Océ 9600
Copier/Printer
User Manual
Page 2
Océ-Technologies B.V.
This manual, which can be kept behind the left-hand door of the copier,
contains a description of the Océ 9600 and the copy jobs that can be done with
it. The introduction (chapter 1) contains general instructions for using the
printer. We recommend that you read at least this chapter.
Safety information
This manual contains the following safety information:
Appendix B lists ‘Instructions for safe use’.
■
information before you start to actually use the copier.
information such as safety data sheets can also be found in appendix B.
Where applicable, cautions and warnings are used throughout this manual to
■
draw your attention to safety precautions to be taken.
You are advised to read this
Technical safety
Copyright
Océ-Technologies B.V. Venlo, The Netherlands © 2000
All rights reserved. No part of this work may be reproduced, copied, adapted,
or transmitted in any form or by any means without written permission from
Océ.
Océ-Technologies B.V. makes no representation or warranties with respect to
the contents hereof and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose.
Further, Océ-Technologies B.V. reserves the right to revise this publication and
to make changes from time to time in the content hereof without obligation to
notify any person of such revision or changes.
Edition 3.0
US
Page 3
Table of contents
Chapter 1
Introduction
About this manual 10
The Océ 9600 12
Océ 9600 key concepts 13
Océ 9600 users 16
Océ 9600 components 17
Océ 9600 printer 17
Océ 9600 scanner 18
Océ 9600 manual feeder 18
Océ 9600 controller 19
Océ 9600 optional features 21
Chapter 2
Using the Océ 9600 Printer
Printer operating panel 26
Display 27
Counter 28
Buttons 29
Printer panel actions 30
Starting up and shutting down the Océ 9600 31
Media type and size on the printer 32
Special media indication 34
Interrupt a print job 34
Select a language 35
Off-line folding settings 36
Positioning the reinforcement knives (optional) 37
Chapter 3
Using the Océ 9600 Copier
Scanner operating panel 40
Display 41
Buttons 41
Section, Function and Arrow buttons 42
Sections on the operating panel 42
Settings on the Océ 9600 Copier operating panel 44
Table of Contents 3
Page 4
Chapter 4
Perform basic copy jobs 46
Starting up and shutting down the scanner 47
Make copies 48
Selecting the required media 49
Selecting the input mode 50
Specifying the zoom factor 51
Select the exposure 52
Delivering originals after scanning 52
Defining settings for the next original 53
Using the manual feeder for copying 54
Defining delivery of copies 55
Stopping a copy job 55
Performing special copy jobs
Non-standard size originals 58
The scan width 59
The copy size 60
Scanning originals with filing strip 61
Improving the image quality 65
Brightness 65
Editing functions 67
Auto shift 67
Shift the image 69
Mirror-image copies 71
Chapter 5
Managing print and copy jobs
Introduction 74
Structure 74
Icons 77
The connection to a controller 78
Managing print jobs 79
Chapter 6
Scan to file
Introduction 82
Make a scan-to-file 83
Settings for scan-to-file 85
File mode 86
4 Océ 9600 Copier/Printer User Manual
Page 5
Destination 86
File type 86
Tiff subformat 87
Resolution 88
Zoom 88
Optimization 88
Mirror 89
Scan Manager 90
Tree view 91
Table view 91
Actions from the Scan Manager 93
Destinations 93
Scanned files 96
Manage the temporary store 98
How to retrieve scanned files? 99
Get files via FTP 99
Océ View Station 101
Menu options 102
Function buttons 103
View error 104
Chapter 7
Chapter 8
Chapter 9
System status
Introduction 106
Structure 106
Icons 110
User operations 111
Remote Logic
Introduction 114
Installation procedure 115
The Océ 9600 applications
Introduction 120
User modes 121
Log in 122
Logout 122
To change the password 122
Table of Contents 5
Page 6
Chapter 10
Automatic login 123
Ease of use 124
Language 124
Help 124
Command line parameters 125
Work on a remote system 127
Key operator settings
Introduction 130
Starting up and shutting down the controller 131
Settings Editor 132
General structure 133
Menu bar 134
Row of buttons 134
Settings area 134
General control buttons 135
Status bar 136
How to access the Settings Editor 137
How to perform actions from the Settings Editor 137
Key operator settings 139
Job-related settings for copying 140
Job-related settings for copying (single) 141
Original (group) 143
Copy (group) 149
File (group) 154
Zoom calibration 157
Job-related settings for printing 158
Sheet (group) 160
Finishing (group) 165
Image (group) 168
Layout (group) 172
Printer-related settings 174
System related settings 176
Single options 177
Localization (group) 177
Job priorities (group) 179
Media (group) 180
Timers (group) 181
Disk clean up (group) 183
Scanner related settings 185
Single options 186
Zoom steps (group) 187
6 Océ 9600 Copier/Printer User Manual
Page 7
Chapter 11
Chapter 12
Timers (group) 188
System administrator settings
Introduction 192
System Administrator settings 193
Printer related settings 195
Printer Descriptive Language settings (groups) 197
Pen settings 206
System related settings 208
Controller identification settings (group) 209
Set memory reservation settings 211
Connectivity settings 211
Loading supplies
Introduction 218
Media 219
Rolls 220
Cut sheet material 225
Toner 227
Maintenance of the glass platen and the reference roller 230
Reinforcement unit maintenance 232
A new tape roll 232
The waste box 240
Maintenance of the reinforcement knives 241
Chapter 13
Problem solving
Introduction 244
Original jams in scanner 245
Jams in printer 247
Cut sheet feed section 248
Roll feed section 248
Manual feeder 249
Fuser section 250
Folder 252
Reinforcement unit 260
Other problems 266
7
Page 8
Chapter 14
Appendix A
Folder
Océ 9600 folder 268
Folder 268
Off line folding 272
Reinforcement unit 273
Belt unit 275
Overview and tables
Overview of the Océ 9600 system 278
Printer operating panel 279
Scanner operating panel 280
Product specifications Océ 9600 281
List of available material types and sizes 288
Reinforcement strips 289
Appendix B
Appendix C
Safety information
Recommended weight limits 292
Instructions for safe use 294
Safety data sheets 295
Safety data sheet Océ 9600 printer and folder 295
Safety data sheet Océ 9600 scanner 295
Safety data sheet Océ 9600 printer 296
EPA Energy Star® 297
Miscellaneous
How to read this manual 300
User survey 301
Addresses of local Océ organizations 303
8 Océ 9600 Copier/Printer User Manual
Page 9
Chapter 1
Introduction
Océ 9600 Copier/Printer
User Manual
This chapter contains a general introduction to the
Océ 9600, including a general description of the main
features, delivery options and software applications
provided with the system.
9
Page 10
About this manual
This manual contains the following chapters
Chapter 1: Introduction
contains a general introduction to the Océ 9600
system, including a general description of the main features, delivery options
and software applications provided with the system.
Chapter 2: Using the Océ 9600 printer
contains a brief description of the
actions that can be performed on the printer operating panel of the Océ 9600.
Chapter 3 Using the Océ 9600 copier
contains a brief description of the
actions that can be performed on the scanner operating panel of the Océ 9600
plus the basic copy functions that are available from the system.
Chapter 4: Performing special copy jobs
provides a detailed description of
special copy functions to be performed on the Océ 9600.
Chapter 5: Managing print and copy jobs
describes how to view the Océ 9600
print queue and how to abort the active print, how to delete and pause print jobs
in the queue and how to restart jobs that have been put on hold.
Chapter 6: Scan to file
describes how to scan originals to a file.
Chapter 7: System status
describes how to view the system status of the Océ
9600.
Chapter 8: Remote Logic
describes how to install the remote versions of the
Queue Manager, System Control Panel and Settings Editor on a user PC.
Chapter 9: The Océ 9600 applications
describes the general functionality of
the Océ 9600 applications.
Chapter 10: Key operator settings
describes how to make key operator
settings with the Settings Editor.
Chapter 11: System administrator settings
describes how to make system
administrator settings with the Settings Editor.
Chapter 12: Loading supplies
describes regular maintenance tasks, such as
refilling paper and toner or refilling the reinforcement unit.
10 Océ 9600 Copier/Printer User Manual
Page 11
Chapter 13: How to solve problems
while using the Océ 9600.
describes the problems that may occur
Chapter 14: Folder
contains a description of the optional folder delivered with
the Océ 9600.
Appendix A: Overview and tables
contains the product specifications for the
Océ 9600, a list of available material types and sizes.
Appendix B: Safety information
contains the recommended weight limits,
instructions for safe use, the available safety data sheets and the applicable
NERGY STAR
E
Appendix C: Overview of printer/copier parts
®
specifications.
To help you quickly find the
parts of the copier and the functions on the operating panel, an illustration of
the Océ 9600 is presented in appendix A or B.
Appendix D: Miscellaneous
contains the notation conventions, a reader’s
comment sheet and the addresses of local Océ organizations.
Index
indicates where you can find the most commonly used terms in the
manual.
Introduction 11
Page 12
The Océ 9600
The Océ 9600 is a wide-format, black-and-white, electrophotographic, mid- to
high-volume copier/printer/scanner. The machine is available in a number of
printer configurations, ranging from two rolls in a single drawer (the minimum
configuration) to a maximum of six rolls (with one cassette tray) and three
cassette trays (with four rolls).
The Océ 9600 is a versatile, highly productive system which offers you a broad
range of functions. See ‘Product specifications Océ 9600’ on page 281 for
more information.
[1] Océ 9600
12 Océ 9600 Copier/Printer User Manual
Page 13
Océ 9600 key concepts
Printer configuration
The Océ 9600 is available in a number of printer
configurations, ranging from two rolls in a single drawer (the minimum
configuration) to a maximum of six rolls with one cassette tray and four rolls
with three cassette trays. Also, a number of optional features are available,
including a folder, a horizontal delivery tray, a roll loader and a paper switch
for supporting customer finishing units.
Copy functionality
With the Océ 9600 scanner, a large number of copy
activities can be performed. A wide variety of original and copy related
settings are supported. Users can specify particular layout, media, finishing,
feeding and quality enhancement options from the scanner operating panel.
See ‘Product specifications Océ 9600’ on page 281 for more information.
Scan to file
The Océ 9600 offers full hybrid performance with its optional
scan-to-file function. Documents are scanned and then digitally stored. Ten
customizable destinations are supported.
Network connectivity
The Océ 9600 supports a number of popular network
protocols. This means that it can be used in multiple networking environments
such as TCP/IP, NetBEUI, and Novell Pserver (IPX/SPX).
Set processing
The Océ 9600 supports set processing. This means that when
you send a file to the printer, it is processed once and can be printed many times
(as required). The Océ 9600 is equipped with a set memory for storing up to
250 A0s, which allows for the creation of identical sets that are sorted either
by page or by set.
Print/copy job
A print/copy job is a job sent to the Océ 9600 Printer from a
user application (print job) or from the scanner (copy job). A print/copy job
may consist of several sets, which in turn may consist of several pages. Sorting
of a print/copy job may take place based on sets or on pages.
Spool memory
The Océ 9600 contains a spool memory which provides a
queuing system for files you want to print. The spool memory allows multiple
users to send print jobs to the Océ 9600 simultaneously. The print jobs are then
placed in the print queue where they wait to be printed. The first job put into
the queue is the first to be printed.
Introduction 13
Page 14
Job recovery
The Océ 9600 is equipped with a job recovery function that
safeguards users against data loss in case of a printer failure. After a restart, the
data submitted to the printer before the crash will be automatically processed
and printed. This means that jobs do not have to be resubmitted after a printer
malfunction, thus saving valuable time for the users.
