For Customer Use:
Enter below the serial number that is located on the
bottom of the unit. Retain this information for future
reference.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF FIRE AND ELEC TRIC SHOCK , DO NOT REMOVE THE COVER (OR BACK)
OF THE UNIT. REFER SERVICING ONLY TO QUALIFIED
SERVICE PERSONNEL.
The lightning fl ash with arrowhead symbol within an equilateral triangle is intended to alert
the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of suffi cient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operation and servicing instructions in the literature accompanying the
appliance.
WARN ING:
To p rev ent fi re or shock hazard, do not expose this device to rain or moisture. Dangerous high voltage is present inside the
enclosure. Do not open the cabinet.
Handling the cords on this product will expose you to lead, a chemical known to the State of California to cause cancer, and
birth defects or other reproductive harm. Wash hands after handling.
CAUTION:
This Digital Video Disc player employs a laser system. To prevent direct exposure to the laser beam, do not try to open the
enclosure or defeat the safety interlocks. When open and the interlocks are defeated, visible laser radiation is present.
To prevent electric shock, match wide blade of plug to wide slot of outlet and fully insert.
Use of controls, adjustments, or performance of procedures other than those specifi ed herein may result in hazardous radiation
exposure. DO NOT STAR E INTO THE BEAM.
NOTICE:
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property
rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
PRECAUTIONS
WARNING:
THIS MODEL AND ITS ENCLOSED CAR ADAPTOR ARE ONLY COMPATIBLE WITH
12V VEHICLES.
PLEASE NOTE: THIS MODEL IS NOT COMPATIBLE WITH 24V VEHICLES.
DO NOT CONNECT THE UNIT TO THE CAR VIA CAR ADAPTOR BEFORE THE
ENGINE HAS BEEN STARTED.
DISCONNECT THE CAR ADAPTOR WHEN IT IS NOT IN USE.
Page 3
For recycling or disposal information about this product, please
contact your local authorities or the Electronics Industries Alliance:
www.eiae.org.
PRECAUTIONS
Do not make any changes or modifications to the equipment unless other wise specified in
the manual. If such changes or modifications should be made, you could be required to stop
operation of the equipment.
Page 4
IMPORTANT SAFETY INSTRUCTIONS
Read Instructions: All the safety and operating instructions should be read before the product 1.
is operated.
Retain Instructions: The safety and operating instructions should be retained for future refer-2.
ence.
Heed Warnings: All warnings on the product and in the operating instructions should be 3.
adhered to.
Follow Instructions: All operating and usage instructions should be followed.4.
Cleaning: Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners 5.
or aerosol cleaners. Use a damp cloth for cleaning.
Attachments: Use only attachments recommended by the manufacturer. Use of other attach-6.
ments may be hazardous.
Water and Moisture: Do not use this product near water (e.g., near a bath tub, washbowl, 7.
kitchen sink, laundry tub, in wet basements, or near a swimming pool and the like).
Heat: The product should be situated away from heat sources such as radiators, heat regis-8.
ters, stoves, or other products (including amplifi ers) that produce heat.
Accessories: Do not place this product on an unstable cart, stand, tri-9.
pod, bracket, or table. Use only with carts, stands, tripods, brackets,
or tables recommended by the manufacturer or sold with the product. Any mounting of the product should follow the manufacturer’s
instructions and should use a mounting accessory recommended
by the manufacturer.
A product and cart combination should be moved with care. Quick 10.
stops, excessive force, and uneven surfaces may cause the product
and cart combination to overturn.
Ventilation: Slots and openings in the cabinet are provided for ventilation 11.
to ensure reliable operation of the product and to protect it from overheating. These openings
should never be blocked by placing the product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer instructions have been adhered to.
Power Sources: This product should be operated only from the type of power source indi-12.
cated on the rating label. If you are not sure of the type of power supply to your home, consult
your product dealer or local power company. For products intended to operate from battery
power or other sources, refer to the operating instructions.
Power Sources: 13.
Do not connect the power plug to a power outlet other than that which is
indicated here and on the label as this may result in the risk of fi re or electric shock. Do not
handle the power plug with wet hands. Doing so may cause electric shock.
Power Lines: An outside antenna system should not be located in the vicinity of overhead 14.
power lines or other electric light or power circuits, or where it can fall into such power lines
or circuits. When installing an outside antenna system, extreme care should be taken to keep
from touching such power lines or circuits, as contact with them might be fatal.
