ITP-5112L IP Telephone User Guide
IP Telephone
User Guide
ITP-5112L
SSAAFFEETTYY CCOONNCCEERRNNSS
The following is the contents for securing user’s safety and for preventing the damage to
user’s property. Please make a good use of our product with its description below.
Conventions
Warning
Provides information or instructions that you should follow in order to avoid
personal injury or fatality.
Caution
Provides information or instructions that you should follow in order to avoid a
service failure or damage to your phone.
Note
Indicates additional information for referrence.
Symbols
Caution
Indication of a general caution.
Restriction
Indication for prohibiting an action for a product.
Instruction
Indication for commanding a specifically required action.
2 © SAMSUNG Electronics Co., Ltd.
Warning
ITP-5112L IP Telephone User Guide
Do not leave the telephone in
dusty areas or in environments
with extreme thermal
differences or near a heating
apparatus(cigarette or heater
and so on).
Failure to do so may cause fire or
electric shock.
Do not place vases, flowerpots,
cosmetics, or medicine, which
contain water, near the
telephone.
Failure to do so may cause fire or
electric shock.
WARNING
Do not use damaged power
plug or cord, or loose outlet.
Failure to do so may cause fire or
electric shock.
Do not use or store flammable
spray or materials near the
telephone.
Failure to do so may cause fire or
electric shock.
Do not pull or bend the power
plug by force.
Do not touch the power plug
with wet hands.
Failure to do so may cause
damage to the power cord, fire
or electric shock.
Pull out the power plug when
the telephone is not used for
a long time.
Failure to do so may cause fire
or electric shock.
Pull out the power plug and
brush it with a cloth if the
contact surface with power plug
pins is dusty or gets wet. Contact
the service center if the foreign
materials or water is not
removed even after brushing.
Failure to do so may cause fire or
electric shock.
Be sure to connect the p owe r
connection port to t he power
adapter(for 220 V) offered
with the telephone.
The use of another adapter may
cause the critical damage to the
telephone.
Pull out the telephone line at
once and contact the service
center if unusual sound,
smell, or smoke comes out.
Failure to do so may cause fire
or electric shock.
© SAMSUNG Electronics Co., Ltd. 3
Caution
Be sure to connect the LAN
cable linked to network to the
LAN connection port of the
telephone, not to the PCconnection port of th e
telephone.
If the LAN cable is connected to
the PC connection port, the
telephone or PC communication
will be out of service.
Do not turn off the power while
the telephone is upgrading its
software.
Failure to do so interrupts the
upgrades by stopping the
operation of the telephone.
CAUTION
Clean the telephone with a soft
and dry cloth when cleaning.
Do not spray water directly or
do not use chemical solvents
such as wax, benzene, alcohol,
thinner, mosquito spray,
aerosol, lubricant, and
detergent.
The use of those chemical solvents
may cause the telephone’s surface
to be discolored.
Do not place the telephone
under direct sunlight.
Failure to do so may cause the
damage to the parts of the
telephone and the telephone to be
out of order.
Do not put a heavy material on
the telephone.
Failure to do so may cause the
damage to the parts of the
telephone and the telephone to be
out of order.
Do not separate, repair, or
remodel at your discretion.
Contact the retailer or the service
center if repair needs.
4 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
TTAABBLLEE OOFF CCOONNTTEENNTTSS
SAFETY CONCERNS 2
Conventions.......................................................2
Symbols ............................................................2
Warning ............................................................3
Caution .............................................................4
BEFORE USE 7
Main Functions ..................................................7
Checking Parts in the Package ..........................10
Names and Functions of Each Part....................11
Front View of Telephone................................................. 11
Functions of Each Part ...................................................12
Installing the phone.........................................13
Connecting the Phone ....................................................13
Installing the Support ...................................................... 14
THINGS YOU SHOULD KNOW 15
Adjusting Volume.............................................15
Adjusting the Handset Volume........................................15
Adjusting the Speaker Volume........................................ 16
Adjusting the Bell Sound Volume....................................16
Entering Characters..........................................17
Using AOM/Soft Menu Screen ...........................18
AOM Screen ................................................................... 18
Soft Menu Screen........................................................... 19
Phone Status LED ............................................20
LED.................................................................20
© SAMSUNG Electronics Co., Ltd. 5
BASIC FUNCTIONS 21
Making Calls.....................................................21
Making Internal Calls...................................................... 21
Making External Calls..................................................... 22
Making Calls Via Speakerphone..................................... 23
Making External Calls Again........................................... 24
Redialing C.O. Line Number........................................... 24
Saving C.O. Line Number .............................................. 25
Redialing C.O. Line Number Saved ............................... 25
Dialing Recent Number ..................................................26
Answering Calls................................................27
Using Handset................................................................ 27
Using Speakerphone...................................................... 28
Page Pickup ................................................................... 29
Usable Functions While Calling..........................30
Call Hold......................................................................... 30
Call Waiting .................................................................... 31
Mute ............................................................................... 32
Call Transfer................................................................... 33
NAVIGATION MENU 34
Navigation Button.............................................34
Navigation Menu ..............................................35
TROUBLESHOOTING 39
ANNEX 41
Specification....................................................41
6 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
Main Functions
IP Network
ITP-5112L telephone uses the already established data network
for voice communication with no additional telephone line, which
results into no additional expenses and reduction of telephone
charges for companies or individuals with much usage of
international telephone service.