Green button principle
The Océ 9600 is a very user-friendly system. The
scanner, in particular, is very easy to operate. Basic copy jobs can be performed
by simply pressing the green start button on the scanner operating panel. If you
want to perform more complex copy jobs, you have to change the default copy
settings with the help of the other settings on the scanner operating panel.
User interaction
The user can communicate with the Océ 9600 from different
locations, both locally (printer and scanner operating panels, controller
applications) and remotely (drivers on user workstations, Remote Control
Format (RCF) files or Océ Job Tickets (OJT) and remote applications):
Operating panels
■
The Océ 9600 consists of two operating panels for making a wide variety of
settings for printing and copying. See ‘Printer operating panel’ on page 26
and ‘Scanner operating panel’ on page 40 for more information.
Controller applications
■
The Océ 9600 controller applications are used for making default key
operator and system administrator settings (Settings Editor). For viewing the
status of the jobs in the print queue, use the Queue Manager. The ‘System
Control Panel’ shows the status of the entire system. With ‘Scan Manager,’
you can define all relevant settings for scan to file. See ‘Océ 9600 controller’
on page 19 for more information.
Printer drivers
■
With the Océ 9600, a number of printer drivers can be used, including Plot
Director, Windows driver, AutoCAD ADI/HDI and PostScript. With these
drivers, PC users can access the Océ 9600 remotely, from their applications
to print their files. More information about installing, configuring and using
drivers can be found in the documentation provided with the drivers. All Océ
drivers (except Postscript) can be freely downloaded from the Internet at
www.oce.com.
14 Océ 9600 Copier/Printer User Manual
Page 15
A Remote Control Format (RCF) file or Océ Job Ticket (OJT) can be used to
■
instruct the Océ 9600 on how to handle a remote print job. The specific
settings can be made by a user on a control panel, or by means of the user
interface (UI) on a workstation or PC. The RCF file/job ticket specifies the
sets of inputs, the sets of outputs and the processing that is needed to form
the outputs. See the ‘Remote Control Format Reference Manual’ and the
‘Océ Job Ticket Reference Manual’ for more information about Remote
Control Format (RCF) files or Océ Job Tickets (OJT).
Introduction 15
Page 16
Océ 9600 users
On the Océ 9600, the following user types can be identified:
System administrator
The Océ 9600 system administrator is responsible for
installing and configuring the Océ 9600 in his or her environment. He defines
the printer language settings, pen settings and Automatic Language Sensing
(ALS) settings. The system administrator can also provide assistance to normal
users who need to install the printer drivers on their workstations. See
chapter 7, ‘System status’ on page 105 for more information. Configuration
information can be found in the Océ 9600 Connectivity Manual provided with
the Océ 9600.
Key operator
The Océ 9600 key operator is responsible for daily maintenance
of the Océ 9600. The key operator replenishes toner when necessary, loads
media as needed and defines the default printer settings for recurring print jobs.
Also, the key operator defines all time settings, such as panel time out and
sleep mode time out. See chapter 10, ‘Key operator settings’ on page 129 for
more information.
Repro operator
The Océ 9600 repro operator is responsible for the daily
operations on the Océ 9600. The repro operator performs all job-related
activities on the system and is allowed to change the default settings for
job-related activities in the Settings Editor.
Anonymous user
Typically, an anonymous user on the Océ 9600 can be either
a PC user who has remote access to the system through one or more drivers
(Plot Director, Windows driver, AutoCAD ADI/HDI or PostScript), the remote
applications (Queue Manager, System Control Panel and Settings Editor), or a
user performing a copy job at the scanner.
16 Océ 9600 Copier/Printer User Manual
Page 17
Océ 9600 components
The Océ 9600 is available as a digital network printer, copier and scan-to-file
system. It consists of the following components:
Printer (see ‘Océ 9600 printer’ on page 17)
■
Scanner (see ‘Océ 9600 scanner’ on page 18)
■
Controller (see ‘Océ 9600 controller’ on page 19)
■
Optional features (see ‘Océ 9600 optional features’ on page 21)
■
These components, in combination with your network, Plot Director and one
or more drivers (Windows driver, AutoCAD HDI or PostScript), allow you to
use the Océ 9600 as your default enterprise printing and copying solution.
See the Océ 9600 Connectivity Manual for more details about making
networking settings on the Océ 9600 printer. More information about
installing, configuring and using drivers can be found in the documentation
provided with the drivers.
Note:
All Océ drivers and file submitters can be freely downloaded from the
Internet at www.oce.com.
Océ 9600 printer
As a user, you can perform a number of activities at the Océ 9600 printer. You
can start up and shut down the printer, set the media type and size, set a special
media indication, stop a print job or select your preferred language from the
printer operating panel (see chapter 2, ‘Using the Océ 9600 Printer’ on page 25
for more details). With the manual feeder, you can manually feed sheets of
printing material if you want to print a job on a media type and/or size that is
not available on one of the paper rolls or in one of the cassette trays (see ‘Océ
9600 manual feeder’ on page 18 for more information).
Introduction 17
Page 18
Océ 9600 scanner
The Océ 9600 scanner supports a wide range of copy activities. It provides a
large number of functions for defining original and copy-related settings.
Users can specify particular layout, media, finishing, feeding and quality
enhancement options from the scanner operating panel. In combination with
the Océ 9600 printer, it constitutes a powerful productivity tool.
The Océ 9600 scanner is also used to carry out ‘scan to file’ operations.
Océ 9600 manual feeder
The Océ 9600 offers you the ability to manually feed sheets of printing
material. This can be convenient if you want to print a job on a media type
and/or size that is not available on one of the paper rolls or in one of the cassette
trays. The manual feed is a special slot just above the paper drawers on the
engine. You can insert cut sheet material in this slot, one sheet at a time.
Only use material as specified in ‘List of available material types and
Note:
sizes’ on page 288.
[2] Océ 9600 manual feeder
Attention:
When you feed a sheet of printing material in the manual feeder
while a normal print job is being executed, a media jam may occur.
18 Océ 9600 Copier/Printer User Manual
Page 19
▼▼▼▼
Use the manual feeder
Select the manual feed option from the printer driver and select the media to
1
print on before you send the job to the printer.
Note:
More information about Océ 9600 Plot Director and other printer
drivers can be found in the online help provided with those drivers.
Wait until the following message appears on the printer display:
2
(for example):
Go to the printer and specify the required media on the operating panel. See
3
Waiting for manual feed job xxx. Feed A3 portrait, plain paper
‘Set media type for manual feeder’ on page 33 for more information.
Take your sheet of print material to the manual feed.
4
Note:
Avoid using sheets that have already been printed on one side.
Otherwise, the Océ 9600 might become damaged.
Use both hands to align the print material with the format indication on the
5
manual feed.
Move the material forward into the manual feed slot until the printer pulls in
6
the first part of the sheet.
A few seconds later, the complete sheet will be pulled into the printer.
If the print job requires more sheets, the printer will ask you to feed in the next
7
sheet.
Collect your output.
8
.
Note:
The sheet must be inserted face-up.
Océ 9600 controller
The Océ 9600 is equipped with a workstation which helps you to make
optimum use of your system. This workstation runs a number of applications
which allow you to control your print jobs, make your default printer settings
and monitor the printer status. These applications include:
Queue Manager (QM)
■
System Control Panel (SCP)
■
Settings Editor (SE)
■
Scan Manager (SM)
■
Introduction 19
Page 20
Queue Manager
The Océ 9600 Queue Manager (QM) application provides
you with a graphical representation of the print queue. It allows you to view
the print queue and the status of the print jobs, as well as to manage the jobs in
the queue. With the Océ 9600 Queue Manager you can:
View the print queue
■
Abort the job currently being printed
■
Delete job(s) in the queue
■
Pause job(s) in the queue
■
Restart previously paused job(s) in the queue
■
See chapter 5, ‘Managing print and copy jobs’ on page 73 for more
information about the Océ 9600 Queue Manager.
System Control Panel
The Océ 9600 System Control Panel (SCP) application
provides you with status information about the printer. This includes:
Machine status of the Océ 9600 printer and scanner
■
Set memory monitor to view the available storage space on the controller.
■
Overview of the loaded media types and sizes.
■
See chapter 6, ‘Scan to file’ on page 81 for more information about the Océ
9600 System Control Panel.
Key Operator settings / System Administrator settings
The Océ 9600
Settings Editor allows an operator to configure and set up job, printer, system
and scanner specific settings. These settings include:
Format options
■
Editing options
■
Media-related options
■
Finishing options
■
General job, printer and system options
■
See chapter 10, ‘Key operator settings’ on page 129 for more information
about the Océ 9600 Settings Editor application.
The system administrator settings in the Océ 9600 Settings Editor application
allow the system administrator to configure and set up all aspects related to the
infrastructure of the system. These settings include:
Host information
■
Network settings
■
Pen settings
■
Printer language settings
■
General administrator settings
■
20 Océ 9600 Copier/Printer User Manual
Page 21
See chapter 9, ‘The Océ 9600 applications’ on page 119 for more information
about the Océ 9600 Settings Editor application.
Scan Manager
The Scan Manager is an application available only locally on
the controller. With the Scan Manager you can:
configure the destinations for ‘scan to file’.
■
increase your productivity with automatic file naming.
■
See chapter , ‘Scan Manager’ on page 90 for more information about the Océ
9600 Scan Manager application.
Océ 9600 optional features
By default, the Océ 9600 is equipped with an Integrated Receiving Tray (IRT)
as the output delivery device. The IRT is the rack on top of the machine (see
figure 1 on page 12). A number of optional features are also available with the
Océ 9600. These include:
Rolls and cassette trays
ranging from two rolls in a single drawer, to four rolls in two drawers plus three
cassette trays. A maximum of six rolls (in combination with one sheet feeder)
and three sheet feeders (in combination with four rolls) can be configured.
The Océ 9600 is available in many configurations,
Note:
Contact your Océ representative if you want to know more about the
available configurations.
Each of the rolls and cassette trays on the Océ 9600 may be loaded with print
material of a different size or type. The size and type of the available media are
indicated on the operating panel.
Introduction 21
Page 22
Original delivery tray
The original delivery (see figure 3) tray can be used to
stack a number of originals behind the scanner after they have been scanned.
[3] Original delivery tray
Roll loadr
In order to help customers to achieve optimum productivity with
their Océ 9600 and at the same time comply with the international safety
regulations as far as maximum roll weights are concerned, Océ provides an
optional roll loader for use with the Océ 9600. See ‘Recommended weight
limits’ on page 292 for more information about the maximum recommended
roll weights.
[4] Roll loader
Paper switch
To allow customers to use their own output delivery devices, or
CFUs (Customer Finishing Units), with the Océ 9600, Océ has developed the
paper switch. This switch is used to direct output to the delivery device of your
choice.
22 Océ 9600 Copier/Printer User Manual
Page 23
Copy Delivery Tray
The Copy Delivery Tray can be used to neatly stack a
number of prints of various sizes. This tray can be extended for longer prints.
Unfolded copies can be delivered to the Copy Delivery Tray. The Copy
Delivery Tray can be used in combination with the Integrated Receiving Tray
(IRT).
[5] Copy Delivery Tray
Folder
If the Océ 9600 is equipped with a folder, the folded copies are fed into
the standard delivery of the folder, by default. The folder can be combined with
the integrated receiving tray (IRT).
