Olympia OC 1280 P Operating Manual

OC 1280 P Outdoor Camera

Operating Manual

…easy to operate using the

"ProHomeIPC" app from Olympia

Version 03.2016

R

3

D

General Information 7............

Intended Use 7....................

Unintended Use 7......................

Legal Notice 7....................

General Safety Information 8........

General Overview 9...............

Package Contents 9...............

Notations Used in this Manual 9.....

Connections and Operating Elements 10

General View 10.........................

Interfaces on the Connection Cable 11.....

Receiver for Connection to Alarm System 11

Installing the Camera 12...........

1. Connecting the Power Adapter 14.

Use With an Alarm System 14.............

Use Without an Alarm System 16..........

2. Connecting the Network Cable 17..

3. Installing the Camera App 17......

4. Connecting the Camera App to

the Camera 18..................

5. Connecting the Camera

to the WLAN 19.................

6. Last Steps Prior to Assembly 20....

7. What is the Correct Installation

Location for My Camera? 20......

8. Installing the Camera 21..........

9. Assembling the Cable Box 22.....

10. Final Steps 23..................

11. Aligning the Camera 24.........

4

D

Using the ProHomeIPC App 25.....

Operating the Camera (iOS) 27.....

Opening the Menu Bar 27...........

Buttons in the Menu Bar 27..........

Snapshots 27...........................

Activating Night Vision 28.................

Flipping the Image Section Horizontally 29..

Flipping the Image Section Vertically 29....

Changing the Resolution 30...............

Adapting to Environmental Conditions 30...

Start Screen of the ProHomeIPC-App 31
Context Menu of the

ProHomeIPC-App 32............

Camera List 33.....................

Event 34..........................

Add Camera 35....................

QR Code 36............................

Automatic Search 37.....................

Connecting Manually 38..................

Information 39.....................

Remove Camera 40................

Edit Camera 41....................

Device Setting 42........................

Advanced Setting 46................

Alarm Setting 51...................

Time Setting 57....................

5

D

Operating the Camera (Android) 58.

Opening the Menu Bar 58...........

Buttons in the Menu Bar 58..........

Snapshots 58...........................

Activating Night Vision 59.................

Flipping the Image Section Horizontally 60..

Flipping the Image Section Vertically 60....

Changing the Resolution 61...............

Adapting to Environmental Conditions 61...

Start Screen of the ProHomeIPC App 62

Add Device 63.....................

QR Code 64............................

Automatic Search 65.....................

Connecting Manually 66..................

Context Menu of the Camera 67......

Reconnect 68...........................

View Event 69...........................

View Snapshot 70.......................

Remove Camera 71......................

Edit Camera 72..........................

Device Setting 73........................

Advanced Setting 77................

Alarm Setting 81...................

Time Setting 87....................

6

D

Other Important Information 88.....

Guarantee 88......................

Regular Maintenance and Service 88.

Technical Modifications 88...........

Information on Disposal 88..........

CE Mark 88........................

Technical Data 89..................

Troubleshooting 90.................

General Information

7

D

General Information

Please read and observe the following
information and keep this operating

manual in a safe place for future reference!

Intended Use

The OC 1280 P Outdoor Camera (subsequently referred
to as camera) is designed to perform video surveillance
(CCTV) by day and night. When installing and selecting
the area of use of the camera, pay attention to the person
al rights of third-parties and that the respective, applicable
local laws and regulations are not violated.

Unintended Use

The camera is not suitable for use in potentially explosive
areas. The camera is not intended for use outside the per
missible ambient conditions stipulated in the Section
"Technical Data".

Monitoring of third-parties is not permitted without having
obtained the respective, explicit authorisation and could
have legal consequences.

Any use other than that described in Intended Use is con
sidered unintended use. Unauthorised modification

or reconstruction is not permitted.
Under no circumstances open the camera or accessories

or attempt to complete any repair work yourself.

Legal Notice

All the trademarks or brand names on the product and/or
accessories or which appear in this operating manual
serve solely for descriptive purposes and do not imply that
they are freely available. The trademarks and brand
names are the property of the respective proprietor of the
rights.

General Information

8

D

General Safety Information

Observe the following safety instructions in order to pro
tect yourself from the possibility of personal injury and the
product from damage.

 WARNING!

Risk of electric shock!

Never attempt to open and repair the device or acces
sories yourself. Never touch bare contacts with metallic
objects. Never plug-in or unplug the power cable when
your hands are wet. Never open the camera or compo
nents yourself. Repairs to this device may only be com
pleted by properly qualified service personnel.

 WARNING!

Risk of suffocation!

Keep out of reach of children! Keep packaging materials
and protective foils out of reach of children. Keep the de
vice and any accessories out of reach of children.
Small children can swallow small parts. Seek medical at
tention immediately if a small part is swallowed.

ATTENTION!

Do not use the camera in prohibited areas!

Prohibited areas could include public buildings or spaces,
for example. Please observe local laws and regulations!

ATTENTION!

Protect the camera from chemicals, vapours, heat and

direct sunlight.

ATTENTION!

Only use original accessories.

Only connect accessories approved by the manufacturer
to the camera and only us the power adapter supplied.

ATTENTION!

Property damage is possible.

Only use properly installed, easily accessible power sock
ets.

General Overview

9

D

General Overview

This section provides information on the package contents
as well as the connections and operating elements on the
camera.

Package Contents

Unpack the camera and check that the package contents
are complete. The camera package contains the following
components:

 Camera
 Power adapter
 Receiver
 Cable box
 Assembly material (3 screws, 3 dowels)
 Network cable (RJ45/RJ45, Cat.5e)
 Operating manual

Check for any visible signs of damage to the camera
packaging or the components supplied. If there are, do not
put the camera into operation.

Notations Used in this Manual

The section below explains the presentations and nota
tions used in this operating manual.

1. This indicates the first step in a set of instructions.

2. This indicates the next step in a set of instructions.

This symbol indicates useful information which will
help you to use the camera and ProHomeIPC-App.

 Indicates a list.

General Overview

10

D

Connections and Operating Elements

Before installing the camera, familiarise yourself with the connections and operating elements on it.

