Oce em3521 Quick Manual

Welcome

Welcome

Thank you for purchasing the this machine.

This machine is equipped with an integrated printer controller that allows you
to print directly from Windows-compatible computers or Macintosh comput­ers.

This Quick Guide describes the printing functions, operations, usage, and
safety precautions of the printer controller. In order to ensure that this ma­chine is used efficiently, carefully read this manual before using the machine.
In order to ensure that this machine is used safely, carefully read “Installation
and Operation Precautions” in the User’s Guide [Copy Operations] before
using the machine.

The illustrations used in this Quick Guide may differ from the actual model.

Trademarks and copyright

- Netscape Communications, the Netscape Communications logo, Net-

scape Navigator, Netscape Communicator, and Netscape are trade­marks of Netscape Communications Corporation.

- Novell and Novell NetWare are registered trademarks of Novell, Inc.

- Microsoft, Windows, and Windows NT are registered trademarks of Mi-

crosoft Corporation.

- IBM is a registered trademark of International Business Machines, Inc.

- Apple, Macintosh, and Mac are registered trademarks of Apple Compu-

ter, Inc.

- Adobe, the Adobe logo, Acrobat, the Acrobat logo, PostScript, and the

PostScript logo are either registered trademarks or trademarks of Adobe
Systems Incorporated.

- Ethernet is a registered trademark of Xerox Corporation.

- PCL is a registered trademark of Hewlett-Packard Company Limited.

- All other product and brand names are trademarks or registered trade-

marks of their respective companies or organizations.

- This machine and Box Operator are based in part on the work of the In-

dependent JPEG Group.

- Compact-VJE

Copyright 1986-2003 VACS Corp.

®

- RC4

United States and/or other countries.

- RSA

BSAFE® is a registered trademark or trademark of RSA Security Inc. in
the United States and/or other countries.

is a registered trademark or trademark of RSA Security Inc. in the

®

is a registered trademark or trademark of RSA Security Inc. RSA

cm3521 x-1

Welcome

License information

This product includes RSA BSAFE Cryptographic software
from RSA Security Inc.

OpenSSL statement

OpenSSL license

Copyright © 1998-2000 The OpenSSL Project. All rights reserved.
Redistribution and use in source and binary forms, with or without modifica­tion, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice,
this list of conditions and the following disclaimer.

2. Redistributions in binary form must reproduce the above copyright no­tice, this list of conditions and the following disclaimer in the documen­tation and/or other materials provided with the distribution.

3. All advertising materials mentioning features or use of this software must
display the following acknowledgment:
“This product includes software developed by the OpenSSL Project for
use in the OpenSSL Toolkit. (http://www.openssl.org/)”

4. The names “OpenSSL Toolkit” and “OpenSSL Project” must not be used
to endorse or promote products derived from this software without prior
written permission. For written permission, please contact openssl­[email protected].

5. Products derived from this software may not be called “OpenSSL” nor
may “OpenSSL” appear in their names without prior written permission
of the OpenSSL Project.

6. Redistributions of any form whatsoever must retain the following ac­knowledgment:
“This product includes software developed by the OpenSSL Project for
use in the OpenSSL Toolkit (http://www.openssl.org/)”

THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT “AS IS” AND
ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIM­ITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FIT­NESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT
SHALL THE OpenSSL PROJECT OR ITS CONTRIBUTORS BE LIABLE FOR
ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CON­SEQENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCURE­MENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR
PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON
ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY,
OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY

x-2 cm3521

Welcome

WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.

This product includes cryptographic software written by Eric Young
([email protected]). This product includes software written by Tim Hud­son ([email protected]).

Original SSLeay license

Copyright © 1995-1998 Eric Young ([email protected]) All rights reserved.
This package is an SSL implementation written by Eric Young (eay@crypt­soft.com).
The implementation was written so as to conform with Netscapes SSL.
This library is free for commercial and non-commercial use as long as the fol­lowing conditions are aheared to. The following conditions apply to all code
found in this distribution, be it the RC4, RSA, Ihash, DES, etc., code; not just
the SSL code.
The SSL documentation included with this distribution is covered by the
same copyright terms except that the holder is Tim Hudson (tjh@crypt­soft.com).
Copyright remains Eric Young’s, and as such any Copyright notices in the
code are not to be removed. If this package is used in a product, Eric Young
should be given attribution as the author of the parts of the library used. This
can be in the form of a textual message at program startup or in documen­tation (online or textual) provided with the package.
Redistribution and use in source and binary forms, with or without modifica­tion, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the copyright notice, this list
of conditions and the following disclaimer.

2. Redistributions in binary form must reproduce the above copyright no­tice, this list of conditions and the following disclaimer in the documen­tation and/or other materials provided with the distribution.

3. All advertising materials mentioning features or use of this software must
display the following acknowledgement:
“This product includes cryptographic software written by Eric Young
([email protected])”
The word ‘cryptographic’ can be left out if the rouines from the library be­ing used are not cryptographic related.

4. If you include any Windows specific code (or a derivative thereof) from
the apps directory (application code) you must include an acknowledge­ment:
“This product includes software written by Tin Hudson (tjh@crypt­soft.com)”

THIS SOFTWARE IS PROVIDED BY ERIC YOUNG “AS IS” AND ANY EX­PRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AU-

cm3521 x-3

Welcome

THOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCI­DENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE
GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS
INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILI­TY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE
OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE.

The licence and distribution terms for any publically available version or de­rivative of this code cannot be changed. i.e. this code cannot simply be cop­ied and put under another distribution licence [including the GNU Public
Licence.]

Note

- This Quick Guide may not be reproduced in part or in full without permis-

sion.

- Information included in this Quick Guide is subject to change without no-

tice.

x-4 cm3521

Welcome

SOFTWARE LICENSE AGREEMENT

This package contains the following materials provided by Océ N.V. (Océ): software
included as part of the printing system, the digitally-encoded machine-readable
outline data encoded in the special format and in the encrypted form (“Font
Programs”), other software which runs on a computer system for use in conjunction
with the Printing Software (“Host Software”), and related explanatory written materials
(“Documentation”). The term “Software” shall be used to describe Printing Software,
Font Programs and/or Host Software and also include any upgrades, modified
versions, additions, and copies of the Software.

The Software is being licensed to you under the terms of this Agreement.

Océ grants to you a non-exclusive sublicense to use the Software and Doc­umentation, provided that you agree to the following:

1. You may use the Printing Software and accompanying Font Programs for
imaging to the licensed output de-vice(s), solely for your own internal
business purposes.

2. In addition to the license for Font Programs set forth in Section 1 (“Print­ing Software”) above, you may use Roman Font Programs to reproduce
weights, styles, and versions of letters, numerals, characters and sym­bols (“Typefaces”) on the display or monitor for your own internal busi­ness purposes.

3. You may make one backup copy of the Host Software, provided your
backup copy is not installed or used on any computer. Notwithstanding
the above restrictions, you may install the on any number of computers
solely for use with one or more printing systems running the Printing Soft­ware.

4. You may assign its rights under this Agreement to an assignee of all of
Licensee’s right and interest to such Software and Documentation (“As­signee”) provided you transfer to Assignee all copies of such Software
and Documentation Assignee agrees to be bound by all of the terms and
conditions of this Agreement.

5. You agree not to modify, adapt or translate the Software and Documen­tation.

6. You agree that you will not attempt to alter, disassemble, decrypt, re­verse engineer or decompile the Software.

7. Title to and ownership of the Software and Documentation and any re­productions thereof shall remain with Océ and its licensor.

8. Trademarks shall be used in accordance with accepted trademark prac­tice, including identification of the trademark owner’s name. Trademarks
can only be used to identify printed output produced by the Software.
Such use of any trademark does not give you any rights of ownership in
that trademark.

cm3521 x-5

Welcome

9. You may not rent, lease, sublicense, lend or transfer versions or copies
of the Software Licensee does not use, or Software contained on any un­used media, except as part of the permanent transfer of all Software and
Documentation as described above.

10. IN NO EVENT WILL Océ OR ITS LICENSOR BE LIABLE TO YOU FOR
ANY CONSEQUENTIAL, INCIDENTAL INDIRECT, PUNITIVE OR SPE­CIAL DAMAGES, INCLUDING ANY LOST PROFITS OR LOST SAVING,
EVEN IF Océ HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES, OR FOR ANY CLAIM BY ANY THIRD PARTY. Océ OR ITS LI­CENSOR DISCLAIMS ALL WARRANTIES WITH REGARD TO THE SOFT­WARE, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PAR­TICULAR PURPOSE, TITLE AND NON-INFRINGEMENT OF THIRD PAR­TY RIGHTS. SOME STATES OR JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTIAL, CONSEQUENTIAL OR
SPECIAL DAMAGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY
TO YOU.

11. Notice to Government End Users: The Software is a “commercial item,”
as that term is defined at 48 C.F.R.2.101, consisting of “commercial com­puter software” and “commercial computer software documentation,” as
such terms are used in 48 C.F.R. 12.212. Consistent with 48 C.F.R.

12.212 and 48 C.F.R. 227.7202-1 through 227.7202-4, all U.S. Govern­ment End Users acquire the Software with only those rights set forth
herein.

12. You agree that you will not export the Software in any form in violation of
any applicable laws and regulations regarding export control of any
countries.

x-6 cm3521

Welcome

Contents

Welcome

SOFTWARE LICENSE AGREEMENT ............................................... x-5

Contents ............................................................................................ x-7

About this quick guide ................................................................... x-10

User’s Guides ................................................................................x-10

Notations .......................................................................................x-10

Screen images in this quick guide ................................................x-10

Using this quick guide ...................................................................x-11

1 Overview

1.1 Printer controller ............................................................................... 1-1

Role of the printer controller .......................................................... 1-1

Available printer controller functions ............................................. 1-1

Machine modes .............................................................................. 1-2

Printing flow ................................................................................... 1-3

Flow of the computer faxing operation .......................................... 1-4

1.2 Operation environment .................................................................... 1-5

Compatible computers and operating systems ............................. 1-5

Compatible interfaces .................................................................... 1-6

1.3 Setting up the system ...................................................................... 1-8

To set up the printing system ........................................................ 1-8

2 Installing the printer driver

2.1 Printer drivers and supported operating systems ......................... 2-1

2.2 When used with Windows ................................................................ 2-2

Automatic installation using the installer ........................................ 2-3

To install the printer driver ............................................................. 2-4

Installing the printer driver using the Add Printer Wizard .............. 2-6

For Windows XP/Server 2003 ........................................................ 2-6

For Windows 98SE/Me/2000/NT 4.0 ............................................. 2-9

Installing the printer driver using Plug and Play ........................... 2-11

For Windows 98SE ....................................................................... 2-11

For Windows Me/2000 ................................................................. 2-12

For Windows XP/Server 2003 ...................................................... 2-13

Uninstalling the printer driver ....................................................... 2-14

2.3 When used with Macintosh ........................................................... 2-16

Installing the printer driver ........................................................... 2-16