[6] Folder
Introduction 23
Page 24
Reinforcement unit
The optional reinforcement unit adds a firm plastic rim
with punched holes to the copy (see figure 7).
[7] Copy with reinforcement unit
24 Océ 9600 Copier/Printer User Manual
Page 25
Océ 9600 Copier/Printer
User Manual
Chapter 2
Using the Océ 9600 Printer
This chapter contains a brief description of the operating
panel of the Océ 9600 Printer and the actions that can be
performed on it.
25
Page 26
Printer operating panel
The printer operating panel, located on the right-hand side of the printer
console, is easy to use (see figure 8). The panel consists of a number of buttons
and a graphical display. At the top of the panel there is an indicator (a light)
which starts flashing when operator intervention is required.
Up/Down
buttons
On line
button
Selection
buttons
Stop button
[8] Printer operating panel
26 Océ 9600 Copier/Printer User Manual
Page 27
Display
The graphical (LCD) display offers feedback about the current printer status.
It provides you with the following information:
Status information (e.g. ‘Preparing for run’ or ‘Ready to print’).
■
During normal operation, the following message types may appear:
Status/action message: indicates the actual status of the printer plus the
action to be taken, e.g. ‘Roll empty. Feed A2, plain paper’.
Warning message: during a warning message, the printer will continue to
operate, but it is possible that the print quality will not be optimal, e.g. ‘Fill
B5 toner’.
A graphical overview of available rolls and cassette trays, including the
material type and size used by each roll or cassette tray.
A symbol indicating the paper orientation (for cassette trays only).
■
An indication that a particular roll or cassette tray is empty (if applicable).
■
An empty roll is represented by a dotted roll symbol.
An empty cassette tray is displayed as an empty paper tray.
In the event of an error, a graphical representation of any error location (cover
■
or panel), together with instructions on how to solve the problem is
displayed.
Using the Océ 9600 Printer 27
Page 28
Counter
On theOcé 9600 Printer operating panel, a counter will be displayed that gives
the user feedback about the progress of the job that is currently being printed.
The counter, located at the bottom of the upper window on the operating panel,
displays the number of sets and/or pages printed. Counting starts at 1. The
following options are available:
When no sets are made, only the current page and the total number of pages
■
are displayed (e.g. ‘Page 3 of 5’). At the beginning of a job, when the system
does not yet know the total number of pages, only the current page may be
displayed (e.g. ‘Page 5’).
With set input: set counter. In this case, the counter shows the current, total
■
number of sets and the current page (e.g. ‘Set 3 of 5, Page 10’). At the
beginning of a job, when the system does not yet know the total number of
sets, only the current set and page may be displayed (e.g. ‘Set 2, Page 5’).
With set input: multiple sheet counter. In this case the counter shows the
■
current page, the total number of pages and the current copy, e.g. ‘Page 2 of
12, Copy 5’). At the beginning of a job, when the system does yet not know
the total number of pages, only the current page and copy may be displayed
(e.g. ‘Page 2, Copy 5’).
28 Océ 9600 Copier/Printer User Manual
Page 29
Buttons
With the buttons on the operating panel, you can make a number of settings for
the Océ 9600 Printer, such as the media type and size or the preferred language.
The following buttons are available:
Button types
Function
Selection
buttons
The selection buttons are located immediately below the
graphical display. The left button can be used to activate one
of the main menu choices (Language, Folding or
Media) on the left part of the display.
Note: A shadow highlighting effect is used to indicate the ac-
tive menu option.
The right selection button can be used to activate the options
on the right part of the graphical display.
Up/Down
buttons
On line button
Stop button
Key button
Note: To identify the active selection, the dotted line around
this selection is changed into an uninterrupted line and the
small selection triangles next to the specified option are no
longer dimmed.
These selection triangles indicate that you can select an op-
tion from a predefined list with the help of the Up/Down but-
tons.
These two triangular buttons to the right of the graphical dis-
play are used to display the next or previous option from the
selected menu choice and to select the desired option.
By pressing the on line button you can put the printer on line
or off line. If the green light above the on line button is on, the
printer is on line; if this light is off, the printer is off line.
The red stop button is used to stop the present print job. After
this button is pressed, a dialog will display and ask for confir-
mation.
Note: The printing process does not stop instantaneously be-
cause a number of prints may already have been submitted to
the printer after processing. The prints cannot be stopped.
The green key button has no function.
Using the Océ 9600 Printer 29
Page 30
Printer panel actions
On the Océ 9600 printer operating panel you can perform a limited number of
actions. These include:
Starting up and shutting down the printer
■
Setting media type
■
Setting media type for manual feeder
■
Setting media size
■
Setting a special media indication
■
Stopping a print job
■
Selecting the preferred language
■
Making off-line folding settings
■
Cleaning the reinforcement knives
■
30 Océ 9600 Copier/Printer User Manual
Page 31
Starting up and shutting down the Océ 9600
After starting up the Océ 9600 Printer, it is ready for operation.
▼▼▼▼
Start up the system
Set the on/off switch at the rear of the printer to position ‘1’ (see figure 9). If
1
the mains is connected correctly, the green switch will light up.
On/off switch
[9] Printer on/off switch
Turn on the scanner.
2
Turn on the controller and the monitor.
3
▼▼▼▼
Note:
Turn off the system
Select the ‘Shut down’ option from the System Control Panel.
1
Turn off the controller and the monitor.
2
Set the on/off switch at the rear of the printer to position ‘0’ (see figure 9).
3
Note:
The Océ 9600 controller will be started up automatically.
Turning off the printer during a print job may cause loss of
information or a paper jam.
Note:
After turning it off, wait at least 5 seconds before you restart the system.
Using the Océ 9600 Printer 31
Page 32
Media type and size on the printer
One of the features of the Océ 9600 printer is the automatic media change
function. This function allows the printer to switch to another roll of the same
format and copy material when the roll or cassette tray becomes empty during
printing.
Because the Océ 9600 Printer cannot detect the loaded copy material
Note:
type and format itself, you have to specify type and size after you (re)load
media, as described in ‘Media’ on page 219.
See ‘List of available material types and sizes’ on page 288 for an overview of
all materials that can be used on the Océ 9600 Printer.
▼▼▼▼
Set media type
Press the on line button on the printer operating panel to put the printer off line.
1
The ‘Off line’ message is displayed in the status window.
[10] Operating panel in off line mode
The focus is shifted to the Media option (indicated by the shadow effect).
Use the Up/Down buttons to select the roll or cassette tray for which you have
2
just loaded new media.
32 Océ 9600 Copier/Printer User Manual
Page 33
Press the right selection button to activate the Mat. (Material) option.
3
The dotted line around the current selection is changed into an uninterrupted
line and the small selection triangles next to the specified material are no
longer dimmed.
Use the Up/Down buttons to select the material you just loaded.
4
Press the on line button to put the printer on line again. The printer now knows
5
which material is used for the specified roll or cassette tray.
▼▼▼▼
▼▼▼▼
Set media type for manual feeder
Press the on line button on the printer operating panel to put the printer off line.
1
The ‘Off line’ message is displayed in the status window.
Press the left selection button to shift the focus to the Media option.
2
A shadow effect is used to indicate that the focus is set to this option.
Use the Up/Down buttons to select the Manual option.
3
Press the right selection button to activate the Mat. (Material) option.
4
The dotted line around the current selection is changed into an uninterrupted
line and the small selection triangles next to the specified material are no
longer dimmed.
Use the up/down buttons to select the material you just loaded.
5
Press the on line button to put the printer on line again. The printer now knows
6
which material is used by the manual feeder.
Set media size
Press the on line button on the printer operating panel to put the printer off line.
1
The ‘Off line’ message is displayed in the status window (see figure 10 on
page 32).
Press the left selection button to shift the focus to the Media option.
2
A shadow effect is used to indicate that the focus is set to this option.
Use the up/down buttons to select the roll or cassette tray for which you have
3
just loaded new media.
Press the right selection button to activate the Size option.
4
The dotted line around the current selection is changed into an uninterrupted
line and the small selection triangles next to the specified size are no longer
dimmed.
Use the up/down buttons to select the size of the media you just loaded.
5
Press the on line button to put the printer on line again. The printer now knows
6
which media size is used for the specified roll or cassette tray.
Using the Océ 9600 Printer 33
Page 34
Special media indication
On the Océ 9600 Printer, you can attach a Special indication (exclamation
mark: !) to a roll or cassette tray which uses special media (for instance colored
paper). This indication is used to identify the roll or cassette tray to the printer.
For this roll or cassette tray, the automatic media change option is disabled.
▼▼▼▼
Set a special media indication
Press the on line button on the printer operating panel to put the printer off line.
1
The ‘Off line’ message is displayed in the status window (see figure 10 on
page 32).
Press the left selection button to shift the focus to the Media option.
2
A shadow effect is used to indicate that the focus is set to this option.
Use the up/down buttons to select the roll or cassette tray for which you have
3
just loaded special media.
Press the right selection button to activate the ‘Type’ option.
4
The dotted line around the current selection is changed into an uninterrupted
line and the small selection triangles next to the specified type are no longer
dimmed.
Use the up/down buttons to select the Special option for the specified roll or
5
cassette tray.
Press the on line button to put the printer on line again. The printer now knows
6
that the specified roll or cassette tray contains special material.
Interrupt a print job
The red ‘Stop’ button on the Océ 9600 Printer operating panel interrupts the
active print process. You can cancel or continue the current print job.
▼▼▼▼
▼▼▼▼
34 Océ 9600 Copier/Printer User Manual
Cancel a print job
Press the ‘Stop’ button.
1
A dialog is displayed informing you that you can press ‘on line’ to continue or
stop to cancel the job.
Press the ‘Stop’ button again to cancel the current job.
2
In general, the printer cannot be stopped immediately because the
Note:
started prints have to be finished. Printing will be stopped at the end of the
page.
Continue a print job
Press the ‘Stop’ button.
1
Page 35
A dialog is displayed informing you that you can press ‘on line’ to continue or
stop to cancel the job.
Press the ‘On line’ button to continue the current print job.
2
Select a language
On the operating panel of the Océ 9600 Printer you can specify which language
you want to use for displaying printer information, such as status and error
messages.
By default, you can choose between two languages, which have been defined
for your system by the key operator (see chapter 10, ‘Key operator settings’ on
page 129).
▼▼▼▼
Note:
If the key operator has specified only one language, it will not be possible
for you to choose. In that case, the language option will not appear on the
operating panel.
Select a language
Press the on line button on the printer operating panel to put the printer off line.
1
The ‘Off line’ message is displayed in the status window.
Press the left selection button to shift the focus to the Language option.
2
A shadow effect is used to indicate that the focus is set to this option.
Activate the Language option by pressing the right selection button.
3
The dotted line around the current selection is changed into an uninterrupted
line and the small selection triangles next to the specified language are no
longer dimmed.
Use the up/down buttons to switch between the predefined languages.
4
The language specific elements on the display are immediately customized to
5
reflect your language choice. Only the indicator for the language itself is in the
alternate language. This way you always know what your alternate language is.
Put the printer on line again by pressing the on line button. The printer now
6
uses the selected language.
Using the Océ 9600 Printer 35
Page 36
Off-line folding settings
On the Océ 9600 Printer operating panel, you can specify the settings you
want to use for off-line folding. These settings include defining the length and
width of the folded package, enabling and defining the binding edge, selecting
the input method and legend position and cleaning the reinforcement knife.
▼▼▼▼
Make off-line folding settings
Press the on line button on the printer operating panel to put the printer off line.
1
The ‘Off line’ message is displayed in the status window.