General View

1234

56789

1 Connection cable (several interfaces) 6 Infrared LEDs (night vision)

2 Device mounting bracket 7 Brightness sensor

3 Union nut for mounting bracket 8 Lens

4 Antenna (for WLAN) 9 Interfaces (see Page 11)

5 Ball joint

General Overview

11

D

Interfaces on the Connection Cable

10

11 12 13 14

10 LEDs for network activity

11 Port (for network cable)

12 Port (for connection to the receiver)

13 Port (for power supply)

14 Reset button

Receiver for Connection to Alarm System

15

16

17

15 Plug (for power supply)

16 Port (for power supply)

17 Plug (for connection to camera)

18 Status LED (not illustrated here)

Installing the Camera

12

D

Installing the Camera

Observe the recommended sequence of working steps
when installing the camera.

To set-up and install your camera easily, we recommend
that you first connect the camera to the home network and
camera app before connecting it at the location of use.

This operating manual describes the sequence of working
steps recommended by us:

1. Connecting the Power Adapter

This section explains how to connect the power supply to
the camera and decide whether you want to use it in con
nection with an alarm system or not.

2. Connecting the Network Cable

This section explains how to define the camera, to be
used in your home network, to the router. This step is nec
essary in order to be able to integrate the camera in your
wireless home network (WLAN).

3. Installing the Camera App

This section explains how to install the relevant Olympia
camera app (ProHome IPC) on your smartphone or tablet
PC.

4. Connecting the Camera App to the
Camera

This section explains how to connect the camera to the
camera app and complete the first function test.

5. Connecting the Camera to the WLAN

This section explains how to connect the camera to the
wireless home network (WLAN).

6. Last Step Prior to Assembly

Before beginning with the installation at the site of use,
you must disconnect all the cable connections again.

Installing the Camera

13

D

7. What is the Correct Installation Location
for My Camera?

To ensure good results of the surveillance, there are a few
points to take into account when selecting a suitable in
stallation location. We can help you make the right deci
sion.

8. Installing the Camera

This section explains how to install the camera at the loca
tion of use.

9. Assembling the Cable Box

This section explains how to install the camera's cable box
at the location of use.

10. Final Steps

This section explains the final work which you must com
plete before you can align the camera and use it in con
nection with the camera app.

11. Aligning the Camera

This section explains how to align the viewing angle of the
camera optimally to the area to be monitored.

Installing the Camera

14

D

1. Connecting the Power Adapter

This section explains how to connect the camera to the
power supply and then decide whether the camera is to
be integrated in an existing alarm system.

Use With an Alarm System

If you want to integrate the camera in an alarm system
(Protect Series 6xxx / 9xxx alarm system from Olympia),
you must use the receiver supplied. If you do not want to
integrate the camera in an alarm system, skip this section
and continue with Use Without an Alarm System.

The receiver is connected directly to the camera and pow
er adapter of the camera. In this case, power is supplied
to the camera from the receiver.

1. Connect the plug (17) on the receiver to the port
(12) on the connection cable of the camera to enable
data exchange with the alarm system.

2. Connect the plug (15) on the receiver to the port
(13) on the connection cable of the camera to provide
the power supply.

3. Connect the power adapter supplied to the port
(16) on the receiver and a power socket.

The LEDs on the network connection port (10) signal
when power is being supplied and a connection exists
to the network (lights up orange) and data is being
transmitted (flashes green).

Registering the Receiver on the Alarm
System

The following section describes how to register the receiv
er on the alarm system.

1. Disconnect the power adapter from the power socket.

2. Select the Register menu on the alarm system

according to the relevant operating manual.

3. Connect the power adapter to the power socket.

4. When the message Siren followed by a number ap

pears in the alarm system display, registration on the
alarm system has been completed successfully.

5. The receiver is now registered on the alarm system.

6. You can alter the Siren entry to Camera or Video, for

example, according to the relevant operating manual.

Installing the Camera

15

D

Installing the Camera

16

D

Use Without an Alarm System

If you want to use the camera without an alarm system
(Protect Series 6xxx / 9xxx alarm system from Olympia),
you do not need the receiver supplied.

1. Connect the power adapter supplied to the
port (13) on the camera's connection cable and a pow
er socket.

Installing the Camera

17

D

2. Connecting the Network Cable

You must identify your camera in your network.
The camera must be assigned an unambiguous address

within your network so that you can access the camera
app on the camera later.

If you have not changed the default setting of your router,
the camera will be assigned an unambiguous address au
tomatically during connection to the router.

In the case of most routers, the DHCP function is acti
vated at the factory. More detailed information on the
DHCP function is provided in the operating manual
supplied with your router.

1. Connect the network cable to the port (11) on the con
nection cable and a free network connection port on
the router.

2. Wait about 60 seconds until the router has automati
cally assigned an unambiguous address to the cam
era.

3. Installing the Camera App

1. Download the ProHomeIPC-App from the App Store

(for iOS) or Google Play Store (for Android).

2. Enable the ProHomeIPC-App access to the camera

of your smartphone or tablet PC and mobile internet.
This simplifies connecting the camera and
ProHomeIPC-App and also provides remote access
to the camera via the smartphone or tablet PC.

You require access to the camera on your smartphone
or tablet PC when you want to scan the QR code as
described in Section Connecting the Camera App to
the Camera.

Access to the camera and mobile internet can also be
enabled or refused later in the setting options provided
by your smartphone or tablet PC. More detailed infor
mation is provided in the operating manual supplied
with your smartphone or tablet PC.

Installing the Camera

18

D

4. Connecting the Camera App to
the Camera

1. Connect your smartphone or tablet PC to the same

wireless network (WLAN) in which the camera is inte
grated.

2. Start the ProHomeIPC-App.

3. Touch Add Device or Click here to add camera.

4. Touch QRCode or Scan.

5. Scan the QR code on the rear of the camera using

your smartphone or tablet PC. The ProHomeIPC-App
automatically searches for all the cameras available in
the network.

6. When the smartphone or tablet PC is connected to the

same wireless network as the camera, the camera is
displayed.

7. Enter the camera's password. When the default set

ting are set, the password is admin.

8. Save the settings by touching Save or OK.

Your camera is now listed in the overview of cameras
available.

The first time you attempt to select your camera, you
will be requested to change the camera's password for
reasons of security. We urgently recommend that you
change the camera's password in order to prevent
unauthorised access to your camera, and thus your
privacy, by third parties.

Installing the Camera

19

D

5. Connecting the Camera to the WLAN

The following section describes how to connect the cam
era to the wireless home network (WLAN).

1. Open the Advanced Setting menu. When using iOS,

touch the highlighted arrow on the right in the over
view of available cameras. When using Android, also
touch the arrow and then on the icon highlighted on
the right.

