Full HD Digital Satellite Receiver
Digital Innovation Life
User’s Manual
OCTAGON SF 1008G+ SE+ HD INTELLIGENCE
3
INDEX
INDEX ................................................................................................................................... 3
Precautions ......................................................................................................................... 5
1. Important Safety Instructions...................................................................................................... 5
2. Notice ......................................................................................................................................... 5
3. Copyright .................................................................................................................................... 6
4. Disclaimer ................................................................................................................................... 6
5. Trademarks ................................................................................................................................ 6
Before Y ou Begin ................................................................................................................ 7
1. Main Features ............................................................................................................................ 7
2. Accessories ................................................................................................................................ 8
Hardware Description ......................................................................................................... 9
1. Front Panel Configuration .......................................................................................................... 9
2. Rear Panel Configuration ......................................................................................................... 10
3. Remote Control Unit ................................................................................................................. 11
Connecting diagram ......................................................................................................... 14
1. Receiver to A/C power .............................................................................................................. 14
2. Receiver to TV with Digital A/V Output ..................................................................................... 14
3. Receiver to TV with Analog A/V Output .................................................................................... 15
4. Connecting to Antenna Cable .................................................................................................. 15
Guide of Functions ........................................................................................................... 17
1. Selecting a Service ................................................................................................................... 17
1.1 Using CH UP/DOWN buttons.............................................................................................. 17
1.2 Using Service List ............................................................................................................... 17
1.3 Using Simple Service Lis t ................................................................................................... 17
1.4 Using Recent Service List ................................................................................................... 18
2. Information Window .................................................................................................................. 18
3. Multi-Picture Display. ................................................................................................................ 18
4. Electronic Program Guide (EPG) ............................................................................................. 18
5. Favorite Group ......................................................................................................................... 19
6. Volume Control ......................................................................................................................... 19
7. Pause ....................................................................................................................................... 19
8. Subtitle...................................................................................................................................... 20
9. Audio Control ............................................................................................................................ 20
10. Teletext ..................................................................................................................................... 21
11. PIP (Picture in Picture) ............................................................................................................. 21
4
PVR (Personal Video Recorder) Function ....................................................................... 23
1. Recording ................................................................................................................................. 23
1.1 Recording methods ............................................................................................................. 23
1.2 Recording Edit ..................................................................................................................... 25
1.3 Long Time recording ........................................................................................................... 25
1.4 Pause during recording ....................................................................................................... 25
2. Time Shifting ............................................................................................................................. 27
3. Playback (Play List) .................................................................................................................. 28
3.1 Recorded Files .................................................................................................................... 28
3.2 Imported Files ..................................................................................................................... 29
3.3 Music ................................................................................................................................... 29
3.4 Photo ................................................................................................................................... 29
4. Bookmark ................................................................................................................................. 30
5. Trick mode ................................................................................................................................ 30
Menu Map .......................................................................................................................... 31
Main Menu of Guide .......................................................................................................... 32
1. System Tools ............................................................................................................................ 32
1.1 Storage Manager ................................................................................................................. 32
1.2 Timer Settings ..................................................................................................................... 33
1.3 Service List Manager .......................................................................................................... 33
1.4 Data Transfer....................................................................................................................... 35
2. Configuration ............................................................................................................................ 36
2.1 Recording Option ................................................................................................................ 36
2.2 Parental Control .................................................................................................................. 37
2.3 Display Setting .................................................................................................................... 37
2.4 Time Setting ........................................................................................................................ 38
2.5 Language Setting ................................................................................................................ 38
2.6 A/V Output Setting .............................................................................................................. 39
3. Installation ................................................................................................................................ 40
3.1 Dish Setting ......................................................................................................................... 40
3.2 Positioner Setting ................................................................................................................ 40
3.3 Service Search .................................................................................................................... 41
3.5 System Recovery ................................................................................................................ 43
3.6 System Information ............................................................................................................. 44
4. Utility ......................................................................................................................................... 44
4.1 Calculator ............................................................................................................................ 44
4.2 Calendar .............................................................................................................................. 44
4.3 CAS (Conditional Access System) ...................................................................................... 44
4.4 Plugin .................................................................................................................................. 45
4.5 Free TV+ ............................................................................................................................. 46
4.6 Internet TV+ ........................................................................................................................ 47
4.7 Internet Radio+ (WebRadio+) ............................................................................................. 48
4.8 Weather forecast ................................................................................................................. 49
Troubleshooting ................................................................................................................ 50
Specifications .................................................................................................................... 51
5
Precautions
1. Important Safety Instructions
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
Do not reverse the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or third prong is provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
Unplug this apparatus during lightning storms or when unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
WARNING : To Prevent fire or shock hazard do not expose the set to rain or moisture.
2. Notice
These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock, do not perform any servicing other than that contained in the operating instructions
unless you are qualified to do so.
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
The mains plug is used as the disconnect device. The disconnect device shall remain readily operable.
6
To reduce the risk of electric shock, do not remove
the cover (or back).
No user serviceable parts are inside.
Refer servicing to qualified service personnel.
