2 bizhub C550
Introducing the new bizhub with InfoLine design.
The new bizhub with InfoLine design embraces bizhub’s philosophy of change. The C550 builds on the fundamentals of existing bizhub models to bring you a stylish and technologically superior office tool unlike anything you've seen before. Though evolved from the original bizhub, you can clearly see, the C550 is not just another copy. Powered by its three “Core Elements”, Communication Technologies, Design and Engineering and Open Platform, the C550 promises to keep information flowing more easily and seamlessly through your office’s network, offer the flexibility you require with your office’s existing IT infrastructure and provide a surprisingly elegant design that will surely complement any office décor. In short, the C550 promises to change the way you do business forever.
3bizhub C550
Core Elements
The new bizhub with InfoLine design is distinguished by its three Core Elements. This collection of innovative technologies, intelligent manufacturing and user-centred design work together to help offices work as efficiently and productively as possible.
The proprietary bizhub OP control system provides offices with an unprecedented level of flexibility, allowing the bizhub to adhere, adapt and grow with any IT infrastructure. Principle among bizhub OP’s three main features is its Open API (Application Program Interface). This open protocol allows easy customisation and integration with third-party peripherals and applications. The bizhub OP also features the centralised bizhub Architecture, which boosts productivity and security and streamlines your workflow. Thirdly, there’s the powerful Emperon Print System which speeds up document output and gives your office a clear and easy-to-use interface.
4 bizhub C550
The intelligent technologies of the new bizhub streamline the rapid flow of information within, into and out of your office, allowing you to collaborate more effectively and work smarter. These technologies include improved network security functions, upgrades like IPv6, the latest version Internet protocol, and enhanced fax, e-mail and scanning features to ensure seamless data handling and transmission.
Outline
Reengineered inside and out, the new bizhub
Reengineered inside and out, the new bizhub
inspires innovation, improves productivity and
inspires innovation, improves productivity and
fosters creativity. At first glance, the bizhub
fosters creativity. At first glance, the bizhub
with InfoLine design is distinctively different.
with InfoLine design is distinctively different.
But its benefits go much further than its
But its benefits go much further than its
looks. Its signature white line acts as an
looks. Its signature white line acts as an
innate pathway for operational information
innate pathway for operational information
as well as a striking design element. It
as well as a striking design element. It
also boasts solid construction for years
also boasts solid construction for years
of long life, an improved layout and
of long life, an improved layout and
an innovative user-friendly colour
an innovative user-friendly colour
control panel for more intuitive
control panel for more intuitive
user interaction.
user interaction.
Communication and Collaboration
-
“Next generation” Internet protocol, IPv6
-
Scan and Send allows you to scan to FTP, e-mail, SMB and the Box, or perform TWAIN scans.
-
Multi-Method Send allows you to send documents to multiple destinations at once.
-
Ultra-Compact PDF compresses large, colour files for easy sending.
-
The Box makes it easy to catalog, store and share information assets.
-
PageScope Box Operator
-
IP and Internet fax as well as PC-Fax functions are available.
Security and Management
-
User Authentication allows the administrator the ability to set privileges.
-
IC Card provides advanced individual user authentication.
-
Biometric Finger Vein Authentication
-
Copy Protection helps prevent hard copies from being re-copied.
-
Department Management features help you manage your costs by controlling C550 use by department.
Productivity and Production
-
High-Speed, High-Quality printing: 45 pages per minute colour, 55 pages per minute black & white
-
Finishing capabilities and output features include booklet printing, a wide range of paper compatibility, and print status notification.
-
New Tandem Engine improves speed while retaining output quality.
-
Simitri HD Toner
-
New IH Fixing significantly reduces warm up time to best in class.
-
Energy certifications illustrate Konica Minolta's dedication to environmental conservation.
New Design
-
New, colour, LCD control panel boasts a more intuitive user interface.
-
Stylish InfoLine user- centred design
-
Universal Design
5bizhub C550
Communication
and
Collaboration
A host of scanning features along with the new IPv6 help information move efficiently across your office network as well as the Internet.