2. Touch the Advanced Setting option.

3. Touch the arrow beside the WiFi option to display a

list of wireless networks available.

4. Touch the wireless network to which you want to con
nect your camera.

5. Enter the WiFi password of the wireless network se
lected. For security reasons, the characters of the
password appear encrypted.

6. Save the settings by touching OK.

iOS

Android

Installing the Camera

20

D

6. Last Steps Prior to Assembly

Disconnect all the cable connections before beginning
with the installation work.

The settings for the connection between your camera and
the ProHomeIPC-App and the settings for your WiFi are
retained when the camera is disconnected from the power
supply.

1. Disconnect the power adapter from the power socket.

2. Disconnect the network cable from the port (11) on the
connection cable.

7. What is the Correct Installation
Location for My Camera?

You can install the camera at any installation location (e.g.
under a roof projection or on a ceiling) with the aid of the
device mounting bracket.

Observe the following points when selecting the installa
tion location.

 The camera must be installed at a suitable height to

protect the camera and connection cable from any
unwanted manipulation, vandalism or other unautho
rised access.

 The camera must be within the range of the wireless

network (WLAN).

 There must be sufficient space to install the cable box

in the direct vicinity.

 The power socket, which must be located indoors,

must be easily accessible.

 (Option) The receiver must be within range of your

alarm system.

Installing the Camera

21

D

8. Installing the Camera



WARNING!

Risk of fatal injury through electric shock or gas
explosion!

During installation, pay attention to the possibility of
electrical cables and gas pipes running in the walls.

Pay attention that you do not damage electric cables
or gas pipes.

1. Use the holes in the mounting bracket (2) as a drilling
template and drill three sufficiently large holes in the
wall or ceiling.

We recommend the use of special dowels according
to the properties of the mounting surface.

2. Insert the respective dowels in the drill holes.

3. Lay the connection cable in the recess in the mounting
bracket.

4. Assemble the camera with the mounting bracket using
suitable screws.

2

Installing the Camera

22

D

9. Assembling the Cable Box

After assembling the camera, you can stow the connec
tion cable (1) and, if necessary, the receiver in the cable
box to protect excess lengths of cable from any unwanted
manipulation, vandalism or other unauthorised access.

Observe the following points when selecting the assembly
location.

 The cable box must be in the direct vicinity of the

camera.

 The power cable can be laid easily into the box.
 (Option) The receiver must be within range of your

alarm system.

20

1

19



WARNING!

Risk of fatal injury through electric shock or gas
explosion!

During installation, pay attention to the possibility of
electrical cables and gas pipes running in the walls.

Pay attention that you do not damage electric cables
or gas pipes.

1. Use the holes in the cable box as a drilling template
and drill four suitable holes in the wall or ceiling.

2. Loosen the screws in the lid (19) of the cable box us
ing an appropriate screwdriver and remove the cable
box lid (19).

3. Drill another suitable hole in the wall or ceiling close to
the cable box through which to feed the power ca
ble (20) from indoors out to the cable box.

4. Insert the respective dowels in the drill holes for the
cable box.

5. Pay attention that the cable glands face downwards
and assemble the cable box using appropriate screws.

Installing the Camera

23

D

10. Final Steps

Now complete the final steps of the installation work.
Reconnect the two cable connections previously
disconnected.

Using a Receiver

1. Connect the plug (17) on the receiver to the
port (12) on the connection cable of the camera to en
able data exchange with the alarm system.

2. Connect the plug (15) on the receiver to the
port (13) on the connection cable of the camera to
provide the power supply.

3. Connect the plug on the power adapter to the port (16)
on the receiver.

4. Lay the connection cable (1) through the left-hand
cable gland into the cable box.

5. Position the receiver in the cable box as illustrated.

6. Lay the connection cable (1) in loops inside the cable
box.

7. Lay the power cable (20) through the hole drilled in
Step 3 and outdoors from the indoor area.

8. Feed the power cable (20) through the right-hand
cable gland into the cable box.

9. Place the lid (19) on the cable box and screw the
lid (19) in place using the screws provided.

10. Connect the power cable to a properly installed power
socket.

Installing the Camera

24

D

Without Receiver

1. Connect the plug on the power adapter directly to the
port (13) on the camera's connection cable to connect
the power supply.

2. Lay the connection cable (1) in loops inside the cable
box.

3. Lay the power cable (20) through the hole drilled in
Step 3 and outdoors from the indoor area.

4. Feed the power cable (20) through the right-hand
cable gland into the cable box.

5. Place the lid (19) on the cable box and screw the
lid (19) in place using the screws provided.

6. Connect the power cable to a properly installed, indoor
power socket.

11. Aligning the Camera

1. Use the ball joint (21) to align the camera horizontally
and vertically in respect of the area you want to moni
tor.

21

2

The camera has an angle of vision of 60°.

2. Check the monitoring position of the camera with the
camera app using the live image.

3. Fix the camera in the defined position using the union
nut (3).

4. The installation and set-up work for the camera is now
completed. You can now start to learn about our con
venient camera app, ProHomeIPC-App.

Using the ProHomeIPC App

25

D

Using the ProHomeIPC App

Familiarise yourself with how to use the
ProHomeIPC-App.

Swipe your finger in any direction over the display of your
smartphone or tablet PC to move the screen section dis
played.

Tap your finger on the display of your smartphone or
tablet PC to open the submenus and activate functions.

Using the ProHomeIPC App

26

D

Zoom the image displayed on the screen on the display of
your smartphone or tablet PC by touching the image sec
tion with two fingers and spreading them apart according
ly. Move your fingers in the opposite direction to reduce
the size of the image.

Rotate your smartphone or tablet PC on its side. The im
age then appears as a full screen display.

It may be necessary to activate the function to rotate
the screen contents in the Settings menu on the
smartphone or tablet PC. More detailed information is
provided in the operating manual supplied with your
smartphone or tablet PC.

Operating the Camera (iOS)

27

D

Operating the Camera (iOS)

Opening the Menu Bar

Touch your finger on the smartphone or tablet PC screen.
A menu bar opens at the bottom edge of the screen.

A function is assigned to each button in the menu bar.
Touch one of the buttons to activate the function or, if
necessary, define settings.

Buttons in the Menu Bar

This section provides information on which functions are
assigned to the buttons in the menu bar while a live pic
ture is on screen and what you can do with them.

