Olight Odin Users guide

USER MANUAL

Thank you for purchasing this Olight Product. Please read
this manual carefully before use and keep it for future
reference!

IN THE BOX

Odin (with battery)

Wrench Screw

Self-locking

band

SPECIFICATIONS

2000

100%

50%

HIGH

lumens

300

LOW

lumens

300m

(L)5.37* (D)1.14in

(L)136.5 *(D)29mm

2min 9min

100%

22,500cd

Magnetic

Remote Switch

USB Magnetic

Charging Cable

38%

8h

1.5m

7.62oz / 216g

(Including Battery)

All above specifications are test results based on ANSI/NEMA FL1-2009
Standard. The tests are performed using the battery included in the
light.

Note: The light output brightness will decrease as the battery voltage
decreases.

USB MAGNETIC CHARGING CABLE -- MCC3

Parameters Specication

Charge cable

Input

Charging pattern

Maximum
charging current

Full-charged
voltage

Charge indication

Full-charged time

USB type A - magnetic charge connector, length: 0.5m

USB A - Type DC 5V 2A

CC&CV

2A

4.2V±0.05V

Red：charging
Green: full (over 95%) or disconnect with flashlight

5.5 hours (For reference only. When the USB power supply
is insufficient to provide 5V 2A power capacity, the
charging time will be longer)

PRODUCT OVERVIEW

Magnetic Tailcap
Tail Switch

Slide rail mount

Unscrew

Insulating lm

Remove the insulating film

AVAILABLE BATTERIES

• 1 x customized 5000mAh 21700 rechargeable lithium battery

CHARGING

VIBRATING POWER INDICATOR

It helps to alert if the battery is low (power<20% vibrate once every 5
minutes; power<10% vibrate once per minute; power< 5% vibrate
once every 10 seconds).

GREEN Charging Completed

RED Charging

PRODUCT INSTALLATION

a

.

Rotate the button 90 degrees counterclockwise to unlock the

product as the mark shows.

b. Press the button and remove the product.

c. Loosen the screws and install the rail mount in its desired

position, then tighten the screws.

d

.

Slide the product into the rail mount until you hear a click, then turn
the button 90 degrees clockwise as the mark shows to fix the
product.

2

1

REMOTE SWITCH INSTALLATION

a

. Attach the magnetic remote switch to the tail of the product (make

sure the detent ring of the remote switch is unlocked).

b

. Push the ring forward to fix the

DANGER

• DO NOT throw the light directly into human eyes. This may
cause temporary blindness, or permanent damage to the eyes.

• DO NOT cover the light head when the flashlight is on, or place
the light head on the ground. The radiation energy of the light
may cause damage to the flashlight itself, or even result in
burning to flammable objects.

• DO NOT use Non-protected rechargeable batteries.

WARNING

• Keep out of reach of children.

• DO NOT activate high mode repeatedly under high temperature
to prevent the light body from overheating and hurting the
user’ s hand.

• The tail switch may not work while immersed in sea water or
other conductive media. Please try to keep it clean and dry.

• If the light is about to be put aside for a long time or be
transported, please unscrew the tailcap and remove the
battery to cut off the circuit.

remote switch.

2

125

15%

24min

min

IPX8

BATTERY INSTALLATION

Before first use, unscrew the tailcap and remove the insulating
film within the battery compartment before screwing the tailcap
back on tightly. If the battery needs to be changed, make sure that
the positive polarity side of the battery faces toward the direction
of the light head (the side of the LED).

* Before first use please fully charge the product.
* Connect the magnetic USB end of the charging cable (MCC3) to

an external USB power source, then attach the other end of the
magnetic charging cable to the charging port (best charging
efficiency with more than 10W (5V 2A) USB power source). The
red indicator means charging, green indicator means charging
completed (battery power＞95%).

* Only charge with standard MCC3, not compatible with other

MCC.

1

Unscrew

Screw

3

Detent ring

NOTICE

• DO NOT short circuit the switch cap with the ring outside it for
a prolonged period. The short circuit in this case will result in
a loss of current below 3mA, and may lead to a complete
battery drain if it is in this state for too long.

CONTENTS

( EN ) English

( CHS ) 简体中文

( FI ) Finnish

( NO ) Norwegian

( SV ) Swedish

( NED ) Nederland

( PL ) Polska

( DE ) Deutsch

( HU ) Magyarország

( RU ) Русский

( ES ) Español

( RO ) Romanesc

( UA ) Ukrainian

( JP ) 日本語

( TH ) ไทย

( FR ) Français

( BG ) български

( IT ) Italia

( SK ) Slovenskýjazyk

( EN ) English

HOW TO OPERATE

Click the tail switch lightly to produce a low light output or press
the tail switch hard to produce a high light output.

01

01

01

01

01

02

02

02

02

03

Single click (click and release quickly) the tail switch to turn the
flashlight on or off.

