Officezone 1035, 2035, 1036 Operation Manual

Office Zone

1-800-543-5454

1-800-543-5454

[phone]

IDEAL Cutters

Model 1035 Model 2035 Model 1036

1. Knife guard

2. Knife carrier

3. Clamp lever

4. Clamp bar for automatic clamp

5. Back gauge

6. Side lay with cm / inch scale

Safety Regulations

A. IDEA L trimmers comply with international safety regulations and are safety-tested.
B. All trimmers are provided with approved safety guards (#1). For a safe operation of the trimmers

it is important, that the knife guard is not taken off.

C. The knife carrier (#2) is fitted with a friction device. If adjusted correctly, this friction device

insures, that the knife carrier (#2) with the knife cannot move down on its own from any position.

D. If the knife carrier (#2) does not stay in position and moves down on its own, please re-adjust the

friction device immediately.

E. To adjust the friction device loosen the set screw (I) . Tighten the nut (II). Retighten the set screw

(I).

Installation

The Model IDEAL 1036 does not need any assembly. On models IDEAL 1035 and IDEAL 2035
the clamp with the attached knife guard (#1) has been taken off for shipping.

For re-assembling proceed as follows:

Turn out screws on fixing points. Place knife guard (A) with attached clamp bar on machine as
illustrated. The knife guard must be catched behind the guiding screw (B) on knife-carrier. Turn
screws into fixing points (don’t tighten). Adjust knife guard to sit close to the knife and tighten
screws.