The Lightning Flash with arrowhead symbol
within an equilateral triangle, is intended to
alert the user to the presence of un-insulated
"dangerous voltage" within the product
enclosure that may be of sufficient magnitude
to constitute a risk of shock to persons
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product
NOTE : Contents of this manual and features/specifications of the STB are subjected to
change without prior notice.
3. Copyright
This manual is protected by copyright laws.
Copy, use and reproduction of this manual in part or whole without Manufacturer’s prior written
approval are prohibited.
4. Disclaimer
The manufacturers, distributors and agents are not liable to any kind of damage caused by the
use of the information contained in this manual.
The instruction and descriptions which this manual contains are based on the time of this
manual's production.
The manufacturer constantly updates it with new functions and technology.
All the specifications are subject to change without prior notice.
5. Trademarks
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
7
Before You Begin
1. Main Features
Supports MPEG4 /MPEG2 - HD/SD and Fully DVB-S2 /DVB-S Compliant
Intelligent Blind Scan for both SD and HD TV & Multi-Satellite Search
Multi-LNB Controlled by DiSEqC Control Version 1.0, 1.1, 1.2 and USALS
HDTV PVR Receiver ( H.264/ MPEG4 HD )
Embedded Linux OS
Time Shifting, Recording & Playback with External HDD (USB 2.0)
Simultaneously Records upto 3 Channels and allows Viewing of 2 others (PIP) on the same
Transponder
Powerful Extended EPG supports Event Recording
Dual USB 2.0 Host ports (MP3 Player & JPEG Viewer)
MKV, Xvid file play back support
Ethernet Support
High Definition On-Screen Display
Favorite Groups
Powerful Service List Manager for Favorites, Lock, Skip, Move, Edit and Delete
Service Sorting by Name, Transponder and CAS
User Friendly & Multi-language Supported (OSD & Menu)
Teletext / Subtitles Supported
Maximum 10,000 Services(TV & Radio) Programmable
Picture-in-Picture (PIP) & Multi-picture Display
Parental Lock / System Lock / Installation Lock
HDMI Video & Audio Output
(576i, 576p, 720p, 1080i, 1080p)
Supports Y/Pb/Pr(component) Output in HD
CVBS(composite) Video & Audio Output via RCA
CVBS, RGB, Video & Audio Output via TV SCART
Optical Output for Digital Audio(SPDIF)
Software & Service channel Database upgrade via USB & RS-232C port
2 Smart card reader and 2 Common Interface Slots
1W Stand-by Power Consumption
8
2. Accessories
NOTE : If any accessories listed above are missing, contact the sales representative where you
purchased this unit.
User's Manual
AAA size Batteries X2
AC Power Cord
Remote Control
HDMI Cable
9
Hardware Description
1. Front Panel Configuration
1. POWER BUTTON : Press to switch between STANDBY and POWER ON modes.
2. CH Up/Down button : Press to change services in normal mode, or to move highlighted-bar
in menu mode.
3. VFD Display : The VFD consist of 8-digit letter. These letters and icon display the current
status of receiver such as service name, service information and so on.
4. USB (Front) : Use it when connecting to external USB storage device
.
5. SMART CARD READER : Insert smart card for encrypted service access.
6. PCMCIA : To receive pay-tv service you need a CA-Module and a smart card from the
service provider.
10
2. Rear Panel Configuration
1. LNB IN: Use to connect a satellite antenna.
2. LNB OUT: Use it when connecting to another STB for loop-through.
3. RS-232C : Serial port for firmware update and data transfer.
4. Ethernet : Local area network port for direct computer connection.
5. USB : Use it when connecting to external USB storage device.
6. SPDIF : Connects to the audio system using a S/PDIF cable. (digital audio)
7. HDMI : Connects to the TV by using a HDMI cable for the best quality picture and audio.
8. VIDEO : Connects to the TV or VCR using a RCA cable. (Composite video output / Yellow)
9. AUDIO L/R : Connects to the TV or VCR using a RCA cable. (Stereo audio output / White, Red)
10. Component : Connects to the TV or VCR using a component cable. ( YPbPr)
11. TV SCART : Connects to the TV input using a TV SCART cable.
12. A/C power cable socket : Connects to A/C power cord.
13. A/C Switch : Power switch
11
3. Remote Control Unit
1. POWER : Turns the STB On/Off.
2. MUTE : Turns the sound On/Off.
3. V.Format : You can switch the Display Format (4:3 / 16:9)
4. Sleep : To adjust sleep timer.
5. TV/RADIO : Switches between TV and Radio.
6. Resolution : To select the resolution format. Each time you press the Resolution button, the
resolution changes in the following sequence: 576i > 576p > 720p > 1080i
7. Page Up& Down : Move to the next or previous page if more than one page are available. This button
also is change the location of sub picture in PIP.
8. Subtitle : To s how multilingual subtitle.
9. Teletext : To show the digital teletext.
10. Numeric : Controls the numerical operation and service numbers directly.
11. Favorite : To display the satellite group and the favorite groups.
12. Play List : To show the file list in the USB Storage Device or Network Storage Device.
12
13. Information : Shows the information of the current program. If you press one more, detail
information box will be shown.