Snapshots

You can take a photo of the live image currently scanned
by the camera.

1. Touch the Snapshot button. The live image currently
displayed is saved as a snapshot. The Snapshot
saved message appears in the display.

When the default settings are set, the snapshots are
saved locally on the smartphone or tablet PC. You can
also save your snapshots on the camera. More detailed
information is provided in Section Recording on the SD
Card.

Operating the Camera (iOS)

28

D

2. Touch the button to open an overview of the snap
shots taken.

Activating Night Vision

If the brightness of the area being monitored falls below a
certain level, the infrared LEDs are automatically activat
ed.

The infrared LEDs serve as a residual light amplifier so
that the area monitored is illuminated sufficiently despite
the dark and can continue to be monitored. The live image
displayed appears in black and white.

1. Touch the IRLight Switch button.

2. Touch this button to activate automatic night vision.

3. Touch this button to deactivate automatic night vision.

Operating the Camera (iOS)

29

D

Flipping the Image Section Horizontally

You can flip (mirror) the live image displayed on the hori
zontal axis. This is useful, for example, if you want to
install your camera on a ceiling using the holding bracket.

1. Touch the Flip horizontal button. The current live

image displayed is flipped on the horizontal axis.

Flipping the Image Section Vertically

You can flip (mirror) the live image displayed on the verti
cal axis. This can be useful, for example, when the
camera is mounted in such a way that parts of the area
under surveillance lie in a blind spot.

1. Touch the Flip vertical button. The current live image

displayed is flipped on the vertical axis.

Operating the Camera (iOS)

30

D

Changing the Resolution

You can change the resolution of the camera. This can be
useful, for example, when there is a long delay regarding
data transmission; i.e. the camera takes a long time to
react to the movement commands you issue via the
ProHomeIPC-App. In such cases, it may be advanta
geous to reduce the resolution of the live image being
transmitted.

More detailed information on this subject is available
in Section What To Do When Problems Arise.

1. Touch the Video Quality button.

2. Touch the setting required.

Repeat this step until the camera reacts to the move
ment commands issued via the ProHomeIPC-App
without any delay.

Adapting to Environmental Conditions

You can adapt the camera settings to the environmental
conditions of the area under surveillance.

1. Touch the EnvironmentMode button.

2. Touch the required setting depending on whether the
area under surveillance is bright or dark.

Operating the Camera (iOS)

31

D

Start Screen of the ProHomeIPC-App

When a camera has been found and integrated success
fully in the ProHomeIPC-App, the corresponding camera
is displayed on the start screen.

All the cameras integrated in the ProHomeIPC-App are
displayed in this view.

We recommend that you assign each camera connected
an unambiguous name (refer to Section Names).

You are provided with detailed information on

 the unambiguous user identifier (UID) of the camera,
 the name (designation) of the camera,
 the monitoring status of the camera,
 the alarm preset status of the camera.

Operating the Camera (iOS)

32

D

Context Menu of the ProHomeIPC-App

At the bottom edge of the start screen are four buttons
which can be used to complete different settings and func
tions.

 Device
 Event
 Add Device
 Info

1. Touch the respective button to define the setting or
start the function.

The settings or functions assigned to the individual but
tons are described in the following sections.

The following adjustments to the settings only affect the
camera selected. Information on particular, individual fea
tures is provided at the respective point.

Operating the Camera (iOS)

33

D

Camera List

The Device button is active when you open the
ProHomeIPC-App.

1. Touch Device. A list of all the cameras integrated in

your camera app is displayed.

If you touch one of the cameras listed, the live image from
the camera selected is displayed. You can use the buttons
in the menu bar (see Buttons in the Menu Bar).

Operating the Camera (iOS)

34

D

Event

This option enables you to display a list of events which
the camera has recorded and saved in chronological or
der.

1. Touch Event.

2. Touch the camera whose recorded events you want to
display.

If no event has (yet) been recorded, the No result found
message appears.

You can define specific periods of time in the chronologi
cal list of events in order to limit the events displayed to a
certain time range.

3. Touch Search.

4. Touch the period of the events which should be dis
played.

5. All the events related to the time period selected are
displayed.

Operating the Camera (iOS)

35

D

Add Camera

You have the possibility of connecting new cameras using
the ProHomeIPC-App.

All the cameras connected are displayed on the start
screen.

1. Touch Add Device.

Operating the Camera (iOS)

36

D

QR Code

1. Touch QRCode.

2. Scan the QR code on the rear of the camera using
your smartphone or tablet PC.

3. Enter the camera's password.

When the default settings are set, the password is
admin.

4. Save the settings by touching Save.

Your camera is now listed in the overview of cameras
available.

The first time you attempt to select your camera, you
will be requested to change the camera's password for
reasons of security. Change the camera's password in
order to prevent unauthorised access to your camera,
and thus your privacy, by third parties.

Operating the Camera (iOS)

37

D

Automatic Search

The ProHomeIPC-App automatically searches for all the
cameras available in the network. If your smartphone or
tablet PC is connected within the same network as the
camera, the camera is displayed (together with the unam
biguous user identifier (UID) and IP address).

1. Touch the camera displayed.

2. Enter the camera's password.

When the default settings are set, the password is
admin.

3. Save the settings by touching Save.

Your camera is now listed in the overview of cameras
available.

The first time you attempt to select your camera, you
will be requested to change the camera's password for
reasons of security. Change the camera's password in
order to prevent unauthorised access to your camera,
and thus your privacy, by third parties.

Operating the Camera (iOS)

38

D

Connecting Manually

You can also connect your camera to the
ProHomeIPC-App manually.

1. Touch Add.

The user identifier (UID), the name and password are on
the rear of the camera.

2. Enter the user identifier (UID), the name and pass
word of the camera.

Your camera is now listed in the overview of cameras
available.

The first time you attempt to select your camera, you
will be requested to change the camera's password for
reasons of security. Change the camera's password in
order to prevent unauthorised access to your camera,
and thus your privacy, by third parties.

Operating the Camera (iOS)

39

D

Information

It is possible to display detailed information on the version
of the ProHomeIPC-App.

The version information changes each time the app is up
dated.

1. Touch Info. Information on the current version of the
ProHomeIPC-App is displayed.

Operating the Camera (iOS)

40

D

Remove Camera

It is possible to delete individual cameras from the
ProHomeIPC-App.