Activate the Folding option by pressing the left selection button.
2
The dotted line around the current selection is changed into an uninterrupted
line and the small selection triangles next to the specified option are no longer
dimmed.
Use the up/down buttons to toggle through the available options.
3
Activate the Input option and press the right selection button to activate the
4
Legend option.
If necessary, change the value in the Legend field with the up/down buttons.
5
Press the right selection button again to activate the Method option.
6
If necessary, change the value in the Width field with the up/down buttons.
7
Press the left selection button again and use the up/down buttons to select
8
another option. This can be Package (with sub-options Length and Width),
Binding (with suboptions Size and Binding), or Special (with sub-option
Knife).
Make any desired settings.
9
Put the printer on line again by pressing the on line button. The printer now
10
uses the specified off-line folding settings.
36 Océ 9600 Copier/Printer User Manual
Page 37
Positioning the reinforcement knives (optional)
Because the knives of the optional reinforcement unit of the folder get sticky
from the glue on the reinforcement tape, they have to be cleaned regularly. You
are recommended to clean the knives each time you have inserted a new tape
roll (see ‘A new tape roll’ on page 232) or when an error in the reinforcement
unit has occurred.
Before you can clean the reinforcement knives, you have to place them in such
a position that all the parts that need to be cleaned are accessible. You can do
this from the printer operating panel.
▼▼▼▼
Prepare the reinforcement knives for cleaning
Press the
1
The ‘
Press the left selection button to shift the focus to the
2
on line
Off line
button on the printer operating panel to put the printer off line.
’ message is displayed in the status window.
Folding
menu.
A shadow effect is used to indicate that the focus is set to this menu.
Select the
3
Press the ‘start’ right selection button to activate the
4
Special
option from the
Folding
menu.
Knife
option.
The following information is now displayed in the panel display:
[11] Cleaning the reinforcement knife
Note:
When a job is running, the ‘Job interrupted’ message appears. The
machine stops running after it has correctly finished the prints that were
already in the engine. Then the reinforcement knives are placed in the
correct position.
You can now continue to clean the reinforcement knives (see ‘Maintenance of
5
the reinforcement knives’ on page 241).
Using the Océ 9600 Printer 37
Page 38
38 Océ 9600 Copier/Printer User Manual
Page 39
Océ 9600 Copier/Printer
User Manual
Chapter 3
Using the Océ 9600 Copier
This chapter contains a brief description of the interface of
the Océ 9600 Copier and the actions that can be performed
on its operating panel.
39
Page 40
Scanner operating panel
The Océ 9600 is a very user-friendly system. The scanner, in particular, is very
easy to operate. Basic copy jobs can be performed by simply pressing the green
start button on the scanner’s operating panel. If you want to perform more
complex copy jobs, you have to change the default copy settings with the help
of the other settings on the scanner operating panel.
The operating panel is located above the original feed. The Océ 9600 Copier
operating panel is illustrated below. As you can see in this diagram, the panel
consists of a display in the center, surrounded by a number of function, section
and arrow buttons. To the left of the display, you can find the Stop and Interrupt
buttons. Below the display, you can find the Start, Numeric and Correction
buttons as well as the Counter window.
This section consists of two parts. The first part explains the basic use of the
buttons. The second part deals with special use of the display. It describes how
to use the soft buttons above and along the sides of the display to define your
copy settings.
.
Stop
button
Interrupt
button
Function
buttons
[12] Scanner operating panel
Section buttons Arrow buttons
Numeric buttons
Correction buttonStart button
40 Océ 9600 Copier/Printer User Manual
Page 41
Display
Buttons
The display is used to make settings for copying. The display provides
feedback about the system status.
The scanner display informs you about:
the number of copies you have selected, the media selection, input mode,
■
zoom settings and exposure.
the actual system status, for example ‘Ready to copy’. In the event of an error
■
in the scanner, the exact error location is graphically shown on the scanner
display, together with instructions on how to solve the problem.
With the buttons on the operating panel you can make a number of settings for
the Océ 9600 Copier.
The following buttons are available:
Button type
Start buttons
Numeric buttons
Correction button
Stop button
Interrupt button
Function
The green button marked with is used to start the
feeding of the original, or to re-start the copy process.
The buttons with numbers on the lower part of the operating panel are used to enter numbers.
The orange button marked with C, located at the bottom
right of the operating panel. If you press the correction
button once, the copy counter is set to the default (probably ‘1’). If you press this button twice, all settings are
reset to their default values.
Pressing the red button to the left of the display stops the
copy process for the current original. You can stop the
original transport immediately when an original jam occurs.
Currently not in use.
Using the Océ 9600 Copier 41
Page 42
Section, Function and Arrow buttons
Apart from the buttons mentioned above, the operating panel of theOcé 9600
Copier contains a number of other buttons. These include:
Section buttons
■
Function buttons
■
Arrow buttons.
■
The section buttons are the four buttons located above the display. These
buttons provide access to the ‘Custom’, ‘Original’ and ‘Copy’ sections on the
display.
Each section contains several functions (cards). These can be accessed with the
help of the function button on the far left, which is also called the card selection
button.
The other function buttons allow you to select functions or subfunctions within
a card.
Finally, the arrow buttons can be used, like the numeric buttons, to define
numeric settings. The arrow buttons are also used for selecting subfunctions
Sections on the operating panel
The operating panel of the Océ 9600 Copier consists of the following three
sections:
Custom
■
Original
■
Copy.
■
Custom section
settings are available from the ‘Custom’ section. These settings, which can
also be found in one of the other two sections, are the most commonly used
options on the Océ 9600 Copier. The key operator can change the contents of
the ‘Custom’ section from the Settings editor on the controller (see ‘Specify
the custom card’ on page 138).
Upon startup of the Océ 9600 Copier, a number of default
42 Océ 9600 Copier/Printer User Manual
Page 43
By default, the ‘Custom’ section includes the ‘Media’, ‘Input mode’ and
‘Zoom’ settings plus one or two others. This could be, depending on your
configuration and language settings, the ‘Folding’ (if you have a folder),
‘Language’ (if you work with more than one language) or ‘Exposure’ settings.
See figure 12 on page 40 for an example of the ‘Custom’ section.
Original section
The ‘Original’ section contains all settings for the original,
divided over a number of cards. The following cards are available (top to
bottom):
Scanner
■
■
Sheet
■
Feeding
■
Each card contains a number of specific options, as shown below.
[13] Original section of the Océ 9600 Copier
Copy section
The ‘Copy’ section contains all settings for the copy, divided
over a number of cards. The following cards are available (top to bottom):
■
Layout
■
Finishing
■
Sheet
■
Using the Océ 9600 Copier 43
Page 44
Each card contains a number of specific options, as shown in figure 14 on
page 44.
[14] Copy section of the Océ 9600 Copier
Settings on the Océ 9600 Copier operating panel
On startup of the Océ 9600 Copier, the ‘Custom’ section is displayed. This
contains a number of default values that have been defined by the key operator.
If you want to make other settings, which are not available from the ‘Custom’
section, you take the following steps:
▼▼▼▼
Make settings on the Océ 9600 Copier operating panel
Press one of the Section buttons to activate the desired menu.
1
The active menu is moved slightly downward to visually separate it
Note:
from the other menus. Apart from that, a shadow highlighting effect is used
for extra highlighting.
Press the Card selection button to select the appropriate card. You can switch
2
cards (from bottom to top) by pressing the button again.
The active card is likewise visually separated from the other cards
Note:
and given a shadow highlighting effect for extra highlighting.
Select the desired function values in one of the following ways:
3
Simple (non-numeric) selection: press the Function button to activate the
■
desired (non-numeric) value. The selected value is preceded by a ‘
’ symbol.
●
The ‘Background compensation’ setting demonstrated in figure 13 on
page 43 is an example of this.
Long list selection: if you want to select a value from a list of options that
■
cannot be fully displayed on the panel, activate the selection triangles next to
the specified option (the dotted line around this selection is changed into an
solid line and the selection triangles are no longer dimmed, indicating that
there are additional options available. Select one of the non-displayed values
44 Océ 9600 Copier/Printer User Manual
Page 45
with the Arrow buttons.) The ‘Original type’ setting demonstrated in figure
13 on page 43 is an example of this.
Numeric selection: activate the selection triangles and select the desired
■
value with the Arrow buttons or with the numeric buttons. The ‘Brightness’
setting demonstrated in figure 13 on page 43 is an example of this.
Also a combination of simple selection and numeric selection is possible, as
shown in the ‘Cut length’ setting demonstrated in figure 14 on page 44.
Note:
The Up arrow and Down arrow buttons can be used to increase or
decrease the active value by 1; the Left arrow and Right arrow buttons
increase or decrease the active value by 10. An exception to this rule is the
selection of zoom values. The Left arrow button can be used to browse
through the predefined reduction steps and the Right arrow button to
browse through the predefined enlargement steps.
Using the Océ 9600 Copier 45
Page 46
Perform basic copy jobs
On the Océ 9600 Copier you can perform a number of basic tasks. These
include:
Starting up and shutting down the scanner
■
Making copies
■
Selecting the required media
■
Selecting the input mode
■
Specifying the zoom factor
■
Select the brightness
■
Delivering originals after scanning
■
Defining settings for the next original
■
Defining delivery of copies
■
Stopping a copy job
■
46 Océ 9600 Copier/Printer User Manual
Page 47
Starting up and shutting down the scanner
TheOcé 9600 Copier can be started up and shut down with the on/off switch,
which is located on the scanner underneath the original feed table (see
figure 15).
The on/off switch has two settings:
on: the scanner is switched on
■
off: the scanner is switched off.
■
▼▼▼▼
▼▼▼▼
[15] On/off switch
Start up
Push the switch to the ‘on’ position.
1
The system is immediately available for work. The message ‘Ready to copy’
appears.
Note:
Shut down
Push the switch to the ‘off’ position.
1
Note:
Make certain the printer and controller are started as well.
The scanner can be turned off while the printer is still working.
Using the Océ 9600 Copier 47
Page 48
Make copies
Place your original face-down, aligned to the right along the original guide.
1
Keep the legend at your right-hand side.
Note:
(about 1 cm) into the machine.
[16] Inserting the original
When feeding the original, keep it in place until it is transported
Inserting the original
Note:
Specify the number of copies using the numeric buttons.
2
Specify the desired copy material on the operating panel.
3
If you select ‘Automatic’ the Océ 9600 Copier will try to use a roll format that
matches the specified size.
After inserting the original, the roll or cassette tray that is used is
Note:
indicated by the ‘
’ symbol.
❍
Use the ‘Media’ function to select copy material and format.
Specify how a job will be sorted: ‘Single sheet’, ‘Multiple sheets’ (output: 1-1,
4
2-2, 3-3) or ‘Set’(output: 1-2-3, 1-2-3).
The currently selected input mode is indicated by the ‘
Specify a reduction or enlargement factor on the operating panel by using the
5
’ symbol.
●
‘Zoom’ function.
If you select ‘Automatic’, the Océ 9600 Copier will use a zoom factor that is
needed to obtain a copy without loss of information. After inserting the
original, the zoom factor that is used is indicated by the ‘
Specify the desired brightness on the operating panel.
6
’ symbol.
❍
You can use the ‘Brightness’ setting to correct for a lighter or darker original.
Specify folding options on the operating panel.
7
If the optional folder is installed, you can use the ‘Folding’ settings to get a
neatly folded copy.
48 Océ 9600 Copier/Printer User Manual
Page 49
Press the green start button to start the copy job.
