Odys UNO X8 User guide

Safety Precautions

Do not subject the device to severe impact or drop
it from heights.
Do not use the device in extreme hot or cold, dusty
or damp conditions. Do not expose it to direct sunlight.
Avoid using the device near strong magnetic fields. Keep the device away from water and other liquids.
In the event that water or other liquids enter the device, power off the product immediately and clean the device.
Do not use chemicals to clean the device in order
to avoid corrosion. Clean it with a dry cloth.
We are not responsible for damage or lost data
caused by malfunction, misuse, modification of the device or battery replacement.
Do not attempt to disassemble, repair or modify the
product. This will invalidate the warranty.
If the device will not be used for an extended period
of time, please charge the battery at least once per month to maintain battery life.
Charge the battery if:
a) The battery level icon displays (An empty battery) b) The device powers off automatically when restarted. c) There is no response when pressing keys with keys unlocked and battery full.
When the device is being formatted or transferring
a file, do not interrupt the connection. Otherwise, data may be corrupted of lost.
When the device is used as a portable HD, please
use only per the instructions. Otherwise, permanent data loss could occur.
Please use and install data using the
attachments/accessories provided and only according to the manufacturer’s instruction.
EN
1
Please refer to the information on the bottom of the
device for electrical and safety information before installing data or operating the device.
EN
To reduce the risk of fire or electric shock, do not
expose this device to rain or moisture. The device should not be exposed to dripping or splashing. Never place objects filled with liquids, such as vases, on the device.
There is danger of explosion if the battery is
replaced incorrectly. Replace only with the same or equivalent type.
The battery (battery or batteries or battery pack)
should not be exposed to excessive heat such as sunlight, fire or the like .
Please follow responsible procedures for battery
disposal.
If the power adaptor is disconnected from the
device, the device will remain operable as long as the battery has sufficient charge.
The power adaptor is a CLASS II apparatus with
double insulation, and no external ground is provided.
Safety symbol explana ti on:
- The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
- To reduce the risk of electric shock, do not remove the cover (or back) as there are no user-serviceable parts inside. Refer servici ng to qualified personnel.
- The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the device.
Do not leave the device on in a confined space
such as a book case or similar. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, cur tains, etc.
No open flames, such as lighted candles, should be
placed on the device.
Use the device in moderate climates. Never disconnect the USB cable from your e-book
reader to the PC during a data transfer or formatting. Correctly disconnect the device from the operating system. Information loss and malfunctions can occur.
EN
3
EN
Note
before first use.
Disposal
recycling.
Note
customer service at www.odys.de.
Please only charge the battery while the device is turned off. The charging time will be shorter and the lifetime of the battery will be enlarged. Please fully charge the battery
Please note that the internal battery can only be replaced by qualified personnel. If necessary please contact to the ODYS
Correct Disposal of this product. This marking indicates that this product should not be disposed of with other household waste in the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To dispose of your used device, please use the return and collection systems available in your area or contact the retailer where the product was purcha s ed. They can take this product for safe environmental

Conformity

We, Axdia International GmbH, hereby declare that this Android Tablet corresponds to the basic requirements and relevant regulations outlined in guideline 1999/5/EG.
The CE declaration of conformity for this product may be found on the following link:
www.odys.de – Service – Downloads
(http://www.odys.de/web/downloads_de.html) This device uses a non harmonized frequency and is
suitable for operation in the following European countries: Germany, Belgium, Netherlands, Luxembourg, Austria, Switzerland, France, Spain, Portugal, Italy, Greece, Norway, Sweden, Finland, Denmark, Liechtenstein
Within the European Union, operation of the WLAN/Bluetooth function in buildings is not restricted. Operation outside of buildings is restricted.
EN
V2.3
5
Hearing Safety
Listen at a moderate volume: Using headphones at a high volume can impair your
ring. This product can produce sounds in decibel ranges that may cause hearing loss for a normal person, even for exposure less than a minute. The higher decibel ranges are offered for those that may have already
deceiving. Over time your hearing ‘comfort level’ adapts to higher volumes of sound. So after prolonged listening, what sounds ‘normal’ can actually be loud and harmful to your hearing. To guard against this, set your volume
aring adapts and leave it there. To establish a safe volume level: Set your volume control at a low setting. Slowly increase the sound until you can hear it comfortably and clearly, without distortion. Listen for reasonable periods of time:
ure to sound, even at normally ‘safe’ levels, can also cause hearing loss. Be sure to use your equipment reasonably and take appropriate breaks. Be sure to observe the following guidelines when using your headphones. Listen at reasonable volumes for
able periods of time. Be careful not to

Listening Cautions

EN
hea
experienced some hearing loss. Sound can be
to a safe level before your he
prolonged expos
reason adjust the volume as your hearing adapts. …
… Do not turn up the volume so high that you can’t hear what’s around you. You should use caution or temporarily discontinue use in
not use headphones while operating a motorized vehicle, cycling, skateboarding, etc.; it may create a traffic hazard and is illegal in many areas.
potentially hazardous situations. Do
7
EN

Support

http://www.odys.de support@odys.de
EN
On our website you will find the latest information about this product, other products of our enterprise, our company itself and valid warranty terms. The latter you will find under Service - Downloads. Firmware upgrades for this device are also offered on our website. For questions or problems read our FAQs on our website or contact our after sales service.

Appropriate use

Device is designed for playing music and video files in commonly used formats, showing photos and access internet functions using the build in Wi-Fi function. It is exclusively meant for this purpose and must only be used for the same.
This also includes paying attention to all information contained in this operating manual, especially in the safet y instructions. Any other usage is considered to be improper and may lead to material damages and even personal injuries. Moreover, it will result in the immediate loss of guarantee. The manufacturer does not bear any liability for damages caused due to improper use.
This manual may not reflect your actual device’s operation. All information is subject to change without prior notification. Please follow your actual device’s operational procedures.
Table of Content
Safety Precautions ...................................................... 1
Conformity ................................................................... 5
Listening Cautions ....................................................... 6
Support ....................................................................... 8
Appropriate use ........................................................... 8
Firmware updates (OTA update) ............................... 10
Feature Summary ..................................................... 11
Accessories ............................................................... 11
Buttons & Ports ......................................................... 12
Charging Battery ....................................................... 14
Installing Memory Card ............................................. 15
HDMI Output ............................................................. 16
Connect via USB ....................................................... 17
Transferring Files ...................................................... 19
Turning On/Off ........................................................... 20
Screen Lock .............................................................. 20
Home Screen ............................................................ 21
Using the Touch Screen ............................................ 26
Bluetooth Connection ................................................ 28
Access Internet - Wifi ................................................ 30
Internet Access - UMTS ............................................ 36
Virtual Keyboard ........................................................ 42
Using the Web Browser ............................................. 44
Sending/Receiving E-Mails ....................................... 47
Reading E-Books ...................................................... 53
Playing Music ............................................................ 64
Video / Photo Playback ............................................. 68
Kamera bedienen .. Fehler! Textmarke nicht definiert.
ES File Explorer ........................................................ 77
Manage Third-part y Applicati ons ............................... 84
System Settings ........................................................ 86
Troubleshooting......................................................... 90
Specifications ............................................................ 96
Warranty Conditions .................................................. 99
9
EN
Note
ODYS is not responsible for any lost data.
Please connect the power supply while charging.