14. Recall : Moves to previous service.
15. ARROW Buttons
a. Up & Down Buttons : To change the value of a selected item with preprogrammed values in menu.
b. Left & Right Buttons : To move the cursor left and right in menu.
16. OK or Service List : Show the service list in non-menu mode and select an item or confirm in menu
mode.
17. Menu : To enter the main menu or to move to the previous menu.
18. EXIT : Exit from the menu or pop-up window.
19. Volume Up & Down : To change the Volume.
20. Channel Up & Down: To change service channel.
21. EPG(Electronic Program Guide) : Show the TV/Radio program guide.
22. Color Buttons
a. RED : Used for special function in menu. RED key is used to sort lists in service list or go to previous
day search in EPG or make/delete the current position as a bookmark.
b. GREEN : Used for special function in menu. Green key is used to set favorites setting in service list
or go to the next bookmark position.
c. YELLOW : Used for special function in menu. Yellow key is used to find service in service list or
change the audio track.
d. BLUE : Used for special function in menu. Blue key is used to set service list option in service list or
display Multi-Picture.
13
23. Rewind : Rewinds at high speed. Each time you press this button the rewind speed is increased.
24. Play / Time shift : Display the progress bar of playback when no progress bar is displayed. Start
playback with normal speed. Return to normal speed from trick mode..
25. Pause : This key is used to pause the video. Press once more to resume the video.
26. Fast Forward : Fasts forward at high speed. Each time you press this button the speed is increased.
27. Previous File : To play the previous MP3 file in MP3 play mode. This button is also used to jump back
to beginning of recording during a playback.
28. STOP : To stop time shifting, play back or recording.
29. Recording : To start Recording.
30. Next File : To play the next file. This button is also used to jump to end of recording during a playback.
31. Repetition (*): This key is used to play back a recording repeatedly.
32. PIP Buttons
a. PIP(Picture in Picture) : To set PIP window.
b. PIP Swap : Switching between main-picture and sub-picture
c. PIP(Picture in Picture) Service List : To shown the sub-picture service list.
NOTE : (*) This Feature(Repetition) will be supported later, by new s/w version by upgrading.
Please refer to your local dealer / distributor.
14
Connecting diagram
1. Receiver to A/C power
Connect the A/C power cord between A/C power cord socket of receiver and A/C outlet.
2. Receiver to TV with Digital A/V Output
Connect the HDMI Cable to the HDMI Connector of the TV.
Connect SPDIF to Digital audio input of the equipment(Digital Audio)
NOTE : Depending on the A/V equipment you own, there are various ways you can connect
the STB. To choose the best connection option, please refer to the manual of the
equipment you would like to connect to. To get High Definition playback of High
Definition content, we recommend that you connect your high definition display
with a HDMI cable. HDMI supports standard, enhanced or high-definition video
and multichannel audio in a single cable.
15
3. Receiver to TV with Analog A/V Output
Connect the VIDEO and AUDIO L, R to VIDEO IN and AUDIO L, R IN of TV.
Connect the Component to the Component input of the TV.
Connect the TV SCART to the SCART input of the TV.
NOTE : The SCART cable connection is recommended for analogue TV or VCR
The composite connection(RCA cable) is recommended for analogue TV
You ca nnot vie w high def initio n vide o with the SCART and the composite video
connector.
4. Connecting to Antenna Cable
Using Single DISH : Connect the Satellite Antenna cable to LNB IN.
16
Using DiSEqC switch : Connect the cable of DiSEqC switch to LNB IN.
Using DiSEqC motor : Connect the cable of DiSEqC motor to LNB IN.
17
Guide of Functions
1. Selecting a Service
To select the desired service (channel), please refer to the instructions below.
1.1 Using CH UP/DOWN buttons
You can navigate between services by pressing CH UP/DOWN buttons. Whenever you press the CH
UP(DOWN) button, current service will be changed to next/previous service. Please press CH UP or CH
DOWN button until you fine the service you want to watch.
1.2 Using Service List
To select the desired service in the service list, you should firstly
display the service list by pressing the OK button.
Use the ARROW buttons to select a desired service and press
the OK button.
You can see that the service is changed in the small screen on
the top-right.
To watch that service, press the OK button once more.
To watch the previous service, press the EXIT button.
In the Service List window, you can also select additional functions with the COLOR buttons. Press the
RED button, and you can sort the services by the Alphabet, Transponder(TP), Group, Tuner and CAS
(Conditional Access System).
Press the GREEN button, and you can add the services to one of 10 Favorite List.
Press the YELLOW button, and you can search & find the service via a virtual keyboard.
Press the BLUE button, and you can adjust service list option.
1.3 Using Simple Service List
If you press NUMERIC buttons or UP/DOWN ARROW button,
instant service list will be displayed.
Select the desired service by using the ARROW button, and
press OK button to watch.
You can also enter the service number directly by using the
NUMERIC button.
Loading...
