OJ Electronics UDG4 User Manual

WWW.OJELECTRONICS.COM
© 2014 OJ Electronics A/S© 2014 OJ Electronics A/S
UDG4 Touch Thermostat
Interactive User Manual
67371 02/15 JRK
67370 02/15 (JRK)
Touch
PAGE 2
© 2014 OJ Electronics A/S
1. Contents
2. Menu Overview . . . . . . . . . . . . . .3
3. Introduction . . . . . . . . . . . . . . . . 4
4. General Operation . . . . . . . . . . . .5
4.1.Navigation Buttons . . . . . . . . . . 6
5. Ground Fault Circuit Interrupter (GFCI)
. . . . . . . . . . . . . . . . . . . . . . 7
6. Icons 1/2. . . . . . . . . . . . . . . . . . . 8
6. Icons 2/2. . . . . . . . . . . . . . . . . . . 9
7. Startup Wizard . . . . . . . . . . . . . . 10
7.1 Set the language . . . . . . . . . . .11
7.2 System Test . . . . . . . . . . . . . . 12
7.3 GFCI Test. . . . . . . . . . . . . . . . 13
7.4 Set the preferred temperature unit 14
7.5 Set the floor load . . . . . . . . . . . 15
7.6 Set the sensor type. . . . . . . . . . 16
7.7 Set the date . . . . . . . . . . . . . . 17
7.8 Set the time . . . . . . . . . . . . . . 18
7.9 Set floor protection . . . . . . . . . 19
7.10 Thermostat activation . . . . . . . 20
8. Programed Heating Schedule . . . . 21
9. Operating Modes . . . . . . . . . . . . 22
9.1 Scheduled Operation . . . . . . . . 23
9.2 Manual Operation. . . . . . . . . . . 24
9.2.1 Manual Operation Adjust . . . . . 25
9.2.1.1 Adjust... for a few hours. . . . . 26
9.2.1.2 Adjust... for a few days . . . . . 27
9.2.1.3 Adjust... permanently . . . . . . 28
9.3 Regulator Mode. . . . . . . . . . . . 29
10. Thermostat Setup Menu . . . . . . 30
10.1 Heating Schedule 1/2 . . . . . . . 31
10.1 Heating Schedule 2/2 . . . . . . . 32
10.2 Energy Use . . . . . . . . . . . . . 33
10.3. User Settings . . . . . . . . . . . . 34
10.3.1 Child Lock 1/2 . . . . . . . . . 35
10.3.1 Child Lock 2/2 . . . . . . . . . 36
10.3.2 Display Brightness . . . . . . . 37
10.3.3 Screen Saver . . . . . . . . . . 38
10.3.4 Energy Tari . . . . . . . . . . . 39
10.3.5 Date . . . . . . . . . . . . . . . 40
10.3.6 Time . . . . . . . . . . . . . . . 41
10.3.7 Daylight Saving Time . . . . . 42
10.3.8 Unit . . . . . . . . . . . . . . . . 43
10.3.9 Language . . . . . . . . . . . . 44
10.3.10 Information . . . . . . . . . . 45
10.3.11 Support . . . . . . . . . . . . 46
10.4 Installer Settings . . . . . . . . . .47
10.4.1 Adaptive Function . . . . . . . 48
10.4.2 Open Window . . . . . . . . . 49
10.4.3 Sensor Application 1/2 . . . . 50
10.4.3 Sensor Application 2/2 . . . . 51
10.4.4 Sensor Type 1/2 . . . . . . . . 52
10.4.4 Sensor Type 2/2 . . . . . . . . 53
10.4.5 Floor Sensor Calibration . . . 54
10.4.6 Room Sensor Calibration . . . 55
10.4.7 Floor Protection 1/2 . . . . . . 56
10.4.7 Floor Protection 2/2 . . . . . . 57
10.4.8 Factory Reset . . . . . . . . . . 58
11. Factory Settings . . . . . . . . . . . . 59
12. Troubleshooting 1/2. . . . . . . . . . 60
12. Troubleshooting 2/2. . . . . . . . . . 61
PAGE 3
© 2014 OJ Electronics A/S
Installer Settings
2. Menu Overview
Menu Structure
Menu
Heating Schedule
User Settings
PAGE 4
© 2014 OJ Electronics A/S
3. Introduction
Congratulations on the purchase of your new touch thermostat. We hope that you will enjoy the ease of use oered by the touchscreen and the intuitively designed user interface. You can program the thermostat in any way you would like with the options provided under Heating Schedule and User Settings.
The thermostat will switch your underfloor heating system on at predetermined times each day of the week. You can set individual temperatures for up to six separate events for each day of the week. Lowering the temperature when your home is unoccupied will reduce your energy costs without reducing comfort.
The thermostat comes with a preset heating schedule that is suitable for most homes. Unless you change the settings, the thermostat will operate according to this preset heating schedule.
The thermostat features an adaptive function that automatically changes the heating start times to ensure that the required temperature has been reached at the beginning of any specific event. After a few days, the adaptive function will have learned how much earlier the heating must be switched on.
The resistive touchscreen only requires a soft tap with your fingertip to register the touch. In this manual, the touch areas on the screen will be referred to as buttons.
PAGE 5
© 2014 OJ Electronics A/S
67370 02/15 (JRK)
Touch
The thermostat has two physical buttons. A ground fault circuit interrupter (GFCI) test button is located on top of the thermostat, and a power/reset button is located on the right side of the thermostat. The GFCI should be tested monthly (all settings, including time and date, will be remembered). The thermostat is an intuitively operated touch thermostat in which the touchscreen is used to navigate through the menus and to change the settings. The function of the buttons and icons on the home screen can be seen below.