Large LCD Screen
ITP-5112L telephone displays many functions on the LCD
screen for user’s convenience so that a user can use the
functions by means of the direction button and [Enter] button of
Navigation.
BBEEFFOORREE UUSSEE
Navigation Button
Speed Button
You can display many functions of ITP-5112L telephone
(Phonebook, E-diary, Message, Sound/Screen, Conference,
Call forward, My phone, Setting) on the LCD screen through
icons or menus and use the functions conveniently by operating
the navigation.
After setting the functions or telephone numbers with frequent
use to the Add On Module(AOM) button, you can use the
functions or dial the numbers only by pressing the speed button.
© SAMSUNG Electronics Co., Ltd. 7
Call Pick-Up
Auto-Redial
Call Hold
You can pick up a call to other telephone into yours.
You can use the functions of auto-redial, call waiting, and call
queuing right after a call is completed if you want to use the
functions during a call.
If an urgent matter arises or an urgent call arrives while you are
on the line, you can put the caller on hold and resume the call
after a while.
Conference Calls
You can make a conference call by pressing the [Conference]
button. Up to five people can make a conversation.
Call Forwarding
You can forward an incoming call to another station when you
cannot answer the call.
Do Not Disturb (DND)
You can set DND if you don’t want to answer the telephone.
Then, bell does not ring even when a call is connected.
8 © SAMSUNG Electronics Co., Ltd.
Paging
You can use this function when you deliver an urgent message.
The function enables you to announce your message via the
speakers of other telephones or external speakers without
notifying one by one.
Executive/Secretary
When the Executive/Secretary button is pressed once, the
executive and his/her secretary can be connected.
The secretary can use this Executive/Secretary feature to receive
an incoming call and then simply forward it to the executive.
Call ID
When there is an incoming call, the caller ID or name will be
displayed on the LCD screen. You can see who is calling before
answering the call and respond accordingly.
ITP-5112L IP Telephone User Guide
© SAMSUNG Electronics Co., Ltd. 9
Checking Parts in the Package
Handset Support
Handset
ITP-5112L
Power Adapter(Optional)
UTP(LAN) Cable
Quick Reference Guide
If any item is missing or damaged, please contact your dealer.
10 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
Names and Functions of Each Part
Front View of Telephone
Speaker
Dial Button
Speaker Button
Hold Button
Microphone
Navigation Button
Select Buttons(6EA)
LCD Screen
Status Light
Select Buttons(6EA)
Screen Button
Volume Button
Scroll Key
Conference Button
Transfer Button
© SAMSUNG Electronics Co., Ltd. 11
Functions of Each Part
Button Functions
Select Buttons This button is used to select a desired function from the
,
LCD Screen LCD screen is composed of
Status Light The red LED displays the telephone status such as busy,
menus displayed on the LCD screen.
the status and main screens.
- The setup status of the
telephone function is
displayed on the upper part
of the LCD screen as icons.
- The LCD main screen, except the status screen, displays
the menus, call process status, or various messages.
ringing and receiving internal message.
Screen Button This button is used to select the screens of AOM, Soft
Volume Button This button is used to adjust the volume of handset,
Scroll Key This button performs the same function as [ ][ ] of
Conference Button This button is used to make a conference call.