When you press and hold the switch, the flashlight will be in
momentary mode; when you release the tail switch, it will turn off.

) 简体中文

( CHS

如何操作手电

轻按输出低亮档，重按输出高亮档;

单按（按下并快速释放）开启或关闭手电；

长按并保持，手电开启，按键释放时手电同步关闭。

( FI

) Finnish

VALAISIMEN KÄYTTÖ

Käytä alhaista valotehoa painamalla kytkintä kevyesti ja korkeaa
valotehoa painamalla kytkintä kovaa.

Kytke valaisin päälle ja pois päältä painamalla kytkintä kerran
lyhyesti.

Käytä valaisinta hetkellisesti pitämällä kytkintä käytön ajan

03

03

03

04

04

04

04

04

05

painettuna. Valo sammuu kun kytkin vapautetaan.

) Norwegian

( NO

HVORDAN BRUKE

Klikk lett på bryteren for å produsere et svakt lys, eller trykk hardt
på bryteren for høy lyseffekt.

Enkelt klikk (klikk og slipp raskt) på bryteren for å slå lommelykten
av eller på.

Når du trykker og holder inne bryteren, vil lommelykten være i
øyeblikkelig modus, når du slipper bryteren, vil den slå seg av.

) Swedish

( SV

BYTA EFFEKTLÄGE

Klicka på knappen lätt och lampan kommer lysa med svag styrka
eller klicka på knappen hårt för att lampan ska lysa med hög ljusstyrka.

Klicka en gång (tryck släpp snabbt) på knappen för att tända/släcka
lampan.

När du klickar och håller ned knappen, kommer lampan tändas
momentant, när du släpper knappen, slocknar lampan.

( NED ) Nederland

HOE TE BEDIENEN

Klik zachtjes op de staartschakelaar om een laag lichtrendement te

produceren of druk hard op de staartschakelaar om een hoog
lichtrendement te produceren.

Eén keer klikken (snel klikken en loslaten) op de staartschakelaar
om de zaklamp in of uit te schakelen.

Als u de schakelaar ingedrukt houdt, bevindt de zaklamp zich in
tijdelijke modus; als u de staartschakelaar loslaat, wordt deze

uitgeschakeld.

( PL ) Polska

INSTRUKCJA UŻYTKOWANIA:

lekkie wciśnięcie tylnego przycisku spowoduje uruchomienie
latarki w trybie najniższym. Mocne wciśnięcie tylnego przycisku

spowoduje włączenie trybu najwyższego.
Pojedyncze wciśnięcie tylnego przycisku spowoduje włączenie lub

wyłączenie latarki.
Wciśnięcie i przytrzymanie tylnego przycisku spowoduje chwilowe

włączenie, puszczenie przycisku wyłączy latarkę.

) Deutsch

( DE

BEDIENUNG

Durch leichtes Drücken des Endkappenschalters erhält man eine
niedrige Lichtleistung, durch festeres Drücken des Endkappen­schalters erhält man eine hohe Lichtleistung.

Durch einmaliges Drücken des Endkappenschalters (schnelles
Klicken und Loslassen) wird die Taschenlampe an- oder
ausgeschaltet.

Wenn Sie den Endkappenschalter gedrückt halten, leuchtet die
Taschenlampe im Momentary Modus; Wenn Sie den
Endkappenschalter loslassen, wird die Taschenlampe
ausgeschaltet.

( HU ) Magyarország

A HASZNÁLAT MÓDJA

Nyomja meg finoman a hátsó zárókupakon lévő kapcsolót az
alacsony fényerőfokozat üzemmód kapcsolásához. A lámpa erős
fényerőfokozatra kapcsolásához nyomja be teljesen a hátsó
zárókupakon lévő kapcsolót.

A hátsó zárókupakon lévő kapcsoló gyors teljes benyomásával és
felengedésével a lámpa bekapcsolható, illetve kikapcsolható.

A kapcsoló benyomásának és nyomva tartásának idejére a lámpa
bekapcsol, majd a kapcsoló felengedésekor kikapcsol.

( RU ) Русский

Инструкция

Легкое нажатие активирует режим 300 люмен,
полное нажатие активирует режим 2000 люмен.

Для вкл/выкл фонаря необходимо быстро нажать
и отпустить торцевую кнопку.

Если нажать и удерживать кнопку, фонарь будет
гореть до тех пор, пока Вы ее не отпустите.

( ES ) Español

CÓMO OPERAR

Pulse suavemente el interruptor remoto para producir poca luz de
salida o pulse fuerte el interruptor remoto para producir mucha luz

de salida.
Un Sólo Clic (pulse brevemente) el interruptor remoto para

encender o apagar la linterna.
Cuando mantiene pulsado el interruptor, la linterna estará en modo

momentáneo; Cuando suelta el interruptor remoto, se apaga.