All personally defined settings are stored locally on the
camera. If you want to reconnect cameras deleted from
the list to your smartphone or tablet PC at a later point in
time, the personally defined settings are reactivated.

This does not apply if the settings have been defined
on another smartphone or tablet PC. The modified
settings are activated in such cases.

1. Touch Edit.

2. Touch the Delete icon and then the Delete option.

The camera selected is deleted.

3. Touch Done. The start screen reappears.

Operating the Camera (iOS)

41

D

Edit Camera

You can use this menu to define the various functions and
settings which control the way in which the camera be
haves.

The Settings menu is arranged into four areas.

 Device Setting
 Advanced Setting
 Alarm Setting
 Time Setting

1. Touch the arrow to the right beside the required cam
era.

The following settings only affect the respective camera
selected. Information on particular, individual features is
provided at the respective point.

Some menus contain entries behind which is a small ar
row. If you touch this arrow, a list with various options
opens. Touch the required entry to select it.

Operating the Camera (iOS)

42

D

Device Setting

This menu option provides information on

 the unambiguous user identifier (UID),
 the name of the camera,
 the camera's password.

Example Camera

Operating the Camera (iOS)

43

D

User Identifier (UID)

The camera's user identifier (UID) serves to identify the
camera unambiguously within the network.

The user identifier cannot be changed.

Example Camera

Operating the Camera (iOS)

44

D

Name

The name of the camera is displayed on the
ProHomeIPC-App start screen.

This enables you to simplify the assignment of your cam
era if you have connected several cameras to the
ProHomeIPC-App.

You should assign each camera an unambiguous
name, such as Living room, Office or Workshop.

1. Touch the field beside the Name option.

2. Change the name of the camera.

Example Camera

Operating the Camera (iOS)

45

D

Password

The camera password protects the camera from access
by unauthorised third-parties.

For reasons of security, we recommend that you
change the camera's password when you put the
camera into operation for the first time (refer to Secu
rity Settings).

For reasons of security, the characters entered are en
crypted.

Example Camera

Operating the Camera (iOS)

46

D

Advanced Setting

This option provides various functions and settings with
which you can define how the camera behaves according
to your own individual requirements.

The Advanced Setting menu is arranged into four areas.

 Security Code
 WiFi
 SDCard
 About Device

1. Touch Advanced Setting.

Example Camera

Operating the Camera (iOS)

47

D

Security Code

You have the option of changing your camera's security
code. The camera's security code protects the camera
data from access by unauthorised third-parties.

For reasons of security, we recommend that you
change the camera security code when you put the
camera into operation for the first time.

1. Touch Security Code in the Advanced Setting
menu.

2. Enter the existing security code.

When the default setting are set, the security code is
admin.

3. Enter the new security code.

4. Enter the new security code again.

5. Save the settings by touching OK.

TEST WLAN

Operating the Camera (iOS)

48

D

WiFi

You can connect the camera to a wireless network.

If the camera is already connected to a wireless network
(WLAN), refer to the name of the connected network be
side the WiFi option.

In this example, the name is TEST WLAN.

1. Touch WiFi in the Advanced Setting menu.

2. Touch the arrow on the right to open a list containing
all the wireless networks available in the vicinity.

3. Touch the network to which you want to connect your
camera.

4. Enter the WiFi password of the network selected. For
security reasons, the characters of the password ap
pear encrypted.

5. Save the settings by touching OK.

TEST WLAN

Operating the Camera (iOS)

49

D

Formatting the SD Card

The internal memory of the camera has a memory
capacity of 8 Gb.

You should format the SD card if you transfer the camera
to third-parties or need to hand it over for any reason. This
ensures that your private recordings and photos do not
get into unauthorised hands.

1. Touch SDCard in the Advanced Setting menu.

2. Touch SDCard and confirm the prompt. The internal

memory is formatted.

All the data stored on the SD card is deleted.

TEST WLAN

Operating the Camera (iOS)

50

D

About Device

This menu provides detailed information on your camera.

This area displays

 the name (designation) of the camera,
 the firmware version on the camera,
 the camera manufacturer,
 the total memory capacity of the SD card,
 the remaining memory capacity on the SD card.

1. Touch About Device in the Advanced Setting menu.

TEST WLAN

Operating the Camera (iOS)

51

D

Alarm Setting

Adapt the alarm settings of the camera and the
ProHomeIPC-App as required.

1. Touch Alarm Setting.

Your smartphone or tablet PC can be set-up to issue an
acoustic signal when the camera detects a movement. To
do this, activate the Push Notification option in the
ProHomeIPC-App in the settings options provided in
smartphone or tablet PC.

Example Camera

Operating the Camera (iOS)

52

D

Alarm Switch

This option is used to define whether surveillance by the
camera should be activated or not. If the surveillance
function is active, a recording is made of the area under
surveillance and you are alerted to an alarm situation by
an acoustic alarm and Push Notification on your smart
phone or tablet PC according to the settings defined.

1. Touch the Switch icon beside the Guard option. The
Switch icon indicates it is ON.

To avoid false alarms, we recommend deactivating
the guard when you are at home yourself or, accord
ing to your knowledge, other persons are permanently
in the area under surveillance.

TEST WLAN

Operating the Camera (iOS)

53

D

Motion Detection

You can select from the list how sensitive the camera
should react to movements in the area under surveillance.

In the case of a static image, we recommend the High
setting, in the case of possibly recurrent movements (such
as a pet or clouds), we recommend the Medium or Low
setting in order to prevent false alarms.

1. Touch Motion Detection in the list.

2. Touch the setting required. The setting is saved.

TEST WLAN

Operating the Camera (iOS)

54

D

Receiver (Protect)

If you want to integrate the camera in an alarm system
(Protect Series 6xxx / 9xxx alarm system from Olympia),
you must use the receiver supplied.

When you want to activate the receiver, make sure the
receiver is connected to the camera and has been regis
tered on the alarm system (see Section Installing the
Camera).

1. Touch the Switch icon beside the Receiver (Protect)
option. The Switch icon indicates it is ON.

When this function is activated, the camera receives a
signal from the alarm system in the event of an alarm.
Your camera starts to make a video recording of the area
under surveillance and, at the same time, sends a push
notification to your smartphone or tablet PC.

TEST WLAN

Operating the Camera (iOS)

55

D

Recording on the SD Card

You can use this option to define whether your recordings
should be stored on the internal SD card.