Transfer Button This button is used when transferring a busy call, or
Navigation Button This button is used to operate Phonebook, E-diary,
Microphone You can speak via the microphone when making a
Hold Button This button is used to hold a call.
Speaker Button
Dial Button This button is used to enter numbers and characters.
Speaker You can hear caller’s voice or various incoming rings via
menu, or background.
speaker, or key tone.
Navigation when selecting functions. You can see the
menus or contents of the next page that is not displayed
on the current screen by scrolling the key up and down
setting functions in the button on the AOM screen.
Message, Sound/Screen, or Conference function.
conversation with speakerphone.
This button is used to call via the speakerphone, not use
the headset.
the speaker.
12 © SAMSUNG Electronics Co., Ltd.
Installing the phone
Connecting the Phone
Connect the headset to the headset connection port of the phone.
1
Connect a side of the LAN cable for linking PC provided with the phone to PC
2
connection port of the phone, and the other to the network port of the PC.
Connect the LAN cable linked to the network to the LAN connection port of
3
the phone.
ITP-5112L IP Telephone User Guide
Connect the power adapter provided with the phone to the power
4
connection port. Connect the plug of the power adapter to the outlet.
Then, the phone boots.
Connect a tape recorder to the recorder connection port on the bottom of the
5
phone if you want to connect the recorder to the phone.
5
Network
2 3
4
1
© SAMSUNG Electronics Co., Ltd. 13
Installing the Support
Align the support with both grooves on the bottom of the phone and push the support
upward as shown in the figure below:
Check if the phone is fixed completely on the flat floor.
14 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
TTHHIINNGGSS YYOOUU SSHHOOUULLDD KKNNOOW
W
Adjusting Volume
This function adjusts the volume of the handset, speaker and bell sound by pressing the
[TVolumeS] button.
Adjusting the Handset Volume
This function is used to adjust the handset volume.
Perform the following steps while holding the
1
handset in busy state.
Press the [VolumeS] button to increase the
2
handset volume.
Press the [TVolume] button to decrease the
3
handset volume.
© SAMSUNG Electronics Co., Ltd. 15
Adjusting the Speaker Volume
This function is used to adjust the speaker volume.
Perform the following steps while making a
1
conversation via the speaker.
Press the [VolumeS] button to increase the
2
speaker volume.
Press the [TVolume] button to decrease the
3
speaker volume.
Adjusting the Bell Sound Volume
This function is used to adjust the bell sound volume.
Press the [VolumeS] button to increase the bell
1
sound volume while ringing.
Press the [TVolume] button to decrease the bell
2
sound volume while ringing.
16 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
Entering Characters
You can use the dial button and the navigation button to enter or edit English letters,
numbers, or special characters.
Press the [Menu] button when the Memo screen appears. Repeat pressing
1
the [Menu] button until the cursor moves to the target input mode.
Memo Screen
Input Mode
: Capital Letter
: Small Letter
: Number
: Special Character
2
Enter English letters or numbers by pressing the Dial button, and enter
special characters by using the direction button of the navigation button.
- Entering English letters: Default is English input mode. Enter or edit an English
letter by pressing the dial button.
- Entering numbers or special characters: Select number of special character
input mode by pressing the [Menu] button. Enter or edit a number or special
character by pressing the dial button.
Navigation Button
Dial Button
© SAMSUNG Electronics Co., Ltd. 17
Using AOM/Soft Menu Screen
You can use various functions of a phone conveniently on the Add On Module(AOM)
screen or Soft menu screen.
In standby mode or during a call, if the [Screen] button is pressed once, the AOM screen
appears. If the [Screen] button is pressed twice, the Soft menu appears. Each screen
displayed is as follows:
AOM Screen
The AOM screen appears during a call or when pressing the [Screen] button once in
standby mode. On each screen, various functions set in a phone appear. Use the
direction button of navigation or the scroll key to select the target function and press
the [Enter] button on the AOM screen displayed during a call. Then, the function can
be performed.
Or, press the [Select] button of the target menu on the AOM screen displayed in
standby mode.
The AOM screen displayed when
pressing [Screen] button during a call
The AOM screen displayed when
pressing [Screen] button in standby mode
[Select] Buttons
- Standby mode indicates the case that the handset is not lifted.
- The menus not displayed on the screen can appear by using the scroll key.
18 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
Soft Menu Screen
Soft menu screen appears during a call or when pressing the [Screen] button twice
in standby mode. Various functions of a phone are displayed as menus.