For Mac OS X ............................................................................... 2-16

Selecting a printer ........................................................................ 2-18

cm3521 x-7

For Mac OS X ...............................................................................2-18

For Mac OS 9.2 .............................................................................2-21

Uninstalling the printer driver ........................................................2-23

For Mac OS X ...............................................................................2-23

For Mac OS 9.2 .............................................................................2-24

3 Setting up network printing

3.1 Overview of network functions ........................................................3-1

Network functions ...........................................................................3-1

Features of the network functions ..................................................3-2

Network connection methods that can be selected in each

Windows operating system ............................................................3-3

Network printing from a Windows operating system .....................3-3

Network printing in a NetWare environment ...................................3-4

3.2 Accessing Web Connection .............................................................3-5

To access Web Connection ............................................................3-5

Welcome

4 Various printing methods

4.1 Printing operations ............................................................................4-1

For Windows ...................................................................................4-1

Test printing ....................................................................................4-4

For Macintosh .................................................................................4-5

For Mac OS X .................................................................................4-5

For Mac OS 9.2 ...............................................................................4-6

4.2 Setting the printing functions ...........................................................4-7

Function list .....................................................................................4-7

Function overview ...........................................................................4-9

Orientation ......................................................................................4-9

Original Size and Output Size .......................................................4-10

Zoom (enlargement and reduction) ...............................................4-11

Input Tray (Paper Source) .............................................................4-12

Paper Type ....................................................................................4-12

Print Type (duplex printing/booklet printing) .................................4-13

Printing multiple pages on one page ............................................4-14

Stapling and hole punching ..........................................................4-15

Output Method (Job Management) ..............................................4-16

Sorting (Collating) and Classifying (Offset) ...................................4-16

Skip Blank Pages (saving paper) ..................................................4-17

Front Cover, Back Cover, and Transparency Interleave ...............4-17

Per Page Setting ...........................................................................4-18

Chapter .........................................................................................4-18

Overlay ..........................................................................................4-18

Watermark ....................................................................................4-19

x-8 cm3521

Welcome

Copy Protect ................................................................................ 4-19

Quality Adjustment ....................................................................... 4-20

Use Printer Fonts (substitute fonts) ............................................. 4-20

User Authentication ...................................................................... 4-20

Account Track .............................................................................. 4-21

5 Various settings

5.1 Print reports ...................................................................................... 5-1

To print ........................................................................................... 5-1

5.2 Printing on banner paper ................................................................. 5-3

Paper .............................................................................................. 5-3

Paper types .................................................................................... 5-3

Printer drivers and supported operating systems .......................... 5-3

Specifying printer driver settings ................................................... 5-3

To specify printer driver settings .................................................... 5-3

Printing ........................................................................................... 5-5

To print ........................................................................................... 5-5

6 Troubleshooting

6.1 Unable to Print .................................................................................. 6-1

6.2 Unable to specify desired settings or unable to print as

specified ............................................................................................ 6-3

6.3 Error message ................................................................................... 6-5

7 Appendix

7.1 Specifications ................................................................................... 7-1

7.2 Configuration page ........................................................................... 7-3

7.3 Font list .............................................................................................. 7-4

PCL font list .................................................................................... 7-4

PS font list ...................................................................................... 7-5

Demo page ..................................................................................... 7-6

cm3521 x-9

About this quick guide

This Quick Guide contains information for using the printing functions of the
printer controller. For details on the copy functions, scanning functions, box
functions, fax functions, and printer functions refer to the respective User’s
Guide.

This Quick Guide is aimed at users who already have a basic knowledge of
computer and copier operations. For Windows or Macintosh operating sys­tem and application operations, refer to the operation manual of the respec­tive product.

User’s Guides

The User’s Guides for this machine are divided by function and consist of the
following:

User’s guide Details

Welcome

Print Operations Quick Guide This guide describes the basic information of the printer

functions.

Print Operations This guide describes the detailed information of the printer

functions.
Read this guide when the necessary information is not de­scribed in the Print Operations Quick Guide.

Network Scanner Operations Read this guide when using this machine as a scanner.

Box Operations Read this guide when using this machine’s box functions.

Facsimile Operations Read this guide when using this machine’s fax functions.

Network Facsimile Operations Read this guide when using this machine’s network fax (In-

ternet fax, SIP fax, IP address fax) functions.

Notations

Product name

Integrated network controller Network controller

Printer controller, including this
machine, and printing system

Microsoft Windows Windows

Printing system

Screen images in this quick guide

Unless stated otherwise, the printer driver functions are described using the
printer driver for Windows XP.

x-10 cm3521

Welcome

Using this quick guide

Subject titles

Explains the operation
procedure.

Windows, dialog boxes,
icons, and function names
displayed on the screen
are enclosed in .

Button names displayed
on the screen are
enclosed in .

Contents displayed on
a screen.

Various Printing Methods

4 Various Printing Methods

4.1 Printing Operations

For Windows

Data can be printed from an applic ation.

Print jobs are specified from the application software.

1 Open the data in the application , “File”, and then cl ick “Pri nt”.

2 Check that the pri nter name has been selected.

If the printer is not selected, c lick the [

3 Specify the page range and the number of copies to print.

] and select the printe r.

4

Additional explanation
of the text is given.

Note

The Print dialog box differs d epending on the applicat ion.

35C-3 4-1

(The page shown above is an example only.)

cm3521 x-11

Welcome

x-12 cm3521

Overview

1Overview

1.1 Printer controller

The printer controller is a device for performing printing functions and net­work printing functions with this machine.

Role of the printer controller

The printer controller is built into the machine.

You can print from applications on the computer connected to the printing
system. When using this machine as a network printer, you can print from
applications on the computer.

1

Printing system

Machine

Printer
controller

Available printer controller functions

The printer controller provides the following functions.

- Printing from a computer (using the PCL printer driver or PS printer driver)

- Support of network protocols including TCP/IP, NetBEUI, IPX/SPX, and

AppleTalk

- Direct printing over a network using SMB (Windows), LPR, and IPP print-

ing

- Access to settings for this machine and the printer controller from a client

computer over the network (using a Web browser)

- Control of the number of pages printed (“User Authentication” and “Ac-

count Track” functions)

- Fax operations using a computer (fax transmission)

Computer

2

Note

To perform fax operations, optional fax kit cm3500210 is required.

cm3521 1-1

1

Power Save

Box

Access

ABC DEF

JKLGHI MNO

TUVPQRS WXYZ

Mode Memory

Mode Check

Utility/
Counter

Fax

Scan

Copy

Reset

Interrupt

Power

Stop

Proof Copy

Start

Data

Main Power

Help

Accessibility

Enlarge Display

Contrast

Overview

Machine modes

The printer driver settings are mainly set using a computer, however, the font
list can be printed, and the printer controller settings and default print set­tings can be set using the control panel of this machine. In addition, fax and
scanning operations can be used by switching the mode.

To switch between modes, press the mode keys on the control panel.

[Copy]

This machine can be used as a copier.

[Scan]

This machine can be used as a scanner.

[Fax]

This machine can be used for faxing.

[Box]

This machine can be used to store jobs and as a document folder for for­warding data to a computer over the network.

2

Note

You can use this machine as a printer in all modes.

Change the default print settings in the Utility mode.

1-2 cm3521

Overview

1

Printing flow

When using this printing system as a printer, the flow of the main process is
described below.

Print commands transmitted from the application are received by the printer
driver.

Data is transmitted to this machine over a parallel interface (IEEE 1284) when
this machine is used as a local printer, over a USB interface when this ma­chine is used as a USB printer, or over an Ethernet interface (TCP/IP, IPX/
SPX or AppleTalk) when this machine is used as a network printer. The data
is then delivered from this machine to the printer controller, which performs
image rasterization (development of output characters and images to bitmap
data). Finally, this data is printed from this machine.

2

Note

The parallel and USB interfaces cannot be used simultaneously.

Computer

Used as a local

printer

Application Application Application

Printer driver Printer driver Printer driver

Parallel interface

(IEEE 1284)

Print

PS/PCL processing (rasterizing)

Used as a USB

printer

USB

Machine

Printer controller

Used as a

network printer

Ethernet (TCP/IP, IPX/

SPX, or AppleTalk)

Original documents can be scanned in the copy function or network scan
function while this machine is operating as a printer.
To use this machine as a copier, press the [Copy] key on the control panel.

cm3521 1-3

1

Overview

When a print job is received during copying, the data is stored in the memory
of this machine. When copying is complete, the print job is automatically
printed.

Flow of the computer faxing operation

Conventionally, faxes are sent by loading an original into a fax machine and
sending it.

With computer faxing, you can send a fax directly from your computer with­out using any paper.

Transmission commands sent from the application are received by the print­er driver.

Data is transmitted to this machine over a parallel interface (IEEE 1284) when
this machine is used as a local printer, over a USB interface when this ma­chine is used as a USB printer, or over an Ethernet interface (TCP/IP, IPX/
SPX or AppleTalk) when this machine is used as a network printer. The data
is then delivered from this machine to the printer controller, which performs
image rasterization (development of output characters and images to bitmap
data). Finally, this data is stored in the memory of this machine and transmit­ted like a conventional fax job.

Computer

Used as a local

printer

Application Application Application

Printer driver Printer driver Printer driver

Parallel interface

(IEEE 1284)

Print

PS/PCL processing (rasterizing)

Used as a USB

printer

USB

Machine

Printer controller

Used as a

network printer

Ethernet (TCP/IP, IPX/

SPX, or AppleTalk)

1-4 cm3521

Overview

1.2 Operation environment

The system requirements for using this printing system and the interfaces
used for connection are explained below.

Compatible computers and operating systems

Check that the computer being connected meets the following conditions.

Windows

Item Operating environment

Operating System Windows 98 Second Edition, Windows Me, Windows NT 4.0

(Service Pack 6a or later), Windows 2000 Professional (Serv­ice Pack 4 or later), Windows XP Home Edition/Windows XP
Professional (Service Pack 2 or later), or Windows Server 2003

Processor Pentium or higher

Memory Capacity recommended for the operating system

With sufficient memory resources in the operating system and
application being used

1

Drive CD-ROM

Web Browser (when using Web
Connection)

Microsoft Internet Explorer 6 or later recommended (JavaS­cript enabled, Cookies enabled)
Microsoft XML Parser MSXML3.X must be installed when us­ing Internet Explorer 5.5.
Netscape Navigator 7.02 or later (JavaScript enabled, Cook­ies enabled)
Macromedia
sion 7.0 or later plugin is required.)

®

Flash® (If “Flash” is selected in View Mode, ver-

Macintosh

Item Operating environment

Operating System Mac OS 9.2, Mac OS X 10.2, Mac OS X 10.3, or Mac OS X

10.4

Processor PowerPC, Intel Processor

Memory Capacity recommended for the operating system

Drive CD-ROM

Web Browser (when using Web
Connection)

Netscape Navigator 7.02 or later (JavaScript enabled, Cook­ies enabled)
Macromedia
sion 7.0 or later plugin is required.)