8
Your original will be fed into the scanner. The printer starts.
Collect your output.
9
Your copy will be delivered on the selected output unit of the print engine.
Selecting the required media
The ‘Media’ setting can be used to select copy material and format. The
display will show you what rolls or cassette trays are currently loaded. The
currently selected roll or cassette tray is indicated by the ‘
If you select ‘Automatic’, the Océ 9600 Copier will try to use a roll or cassette
tray format that matches the original size. After inserting the original, the roll
or cassette tray that is used is indicated by the ‘
’ symbol.
❍
’ symbol.
●
▼▼▼▼
Note:
The
symbol remains in place until a new original is inserted. Then it
’
‘
❍
may move to indicate another roll or cassette tray, depending on the original
format.
Selecting the required media
Select the ‘Sheet’ card in the ‘Copy’ section.
1
Select the desired media with the ‘Media’ function button.
2
Interrupt
Access to
job
Page
[17] Selecting the required media
Note:
You can also select the desired media from the ‘Custom’ section, if this
Access to
ial
setting has been defined for this (see figure 12 on page 40).
Using the Océ 9600 Copier 49
Page 50
Selecting the input mode
You can use the ‘Input mode’ setting to specify how a job will be sorted: the
‘Single sheet’ option treats each sheet as a separate job. ‘Multiple sheets’
produces the specified number of copies for each sheet in a job and then
continues with the next sheet. Graphically that would look something like this:
1 1 1 2 2 2 3 3 3 4 4 4 5 5 5
An important characteristic of ‘Multiple sheets’ is that, if this setting is
Note:
selected, the active job is kept together and treated as a whole. In this case, the
job cannot be interrupted by a high-priority copy job, and there will be no risk
of getting mixed output.
‘Set’ produces one copy for each sheet in a set and then continues with the next
copy of the entire set, as follows:
1 2 3 1 2 3 1 2 3 1 2 3 1 2 3
▼▼▼▼
The current input mode can be closed by pressing the Stop button.
The currently selected input mode is indicated by the ‘
Selecting the input mode
Select the ‘Feeding’ card in the ‘Original’ section.
1
Select the desired media with the ‘Input mode’ function button.
2
Interrupt
Access to
job
Page
[18] Selecting the input mode
You can also select the input mode from the ‘Custom’ section (if this
Note:
Access to
ial
’ symbol.
●
setting has been defined for this).
50 Océ 9600 Copier/Printer User Manual
Page 51
Specifying the zoom factor
You can use the ‘Zoom’ setting to select a zoom factor. If you select
‘Automatic’ with the ‘
that is needed to obtain a copy without loss of information. This will be done
according to the selected media roll or cassette tray. After inserting the
original, the zoom factor that is used is indicated by the ‘
’ symbol, the Océ 9600 Copier will use a zoom factor
●
’ symbol.
❍
▼▼▼▼
If you select the numeric zoom factor with the ‘
’ symbol, you can define a
●
zoom factor yourself between 25% and 400%. After selecting the numeric
zoom factor, the four little triangles will appear to the right. Now you can
define a new zoom factor in two different ways:
By using the Arrow buttons on the right of the display (see figure 12 on
■
page 40). If you press one of the vertical buttons, the zoom factor will
increase or decrease with steps of 0.1%. If you press one of the horizontal
buttons, the zoom factor will increase or decrease with the steps predefined
in the Settings Editor by the key operator.
By using the numeric buttons at the bottom of the operating panel. You can
■
specify the exact zoom factor in increments of 0.1%.
For example, if you want to specify a zoom factor of 25.4%, you type 254. If
you want to specify a zoom factor of 254%, you type 2540.
Selecting the zoom factor
Select the ‘Image’ card in the ‘Copy’ section.
1
Select the desired media with the ‘Zoom’ function button.
2
Interrupt
Access to
job
Page
[19] Selecting the zoom factor
Note:
You can also select the zoom factor from the ‘Custom’ section (if this
setting has been defined for this).
Using the Océ 9600 Copier 51
Access to
ial
Page 52
Select the exposure
You can use the ‘Exposure’ setting to correct for a lighter or darker original.
▼▼▼▼
Selecting the exposure setting
Select the ‘Image’ card in the ‘Original’ section.
1
Select the desired exposure level by using the Arrow buttons to the right of the
2
display (see figure 12 on page 40).
Interrupt
Access to
job
Page
[20] Selecting the exposure level
You can also select the exposure level from the ‘Custom’ section (if this
Note:
Access to
ial
setting has been defined for this).
Delivering originals after scanning
You can choose for delivery of the original at the front (rewind) or the rear side
of the scanner.
Attention:
tray is installed.
Note:
damaged or originals in a carrier sheet, it is recommended to use the output at
the rear side of the scanner to ensure correct delivery (‘Rewind’ function off).
The ‘Rewind’ function is disabled if the optional copy delivery
If you are copying thick or very thin originals, originals that are
52 Océ 9600 Copier/Printer User Manual
Page 53
▼▼▼▼
Select original delivery
Open the ‘Scanner’ card in the ‘Original’ section.
1
Press the ‘Rewind original’ function button to make your selection:
2
‘On’: Originals are delivered at the front side of the scanner. You have to
■
collect each original by hand.
‘Off’: Originals are delivered at the rear side of the scanner.
■
Interrupt
Access to
job
Page
[21] Using the Rewind original function to select original delivery at the front or the rear
Access to
ial
Defining settings for the next original
You can define the settings for each original you want to copy. When
‘Automatic feed’ is enabled, you should bear in mind that the original is
automatically pulled into the scanner. If you want to be absolutely sure about
the settings that belong to an original, insert an original when the settings are
correct.
Note:
key operator to turn off Automatic feed. When using the scanner with
automatic feed off, you must press the start button for each new original to be
scanned. This allows you the possibility of changing the settings for the next
original, even if you already put the original in place on the scanner feed table.
To increase your versatility at the scanner input side, you can ask your
▼▼▼▼
Define settings for the next copy job
Select all settings required for the next original.
1
Insert the next original.
2
If ‘Automatic feed’ is off, press the start button.
If ‘Automatic feed’ is on, the original is fed automatically.
Note:
You can enable or disable this function from the ‘Scanner’ card in the
‘Original’ section. See figure 21 on page 53.
Using the Océ 9600 Copier 53
Page 54
Using the manual feeder for copying
If you want to copy a job on a media type and/or size that is not available on
one of the paper rolls or cassette trays, it is more convenient to manually feed
sheets instead of switching paper rolls or cassette trays. The sheet feed is a
special slot just above the roll drawers on the engine. You can insert pre-cut
copy material in this slot, one sheet at a time.
Only use media as specified in ‘’ on page 287.
Note:
▼▼▼▼
Copying on pre-cut sheets
Open the ‘Sheet’ card in the ‘Copy’ section.
1
Press the ‘Manual feed’ button. The display will look as follows:
2
[22] Using the manual feed option
Select any other required settings.
3
Enter the number of copies using the numeric buttons.
4
Feed in the original.
5
Press the start button.
6
Take your sheet of copy material to the side of the printer engine that contains
7
the sheet feed.
Use both hands to align the copy material in accordance with the format
8
indication and the sticker on the manual feed table.
Move the copy material forward onto the tip of the roller. This should cause an
9
ample paper bulge over the full width of the page.
Hold the paper with both hands until the engine pulls in the first part of the
10
sheet.
The bulge will be reduced or disappear. A few seconds later, the complete sheet
will be pulled into the printer.
If the copy job requires more sheets, the display will ask you to feed
Note:
in the next sheet.
Repeat steps 7 to 11 to complete the job.
11
Collect your output.
12
54 Océ 9600 Copier/Printer User Manual
Page 55
Note:
The image will be printed on the side of the sheet which is facing up.
Defining delivery of copies
Normally, your copies are delivered on the integrated receiving tray on top of
the Océ 9600 Printer. However, you can specify settings for the delivery of
your copies on the optional copy delivery tray or on a folder. If you want to use
your copy delivery tray, take the following steps.
▼▼▼▼
Deliver copies on the copy delivery tray
Open the ‘Finishing’ card in the ‘Copy’ section.
1
Use the ‘Copy delivery’ function button to select the ‘Copy deliv. tray’ option.
2
Interrupt
Access to
job
Page
[23] Delivering copies on the copy delivery tray
Stopping a copy job
Pressing the Stop button interrupts the original transport.
Access to
ial
▼▼▼▼
Stop a job
Press the Stop button.
1
The original transport is now stopped and you are prompted the open the
scanner cover in order to remove the original.
Open the cover, remove the original and close the cover again
2
You are now ready to start the next copy job.
Using the Océ 9600 Copier 55
Page 56
56 Océ 9600 Copier/Printer User Manual
Page 57
Océ 9600 Copier/Printer
User Manual
Chapter 4
Performing special copy jobs
In this chapter, special copy functions are described in
greater detail.
57
Page 58
Non-standard size originals
The scanner of the Océ 9600 system automatically detects the width of the
inserted original. For Example: with European sizes, it detects whether the
width is A0, A1, A2, A3, A4, 500 mm, or 700 mm. The Océ 9600 system uses
a memory table that contains all standard width - standard length combinations
to predict the length of the original. The scanner also measures the real length
of each original while it is transferred through the scanner.
If you are copying thick, thin or damaged originals or originals in a
Note:
carrier sheet, we recommend that you use the output at the rear side of the
scanner to ensure correct delivery (see ‘Delivering originals after scanning’
on page 52).
58 Océ 9600 Copier/Printer User Manual
Page 59
The scan width
To prevent information loss when copying a non-standard original, you can
select the ‘non-standard’ scan width. The scanned width will then be larger
than the original width. It is also possible to define the scanned width and
length yourself.
▼▼▼▼
Defining the scan width
Open the ‘Sheet’ card in the ‘Original’ section.
1
Press ‘Scan width’ to select the required setting:
2
Standard. This option must be used to copy a standard-sized original.
■
Non-standard. This option can be used to copy a non-standard original. The
■
scanned width will be larger than the original width (to the next larger,
standard size), to prevent information loss.
Numeric. You can define the scan width yourself, using the higher/lower
■
buttons or the numeric buttons.
[24] Selecting ‘Non-standard’ scan size
Performing special copy jobs 59
Page 60
The copy size
The copy width depends on the selected roll or cassette tray or the custom
defined scan width, whereas the copy length depends on the selected cut
option.
▼▼▼▼
Copying non-standard size originals
Press the ‘Media’ button in the ‘Sheet’ card of the ‘Copy’ section to select
1
‘Automatic’, or to select the roll or cassette tray with the correct width.
................
[25] Selecting roll or cassette tray in the ‘Custom’ section
The media can also be selected directly from the ‘Custom’ section.
Note:
When ‘Automatic’ is selected, the roll or cassette tray that is used is
Note:
indicated by the ‘
Press the ‘Cut length’ function button to select the required cut option:
2
Standard, which cuts copies at a standard length.
■
Synchro, which cuts copies at the end of the image. The system cuts at the
■
’ symbol.
❍
measured length of the original times the zoom factor.
Custom (numeric), which cuts copies on a specified length. You can define
■
the copy length yourself, using the arrow buttons or the numeric buttons.
Make other settings as required.
3
Feed the original.
4
Refer to table ‘Standard folding settings’ on page 269 for more information
about folding copies of non-standard sized originals.
60 Océ 9600 Copier/Printer User Manual
Page 61
Scanning originals with filing strip
You can adjust the original guide of the scanner to remove a filing strip along
the left-hand side (right-hand side in the feed direction, face-down). This side
can be reduced by up to 60 mm (2.36 inches) (see figure 26).