Use the direction button of Navigation or the scroll key to select the target function
and press the [Enter] button. Then, the function can be performed.(The [Select]
button cannot be used.)
Soft menu screen
displayed during a call
Soft menu screen displayed when
pressing [Screen] button in standby mode
© SAMSUNG Electronics Co., Ltd. 19
Phone Status LED
Phone status light is turned on or off according to the phone status.
Status Status LED
Line is busy. Red light continuously turns on.
Internal call is ringing.
External call is ringing.
Re-incoming call is ringing.
Message is left
Red light blinks.
LED
There are LEDs on the [Hold] and [Speaker] buttons. The LEDs are turned on or off
according to the phone status.
Button LED LED Status Function
Red LED is turned on. A call is on hold.
Red LED is turned on. Speaker phone is activated.
Back Ground Music(BGM)
is set.
20 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
BBAASSIICC FFUUNNCCTTIIOONNSS
Making Calls
This function is used to make internal or external calls.
Phone is set to enblock mode that a caller should press the target number buttons
and press the [Send] button by default. If a caller changes the mode to overlap
mode, a caller can make a call just by pressing the target number buttons. This
guide describes how to use a phone in enblock mode.
Making Internal Calls
This function is used to make an internal call.
Lift the handset and check if a calling tone is
1
heard. Press the number of the recipient’s
station.
- Or, press the [Speaker] button to check if a calling
tone is heard.
Press the [Send] button. Then, a ring back tone
2
is heard.
Start conversation when the recipient answers.
3
- Internal call is a call connected to a user who use another internal phone
connected to the system in an office.
- External call is a call directly connected to the switching system of a phone
company. The call is made from an office to another area(e.g., house) or from
another area to an office.
© SAMSUNG Electronics Co., Ltd. 21
Making External Calls
This function is used to make an external call.
Lift the handset and check if a calling tone is
1
heard.
- Or, press the [Speaker] button to check if a calling
tone is heard.
Press the [9] button, a C.O. line group number,
2
and press the target number.
Press the [Send] button. Then, a ring back tone
3
is heard.
Start conversation when the recipient answers.
4
22 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
Making Calls Via Speakerphone
This function is used to make a call via a speakerphone without using a handset.
Press the [Speaker] button without lifting the
1
handset.
Press the target phone number and
2
the [Send] button.
Start conversation when the recipient answers.
3
- If the handset is lifted during a call, the speaker is
turned off and you can continuously make a
conversation via the handset.
After finishing the conversation, press the
4
[Speaker] button again.
© SAMSUNG Electronics Co., Ltd. 23
Making External Calls Again
This function is used to use a C.O. line previously used without disconnecting a C.O.
line after the C.O. line is being connected.
After finishing an external call, use the
1
navigation button or the scroll key to select
[NEW CALL] item and press the [Enter]
button.
After checking if an external calling tone is
2
heard, press the target number.
(At this time, pressing the [9] button is not
required.)
Redialing C.O. Line Number
This function is used to dial a recently dialed number without pressing the target
number when making an external call.
Press the [Screen] button twice in standby
1
mode to enter into Soft menu.
Select [LAST REDIAL] item from the Soft menu
2
and press the [Enter] button.
- Or, press the [1] ► [9] buttons, function codes of
redial, in standby mode and press the [Send] button.
(Do not press the [Send] button in overlap mode.)
24 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
Saving C.O. Line Number
When you make an external call, the recipient may be busy or may not answer to the
call. At the time, this function is used to make a call immediately without pressing the
target number by saving the number of the recipient.
Select [SAVE/REPEAT] item and press
1
the [Enter] button before disconnecting a call.
When the ‘number saved’ message appears,
2
replace the handset.
Redialing C.O. Line Number Saved
This function is used to dial a C.O. line number saved.
Press the [Screen] button twice in standby
1
mode to enter into the Soft menu.
Select [SAVE/REPEAT] item from the Soft
2
menu and press the [Enter] button.
- Or, press the [1] ► [7] buttons, function codes of
[Dial Saved Number], in standby mode and press
the [Send] button.(Do not press the [Send] button in
normal phone mode.)
© SAMSUNG Electronics Co., Ltd. 25
Dialing Recent Number
This function is used to dial a recently dialed internal/C.O. line number.