Overseas PC Overseas PCMobile PC
Fax Fax
Box
Head office Branch office
Scan to
E-Mail
Compact PDF
E-mail attachment
Scan to
FTP
PCs on LAN
Compact PDF
E-mail attachment
Internet
Scan to
SMB
TIFF
E-mail attachment
Internet
Scan to
Scanning and Sending
Client BClient A
Super G3 faxInternet fax
PSTN
Colour fax
IP Address fax
Intranet
6 bizhub C550
Scan & Send
Share your black & white or colour documents quickly and easily with the C550’s scan & send features. Use the Automatic Document Feeder to scan a large number of originals consecutively.
Scan to FTP. Send documents to the FTP server,
and then store them in a directory that is easily accessible by all the PCs on the network.
Scan to E-mail. The C550 allows you to scan and
then attach documents as PDF, JPEG or TIFF files. You can also easily search and retrieve destination e-mail addresses with the LDAP (Lightweight Directory Access Protocol) server.
Scan to SMB. This function lets you send scanned
data directly to a shared folder on a PC.
Scan to Box. Scan and send originals to the Box
on the C550’s hard disk drive. From the Box, you can then send them to FTP, e-mail or SMB.
TWAIN Scan. Scan over the network from PCs
running applications that support TWAIN.
Scan to USB.* You can send scanned data, in
PDF, compact PDF, JPEG or TIFF format, to a USB memory device.
Optional Local Interface Kit EK-603 is required.
*
High-Speed Network Scanner
Quickly scan one document or convert large volumes into electronic data with the high-speed, sheet-through Automatic Document Feeder. Scan colour or black & white originals at 70 pages/min*. The ADF can also handle postcard-size paper and scan both thick and thin paper (35-210g/m
300dpi, A4 Crosswise
*
One-Scan ACS/Mixed Original Scanning
2
) at the same speed as plain paper.
The C550 significantly speeds up scanning of
mixed size and colour
originals by automatically
detecting the proper size
paper for output and by
distinguishing black &
white from colour,
without pre-scanning.
Multi-Method Send
Accomplish more tasks in less time and with less equipment with the C550’s Multi-Method Send feature. This feature allows you to send data by fax and e-mail to multiple destinations with a single operation while simultaneously storing a copy of the data in the Box or sending it to SMB or FTP.
Fax
Scan to E-mail
Scan to SMB
Fax
E-mail Server
PCs on LAN
Ultra-Compact PDF
Make large files more portable by shrinking them with our “ultra-compact PDF” feature. The C550 uses lightning-fast hardware and software processes to compress text and images separately, creating PDF files that are now smaller than ever. Perfect for colour documents with large file sizes, these compressed PDFs have outstanding image quality, and are much easier to send and receive.
Text compression
Combining
&
PDF conversion
Image compression
Ultra-compact PDF
Text extraction
Image extraction
IPv6
Scanned original
Labelled the “next generation” protocol, IPv6 allows you to dramatically expand the number of IP addresses used with your C550.
IPv6 solves a number of problems associated with the past standard IPv4, including the limited number of available IPv4 addresses. With IPv6, all devices on the Internet have their own IP addresses, enabling direct communication between devices. IPv6 also helps improve security functions.
FTP Server
Scan to FTP
Box
Scan to Box
XPS Support and DPWS
*
To simplify document handling, bizhub provides seamless connectivity with Windows Vista through the Emperon Print System, a native XPS (XML Paper Specification) interpreter. XPS Direct Scan converts scanned documents to XPS format. XPS Direct Print allows easier printing without opening the native application or using the PDL driver. DPWS (Devices Profile for Web Services) simplifies connectivity between Vista and bizhub through features like dynamic discovery and one-click scanning. Linked by DPWS, Windows Vista and bizhub create a powerful combination that supports a wide range of document handling needs.
An upgrade to the main unit is needed for compatibility with XPS Direct Scan/Direct
*
Print, as well as DPWS. Please contact your service centre for further details.
i-Option
*
The new i-Option will expand the possibilities of your bizhub's control panel. This optional feature contains Web browser functions that enable PDF files to be easily previewed, downloaded and printed from the MFP control panel without a PC. i-Option also includes an Image Panel function that divides the control panel into three areas, input, edit and output, and allows intuitive data handling. Finally, i-Option allows the user to add a PDF encryption function using a password or digital signature.