▼▼▼▼
Face-up:
Left-hand side
- 40 mm (1.57 inches)
[26] Example of adjusting the left-hand side of an original
Copying with removed filing strip along the left-hand side
Press the catch underneath the original guide, and move it to the right.
1
Face-down:
right-hand side
in feed direction
[27] Adjusting the original guide to add or remove a filing strip along the left-hand side
Make all required settings.
2
Insert the original face-down, aligned to the right, with the original guide on
3
the original feed table.
Performing special copy jobs 61
Page 62
You can also remove the filing strip along the right-hand side (left-hand side in
the feed direction, face-down) by selecting a specific roll or cassette tray. If the
paper width of the original is greater than the paper width of the selected roll
or cassette tray, the remaining paper part on the right-hand side will not be
scanned (see figure 28).
▼▼▼▼
Face-up:
Right-hand side
- 40 mm (1.57 inches)
[28] Example of removing the right-hand side of an original
Scan with removed filing strip along the right-hand side
Select the required media in the ‘Custom’ section on the operating panel.
1
Select the 100% value for the ‘Zoom’ function.
2
Make other settings as required.
3
Feed the original.
4
Face-down:
left-hand side in feed
direction
62 Océ 9600 Copier/Printer User Manual
Page 63
It is also possible to adjust the length of both the leading and trailing edge to
eliminate or add a filing strip. Leading and trailing edges can be extended up
to 400 mm (15.7 inches) or shortened up to 100 mm (3.9 inches) (see
figure 29).
▼▼▼▼
Leading edge:
-1.57 in
Trailing edge:
-1.57 in
[29] Example of adjusting the leading/trailing edge of an original
Copy with removed filing strips along the leading and trailing edge
Open the ‘Sheet’ card in the ‘Original’ section.
1
Press the ‘Remove strip’ function button.
2
Leading edge:
1.57 in
Trailing edge:
1.57 in
[30] Removing strip
Adjust the values for the trailing edge using the numeric or arrow buttons.
3
Press the ‘Remove strip’ function button again.
4
Adjust the values for the leading edge using the numeric or arrow buttons.
5
Make other settings as required.
6
Feed the original.
7
Performing special copy jobs 63
Page 64
▼▼▼▼
Copy with added filing strips along the leading and trailing edge
Open the ‘Layout’ card in the ‘Copy’ section.
1
Press the ‘Add strip’ function button.
2
[31] Adding strip
Adjust the values for the trailing edge using the numeric or arrow buttons.
3
Press the ‘Add strip’ function button again.
4
Adjust the values for the leading edge using the numeric or arrow buttons.
5
Make other settings as required.
6
Feed the original.
7
64 Océ 9600 Copier/Printer User Manual
Page 65
Improving the image quality
You can improve the image quality by modifying the exposure setting, or
making use of special functions. You will learn how to turn on and off
automatic background compensation, how to use the lighter and darker buttons
to achieve the best possible copy quality, or how to adjust the brightness based
on the type of image you want to copy.
Brightness
The automatic background compensation will provide a good quality copy
from a large variety of originals. The automatic background compensation
setting, which is activated (by default), ensures the production of
background-free copies of most line drawings.
▼▼▼▼
[32] Brightness settings
Set the automatic background compensation
Open the ‘Image’ card in the ‘Original’ section.
1
Press the ‘Background compensation’ function button if this function is
2
disabled.
When copying extremely light or dark originals, or originals with unequal
background intensity, the result may not meet your requirements (e.g. too
much background). In such cases, you can manually adjust the brightness (see
figure 32).
Performing special copy jobs 65
Page 66
▼▼▼▼
Manually adjust the exposure setting
Press the ‘Exposure’ function button and use the arrow buttons to set the
1
exposure as desired.
The Up and Down arrow buttons can be used to gradually increase
Note:
or decrease the exposure setting; the Left or Right arrow buttons can be
used to go to the highest or lowest available exposure level at once. If you
want to go from any negative value to the highest possible positive value or
vice versa, you have to press the corresponding Left or Right button twice.
Specify other settings as required.
2
Feed in the original.
3
The Océ 9600 Copier allows you to adjust the exposure setting according to
the type of image on the original. There are five original types available. Select
a suitable mode according to the original (see figure 32 on page 65).
▼▼▼▼
Adjust the brightness according the type of image
Press the ‘Original type’ function button to select the appropriate image type:
1
By default ‘Lines/text’ is selected with ‘Background compensation’ enabled.
■
This is the most suitable setting for originals that contain characters and line
art.
Press the ‘Original type’ function button to select ‘Photo’ when the original
■
consists of a combination of characters, line art and picture images.
If you select ‘Photo’ or ‘Grays&lines’ , the ‘Background
Note:
compensation’ will be disabled automatically by default.
Press the ‘Original type’ function button to select ‘Grays&lines’ when the
■
original contains many gray scales and lines.
Press the ‘Original type’ function button to select ‘Blue print’ when you want
■
to copy an original with an image in ‘negative’ (image in white on dark
background). The copy will be ‘positive’ (image in black on white
background).
Press the ‘Original type’ function button to select ‘Dark orig’ when the
■
original has an extremely dark background (i.e. low contrast).
Specify other settings as required.
2
Feed in the original.
3
66 Océ 9600 Copier/Printer User Manual
Page 67
Editing functions
The Océ 9600 Copier is equipped with a number of editing functions. These
functions can be set before scanning the original.
Note:
Auto shift
By selecting the automatic shift function you can move your image to one side
of the page.
Auto shift supports these shift options:
You can select only one edit function at a time.
Top Left Top Middle Top Right
[33] Auto shift options with standard cut option active
Performing special copy jobs 67
Middle Left Middle Middle Right
Bottom Left Bottom Middle Bottom Right
Page 68
You must turn on standard cut length to get copies like the one in the
Note:
illustration 33 above. If synchro cut length has been turned on, the result will
be as follows:
Top Left Top Middle Top Right
Middle Left Middle Middle Right
Bottom Left Bottom Middle Bottom Right
[34] Auto shift options with synchro cut option active
In ‘Shift the image’ on page 69 you can read how to define the exact place of
your image on the page.
▼▼▼▼
Select default settings for auto shifting
Open the ‘Layout’ card in the ‘Copy’ section.
1
[35] Automatic shift with the ‘Align’ function
Press the ‘Align’ function button and select a horizontal alignment value (Left,
2
Middle or Right) with the arrow buttons.
Press the ‘Align’ function button again and select a vertical alignment value
3
(Top, Middle, or Bottom) with the arrow buttons.
If you select ‘Center’, make sure the original width is specified as
Note:
follows (see ‘The scan width’ on page 59):
‘Standard’ if a standard sized original is used
■
The exact original width (numeric) if a non standard sized original is used.
■
Feed your original.
4
68 Océ 9600 Copier/Printer User Manual
Page 69
Shift the image
In some cases the margin may be too narrow to accommodate filing strips
without loss of information. To avoid this, you can shift the image in horizontal
and/or vertical direction, as shown below.
[36] Example of shifting the image
Performing special copy jobs 69
Page 70
▼▼▼▼
Shift the image
Open the ‘Layout’ card in the ‘Copy’ section.
1
[37] Image shift
Press the ‘Shift’ function button and select a horizontal shift value by pressing
2
the numeric or arrow buttons until the required distance is set to shift the image
to the left or to the right.
When you shift the image horizontally, you can only shift to the left or to
Note:
the right.
Press the ‘Shift’ function button again and select a vertical shift value by
3
pressing the numeric or arrow buttons until the required distance is set to shift
the image upwards or downwards.
When you shift the image vertically, you can only shift up or down.
Note:
Specify other settings as required.
4
Feed in the original.
5
You can use horizontal and vertical shift simultaneously.
Note:
70 Océ 9600 Copier/Printer User Manual
Page 71
Mirror-image copies
With the Océ 9600 Copier you can make a mirror-image copy of an original,
as shown in the next figure:
[38] Example of a mirror-image copy
▼▼▼▼
Make mirror-image copy
Open the ‘Image’ card in the ‘Copy’ section.
1
Roll 2
Process
type
[39] Mirror-image
Press the ‘Mirror’ function button to enable the ‘Mirror’ function.
2
Specify other settings as required and feed in the original.
3
Performing special copy jobs 71
Page 72
72 Océ 9600 Copier/Printer User Manual
Page 73
Océ 9600 Copier/Printer
User Manual
Chapter 5
Managing print and copy jobs
This chapter describes how to view the Océ 9600
print/copy queue and how to abort the active print, how to
delete and put on hold print and copy jobs in the queue and
how to restart jobs that are put on hold.
73
Page 74
Introduction
The Océ 9600 Queue Manager application provides you with a graphical
representation of the print queue. It allows you to view the print queue and the
status of the print jobs as well as to manage the jobs in the queue. With the Océ
9600 Queue Manager you can:
Abort the job currently being printed
■
Delete job(s) in the queue
■
Put job(s) in the queue on hold
■
Restart job(s) that were previously put on hold in the queue
■
Structure
The Océ 9600 Queue Manager window is divided into the following parts (see
figure 40 on page 75):
The standard menu bar.
■
The menu bar for the Queue Manager contains the following menus:
File options: Login, Logout, Connect to, Exit
■
Edit options: defining first and second language and setting default printer
■
(only remote). The 'Auto login' option allows you to start the Queue Manager
application automatically in the specified user mode.
View options: selecting first and second language
■
Help options: About Queue Manager, Contents of Queue Manager,
■
The active print job window.
■
This window displays the job currently being printed on the Océ 9600.
The print queue window.
■
This window has a tabular format and shows the jobs waiting to be printed.
The jobs are displayed in the order in which they are expected to be printed.
Copy jobs are automatically moved up in the queue, because they take
Note:
preference over print jobs.
Status bar
■
The Queue Manager has a status bar displaying the following information:
System status (connected, not connected)
■
Server (system that contains the controller)
■
User mode
■
74 Océ 9600 Copier/Printer User Manual
Page 75
menu bar
active print
job window
The following information is displayed for each job:
The current status of the job in the form of an icon. See ‘Icons’ on page 77.
■
The name of the print job.
■
The type of job (print job / copy job)
■
The name of the user who has submitted the print job.
■
The number of sets and pages.
■
Any remarks (e.g. 'Manual Feed').
■
You can resize the columns in the main queue window by dragging the table
header separators. It is also possible to change the order of the columns by
dragging a specific column to a new position.
header
separator
print queue
window
status
bar
[40] Queue Manager window
Modes
■
■
■
■
The Océ 9600 Queue Manager has four modes:
Anonymous user mode
Repro operator mode
Key operator mode
System administrator mode
These different modes are designed to limit access to specific functions to
authorized users only.
The anonymous user mode only offers view access to the queue. In this mode,
the available buttons are disabled, except for the
9600 system.
Managing print and copy jobs 75
Abort
button on the local Océ
Page 76
The repro operator, the key operator and the system administrator modes allow
you to perform a number of activities on the jobs in the queue, with the help of
the Abort, Delete, Resume and Hold buttons.
In the Queue Manager and the System Control Panel, the repro operator,
Note:
the key operator and the system administrator have the same user rights. In the
Settings Editor, however, the user modes offer different rights.
Access
The access to the key operator, repro operator and system
administrator modes is password protected to allow only authorized personnel
to use particular functions. You can enter these modes by selecting the Login
option from the File menu and by specifying the correct password when
prompted for it (see ‘Log in’ on page 122).