Battery: Danger of explosion if battery is incorrectly replaced. Replace only with the same or 15.
equivalent type. Battery pack or batteries installed shall not be exposed to excessive heat
such as sunshine, fi re or the like.
16.
WARNING: THIS MODEL AND ITS ENCLOSED CAR ADAPTOR ARE ONLY COMPATIBLE WITH 12V VEHICLES.
PLEASE NOTE: THIS MODEL IS NOT COMPATIBLE WITH 24V VEHICLES.
DO NOT CONNECT THE UNIT TO THE CAR VIA CAR ADAPTOR BEFORE THE ENGINE HAS BEEN STARTED.
DISCONNECT THE CAR ADAPTOR WHEN IT IS NOT IN USE.
Page 5
IMPORTANT SAFETY INSTRUCTIONS
motor vehicle, or left unsecured in the vehicle whilst driving. If this unit is being used by a
passenger in your vehicle, be sure that it is secured or held safely, and does not obstruct any
safety device (i.e. airbag, seat belt etc.) that is fi tted. All passengers should wear seat belts
when using this unit in a moving vehicle. If in doubt, please contact your vehicle manufacturer
for further advice. Using other car power adaptors could damage the unit.
Using 18. Headphones or Earphones: Hearing experts advise against the constant use of personal stereos played at high volume. Constant high volume use can lead to hearing loss.
If you experience ringing in the ears or hearing loss, discontinue use and seek medical
advise.
Grounding or Polarization: This product may be equipped with a polarized alternating-current 19.
line plug that has one blade wider than the other. This plug will only fi t into the power outlet in
one direction. This is a safety feature. If you are unable to insert the plug fully into the outlet,
try reversing the direction of the plug. If the plug should still fail to fi t, contact an electrician to
replace the obsolete outlet. Do not defeat the safety purpose of the polarized plug.
Power-Cord Protection: Power supply cords should be routed so that they are not likely to 20.
be walked on or pinched by items placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and at the point which they exit from the product.
Protective Attachment Plug: The product may be equipped with an attachment plug with 21.
overload protection. This is a safety feature. See the operating instructions for replacement
or directions to reset the protective device. If replacement of the plug is required, be sure the
service technician has used a replacement plug that has the same overload protection as the
original plug as specifi ed by the manufacturer.
Outdoor Antenna Grounding: If an outside antenna is connected to the product, be sure the 22.
antenna system is grounded so as to provide some protection against voltage surges and
built-up static charges. Article 810 of the National Electrical Code, ANS/NFPA 70 provides
information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding conductors, location
of antenna-discharge unit, connection to grounding electrodes, and requirements for the
grounding electrode (see fi gure).
Lightning: For added protection for this product, unplug it from the wall outlet and disconnect 23.
the antenna or cable system during a lightning storm or when it is left unattended and unused
17. Using the unit in a Vehicle :On no account should this unit be used by the driver of a moving
Page 6
IMPORTANT SAFETY INSTRUCTIONS
for long periods of time. This will prevent damage to the product due to lightning or power-line
surges.
If at any time in the future you should need to dispose of this product please note24.
that Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer for
recycling advice.(Waste Electrical and Electronic Equipment Directive)
Overloading: Do not overload wall outlets, extension cords, or integral convenience 25.
receptacles as this can result in a risk of fi re or electric shock.
Object and Liquid Entry: Never push objects of any kind into this product through openings 26.
as they may touch dangerous voltage points or shout-out parts that could result in a fi re or
electric shock. Never spill liquid of any kind on the product.
Servicing: Do not attempt to service this product yourself as opening or removing covers may 27.
expose you to dangerous voltage or other hazards. Refer all servicing to qualifi ed service
personnel.
Damage Requiring Service: Unplug this product from the wall outlet and refer servicing to 28.
qualifi ed service personnel under the following conditions: a) when the power-supply or plug
is damaged; b) if liquid has been spilled or if objects have fallen into the product; c) if the
product has been exposed to rain or water; d) if the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating
instructions as improper adjustment of other controls may result in damage and will often
require extensive work by a qualifi ed technician to restore the product to its normal operation;
e) if the product has been dropped or damaged in any way; f) when the product exhibits a
distinct change in performance—this indicates a need for service.
