Issue Department： Date：
2018.11.15
Instruction of RF3409
1 Key description
1.1 appearance
System Instruction
Instruction of RF3409
Author：
Edition：
Page 1 of 4
1.1
FCC ID：PCU-CB1220
IC: 21319-CB1220
FCC ID: PCU-RF3409
IC：21319-RF3409
5
9
7
8
6
2 3
1
4
Figure1buttonofremote
1/4
Issue Department： Date：
2018.11.15
Author：
Edition：
Page 2 of 4
Key description
2.
System Instruction
Instruction of RF3409
2.1 ZG button
Click the ZG button, the actuator moves to ZG position, stop when click any button during the
movement;
Press and hold the ZG button for 5s, timer LED of remote flashes, the control box records
current position as ZG position;
When in the process of movingto memory positions, the head and foot actuatorsmove first,
then the tilt and lumbar actuators move;
1.1
2.2 AntiSnore button
Click AntiSnore button, actuators move to AntiSnore position, stop when click any b utton
during movement；
Press and hold
current position as
When in the process of moving to memory positions, the head and foot actuators move first,
then the tilt and lumbar actuators move;
AntiSnore button for 5s, timer LED of remote flashes, the control box records
AntiSnore position;
2.3 Memory A button
Click MA button, actuators move to MA position, stop when click any button during
movement；
Press and hold MA button for 5s, timer LED of remote flashes, the control box records current
position as MA position;
When in the process of moving to memory positions, the head and foot actuators move first,
then the tilt and lumbar actuators move;
2.4 Reset all memory positions to default settings
Pressa and hold ZG+FLAT buttonsfor 5s, timer LED of remote flashes, the control box reset
all memory positions to default settings；
2/4
Issue Department： Date：
2018.11.15
System Instruction
Instruction of RF3409
Author：
Edition：
Page 3 of 4
1.1
2.5 Head up
Press and hold HEAD UP button of remote, head actuator moves out, stop when
released；
2.6 Head down
Press and hold HEAD DOWN button of remote, head actuator moves in, stop when released；
2.7 Foot up
Pressa and hold FOOT UP button of remote, foot actuator moves out, stop when released;
2.8 Foot down
Press and hold FOOT DOWN button of remote, foot actuator moves in , stop when released；
When moving to flat position, lumbar actuator and tilt actuator move first, after 500ms, head
andfoot actuators start moving;
2.9 Flat
Click FLAT button, the bed goes flat, stop when click any button during the process of going
flat；
2.10 Under bed light
Click the under bed light button, the under bed light switch its on/off state; After the under bed
light opens, if do not manually close, it will automatically turn off after 5 minutes;
3/4
Issue Department： Date：
2018.11.15
System Instruction
Instruction of RF3409
Author：
Edition：
Page 4 of 4
1.1
FCC Warning：
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
ISED RSS Warning:
This device complies with Innovation,Science and Economic Development Canada
licenceexemptRSS standard(s). Operation is subject to the following two conditions: (1) this
devicemay not cause interference, and (2) this device must accept any interference,
includinginterference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'ISED applicables aux appareils radioexempts de
licence.
L'exploitation est autorisée aux deux condi tions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,même si le
brouillage est susceptible d'en compromettre le fonctionnement.
ISED RF exposure statement:
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled
environment.The device has been evaluated to meet general RF exposure requirement.
Le matériel est conforme aux limites de dose d'exposition aux rayonnements énoncés pour fac un
autre environnement.ce dispositif a été évalué à satisfaire l'exigence générale de l'exposition aux rf.
4/4