You can exit the Queue Manager altogether by selecting the
File
the
Note:
menu.
The Exit option is only available when you are working remotely (see
Exit
option from
chapter 8, ‘Remote Logic’ on page 113). In local mode you cannot stop the
Queue Manager.
Job priority
The priority of print jobs in the Queue Manager is determined by
the order in which they are submitted to the Océ 9600. However, there is a
setting in the Settings Editor which allows you to give copy jobs priority over
print jobs. See ‘Copy priorities’ on page 179 for more information.
76 Océ 9600 Copier/Printer User Manual
Page 77
Icons
The Océ 9600 Queue Manager uses a number of icons to display information
about a job in the queue. The following icons are used:
The job is in the spool and is currently being transferred to the print
queue.
The job is currently being processed for printing in the print queue.
The job is ready for printing in the print queue.
The job is being received and printed at the same time.
The job is being processed and printed at the same time.
The job is being printed.
Note:
Jobs that are being printed (this is indicated by a printer
symbol next to the job in the queue) cannot be put on hold anymore.
If you select such a job, the Hold button is disabled.
Indicates, both in the active print job and in the print queue
window, that the job needs special operator attention (e.g. manual
feed).
The job is marked for deletion and will be automatically deleted
after a few seconds.
The job is put on hold.
Managing print and copy jobs 77
Page 78
The connection to a controller
The Océ 9600 applications are not only available locally or on the controller,
but are also delivered as remote or client versions (except for Scan Manager).
This means that users can access one or more Océ 9600 systems from their own
computer.
Anonymous users can view the status of both their jobs (Queue Manager) and
the entire system (System Control Panel). This way they can, for instance,
determine which queue is shortest and send their jobs there to avoid lengthy
delays.
From a management point of view, the availability of remote versions of the
applications is quite useful as well. The remote applications allow key
operators and system administrators to manage multiple Océ 9600 systems
from a single location. They can centrally monitor the system status and
identify potential problems without having to work at the controller itself.
When the Océ 9600 Queue Manager has been installed on a remote client, the
Connect to option is available in the File menu.
▼▼▼▼
Connect to a controller
Click on the Connect to option in the File menu.
1
A dialogue box will appear containing all the available Océ 9600 systems.
Select one of the available Océ 9600 systems and click on OK.
2
If the system you want to connect to is not available in the list, you can
Note:
click on the Edit... button. A dialogue box will appear which allows you to
manually add a Océ 9600 system. For this you need a valid IP address.
78 Océ 9600 Copier/Printer User Manual
Page 79
Managing print jobs
The Océ 9600 Queue Manager allows you to perform the following operations:
View the print queue
■
Abort the job currently being printed
■
Delete job(s) in the queue
■
Put job(s) in the queue on hold
■
Restart job(s) that were previously put on hold in the queue
■
▼▼▼▼
▼▼▼▼
View the print queue
The Océ 9600 Queue Manager displays all jobs sent to the print queue in a list
sorted according to the order in which they are expected to be printed. This
ordering can be changed by deleting jobs, putting jobs on hold or restarting
jobs currently on hold. This list will be automatically updated.
Note:
Queue operations can only be performed when you are properly
authorized. Before you can use the Queue Manager in a different mode, you
first have to enter a password to get the required access (see ‘User modes’
on page 121).
Abort the job currently being printed
Click on the Abort button to the right of the active print job window. The active
1
job will now be aborted.
Note:
To abort the job which is currently being printed on the controller, no
password is required. To abort the current job from a remote client, you
need repro operator, key operator or system administrator rights.
Note:
Consider carefully before you use the Abort button. An abort
operation cannot be undone.
Managing print and copy jobs 79
Page 80
▼▼▼▼
Delete print jobs
Select the desired job(s) by clicking on them.
1
You can select a consecutive list of jobs to be deleted by clicking on
Note:
the first job, holding down the Shift key and clicking on the last job. You can
select a non-consecutive list of jobs to be deleted by clicking on each
desired job while holding down the Ctrl key.
To delete a job from a remote client, you need repro operator, key
Note:
operator or system administrator rights.
Click on the Delete button.
2
A cross icon is displayed in front of the job and a confirmation window will
now be displayed.
Consider carefully before you use the Delete button. A delete
Note:
operation cannot be undone.
▼▼▼▼
▼▼▼▼
Put print jobs on hold
Select the desired job(s) by clicking on them.
1
You can select a consecutive list of jobs to be put on hold by clicking
Note:
on the first job, holding down the Shift key and clicking on the last job. You
can select a non-consecutive list of jobs to be put on hold by clicking on
each desired job while holding down the Ctrl key.
Click on the Hold button.
2
An icon for a job that is put on hold (see ‘Icons’ on page 77) is displayed in
front of the job when the job is put on hold.
A job that is put on hold will retain its position in the print queue.
Note:
Once it reaches the top of the queue, the job that is put on hold will stay
there until it is restarted or deleted. While a job is on hold, other jobs will
be printed, even when they were behind the job on hold in the queue. The
active job and the jobs in printing state cannot be put on hold by the Queue
Manager.
Restart jobs that are put on hold
Select the desired job(s) by clicking on them.
1
You can select a consecutive list of jobs to be restarted by clicking on
Note:
the first job, holding down the Shift key and clicking on the last job. You can
select a non-consecutive list of jobs to be restarted by clicking on each
desired job while holding down the Ctrl key.
Click on the Resume button.
2
The selected job(s) will now be restarted.
80 Océ 9600 Copier/Printer User Manual
Page 81
Chapter 6
Scan to file
Océ 9600 Copier/Printer
User Manual
This chapter describes the Océ 9600 scan-to-file function.
81
Page 82
Introduction
Scan-to-file is an option which enables you to scan a document to a file for later
(re)use. You enable scan-to-file via a password (see ‘Scan-to-file password
(single)’ on page 177).
You use scan-to-file in order to:
print documents at a later time
■
archive documents
■
email documents
■
reuse the information documents contain in another application
■
A scan-to-file is made at the Océ 9600 scanner. On the scanner operating panel
you can, among other things, choose at which resolution you want to scan and
where you want to store your file.
The result of the scan-to-file can be stored on the controller (temporary store)
or directed forward towards a network destination via Window’s Network
Neighborhood.
Océ View Station, linked to the Scan Manager application, enables you to
automatically or manually view the scanned documents afterwards.
82 Océ 9600 Copier/Printer User Manual
Page 83
Make a scan-to-file
Scanning an original to file is an easy operation. If the settings (see chapter ,
‘Settings for scan-to-file’ on page 85) are correct, the only thing you have to
do is press the start button on the scanner.
▼▼▼▼
Scan-to-file
Place your original face-down, aligned to the right along the original guide.
1
Select the appropriate original type.
2
Select the ‘Destination’ card in the ‘File’ section.
3
[41] ‘Destination’ card in the file section
Select ‘File mode’ On.
4
The status message is displayed: Ready to scan to file.
Select a Destination (see ‘Destinations’ on page 93).
5
Press the start button
6
.
The original is scanned.
A status message is displayed (see figure 42 on page 84):
“Scanning job “Scan job number X””
“File scan22.tif”
Scan to file 83
Page 84
[42] Feedback during scan-to-file
On the controller, Océ View Station starts automatically, showing the result of
7
the scan (see figure 43).
[43] Océ View Station
84 Océ 9600 Copier/Printer User Manual
Page 85
Settings for scan-to-file
The settings regarding scan-to-file on the scanner operating panel are divided
into two cards: Destination and Image.
Destination card:
File mode
■
Destination
■
File type
■
Tiff subformat
■
[44] Scanner operating panel: Destination card
Image card:
Resolution
■
Zoom
■
Optimization
■
Mirror
■
[45] Scanner operating panel: Image card
Scan to file 85
Page 86
File mode
File mode can be ‘Off’, ‘On’ or ‘On with check plot’. ‘Off’ means normal copy
mode. ‘On’ results in scan-to-file. Choose ‘On with check plot’ to scan to file
with a check plot. A check plot is a print of the scanned original, ensuring
consistency with a later re-print.
Note:
setting during a set from ‘On’ to ‘Off ’ or vice versa. However, changing from
‘On’ to ‘On with checkplot’ and vice versa is allowed.
Note:
Turning check plot on or off does not influence this automatic behavior
Destination
You can store your scan either in the temporary store on the controller or on a
network destination. You can define up to ten destinations in the Scan Manager
application. On the scanner operating panel you can choose one of these
destinations.
The Océ 9600 system does not allow you to change the ‘File mode’
In scan-to-file mode, the automatic behavior is optimized for scanning.
▼▼▼▼
1
2
File type
Select a destination
Press the function button to select destination 1 through 4.
To select destinations four through ten, you have to begin by selecting
destination four. Press the arrow buttons to select destinations 4 through 10.
You can choose any name for the destinations. However, for your
Note:
convenience, you are able to define understandable nicknames in the Scan
Manager application (see ‘Create a destination’ on page 93).
To define the internal organization of the scanned files, choose between TIFF
(Tagged Image File Format) and CALS-I (Continuous Acquisition and
Life-Cycle support).
describes image data that typically comes from scanners, frame grabbers,
TIFF
and paint- and photo-retouching programs. The purpose of TIFF is to describe
and store raster image data. A primary goal of TIFF is to provide a rich
86 Océ 9600 Copier/Printer User Manual
Page 87
environment within which applications can exchange image data. This
richness is required to take advantage of the varying capabilities of scanners
and other imaging devices. For example, TIFF supports image compression
with no loss. Though TIFF is a rich format, it can easily be used for simple
scanners and applications as well because the number of required fields is
small.
CALS
highly automated, integrated processes for defense system acquisition, design,
manufacturing, and life cycle support.
Tiff subformat
Within the ‘Tiff subformat’ option, you can define the ‘Organization’ and
‘Compression’ of the file.
Organization
Stripped
■
Tiled
■
Raw
■
Note:
organizations afterwards. Choose ‘Raw’ in any other case.
Compression
■
■
■
Only choose ‘Stripped’ or ‘Tiled’ when you are sure you can use these
Group 4
Group 3-1D
None
is an industry strategy for transition of paper-intensive processes to
can be (select with the arrow buttons):
can be (select with the arrow buttons):
Note:
Only choose ‘Group 4’ or ‘Group 3-1D’ when you are sure you can use
these compressions afterwards. Choose ‘None’ in any other case.
Note:
If you are scanning grayscales or dark originals, use Group 3-1D
compression. In these cases, group 4 can increase the file size.
Note:
‘Group 4’ or ‘Group 3-1D’ are compression methods which are
optimized for text and vector drawings. If you choose these compressions when
scanning a photo with many grayscales, these compressions can result in a
negative compression: the file size increases instead of decreasing. Use these
compressions sparingly.
Scan to file 87
Page 88
Resolution
The Océ 9600 scan-to-file option allows you to scan at the following three
resolutions:
■
■
■
The higher the resolution, the better the image quality. Higher resolution also
leads to larger file sizes. The default value is 200 dpi.
Zoom
The ‘Zoom’ option allows you to scale while scanning to a file. When you set
‘File mode’ to ‘On’, the automatic ‘Zoom’ setting will result in ‘1:1’. You can
change this default setting into one of the following three settings:
200 dots per inch (dpi)
300 dpi
400 dpi
Custom
range from 25% to 400%. This value also shows the zoom value when the
‘Automatic’ option is chosen.
With this option selected, scan-to-file will result in an image that is exactly
1:1
the same size as the original. ‘Zoom’ displays 100%.