Replacement Parts: When replacement parts are required, be sure that your service techni-29.
cian has used replacement parts specifi ed by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fi re, electric shock, or
other hazards.
Safety Check: Upon completion of any service or repairs to this product, ask the service tech-30.
nician to perform safety checks to ensure that the product is in proper operating condition.
Wall or Ceiling Mounting: The product should be mounted to a wall or ceiling only as recom-31.
mended by the manufacturer.
Page 7
TABLE OF CONTENTS
PRECAUTIONS ...............................................................................................................................2
IMPORTANT SAFETY INSTRUCTIONS ........................................................................................4
TABLE OF CONTENTS ...................................................................................................................7
PACKAGE CONTENTS ...................................................................................................................9
ABOUT OPTICAL DISCS ..............................................................................................................10
Disc Requirements.................................................................................................................10
Disc Care and Maintenance ..................................................................................................10
Handling a Disc ..............................................................................................................10
Cleaning a Disc ..............................................................................................................10
LOCATION OF CONTROLS .......................................................................................................... 11
Front View (Main Unit) ...........................................................................................................11
Left View (Main Unit)..............................................................................................................12
Right View (Main Unit) ...........................................................................................................12
Bottom View (Main Unit) ........................................................................................................12
Left View (Monitor) .................................................................................................................13
Right View (Monitor) ..............................................................................................................13
Front View (Monitor) ..............................................................................................................13
Remote Control ......................................................................................................................14
Battery Installation .................................................................................................................15
Power Supply .........................................................................................................................15
CONNECTIONS ............................................................................................................................16
Power, Audio and Video Output Connections .......................................................................16
Connecting to a wall outlet ............................................................................................16
Outputting AV signal from the main unit to the monitor by the DC car cord .................16
Using the car p lug .......................................................................................................... 17
Outputting AV signal from the main unit to the monitor ................................................17
Audio and Video Connectios ( external device) ....................................................................17
USB/SD/MMC Card Connection ...........................................................................................18
Connecting to an Amplifi er Equipped with a Dolby Pro Logic Surround ..............................18
Rechargeable Battery Pack ...................................................................................................19
Using Headphones/Earphones .............................................................................................19
BASIC OPERATIONS ....................................................................................................................20
Basic Playback .......................................................................................................................20
Play/Pause/Stop ............................................................................................................20
Previous /Next (Skip) .....................................................................................................20
Forward/Reverse (Search) ............................................................................................20
Slow/Ste p .......................................................................................................................20
Menu Navigation ....................................................................................................................21
Numeric Keypad ....................................................................................................................21
Disc Error Messages .............................................................................................................21
Power Management ...............................................................................................................21
Page 8
PLAYER FUNCTIONS ...................................................................................................................22
Menu/ Title ..............................................................................................................................22
Setup ......................................................................................................................................22
Display ...................................................................................................................................22
Repeat Mode..........................................................................................................................22
Repeat A-B Mode ..................................................................................................................23
Multi-Angle/Subtitle/Audio .....................................................................................................23
Zoom ......................................................................................................................................23
Clear .......................................................................................................................................23
Searc h ....................................................................................................................................23
DVD Mode......................................................................................................................23
CD Mode ........................................................................................................................23
LCD Menu ..............................................................................................................................24
Program Function ..................................................................................................................24
USB/SD/MMC Card Access ..................................................................................................24
SETUP ...........................................................................................................................................25
Language Setup .....................................................................................................................25
Screen Setup .........................................................................................................................25
Audio Setup ............................................................................................................................26
Custom Setup ........................................................................................................................26
SPECIFICATIONS .........................................................................................................................27
HEADREST MOUNTING BAG PLACEMENT ..............................................................................28
TROUB LESH OOTIN G ...................................................................................................................29
TABLE OF CONTENTS
Page 9
Please make sure the following items are included in the package. If any items are missing, please
contact your local dealer.
PACKAGE CONTENTS
Audio & Video Cable
Headrest Mounting Bags
Car Adaptor with AV
cable
Page 10
ABOUT OPTICAL DISCS
Disc Requirements
This DVD player supports playback of the following discs.