Firmware updates (OTA update)

EN
system. The ODYS Update App is preinstalled at your ODYS Device Gerät vorinstalliert. Select, if you you would lik e to update manually of if the system update should be done automatically.
Please note that updates improve the capability oft that device. Therefore updates are highly recommended.
Settings und saved Data will not be influe nced b y a succ es sf ul update. However it is highly recommended to save your data before making an update.
Take care to save your data regularly in a suitable way at another device.
ODYS would like to offer a easy and most comfortable way to keep the operating system of your device up-to-date. Using this specially for ODYS Tablet PCs designed App, which you can download from the Google P lay Store; you can easil y update the

Feature Summary

Wi-Fi Connectivity
With the latest Wi-Fi technology, this device can connect you to the Internet wherever you are.
8” Touch Screen
Touch or slide your finger on the screen, the screen responds instantly.
EN
Third-party Application Support
With the built-in Android
TM
OS, you can install a large
number of third-party applications in this device.
Please note that you need to insert an SD-Card for it.
Built-in G-sensor
The screen changes to landscape or portrait automatically when the device rotates.
Entertainment
You can enjoy music, movies, pictures and e-books with the Mobile Tablet.

Accessories

USB Cable Power Adaptor Quick start
11
1. Volume + /- key
Shortly press to increase / decrease the volume level.
2. Back Key
Tap to return to the previous screen, tap to close the keyboard.
3. Front Camera
Front-facing camera for taking
4. Power Button
Press and hold the power switch
screen on or off.
5. Headphone
Audio output connecti o n for
headphones are connected to the
12

Buttons & Ports

EN
screen. If the keyboard is on the
avatar pictures
to turn on or off the device; Briefly press the switch to turn the
jack
head-phones
Note: Speaker output is automatically disa bled wh en
player.
6. Micro Hi-speed
Connect to a computer to transfer files).
7. Mini HDMI
8. Power jack
Charge and power the tablet with the included power adapter.
9. Reset
abnormal.
10. Micro SD Card Slot
Accommodates any standard Micro SD/SDHC memory card.
USB 2.0
data (e.g., music, videos, photos,
Reset and restart the devise if it freezes or otherwise behaves
Hint:
Simultaneously press the On/Off key and the Vol-Key together for 2 seconds to take a screenshot of the current view.
EN
13

Charging Batter y

The device has a built-in rechargeable battery. No extra battery installation is required. Just charge the
EN
device when it indicates low battery. To c harge the battery, connect the device to any standard wall outlet via the DC using the power adaptor. It takes about 5 hours to fully charge the battery.
Note:
a. We advice to use only the delivered power adapter
with this tablet.
b. You can operate the device even when it is being
charged. But for extended battery life, it is suggested NOT to use the device when it is charging.
c. It is recommended to charge the battery before you
use the device for the first time.
d. For maximum performance, lithium-ion batteries
need to be used often. If you don’t use the device often, be sure to recharge the battery at least once per month.
e. Should the rechargeable battery of the device
discharge completely, connect the device (using the adapter) to the main power source for approximately 5-10 minutes before attempting normal operation.
f. In some cases, devices which have been charged
for longer periods of time may not be able to be switched back on. Should this occ ur, press the RESET switch.

Installing Memory Card

This device can read files directly from memory card. To use a memory card, find the card slot at the back of the device and then insert the memory card into the slot in the correct orientation. T o access the files stored in the memory card, enter the ES File Explorer mode by tapping the Explorer icon and select the “external_SD” directory.
Check that the Micro SD card is in the correct position with the contact pin facing downwards a nd to the front as illustrated. You may damage the card and the reader if Micro SD card is not inserted in correct position.
Push the card into the card slot until it clicks.
To remove SD card, push the Micro SD card once
again until it clicks.
Note: We recommend using only Micro SD or SDHC cards up to 32GB capacity.
When a Micro SD card is inserted in or ejected from the device, it may take few seconds for the device to update the content.
Please avoid inserting or ejecting Micro SD card when other operation is running as this may cause the system hang.
Do not remove the card if the content inside the card is being played. This will halt the operation of the device and might cause a system hang.
EN
15

HDMI Output

EN
- Connect the device using an appropriate cable
to your TV.
- The display changes from the device to the screen.
- The touch screen remains black, but can be used for the operations. For this reason, we recommend a USB mouse (not included) for the operations
Note:
Only use connecting cable with a maximum length of 25cm.
Please note that video and au dio are only output via HDMI for video playback. Simultaneous audio output via HDMI and the internal speakers and/or earphones jack is not possible.
If HDMI is connected, then videos are only displayed on the TV set. Controls can be displayed as usual by tapping on the tablet.
HDMI output is only intended when using the device in landscape mode.
Note: The device is equipped with a mini HDMI connector. You need an HDMI cable with a mini HDMI connector on one end and a standar d HDM I c onn ec tor on the other end (not supplied).

Connect via USB

Connect a USB Cable
Please note: Only use connecting cable with a maximum length of 80cm. Please make sure when connecting the USB adapter or connector cables attention to the correct alignment of the connector before inserting it into the USB socket on the unit. Incorrect insertion may cause damage to plug and socket.
On the side of the plug there are usually small sizes of hooks that secure the fix ati on. Pay special attention on the position of the hooks, they show upward when connecting cables while the screen is above.
EN
17
Establish a USB connection
The dialog to activate the USB connection will be prompted after connecting a USB Cable.
EN
Tap at „Turn on USB storage“ and confirm the security note if necessary.
Note:
While connected to USB, the USB Symbol is shown at the top left corner of the screen. Please drag down the status bar if the above dialog window does not appear and tap at the below notice to open it manually:

