Oculus Ri Development Kit

The Oculus Ri Development Kit includes everything
you need to start building virtual reality content for
the Oculus Ri.

• Headset and control box

• Power cord with adapter

• DVI/HDMI adapter

• 6 HDMI cable

• 3 USB cable

• 3 pairs of vision lenses

• Over-the-head strap

3 Pairs of Lenses

Power Cord with

Adapter

Over-the-head

Strap

DVI/HDMI Adapter

Geng Started

Remove the contents of the case carefully.

If any part is missing or damaged, please contact Oculus
Customer Support.

More detailed informaon on setup and
troubleshoong can be found online at:

hps://developer.oculusvr.com

Oculus VR, Inc.
[e-mail]

TM & © 2013 Oculus VR, Inc. All Rights Reserved.

1

Oculus Rift Development Kit

Seng Up the Headset

1. Carefully remove the headset and the control box from
the case. The headset cord is permanently aached to
the control box. Avoid having this cord bend sharply.

2. Adjust the head strap so that it ts snugly around your
head.

3. An over-the-head strap is included. If you choose to use
it, loop the strap from the front to the back and adjust
so it ts over your head comfortably. Adjust the over­the-head strap to t as desired.

4. If you wear glasses, you can adjust the distance of
the lenses and screen by turning the screws on either
side of the headset using a coin. Make sure that the
adjustment sengs on both sides match aer making
changes.

Note: Wearing glasses while using the headset will
reduce your eld of view. You also risk scratching your
lenses. If you are nearsighted, we recommend you use
the included vision eye cups or contact lenses.

5. Three dierent pairs of lenses are included with the
development kit. The tallest set (A) is designed for 20/20
or farsighted vision. The middle set (B) is designed for
moderately nearsighted users. The shortest set (C) is
designed for very nearsighted users. The lenses are
designed to be swapped using an insert-lock-in-place
mechanism. If you wish to wear correcve lenses while
using the Ri, please use lens set A, the tallest lens cups
and use the side screws of the Ri to adjust the headset
to t on your head.

Note: To prevent dust from geng inside the headset,
we recommend you turn the headset face down before
changing lenses.

2

Oculus Rift Development Kit

Seng Up the Oculus Ri Control Box

HDMI

DVI

USB

Power

Power

Contrast

Brightness

1. There are four connectors on the back of the control
box. The connectors are:

- HDMI

- DVI

- USB

- Power

2. Connect one end of the video cable (DVI or HDMI) to
your computer and the other end to the control box.
Only one video input should be connected to the control
box at a me. You can use the DVI Adapter with the
HDMI cable.

3. Connect one end of the USB cable to your computer and
the other to the control box.

4. Plug the power cord into an outlet and connect the
other end to the control box.

5. The buons on the top of the control box are used to
adjust brightness and contrast of the headset's display.

The le most two buons adjust the display's contrast.
The next two adjust the display's brightness.
The right most buon turns the power on and o.

6. Press the power buon to power on the control box and
the headset. A blue LED on the top of the control box
indicates whether the device is on or o.
