User Manual for
Oliso™ Steam Iron with Auto-Lift System™
Models
TG-800 with Non-Stick Soleplate
TG-1000 with Stainless Steel Soleplate
Safer. Smarter. Simpler.
Page 2
IMPORTANT SAFETY INSTRUCTIONS
When using your iron, basic safety precautions should always be followed, including the following:
1 ) Use iron only for its intended use.
2 ) To protect against a risk of electric shock, do not immerse the iron in water or other liquids.
3 ) The iron should always be turned to “Off” before plugging or unplugging from the outlet. Never yank
cord to disconnect from the outlet; instead, grasp plug and pull to disconnect.
4 ) Do not allow cord to touch hot surfaces. Let iron cool completely before putting away. Loop cord
loosely around iron when storing.
5 ) Always disconnect iron from electrical outlet when filling with water or emptying and when not in use.
6 ) Do not operate iron with a damaged cord or if the iron has been dropped or damaged. To avoid the
risk of electric shock, do not disassemble the iron. Take it to a qualified serviceman for examination and
repair. Incorrect reassembly can cause a risk of electric shock when the iron is used.
7 ) Do not allow children to use iron. Close supervision is necessary for any appliance being used near
children. Do not leave iron unattended while connected or on an ironing board.
8 ) Burns can occur from touching hot metal parts, hot water, or steam. Use caution when you turn a
steam iron upside down – there may be hot water in the reservoir.
9 ) If the LED flashes orange (not red or green), the iron is not operating normally. Disconnect from the
power supply and have the iron serviced by qualified service personnel.
Read all instructions before using this product.
SPECIAL INSTRUCTIONS
1 ) This is a 1440 watt appliance. To avoid a circuit overload, do not operate another high wattage
appliance on the same circuit.
2 ) If an extension cord is absolutely necessary, a 12 ampere cord should be used. Cords rated for
less amperage may overheat. Care should be taken to arrange the cord so that it cannot be pulled or
tripped over.
SAVE THESE INSTRUCTIONS
Page 3
Welcome
Thank you for purchasing the Oliso™ Iron, the only iron with the patented AUTO-LIFT
SYSTEM™. You’re just a few steps away from a new safer, easier way of ironing. Follow
the instructions in this manual to learn about your new iron’s features and care. We
hope you enjoy your Oliso™ Iron.
Smart. Simple. Delightful.
Page 4
3 simple steps to start
1 2
FILL SET UP
Open the Flip Funnel™ and add
water to the tank with the fill cup
or directly from a faucet.
Plug in, then choose a fabric
setting.
Page 5
3
IRON
When the green light stops blinking
and is constantly lit, the iron is ready
for use. Touch the handle and begin.
Enjoy your Oliso™ iron
If you would like to learn more
about your iron’s unique features,
please read on.
Page 6
getting to know your Oliso™ iron
Status Light
Steam Button
Spray Button
Steam Selector
Electronic Fabric Selector
Drain Spout
Spray Nozzle
Detailer
Lifters
Touch-activated handle
Auto-Lift™
on/off switch
Flip Funnel™
Water Tank
Soleplate
- non-stick (TG-800)
- stainless steel (TG-1000)
Page 7
Auto-Lift System™
To operate, place the iron right side
up on a flat surface. Plug the iron into
an outlet and make sure the Auto-Lift
switch is in the on ( ) position.
OVERRIDING THE AUTO-LIFT SYSTEM™
If you wish to turn off the Auto-Lift system, move the switch on the back of the
iron to the off ( ) position. Your iron will now operate like a standard iron. If the
iron is left in the horizontal position without being touched for more than 30
seconds, the Auto-Lift system will automatically raise the iron. This will prevent
the iron from scorching or burning. Touch the iron handle, and the iron will lower.
You can restore Auto-Lift by returning the switch to the on ( ) position.
Touch the iron handle and the iron will
sense your hand and lower. Let go and
the iron’s Lifters will automatically raise
the iron above fabric.
Page 8
water tank
Before filling, slide
the steam selector
to off ( ). Make
sure the iron is
unplugged.
Open the Flip
Funnel™.
Leave the iron in a
horizontal position
and fill using the
included fill cup. Two
fill cups equal the
maximum capacity
of the water tank.