Transferring File s

Before reading or playing files, you need to transfer media files from a computer to the device. (1) Connect the device to a computer with the
supplied USB cable.
(2) Once connected, two removable disk drives will
show on your computer. One represents the internal memory of the device, and the other represents the memory card inserted into the device. Now you can copy files from or to these disk drives just as you would on your hard drive.
(3) Choose “Turn off USB Storage” and then tap
“Turn Off” to disconnect the device from computer.
(4) Disconnect the device from the PC safely.
a) Left-click the or icon at the right bottom
corner of the computer desktop.
b) Click the pop-up mini-window message of “Stop
the USB Mass Storage Device – Drive (X).”
c) Disconnect the device from the computer.
Note: The pre-installed applications and Android OS occupy a considerable part of capacity – nearly more than 1GB, it is normal that you see huge difference between available memory space and total capacity.
EN
19

Turning On/Off

To turn on the device, press and hold the Power
button on the unit until you see the boot-up screen
EN
then release. It may take a few minutes to start up the system, please wait before you proceed. To turn off the device, press and hold the Power button until you see the option “Power Off”, tap on “Power Off” and then tap on “OK”.
Tip: This device will sleep with the screen off if it stays inactive for a few seconds. You can briefly press the Power button to turn on the screen and wake it up.

Screen Lock

The screen automatically turns off and locks itself after a set period of time. When the s creen t urned off, pr ess the Power button to light up the screen.
Push the lock icon and drag it to the surrounding edge to unlock.
a.
system status information’s
b. System
System information’s like wifi and
shortcuts.
c. Google
Search Bar
d. Google Voice
Search
e. eManual
Manual in ebook format
f. Browser
Tap to launch the Browser to visit your favorite websites.
f g h i j k l
c d
e
m n o p

Home Screen

a b
System Hints Informs the user if attached memory
or updates are available and other
EN
settings
battery status and the current time will be shown here. Drag down the bar to open additional setting s
21
g. E-Mail
To open the mail client
h. Weather
Weather information (While connected to the internet)
i. Applications
Tap on this icon to reveal all
You can delete the applicati on fr om
appears at the top of the screen .
j. Galerie
Picture view / Video playback
k. Music
Music Playback
l. System
Settings
m.
to close the keyboard.
n. Home soft key
Tap to return to the home screen.
o. Running apps
Show apps which are currently running in background.
p. Menu soft Key
Tap to view the option menu
icon at the top right corner.
EN
icon
applications installed on your Tablet
- You can copy the applications onto the Home screen by pressing and holding on their icons.
­the Home Scre en by dragging their icons to the Cross that
Back soft
key
Tap to return to the previous screen. If the keyboard is on the screen, tap
Note: When you Tap the Menu key from within an application, you will see the options for that application. But you will not see them on start screen. Caution! Some apps may show this
Status bar areas
The status bar at the top of the screen is divided into two areas.
(1) At the left side you will see status information’s and
system notes like new e-mails and available app updates.
(2) At the right side you will get direct access to the
most important system settings. System information’s like wifi and battery status and the current time will be shown here.
System hints System settings
EN
23
System hints
Clear list
Current
Your contact dates,
Wifi status
Turn off/on
Bluetooth function.
3G connection
Note:
canceled.
Caution!
EN
Mustermann@Muster.com
System settings
if you have set it up.
Brightness setting
notification’s and indications
System settings
automatic screen rotation
Battery status
Airplan mode
status (Only available using optional accessories)
This view may vary and could show different or less elements at your device.
All wireless connections will be
Display all Applications
The device supports most of popular third-party applications. It has many useful applications pre-installed, such as music player, video player, photo viewer, alarm clock, calculator, etc. Furthermore, you can add more applications to the device by installing them manually. To display all applications installed on your device, tap the Application Tab. Refer to the figure below.
EN
25

Using the Touch Screen

This device is equipped with a touch-screen. Foll owing are a few tips on how to use the touch screen.
EN
Tip: For a proper usage please use your finger.
Main Touch Screen Actions
In many applications, you can go back one level in the interface by tapping on the Back icon (at the lower left corner of the screen). Wherever you are in the interface, you can go back directly to the Home Screen by tapping on the Home icon (in the lower left corner of the screen).
Other Touch Screen Actions
When watching a video or
listening to music, you can tap the progression bar to
go directly to a different location in the video or song. You can also use your finger to drag the cursor in the progression bar to another location in the video or song.
In the file browsers (File,
Music, Video, Photo, etc.), you can drag your finger up and down to scroll the file list up and down.
In the Web browser, you can scroll up and down by
tapping on the page and dragging it up or down (be careful not to tap a link until you are ready!).
Tap the link to open the page.
Note: DON’T use a pen or pencil or other sharp items to tap on the screen! This may damage the screen. DON’T place heavy or sharp edged items on the screen. Clean it carefully with a soft cloth. DON’T use cleaner.
EN
27

Bluetooth Connection

Your tablet is equipped with an integrated Bluetooth technology to enable your device be connected with
EN
other Bluetooth devices such as Other tablets, mobile phones, headsets or Bluetooth keyboards.
Pair other devices
(1) Touch the icon for the „Settings“ on t he ho me
screen.
(2) Tap to turn on the „Bluetooth“, and slide the switch
to the right. Bluetooth is ON“ will be displayed.
(3) Select the device that you want to pair from the list
on the right side.
(4) Follow the pairing wizard. You may have typed on
both or only one of the devices for a PIN code.
Visibility setup
(1) Touch the icon for the „Settings“ on t he ho me
screen.
(2) Tap to turn on the „Bluetooth“, and slide the switch
to the right. Bluetooth is ON“ will be displayed.
(3) Tap on the devices name above the list of
available devices to enable or disable the visibility.
Please note: Depending on the device, another procedure code can be applied. For some devices, you will find a four digit pin number in the manual of this device. Newer devices will be shown the code to be used on one or both devices.
Notice:
The Bluetooth status and received data is displayed at the top bar.
Advanced setting
To access the advanc ed settings, first press the menu button ( ).
Here you will fin d for example Visibility settings, and the name, apply to this device in the Bluetooth mode.
EN
29