®

Flash® (If “Flash” is selected in View Mode, ver-

cm3521 1-5

1

Overview

Compatible interfaces

The various interfaces that can be used to connect this printing system to a
computer are described below.

Ethernet interface

Connect when using this printing system as a network printer.

Supports 10Base-T and 100Base-TX standards. In addition, the Ethernet in­terface supports the TCP/IP (LDP/LPR, peer-to-peer), IPX/SPX (NetWare)
and AppleTalk (EtherTalk).

Parallel interface (optional)

Connect when using this printing system as a local printer.

A computer running Windows and an IEEE 1284 parallel cable are required
for connection. Use a parallel cable that uses a terminal with an Amphenol
36-pin male connector.

The parallel interface supports the compatible, nibble, and ECP modes.

USB interface (optional)

Connect when using this printing system as a network printer.

The USB interface can be connected to a computer running Windows. A
USB cable is required for connection. Use a type A (4 pin, male) or type B (4
pin, male) USB cable. A USB cable measuring 3 meters or less is recom­mended.

The parallel and USB interfaces cannot be used simultaneously. You can
switch the interfaces in the administrator mode.

1-6 cm3521

Overview

1

Connection diagram

The printer cables can be connected to each port at the back of this ma­chine.

Machine (rear view)

USB
cable

Parallel
cable

USB port

Parallel
port

Ethernet
(10Base-T or
100Base-TX)

cm3521 1-7

1

1.3 Setting up the system

In order to use this printing system, it must first be set up.

Setup consists of connecting this machine to a computer and installing the
printer driver onto the computer being used.

To set up the printing system

Setup of the printing system as described below.

1 Connect this machine to a computer. (Refer to “Compatible interfaces”

on page 1-6.)

2 Install the printer driver. (Refer to “Installing the printer driver” on

page 2-1.)

3 When using a network connection, set up the network. (Refer to “Set-

ting up network printing” on page 3-1.)

Overview

4 Check the setup by printing a test page. (Refer to “Test printing” on

page 4-4.)

5 Install the screen fonts.

– The User Software CD-ROM and the PostScript Printer Driver CD-

ROM contain the Latin TrueType fonts as screen fonts.

– Install the screen fonts after adding the operating system standard

fonts.
– For details, refer to Help of the operating system.
– The CD-ROM “Screenfont” or “Screenfonts” folder contains the

screen fonts.
– The Macintosh fonts are compressed. Install the fonts after decom-

pressing them.

Installation of the printer driver may differ depending on the connection
method used with this machine in addition to the operating system of the
computer and the type of printer driver being used.

!

Detail

For details on connecting this machine to a computer, refer to “Compat­ible interfaces” on page 1-6.

1-8 cm3521

Overview

1

2

Note

To update an existing printer driver, delete the existing printer driver first.
For details, refer to “Uninstalling the printer driver” on page 2-14 and
page 2-23.

As necessary, set the interface timeout settings and parallel interface
mode (Compatible, Nibble, or ECP) in the Utility mode on the control pan­el. For details, refer to “Printer Settings in Administrator Mode” on the Us­er’s Guide [Print Operations].

When using the parallel or USB local port, you must select the port being
used. For details, refer to “IEEE 1284/USB” on the User’s Guide [Print
Operations].

cm3521 1-9

1

Overview

1-10 cm3521

Installing the printer driver

2 Installing the printer driver

2.1 Printer drivers and supported operating systems

In order to use this printing system, the printer driver must be installed. The
printer driver is a program that controls the processing of data for output. In­stall the printer driver onto the computer from the provided CD-ROM.

The printer drivers included on the CD and the supported computer operat­ing systems are listed below. Install the required printer driver.

2

Printer driver Page description

language

PCL Driver PCL

(PCL XL)

PostScript Driver PostScript 3

Emulation

PostScript PPD Driver Windows 98 Second Edition, Windows Me

* The User Software CD-ROM contains the PCL printer driver, and the PostScript Printer Driver

CD-ROM contain the PostScript driver.

Supported operating systems

Windows 98 Second Edition, Windows Me,
Windows NT 4.0 (Service Pack 6a),
Windows 2000 Professional (Service Pack 4 or
later), Windows XP Home Edition/Professional
(Service Pack 2 or later), and Windows Server
2003

Windows NT 4.0 (Service Pack 6a),
Windows 2000 Professional (Service Pack 4 or
later), Windows XP Home Edition/Professional
(Service Pack 2 or later), Windows XP Profes­sional x64, Windows Server 2003, and Win­dows 2003, and Windows Server 2003 x64

Mac OS 9.2 or later, Mac OS X 10.2, Mac OS X

10.3, and Mac OS X 10.4

cm3521 2-1

2

2.2 When used with Windows

The installation procedure for the Windows printer driver differs depending
on how this machine is connected to the computer and depending on which
printer driver is used. The installation method also differs depending on the
version of Windows that you are using. Refer to the table below for the ap­propriate procedure for installing the printer driver on your computer.

Printer driver Connection method Refer to

Installing the printer driver

PCL Driver
PostScript
Driver

PCL Driver
PostScript
Driver
PostScript PPD
Driver

All connection methods “Automatic installation using the installer” on

page 2-3

Network connection “Installing the printer driver using the Add Printer

Wizard” on page 2-6
“For Windows 98SE/Me/2000/NT 4.0” on
page 2-9
“For Windows XP/Server 2003” on page 2-6

Parallel connection “Installing the printer driver using Plug and Play”

on page 2-11
“For Windows 98SE” on page 2-11
“For Windows Me/2000” on page 2-12
“For Windows XP/Server 2003” on page 2-13

“Installing the printer driver using the Add Printer
Wizard” on page 2-6
“For Windows 98SE/Me/2000/NT 4.0” on
page 2-9
“For Windows XP/Server 2003” on page 2-6

USB connection “Installing the printer driver using Plug and Play”

on page 2-11
“For Windows 98SE” on page 2-11
“For Windows Me/2000” on page 2-12
“For Windows XP/Server 2003” on page 2-13

2

Note

For details on installing the printer driver in a network environment, refer
to “Setting up network printing” on page 3-1. Because it is necessary to
specify other network settings in advance when installing the printer driv­er using a network connection, install it using a local connection at this
time.

To install the printer driver under Windows XP, Windows Server 2003,
Windows 2000, or Windows NT 4.0, log on using a user name that is au­thorized by the administrator.

To connect this machine to a computer using a parallel connection or a
USB connection, the optional local interface kit is required.

2-2 cm3521

Installing the printer driver

Automatic installation using the installer

With the installer, this machine is detected to determine whether it is con­nected by USB or is on the same TCP/IP network as the computer, and then
the required printer driver is automatically installed. You can also manually
specify the printer driver to be installed.

2

Note

Since this machine is automatically detected with a network connection,
be sure to set the IP address of this machine before connecting it. For de­tails on specifying the settings, refer to “Setting the IP Address for This
Machine” on the User’s Guide [Print Operations].

When installing on Windows NT 4.0, 2000, XP, or Server 2003, adminis­trator permissions are required.

If the wizard starts up in order to add new hardware with a USB or parallel
connection, click [Cancel].

2

For IPP printing, it is not necessary to install the printer driver at this time
since IPP printing setup is performed when the printer driver is installed.
For further details on IPP printing, refer to “IPP Printing (Windows 2000/
XP/Server 2003)” on the User’s Guide [Print Operations].

Installer operating environment

Item Operating environment

Operating System Windows 98 Second Edition, Windows Me, Windows NT 4.0 (Serv-

ice Pack 6a or later)*, Windows 2000 Professional (Service Pack 4 or
later), Windows XP Home Edition/Windows XP Professional (Service
Pack 2 or later), or Windows Server 2003

Processor Pentium 300 MHz or higher recommended

Memory 64 MB or more (128 MB or more recommended)

* With Windows NT 4.0, in order to install a machine that is connected directly to a network using

the TCP/IP protocol, Windows TCP/IP Printing Services must first be installed on the computer
being used.

cm3521 2-3

2

Installing the printer driver

To install the printer driver

1 Insert the Windows printer driver CD-ROM into the computer’s CD-

ROM drive.

– For the User Software CD-ROM (for a PCL driver), check that the

installer starts up, and then continue with step 2.
– For the PostScript Printer Driver CD-ROM (Win) (for a PS driver),

double-click “UserInst.exe” in the Driver folder on the CD-ROM,

and then continue with step 3.

2 Click “Printer Install”.

The installation of the printer driver starts.

3 Click the [AGREE] button if you agree with all terms and conditions of

the license agreement.

– If you do not agree with the terms and conditions of the license

agreement, the software cannot be installed.
– You can change the display language of the installer box in the low-

er-left corner.

4 When the setup selection dialog box appears, click the “Install printers/

MFPs” button, and then click the [Next] button.

The connected printers and copiers are detected.

2-4 cm3521

Installing the printer driver

5 Select this machine and proceed with the installation.

Follow the on-screen instructions to complete the installation.

2

– If the connection of this machine cannot be recognized or for par-

allel connections, the machine will not be listed. When this occurs,
select “Specify the Printer/MFP Except for the Above. (IP Address,
Host Name)”, and then specify this machine directly.

cm3521 2-5

2

Installing the printer driver

Installing the printer driver using the Add Printer Wizard

2

Note

For IPP printing, it is not necessary to install the printer driver at this time
since IPP printing setup is performed when the printer driver is installed.

For further details on IPP printing, refer to “IPP Printing (Windows 2000/
XP/Server 2003)” on the User’s Guide [Print Operations].

2

Note

For details on installing the printer driver in a network environment, refer
to “Setting up network printing” on page 3-1. Because it is necessary to
specify other network settings in advance when installing the printer driv­er using a network connection, install it using a local connection at this
time.

For Windows XP/Server 2003

1 Insert the Windows printer driver CD-ROM into the computer’s CD-

ROM drive.

– PCL Driver: User Software CD-ROM
– PostScript Driver: PostScript Printer Driver CD-ROM

2 Click the [Start] button, and then click “Printers and Faxes”.

– If “Printers and Faxes” does not appear in the Start menu, open the

Control Panel from the Start menu, select “Printers and Other Hard-

ware”, and then select “Printers and Faxes”.

2-6 cm3521

Installing the printer driver

3 For Windows XP, click “Add a printer” on the “Printer Tasks” menu.

– For Windows Server 2003, double-click the “Add Printer” icon.

Windows XP Windows Server 2003

The Add Printer Wizard starts up.

2

4 Click the [Next] button.

5 Select “Local printer attached to this computer”, and then click the

[Next] button.

– Clear the “Automatically detect and install my Plug and Play print-

er” check box.

6 The Select Printer Port dialog box appears. Select “LPT1” here, and

then click the [Next] button.

cm3521 2-7

2

Installing the printer driver

7 Click the [Have Disk] button.

8 Click the [Browse] button.

9 Specify the folder on the CD-ROM that contains the printer driver for

the operating system that you are using, and then click the [OK] button.