Automatic
Optimization
There are two ways to optimize a scan to file.
Scan quality
original as much as possible.
File size
size and an image quality comparable to copy quality.
This option let’s you specify a custom zoom value. You can enter a
Selecting ‘Automatic’ always results in a 1:1 scan to file.
optimizes for the best image quality. The scan resembles the
optimizes for better compression. Generally resulting in a smaller file
88 Océ 9600 Copier/Printer User Manual
Page 89
Mirror
You can use the ‘Mirror’ option to scan a horizontally mirrored image of an
original. Mirroring is performed in the vertical axis.
Scan to file 89
Page 90
Scan Manager
The Scan Manager is an application available only locally on the controller.
With the Scan Manager you can configure the destinations for scan-to-file. To
increase your productivity, you can define automatic file naming. This way,
you can do batch scans without operating the controller.
During scan-to-file, Scan Manager displays the filename and the status of the
file generation process. When the scan is completed, a view of the scanned
image is automatically displayed on the controller.
Figure 46 on page 90 shows the Scan Manager application. It has the looks and
functions of a Microsoft Windows ‘Explorer’. The left part displays a tree view
containing folders which contain destinations. The right part displays a table
view containing the content of the folder currently selected. In 46 on page 90
folder ‘Next Dest(8)’ is selected.
[46] Overview of the Océ 9600 Scan Manager application
90 Océ 9600 Copier/Printer User Manual
Page 91
Note:
user mode to perform specific tasks with Océ 9600 Scan Manager (see ‘User
modes’ on page 121).
Tree view
The tree view displays:
■
■
■
Not all options are available to all users. You must log into a particular
the system name
the collapsible destination tree
the collapsible temporary store tree.
If you scan to a particular destination, that destination is displayed in
well as the corresponding icon changes. The destination to which you last
scanned, is displayed in bold.
If you select a destination in order to view it’s content in the right table viewer,
this destination will appear as having been selected. Figure 46 on page 90
shows that the destination ‘Temp10’ is selected.
If for any reason a scan to file cannot be sent to the appropriate remote
destination, the file will be stored in the ‘Unsent’ folder.
Table view
The table view (on the right side of figure 46 on page 90) displays the
filenames of the files in the opened destination or temporary folder.
Each file has the following information:
■
■
■
■
■
■
Name
Size
Type
Modified
Resolution
Image size.
bold
as
If the currently viewed destination is the one you are scanning to, then the
scanned file will appear at the end of the table. If you currently view another
destination than the one you are scanning to, the scanned to destination is
displayed in bold.
Scan to file 91
Page 92
It is possible that there are more files in the table than fit on the screen. The
most recently scanned files appear at the end of the table. Under these
circumstances, it is possible that your most recent scanned file is not visible in
the on-screen table. In this case, you can update the table view.
▼▼▼▼
Update the table view
From the ‘View’ menu select ‘Refresh’ or click the ‘Refresh’ button on the
1
toolbar (see figure 47). If the opened destination is also the one which is
currently scanned to, the view is automatically updated.
[47] ‘Refresh’ button on the toolbar
92 Océ 9600 Copier/Printer User Manual
Page 93
Actions from the Scan Manager
The Océ 9600 Scan Manager enables you to choose settings regarding
scan-to-file. You can edit and view the destination properties. You can also
view the properties of scanned files.
Destinations
A destination is a place to which you scan your file. You can create, delete and
lock destinations. You can also define automatic file naming to ensure your
files get the desired names.
A destination can also be a file server or an end user PC. It is better to select
remote destinations instead of the local ones. The local destinations are
temporary and cannot contain many of scan files.
▼▼▼▼
Create a destination
Select ‘Destinations’ in the tree view.
1
Open the ‘File’ menu and select ‘New’ or click on the ‘New’ button on the
2
toolbar (see figure 48).
[48] ‘New’ button on the toolbar
Scan to file 93
Page 94
The following dialog box appears (see figure 49):
[49] ‘Destination properties’ window
Enter a logical name for the destination in the ‘Name’ text box.
3
This logical name also appears on the scanner panel (see figure 41 on page 83).
Choose a destination type from the ‘Type’ drop-down list box.
4
You can choose between File Transfer Protocol (FTP), Server Messages Block
(SMB) or local storing in the temporary store on the controller.
Enter the name of the system you want to scan your files to in the ‘System’ text
5
box.
Enter a path of the target folder in the ‘Path’ text box. You can also click the
6
‘Browse’ button to select the path.
This is only possible if you choose ‘On the controller’ as ‘Type’ (see
Note:
step 4).
Enter, if required, a user name for the network destination in the ‘User name’
7
textbox.
Enter, if required, the appropriate password for the network destination in the
8
‘Password’ textbox.
Click Ok to accept the destination properties.
9
You can create a maximum number of 10 destinations.
Note:
A key operator can determine whether a destination can be modified by an
anonymous user. This done by locking and unlocking a destination.
▼▼▼▼
94 Océ 9600 Copier/Printer User Manual
Lock a destination
Select a destination.
1
Open the ‘File’ menu and select ‘Properties’.
2
Check the ‘Locked’ check box.
3
Page 95
Click Ok to accept the destination settings.
4
The destination properties are now locked.
Note:
This option is only available if you are logged on as a Key operator (see
chapter , ‘User modes’ on page 121).
▼▼▼▼
▼▼▼▼
Unlock a destination
Select a destination.
1
Open the ‘File’ menu and select ‘Properties’.
2
Uncheck the ‘Locked’ check box.
3
Click Ok to accept the destination settings.
4
The destination properties are now unlocked.
Note:
This option is only available if you are logged on as a Key operator (see
chapter , ‘User modes’ on page 121).
Delete a destination
Select a destination.
1
Open the ‘File’ menu and select ‘Delete’ or click the ‘Delete’ button on the
2
toolbar (see figure 50).
[50] ‘Delete’ button on the toolbar
The selected destination is deleted.
Note:
This option is only available if you are logged on as a Key operator or
as a Repro operator.
▼▼▼▼
Note:
Define file name
Select a destination.
1
Open the ‘File’ menu and select ‘Properties’.
2
You are not able to delete the last destination.
The ‘Destination properties’ screen appears as in figure 49 on page 94.
Enter a name in the ‘Base name’ textbox.
3
Note:
The ‘Base name’ may contain ‘###’ for automatic file naming. The
‘###’ will be replaced by an ascending number. You may place an equal
amount of dots in the ‘Base name’.
Check or uncheck the ‘Add appropriate file extension’ check box to add or
4
respectively leave out an appropriate file extension. The file extension can be
set in the Settings Editor (see ‘File extension TIFF’ on page 155 or ‘File
extension CALS’ on page 155).
Click Ok to accept the settings.
5
Scan to file 95
Page 96
▼▼▼▼
Set / Change destination properties
Select a destination.
1
Open the ‘File’ menu and select ‘Properties’ or click the ‘Properties’ button on
2
the toolbar (see figure 51).
[51] ‘Properties’ button on the toolbar
The ‘Destination properties’ screen appears as in figure 49 on page 94.
Change the destination properties as described in ‘Create a destination’ on
3
page 93.
Scanned files
The right-hand pane of the Océ 9600 Scan Manager contains the scanned files
and additional information about the files. You can view, print and delete these
files. You can also view the file properties.
▼▼▼▼
▼▼▼▼
View a scanned file
Select a file in the right-hand pane.
1
Open the ‘File’ menu and select ‘View’ or click the ‘View’ button on the
2
toolbar (see figure 52).
[52] ‘View’ button on the toolbar
Océ View Station (see ‘Océ View Station’ on page 101) starts up and displays
the file.
When you scan to file, the Océ View Station controller starts
Note:
automatically, showing the result of the scan.
Print a scanned file
Select a file in the right-hand pane.
1
Open the ‘File’ menu and select ‘Print’ or click the ‘Print’ button on the toolbar
2
(see figure 53).
[53] ‘Print’ button on the toolbar
The selected file will be printed with the default settings as defined in the
Settings Editor (see ‘Job-related settings for printing’ on page 158).
96 Océ 9600 Copier/Printer User Manual
Page 97
▼▼▼▼
Delete a scanned file
Select a file in the right-hand pane.
1
Open the ‘File’ menu and select ‘Delete’ or click the ‘Delete’ button on the
2
toolbar (see figure 54).
[54] ‘Delete’ button on the toolbar.
The selected file will be deleted.
Note:
This option is only available if you are logged on as a Key operator
or as a Repro operator.
▼▼▼▼
View properties of a scanned file
Select a file in the right-hand pane.
1
Open the ‘File’ menu and select ‘Properties’ or click the ‘Properties’ button on
2
the toolbar (see figure 55).
[55] ‘Properties’ button on the toolbar.
The following window appears (see ‘‘Scanfile properties’ window’ on
page 97):
[56] ‘Scanfile properties’ window
Click OK to close the ‘Scanfile properties’ window.
3
Scan to file 97
Page 98
▼▼▼▼
Automatically view a file after scanning
You can choose to view a file automatically after scanning:
Open the ‘System’ menu and select ‘Auto view’.
1
Whenever you scan to file, Océ View Station will start automatically and show
the scanned file.
Manage the temporary store
When you regularly scan originals to a file, many files are created in the
temporary store. You can clean up the temporary store manually or
automatically.
To manually delete
the files in the temporary store, select the ‘Purge’
command from the ‘System’ menu.
To automatically delete
the scanned files from the temporary store, you must
choose some settings in the Océ 9600 Settings Editor (see chapter 10, ‘Key
operator settings’ on page 129).
98 Océ 9600 Copier/Printer User Manual
Page 99
How to retrieve scanned files?
When you scan to file, your files will be stored in the destination you set. This
can be on the local controller or on a remote system. You can retrieve your files
from the local host via File Transfer Protocol (FTP) (see figure 57). Also, if
during scanning to a remote destination something goes wrong, you can
retrieve your files from the local host.
P
T
F
a
i
v
s
e
l
i
f
t
e
G
G
e
t
f
i
l
e
s
v
i
a
F
T
P
Local host (Controller)
Windows NT 4.0
Remote client
Windows 95 / 98
[57] How to retrieve scanned files?
Get files via FTP
Launch an FTP client.
1
Enter the ‘ftp’ command.
2
A DOS box now appears with the FTP prompt.
Enter the ‘Open’ command followed by either the registered name of the Next
3
Generation Controller (NGC) or the IP address (for example: 194.2.66.146) to
connect to the NGC and press Enter: ‘open 194.2.66.146’.
Note:
in the FTP client.
The connection with the NGC is now established and a window appears asking
you for a user name.
Enter the user name ‘anonymous’, and enter ‘anonymous’as your password
4
also.
A connection is now set up for the ‘anonymous’default user.
Instead of performing steps 2 and 3, you could type “ftp host_name”
Remote client
Windows NT 4.0
Scan to file 99
Page 100
Because there is no registered user, you can simply press Enter to
Note:
initiate the connection.
Set the transmission mode to binary by entering ‘binary’.
5
Go to the ‘tempstore’ directory using the following command: ‘cd tempstore\’.
6
Go to the ‘scan’ directory if you want to retrieve a file from a destination on
7
the local host,
or
go to the ‘unsent’ directory if you want to retrieve a file from ‘unsent’ folder
on the local host.
Get the data file (for example: bugatti.tif) via the ‘get’ command:
8
‘get bugatti.tif’.
Quit FTP by entering the ‘bye’ command.
9
100 Océ 9600 Copier/Printer User Manual
Loading...