Access Internet - Wifi

Your Tablet features built-in Wi-Fi technology so that you can access the internet via Wi-Fi network.
EN
First of all, you need to configure a Wi-Fi network. For the Wi-Fi configuration procedure to work, you need to be in a Wi-Fi zone that will allow you to connect to it. Every time Your Tablet is in range of a network that you have already configured once, it will attempt to make a connection.
Note: In order to establish a Wi-Fi connection it is required to know the encryption password of the desired Wi-Fi network. Be sure that you are allowed to use this network and that no other settings of this network like MAC address filter will deny the connection. The MAC Address of your device can be found at: “Settings” – “About device” – “ Status”.
Connect to a WPS capable router
This device also supports Wi-Fi Protected Setup (WPS), if your router is WPS capable, you can use
WPS button to connect this player to your router. Note:
- Consult the user manual of the router and learn how to add a WPS device to the router.
- Please use the manual setup if WPS does not work.
1. Press the WPS button on the wireless router.
Note: Some router use the W LAN key also for WPS Connections. Please press the WLAN-Key of your Router for 6 Seconds in these cases.
2. In the Home screen, tap on the Settings icon.
EN
31
3. Tap on the “Wi-Fi” setting to turn on the Wi-Fi. your
Tablet will scan automatically for available WiFi networks and display them.
EN
4. Now tap at the WPS-Key at the upper right corner.
5. Please wait until the connection was established.
Manual WIFI Configuring (1) In the Home screen, tap on the Settings icon.
EN
(2) Tap on the “WLAN” to turn on the Wi-Fi. your
Tablet will scan automatically for available WiFi networks and display them. The list of available networks shows all the wireless networks in range of your device.
33
(3) The list of available networks will be shown at the
right side
EN
Note:
The available network list is constantly refreshed automatically. When the Wi-Fi is enabled, Your Tablet will connect automatically to your configured networks when they are in range. If Your Tablet finds a network that has never been configured, it will display a notification icon.
(4)Tap on the network you want to connect to, enter
the required network information (password) and then tap on “Connect”. Your Tablet will now attempt to establish a connection to that WiFi hot spot with the network parameters you entered. If the connection is successful, the message Connected to XXX will appear under the WIFI setting.
Advanced Connection
To manually scan for available Wi-Fi networks, in the “WIRELESS&NETWORKS” screen, tap the SCAN icon (at top right corner). If the Wi-Fi network you want to connect does not appear in the list, then tap “ADD NETWORK.” Enter the required settings, then tap “Save.”
Launching the Web browser
Tap the Applications icon to display all applications, and then tap the Browser icon
EN
to launch the Web browser. If you are already connected to a network, the Web browser will simply open and you can start browsing the Web. To access a new website, tap the Menu icon
to display the menu, and input another addr e s s.
Note: Not all wireless networks offer access to the Internet. Some Wi-Fi networks only link several computers together, without any Internet connection.
35

Internet Access - UMTS

For mobile Internet access you can use common
EN
UMTS Internet sticks with your tablet.
Please note:
- Under the same named model of UTMS Internet
Dongle there can be found also some versions this
dongle which cannot be used with this device.
Unfortunately it is not possible to see the difference
between these sticks.
Please refer to our homepage (www.odys.de) or
please contact our support service
(support@axdia.de)
There you will obtain all current information about
compatible UMTS Dongles.
- This function is a special feature, which can only be
used with additional acc ess ori es , whic h are n ot
supplied with the devic e.
- For Internet connection you need a SIM card plus
the respective Internet connection tariff.
Caution! If your SIM card is PIN-protected it must be disabled before use. You can use any common mobile phone. Find the respective menu item in the security settings of your mobile phone.
3. In the Home screen tap on the settings icon.
Configure 3G Internet Connection Note
Take care to connect the 3G Dongle while the device is turned off. Normally your provider settings will be set up automatically. If not, please got to „Settings“ – „Wireless & Network“ – „More…“ – „Mobile networks“ – „Access Point Names“ and check if the correct APN was selected and activate it by taping if necessary. Only if your provider could not be recognized, please follow the instructions below and set up the APN manually.
1. Use the USB adaptor cable to connect the dongle to
the device.
2. Turn the device on.
After the device is turned on, press the On/Off button until the menu is displayed and press the OK button to confirm.
EN
37
4. Open the page with installed apps
Settings – Wireless & Network –
EN
More…– Mobile Networks.
5. Enable the item “Data Enabled” if it is not yet
ticked.
6. Select item “Access Point Names” to add an
Internet access point.
EN
39
7. Press the menu button and select “New APN”.
Note:
8. Enter the access dat a obtained from your mobile
The list stays empty if no APN is entered or the
EN
connected dongle was not detected.
service provider. Contact your mobile service provider to obtain all required access data, i f neces sar y.
9. Press the Return button to save the settings.
10. The list of set APNs is displayed. After setup
generally only one value is listed.
11. Ensure that the item on the right of your entered
APN is green; otherwise tap on it to activate.
12. Exit the settings and access a website with the
browsers.
13. Observe the dongle status LED. It generally
(depending on model) turns blue after successful connection. The LED flashes blue if the connection to the provider is established, but no data are transmitted yet .
Caution!
A dongle must be connected to add an access point! Observe the 3G icon on the status bar. The connection is available if it is displayed. Re-connect the dongle with the device if it is not displayed.
The letters at the connection icon show the current connection speed. H = HSDPA (highest speed) 3G = UMTS E = EDGE G = GPRS (lowest speed)
EN
Contact our customer support at support@axdia.de if you require help.
41
a. Tabulator
d. OK / Enter
e. Shift
a b c d e
f g h
i
e

Virtual Keyboard

Tapping on any text input field opens the virtual keyboard. Enter a website address or any required text
EN
with the virtual keyboard.
b. Back-space c. Switch between
Numbers and Characters
Special character Some or the keys provide the possibility to enter special character. (1) Press the corresponding key and keep
pressing. (2) While pressing move your finger tot he
desired character. (3) Release to write the selected symbol.
f. Input settings g. Voice input h. Space bar i. Emoticons
Select Input Method Open the Android keyboard settings and select the input method if more than one input method is installed.
Please note: The keyboard layout changes according to OSD language settings.
EN
43

Using the Web Browser

EN
You can scroll the screen up and down by tapping
on the page and dragging it up or down (be careful not to tap a link until you are ready!).
To open a link, simply tap it. You can open several web pages at a time, view
them all at once on the screen, and then tap one of them to view it in full screen.
To go back to the previous page that you browsed,
tap the Back icon
To display the available menu items, tap the Menu
icon
To go back directly to the Home screen, tap the
Home icon
Depending on where you are in the web browser,
holding down on an item will give you access to more options.
To fill in a text field, tap in the field, then use the
virtual keyboard to type in the required text.
Refresh / Stop
Refresh the current page after it was fully loaded / Stops refreshing
Forward
To open the next page if existing .
NewTab
Open a new tab
New tab
Open a new tab that will not be There will also be no cookies crated.
Share page
Share the current page by mail.
Find on page
Find a word at the page.
Request site
To view the pages in desktop style.
Never sleep browsing
Screen stays on while browsing.
Save for
Stores the current page at the
version.
Page info
Informations about the current page.
You can tap on the screen to enlarge or diminish the
page.
Webbrowser options
While a Web page is prompted press the me nu key at the top right corner, to open the browser settings.
EN
incognito
saved in the history.
desktop
when
offline reading
internal memory for later offline use. Note: Containing functions or links may not work using the offline
45
Settings
Additional browser settings:
General
Select start-up text functions
Privacy &
To manage
history
Accessibility
Text settings and contrast
Advanced
Advanced browser settings
mangement
transfer
Labs
Experimental functions
EN
security
Bandwidth
page and auto-fill
formular data, cache, cookies and
Settings for data