1. Touch the Switch icon beside the Alarm SD Record
option. The Switch icon indicates it is ON.

TEST WLAN

Operating the Camera (iOS)

56

D

Push Notification

You can use this option to define whether the
ProHomeIPC-App push notifications should be sent to
your smartphone or tablet PC when the camera detects
movements or the alarm system connected is triggered.

A condition for the successful activation of this function is
that the transmission of push notifications has been en
abled in the system settings on the smartphone or tablet
PC. More detailed information is provided in the operating
manual supplied with your smartphone or tablet PC.

The transmission of push notifications also functions when
the ProHomeIPC-App is not running in the background
but has been terminated.

1. Touch the Switch icon beside the Push Notification
option. The Switch icon indicates it is ON.

TEST WLAN

Operating the Camera (iOS)

57

D

Time Setting

This option provides information and functions regarding
the time settings used.

1. Touch Settings in the Time Setting menu.

2. Define the respective settings as required.

When the default settings are active, the time and date
stamp displayed in the live image reflect the time and date
provided by the network connected.

Example Camera

Operating the Camera (Android)

58

D

Operating the Camera (Android)

Opening the Menu Bar

Touch your finger on the smartphone or tablet PC screen.
A menu bar opens at the bottom edge of the screen.

A function is assigned to each button in the menu bar.
Touch one of the buttons to activate the function or, if
necessary, define settings.

Buttons in the Menu Bar

This section provides information on which functions are
assigned to the buttons in the menu bar while a live pic
ture is on screen and what you can do with them.

Snapshots

You can take a photo of the live image currently scanned
by the camera.

1. Touch the Snapshot button. The live image currently
displayed is saved as a snapshot. The Snapshot
succesfully message appears in the display.

When the default settings are set, the snapshots are
saved locally on the smartphone or tablet PC. You can
also save your snapshots on the camera. More detailed
information is provided in Section Recording on the SD
Card.

Operating the Camera (Android)

59

D

2. Touch the button to open an overview of the snap
shots taken.

Activating Night Vision

If the brightness of the area being monitored falls below a
certain level, the infrared LEDs are automatically activat
ed.

The infrared LEDs serve as a residual light amplifier so
that the area monitored is illuminated sufficiently despite
the dark and can continue to be monitored. The live image
displayed appears in black and white.

1. Touch the Infrared switch button.

2. Touch this button to activate automatic night vision.

3. Touch this button to deactivate automatic night vision.

Operating the Camera (Android)

60

D

Flipping the Image Section Horizontally

You can flip (mirror) the live image displayed on the hori
zontal axis. This is useful, for example, if you want to in
stall your camera on a ceiling using the holding bracket.

1. Touch the Flip horizontal button. The current live

image displayed is flipped on the horizontal axis.

Flipping the Image Section Vertically

You can flip (mirror) the live image displayed on the verti
cal axis. This can be useful, for example, when the cam
era is mounted in such a way that parts of the area under
surveillance lie in a blind spot.

1. Touch the Flip vertical button. The current live image

displayed is flipped on the vertical axis.

Operating the Camera (Android)

61

D

Changing the Resolution

You can change the resolution of the camera. This can be
useful, for example, when there is a long delay regarding
data transmission; i.e. the camera takes a long time to
react to the movement commands you issue via the
ProHomeIPC-App. In such cases, it may be advanta
geous to reduce the resolution of the live image being
transmitted.

More detailed information on this subject is available
in Section What To Do When Problems Arise.

1. Touch the Video Quality button.

2. Touch the setting required.

Repeat this step until the camera reacts to the move
ment commands issued via the ProHomeIPC-App
without any delay.

Adapting to Environmental Conditions

You can adapt the camera settings to the environmental
conditions of the area under surveillance.

1. Touch the Environment Mode button.

2. Touch the required setting depending on whether the
area under surveillance is bright or dark.

Operating the Camera (Android)

62

D

Start Screen of the ProHomeIPC App

When a camera has been found and integrated success
fully in the ProHomeIPC-App, the corresponding camera
is displayed on the start screen.

All the cameras integrated in the ProHomeIPC-App are
displayed in this view.

We recommend that you assign each camera connected
an unambiguous name (refer to Section Names).

You are provided with detailed information on

 the unambiguous user identifier (UID)) of the camera,
 the name (designation) of the camera,
 the monitoring status of the camera,
 the alarm preset status of the camera.

Operating the Camera (Android)

63

D

Add Device

You have the possibility of connecting more cameras by
means of different processes using the
ProHomeIPC-App.

All the cameras connected are displayed on the start
screen.

1. Touch Click here to add camera.

Operating the Camera (Android)

64

D

QR Code

1. Touch Scan.

2. Scan the QR code on the rear of the camera using
your smartphone or tablet PC.

3. Enter the camera's security code (password).

When the default setting are set, the security code is
admin.

4. Save the settings by touching OK.

Your camera is now listed in the overview of cameras
available.

The first time you attempt to select your camera, you
will be requested to change the camera's security
code for reasons of security. Change the camera's
security code in order to prevent unauthorised access
to your camera, and thus your privacy, by third par
ties.

Operating the Camera (Android)

65

D

Automatic Search

The ProHomeIPC-App automatically searches for all the
cameras available in the network. If your smartphone or
tablet PC is connected within the same network as the
camera, the camera is displayed (together with the unam
biguous user identifier (UID) and IP address).

1. Touch Search.

2. Touch the camera required.

3. Enter the camera's security code.

When the default setting are set, the security code is
admin.

4. Save the settings by touching OK.

Your camera is now listed in the overview of cameras
available.

The first time you attempt to select your camera, you
will be requested to change the camera's security
code for reasons of security. Change the camera's
security code in order to prevent unauthorised access
to your camera, and thus your privacy, by third par
ties.

Operating the Camera (Android)

66

D

Connecting Manually

You can also connect your camera to the
ProHomeIPC-App manually.

1. Enter the user identifier (UID), the security code and
name of the camera.

The user identifier (UID), name and security code are on
the rear of the camera.

2. Save the settings by touching OK.

Your camera is now listed in the overview of cameras
available.

The first time you attempt to select your camera, you
will be requested to change the camera's security
code for reasons of security. Change the camera's
security code in order to prevent unauthorised access
to your camera, and thus your privacy, by third par
ties.

Operating the Camera (Android)

67

D

Context Menu of the Camera

You can use the start screen to open the context menu of
the connected cameras individually.