Optional UK-201 is required.
*
Web browser function
7bizhub C550
Communication and Collaboration
Improve the way you share and store knowledge with the C550's state­of-the-art fax features and Box function.
Box
PageScope Box Operator
PageScope Box Operator allows you to download and access scanned data stored in a Box directly from your PC. With multi-file preview you can search through thumbnails to find any file easily. Then you can print scanned or faxed data stored in the Box without ever walking away from your PC screen. If you’d like to attach and e-mail a file, you can also convert with this software by turning a PDF, TIFF or JPEG into an ultra-compact PDF.
Copied data
Printed data
Scanned data
Faxed data
Up to 3,000 documents
Data storage
Up to 10,000 pages
Up to 3,000 documents or 10,000 pages can be stored
*
in the Box. Each Box can store a maximum of 200 documents. Up to 1,000 Boxes can be created.
*
Re-Output
Box
Distribution
Box Function
Store and manage data efficiently on the C550’s hard disk drive with our Box function. Assign Boxes to individuals, project teams or departments for more reliable storage (up to 3,000 documents or 10,000 pages), seamless distribution and easier sharing of knowledge. You can also allocate Boxes by theme, project or goals for more flexible data management. And for optimal security, the password authentication function allows you to assign a password to each Box. Once in a Box, stored data can be sent to fax, e-mail, FTP or SMB.
Outside the office Client AOverseas Client B
Mobile PC
Internet
Internet fax Internet fax Super G3 fax
Internet
PSTN
8 bizhub C550
Send to E-mail
Automatic forwarding of received fax
Send to FTP
FTP server Client PC
Send to SMB
Head office
Intranet
IP address fax
Branch office
Fax
PC-Fax Function
Send data directly from your PC to an outside fax machine. You can create a cover sheet directly from the driver screen on your PC and attach it to the document. Because there’s no need to print before faxing, the C550’s PC-Fax saves time and paper, and preserves image quality.
IP Address Fax
Send faxes faster and in a more cost efficient manner with bizhub’s IP Fax. With IP Address Fax, you can send a colour or black & white fax to any bizhub on the network that supports IP Fax simply by selecting an IP address. No additional costs are associated with this feature because it uses existing network systems.
Optional Fax Kit FK-502 is required.
*
Internet Fax
Send and receive fax data as an e-mail attachment with the C550’s Internet Fax. This helps reduce communication costs especially when faxing internationally or to remote areas.
TSI Routing
By using TSI (Transmitting Subscriber Identification), faxes can be identified and sorted by whom, or what organisation, sent them. With this TSI information, you can then set up a folder within the Box, which will automatically receive and store all of that party’s faxes. The TSI identified data can also be sent separately to an e-mail, FTP or SMB server and be printed at the same time.
Client PC
Automatic sorting of
incoming faxes by sender's TSI
Company A
Company B
Company C
)
Saved in Company A Box
Send to
SMB
Send to E-mail
Sent to specified
Company B folder
FTP Server
Send to FTP server
Sent to
specified Company C
shared folder
E-mail Server
Fax Security Functions
Avoid fax transmission errors with the C550’s fax security functions. Check that you’re faxing the correct destination by having the destination name and fax number appear on the control panel before faxing. For even more secure transmissions, the C550 can automatically verify that the destination machine’s CSI (Called Subscriber Information) data matches your specified fax number before transmitting.
Address Registration/
Programmed Transmission
Register up to 2,000 individual and 100 group addresses and fax numbers as well as their respective scan and telecommunication methods, for quick access and easy sending.
Multi-Port Fax* (Optional)
By connecting two telephone lines, data can be sent to two destinations at the same time. Faxes can also be received on one line while the other line is sending.
Not applicable when using IP address fax.
*
Tr ansmission Result Report
The C550 can print out a fax transmission result report to show a record of your fax transmission(s).
Tel/Fax Automatic Switching
The C550 lets you share a single line for both telephone and fax use.
Company D
Sent to specified
Company D
e-mail address
9bizhub C550
Security
Security
and
Management
Keeping your office's network secure and managing the flow of work is of primary importance. The C550 helps with features like biometric finger vein authentication and software like PageScope Data Administrator.