Sending/Receiving E -Mails

This device has an email app pre-installed. You can send or receive emails via the Internet. Make sure that you have an Internet connection before using the email service. In the Home screen, tap the email icon to access the email app. alternatively, tap on the app shortcut to display all apps and then tap on the email icon to launch the email app.
EN
47
Setup Email Account
First you need to setup an email account for receiv i ng or sending emails.
EN
(1) Start up the email app and you are prompted to
setup an account. Tap on “Next”.
(2) Enter your email address and login password. You
can set the account as default by selecting the option “Send email from this ac co unt by default”. Tap on “Next”.
(3) Enter the required information for POP3/IMAP
server. Contact your service provider, network administrator or search for information on the Internet.
EN
(4) Tap on “Next” after setting the POP3 server. The
device verifies the server settings and continues with IMAP server settings if your input was correct. Set up the IMAP server similar to the POP3 server. Please note that in field “IMAP Server” “imap. + domain name” must be entered.
49
(5) The device verifies the settings. After “Your account
is set up, and email is on its way” is displayed your account is set up successfully.
EN
(6) Enter your name to be displayed on emails and tap
on “Done” to finish.
Please note: If you have more than one account, every time when you start up the email app, you enter the default email account.
Caution! Please check correctness of inbox and outbox server! Depending on your service provider, there are sometimes problems with automatic settings.
Email Menu
Email functions are displ ayed on the right side of the email header.
Create new email. Search inbox. Refresh current email. Delete current email. Move current email to folder. Check settings, Refresh / Mark as unread.
Manage Accounts
You can setup more than one account and manage these accounts by checking information about the account, adding a new account or deleting an account.
Add New Account Follow these steps to add a new account. (1) Launch the email app, press the Menu icon
and tap on “Settings” in the top right corner to
display the menu item s. Select “Accounts”. (2) In the top right corner tap on “Add Account”. (3) Follow the steps to s et up an email ac cou nt .
Delete Email Account (1) Launch the email app, press the Menu icon
and tap on “Settings” in the top right corner to
display the menu item s. Select “Accounts”. (2) Select the account to be deleted and navigate in
the settings list for this account all the way to the
bottom. (3) Tap on “Remove Account” and tap on “OK” to
confirm. Check Account Settings
(1) Launch the email app, press the Menu icon
and tap on “Settings” in the top right corner to
display the menu item s. Select “Accounts”. (2) Select the desired account. (3) The settings list for this account is displayed.
EN
51
View Emails
Access your mailbox when you start up the email app.
In the mailbox, wipe with your finger up and down to
EN
scroll through the email list.
Tap on an email to open it.

Reading E-Books

Start Reading
(1) Open the page for further applicati o ns (2) Tap on the icon of "Aldiko" (3) Tap an e-book to start reading immediately.
Note: a. Make sure your e-books are in format of PDF and
EPUB supported by the device.
b. E-book cover will show as defaulted cover by the
device if the e-book has no cover data. That’s why you see some e-book covers are the same.
c. We recommend to modify or disable the automatic
display turn off function while reading.
EN
53
History and My Library
You can tap “History” to view your reading history or tap “My Library” to enter the e-book library. “History”
EN
shows all of the e-books that you have read by date. “My Library” shows all of e-books stored in the device.
To open the Aldiko Home page.
Select the desired view of the e-books list at the Aldiko Home page.
Add already transferr e d e-Books using “Files” to the e-books list.
Adding new e-books
1. First open “Files” page as shown above. This will automatically open the internal memory (internal sd-card) of your device.
2. Now find the right folder containing new e-books at the left side of the screen and tap at the corresponding rectangle at the right.
EN
Note
If you have used Adobe Digital Editions please mark the corresponding folder to add these books.
3. Tap on “Import” at the now appearing bar at the top of the screen.
4. Now you directly can open the new e-books or use the back key to go back step by step to the aldiko home screen.
55
View e -book Information In the history or e-book library, you can view information about an e-book before you start reading it.
EN
Tap an e-book, and the book name; aut hor or publication year of the e-book should display at the top screen.
Sort e-books In the history or e-book library, you can sort e-books by title, author or file size by tapping on Title, Author or Size.
Start Reading To start reading an e-book, tap “Continue Read”.
Page Up/Down
When you are reading the e-book, you can slide your finger on the screen left and right.
Increase Font Size
When you are reading, tap the Menu icon to display e-book settings. (1) Tap at the middle of the screen.
EN
(2) Tap at to adjust the font size (3) Tap a size that you want.
Note
Please note that some files like PDF-Files do not offer the possibility to change the font type.
57
Jump to a Page
You can directly go to a page that you have specified. When you are reading, tap the Menu icon to
EN
display e-book settings. (1) Tap at the middle of the screen.
(2) Tap at (3) Tap at Go to
(4) Tap the numbers to input the page number. (5) Once you finish inputting the page number, tap
“OK” to jump to the specified page.
Use Bookmarks
You can add, delete or load bookmarks on the page. When you are reading, tap the Menu icon to display e-book settings. (1) Tap at the middle of the screen.
(2) Tap at to add a bookmark to the current
page.
(3) Tap again to delete the bookmark. (4) Tap “go to” then tap “Bookmarks” to open a
bookmarked page.
Show Outline of the e-book
You can view the outline of the e-b ook and then choose your desired chapter or section to read. When reading, tap on the Menu icon to display e-book settings. (1) Tap at the middle of the screen.
(2) Tap “ ” then tap “Outline”
EN
59
Download DRM protected e-books with the Adobe Digital Edition
EN
Attention! Please note that you must install Adobe Digital Editions BEFORE you buy your first e-book online!
Once you have purchased eBooks online, you need to transfer them to your Tablet using the Adobe Digital Editions software which allows you to view and manage e-books prote cted by DRM license.
To transfer DRM-prote ct ed e-books,
1. Access the website http://www.adobe.com/products/digitaleditions/, and then install the Adobe Digital Edition software following the instructions online.
Note: To show the above installation window at the adobe website you must install or enable adobe flash player for the browser you are using first.
For first time user, you will need to get a free adobe ID from adobe website. Click on the [get an Adobe ID online] link as illustrated:
Enter your email address and complete the online form as per instructed.
2. Upon registration, return to the ADE window. Enter the username and password to activate your Adobe account and authorize your computer.
EN
3. Activate your Tablet. Connect your Tablet to computer with the USB cable and start up the Adobe Digital Editions. Click “Authorize Device” to authorize your Tablet.
61
4. Download DRM-protected PDF files to your
computer.
Access the Internet and searc h for e-books, choose
EN
your favorite e-books and download them. If the e-book is protected by DRM, you should be prompted by DRM license information. Click “Open” to start downloading the DRM-protected e-book.
Note: You need to “OPEN” the e-Book you wish to download. DON’T use the “Save as”!
5. Click “Purchase”, and then you should see your
downloaded e-book at the ri g ht panel o f the A dob e Digital Editions user interface.
6. Connect your Tablet to the computer with the USB
cable, and the Adobe Digital Editions should recognize your Tablet.
7. Click “Purchase” to see your downloaded e-book
and then drag it to your Tablet.
EN
63