Press and hold the [Send] button in standby
1
mode. Then, the number recently dialed is
connected immediately.
- When pressing the [Send] button shortly, the list of
numbers recently dialed appears.
Move to the target number in the list and press the
[Send] button.
Make a conversation via the speakerphone.
2
- If the handset is lifted during a call, the speaker is
turned off and you can continuously make a
conversation via the handset.
26 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
Answering Calls
This section describes how to answer an internal call or external call.
Using Handset
Calls can be answered using the handset.
Lift the handset if a bell rings.
1
Answer the call.
2
Replace the handset to end the call.
3
© SAMSUNG Electronics Co., Ltd. 27
Using Speakerphone
Calls can be answered using the speakerphone without lifting the handset.
Press the [Speaker] button if a bell rings.
1
Answer the call.
2
- You can lift the handset to continue the call using the
handset while speaking through the speakerphone.
Press the [Speaker] button again to
3
end the call.
If the notification message only appears on the screen without the bell ringing,
lift the handset to answer the call.
28 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
Page Pickup
This function allows you to pick up an incoming call to another station in the same
group.
Another station rings in the same group.
1
Select the [PAGE PICKUP] item from the soft
2
menu and press the [Enter] button.
- Or press [6] ► [5], which are the function code of
the Pick Up function, and press the [Send] button.
(You do not need to press the [Send] button in
the overlap mode.)
The ‘enter station or line #’ message appears.
3
Press the ringing station number.
4
If the call is connected, answer the call.
To pick up an incoming call to another station, the station should be designated in
the same group. For group designation, contact the system administrator.
© SAMSUNG Electronics Co., Ltd. 29
Usable Functions While Calling
This section describes the usable functions during an internal call or external call.
Call Hold
If an urgent matter arises or an urgent call arrives while you are on the line, you can
put the caller on hold and resume the call after a while.
Press the [HOLD] button during a call to put the
1
call on hold and replace the handset.
The ‘On ex-hold’ message appears with its
2
background screen.
Press the [Screen] button to resume the call.
3
If the AOM screen appears, press the [Select]
button, which is blinking in the screen.
- If clicking the [Hold] button once, the call on hold can be resumed by the station
that have held the call or another station.
- If double-clicking the [Hold] button, the call on hold can be only resumed by the
station that have held the call.
30 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
Call Waiting
When making a call to a station, if the recipient is busy, you can use this function to
have a conversation urgently.
When making a call, if the recipient is busy,
1
select the [CALL ON] item on the screen and
press the [Enter] button.
The ‘a call back is set to 0000’ message
2
appears.
The recipient’s phone rings right after the
3
previous call ends. If the recipient lifts the
handset, the call is made.
© SAMSUNG Electronics Co., Ltd. 31
Mute
This function allows you to hear the recipient during an internal call while the recipient
cannot hear you.
Select the [MUTE] item during a call and press
1
the [Enter] button.
Then the recipient cannot hear you.
Select the [mute(Off)] menu to cancel the mute
2
and the [Enter] button.
Then the mute is cancelled.
32 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
Call Transfer
This function allows you to transfer a connected call to another station or a C.O. line.
Press the [Transfer] button to transfer the call.
1
After hearing a transfer calling tone, press the
2
internal number or external number.
- For an external number, press the number after the
C.O. line group number such as [9]. For an internal
number, press only the internal number.
If a ring tone is heard, replace the handset.
3
- Or replace the handset after waiting until the call is
answered and having a conversation.
When transferring a call, the following situations may occur:
- When the recipient to whom the call is transferred is busy or does not answer
Press the [Transfer] button again to return the call to the original caller.
- In the case there is no answer when transferring an external call to a station
The call returns to the recipient who has transferred the call.
- When the recipient to whom the call is transferred is busy
Return the call to the original caller or wait until the recipient to whom the call is
transferred ends the previous call by transferring to the call-waiting mode.
© SAMSUNG Electronics Co., Ltd. 33
NNAAVVIIGGAATTIIOONN M
MEENNUU
Navigation Button
This section describes the navigation buttons of ITP-5112L that allows you to use its
functions conveniently.
Button Function
Menu Press the [Menu] button in the standby state or during a call. Then, the
main menu appears.(For the description of the menu window, refer to the
next page.)
Send - Used when checking the recent calling/called numbers or when making
calls to the numbers directly.
- Press the [Send] button long in the standby state to make a call to the
most recent number.