Secure Print
Protect important confidential documents such as job estimates or salary reports by setting a password as a security lock. Protected documents cannot be output until the set password is entered into the C550, ensuring that the documents are opened only by those intended to read them.
Data stored in Secure Print Box
Enter Password
Secure Print
Secure Print
Box
Select Secure Print
User Authentication
With this feature, the administrator can permit or restrict the use of the C550's functions. This system allows the administrator to set privileges for copying, printing, scanning, faxing and Box functions for each individual user with an authentication function based on the Active Directory server. If your network lacks a server, the administrator can use the C550’s built-in user authentication function.
Box
IC Card Authentication
The C550's IC card authentication is a perfect option for individual user authentication. Copy, print, scan and fax functions can all be restricted through its use. This quick-response, noncontact IC card supports the widely used Felica smart card system. In the office, Felica cards are traditionally used for company identification purposes, but can now also be repurposed to work directly with the C550. This means you only have to carry one card.
Optional Authentication Unit AU-201 and Local Interface Kit
*
EK-602 are required.
Biometric Finger Vein Authentication
The cutting edge in biometric
finger vein patterns captured by
scanning the finger. This measurement uses an internal characteristic as identification, and is nearly impossible to falsify. Functionally, this authentication method is easy and fast, since there’s no need to remember passwords or carry a card.
Optional Authentication Unit AU-101 and Local Interface Kit
*
EK-602 are required.
*
*
authentication, finger vein authentication uses images of
10 bizhub C550
Encrypted PDF
Prevent unauthorised viewing or printing of a scanned paper document by creating an encrypted PDF while you scan. By requiring a password to open the file, access to confidential data is restricted, which helps prevent information leaks.
Copy Protection
To prevent unauthorised individuals from re-copying private documents, the C550 offers a selection of concealed watermarks to identify printouts as reprints. The watermark, with messages such as “Confidential”, only becomes apparent upon re-copying a printout. There are several watermark phrases or patterns available, or the administrator can create and register a customised mark. This standard feature works when re-copying a document on any brand of MFP.
Original
Copy
Print
Concealed watermark appears when re-copied.
Annotation Function
Protect data and manage it by client or production date with the C550’s Annotation function. When a document is stored in an Annotation User Box, a pre-set administrator counter number will automatically be printed on the document when retrieved from the Box. This imprinted information deters unauthorised personnel from printing these documents.
Output document
with concealed watermark
Distribute
Re-copy distributed document
IP Filtering
Prevent unauthorised access to the C550 by registering the IP addresses of those PCs that your company wants to grant access to.
SSL/TLS Encryption
The SSL/TLS encryption protocol protects data during data exchanges between the C550 and the LDAP server, Pagescope Data Administrator, PageScope Web Connection as well as other programs.
S/MIME
The C550 uses Secure Multipurpose Internet Mail Extensions (S/MIME), an e-mail encryption standard that protects e-mail exchanges.
HDD Data Encryption
Automatically encrypt or decrypt job or settings data as it is written to or read from the hard disk drive.
Optional Security Kit SC-503 is required.
*
HDD Auto Deletion
The C550 can automatically delete management information or other recoverable data on the hard disk drive, after copying, scanning, printing or faxing by overwriting specially formatted data.
HDD Lock
A password-protected lock can be applied to the hard disk drive preventing anyone from reading it, even if the drive is removed from the C550.
Security Log
Protect confidential information and dissuade unauthorised users. The security log feature allows administrators to manage a detailed log of authentication data, Box access information and executed jobs.
(In development)
*
Management
Department Management
Better manage your costs by fully understanding and controlling C550 use by department. Choose the functions available as well as the number of pages that can be output by department (up to 1,000). In addition, you can monitor each department’s use of copy, print, fax and scan functions. Combine these features with the user authentication function, and you can also set restrictions for individual users.
PageScope Data Administrator
With this software, administrators can manage user and department authentication data and directory information such as e-mail addresses and fax numbers.
PageScope Workware (Optional)
Combine data from scanned paper documents and ordinary application files in a single PDF. This software allows you to edit and output from your PC.