Playing Music

Tap the Music icon to enter the music player mode. Optionally, you can tap the Applications shortcut to
EN
display all applications and then tap the Music icon to enter the music mode.
Music Library
You should enter the music library once you start the music player. The Music Library shows your music files sorted by categories (Artist, Album, Title, Genre, etc.) if your music files contain these song information tags. If some of your music files do not contain information tags, they will be classified as (Unknown) in the Music Library. When new music is copied to the device, the Music Library will be updated automatically.
You can drag your
finger up and down on the file list to scroll through the list.
Tap a track to play a
track.
EN
To return to the Home Screen, tap / .
65
l. Menu key
f b g
h
j
i
k
c
d
l
a
e
Playback Screen
EN
a. Shows that the player app is running, if running in
background. b. Show current playlist. c. Random playback on / off. d. Change replay mode e. Lyrics, if available f. CD Cover (If existing) g. ID3-Information’s (Artist, Album etc.) h. Short press – Previous track i. Play/Pause j. Short press – Next track k. Progress bar
To pause or resume the playback, tap on th e
To play the previous/next song, tap on / .
Pause / Play icon.
You can tap on the progression bar to go directly
to a different location in the song. You can also drag the cursor in the progression bar to another location in the song.
Tapping continuously on the ID3 information tag
will search for the information about the track from the Internet.
To go back to the music library, tap on
To go back directly to the Home screen, tap on the
Home icon or Return icon .
EN
67

Video / Photo Playback

On the Home screen tap on the photo browser icon to launch the photo viewer. Alternatively, tap on the app
EN
icon to access all apps and tap on the photo icon to launch the music mode.
Thumbnails
The first screen in photo mode shows all photos/videos and sub folders in the device or on memory card as thumbnails. Tap on a photo thumbnail to view the photo in full screen mode. Open the sub folder if the photo is stored in a sub folder to display the photo/video contents as thumbnail s.
View Photo
While viewing photos tap on the screen to show the status bar at top and bottom.
EN
69
Press the menu button or tap on the respective icon
( ) in the top right corner and then on “Slide Show”
to start the slide show.
EN
Tap on the screen again to end the slide show. Wipe with your finger to the left or right over the
image to display the previous/next photo.
To zoom in or out tap with two fingers on the
display and pinch the image between thumb and
pointer finger.
Tap on and then “Rotate Left” or “Rotate Right”
to rotate the image 90° left or right.
Tap on again and then on “Details” to show
image details.
Tap on and then on “Set Image As” to use the
image as wallpaper or contact image.
a. Progress bar
g. Play/Pause
b
c
d e f
g h a
i j k
l
Video Playback Screen
When Video Playback you will see the following image:
EN
b. Decrease volume c. Increase volume d. Add bookmark e. Brightness setting f. Previous video
h. Next video i. Screen scaling j. Preview mode k. Return l. Video settings
71
Tap on Pause / P lay to pause or continue
video playback.
Tap on to display the menu items.
EN
Tap on the progress bar to skip to a position in the
video. Alternatively, drag the cursor on the progress
bar to a different position in the video.
Tap on / to set the volume level. Tap on / to play the previous/next video.
Tap on to end playback and to return to the video
list.
Preview Mode ( )
In preview mode the Video will be played in a small window and can be moved to any position at the screen.
Simultaneously tap with two fingers at this window.
Drag the fingers together or apart scale the window.
Tap once at the window to show the progress bar. Tap at the window while the progress bar is visible
to pause playback. Tap again to resume.
Tap at the arrow at the bottom right () while the
progress bar is visible to fade out the window.
Use the symbol to fade in the window again.
Longer tap at the window (2 Sec.) while the progress
mar is NOT visible. Now tap at the appearing cross
to stop playback and close the window completely.
Delete bookmark and play from beginning
Delete bookmark
Play mode
Select:
- Repeat all
External, embedded selection
Select if external or have first priority
Embedded subtitle
Select between the subtitles
Audio track select
Select the sound track if different are available
Help
Function overview
Return
Exit menu
Video settings ( )
Use to set up the video playback
EN
- Single
- Repeat one
subtitles priority
select
embedded subtitles will
available embedded
73
Settings

Camera usage

The camera can be used for capturing photos or videos of for internet video calls.
EN
Shutter for camera and video capturing (While recording a video, tap again to stop recording)
Switch between
Zoom
Simultaneously tap with two fingers at the screen. Drag the fingers together or apart to zoom out or in.
Zoom out
Zoom in
Photo-, Video-
Camera settings
Store location
The current position will be saved if
Tap at to open the settings. More symbols will appear in the middle of the screen. Tap at the desired symbol to open.
General settings
EN
75
Picture settings (White Balance)
EN
Cloudy Sunny
Auto Neon light
Tungsten
path
Quick Access
hidden
App configuration
Menu bar