– PCL Driver: User Software CD-ROM “Driver\35C-3” folder
– PostScript Driver: PostScript Printer Driver CD-ROM

“Driver\35C-3” folder

10 Click the [OK] button.

– The “Printers” list appears.

11 Click the [Next] button.

12 Follow the on-screen instructions.

– When the Digital Signature message appears, click the [Continue]

button.
– When using a network connection, perform a test print after the net-

work settings have been specified.

13 When installation is complete, make sure that the icon of the installed

printer appears in the Printers and Faxes window.

14 Remove the CD-ROM from the CD-ROM drive.

This completes the printer driver installation.

2-8 cm3521

Installing the printer driver

For Windows 98SE/Me/2000/NT 4.0

1 Insert the Windows printer driver CD-ROM into the computer’s CD-

ROM drive.

– PCL Driver: User Software CD-ROM
– PostScript Driver: PostScript Printer Driver CD-ROM

2 Click the [Start] button, point to “Settings”, and then click “Printers”.

The Printers window appears.

3 Double-click the “Add Printer” icon.

The Add Printer Wizard starts up.

4 Follow the on-screen instructions.

5 On the screen for selecting the printer connection, select “Local Print-

er”.

2

6 Click the [Next] button.

7 Click the [Have Disk] button.

8 Click the [Browse] button.

cm3521 2-9

2

Installing the printer driver

9 Specify the directory on the CD-ROM that contains the printer driver for

the operating system that you are using, and then click the [OK] button.

– For Windows 98SE/Me

PCL driver: User Software CD-ROM “Driver\35C-3” folder

PostScript PPD driver: PostScript Printer Driver CD-ROM

“Driver\PS-PPD” folder
– For Windows 2000

PCL driver: User Software CD-ROM“Driver\35C-3” folder

PostScript driver: PostScript Printer Driver CD-ROM

“Driver\35C-3” folder
– For Windows NT 4.0

PCL driver: User Software CD-ROM “Driver\35C-3” folder

PostScript driver: PostScript Printer Driver CD-ROM

“Driver\35C-3” folder

10 Click the [OK] button.

The “Printers” list appears.

11 Click the [Next] button.

12 Specify the connection port. Select “LPT1” here.

13 Follow the on-screen instructions.

– When using a network connection, perform a test print after the net-

work settings have been specified.

14 When installation is complete, make sure that the icon of the installed

printer appears in the Printers window.

2-10 cm3521

Installing the printer driver

15 Remove the CD-ROM from the CD-ROM drive.

This completes the printer driver installation.

Installing the printer driver using Plug and Play

For Windows 98SE

1 After using a parallel cable or a USB cable to connect this machine to

a computer, turn on the computer.

– Do not disconnect or connect the cable while the computer is start-

ing up.

2 Insert the Windows printer driver CD-ROM into the computer’s CD-

ROM drive.

– PCL Driver: User Software CD-ROM
– PostScript Driver: PostScript Printer Driver CD-ROM

2

3 Turn the main power of this machine on.

The Add New Hardware Wizard starts up.

4 Click the [Next] button.

5 Select “Search for the best driver for your device (Recommended)”,

and then click the [Next] button.

6 Select “Specify a location”, and then click the [Browse] button.

7 Specify the folder on the CD-ROM that contains the printer driver for

the operating system that you are using, and then click the [OK] button.

– PCL Driver: User Software CD-ROM “Driver\35C-3” folder
– PostScript PPD driver: PostScript Printer Driver CD-ROM

“Driver\PS-PPD” folder

8 Click the [Next] button, and then follow the on-screen instructions.

If using a parallel connection, proceed to step 10.

9 The Add New Hardware Wizard dialog box appears again. Repeat

steps 4 through 8.

10 When installation is complete, make sure that the icon of the installed

printer appears in the Printers window.

11 Remove the CD-ROM from the CD-ROM drive.

This completes the printer driver installation.

cm3521 2-11

2

Installing the printer driver

For Windows Me/2000

1 After using a parallel cable or a USB cable to connect this machine to

a computer, turn on the computer.

– Do not disconnect or connect the cable while the computer is start-

ing up.

2 Insert the Windows printer driver CD-ROM into the computer’s CD-

ROM drive.

– PCL Driver: User Software CD-ROM
– PostScript Driver: PostScript Printer Driver CD-ROM

3 Turn the main power of this machine on.

– For Windows Me

The Add New Hardware Wizard starts up.
– For Windows 2000

The Found New Hardware Wizard starts up.

4 Select “Search for a suitable driver for my device (recommended)” (for

Windows Me, select “Automatic search for a better driver (Recom­mended)”), and then click the [Next] button.

5 For Windows 2000, select “Specify a location”, and then click the

[Next] button.
For Windows Me, select “Specify a Location”, and then click the
[Browse] button.

6 Specify the folder on the CD-ROM that contains the printer driver for

the operating system that you are using, and then click the [OK] button.
Printer drivers that can be selected:

– For Windows Me

PCL driver: User Software CD-ROM “Driver\35C-3” folder

Postscript PPD: PostScript Printer Driver CD-ROM

“Driver\PS-PPD” folder
– For Windows 2000

PCL driver: User Software CD-ROM “Driver\35C-3” folder

PostScript driver: PostScript Printer Driver CD-ROM

“Driver\35C-3” folder

7 Click the [OK] button (for Windows Me, click the [Next] button), and

then follow the on-screen instructions.

8 Click the [Finish] button.

2-12 cm3521

Installing the printer driver

9 When installation is complete, make sure that the icon of the installed

printer appears in the Printers window.

10 Remove the CD-ROM from the CD-ROM drive.

This completes the printer driver installation.

For Windows XP/Server 2003

1 After using a parallel cable or a USB cable to connect this machine to

a computer, turn on the computer.

– Do not disconnect or connect the cable while the computer is start-

ing up.

2 Insert the Windows printer driver CD-ROM into the computer’s CD-

ROM drive.

– PCL Driver: User Software CD-ROM
– PostScript Driver: PostScript Printer Driver CD-ROM

2

3 Turn the main power of this machine on.

The Found New Hardware Wizard starts up.
If the Add New Hardware Wizard does not appear, turn the power of
this machine off, then on again.
When turning the power off, then on again, be sure to turn the sub­power switch off first, then the main power switch. In addition, wait at
least 10 seconds before turning the power on again; otherwise, this
machine may not function properly.

4 Select “Install from a list or specific location (Advanced)”, and then

click the [Next] button.

5 Under “Search for the best driver in these locations”, select “Include

this location in the search”, and then click the [Browse] button.

6 Depending on the operating system and printer driver that you are us-

ing, specify the folder on the CD-ROM that contains the printer driver,
and then click the [OK] button.

– PCL driver: User Software CD-ROM “Driver\35C-3” folder
– PostScript driver: PostScript Printer Driver CD-ROM

“Driver\35C-3” folder

7 Click the [Next] button, and then follow the on-screen instructions.

– When the Digital Signature dialog box appears, click the [Continue]

button.

cm3521 2-13

2

Installing the printer driver

8 Click the [Finish] button.

9 When installation is complete, make sure that the icon of the installed

printer appears in the Printers and Faxes window.

10 Remove the CD-ROM from the CD-ROM drive.

This completes the printer driver installation.

Uninstalling the printer driver

If it becomes necessary to delete the printer driver, for example, when you
want to reinstall the printer driver, follow the procedure below to delete the
driver.

1 For Windows 98SE/Me/2000/NT 4.0, click the [Start] button, point to

“Settings”, and then click “Printers”.
For Windows XP/Server 2003, click the [Start] button, and then click
“Printers and Faxes”.

– If “Printers and Faxes” does not appear in the Start menu, open the

Control Panel from the Start menu, select “Printers and Other Hard-

ware”, and then select “Printers and Faxes”.

2 In the Printers window (for Windows XP/Server 2003, Printers and Fax-

es window), select the icon of the printer that you want to delete.

3 Press the [Delete] key on the computer keyboard to delete the printer

driver.

4 Follow the on-screen instructions.

When the printer driver has been deleted, the printer icon will disappear
from the Printers window (for Windows XP/Server 2003, Printers and
Faxes window).
For Windows 98 Second Edition/Me/NT 4.0, this completes the unin­stallation procedure.
For Windows 2000/XP/Sever 2003, delete the driver from the server
properties.

5 Click the “File” menu, and then click “Server Properties”.

6 Click the Driver tab.

7 Select the printer driver to be deleted from the Installed Printer Drivers

list, and then click [Delete].

8 On the Deletion Confirmation dialog box, click the [Yes] button.

2-14 cm3521

Installing the printer driver

9 Close the Print Server Properties dialog box and Printers window (for

Windows XP/Server 2003, “Printers and Faxes” window).

10 Restart the computer.

This completes the uninstallation procedure.

2

Note

Even if the printer driver is deleted using the method described above,
the model information file will remain in the computer. Therefore, the driv­er may not be able to be overwritten when reinstalling the same version
of the printer driver. When installing the same version of the printer driver,
be sure to also delete the files described below.

Check the “C:\WINDOWS\system32\spool\drivers\w32x86” folder and
delete the folder of the corresponding model if it is available. If the PCL
driver and PostScript driver are both installed, the model information of
both drivers is deleted. If one driver is remaining, do not delete it.

2

Delete the “oem*.inf” and “oem*.PNF” files in the “C:\WINDOWS\inf”
folder. (The asterisk (*) in the file name displays a number, and the
number varies according to the environment of the computer.) Before de­leting the files, open the INF file, check that the model name is described
in the last several lines, and then check that the file of the corresponding
model is available.

The PNF file is the same number as the INF file.

cm3521 2-15

2

2.3 When used with Macintosh

The installation procedure for the Macintosh printer driver differs depending
on the Mac OS version and printer driver being used. Refer to the table below
for the appropriate procedure for installing the printer driver on your Macin­tosh computer.

Mac OS Printer driver Refer to

Installing the printer driver

Mac OS X 10.2,
Mac OS X 10.3, and
Mac OS X 10.4

Mac OS 9.2 or later PostScript PPD “Selecting a printer” on page 2-18

Installing the printer driver

For Mac OS X

PostScript PPD “Installing the printer driver” on page 2-16

1 Turn the Macintosh computer on.

2 Insert the Macintosh printer driver CD-ROM into the Macintosh com-

puter’s CD-ROM drive.

– Quit all running applications that may have started when the Mac-

intosh computer was turned on.

3 Open the “OS10_2_X” or “OS10_3_X” folder from “English”—“Driver”

on the CD-ROM.

4 Select the Mac OS version being used, and then copy the drive file onto

the desktop.
Mac OS X 10.2: GENERIC_35C-3_102.pkg
Mac OS X 10.3: GENERIC_35C-3_103.pkg
Mac OS X 10.4: GENERIC_35C-3_103.pkg

5 Double-click the file copied onto the desktop.

– Enter the requested administrator’s name and password.
– For the administrator’s name and password, ask your network ad-

ministrator.
– To quit the installation, click the [Cancel] button.