11bizhub C550
Outstanding colour, faster output time, better networkability and a host of innovative finishing functions. These are the features that make you more productive using the C550.
High Speed, High Quality
Productivity
and
Production
High-Speed, High-Quality Printing
The C550 produces presentation-quality outputs quickly and efficiently. It churns out 45 pages per minute of colour pages and 55 pages of black & white. And now, the C550 also boasts some of the fastest first copy times on the market at 4.3 seconds in black & white and a class-leading 6.5 seconds in colour. The C550’s superior text reproduction technology achieves low noise and uniform reproduction of both black and colour text and fine lines.
Network Printing
Freely print out documents and graphics from a variety of PCs on the network utlising the C550’s network
printing function with the standard Emperon Print System. For demanding desktop publishing and graphic design needs, the optional Fiery Image Controller* permits printing in a PostScript 3 environment. Multi-OS and multi-protocol
Network printer system example
Windows XP Windows NT4.0 Mac OS
support on the C550 allows a wider range of use, including networks with Windows and Macintosh computers.
Optional Image Controller IC-409 and Video Interface Kit
*
VI-504 are required.
Large-Capacity Paper Supply &
Paper Compatibility
The C550 holds up to 3,650 sheets of paper (up to 3,500 sheets of A4 and up to 150 sheets of paper as wide as A3 size in the multiple bypass tray). With the optional Side Paper Deck LU-301 the C550’s capacity increases to 6,650 sheets! The C550 handles paper ranging in size from A6 to A3 wide as well as thick paper up to 256g/m bypass tray.
Top tray
<
500 sheets
2
:A4)
>
2
:A4)
>
Max. A3 Wide
(80g/m
Middle tray
<
Max. A3 Wide
500 sheets
(80g/m
2
or 300g/m2 from the multiple
Multiple Bypass tray
<
(manual feed) Max. A3 Wide 150 sheets (80g/m
>
2
)
12 bizhub C451bizhub C550
Windows 2000
Windows Server 2003
Windows Vista*
Compatibility in development.
*
Bottom
<
left tray
Max. A4
1,500 sheets
(80g/m
>
2
LU-301
<
>
)
Bottom right tray
<
Max. A4 1,000 sheets (80g/m
>
2
)
Max. A4 3,000 sheets
2
(80g/m
)
Improved Multi Job Ability
The C550 can simultaneously handle multiple jobs better than ever—fax and scan, scan and print, print and save to Box or perform a multitude of other combinations.
Image Stabilisation
We’ve reduced image stabilisation time, which means that the C550 is more efficient— making you more productive.
100% Duplex Productivity
Double-sided colour output doesn’t slow down the C550. Achieve a fast 45 pages per minute when outputting double-sided pages thanks to a complex paper feed control system that alternately feeds three sheets at a time. A specially designed roller also helps maintain maximum productivity.
Finishing
ADF Dust Reduction
The scanner glass slides back and forth to remove dust from the glass surface. This suppresses streaks during scanning, and improves your output.
ICC Profile Supported*
To meet the colour-management requirements of high-end graphic design and imaging users, the C550 supports ICC (International Color Consortium) profiles that enable more accurate colour matching with monitors and scanners.
PostScript driver only.
*
Booklet Printing
Create booklets with ease. The C550’s pagination function outputs pages in the proper order for producing presentation­quality booklets. Equipped with the optional Finisher FS-608, the C550 can create booklets up to 80 pages in length, handling paper as thick as 209g/ m
Versatile Finisher (Optional)
Create professional presentations, attractive manuals, proposals and even direct mail pieces
Stapling Function
Corner staple
Folding Function
2
2-point staple (Side)
.
Booklet (Centre staple
and folding)
Hole Punching Function
without sending materials to a printer. Combined with the C550, the optional Finisher FS-517 or FS-608 give you efficient, print-on-demand versatility. These high performance finishers feature automatic stapling, hole punching,* saddle stitching, and many other finishing tasks, allowing you to take on both large and small-volume jobs in-house.
Optional Punch Kit PK-512 is required.
*
Cover Sheet/Inter Sheet
Create more attractive looking booklets. Use paper of different colours or thicknesses for front or rear cover sheets or section dividers.