Type Disc Mark Content Type Disc Size Max. Playback Time
DVD-Video Discs
Audio + Video
(moving picture)
12 cm
133 min (SS-SL)
242 min (SS-DL)
266 min (DS-SL)
484 min (DS-DL)
Audio Compact Discs (CDs)
Audio 12 cm 74 min
JPEG CDs -- Still Picture 12 cm --
This unit can play back CD-R and CD-RW discs that contain JPEG picture fi les. Discs not listed
above are not supported by this unit (eg, PC CD-ROM, CD-Extra, CD-G, CD-I, etc.)
Disc Care and Maintenance
Optical discs (DVDs, CDs) contain high-density compressed data and need proper handling.
Handling a Disc
Hold a DVD/CD by its edges. Avoid touch-•
ing the recorded side of the disc. To remove
a DVD/CD from its storage case, press down
on the center retention mechanism of the case
and lift the disc out.
Do not subject discs to prolonged exposure to direct sunlight, high humidity, or high tem-•
peratures.
Do not bend or press discs. •
To reduce the risk of scratches, always put discs back in their case after use. Store discs •
vertically in a cabinet.
Do not place stickers or labels on either side of a disc.•
Cleaning a Disc
Use a dry, soft cloth to wipe off any fi ngerprints and dusts from the playing surface of the disc.
Wipe in a straight line radially from the center to the outside edge of the disc. Small dust particles
and light stains will not affect playback quality.
Never use chemicals such as record sprays, anti-static sprays, benzene, or thinners to clean •
a disc. Doing so will damage the surface of the disc permanently.
Note: In stop mode, do not touch the disc until it completely stops.
Page 11
••
/USB/SD
LOCATION OF CONTROLS
For your reference:
Place a disc with the label facing up and push gently on the center of the disc so it goes into position.1.
To start playing, press the PL AY/PAUSE button. (Some discs will start playing automatically).2.
To stop playing, press the STOP button.3.
To Skip Forward/Skip Backward, press the NEXT/PREV button.4.
To Fast Forward/Fast Backward, press/hold the NEXT/PREV button.5.
Front View
1
Integrated Stereo Speakers
2
Power on Indicator
3
Battery LED Indicator
Lights red when charging the battery.•
Lights green when the battery is fully •
charged.
4
Remote Sensor
5
LCD Mode/USB/SD Button
Briefl y press this button to display the LCD •
Menu.
Press up/down direction button to high-1.
light item and then make adjustment by
left /right direction button.
Press up/down direction button to select 2.
SCREEN and then press left/right direction button to set screen dimension as
Main unit
16:9 or 4:3
To reset all items, select RESET by up/down 3.
direction button and then press ENTER button
to confi rm.
Press and hold this button for a short while to dis-•
play the working source menu, you can access the
DVD/USB/Card using this menu.
6
Setup
To access the setup menu which various features of
the player can be adjusted in.
7
Stop
Press once to prestop the playback, press twice to stop
completely.
8
Play/Pause
Press the Play/Pause button to play the disc. Press
again to pause playback.
9
Up/Down/Left/Right / Enter buttons
Press the direction buttons to select an item and press
the ENTER to confi rm
10
Fast Forward/Reverse
11
7″ TFT Display.
1
2
3
4 5 6 7 8 9
10
11
Press to skip forward/reverse. Hold to fast forward/reverse.
Page 12
Back ViewLeft View
Right View
Main unit
1
Left View
1
DC 9V IN
To connect to the supplied AC Adaptor/DC Car
Cord for power supply.
2
Power Switch
To turn on/off the unit.
3
Headphone Jack
To connect to the supplied headphone. As the
headphone is plugged in, the speakers’ volume output will be OFF.
4
Coaxial Out
To connect to an external speaker system by
the coaxial cable.
5
Audio Jack
To connect to an external speaker system by
the supplied RCA cable.
6
Video Jack
To connect to an external TV screen by the
supplied RCA cable.
7
AV Switch
Set the AV jack as input or output
8
Hold Switch
Prevent any unwanted function changes in
PLAY or STOP mode.
Right View
9
Headphone Jack
To connect the headphone.
Before connection, make sure that the volume
is at low level.
10
SD/MMC Card Slot
11
USB Port
For use with USB fl ash drives.
12
Volume Dial
To Adjust the Volume Level.
Bottom View
13
Using the Stand
14
Stand Lock
15
Battery Cover
LOCATION OF CONTROLS
2
4
5
6
7
8
3
10
9
11
12
13
1415
To access media files on SD/MMC cards.