6 Click the [Continue] button and follow the on-screen instructions until

the Installation dialog box appears.

2-16 cm3521

Installing the printer driver

7 On the Installation dialog box, click the [Install] button.

– From the second time the printer driver is installed and thereafter,

the [Install] button may appear as the [Upgrade] button.

The printer driver is installed onto the Macintosh computer. When in­stallation is complete, a message appears.

2

8 Click the [Close] button.

This completes the printer driver installation.
Next, select the printer.

cm3521 2-17

2

Installing the printer driver

Selecting a printer

2

Note

If connecting using AppleTalk, the AppleTalk settings on this machine
must be specified. For specifying the AppleTalk settings, refer to “Print­ing With Macintosh” on the User’s Guide [Print Operations].

If connecting using Bonjour with Mac OS X 10.4, the Bonjour settings
must be specified on this machine. For specifying the Bonjour settings,
refer to “Printing With Macintosh” on the User’s Guide [Print Operations].

If connecting using Rendezvous with Mac OS X 10.3, the Bonjour set­tings must be specified on this machine. For specifying the Bonjour set­tings, refer to “Printing With Macintosh” on the User’s Guide [Print
Operations].

For Mac OS X

After connecting this machine to a Macintosh computer, it can be used as a
printer by selecting it in Print Center or the Printer Setup Utility as the printer
to be used.

1 Open Print Center or Printer Setup Utility, located in “Applications”—

“Utilities” of “Hard Disk”.

2 When the Add Printer dialog box appears, click the [Add] button. When

the printer list appears, click the [Add] button.

– For Mac OS X 10.4, proceed to step 3.
– For Mac OS X 10.2 and Mac OS X 10.3, proceed to step 4.
– If usable printers have already been set up, the Add Printer dialog

box does not appear.

3 If this machine appears as a printer of a Bonjour connection, select

“GENERIC” from the “Print Using” drop-down list, select “35C-3/30C­1” in the model list, and then click the [Add] button.

– If the selected printer is registered in the printer list, this completes

the setting procedure.

2-18 cm3521

Installing the printer driver

– When connecting with AppleTalk and this machine does not appear

as a printer, click the [More Printers] button, and then proceed to
step 4.

2

4 Select the applicable connection method and printer name.

– To specify an AppleTalk zone for an AppleTalk connection, select

“Local AppleTalk Zone”.

– When “IPP” is selected as the protocol in IP Printer, the text box for

entering the queue name appears.
For Mac OS 10.3, leave the queue name text box empty.
For Mac OS 10.4, enter “ipp” in the queue name text box.

5 Select “GENERIC” from the “Printer Model” drop-down list.

cm3521 2-19

2

Installing the printer driver

6 Select “35C-3/30C-1”, and then click the [Add] button.

– The selected printer is registered in the printer list.

2-20 cm3521

Installing the printer driver

For Mac OS 9.2

After connecting this machine, it can be used as a printer by selecting “Post­Script printer” under “Chooser” and by specifying the printer description
(PPD) file.

First, copy the printer description (PPD) file onto the Macintosh computer.

1 Insert the Macintosh printer driver CD-ROM into the Macintosh com-

puter’s CD-ROM drive.

2 Open the “OS 9_x” folder in “English”—“Driver” on the CD-ROM.

3 Select PPD file “35C-3UVxxx.ppd”, and then copy it into the “Printer

Descriptions” folder in “System Folder”—“Extensions” of “Hard Disk”.

– Next, select a printer.

The printer driver can use a standard Macintosh LaserWriter.

2

4 On the Apple menu, click “Chooser”.

5 Make sure that “AppleTalk” is set to “Active”, and then click the “La-

serWriter” icon.

6 From the “Select a PostScript Printer” list, click the applicable printer

for the printing system, and then click the [Create] button.

– If a different PPD file has already been selected, click the [Setup]

button, and then click the [Select PPD] button from the screen that
is already displayed.

The PostScript printer description (PPD) file selection screen appears.

cm3521 2-21

2

Installing the printer driver

7 Select the applicable PPD file, and then click the [Select] button or the

[Open] button.

The setting screen for adding Options appears.

8 Select the option that is installed on this machine from Options In-

stalled 1 and Options Installed 2.

9 Click the [OK] button.

The Chooser window appears again.

10 Close the Chooser window.

2-22 cm3521

Installing the printer driver

Uninstalling the printer driver

If it becomes necessary to delete the printer driver, for example, when you
want to reinstall the printer driver, follow the procedure below to delete the
driver.

2

Note

Quit all running applications that may have started when the Macintosh
computer was turned on.

For Mac OS X

1 Open Print Center or Printer Setup Utility, located in “Applications”—

“Utilities” of “Hard Disk”.

2 Select the name of the printer to be deleted, and then click the [Delete]

button.

2

The selected printer is deleted.

3 Close the printer list.

4 Drag the following file, which is located in “Library”—“Printers”—

“PPDs”—“Contents”—“Resources”—“en.lproj” of “Hard Disk”, to the
“Trash” icon.

– “GENERIC 35C-3.gz”

5 Delete the unnecessary files from “Library”—“Printers”.

6 For Mac OS 10.3 and Mac OS 10.4, drag the “***35c-3” file, which is

located in “Library”—“Printers”—“GENERIC”—“filter”, and the follow­ing files, which are located in “Library”—“Printers”—“GENERIC”—
“PDEs”, to the “Trash” icon.

– GENERIC 35C-3 Finishing.plugin
– GENERIC 35C-3 ImageLayout.plugin
– GENERIC 35C-3 Security.plugin
– GENERIC 35C-3 Setup.plugin

7 For Mac OS 10.2, drag the following files, which are located in “Li-

brary”—“Printers”—“PPD Plugins”, to the “Trash” icon.

– GENERIC 35C-3 Finishing.plugin
– GENERIC 35C-3 ImageLayout.plugin
– GENERIC 35C-3 Security.plugin
– GENERIC 35C-3 Setup.plugin

cm3521 2-23

2

Installing the printer driver

Enter “/usr” in “Go”-“Go to Folder” to move to the “/usr” folder, and
then drag the “***35c-3” data, which is located in “libexec”-“cups”-“fil­ter”, to the “Trash” icon.

8 Restart the Macintosh computer.

This completes the uninstallation procedure.

For Mac OS 9.2

1 Drag PPD file “35C-3UVxxx.ppd”, which is located in “System Fold-

er”—“Extensions”—“Printer Descriptions” of “Hard Disk”, to the
“Trash” icon.

The related printer driver files are deleted.

2 Restart the Macintosh computer.

This completes the uninstallation procedure.

2-24 cm3521

Setting up network printing

3 Setting up network printing

3.1 Overview of network functions

Network functions

By connecting this machine to a network through the Ethernet port, this
printing system can be used as a network printer.

Printing system

This machine

Ethernet

Network

3

Hub

This printing system supports 10Base-T and 100Base-TX standards. In ad­dition, the Ethernet interface supports the TCP/IP (LDP/LPR, IPP, SMB), Net­BEUI (SMB), IPX/SPX (NetWare), and AppleTalk (EtherTalk) protocols.

2

Note

When setting up the network, the administrator password is required to
enter Administrator mode.

Ask the administrator of this machine for the administrator password.

cm3521 3-1

3

Setting up network printing

Features of the network functions

This printing system is equipped with the following network functions to flex­ibly support various network environments.

- Automatic selection of 10Base-T or 100Base-TX (Fast Ethernet)

- Obtains the IP address automatically from DHCP or BOOTP

- Printing with SMB printing (Windows 98SE/Me/2000/XP/Server 2003)

You can print in Windows 98SE, Windows Me, Windows 2000, Windows
XP, or Windows Server 2003 using SMB.

- Printing with LPR printing (Windows NT 4.0/2000/XP/Server 2003)

You can print with LPD/LPR using Windows NT 4.0, Windows 2000, Win­dows XP, or Windows Server 2003. Windows 98SE and Windows Me
cannot be used.
LPR (Line Printer Request): This print request system can be used under
Windows NT 4.0, Windows 2000, Windows XP, or Windows Server 2003.
Enter the queue name as [Print].

- Printing with Port 9100 (Windows 98SE/Me/2000/XP/Server 2003)

You can print (Raw print) using Port 9100 under Windows 98 Second Edi­tion, Windows Me, Windows 2000, Windows XP, or Windows Server

2003.
When using a Port 9100 connection under Windows 98 Second Edition
or Windows Me, it may be necessary to install the Peer to Peer Printing
Tool.
To obtain the Peer to Peer Printing Tool, consult the dealer where you
purchased this machine.

- Supports Novell NetWare Pserver and Rprinter (Nprinter)

- Supports the Novell NetWare print server functions and supports both

bindery mode and Novell Directory Service (NDS)

With NetWare

The Novell NetWare 4.x–6 print server functions are supported.

You can connect this printing system to a network using Novell NetWare 4.x–
6 as the network operating system and send print jobs from the client to the
print server (network controller). The three modes supported are as follows:

- Nprinter

- Pserver

- NDS/NDPS

2

Note

For details on the NetWare functions, refer to the NetWare operation
manual.

3-2 cm3521

Setting up network printing

With Macintosh

You can print from your Macintosh computer using LPR, AppleTalk, or Bon­jour/Rendezvous.

You can connect this printing system to a print server in an AppleTalk or a
Bonjour/Rendezvous environment and send print jobs from the Macintosh
computer to this machine.

Network connection methods that can be selected in each Windows op­erating system

This chapter describes the settings that must be specified for network print­ing.

Setting procedures differ depending on the method of networking printing
used (SMB, LPR, or IPP printing). Select the best method of network printing
for your Windows environment.

Network printing from a Windows operating system

3

Proto­col used

SMB Print­ing

LPR Printing TCP/IP oooo

IPP Printing TCP/IP oo o

Port 9100
Printing

* When using Port 9100 printing under Windows 98 Second Edition or Windows Me, the Peer to

Peer Printing Tool must be installed. For the details, refer to the table below.

TCP/IP,
NetBEUI

TCP/IP +* +* oo o

Win­dows 98
Second
Edition

oooo o

Win­dows
Me

Win­dows
2000

Win­dows XP

Win­dows NT

4.0

Win­dows
Server
2003

Conditions when the Peer to Peer Printing Tool must be installed while using
Port 9100

Operating System

Windows 98SE/Me Windows 2000/XP/2003

Driver type Using installer Not using

installer

PCL Not required

PostScript -

PostScript PPD -

*1

*3

Required Not required

*2

Required -

Using installer Not using

installer

*4

*2

cm3521 3-3

3

Setting up network printing

*1

If the printer driver is installed using the installer while this machine is con­nected to the network, the required Peer to Peer Printing Tool is also installed
automatically, and Port 9100 is created.

*2

The printer driver is not compatible with the operating system.

*3

Installing the printer driver using the installer is not applicable.

