Olin HVBTR-1400, HVBTR-1200 User Manual
Contents
Contents
GENERAL INFORMATION
INSTALLATION
P1
P5
P8
MAIN MENU
Main Features
For Your Safety
Unpacking(optional)
General Operation
RCU
P1
P2
P3
P3
P4
1. Edit Channel
2. Installation
3. System Setup
4. Tools
5. Game
6. REC(PVR Ready)
7
. Hot key
P8
P10
P11
P13
P16
P17
P19
SPECIFICATION
P22
P7
WELCOME PAGE
TROUBLE SHOOTING
P23
HVBTR-1400_User_Manual_V1.1
1
GENERAL INFORMATION
GENERAL INFORMATION
This Set Top Box (STB) will take you to the new and exciting world of television. A
world of crystal clear widescreen pictures, digital sound, more information services.
To make full use of your STB, please take the time to familiarize yourself extensive
features of the unit detailed in this User Manual.
Main Features
SD MPEG-2/HD H.264 & fully DVB-T compliant
Automatic PAL/NTSC conversion
1000 channels TV and Radio programmable
8 different favorite groups selection
Fully support to 7 days Electronic Program Guide(EPG)
256 colors On Screen Display
Channel search in automatic, manual search
Various channel editing functions(favorite, move, lock, rename and sort)
Parental control for channels
Ease to use Menu System
Time set by GMT offset automatic and manual,Summer Time support
Automatic turn on\ off by Timer setting(multiple options)
Automatic save for last channel
Support Logic Channel Number(LCN)
Games: Teris,Othello,Sudoku
Support FAT32,NTFS(Option)
MP3/ JPEG/ BMP/ OGG files
Record Live TV with Subtitle (you can choose to display or close subtitle during playback)
Lock/Delete/Rename,Preview playback,Browse record files information
Play/Pause/Stop/Step
Fast Forward/Fast Backward 2/4/8/16/24,
Slow Forward/Slow Backward 1/2, 1/4, 1/8
GENERAL INFORMATION
GENERAL INFORMATION
2
For Your Safety
Be sure to turn the Receiver off and
disconnect the AC power cord before
cleaning the Receiver surface. If the
surface is dirty, wipe clean with a cloth
which has been dipped in a weak soap-andÂwater solution and wrung out thoroughly,
and then wipe again with a dry cloth.
Switch the receiver off whenever it remains
out of service for an extended period.
Do not touch the receiver during thunder,
since that might create electric-shock
hazards.
Do not block ventilation holes of the
Receiver so that air can circulate freely.
Do not expose the receiver un-der the
sunlight. And keep it away from the heat
source.
Keep the receiver away from flower vases,
tubs, sinks, etc., in order to avoid damaging
the equipment.
To avoid electric-shock hazards, do not
open the cabinet, refer servicing to qualified
personnel only.
When the abnormal phenomenon occur,
you should cut off the power immediately.
PR
MENU
INFO
FAV
EPG
OK
LIST
EXIT
TV/RA
DIO
PAGE+
PAGE-
F1
F2
GENERAL INFORMATION
GENERAL INFORMATION
3
Unpacking(optional)
General Operation
Throughout this manual you will notice that the everyday operation of the receiver is
based on a series of user friendly on screen display and menus. These menus will
help you get the most from your receiver, guiding you through installation, channel
organizing, viewing and many other functions.
All functions can be carried out using the buttons on the RCU, and some of the
functions can also be carried out using the buttons on the front panel.
The receiver is easy to use, always at your command and adaptable for future
advances.
Please be aware that new software may change the functionality of the receiver.
Should you experience any difficulties with the operation of your receiver, please
consult the relevant section of this manual, including the Problem Shooting, or
alternatively call your dealer or a customer service adviser.
Remote Control
Batteries User Manual
AV cable
GENERAL INFORMATION
GENERAL INFORMATION
4
RCU
The picture is for reference only , actual product may vary..
Key
Function
Standby
When watching a channel, mute the sound
Switches between TV and Radio mode
0~9
MENU
EXIT
OK, LIST
PR+, PR-
Enter number of the required menu item or
select a channel number to watch
Press this key one time to run menu onscreen
Return to the previous menu on the menu
screen or escape from the menu
Press once to pause the screen picture, press
once again to go to the normal mode when without
external device
TV/RADIO
PR
Switches back to previous channel
Displays the favorite group list
Show information of the current channel
Switch to teletext mode(subject to teletext broadcasting)
Moves up / down a page in the list
FAV
INFO
Executes the selected item in the menu screen
or enters the desired value in any input mode
When watching a channel, change channels or
move to the next higher or lower item in the menu
When watching a channel, adjust the volume or
move to the left or right item in the menu
Call up the EPG (Electronic Program Guide)
Display the Audio window.
EPG
L
R
PAUSE
FIND
Enter Record Manager to view current recorded list
SLEEP
Enter into the sleep in mode
TXT
SHIFT
RECORD
Press to fast forward or fast backward
Record the program when with external device
Time shift function (External Drive is required)
Press to slow forward or slow backward
PAGE+,PAGE-
Play and stop the program when with external
device
,
TV/AV
Switch between TV and AV modes (not available
in this model)
F1
Shortcut to TV System Setting
F2
Shortcut to Music Function
V-Format Press this key to change display resolution
Press this key to display subtitles
PR
MENU
INFO
FAV
EPG
OK
LIST
EXIT
TV/RADIO
PAGE+
PAGE-
F1 F2
INSTALLATION
INSTALLATION
5
The picture is for reference only , actual product may vary.
Rear Panel
Connecting to TV using RCA support
Front Panel
Pull USB compartment door as indicated on the front panel.
Connect your removable external drive via built-in USB port when trying to record
programs.
LR
INVIDEO
TV
AUDIO
Antenna
DTR
CONNECT TO AUDIO R/L TO TV OR AUDIO TUNER
COMPOSITE VIDEO BROADCAST SIGNAL
POWER ON/OFF
COMPONENT VIDEO OUTPUT, ANALOGUE, HIGH DEFINITION.
ANT IN: CONNECT TO ANTENNA
LOOP OUT : CONNECT TO ANOTHER RECEIVER
CONNECT TO PC FOR
SOFTWARE UPGRADE
CONNECT TO TV SET HDMI-OUT INPUT
CONNECT TO DIGITAL AMPLIFIER
INSTALLATION
INSTALLATION
6
The picture is for reference only , actual product may vary.
Antenna