- Press the [Send] button short in the standby state to use the [Recent
Calling Number Search] function.
Enter - Used when selecting/saving an item where the cursor indicates in the
menu mode.
- Used when verifying a caller information from a C.O. line.
Direction Used when editing letters/numbers or moving menu items.
Cancel - Used when moving to the previous stage from the menu mode.
- Used when ending the menu mode.
- Used when deleting entered letters/numbers.
End - Used when ending calls.
- Used when ending the menu mode.
This phone is basically set in the enblock mode. In this mode, you should
press the [Send] button after telephone number to make a call. If changing into
the overlap mode, you can make a call only by pressing a telephone number.
34 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
Navigation Menu
Press the [Menu] button of the navigation buttons to display the main menu on the LCD
screen when the phone is in a standby state. Select a desired menu using the direction
button, and press the [Enter] button.
Button Submenu Function
Phonebook
1. Search Searches phone numbers using the
speed dials registered in the phone.
2. View Outgoing Call Log
3. View Incoming Call Log
4. Missed Call
5. New Number Saves phone numbers.
6. Edit Group Adds/Modifies/Deletes group names.
7. Delete All Deletes all registered phone numbers.
8. My Own Number
Retrieves recent outgoing call numbers
or makes calls to the numbers.
Retrieves recent incoming call
numbers or make calls to the numbers.
Retrieves call numbers received while
absent or make calls to the numbers
directly.
You can register four numbers per
person(home, mobile phone, office and
another number) and also register fax
numbers, e-mails, groups, and memo.
Shows its own phone number.
© SAMSUNG Electronics Co., Ltd. 35
Button Submenu Function
E-Diary
Message
1. Wakeup Call Sets a wake-up call time and the interval.
2. Alarm Sets an alarm time and the interval.
3. Daily Planner Registers the date and hour of an important
schedule and sets as an alarm rings at the
designated time for a minute.
4. Memo Pad Saves brief memos in the phone.
5. Calculator Performs the four arithmetical rules(+, -, *, /)
using the calculator built in the phone.
6. World Time Shows the local times in 39 cities across the
world.
7. D-Day Plus Registers an important schedule and shows
the left time or the past time.
8. Unit Convert Converts a unit such as length, weight,
extent, temperature, and volume into another
unit.
1. Message Send Writes new messages or import sentences.
2. Received Box Shows text messages received or sets the
message receipt status.
3. Sent Box Manages sent message.
4. Message Box Imports various messages stored in the
Sound/Screen
1. Bell Select Sets the bell sound of the phone.
2. KeyTone Select Sets the sound coming out when pressing
3. Volume Controls the volume of the
4. Select Background Sets the background screen of the LCD
5. Menu Style Sets the screen of the navigation menu.
6. Background Style Sets the background color of the LCD
36 © SAMSUNG Electronics Co., Ltd.
message box.
the telephone button.
bell/handset/speaker/key/background
music/broadcast tone.
screen.
screen.
ITP-5112L IP Telephone User Guide
Button Submenu Function
7. Select Brightness Sets the brightness of the LCD screen. Sound/Screen
8. Screen Saver Sets the screen wait time
(10/30/60 minutes/user define).
Conference - Up to 5 persons(caller included) can have
a conference and speak simultaneously in
the conference.
Call Forward - Forwards an incoming call to another
station when the user is absent.(Disable,
Always, Busy, No Answer, Busy/No
answer, DND)
My Phone
Setting
1. My Name Enters the user’s name to the phone. The
name registered here is displayed on the
LCD screen of the opponent’s phone
when making an internal call.
2. 언어/Language Sets a language between Korean and
English.
3. Change Password Changes the four-digit password in order
to protect the user’s privacy when setting
various functions of the phone.
4. Locked Sets the lock status of the phone in order
that other person may not use the phone.
5. Private Life
Protection
Limits the use of telephone by other
person.
6. Phone Version Confirms the software version of the
telephone.
7. Reset to Default Removes the data(phone number,
message) set by user and set into the
initial status.
1. Answering Mode Sets the answer mode.(Ring, Auto
Answer Mode, Voice Announce)
2. Absent Msg. Sets the message to be displayed on the
LCD screen when user is absent.
3. Internal Call Sets the mode displaying the AOM button.
© SAMSUNG Electronics Co., Ltd. 37
Button Submenu Function
Setting
4. AOM Page Setup Sets the displaying the number of AOM
pages.