1. Lift up the stand from groove
2. For a different angle, unlock the switch on stand first
3. Extend the stand to a comfortable viewing position
4. Lock the switch on stand to keep the position
Page 13
LOCATION OF CONTROLS
Monitor
Left View
1
Power Switch
To turn on/off the unit.
Right View
2
DC 9V In Jack
To Connect to the supplied AD Adaptor
or the DC Car Cord for power supply.
3
Video Jack
To input the video signal.
4
Audio Jack
To input the audio signal.
5
Headphone Jack
To connect the Headphone.
Before connection, make sure that the
volume is at low level.
6
Volume Dial
To adjust the Volume Level.
Front View
7
Power On Indicator
8
Mute Button
To turn off / restore the audio.
9
Screen Ratio Button
To change the screen ratio to 4:3 or 16:9.
10
LCD Mode Button
you can adjust the screen effect in the LCD menu.
For operation details, please refer to the LCD Mode
of the Main unit.
11
Navigation Buttons and Enter button
To select and Confi rm options in the LCD Menu and
Setup Menu of the monitor.
1
7
8
2
4
5
6
3
9
10
11
Front View
Left View
Right View
Page 14
LOCATION OF CONTROLS
Battery Installation
aa
Page 15
CONNECTIONS
Power, Audio and Video Output Connections
Before connecting the power source, ensure that all the connections are properly done.
Connecting to a wall outlet•
Outputting audio and video signal from the main unit to the monitor by the DC car cord.•
Adaptor for monitor:
This adaptor should be
used with 100-240V~ 50/60 Hz 0.3A
Max AC wall outlets.
DC Out: DC 9V
DC Current: 1A
Main Unit
Monitor
DC 9V in
Video in
Audio in
DC 9V in
Audio Jack
Video Jack
Do not plug in
Adaptor for main unit:
This adaptor should be used
with 100-240V~50/60Hz 0.6A MAX
AC wall outlets.
DC Out: 9V
DC Current: 2.0A
To w all out l et
(100-240V 50/60Hz)
To w all out l et
(100-240V 50/60Hz)
Caution:
Do not connect the power plug to a power outlet other than that which is indicated here and on the label as this
may result in the risk of fi re or electric shock.
Do not handle the power plug with wet hands. Doing so may cause electric shock.
Only use adaptors of the type specifi ed here. Failure to do so may case a fi re or damage the player.
Slide the AV switch
of the main unit to
Out.
WARNING:
THIS MODEL AND ITS ENCLOSED CAR
ADAPTOR ARE ONLY COMPATIBLE
WITH 12V VEHICLES.
PLEASE NOTE: THIS MODEL IS NOT
COMPATIBLE WITH 24V VEHICLES.
DO NOT CONNECT THE UNIT TO THE
CAR VIA CAR ADAPTOR BEFORE THE
ENGINE HAS BEEN STARTED.
DISCONNECT THE CAR ADAPTOR
WHEN IT IS NOT IN USE.
Page 16
Main Unit
Monitor
DC 9V in
Video in
Audio in
Using the car plug•
Outputting audio and video signal from the main unit to the monitor.•
To the Cigarette
Lighter Socket
DC 9V in
Audio Jack
Video Jack
CONNECTIONS
Audio and Video Connections (external device)
Slide the AV switch to AV IN to input the AV signal.
Slide the AV swith to AV OUT to output the AV signal.
External Device with
AV input / output.
Refer to the owner’s manual of the external device as well.1.
Before connecting the power source, 2. ensure that all the connections are properly done.
If the player will not be used for a long period of time, disconnect the power and remove the battery from 3.
the remote control.
Main Unit
Monitor
External Device with AV output.
To Video in Jac k
To Audio in Jack
To Video Jack
To Audio Jack
Page 17
CONNECTIONS
USB/SD/MMC-Card Connection
Insert the USB/SD Card into the corresponding slot on the right panel of the main unit, press and hold the 1.
LCD MODE/USB/SD button to display the DVD/USB/Card selection menu. Press the up/down direction
button to select USB or Card from the menu, press ENTER to access.
It takes a short while for the unit’s reading data. After the device is detected, the screen will display the 2.
working menu, press the direction buttons to select the desired fi le from the menu and press Play/Pause
to start playback.