1. Touch the arrow to the right of the camera name to
open the respective context menu. The context menu
is opened.

The context menu contains five options. The individual
options are described in the following sections.

 Reconnect
 Edit Camera
 View Event
 View Snapshot
 Remove Camera

The following adjustments to the settings only affect the
camera selected. Information on particular, individual fea
tures is provided at the respective point.

Operating the Camera (Android)

68

D

Reconnect

Should problems arise involving the connection, you can
connect the camera again using the ProHomeIPC-App.

1. Touch Reconnect. The camera selected is recon

nected.

You cannot access the camera while this process is in
progress.

Operating the Camera (Android)

69

D

View Event

This option enables you to display a list of events which
the camera has recorded and saved in chronological or
der.

1. Touch View Event.

If no event has (yet) been recorded, the No result found
message appears.

You can define specific periods of time in the chronologi
cal list of events in order to limit the events displayed to a
certain time range.

2. Touch the magnifying glass icon at the top right.

3. Touch the required time period for the events.

4. All the events related to the time period selected are
displayed.

Operating the Camera (Android)

70

D

View Snapshot

This option enables you to display a list of snapshots
which you have taken with the camera and saved in
chronological order.

1. Touch View Snapshot. A list of the snapshots avail

able is displayed.

If no snapshot has (yet) been recorded, the No snapshot
found message appears.

2. Touch one of the snapshots. The snapshot selected
appears in a full screen display.

You can delete the selected snapshots from the collection
saved.

3. Touch the waste bin icon.

4. Confirm the prompt by touching Yes. The snapshot
selected is deleted.

Operating the Camera (Android)

71

D

Remove Camera

It is possible to delete individual cameras from the
ProHomeIPC-App.

All personally defined settings are stored locally on the
camera. If you want to reconnect cameras deleted from
the list to your smartphone or tablet PC at a later point in
time, the personally defined settings are reactivated.

This does not apply if the settings have been defined
on another smartphone or tablet PC. The modified
settings are activated in such cases.

1. Touch Remove Camera.

2. Confirm the prompt by touching OK.

The camera selected is deleted.

Operating the Camera (Android)

72

D

Edit Camera

You can use this menu to define the various functions and
settings which control the way in which the camera be
haves.

The Edit Camera menu is arranged into four areas.

 Device Setting
 Advanced Setting
 Alarm Setting
 Time Setting

The following settings only affect the respective camera
selected. Information on particular, individual features is
provided at the respective point.

Some menus contain entries behind which is a small ar
row. If you touch this arrow, a list with various options
opens. Touch the required entry to select it.

TEST WLAN

Operating the Camera (Android)

73

D

Device Setting

This menu option provides information on

 the unambiguous user identifier (UID),
 the camera's security code,
 the name of the camera.

TEST WLAN

Operating the Camera (Android)

74

D

User Identifier (UID)

The camera's user identifier (UID) serves to identify the
camera unambiguously within the network.

The user identifier cannot be changed.

TEST WLAN

Operating the Camera (Android)

75

D

Security Code

The camera security code protects the camera from ac
cess by unauthorised third-parties.

For reasons of security, we recommend that you
change the camera's security code when you put the
camera into operation for the first time (refer to Secu
rity Settings).

For reasons of security, the characters entered are en
crypted.

TEST WLAN

Operating the Camera (Android)

76

D

Name

The name of the camera is displayed on the
ProHomeIPC-App start screen.

This enables you to simplify the assignment of your cam
era if you have connected several cameras to the
ProHomeIPC-App.

You should assign each camera an unambiguous
name, such as Living room, Office or Workshop.

1. Touch the field beside the Name option.

2. Change the name of the camera.

3. Save the settings by touching OK.

TEST WLAN

Operating the Camera (Android)

77

D

Advanced Setting

This option provides various functions and settings with
which you can define how the camera behaves according
to your own individual requirements.

The Advanced Setting menu is arranged into four areas.

 Modify Security Code
 Wi-Fi Setting
 Device information.

1. Touch Advanced in the Advanced Setting menu.

Operating the Camera (Android)

78

D

Security Code

You have the option of changing your camera's security
code (password). The camera security code protects the
camera from access by unauthorised third-parties.

For reasons of security, we recommend that you
change the camera security code when you put the
camera into operation for the first time.

1. Touch Modify Security Code in the Security Setting
menu.

2. Enter the existing security code.

When the default setting are set, the security code is
admin.

3. Enter the new security code.

4. Enter the new security code again.

5. Save the settings by touching OK.

Operating the Camera (Android)

79

D

Wi-Fi Setting

You can connect the camera to a wireless network.

If the camera is already connected to a wireless network
(WLAN), refer to the name of the connected network in
the middle of the marked area on the right. In this exam
ple, the name is TEST-WLAN.

1. Touch Manage Wi-Fi networks in the Wi-Fi Setting

menu.

2. Touch the arrow on the right to open a list containing
all the wireless networks available in the vicinity.

3. Touch the network to which you want to connect your
camera.

4. Enter the WiFi password of the network selected. For
security reasons, the characters of the password ap
pear encrypted.

If you select the checkbox beside Show password,
the characters entered are displayed.

5. Save the settings by touching OK.

Operating the Camera (Android)

80

D

Device Information

This menu provides detailed information on your camera.

This area displays

 the name (designation) of the camera,
 the firmware version on the camera,
 the camera manufacturer,
 the total memory capacity of the internal SD card,
 the remaining memory capacity of the SD card.

No settings can be changed in this area.

TEST WLAN

Connected

Operating the Camera (Android)

81

D

Alarm Setting

Adapt the alarm settings of the camera and the
ProHomeIPC-App as required.

1. Touch Alarm in the Alarm Setting menu.

Your smartphone or tablet PC can be set-up to issue an
acoustic signal when the camera detects a movement. To
do this, activate the Push Notification option in the
ProHomeIPC-App in the setting options provided in
smartphone or tablet PC.

Operating the Camera (Android)

82

D

Alarm Switch

This option is used to define whether surveillance by the
camera should be activated or not. If the surveillance
function is active, a recording is made of the area under
surveillance and you are alerted to an alarm situation by
an acoustic alarm and Push Notification on your smart
phone or tablet PC according to the settings defined.

1. Touch the Switch icon beside the Alarm Switch op
tion. The Switch icon indicates it is ON.

2. Save the settings by touching OK.

To avoid false alarms, we recommend deactivating
the guard when you are at home yourself or, accord
ing to your knowledge, other persons are permanently
in the area under surveillance.