( RO ) Romanesc

MOD DE OPERARE:

Apasati butonul usor pentru a porni in modul mic sau apasati
butonul ferm (tare) pentru a porni modul maxim.

Apasare normala (apasati scurt apoi eliberati) pentru a porni sau
opri lanterna.

Atunci cand apasati și mentineti apasat butonul, lanterna va intra
în mod iluminare momentan; la eliberarea butonului din spate
lanterna se va stinge.

( UA ) Ukrainian

Як працює:

Легке натискання на торцеву кнопку вмикає
економний режим яскравості; сильніше натискання
переводить ліхтарик у стандартний режим світіння.

Одне швидке натискання кнопки (натисніть і одразу
відпустіть) вмикає і вимикає ліхтарик.

Якщо натиснути і так утримувати кнопку, ліхтарик
світитиме, і вимкнеться, якщо кнопку відпустити.

( JP ) 日本語

使用方法

テールスイッチを軽く押すとLowモードで常時点灯。
強く押すとHighモードで点灯します。

テールスイッチをシングルクリック（クリックして
素早く離す）するとライトが点灯・消灯します。

テールスイッチを長押すと（指はスイッチから離し
ないまま）ライトが点灯します、スイッチを離すと
消灯します。

( TH ) ไทย

ไฟฉาย Odin มีโหมดต่าง ๆ

อยู่หลายโหมดซึ่งสามารถกำหนดได้โดยการกดสวิทซ์ท้ายหนักหรือเบา

สำหรับการเปิดปิดไฟฉาย ทำได้โดยการกดสวิทซ์ท้ายแล้วปล่อย
ไฟฉายจะเปิด ทำอีกครั้งเพื่อปิดไฟฉาย

ส่วนการเปิดหรือปิดชั่วคราว ได้โดยการกดสวิทซ์ท้ายครึ่งนึงค้างไว้
ไฟฉายจะติด และไฟฉายจะดับเมื่อปล่อยสวิทซ์ท้าย

( FR ) Français

COMMENT L’UTILISER

Presser légèrement le bouton arrière pour activer le niveau de sortie

faible ou presser plus fort pour activer le mode fort.

Un simple clic (presser et relâcher rapidement) allume et éteint la

lampe.

Lorsque vous pressez et maintenez le bouton, la lampe s’active
momentanément ; lorsque vous relâchez le bouton la lampe s’éteint.

( BG ) български

Начин на работа

Леко задействане на бутона за слаб режим и
пълно задействане за силен режим.

Единичен бърз клик – включване/изключване.
Задействане и задържане на бутона за моментно

задействане. При отпускане на бутона фенера се
изключва.

( IT ) Italia

FUNZIONAMENTO

Premere leggermente l'interruttore posteriore per produrre

un'emissione di luce bassa o premere con forza l'interruttore

posteriore per produrre un'elevata emissione di luce.

Con un solo clic (fare clic e rilasciare rapidamente) l'interruttore
posteriore per accendere o spegnere la torcia elettrica.

Quando si tiene premuto l'interruttore, la torcia si trova in modalità
momentanea; quando si rilascia l'interruttore, si spegne.

( SK ) Slovenskýjazyk

AKO POUŽÍVAŤ
Ľahko stlačte spínač koncovky, aby ste dosiahli slabý svetelný

výkon, alebo stlačte silnejšie koncový spínač, aby ste dosiahli vysoký
svetelný výkon.

Jedným kliknutím (rýchlym kliknutím a uvoľnením) koncovým
spínačom zapnite alebo vypnite svietidlo.

Keď stlačíte a podržíte spínač, svietidlo bude vo chvíľkovom režime;
pri uvoľnení koncového spínača sa vypne.

EU-Declaration of Conformity can be found here CE:

https://olightworld.com/ec-declaration

WARRANTY

Within 30 days of purchase: Contact the original seller for repair

or replacement.
Within 5 years of purchase: Contact Olight for repair or

replacement.
Battery warranty: Olight offers a one year warranty for all

rechargeable batteries.
USB magnetic charging cable: One year.

The other no warranty fragile or low-value fittings like lanyard and
clip, you can contact post-sale in 30 days after purchase if it has
quality drawback or damage under normal use condition. Over 30
days or damage under abnormal use condition, the conditional
quality assurance will be provided as appropriate.

USA Customer Support

[e-mail]

Global Customer Support

[e-mail]
Visit www.olightworld.com to see our complete

product line of portable illumination tools.

Dongguan Olight E-Commerce Technology Co., Ltd

4th Floor, Building 4, Kegu Industrial Park,No 6 Zhongnan Road,
Changan Town, Dongguan City, Guangdong, China.
Made in China

3.0041.6010.9000

A. 05. 19. 2020

01

02

03

04

05