5. Dial Mode Sets the dial mode when making a call.
The basic status is set as the enblock
mode that can make a call by pressing the
[Send] button after dialing. If you change
the basic mode into overlap mode, you can
make a call only by dialing.
6. Station ON/OFF Sets various additional functions.
7. Out-Code Setup Sets in order to display ‘-’ between the
phones numbers when dialing in the
enblock mode.
8. Network Info Shows the network information set in the
phone.
38 © SAMSUNG Electronics Co., Ltd.
ITP-5112L IP Telephone User Guide
This section describes the problems that may occur while the phone is used and the
troubleshooting of the problems. Check the following cases before contacting a service
center.
Please, contact the service center for troubles not solved with the following solutions.
The phone is connected,
but the phone is not
booted.
The phone is booted,
but the phone does not
work.
TTRROOUUBBLLEESSHHOOOOTTIINNGG
- Check if the cables are properly connected to
the phone.
- Check if a power adapter suitable for the
▶
phone(included in the package) is connected.
- Pull out the plug of the phone’s power adapter
and plug in again after 10 seconds.
- When more than one device(phone or PC) has
the same IP address, ‘IP conflict’ is displayed
on the screen of the phone. Contact the
system operator.
▶
- When more than one phone has the same ID,
‘IP conflict’ is, also, displayed on the screen of
the phone. Contact the system operator.
When you pick up the
handset or press the
[Speaker] button, you
cannot hear the dial
tone.
Nothing is displayed on
the LCD screen while
the phone is used.
- Check if the power adapter and various cables
are properly connected to the phone.
- Check if the network environment such as IP
address of the phone is properly
configured.(See ‘navigation menu’ Æ ‘setting’
Æ ‘8. network info’.)
▶
- With the ‘ping’ command in the computer
connected to the phone, check if the IP
address of the phone is available. If the
address is duplicated, contact the system
operator to get a new, available IP address for
the phone.
Check if the phone line is properly connected to
the phone line connection port of the phone.
▶
(See the ‘Installing the Phone’ of ‘BEFORE
USE’ in this Guide).
© SAMSUNG Electronics Co., Ltd. 39
A bell is not ringing, or
the bell sound is low.
The call status is bad
because of noise and
interference while
calling.
There is too much
howling in the
announcement.
Caller ID is not
displayed on the LCD
screen.
Press the [TVolumeS] button to turn the bell
volume up.
▶
(See ‘Adjusting Volume’ of contained of
‘THINGS YOU SHOULD KNOW’ in this
document.
Use the handset for the call if you were using
the speakerphone.
▶
The speaker may echo if the internal phones
are too closed each other. Please keep the
▶
distance between the phones at the interval of
one meter.
- Check if the (Calling Line Identification
Presentation)CLIP service is requested to the
telephone company.
- Caller requested the telephone company not
to disclose his/her ID.
- Call was made from an area where the CLIP
service is not provided(e.g., international
▶
calls).
- Call was made from a public phone.
- Information provided by the telephone
company is damaged.
- The telephone company does not service
CLIP.
Alarm is not ringing at
the setting time.
40 © SAMSUNG Electronics Co., Ltd.
Check if the current time is properly set at the
▶
phone. Contact the system operator if the time
setup should be changed.
ITP-5112L IP Telephone User Guide
AANNNNEEXX
Specification
The specification of ITP-5112L is as follows:
Item Description
Model Name ITP-5112L
Weight(kg) 1.1
Size(mm) 266(Width) × 206(Depth) × 122(Height)
Adapter Input Power AC 220 V/60 Hz; 0.5 A
Adapter Output Power DC 5 V; 3 A
POE Input Power DC 36-57 V(Standard 48 V); 400 mA
Temperature(˚C) 0~45
Humidity(%) 10~90
No. of [Select] Buttons 12
Navigation Buttons 0
Conversation through
Speaker Phone
LCD Color Graphic LCD(320 × 240 px)
B Class Device (Home IT Equipment)
▣ This product is made for home and is a device that has passed Electromagnetic
Compatibility. This product can be used anywhere including residential area.
▣ This product is a B class device that has passed electromagnetic interference.
Available
© SAMSUNG Electronics Co., Ltd. 41
ITP-5112L IP Telephone User Guide
Loading...