ES File Explorer

On the Home screen tap on the app icon to access all apps and tap on the explorer icon to launch the ES Explorer
Screen elements
Quick Access
Higher level of the file current file
EN
77
Favorites
Access memory locati ons marked as favorites
Local
Navigate to the location of local memories
Library
Media library
Network
Access to network elements
Tools
Aditional features
Quick Access
The main elements and places of memory are accessible directly from the rapid access at the left
EN
edge.
By pressing the toolbar bar will be hidden.
Progress
From the path at the top, you could follow the file in which you are.
- Press the left side of the progress bar to exit the current file.
- Press the right side to access the path or select another location
Note
If you reached already the lowest level of the file, the left side is no longer present.
Opened window
Window management
If a new item is opened via a quick access, it will be opened in a new window. The open windows are displayed in the upper part of the screen between the windows, you can change by wiping the left or right.
Press to close the current window.
Close this
window
EN
79
sdcard
Usable internal device memory.
external_sd
Connected microSD memory card.
usb_storage
USB storage media, which are connected via USB adaptor.
Standard path is the internal SD card. Tap on the history above to toggle between connected storage
EN
media. External storage devices are in folder “mnt”:
Navigate Files And Folders
Wipe with your finger up and down to scroll through
the file list.
To open a file or folder, tap the file/fol der . Go back one level in the directory by pressing the
left side of the path
Tap on the Return or Home button anywhere in the
app to return to the Home screen.
Touch to navigate "local" in the fast access and
"Home" directly in the dir ec tor y
Rename selected items
Menu Bar
You can use the toolbar to navigate in the internal memory of your device or memory card and delete or copy files
Add files / Folders Search by file type. Update
Sort
Change the view
Press and hold for (ca. 3 Seconds) on a file or folder to select it and to show other functions. .
Below you can select multiple files or other folders
EN
Copy selected items Cut selected items. Delete selected items
Additional features
81
(1) In the file list, scroll up and down by wiping with
(4) Press on to add into it the file or data
(5) You may open the field at the left
Copy/Move Files And Folders
your finger to select the file/folder to be copied or
EN
moved.
(2) Hold your finger on the selected file/folder until a
pop-up menu appears.
(3) Select “Copy” or “Move” from the pop-up menu.
Navigate to the location where you wish to copy or move the file/folder to.
side of the window to have more options.
Delete Files And Folders
(1) In the file list, scroll up and down by wiping with
your finger to select the file/folder to be deleted.
(2) Hold your finger on the selected file/folder until a
pop-up menu appears.
(3) Select “Delete” from the pop-up menu, then select
“Delete” to confirm or “Cancel” to cancel deleting.
Rename Files And Folders
(3) In the file list, scroll up and down by wiping with
your finger to select the file/folder to be renamed.
(4) Hold your finger on the selected file/folder until a
pop-up menu appears. (5) Select “Rename” from the pop-up menu. (6) Tap on the input field to display the virtual keyboard,
then enter the letters from the virtual keyboard to
rename the file/folder. (7) Tap “OK” to confirm the new name.
EN
83

Manage Third-party Applications

Your Tablet provides support to many useful third-party applications. You can purchase the
EN
applications to add more functions to your device. They are available online at the Internet or directly on your product.
Pre-installed Applications
The device has pre-installed applications when it was manufactured. You can see them by tapping Application Tab. They are video player, audio player, photo browser, calculator etc.
Install Applications
You can install applications manually following these steps: (1) Download the installation file to your computer.
Make sure the file is in format of .apk which is supported by your Tablet system.
(2) Connect your Tablet to computer with the USB
cable. (3) Copy the installation file to your Tablet. (4) Disconnect your Tablet form the computer. (5) Turn on your Tablet and enter the file explorer
mode with the Explorer. (6) Locate the installation file and open it. (7) Follow the on-screen instructions to install the
application. (8) Once the application is installed successfully, you
can find it in the application tab.
Uninstall Applications
(1) Tap the Settings shortcut in the Home Screen to
display all system settings. (2) Select “Applications”. (3) Tab on the application t hat you w ant t o unins t al l . (4) Tab on “Uninstall” to uninstall the application.
Note: You cannot uninstall the pre-installed applications. Some of the applications developed for Android mobile might not run properly in the Tablet. Please consult the respective software developer for further information or support.
Caution! Please note that the installation of third-party application occurs on y our own risk! Any up normal behavior or damage that is caused by installing third-party applications will not be an integral part of the warranty.
EN
85

System Settings

On the Home screen tap on the “Settings” icon and
EN
select the category “Wireless & Networks”, “Sound and Display”, “Date and Time”, etc.
Tap on the function to change the settings. Tap on the tick box on the right side of the
parameter to enable this option.
Wipe with your finger over the screen to display
further settings outside the screen.
After completing your settings tap on the icon to
return to the setting menu or tap on the icon to return to the Home screen. Your changes are saved.
Wireless & Networks
Wi-Fi
Tap to enable/disable the Wi-Fi
manage your Wi-Fi networks.
Bluetooth
Tap to activate/deactivate the Bluetooth function.
Data usage
List of the Data usage of installed apps
More…
mobile use.
connection. Press the menu button or tap on the icon in the top right corner and then on “Advanced” in the top right corner to manually set up and
Here you find the advanced network settings such as for VPN or
EN
87
Device
Sound
Volume
Set the volume level for
on right of the device.
System
Enable/disable touch
lock/unlock.
Display
Brightness
Set screen brightness.
Wallpaper
Select wallpaper.
Sleep
Set auto off delay and
the screen.
Font Size
Change the menu font size.
Show screenshot in status bar
This setting allows the ver ific ati on o f
microSD cards to be searched.
Battery
Capacity display of the rechargeable battery
Apps
This screen allows Android™ apps installed on your device.
EN
music and videos. You can also set the volume with the volume buttons
screen button beeps and notification tones for
screen lock. Press On/Off once to switch on again and tap on the screen once to unlock
the memory capacity of the internal memory and SD card. You can also set media content of connected external USB devices or
management. Info disp l ay of apps
Personal
Location
This screen allows certain Android™ location.
Security
Set security parameters and screen locks.
Language Method
Set your language and region and more accurate text input.
Backup &
This setting allows system or data
reset.
Sync setting for email and mess eng er acc ou nts .
Date & Time
Set date, time, time zone and time format.
Accessibility
Set operating aid such as Auto response time.
Developer
Important functions for app
functions.
About
Display information about your tablet system.
Services
& Input
Reset
Accounts
System
apps to determine their curr ent
EN
configure text settings for faster and
backup or recovery.
Caution! All previous settings are
Display Rotate or the touch screen
Options
developers such as USB debugging mode or user interface display
89

