEMBLE THE CAMERA; IT CONTAINS A
HIGH-VOLTAGE CIRCUIT. IF THE INTERNAL PARTS OF THE CAMERA
ARE EXPOSED DUE TO DROPPING OR DAMAGE, REMOVE THE
BATTERY IMMEDIATELY TO PREVENT FURTHER USAGE.

IN CASE OF MALFUNCTION, CONSULT YOUR NEAREST OLYMPUS
DEALER OR OLYMPUS SERVICE CENTER.

Symbols used in this manual:

Incorrect

Order

Manual
operation

앫Products shown in pictures and illustrations may be slightly different

from the actual unit.

앫Pay particular attention to items in this manual enclosed in boxes

.

Operation
order

Automatic
operation

Depress
halfway

Indicator
on

Indicator
blinking

Attention

Names of parts

Camera body ...................................................................... 4

Viewfinder display/LCD panel ............................................. 5

Using the strap/Diopter adjustment ........................................ 6

Loading and checking the battery ........................................... 7

Loading the film ..................................................................... 8

Taking pictures ....................................................................... 9

Unloading the film ................................................................ 10

Flash photography

Setting the flash mode ..................................................... 11

Auto Flash ........................................................................ 12

Red-Eye Reduction Flash ............................................ 12

Flash-Off ...................................................................... 13

Fill-In Flash .................................................................... 13

Night Scene Flash ........................................................ 14

Red-Eye Reduction Night Scene Flash...................... 14

Exposure modes

Setting the exposure mode .............................................. 15

Spot Metering ............................................................. 15

Infinity ......................................................................... 15

Selftimer/Remote Control/Camera Shake Indicator

Selftimer....................................................................... 16

Remote Control (optional) ............................................. 16

Camera Shake Indicator .............................................. 17

RC-300C (optional) .............................................................. 18

Correcting the date and time (Quartzdate models only)........ 19

Printing the date/time (Quartzdate models only) .................. 20

Care and storage .................................................................. 21

Specifications ....................................................................... 22

2756 Q50N_EN 03.6.3, 10:13 AM2-3

4 5

8

^

&

4

5

1

NAMES OF PARTS — Camera Body

NAMES OF PARTS — Viewfinder Display/LCD Panel

Selftimer indicator/remote
control indicator

Shutter release button

Zoom lever

Strap eyelet

Battery compartment
cover

夡Always try to keep this clean. Dirt and stains can

result in pictures that are unclear and out-of-focus.
Wipe off any dirt or stains with a soft cloth.

Viewfinder

Diopter
adjustment dial

Back cover
release

Green lamp

Back cover

LCD panel

Selftimer/remote
control button

Light sensor夡

Lens barrier

Orange lamp

Exposure mode button

Flash mode button

Viewfinder

Autofocus window夡

Flash夡

Lens夡

Remote control sensor夡

Film window

Battery
compartment
cover

Tripod socket

Date MODE and
SET buttons
(Quartzdate
models only)

Mid-roll
rewind button

2

3

Viewfinder Display

1 Autofocus marks
2 Spot marks
3 Close-up correction marks

4 Green lamp

Lights

Blinks

Blinks

rapidly

You can shoot

You can’t
shoot

You can shoot
while using
caution

The subject is in focus. Press the shutter
release button all the way to take the picture.

The subject is not in focus. The shutter will not
release even if you press the shutter release
button all the way.

The subject is difficult for the autofocus to lock
on. Although the shutter releases, the subject

may be out of focus.

5 Orange lamp

Goes out

You can shoot*

Light

You can shoot*
You can’t

Blinks

shoot

* Shooting is not possible when the green lamp is blinking.

6

The flash doesn’t fire, and the shutter releases.
The flash fires, and the shutter releases.
The flash is being recharged. The shutter

doesn’t release.

7

0

LCD Panel

6 Date/time indicator

(Quartzdate models only)

7 Camera Shake Indicator
8 Exposure counter
9 Remote Control

$

%

!

9

@#

0 Selftimer
! Red-Eye Reduction Flash
@ Fill-In Flash
# Flash-Off
$ Night Scene Flash
% Battery check
^ Spot Metering
& Infinity

Note: Not all indicators are displayed as shown in actual use.

2756 Q50N_EN 03.6.3, 10:13 AM4-5

6 7

USING THE STRAP

LOADING AND CHECKING THE BATTERY

Attach the strap as shown.

DIOPTER ADJUSTMENT

Turn the diopter
adjustment dial until the
autofocus marks are
clear.

If you are nearsighted, turn the
dial up. If you are farsighted,
turn it down.

Use one 3 V lithium battery (CR123A or DL123A).

1

2

3

lights (turns off
automatically).

blinks and other indicators
are displayed normally.

blinks and other indicators
go out.

1. While pressing the bottom of
the battery compartment
cover in direction
in direction

Make sure the lens barrier is
closed before opening the
battery compartment cover.

2. Insert the battery correctly.
Close the battery compart­ment cover.

A brand-new battery lasts for
about 15 rolls of film.

3. Slide the lens barrier in
direction 1 until it clicks.
Check the remaining battery
power on the LCD panel.

Battery is OK. You can shoot.

Battery is low and will need to be replaced
within the next few photos.

Battery is dead and must be replaced with
a new one immediately.

2 to open.

1, turn it