4. General Operation
PAGE 6
© 2014 OJ Electronics A/S
4.1.Navigation Buttons
Accept/Back/Cancel/Arrow Up/Arrow Down/Arrow Left/Arrow Right
Whenever you change a parameter setting, you must tap the “Accept” button for the thermostat to acknowledge the change. “Accept” is shown on the screen as “√”.
“Back” is shown on the screen as a button marked with a hollow arrow pointing to the left. In the various menus and submenus, you will find the “Back” button in the lower left corner of the touchscreen.
Tap the “Back” button to return to the previous menu.
“Cancel” is shown on the screen as a button marked “X”.
Although “Cancel” has the same eect as “Back”, it also results in all the unsaved settings being discarded.
As soon as you leave a home screen and enter one of the menus, either a “Back” button or a “Cancel” button will be shown.
To return to the home screen, tap Back/Cancel once or multiple times depending on where you are in the menu structure.
“Arrow Up”, “Arrow Down”, “Arrow Left”, and “Arrow Right” are used to toggle settings and values and to navigate through the menus. The “Arrow Up” and “Arrow Down” buttons are accelerated buttons. Holding either of them will make the value change continuously.
PAGE 7
© 2014 OJ Electronics A/S
The thermostat has a built-in GFCI that ensures personal safety in case of ground faults. It is important that the GFCI is tested monthly. Installation and use must be according to the national and local regulations.
Testing the GFCI
Press the test button on the top of the thermostat. The test is successful if the red light in the test button lights up and a GFCI error text is shown on the display. Press the power/reset button on the lower right side of the thermostat to reset the GFCI.
The red light should go out and the display should return to normal appearance. If this does not occur, contact your electrician.
If, during normal operation, the GFCI trips even though the test button was not pressed, there could be a ground fault! To determine whether this was caused by a ground fault or by nuisance tripping, press the power/reset button.
If this causes the red light in the test button to go o and stay o, it was nuisance tripping and the system is operating correctly. If the red light remains on, there is a ground fault! In this case, you should contact your electrician.
5. Ground Fault Circuit Interrupter (GFCI)
PAGE 8
© 2014 OJ Electronics A/S
6. Icons 1/2
Menu
Heating Schedule
Energy Use
User Settings
Installer Settings
Child Lock
Display Brightness
Screen Saver
Icon
Meaning
Energy Tari
Date
Time
Daylight Saving Time
Unit
Language
Information
Support
$
7
5
°
Icon
Meaning
Adaptive Function
Open Window
Sensor Application
Sensor Type
Floor Protection
Floor Sensor Calibration
Room Sensor Calibration
Temperature Scale
Icon
Meaning
PAGE 9
© 2014 OJ Electronics A/S
6. Icons 2/2
Factory Reset
Accept
Back
Cancel
Arrow Up
Arrow Down
Arrow Left
Arrow Right
Icon
Meaning
Copy to
“Adjust… for a few days” in the future is activated
Heating is activated
Heating is activated with adaptive mode
Note
icons
+
icons
icons
Icon
Meaning
PAGE 10
© 2014 OJ Electronics A/S
7. Startup Wizard
When the system has been installed and turned on for the first time, or after you have performed a factory reset, the system will run a Startup Wizard. The Wizard will take you through tests, which ensure that the thermostat is fully functional. After the tests, the Wizard leads you through a basic setup routine to ensure that you have the right settings.
PAGE 11
© 2014 OJ Electronics A/S
7.1 Set the language
First you must set the language. The chosen language will become the default language for the thermostat. The language can be changed under Menu/User
Settings/Language
PAGE 12
© 2014 OJ Electronics A/S
7.2 System Test
System Test is an automatic test of the thermostat and sensors. Tap the “Arrow Right” button to continue.
PAGE 13
© 2014 OJ Electronics A/S
7.3 GFCI Test
1. Press the test button on the top of the thermostat. The test is successful if the red light in the test button lights up and a GFCI error
text is shown on the display.
2. Press the power/reset button on the lower right side of the thermostat to reset the GFCI.
3. Tap the “Arrow Right” button to continue.
PAGE 14
© 2014 OJ Electronics A/S
7.4 Set the preferred temperature unit
1. Tap the temperature unit that you prefer.
2. Tap the “Arrow Right” button to continue.
The temperature unit can be changed under Menu/User Settings/Unit
PAGE 15
© 2014 OJ Electronics A/S
7.5 Set the floor load
1. Set the load of the underfloor heating system to be controlled by the thermostat.
2. Tap the “Arrow Right” button to continue.
This setting can be changed later if a factory reset is performed.
PAGE 16
© 2014 OJ Electronics A/S
1. Tap the sensor type installed in the floor.
2. Tap the “Arrow Right” button to continue.
If you want to use the thermostat with the room sensor only, you must complete the Setup Wizard using “Default” as the floor sensor type before going to: Menu/ Installer Settings/Sensor Application and choosing “Room”.
7.6 Set the sensor type
PAGE 17
© 2014 OJ Electronics A/S
7.7 Set the date
1. Tap the “Arrow” buttons to change the values.
2. Tap the preferred date format.
3. Tap the “Arrow Right” button to continue.
The date can be changed under Menu/User Settings/Date
PAGE 18
© 2014 OJ Electronics A/S
7.8 Set the time
1. Tap the “Arrow” buttons to change the values.
2. Tap the preferred time format.
3. Tap the “Arrow Right” button to continue.
The time can be changed under Menu/User Settings/Time
PAGE 19
© 2014 OJ Electronics A/S
7.9 Set floor protection
Set the floor protection according to the floor type.
1. Tap the preferred limits that are used to protect the floor.
2. Tap “√” to continue
Floor protection settings can be changed under Menu/Installer Settings/Floor
Protection.