Connecting to an amplifi er equipped with a Dolby Pro Logic Surround
Amplifi er equipped with a
DolbyPro Logic Surround
To C o a x i a l Out
To Coaxial Input
Coaxial cable (not supplied)
When connecting the equipment to a receiver equipped
with Do lby Digital, refe r to the own er’s manual.
Page 18
CONNECTIONS
Rechargeable Battery Pack
For new or exhausted rechargeable battery pack, we recommend it be recharged for 4 hours.•
To charge the battery, just connect the adaptor. •
If the battery does not work to your expectation, please consult the ser vice center.Do not attempt to •
replace or repair the battery by yourself unless your are a qualifi ed service personnel
(NI- MH Rechargeable Battery Pack)
The battery can be recharged about 300 times without obvious performance drop. •
Note:
Use appropriate charger to charge the NI-MH battery.•
Never dispose of in fi re or heat up. •
Do not use in high temperature or near heat sources. •
Do not open the cover. Refer servicing only to qualifi ed service personnel. •
We do not recommend charging battery pack while DVD player is in use.•
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent •
type.
Low Battery Detection
The unit will access to STANDBY mode automatically when the batter y is low.•
Using Headphones / Earphones
Maximum output voltage ≤ 150mV
HEADPHONE VOLUME WARNING
Connect earphones with the volume set low and increase it if required. Prolonged listening through some earphones at high volume settings can result in hearing damage. When headphones/earphones are connected, no
sound will be emitted from the unit’s speaker.
Caution: Avoid listening to sound at levels which may be harmful to your ears.
Continuous use of earphones at high volume can damage the user’s hearing.
Page 19
BASIC OPERATIONS
“Invalid Disc”.
]Close the cover manually.
Slow/Step
top cover
Play/Pause/Stop
facing up.
reverse
.
.
.
.
.
.
.
.
.
.
.
.
.
mode.
Page 20
BASIC OPERATIONS
Wrong Regional Disc
Wrong Password
Wrong Disc
disc that is damaged or had a format problem, it may play the disc at lower quality or stop playback completely.
Page 21
PLAYER FUNCTIONS
All
,
operation
Each successive press of REPEAT will change the repeat mode of the player shown as below:
Some DVDs do not support the repeat function.
Repeat
Page 22
PLAYER FUNCTIONS
5
by
display the search bar shown below:
Curre nt Title
Tot al Tit l es
Curre nt Chap ter
Tot al Cha pt ers
Play/Pause and playback.
exit
numeric
Clear
Search
In JPEG Mode
3X
1/2X
3X
1/2X
T C
DVD
-- /12
--- /001 0:02:03 Off
Elapsed Time
Repeat Mode
T
CD
-- /12
0:02:03 Off
N
Current Track
Tot al Tr ac ks
Elapsed Time
Repeat Mode
Page 23
Press the Up/Down direction button to select the desired item, press the Left/Right direction button to •
adjust.
Press the Left/Right direction button to change the screen dimension as 16:9 or 4:3.•
When RESET is selected, press the ENTER button to confi rm the Brightness,Contrast and Color settings •
to the factory default settings.
Press the LCD Mode button once to display the LCD menu.
PROGRAM FUNCTION
PLAYER FUNCTIONS
Press the “Program” button to display the progrom menu. (eg:DVD mode)
Press the DIRECTION buttons to move between entries.1.
Press the NUMERIC buttons to input data.2.
To delete the incorrect input, press the CLEAR or ENTER button. To delete all programs, select “Clear 3.
All” and press ENTER.
Press Play/Pause to start playback or select “Play” from the menu and press ENTER.4.
To cancel, press Program twice.5.
USB/SD/MMC Card Access
Press the DVD/USB/SD button on the remote to display the working source menu, you can • also access
this menu by holding the LCD MODE/USB/SD button on the main unit for a short while.
Press the up/down direction button to select DVD/USB/Card from the menu.•
Press ENTER to access.•
LCD Menu
Page 24
Various features of the player can be adjusted in the SETUP menu
1. Press the SETUP button to show the setup menu.
2. Press the direction buttons to select the desired item.
3. Press ENTER to confi rm.
SETUP
Display
Language Setup
PAL
Auto
Australia.
Page 25
SETUP
Parental
SETUP
You must input the four-digit password to access the Parental settigs.