Troubleshooting

Reset the device
EN
If the On/Off button does not reset your device, use
the “pinhole reset” button, located on the back of the device. The device reboots. Settings and data are NOT lost.
Touch screen does not respond
Ensure that the app provides full touch screen
support.
Do not tap to hard on the screen; this can cause
malfunctions.
No sound from earphones
Ensure that the volume setting is not too low and
that the connection is ok. Ensure that the earphones are clean. Corrupted MP3 files can cause different noise or cannot be played. Ensure that the files are not damaged. Try different earphones. Ensure that the Wi-Fi function is enabled and that a wireless network is within range.
Characters are corrupted
Ensure that the language is set properly.
No Wi-Fi connection
Ensure that the Wi-Fi function is enabled and that a
wireless network is within range.
Enter the correct password. Observe special
characters and case sensitivity. Characters must be entered accordingly.
Follow the hints on the next page.
EN
91
Solve Wi-Fi connection problems
Status
settings)
channel
- Deactivate
n
No Internet
-> Connecting
->
- Password wrong or
- Check and
re-enter
1. Open Wi-Fi settings.
2. Select and remove Wi-Fi.
EN
3. Tick “Display Password” and enter password.
4. Look out for status messages below the network name:
Problem
Network not found
No Internet
messages
(below network
name in Wi-Fi
Network not found
-> Connecting
-> Not connected
Possible
cause
- SSID not visible
- Wi-Fi too weak
- MAC filter active
Solution
- Enable SSID in router configuratio n
- Decrease distance to router
- Firmware update or change
filter in router configuratio
Authenticati
connected
wrong
password
- Delete list of
n
No Internet
Reset this device
If the Power button does not reset your device, use
the “pinhole reset” button, located on the back the device.
on…
-> Not
-> Connecting
-> Authenticati on…
-> Retrieving IP address…
-> Not connected
spelling
- Router configurat ion faulty or
- Wi-Fi too weak
- DHCP server off
EN
connected devices on router
- Decrease distance to router
- Activate DHCP in router configuratio
93
Touch-screen Problems
Check if the Application you are usi ng has ful l
touch-screen support.
EN
Don’t press too hard on the screen. This might
cause a wrong behavior.
No Wifi connection
Take care that Wifi is enabled and a wireless
network is in range.
Be sure that you entered the correct password. Take
care of special characters and capital letters. They need to be entered as is.
Without sound inside earphone
Please confirm the volume is not in the status of
Zero and the connection of earphone is ok. Please confirm the earphone is clean. The broken MP3 will produce noise with different grades even cannot play music. Please confirm the complete files. Try another pair of headphones.Take care that Wifi is enabled and a wireless network is in range.
The character on the display screen is in abnormal shape
Please confirm the language that you selected is
correct.
No USB connection is established to the PC
Check cable/plug connection to the PC, Windows
system configuration and USB driver. Restart PC, remove and reconnect the USB cable, reinstall drivers.
It is not possible to store anything at the inserted SD card
Please confirm that the inserted SD card is not write
protected.
It is not possible to download e-books from odysbook.de.
Please disable any popup blocker .
EN
95
Configurations
1,5 GHz Dual Core Processor DDR
1024 MB DDRIII Ram
Built-in system
IBM PC or compatible PC, Notebook or Macintosh with USB port
Internal Memory
Memory Card
System Requirements
Operation System
Windows2000/XP/Vista/windows 7and MAC OS 10.4 or above
USB Interface
Features
Output Port
3.5mm earphone port, buil t-in speaker
Built in microphone
Format
MP3 (MPEG1/2/2.5 Audio Layer
APE (Ve rsion

Specifications

EN
CPU
operating
Hardware
Google Android 4.2.x
8 GB Micro SD card: up to 32GB(SDHC)
USB2.0 High speed
E-book
EPUB, PDF
1/2/3)
Audio
WMA (Version 4,4.1,7,8,9) WAV (MS-ADPCMIMA-ADPCM PCM)
3.95,3.97,3.98,3.99,normal and fast
OGG
Video
AVI (Xvid, Divx 4/5/6 except
/DIVX4/5/6)
Photo Format
WI-FI
Available
Language
Multinational languages
Technical Parameter
Read speed
Write speed
OGG: Q1- Q10
Format
except high and extra high) FLAC (FLAC Audio) AAC (ADIF, ATDS Header AAC-LC and AAC-HE ) (For license)
GMC&QPEL, Divx for License, Audio Codec: MP3, AC3) RM/RMVB (Real Video Codec 8/9/10 except G2, Audio Codec: Real Audio) FLV ( Sonnati H.263, H.264 except O2 VP6) (For license) MKV (H.264, MPEG4, XVID, DIVX4/5/6) MOV (MPEG4, H.264, Audio Codec:MP3) 3GP/MP4(H.264/H.263/MPEG4/XVID
JPEG, BMP, GIF(static), PNG
EN
8.7-9MB/S (MLC flash)
4.5-4.8MB/S (MLC flash)
Audio Bit Rate
MP3: 8320Kbps WMA: 8320Kbps
97
AVI (Max.12 80X720); RM/RMV B
1280X720)
Max. 6Mbps (MPEG4, XVID,
Max. 2Mbps (Sorenson H.263).
Photo Resolution
JPEG (Baseline) (Max.8000*8000), GIF(Static) (Max.1000*1000)
n Media
Battery Time
Battery Life
Display
8 inch1024 x 768 | 4:3 HD Display
SNR
65dB above
Frequency Range
Rechargeable lithium-ion polymer
50/60Hz, DC Output 5V/2A
Physical Parameters
Video
EN
Resolution
Video Bit rate
(Max.1280X720); FLV(Max.1280*720); MKV (Max. 1280X720); MOV (Max.
DIVX4/5/6); Max. 2.5Mbps (H.264, Real video 8/9/10);
Network Connectio
Charge
Wi-Fi (80 2. 11 b/g/n)
About 5 Hours
About 4 hours
Response
Power Supply
20Hz—20KHz
battery; AC Adapter: AC Input 100-240V
Storage Temp.
Ambient Temp.
Operation Humidity
Humidity
-20°C +65°C 0°C ~ +50°C
EN
Relative Storage
Relative
20% ~ 90%(40°C
20% ~ 93%(40°C
The following conditions comprise the requirements and scope of our warranty conditions and do not affect our legal and contractual warranty obligations.

Warranty Conditions

99
We offer a warranty on our products in accordance
with the following conditions:
EN
1. AXDIA products are covered by a 24 month warranty. We will resolve damages or defects on AXDIA products free of charge within 12 months of the purchase date under the following warranty conditions. For any damage or defect determined later than 12 months after the purchase date, proof of a manufacturing fault must be submitted for repair under warranty. The warranty does not cover batteries and other parts, which are considered consumables, parts that break easily such as glass or plastic or defects based on normal wear and tear. There is no warranty obligation in the event of marginal differences compared to the target appearance and workmanship provided these have a negligible effect on the product's fitness for use, in the event of damage caused by chemical or electrochemical effects, by water or generally from abnormal conditions.
2. The warranty will be performed in such a way that we shall decide whether to repair the defective parts or to replace them with working parts free of charge. AXDIA reserves the right to exchange the product for a replacement product of equal value if the product that is sent in cannot be repaired within a reasonable time or at reasonable
Loading...