Print Status Notification
A pop-up dialog box will appear on the user’s PC screen when jobs have finished, paper has run out or when toner is low.
Confirming Copy/Print Jobs
The C550 lets you output a single test job before making multiple copy or print runs. This saves time and reduces paper and toner waste.
Fold
2-hole left 2-hole right2-hole top
13bizhub C451bizhub C550
Productivity and Production
For the C550, we’ve added several advanced technologies to speed up and improve your office’s output.
New Production Technologies
New Tandem Engine
Our new tandem engine transfers the CMYK colours in just one step, rather than the four steps normally required. This greatly improves the C550’s output speed, while maintaining outstanding colour. We’ve also enlarged the most frequently used photoconductive drum, black (K), thus improving its lifespan.
Simitri HD Toner
The small size and consistent shape of Simitri HD toner particles ensure sharp reproduction of text as well as line drawings. Its smooth outer surface provides excellent hold and promises high image quality across a diverse media mix. Furthermore, the C550 uses low-temperature fixing to affix the Simitri HD toner. Using less heat saves energy and effectively reduces paper stress.
Composition of Simitri HD tonerConventional toner Simitri HD toner
Colour material
Wax
6.5µm
New Twin-Beam Laser Printhead
The C550's new twin-beam laser printhead helps achieve high output speed and a compact footprint. Thanks to a new automatic skew-correction mechanism, the new printhead also improves image quality and reduces colour-shift.
IH Fixing
The C550 uses new IH (induction heating) fixing technology in its belt-driven fixing unit. This technology heats the roller’s surface only, rather than the entire roller, thus reducing energy consumption. Together with the low-temperature fixing, Simitri HD toner, this technology works to significantly reduce warm-up time.
IH Coil Unit
Comparison of pulverised toner and Simitri HD toner (internal test)
Pulverised toner
dot line text
Simitri HD toner
Magnetic flux
Demagnetising coil
Magnetising coil
Fixing belt
Fixing roller
Environmental Conservation
Konica Minolta's commitment to the environment is driven by the cutting-edge technologies that earn the C550 various energy certifications.
Energy Star
The C550 utilises technologies including IH fixing and a high-
efficiency supply circuit. These help the C550 to maintain kilowatt hour usage far below the new (April 2007) maximum weekly consumption limit outlined in the Energy Star program's rigorous international guidelines for energy efficient products. And it does so without sacrificing features or performance.
Blue Angel Mark (BAM)*
According to Konica Minolta, the C550 is set to
exceed the standards and guidelines set forth by Germany's Blue Angel Mark (BAM2004) for efficiency and environmental responsibility. Konica Minolta estimates that the C550 will be the only MFP in its class to meet BAM's most stringent guideline “time to recover from sleep mode.” The C550 wakes up in a lightning-quick 30 seconds.
Official Blue Angel Mark approval is pending.
*
RoHS Compliance
The C550 was built in compliance with the European Union’s RoHs (Restriction of Hazardous Substances) guidelines. RoHS restricts certain harmful substances, including lead, mercury, cadmium, hexavalent chromium, PBB and PBDE from being used during the production of electrical and electronic components.
Pressure roller
Halogen heater
Heat soaking roller
Roller Unit
Paper feed path
14 bizhub C550
New Design
The minimalist approach of the C550’s InfoLine design ensures that information is easy to find, convenient to access and intuitive to use.
Colour, LCD Control Panel
At the intersection of the bizhub’s distinctive white lines lies its unique colour control panel. The user interface of this panel boasts an 800 x 480 pixel, colour, touch­screen, LCD display, and the ability to enlarge text. For easier document viewing, colour previews of copied or scanned images can be shown on the display as thumbnails. The entire panel can
also be tilted 22 degrees up and down in 3 stages as well as 30 degrees left and right, making it accessible to just
Basic Screen
Thumbnail Screen
about anyone. Finally, two distinct basic screens are available, allowing you to interface with the C550’s controls as you wish.