Alternatively, fill directly
from a faucet holding
the iron horizontally. Do
not fill the tank past the
MAX fill line on the
side of the iron. Close
the port when done.
If you need to add water during ironing, unplug
the iron and repeat the above steps. After filling,
make sure the iron is fully reheated before ironing.
water recommendations
This iron is designed to be used with regular tap
water. If your water is over 12 grams of hardness we
recommend using either inexpensive bottled spring
water or mixing half tap water with half distilled water.
Never use 100% distilled water as this can cause the
iron to spit and leak.
Page 9
fabric selector
fabric selector
status light
temperature is too low for steam
Turn the fabric selector to select a fabric setting. To use constant steam
or steam burst, the temperature must be set to the wool, cotton, or linen
range.
red flashing green green flashing red
off heating or cooling at set temp auto off
The Oliso iron uses a status light to display the iron’s status. To ensure correct
temperature, wait until the light displays steady green before ironing.
steam ok
Page 10
steam/spray system
Steam Selector: Slide the steam selector to set the amount of constant steam. The iron
can only produce steam when the fabric selector knob is set to the wool ( •• ), cotton, or
linen range (•••). Allow the iron to heat up (steady green status light) before activating
the steam control. Steam will be produced as soon as the iron is lowered.
Dry Ironing: To turn off the steam, slide the steam selector off ( ).
Auto Anti-Drip: Your Oliso™ iron has an anti-drip feature which shuts off steam
production any time the iron’s Lifters are extended. This prevents unwanted
steam while the iron is standing. To prevent dripping entirely, keep the steam selector in
the off ( ) position.
Spray
• press the spray button for a strong mist spray
• the spray will help remove wrinkles
Burst of Steam
• firmly press the steam button for a strong burst of steam from the soleplate.
• the steam button can only be used when the iron is heated to the wool (••),
cotton, or linen range (•••).
• wait at least 3 seconds between each press of steam button.
Vertical Steam
• to steam vertically press the steam button while holding the iron upright.
• this is useful for getting creases and wrinkles out of hanging clothes or curtains.
• wait at least 3 seconds between each press of the steam button.
Page 11
auto shut-off system
If the Oliso™ iron is not being used while it is plugged in, the status light will flash red and the iron will
turn itself off. The auto shut-off timing depends on whether the Auto-Lift System™ is turned on or off.
Touch the handle of the iron to restart it.
Auto-Lift on Auto-Lift off
iron position
iron positionauto shut-off timing auto shut-off timing
30 seconds left untouched,
8 minutes unused
8 minutes vertical
30 seconds knocked over 30 seconds knocked over
lifters will raise iron,
and iron will cool
8 minutes vertical
Page 12
after ironing
a. Turn the fabric selector to off. Slide the steam selector to off ( ).
b. Unplug the appliance (Do not hold iron while unplugging or the
Lifters will not stay extended. Iron should always be stored with Lifters
d.
e.
maintenance
The soleplate should be cleaned if starch or other residue build up. When the iron is cool, wipe the
soleplate with a soft, damp cloth. Do not use abrasive cleaners or scouring pads as this will damage
the iron’s soleplate.
Mineral deposits from tap water can occur in the soleplate vents. To clean, fill the water tank and heat
the iron to the linen fabric setting. Once the iron is fully heated, unplug the iron and hold over a sink.
Press the steam button repeatedly until water begins to drip out of the soleplate. Be careful, as this
creates large amounts of steam.
extended to prevent leaking).
c. Place iron on the Lifters and allow to cool.
d. Important: Empty water from the water tank after use. Tilt the iron
forward to drain from the spout at the front of the iron. To drain faster,
open the Flip Funnel™ .
e. For easy storage, the power cord can be wound loosely around the
iron once it has cooled.
To ensure optimal steam production, the steam valve should be regularly cleared of accumulated
debris and minerals. This is done by moving the steam selector back and forth from the off ( )
to the max ( ) steam settings several times.
