INSTRUCTION MANUAL
!
EXTENDER!INSTRUCTION!MANUAL!2016!
!
!
Extender!Instruction!Manual!2016!
Rel!1.1!
WE WERE ALL BORN FROM THE SEA.
Maybe that’s why we’re so irresistibly attracted to it.
As soon as we’re immersed in it, once again we turn to breathe, we feel we’re back
to our true natural setting.
In our every effort, every thought, every dream, the sea finds its way.
We yearn to be back in it to better observe it, to admire its grandness, always with
new eyes.
To be back in it, to be astonished by it and to share its wonders with our friends.
To be back in it, to imbue new life to the very place that’s been witness to the birth
of all.
3!
!
Extender!Instruction!Manual!2016!
Rel!1.1!
!
PARTS LIST
Number
Name
Quantity
1
Frame
1
2
Bushing
4
3
Bushing Cover
4
4
L Bridge
1
5
R Bridge
1
!
EXTENDER!INSTRUCTION!MANUAL!2016!
!
!
Extender!Instruction!Manual!2016!
Rel!1.1!
6
M3 screw
4
7
L Neutral
1
8
R Neutral
1
9
L Earphone
support
1 10
R earphone
support
1
11
Earphone plug
2
12
Comm support
(New NACS)
1
13
Oring 117
1
Extender frame, kit and accessories are compatible
with all Gdivers IDMs, Neptune Space 2006 IDMs
onward, Raptor IDMs.
5!
!
Extender!Instruction!Manual!2016!
Rel!1.1!
!
Extender Product Options
(EXTENDER FRAME) - In the box
(EXTENDER KIT) – in the box
!
EXTENDER!INSTRUCTION!MANUAL!2016!
!
!
Extender!Instruction!Manual!2016!
Rel!1.1!
(SPACE EXTENDER) – in the box
7!
!
Extender!Instruction!Manual!2016!
Rel!1.1!
!
ASSEMBLY
STEP 1.
Parts 1 + 4 + 5 + 6 + 7 + 8
!
EXTENDER!INSTRUCTION!MANUAL!2016!
!
!
Extender!Instruction!Manual!2016!
Rel!1.1!
Look for
L and R indications on
Parts 7 and 8.
Small flap inside of the
Frame.
STEP 2.
CLICK!
Parts 2+3