As smart outside as it is on the inside. To create an MFP that is at home in a high-designed office as it is in a conventionally designed one, we gave the C550 a unique black body, interrupted only by a single white line (the InfoLine) traversing its length and width. The white line contains LEDs alerting you to current machine status. A blue LED, easily identified even by those with colour recognition problems, indicates printing and data reception status. The red LED indicates various alerts, including paper tray depletion.
The C550 was designed to insure that anyone, regardless of age, gender, body size, or disability could comfortably use the C550. Specifically, the C550 provides a clear, easy to read control panel, trouble-free access to paper and toner and easy­grip trays.
Styling and Colour
Universal Design
Print Preview Screen
15bizhub C550
Type Console Colour Support Full-Colour Copy Resolution Scan 600dpi
Gradation 256 Memory Capacity (Std/Max) 1GB HDD 60GB (Standard) Original Type Sheets, Books, Objects (Max. 2kg) Max. Original Size A3 Max. Paper Size A3 Wide (12 1/4" ✕ 18") Output Size A3SEF-A5, B6SEF, A3 Wide (311 ✕ 457mm),
Image Loss Warm-Up Time (time from when sub-power is turned on) First Copy Time Colour 6.5 sec. or less (23°C, std. voltage) Copy Speed Colour 45 ppm
Copy Magnification
Paper Capacity Std. (80g/m2 paper)
Paper Weight Top Tray, Middle Tray, Bottom Tray: 64-256g/m
Multiple Copy 1-9,999 sheets Power Requirements AC220-240V 10A (50Hz) Max. Power Consumption 2.0kW or less Dimensions Weight Approx. 190kg Space Requirements
Printer Specifications (Standard)
Type Embedded CPU MPC7448 867MHz (Shared with copier) Memory 1GB (Shared with copier) Print Speed Same as Copy Speed (when using the same original) HDD 60GB (Shared with copier) Print Resolution 1,800dpi equivalent PDL PCL6, PostScript3 Emulation Protocol Support OS
Font PCL 80 fonts
Interface (Standard) 10BASE-T/100BASE-TX/1000BASE-T, Hi -Speed USB
Print 1,800dpi equivalent ✕ 600dpi
A6SEF Thick Paper, Postcard (100 Top: 4.2mm or less, Bottom: 3mm or less, Sides: 3mm or less 30 sec. or less
B/W 4.3 sec. or less
B/W 55 ppm Fixed Same Magnification 1:1±0.5% or less Scaling Up 1:1.154/ 1. 224/ 1.4 14 /2.000 Scaling Down 1:0.866/ 0.816/0.707/ 0.500 Preset 3 custom settings Zoom 25-400% (in 0.1% increments)
[W] ✕ [D] ✕ [H] 650mm ✕ 904mm ✕ 1,155mm
[W] ✕ [D]
PS 137 fonts
500 sheets (Top Tray), 500 sheets (Middle Tray), 1,500 sheets (Bottom Left Tray), 1,000 sheets (Bottom Right Tray), 150 sheets (Multiple Bypass Tray)
Multiple Bypass Tray: 64-300g/m
1,150mm ✕ 1,358mm *Multiple Bypass Tray opened
600dpi
TCP/IP, IPX/SPX (NDS), SMB (Net BEUI), LPD, IPP1.1, SNMP, HTTP Windows NT4.0 SP6/ 2000, SP3/ XP/XP64bit/ Server2003/ Server2003 64bit / Vista(compatibility in development) or later, MacOS 9.2(PPD)/ X 10.2,3,4 /10.4 Intel or later, Unix/ Linux
148mm)
2
2
Scanning Function Specifications (Standard)bizhub C550 Specifications
Type Full-Colour Scanner Scanning Size Max. A3 Scanning Resolution 60 0/400/300/200dpi Scanning Speed B/W / Colour 70/70 (300dpi), 55/50 (600dpi) Main Functions Interface 10BASE-T/100BASE-TX/1000BASE-T Protocol TCP/IP (FTP, SMB, SMTP) Support OS Windows 2000, Windows XP Output Format Single TIFF, Multi TIFF, JPEG, PDF, Compact PDF Driver TWAIN (2000/ XP/XP64bit or later)
Internet Fax Function Specifications
Protocol SMTP, POP Connection Mode Full-Mode Sending Paper Size Max. A3 (Long Length Support: Max. 1,000mm) Recording Paper Size Max. A3 Interface Ethernet 10BASE-T/10 0BASE-TX/1000BASE-T Resolution 200✕100dpi, 200✕200dpi Data Format TIFF, JPEG, PDF, Compact PDF