The intial password is 8888.
Sets the maturity rating level of the player.
The player will not play any discs higher than
this setting.
There are eight rating levels. Level 1 will restrict playback to discs suitable for people
of all ages. Level 8 will allow playback of
all discs, including those suitable for adults
only.
Page 26
SPECIFICATIONS
SPECIFICATIONS
Main Unit
Monitor
198 165 37
725.9g
mm
198 165 26
507.5g
mm
1
=7W
Video Input
Audio Input
Specifi cations and manual are subject to change without prior notice.
=10W
Auto/NTSC/PAL
Auto/NTSC/PAL
Page 27
Main Unit
Monitor
Mounting
Straps
Mounting
Straps
Mounting
12V Car Power Adaptor
With AV Cable
Remote
Control
Mounting in the Vehicle
The headrest mounting bags for fi tting the main unit and the monitor on to your car headrests. •
The bag has 2 straps that wrap around the headrest tightly and the main unit / monitor slides in and out •
of the bag.
PLACEMENT
SAFETY WARNING!
On no account should this unit be used by the driver of a moving motor vehicle, or left unsecured •
in the vehicle whilst driving.
If this unit is being used by a passenger in your vehicle, be sure that it is secured or held safely, •
and does not obstruct any safety device (i.e. airbag, seat belt etc.) that is fi tted.
All passengers should wear seat belts when using this unit in a moving vehicle.•
If in doubt, please contact your vehicle manufacturer for further advice.•
Using other car power adaptors could damage the unit.•
Page 28
TROUBLESHOOTING
Main Unit Troubleshooting
There is no power to the device.
Ensure that the Power Switch on the main unit is physically set to the ON position.•
Ensure that the AC adaptor cord is securely connected to the player and the proper wall outlet.•
The device will not play the disc.
Ensure that a supported disc is loaded in the player label-side up.•
Ensure that the disc’s rating level does not exceed the player’s parental rating level.•
Ensure that the disc is not damaged or too dirty. •
Clean the disc or try another disc.Moisture may have condensed inside the player. Remove the disc and •
leave the player on for 1-2 hours and then try again.
There is no picture.
Ensure that the TV set has been powered on and is set to the correct AV mode. •
Ensure that the connections between the player and the TV are secure and correct.•
Check if the connection cables are damaged.•
The picture is noisy or distorted.
The disc may be damaged or dirty. Clean the disc or try another one.•
Reset your TV’s color system.•
Ensure
that the player is connected directly to the TV (and not through a VCR, cable box, satellite re-•
ceiver, etc.)
The picture is not full- screen.
Change the aspect ratio setting of your player from the Setup menu.•
Select a different aspect ratio option from the DVD disc menu.•
There is no sound or distor ted sound.
Page 29
TROUBLESHOOTING
Ensure that the TV and amplifier have been turned on and properly set up.•
Ensure that the TV and amplifier connections are secure and correct.•
Try a different Audio track of the DVD by pressing AUDIO.•
Ensure that the MUTE function of the TV, Amplifier, or Player is not engaged.•
The remote control doesn’t work.
Ensure that the Power Switch has been physically set to the ON position.•
Ensure that there are no obstacles between the remote and the player.•
Point the remote at the remote sensor on the main unit.•
Ensure that the batteries in the remote retain a charge and have been installed correctly.•
Try replacing the remote’s batteries.•
The player has malfunctioned.
Unplug the player. After 30 minutes, plug in and power on the player -- the restore function should reset •
the player.
Monitor troubleshooting
There is no power to the device.
Ensure that the Power Switch on the monitor is physically set to the ON position.•
Ensure that the AC adaptor cord is securely connected to the player and the proper wall outlet.•
There is no sound or distorted sound.
Ensure that the AV cable connections are secure and correct.•
Ensure that the MUTE function of the monitor is not engaged.•
The picture is noisy or distor ted.
Reset the monitor’s color system.•
Ensure that the AV cable connections are secure and correct.•
Page 30
NOTE
Copyright
This manual contains information protected by copyright law.
No part of this document may be used or reproduced in any form or by any means,
or stored in a database/retrieval system without prior written permission from us.
The information of this manual is based on the current version of the product.
We reserve the right to alter the content without prior notice.
All brand names in this manual are the property of their respective owners.
Page 31
Loading...