*4

Not required since standard operating system functions are used.

To obtain the Peer to Peer Printing Tool, consult the dealer where you pur­chased this machine.

To specify the driver settings when installing the Peer to Peer Printing Tool,
refer to “Port 9100 Printing (Windows 98SE/Me/2000/XP/Server 2003)” on
the User’s Guide [Print Operations].

When using SMB printing, you can perform network printing without install­ing the Peer to Peer Printing Tool software. For details, refer to “SMB print­ing” on the User’s Guide [Print Operations].

2

Reminder

Before setting up network printing, install the printer driver. For details on
installing the printer driver, refer to “Installing the printer driver” on
page 2-1.

To perform network printing, change the printer port for the installed
printer driver to one for a network connection, and then change the set­tings on this machine as necessary. For an IPP connection, it is neces­sary to install the printer driver first.

Network printing in a NetWare environment

NetWare version Protocol used Emulation Service mode

NetWare 4.x IPX NDS/Bindery Pserver/Nprinter

NetWare 5.x/6 IPX NDS Pserver

TCP/IP NDPS(lpr)

3-4 cm3521

Setting up network printing

3.2 Accessing Web Connection

Setting the IP address for this machine enables you to access Web Connec­tion.

Use your Web browser to directly access Web Connection.

To access Web Connection

1 Start up the Web browser.

2 In the “Address” bar, enter the IP address for this machine as shown

below, and then press the [Enter] key.

– http://<IP_address_for_this_machine>/

Example: If the IP address for this machine is 192.168.1.20
http://192.168.1.20/

The initial page of Web Connection appears.

For further details on Web Connection, refer to “Using Web Connection” on
the User’s Guide [Print Operations].

3

2

Note

If the user authentication function is enabled, you must enter a user name
and password.

cm3521 3-5

3

Setting up network printing

3-6 cm3521

Various printing methods

4 Various printing methods

4.1 Printing operations

For Windows

Data can be printed from an application.

Print jobs are specified from the application software.

1 Open the data in the application, “File”, and then click “Print”.

2 Check that the printer name has been selected in “Printer Name” or

“Select Printer”.

– If the printer is not selected, click to select the printer.

4

3 Specify the page range and the number of copies to print.

– The Print dialog box differs depending on the application.

cm3521 4-1

4

Various printing methods

4 Click the [Preferences] button or the [Properties] button to change the

printer driver settings as necessary.

– By clicking the [Preferences] button or the [Properties] button on

the Print dialog box, you can specify the settings of each model on
the printer driver dialog box that appears. For details, refer to “Set­ting Up the PCL Driver” on the User’s Guide [Print Operations],
“Setting Up the PostScript Driver (Windows)” on the User’s Guide
[Print Operations] or “Setting Up the PPD Driver (Windows)” on the
User’s Guide [Print Operations].
If the changed settings are not saved in the Print dialog box, the
original settings are restored when the application is quit.

5 Click the [Print] button.

The Data indicator of this machine flashes.

PCL Driver

4-2 cm3521

Various printing methods

PostScript Driver

4

PostScript PPD Driver

cm3521 4-3

4

Various printing methods

Test printing

Printing is possible when the printer driver is installed and the network set­tings have been specified. To check that connection has been made proper­ly, you can print the standard Windows test page.

Print a test page from the printer driver Properties dialog box.

1 For Windows 98SE/Me/2000/NT 4.0, click the [Start] button, point to

“Settings”, and then click “Printers”.
For Windows XP/Server 2003, click the [Start] button, and then click
“Printers and Faxes”.

– If “Printers and Faxes” does not appear in the Start menu, open the

Control Panel from the Start menu, select “Printers and Other Hard­ware”, and then select “Printers and Faxes”.

2 Right-click the icon of the installed printer, and then click “Properties”.

3 Click the General tab, and then click the [Print Test Page] button or the

[Print Test] button.

The test page is printed and the confirmation dialog box appears.

4 Check the printout, and then click the [OK] button or the [Yes] button.

2

Note

If the test page is not printed properly, check that the printer driver has
been installed properly and that the network settings are complete.

4-4 cm3521

Various printing methods

For Macintosh

Printing is possible when the printer driver is installed and the network set­tings have been specified. Print jobs are specified from the application soft­ware.

The functions of this machine that can be used when printing can be speci­fied in the Print dialog box or the Page Setup dialog box.

The settings can only be applied while using the application. When the ap­plication is exited, the settings return to their default settings.

For Mac OS X

1 Open the data in the application, “File”, and then click “Print”.

2 Check that the printer name has been selected.

4

3 Specify the print range and the number of copies to print, and then

click the [Print] button.

The Data indicator of this machine flashes.

2

Note

If the printer name does not appear in the list, select the printer in Print
Center or the Printer Setup Utility. For details, refer to “Selecting a print­er” on page 2-18.

The Print dialog box differs depending on the application.

cm3521 4-5

4

Various printing methods

For Mac OS 9.2

1 Open the data in the application, “File”, and then click “Print”.

2 Check that the printer name has been selected.

3 Select “General”.

4 Specify the Pages and the number of copies to print, and then click the

[Print] button.

The Data indicator of this machine flashes.

2

Note

If the printer name does not appear in the list, select the printer from the
Chooser window. For details, refer to “Selecting a printer” on page 2-18.

The Print dialog box differs depending on the application.

The settings can be saved by clicking the [Save Settings] button.

4-6 cm3521

Various printing methods

4.2 Setting the printing functions

The functions of this machine such as sorting and folding can be set when
printing from a computer. Depending on the operating system running on the
connected computer, the setting procedure of this machine’s functions may
differ.

Function list

The function list contains a summary of the main settings related to printing
and printer driver support.

2

Note

The function names in this list are based on those displayed by the PCL
printer driver in Windows XP. In addition, the items and setting values dis­played may differ depending on whether the options are installed or the
settings are available.

4

Function Overview Printer driver

PCL Post

Script

Orientation Selects the original document paper

orientation.

Original Size Specifies the size of the original document. oo

Output Size Specifies the output paper size. ooo

Zoom Prints enlarged or reduced. ooo

Paper Source Selects the paper source for printing. ooo

Paper Type Settings Specifies the paper type of the paper

source.

Binding Position Selects the binding position. ooo

Print Type Selects the print type (simplex, duplex, or

booklet).

Combination Prints multiple pages on one page. ooo

File Margin Sets Margins for punch holes and staples. o

Staple Staples documents. ooo

Hole-Punch Punches holes in documents. ooo

ooo

ooo

ooo

PPD

Center Staple and
Fold

Output Method
(Job Management)

Copies Specifies the number of copies to print. ooo

cm3521 4-7

Center staples printed documents. ooo

For non-conventional printing, selects the
special output format for secured
documents or saves data in a box.

oo(Mac

OS X
only)

4

Various printing methods

Function Overview Printer driver

PCL Post

Script

Output Tray Selects the tray where to output the printed

pages.

Collate Specifies whether to print multiple copies in

sets.

Offset When printing multiple copies, shifts the

output position of each set.

Skip Blank Pages Does not print blank pages in data. o

Front Cover Page Attaches a front cover page. ooo

Back Cover Page Attaches a back cover page. ooo

Transparency
Interleave

Per Page Setting Switches the paper and trays per page. o

Chapter Specifies the page to be printed on the front

Overlay Prints the original document on top of form

Watermark Prints a watermark (text stamp) on the page

Inserts interleaves between overhead
projector transparencies.

side.

data that was created separately.

being printed.

ooo

ooo

ooo

ooo

o

o

oo

PPD

Distribution Number
Stamping

Copy Protect Prints a special pattern and prevents

Select Color Selects color printing and monochrome

Glossy Mode Prints using a gloss finish. ooo

Original Image Type Prints with a quality suitable for the selected

Quality Adjustment Adjusts the image quality. ooo

Pattern Specifies the graphic pattern details. o

Use Printer Fonts Specifies the replacement of TrueType fonts

FAX Sends data as a fax. o

User Authentication/
Account Track

Prints the number of the copy. o

o

copying.

o (No

printing.

ooo

original document.

ooo

with printer fonts.

Printing is performed after the registered
user name and password are entered.

oo(Mac

two
color
selec­tion)

(No
two
color
selec­tion)

OS X
only)

Account Track Performs account track operations. oo(Mac

4-8 cm3521

OS X
only)

Various printing methods

Function overview

An overview of each function is summarized in this section.

Orientation

You can specify “Portrait” or “Landscape” as the orientation of the page be­ing printed.

4

ABCD

ABCDEF

Portrait

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

PostScript “Specifying the Setup Tab Settings” on the

PostScript PPD “Specifying the Paper Tab Settings” on the

Mac OS X PostScript PPD “Page Attributes (Basic Settings)” on the

Mac OS 9.2 “Page Attributes (Basic Settings)” on the

Landscape

User’s Guide [Print Operations]

User’s Guide [Print Operations]

User’s Guide [Print Operations]

User’s Guide [Print Operations]

User’s Guide [Print Operations]

cm3521 4-9

4

Various printing methods

Original Size and Output Size

You can specify the original document size and the output paper size. By
specifying each size, you can specify the enlargement and reduction ratio.

Output size

Original size

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

User’s Guide [Print Operations]

PostScript “Specifying the Setup Tab Settings” on the

User’s Guide [Print Operations]

PostScript PPD “Specifying the Paper Tab Settings” on the

User’s Guide [Print Operations]

Mac OS X PostScript PPD “Page Attributes (Basic Settings)” on the

User’s Guide [Print Operations]

Mac OS 9.2 “Page Attributes (Basic Settings)” on the

User’s Guide [Print Operations]

2

Note

Only the output paper sizes can be specified with the PostScript PPD
driver for Windows and the Macintosh.

4-10 cm3521

Various printing methods

C

Zoom (enlargement and reduction)

You can specify the enlargement or reduction ratio using numeric values.

4

ABCD

ABCD

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

Original

ABCD

Reduced

PostScript “Specifying the Setup Tab Settings” on the

PostScript PPD “Graphics Tab” on the User’s Guide [Print

Enlarged

AB

ABCD

User’s Guide [Print Operations]

User’s Guide [Print Operations]

Operations]

Mac OS X PostScript PPD “Page Attributes (Basic Settings)” on the

User’s Guide [Print Operations]

Mac OS 9.2 “Page Attributes (Basic Settings)” on the

User’s Guide [Print Operations]

cm3521 4-11

4

Various printing methods

Input Tray (Paper Source)

You can select the input tray as the paper source for printing. When changing
the paper type, you can select an input tray according to the paper type.

Tray

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

User’s Guide [Print Operations]

PostScript “Specifying the Setup Tab Settings” on the

User’s Guide [Print Operations]

PostScript PPD “Specifying the Paper Tab Settings” on the

User’s Guide [Print Operations]

Mac OS X PostScript PPD “Paper Feed” on the User’s Guide [Print

Operations]

Mac OS 9.2 “General (Basic Settings)” on the User’s

Guide [Print Operations]

Paper Type

You can specify the paper type being printed.