Fax Function Specifications
Send Size Max. A3 (Long Length Max.1,000mm) Record Size Communication Standard Super G3 Line Density G3: 8
Communication Time Less than 3 sec. (V.34, JBIG) Communication Speed 2.4kbps-33.6kbps Compression MH/MR/MMR/JBIG Communication Line Public Phone Line, Fax Communication Line Scanning Speed 2.0 sec (A4/detailed mode) Shortcut Dial 2,000 Program 400 Group 100
Fiery Image Controller Specifications
Type Embedded Type CPU Intel Celeron 2.8 GHz Memory 512MB HDD 80GB Print Speed Same as Copy Speed (when using the same original ) Resolution 1,800dpi equivalent PDL Adobe PostScript3 ver.3017, PCL6 Protocol Support OS Windows 2000/ XP/ Server 2003, Mac X(10.3.9/10.4) Std. Fonts 136 fonts Interface 10BASE-T/100BASE-TX/ 10 00BASE-T
Scan to E-Mail, Scan to FTP, Scan to Box, Scan to SMB, TWAIN
(Optional)
Max. A3 (Long Length Record Max.1,000mm - following the page division)
3.85, 8✕7. 7, 8✕15.4, 16✕15.4 line/mm,
200dpi, 400✕400dpi, 600✕600dpi
200
(Optional)
600dpi
TCP/IP(Port9100, LPD, HTTP/HTTPS, SNMP), IPX/SPX, SMB, Ethertalk
,
400✕400dpi, 600✕600dpi
System Options
Finisher FS-517
This reliable and speedy finisher allows you to sort and multi-staple sets of up to 50 sheets.
Finisher FS-608
This high-performance finisher performs the same functions as the FS-517 and it gives you the ability to saddle stitch up to 20 sets of booklets at once. (Max. 20 sheets for each booklet)
Punch Kit PK-512
Attach to Finishers FS-517 or FS-608 for hole punching capability.
Product appearance, configuration and/or specifications are subject to change without notice.
The Konica Minolta logo and the symbol mark, and "The essentials of imaging" are registered trademarks or trademarks of Konica Minolta Holdings, Inc. bizhub, PageScope, Simitri and the Emperon logo are registered trademarks or trademarks of KONICA MINOLTA BUSINESS
TECHNOLOGIES, INC.
Windows is a registered trademark of Microsoft Corporation in the United States and other countries. Adobe and PostScript are registered trademarks or trademarks of Adobe Systems Incorporated. All other brand and product names are registered trademarks or trademarks of their respective owners.
Post Inserter PI- 503
These input trays allow you to include cover sheets or chapter break sheets simultaneously.
Konica Minolta copiers and multi-functional peripherals are designed with the environment in mind.
This product has earned the ENERGY STAR for energy efficiency. ENERGY STAR is a U.S. registered mark.
ISO15408 (EAL Level 3) Certification
Output Tray OT-503
FS-608FS-517
Have Earned ENERGY STAR for Energy Efficiency The Use of Recycled Materials Production at ISO-Certified Factories
This product complies with the security requirements of ISO15408 (EAL Level 3).
*
The ISO 15408 certification applies only to IT security
capabilities. This certification is NOT a product guarantee.
Fax Kit FK-502
Allows the C550 to perform fax functions.
Image Controller IC-409
Video Interface Kit VI-504
Local Interface Kit EK-603 (USB Host)
Working Table
WT-502
Side Paper Deck LU-301
Increases the C550’s paper capacity by 3,000 sheets
2
(A4, 80g/m
).
Requirements for safe use
• Please read and follow the instruction manual to ensure safe operation.
• Only operate using appropriate power supply and voltage.
• Connecting the earth wire to an inappropriate place may cause explosion or
electric shock. Please connect accordingly (Taiwan and
the Philippines only).
This catalogue was printed using soy ink.
    
Loading...