Operating the Camera (Android)

83

D

Motion Detection

You can select from the list how sensitive the camera
should react to movements in the area under surveillance.

In the case of a static image, we recommend the High
setting in the case of possibly recurrent movements (such
as a pet or clouds), we recommend the Medium or Low
setting in order to prevent false alarms.

1. Touch Motion Detection in the list.

2. Touch the setting required.

3. Save the settings by touching OK.

Operating the Camera (Android)

84

D

Receiver (Protect)

If you want to integrate the camera in an alarm system
(Protect Series 6xxx / 9xxx alarm system from Olympia),
you must use the receiver supplied.

When you want to activate the receiver, make sure the
receiver is connected to the camera and has been regis
tered on the alarm system (see Section Installing the
Camera).

1. Touch Receiver (Protect) in the list.

2. Touch the setting required.

3. Save the settings by touching OK.

When this function is activated, the camera receives a
signal from the alarm system in the event of an alarm.
Your camera starts to make a video recording of the area
under surveillance and, at the same time, sends a push
notification to your smartphone or tablet PC.

Operating the Camera (Android)

85

D

Recording on the SD Card

You can use this option to define whether your recordings
should be stored on the internal memory.

1. Touch the Switch icon beside the Alarm recording
sd card option. The Switch icon indicates it is ON.

2. Save the settings by touching OK.

Operating the Camera (Android)

86

D

Push Messaging

You can use this option to define whether the
ProHomeIPC-App push notifications should be sent to
your smartphone or tablet PC when the camera detects
movements or the alarm system connected is triggered.

A condition for the successful activation of this function is
that the transmission of push notifications has been en
abled in the system settings on the smartphone or tablet
PC. More detailed information is provided in the operating
manual supplied with your smartphone or tablet PC.

The push messaging service also functions when the
ProHomeIPC-App is not running in the background but
has been terminated.

1. Touch the Switch icon beside the Push messaging
service option. The Switch icon indicates it is ON.

2. Save the settings by touching OK.

Operating the Camera (Android)

87

D

Time Setting

This option provides information and functions regarding
the time settings used.

1. Touch Advanced in the Time Setting menu.

2. Define the respective settings as required.

3. Save the settings by touching OK.

When the default settings are active, the time and date
stamp displayed in the live image reflect the time and date
provided by the network connected.

Other Important Information

88

D

Other Important Information

Guarantee

The period of guarantee is 24 months. The period of guar
antee begins on the date of purchase.

In the case of problems, please contact our hotline:

0180 5 007514

(Costs using a German landline at time of going to print:
14 ct/min., max. 42 ct/min. using a mobile network.)

If the problem cannot be cleared over the phone, send
your device in the original packaging, with the purchase
receipt enclosed, to the following address:

Service Center Hattingen
Zum Kraftwerk 1
45527 Hattingen

Regular Maintenance and Service

Clean the housing surfaces with a soft, fluff-free cloth.
Never use any chemicals or scouring agents.

Technical Modifications

This instruction manual serves purely for information pur
poses. Its content is not part of any contract for sale. All
the data relates to nominal values. The equipment and
options described may differ from country to country ac
cording to national requirements.

Information on Disposal

The adjacent symbol indicates that old electrical
and electronic apparatus no longer required

must be disposed of separate from domestic
waste in accordance with legal directives.

Packaging materials must be disposed of
according to local regulations.

CE Mark

Olympia Business Systems Vertriebs GmbH, Zum
Kraftwerk 1, 45527 Hattingen hereby declares that
this device fulfils the requirements and complies
with the regulations stipulated in the Directive
1999/5/EC. The CE Mark on the devices confirms
conformity. The Declaration of Conformity for this
product is available at www.olympia-vertrieb.de.

Other Important Information

89

D

Technical Data

Property Value

Lens / Sensor 1/4'' CMOS sensor (colour), focal length f: 3.6 mm
Resolution Max. 1280 x 720 pixel

Image compression H.264

Light sensitivity 0.5 lux

Image refresh rate Max. 30 fps

Night vision 21 IR LEDs, range up to 15 meters

Angle of vision 60°

Motion detection Yes

Memory 8 GB, Flash memory

LAN RJ45 interface (10/100 Mbps)

WLAN IEEE 802.11 b, 802.11 g, 802.11 n

Encryption WEP, WPA and WPA2

Dimensions 175 x 65 mm (L x D), connection cable 1400 mm

Weight Approx. 350 g (without accessories)

Power supply Input: 100 - 240 V, 50 - 60 Hz, 0.5 A, Output: 2500 mA, 5 V

Type of protection IP 65

Permissible
ambient conditions 0 - 55° C at 20 - 80 % rel. humidity

Camera app iOS 7 or later (at least iPhone 4); Android 4.0 or later

Other Important Information

90

D

Troubleshooting

My camera is not detected within the
network.

 Check all the cable connections. Observe the informa

tion in Section Connecting the Camera.

 Check the network settings. The DHCP function must

be activated in the router. Your camera can only be
found automatically in the network when the DHCP
function is switched on.

 Reset your camera to its default factory settings.

Press the Reset button (14) on the camera's connec
tion cable. Ensure that the user identifier and pass
word correspond to the default settings.

 Contact our Service department.

My camera is detected within the network
but I cannot access it.

 Check the entries for the user identifier and password

(security code). The default values are provided on
the rear of the camera.

 Reset your camera to its default factory settings.

Press the Reset button (14) on the camera's connec
tion cable. Ensure that the user identifier and pass
word correspond to the default settings.

 Contact our Service department.

Other Important Information

91

D

My camera does not respond at all or only
very slowly to input via the ProHomeIPC
app.

 The connection to your network is slow or faulty.

Check all the cable connections. Use a shorter net
work cable, if necessary. Observe the information in
Section Connecting the Camera.

 The mobile internet connection available is of different

quality in different localities. Move to a different loca
tion and try again.

 The data volume is used up within the scope of your

mobile phone contract and the speed of the mobile
connection has been slowed by your provider. Contact
your mobile phone provider.

 Reduce the image quality of the image transmission.
 Reset your camera to its default factory settings.

Press the Reset button (14) on the camera's connec
tion cable. Ensure that the user identifier and pass
word correspond to the default settings.

 Contact our Service department.

Olympia Business Systems Vertriebs GmbH

Zum Kraftwerk 1
45527 Hattingen