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

User’s Guide [Print Operations]

PostScript “Specifying the Setup Tab Settings” on the

User’s Guide [Print Operations]

2

Note

With the PCL driver for Windows, the paper type settings can be pre-set
by specifying the paper type of the paper tray.

4-12 cm3521

PostScript PPD “Specifying the Paper Tab Settings” on the

User’s Guide [Print Operations]

Various printing methods

Print Type (duplex printing/booklet printing)

You can print onto both sides of a page or in a booklet format (two facing
pages or center binding). This comes in handy when you want to bind multi­ple-page documents.

The binding area can be specified by specifying the binding position.

Duplex printing

4

Print data

Left binding Top binding

Booklet printing

Printout

Print data

Print data

Printout

Printout

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

Mac OS X PostScript PPD “Finishing” on the User’s Guide [Print

Mac OS 9.2 “Printer Specific Options (Finishing Options

cm3521 4-13

User’s Guide [Print Operations]

PostScript “Specifying the Layout Tab Settings” on the

User’s Guide [Print Operations]

PostScript PPD “Specifying the Device Options Tab

Settings” on the User’s Guide [Print
Operations]

Operations]

1 to 4)” on the User’s Guide [Print
Operations]

4

Various printing methods

Printing multiple pages on one page

You can print multiple document pages on one page. This comes in handy
when you want to reduce the number of output pages.

12

2in1

12

12

34

4in1

12

5637

12

4536

6in1

4

8

4536

91011

789

9in1 16in1

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

13 14 15 16

12

User’s Guide [Print Operations]

PostScript “Specifying the Layout Tab Settings” on the

User’s Guide [Print Operations]

PostScript PPD “Specifying the Layout Tab Settings” on the

User’s Guide [Print Operations]

Mac OS X PostScript PPD “Layout (Printing Multiple Pages on One

Page)” on the User’s Guide [Print
Operations]

Mac OS 9.2 “Layout (Printing Multiple Pages on One

Page)” on the User’s Guide [Print
Operations]

4-14 cm3521

Various printing methods

Stapling and hole punching

Documents can be stapled together or holes can be punched into the docu­ment.

By specifying the file margin, you can specify the margin for stapling or hole
punching.

4

ABCD

Stapling

ABCDEF

Hole punching

ABCD

ABCDEF

2

Note

The staple function is available only when the optional finisher 9270 is in­stalled.

The hole punch function is available only when optional finishers 9270
and punch kit 9278 are installed.

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

Mac OS X PostScript PPD “Finishing” on the User’s Guide [Print

Mac OS 9.2 “Printer Specific Options (Finishing Options

cm3521 4-15

User’s Guide [Print Operations]

PostScript “Specifying the Layout Tab Settings” on the

User’s Guide [Print Operations]

PostScript PPD “Specifying the Device Options Tab

Settings” on the User’s Guide [Print
Operations]

Operations]

1 to 4)” on the User’s Guide [Print
Operations]

4

Various printing methods

Output Method (Job Management)

You can select “Secured Print”, which requires a password to print, or “Save
in User Box”, which saves documents in a document folder.

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

User’s Guide [Print Operations]

PostScript “Specifying the Setup Tab Settings” on the

User’s Guide [Print Operations]

PostScript PPD “Specifying the Device Options Tab

Settings” on the User’s Guide [Print
Operations]

Mac OS X “Security” on the User’s Guide [Print

Operations]

Sorting (Collating) and Classifying (Offset)

You can print the complete document sets the specified number of times or
each page the specified number of times.

By specifying offset, the output position can be shifted and output to the
front and back for each copy. (Multiple paper sources are used when a shift­ing finisher is installed and when no finisher is installed.)

Collate

ABCD

ABCD

ABCD

1

1

1

Operating system Printer driver Refer to

ABCD ABCD

ABCD

ABCD

2

2

2

Offset

ABCD

ABCD

Windows PCL “Specifying the Setup Tab Settings” on the

4-16 cm3521

User’s Guide [Print Operations]

PostScript “Specifying the Setup Tab Settings” on the

User’s Guide [Print Operations]

PostScript PPD “Specifying the Device Options Tab

Settings” on the User’s Guide [Print
Operations]

Various printing methods

Operating system Printer driver Refer to

Mac OS X PostScript PPD “Copies & Pages (General Settings)” and

Mac OS 9.2 “Copies & Pages (General Settings)” and

Skip Blank Pages (saving paper)

Does not print blank pages in the data.

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

Front Cover, Back Cover, and Transparency Interleave

4

“Finishing” on the User’s Guide [Print
Operations]

“Printer Specific Options (Finishing Options
1 to 4)” on the User’s Guide [Print
Operations]

User’s Guide [Print Operations]

A front cover and back cover can be added and interleaves between over­head projector transparencies can be inserted.

Front cover

Back cover

ABCD ABCD

ABCD

Operating system Printer driver Refer to

Windows PCL “Specifying the Per Page Setting Tab

ABCD

Settings” and “Specifying the Setup Tab
Settings” on the User’s Guide [Print
Operations]

cm3521 4-17

PostScript “Specifying the Per Page Setting Tab

Settings” on the User’s Guide [Print
Operations]

PostScript PPD “Specifying the Device Options Tab

Settings” on the User’s Guide [Print
Operations]

4

Various printing methods

Operating system Printer driver Refer to

Mac OS X PostScript PPD “Setup” on the User’s Guide [Print

Operations]

Mac OS 9.2 “Printer Specific Options (Finishing Options

1 to 4)” on the User’s Guide [Print
Operations]

Per Page Setting

You can specify to have paper inserted between pages and specify simplex
printing or duplex printing and the paper for printing for each page.

Operating system Printer driver Refer to

Windows PCL “Specifying the Per Page Setting Tab

Settings” on the User’s Guide [Print
Operations]

Chapter

You can specify the page that you want to print on the front side when duplex
printing or booklet printing.

Even if a specified page comes up to be printed on the back side in duplex
printing or booklet printing, the specified page is moved and printed on the
front side.

Operating system Printer driver Refer to

Windows PCL “Specifying the Per Page Setting Tab

Settings” on the User’s Guide [Print
Operations]

Overlay

Prints the original document on top of form data that was created separately.

New Product New Product

Form data

4-18 cm3521

Created data

Various printing methods

Operating system Printer driver Refer to

Windows PCL “Specifying the Overlay Tab Settings” on

Watermark

Prints a watermark (text stamp) on the page being printed.

4

the User’s Guide [Print Operations]

Confidential

Operating system Printer driver Refer to

Windows PCL “Specifying the Watermark Tab Settings”

on the User’s Guide [Print Operations]

PostScript “Specifying the Watermark Tab Settings”

on the User’s Guide [Print Operations]

Copy Protect

You can print a special pattern on an entire page while printing.

When the pattern on the printed page is copied, the characters embedded in
the pattern appear to prevent an illegal copy.

Operating system Printer driver Refer to

Windows PCL “Specifying the Watermark Tab Settings”

on the User’s Guide [Print Operations]

cm3521 4-19

4

Various printing methods

Quality Adjustment

Adjusts the image quality.

Operating system Printer driver Refer to

Windows PCL “Specifying the Quality Tab Settings” on the

User’s Guide [Print Operations]

PostScript “Specifying the Quality Tab Settings” on the

User’s Guide [Print Operations]

PostScript PPD “Specifying the Device Options Tab

Settings” on the User’s Guide [Print
Operations]

Mac OS X PostScript PPD “Quality” on the User’s Guide [Print

Operations]

Mac OS 9.2 “Printer Specific Options (Finishing Options

1 to 4)” on the User’s Guide [Print
Operations]

Use Printer Fonts (substitute fonts)

Specifies the replacement of TrueType fonts with printer fonts.

Operating system Printer driver Refer to

Windows PCL “Specifying the Font Tab Settings” on the

User’s Guide [Print Operations]

PostScript “Specifying the Quality Tab Settings” on the

User’s Guide [Print Operations]

PostScript PPD “Fonts Tab” on the User’s Guide [Print

Operations]

Mac OS 9.2 PostScript PPD “PostScript Options” on the User’s Guide

[Print Operations]

User Authentication

When the authentication settings have been applied on this machine, you
must enter the required user name and password.

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

Mac OS X PostScript PPD “Security” on the User’s Guide [Print

4-20 cm3521

User’s Guide [Print Operations]

PostScript “Specifying the Setup Tab Settings” on the

User’s Guide [Print Operations]

Operations]

Various printing methods

Account Track

Specifies when this machine is operating in Account Track.

Operating system Printer driver Refer to

Windows PCL “Specifying the Setup Tab Settings” on the

Mac OS X PostScript PPD “Security” on the User’s Guide [Print Oper-

4

User’s Guide [Print Operations]

PostScript “Specifying the Setup Tab Settings” on the

User’s Guide [Print Operations]

ations]

cm3521 4-21

4

Various printing methods

4-22 cm3521

Various settings

Utility/
Counter

5 Various settings

5.1 Print reports

You can output the following four types of reports.

Configuration Page: Outputs a list of this machine’s settings.

Demo Page: Outputs a test page.

PCL Font List: Outputs the PCL font list.

PS Font List: Outputs the PS font list.

To print

1 Press the [Utility/Counter] key.

5

2 Touch [2 User Setting].

cm3521 5-1

5

Various settings

The User Setting screen appears.

3 Touch [6 Printer Setting].

4 Touch [5 Print Reports].

5 Touch the button for the desired setting.

– Configuration Page: Outputs a list of this machine’s settings.

Demo Page: Outputs a test page.
PCL Font List: Outputs the PCL font list.
PS Font List: Outputs the PS font list.

6 Touch the button for the desired paper tray and the [Simplex/Duplex]

button.

7 To output a report, press the [Start] key.

5-2 cm3521

Various settings

5.2 Printing on banner paper

Paper up to 1200 mm (47-1/4 inch) long can be loaded into the bypass tray
and printed on using this machine with the appropriate setting specified from
the control panel.

Loading banner paper and printing on it is referred to as “banner printing”
throughout the manual.

Paper

Paper types

Paper width Paper length Paper type

210 to 297 mm
(8-1/4 to 11-3/4 inch)

457.3 to 1200 mm
(18 to 47-1/4 inch)

2

127 to 160 g/m

2

(33-3/4 to 42-1/2 lb)

5

Note

Feed only one sheet of paper at a time.

Printer drivers and supported operating systems

The following drivers are compatible with banner paper printing.

Page description
language

PCL
(PCL XL)

PostScript 3 Emu­lation

Specifying printer driver settings

To specify printer driver settings

The paper sizes to be printed are preregistered as Custom Size.

Printer driver Supported operating systems

PCL Driver Windows NT 4.0, Windows 2000 Professional,

Windows XP Home Edition, Windows XP Professional,
and Windows Server 2003

PostScript
Driver

Windows NT 4.0, Windows 2000 Professional,
Windows XP Home Edition, Windows XP Professional,
and Windows Server 2003

1 Click the Setup tab.

2 From the “Original Size” or “Output Size” drop-down list, select “Cus-

tom Size Settings”.