Page 13
trouble shooting guide
PROBLEM THINGS TO CHECK SOLUTION
iron does not heat
Lifters do not
come out
iron does not steam
iron leaks
iron is emitting a brown
or white substance
fabric selector is set to off
iron not plugged in correctly
auto shut-off system is activated
Auto-Lift switch set to off
iron not plugged in correctly
handle activated
iron is not hot enough
steam selector set to off
steam valve is clogged
Auto-Lift is off and iron is
horizontal
iron is not hot enough
steam burst button is overused
water hardness may be too high
Turn the fabric selector knob to a fabric setting.
Check to make sure the plug is fully plugged into the socket.
touch the handle.
Set the switch on the back of the iron to the on ( ) position.
Check to make sure the plug is fully plugged into the socket.
Move your hand away from the iron, and the Auto-Lift
System will raise the sole-plate.
The fabric selector must be set to the wool, cotton or linen
settings to produce constant steam.
Steam selector must be turned to a setting.
Move the steam selector from off ( ) to the max ( )
settings a few times to unclog.
When the Auto-Lift switch is set to off ( ), always store
the iron in the vertical position. We recommend turning on
the Auto-Lift system to store the iron.
Make sure the fabric selector knob is set to the cotton or
linen range to ensure proper steam production.
Allow 3 seconds between uses of the steam burst function.
Switch to either spring water or half tap/half distilled water
mixture. See the “water tank” page for more information.
Page 14
One (1) Year Limited Warranty
Oliso, Inc. warrants that for a period of one year from the date of the original purchase, this product will be free from defects in
material and workmanship, when utilized for normal household use. Oliso, Inc. will repair or replace this product or any component
of the product found to be defective during the warranty period without charge to the customer. If a replacement product is sent,
it will carry the remaining warranty of the original product. Replacement will be made with a new or remanufactured product or
component. If the product is no longer available, replacement may be made with a similar product of equal or greater value. This is
your exclusive warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Keep the original
sales receipt. Proof of purchase is required to obtain warranty performance. Oliso, Inc. dealers or retail stores selling Oliso, Inc.
products do not have the right to alter, modify or in any way change the terms and conditions of this warranty.
The liability of Oliso, Inc. is limited solely to the cost of repair or replacement of the product at its option. This warranty does not
cover normal wear of parts and does not apply to any product that has been tampered with or used for commercial purposes.
This warranty does not cover damage caused by misuse, abuse, use on improper voltage or current, use contrary to the operating
instructions, negligent handling or damage due to faulty packaging or mishandling in transit. This warranty does not cover damage
or defects caused by or resulting from damages from shipping or repairs, service or alteration to the product or any of its parts,
which have been performed by a repair person not authorized by Oliso, Inc. Further, the warranty does not cover Acts of God such
as fire, flood, hurricanes, and tornados.
This warranty is extended to the original purchaser of the product and excludes all other legal and/or conventional warranties. The
responsibility of Oliso, Inc. is limited to the specific obligations expressly assumed by it under the terms of the limited warranty. In
no event shall Oliso, Inc. be liable for any incidental or consequential damages caused by breach of any express, implied or statutory
warranty or condition.
Except to the extent prohibited by law, any implied warranty or condition of merchantability or fitness for a particular purchase is
limited in duration to the duration of the above warranty. Oliso, Inc. disclaims all other warranties, conditions, or representations,
express, implied, statutory or otherwise. In no event shall Oliso, Inc. be liable for any indirect, special, incidental or consequential
losses or damages (including but not limited to interruption of business or loss of business or profit) resulting from the use of
or inability to use the product, any breach of contract, fundamental or otherwise, or for any claim brought against purchaser by
any other party. Some states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or
limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
If you have any question regarding this warranty or would like to obtain warranty service, please email Oliso, Inc. at
[email protected], and a service center address will be provided to you.
If you have further questions, you may call 1-800-899-5157.
Page 15
For product questions:
Oliso Customer Service
www.oliso.com
1.800.899.5157
© 2005 Oliso, Inc. All rights reserved. Touch&Glide™, Auto-Lift System™, Auto-Lift™, Flow Glide™,
Flip Funnel™, and Smart Touch™ are trademarks of Oliso Inc. Printed in China
U.S. Patent No. #6,453,587 B1, #6,925,738 B2
Patent Pending
Page 16
Thanks for shopping Oliso!
Visit www.oliso.com/registration.html to register your iron
or
www.oliso.com to buy a 5-year warranty
Loading...