The Custom Size Settings dialog box appears.

cm3521 5-3

5

Various settings

3 Specify settings for the following:

– List of Custom Sizes: Select the size for the custom size being set.

(PCL driver only)

– Custom Size Name: Input the name of the custom size being regis-

tered. (PCL driver only)

– Size: Specify the width and length of the custom size according to

the selected measurement units.

4 Click the [OK] button.

5 When printing, select the Custom Size that was registered from the

“Original Size” and “Output Size” drop-down lists on the Setup tab.

2

Note

For the PCL driver, the custom size settings can only be specified from
the printer driver setup dialog box, which can be displayed from the Print­ers window (for Windows XP/Server 2003,Printers and Faxes window).

5-4 cm3521

Various settings

Printing

To print

1 Press the [Utility/Counter] key in the control panel.

2 Touch [6 Banner Printing].

3 Touch [ON], and then touch [OK].

5

4 Select a job to be printed from the computer, and then click “Print” on

the “File” menu.

5 Specify the desired settings, and then click the [OK] button.

6 Open the bypass tray.

7 With the side to be printed on facing down, insert the paper as much

as possible into the feed slot.

– Before loading the paper, check that the following message ap-

pears in the control panel.

cm3521 5-5

5

Various settings

8 Slide the lateral guides to fit the size of paper being loaded.

– Load one sheet at a time.
– Print while supporting the loaded paper with your hands.

9 If the following screen appears, touch [Complete].

5-6 cm3521

Various settings

10 When printing is finished, touch [Finish].

11 Touch [Yes].

5

– To continue printing, repeat steps 7 through 9.

cm3521 5-7

5

Various settings

5-8 cm3521

Troubleshooting

6 Troubleshooting

6.1 Unable to Print

This chapter explains the troubleshooting procedures for possible malfunc­tions.

Perform the troubleshooting procedures described below if this machine
does not print after you have sent a print job.

Symptom Probable cause Action

6

The message “No
printers are connect­ed.” or “Print error”
appears.

A postscript error ap­pears.

The printer driver selected for
printing is not compatible with the
printer controller.

The network cable, parallel cable,
or USB cable is disconnected.

An error has occurred in this ma­chine.

Available memory space is not
sufficient.

The network cable, parallel cable,
or USB cable is disconnected.

An error has occurred in this ma­chine.

Available computer memory
space is not sufficient.

There is an error in the application
software settings.

The file printing settings are incor­rect.

Check the printer name selected.

Check that the cable is connected
properly.

Check this machine’s control
panel.

Perform a test print to check
whether printing is possible.

Check that the cable is connected
properly.

Check this machine’s control
panel.

Perform a test print to check
whether printing is possible.

Refer to the user’s manual of the
application software to check the
settings.

Change the settings and try to
print again.

cm3521 6-1

6

Troubleshooting

Symptom Probable cause Action

The machine does not
start printing although
the print job was com­pleted on the compu­ter.

The printer driver selected for
printing is not compatible with the
printer controller.

The network cable, parallel cable,
or USB cable is disconnected.

An error has occurred in this ma­chine.

A print job is queued in this ma­chine, delaying printing.

“Save in User Box” was selected
for the print job.

“Secure Print” was selected for
the print job.

If the account track settings have
been applied, an unregistered de­partment name (or password)
may have been entered.

If the authentication settings have
been applied, an unregistered
user name (or password) may
have been entered.

Check the printer name selected.

Check that the cable is connected
properly.

Check this machine’s control
panel.

Check the job order on the Active
Jobs list of the machine’s control
panel.

Check if the print job is stored on
the Box screen of this machine’s
control panel.

Check if the print job is held on the
Secure Print User Box screen of
this machine’s control panel.

Enter the correct department
name (or password).

Enter the correct user name (or
password).

Available computer memory
space is not sufficient.

The connection of this machine to
the network is not yet established
(while connecting to a network).

The enhanced security mode may
be enabled on this machine.

Perform a test print to check
whether printing is possible.

Consult with the network adminis­trator.

Specify the authentication set­tings in the enhanced security
mode. For details, consult with
the network administrator.

If the problem persists after all of these procedures have been performed,
read the User’s Guide [Copy Operations].

6-2 cm3521

Troubleshooting

6.2 Unable to specify desired settings or unable to print
as specified

Perform these troubleshooting procedures if you cannot specify the desired
settings in the printer driver, or if the print results do not represent the set­tings that have been specified.

2

Note

Some of the printer driver functions cannot be combined with other func­tions.

Symptom Probable cause Action

6

A printer driver setting
cannot be selected.

The “Conflicts” mes­sage with “Unable to
Select” or “Function
Canceled” appears.

Printing is not per­formed as specified.

The watermark cannot
be printed.

The staple function
cannot be specified.

Some functions cannot be com­bined.

An incorrect combination of func­tions has been specified.

Incorrect settings are specified. Check each setting in the printer

A combination of functions, al­though possible in the printer driv­er, is not possible with this
machine.

The paper size, orientation, and
other settings specified in the ap­plication have priority over those
specified in the printer driver.

The watermark is not correctly
set.

The watermark density is set to a
level that is too low.

Watermarks cannot be printed in
graphics applications.

Stapling is not possible if “Paper
Type” is set to “Thick” or “Trans­parency”.

Do not try to select settings that
are not available.

Check the settings and specify
the functions correctly.

driver.

Enter the correct settings in the
application.

Check the watermark settings.

Check the density settings.

No watermark can be printed in
this case.

Check each setting in the printer
driver.

Stapling cannot be
performed.

cm3521 6-3

The staple function requires op­tional finisher.

If are a large number of pages to
be printed, stapling cannot be
performed.

Stapling is not possible if the doc­ument contains pages of different
sizes.

Install the required optional finish­er and enable it using the printer
driver.

Change the number of pages to
be printed.

Check the document.

6

Troubleshooting

Symptom Probable cause Action

The stapling position
is not as expected.

The hole punch func­tion cannot be speci­fied.

The pages are not
punched.

The hole punch posi­tion is not as expect­ed.

The form is not printed
properly.

The image is not print­ed properly.

Paper is not fed from
the specified paper
source.

The orientation setting is not cor­rect.

Hole punching cannot be speci­fied if “Booklet”, “Transparency”,
“Thick2”, “Thick3”, or “Envelope”
is selected.

Optional finishers and punch kit
9278 are required.

Printed pages may be fed out
without being punched if the pa­per is loaded into the paper
source with an incorrect orienta­tion.

The orientation setting is not cor­rect.

Available computer memory
space is not sufficient.

Available computer memory
space is not sufficient.

Paper will not be fed from the
specified paper source if that pa­per source is loaded with paper of
a different size or orientation.

Check the stapling position in the
printer driver setup dialog box.

Check each setting in the printer
driver.

Install the required optional finish­er and enable it using the printer
driver.

Check the orientation setting.

Check the punch position on the
Layout tab of the printer driver
setup dialog box.

Simplify the form to reduce the
data size.

Simplify the image to reduce the
data size.

Load the paper source with paper
of the appropriate size and orien­tation.

The access number
cannot be specified.

To specify access numbers, a
hard disk must be added in the
Option tab of the printer driver.

Add a hard disk in the Option tab
of the printer driver.

6-4 cm3521

Troubleshooting

6.3 Error message

Message Cause and remedy

6

Cannot connect to the
network.

A connection to the network could not be established.
Check if the network cable is correctly connected. In addition, check
that the Network Setting parameters on the Administrator Setting
screen have been correctly specified.

cm3521 6-5

6

Troubleshooting

6-6 cm3521

Appendix

7 Appendix

7.1 Specifications

Item Specifications

Model Built-in printer controller

Power supply Common with the main body

CPU PPC750 FX 600 MHz

RAM 512 MB

Hard disk 40 GB

Interface Standard: Ethernet (10Base-T or 100Base-TX)

Frame type Ethernet 802.2

7

Optional: USB 1.1, USB 2.0, or IEEE 1284

Ethernet 802.3
Ethernet II
Ethernet SNAP

Supported protocols TCP/IP

IPX/SPX
NetBEUI
AppleTalk (EtherTalk)

Print speed 35 pages/minute (color/monochrome, 8-1/2 × 11 v paper,

and simplex)
32 pages/minute (color/monochrome, 8-1/2 × 11 v paper,
and duplex)

Fast print time 8.5 seconds or less (color and A4 paper)

6.5 seconds or less (monochrome and A4 paper)

Printer language PCL5e/c Emulation

PCL6 (XL 2.1) Emulation
PostScript 3 Emulation (3011)

Operating environment condi­tions

Resolution Data processing 600 × 600 dpi (printing and fax operations)

Printing 600 × 1800 dpi (equivalent)

Supported paper sizes Maximum Standard Size

Printer fonts PCL Latin 80 Fonts

Temperature 10 to 30°C
Humidity 15—85% RH

400 × 400 dpi (fax operations)
200 × 200 dpi (fax operations)

Postscript 3 Emulation Latin 136 Fonts

Compatible computers IBM PC or compatible, and Macintosh (PowerPC or Intel

cm3521 7-1

Processor)

7

Appendix

Item Specifications

Supported
operating
systems

Printer driver PCL6:

Utility Web Connection

Server Windows NT 4.0 (SP6a), Windows 2000 Server, or Win-

dows Server 2003

Client Windows 98 Second Edition, Windows Me, Windows 2000,

Windows XP, or Windows NT 4.0 (SP6a)
MacOS 9.2 or later or MacOS X 10.2, 10.3 or 10.4

• Windows 98 Second Edition or Windows Me Printer
Driver

• Windows 2000, Windows XP, or Windows Server 2003
Printer Driver

• Windows NT 4.0 Printer Driver

PS3:

• Windows 98 Second Edition or Windows Me PPD File

• Windows NT 4.0 Printer Driver

• Windows 2000, Windows XP (Home/Professional), Win­dows Server 2003 Printer Driver

• Windows XP Professional x64, Windows Server 2003
x64 Printer Driver

• MacOS 9.2 PPD File

• MacOS X 10.2 Printer Driver

• MacOS X 10.3 or MacOS X 10.4 Printer Driver

Web browsers:
Microsoft Internet Explorer 6 or later recommended (Java­Script enabled, Cookies enabled)
Microsoft XML Parser MSXML3.X must be installed when
using Internet Explorer 5.5.
Netscape Navigator 7.02 or later (JavaScript enabled,
Cookies enabled)
Macromedia
version 7.0 or later plugin is required.)

®

Flash® (If “Flash” is selected in View Mode,

7-2 cm3521

Appendix

7.2 Configuration page

7

cm3521 7-3

7

7.3 Font list

PCL font list

Appendix

7-4 cm3521

Appendix

7

PS font list

cm3521 7-5

7

Appendix

Demo page

7-6 cm3521
