BLK-PTZ36X High Resolution 36x Zoom Outdoor PTZ Camera User Manual

Products: BLK-PTZ36X

Please read this manual before using your camera, and always follow the instructions for safety and proper use. Save this manual for future reference.

BLK-PTZ36X_CM

11/06/13

REGULATORY NOTICE

FCC Information

FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

This product and - if applicable - the supplied accessories too are marked with “CE” and comply therefore with the applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC.

LEGAL NOTICE

Observint Technologies (Observint) products are designed to meet safety and performance standards with the use of specic Observint authorized accessories. Observint disclaims liability associated with the use of non-Obser vint authorized accessories.

The recording, transmission, or broadcast of any person’s voice without their consent or a court order is strictly prohibited by law.

Observint makes no representations concerning the legality of certain product applications such as the making, transmission, or recording of video and/or audio signals of others without their knowledge and/or consent. We encourage you to check and comply with all applicable local, state, and federal laws and regulations before engaging in any form of surveillance or any transmission of radio frequencies.

The BLACK Line is a trademark of Obser vint Technologies.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Observint disclaims any proprietary interest in trademarks and trade names other than its own.

No part of this document may be reproduced or distributed in any form or by any means without the express written permission of Observint

11000 N. Mopac Expressway, Building 300, Austin, TX 78759 For Sales and Support, please contact your distributor.

iii

36x PTZ Dome Camera User Manual

SAFETY WARNINGS AND CAUTIONS

Safety Warnings and Cautions

WARNING

Hazardous Voltage may be present: Special measures and precautions must be taken when using this device. Some potentials (voltages) on the device may present a hazard to the user. This device should only be used by those with knowledge and training in working with these types of devices that contain live circuits.

WARNING

Power Supply Hazardous Voltage: AC voltages are present within the power supply assembly. This device must be connected to a UL approved, completely enclosed power supply, of the proper rated voltage and current. No user serviceable parts inside the power supply.

WARNING

Connect only to a properly earth grounded outlet. To avoid shock, ensure that all AC wiring is not exposed and that the earth grounding is maintained. Ensure that any equipment to which this device will be attached is also connected to properly wired grounded receptacles and are approved medical devices.

WARNING

Power Connect and Disconnect: The AC power supply cord is the main disconnect device to AC power. The socket outlet must be installed near the equipment and must be readily accessible. Installation and Maintenance: Do not connect/disconnect any cables to or perform installation/maintenance on this device during an electrical storm.

WARNING

Power Cord Requirements: The connector that plugs into the wall outlet must be a grounding-type male plug designed for use in your region. It must have certication marks showing certication by an agency in your region. The connector that plugs into the AC receptacle on the power supply must be an IEC 320, sheet C13, female connector. See the following website for more information http://kropla.com/electric2.htm.

WARNING

Lithium Battery: This device contains a Lithium Battery. There is a risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries according to the vendor’s instructions and in accordance with local environmental regulations. Perchlorate Material: Special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate. This notice is required by California Code of Regulations, Title 22, Division 4.5, Chapter 33: Best Management Practices for Perchlorate Materials. This device includes a battery which contains perchlorate material.

SAFETY WARNINGS AND CAUTIONS

CAUTION



Management Practices for Perchlorate Materials. This device includes a bat tery which contains perchlorate material. Electromagnetic Interference: This equipment has not been tested for compliance with emissions limits of FCC and

similar international regulations. This device is not, and may not be, oered for sale or lease, or sold, or leased until authorization from the United States FCC or its equivalent in other countries has been obtained. Use of this equipment in a residential location is prohibited. This equipment generates, uses and can radiate radio frequency energy which may result in harmful interference to radio communications. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and o, the user is required to take measures to eliminate the interference or discontinue the use of this equipment.

Warnings

• Use of the product only when in compliance with local electrical safety regulations.

• Use only the required power adapter. The standard power adapter is 24 Vac / 1.5 A.

• Do not connect additional devices to the power adapter. Doing so may over-heat the device and cause a re hazard.

• Always make sure that the power adapter plug is fully inserted into the power socket.

• When the product is installed on a wall or ceiling, it must be securely attached.

• If the camera emits smoke, odors or noise power it o immediately and unplug the power cable. Contact the service center.

• If the camera does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble

the camera yourself. (Your provider is not responsibility for problems caused by unauthorized repair or maintenance.)

Cautions

• Do not drop the dome or subject it to physical shock. Do not expose it to high levels of electromagnetic radiation.

• Do not install the camera on surfaces that are subject to vibrations or shock.

• Do not place the camera in extremely hot, cold (operating temperature range: -22 °F ~ 149 °F (-30 °C ~ +65°C)),

dusty or damp locations. Fire or electrical shock can occur.

• Exposing the equipment to direct sunlight, low ventilation or heat sources such as heater or radiator should be avoided.

• Do not aim the camera at the sun or extra bright places. A blooming or smear may occur (which is not a malfunction however),

and aect the longevity of CCD.

• Use the glove provided when opening the dome cover. Do not touch the dome cover; the acidic moisture on skin can erode the

surface coating.

• Please use a soft and dry cloth when cleaning the inside and outside surfaces of the dome cover. Do not use alkaline

detergents.

36x PTZ Dome Camera User Manual

PREPARATION FOR INSTALLATION

Preparation for Installation

• Basic requirements: — All the electronic operations must be compliant with local electrical safety regulations, re prevention regulations and

other related regulations.

— Verify that all accessories are included with your shipment. — Make sure that the camera is suitable for the location and security requirements where it will be installed. If not, please

contact the supplier.

— Always use this product in accordance with the manufactures specications and recommendations.

• Check installation space. Make sure the place have enough space to install the camera and its accessories.

• Check the intensity of conformation at the installation location. Please make sure that the ceilings or walls are strong enough to

withstand four times the weight of camera and its accessories.

• Preparation of cables: — Choose video cable in accordance with the transmission distance. The video should meet the least demands as: 75 Ω

resistance; 100% copper core conducting wire; 95% weaving copper shield.

— For RS-485 communication cable, please refer to Appendix B. — For 24 Vac power cabling, please refer to Appendix C.

• Keep packaging for possible future use. If a failure occurs, return the product to the factory with the original packaging.

Shipment without the original packaging may damage the product and incur additional costs.

TABLE OF CONTENTS

Table of Contents

SECTION 1 Introduction .......................................................................1

1.1 Features ............................................................................1

1.2 Accessories ..........................................................................3

SECTION 2 Installation ........................................................................8

2.1 Setup the camera address and baud rate DIP switches .....................................8

2.2 Camera wall mount installation .......................................................11

2.3 Ceiling mounting ...................................................................12

2.4 Connecting the cables ...............................................................13

SECTION 3 Getting Started ....................................................................16

3.1 Power-up initial display ..............................................................16

3.1.1 Basic operations ................................................................17

3.2 System-dened Presets .............................................................17

3.3 On Screen Displays ..................................................................18

SECTION 4 Using the OSD Menus ...............................................................19

4.1 Accessing and operating the menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

4.2 Conguring System Information ......................................................21

4.2.1 Checking System Information ....................................................21

4.2.2 Conguring system parameters ...................................................21

4.3 Conguring Image Parameters ........................................................23

4.3.1 TASK 1. Congure the focus settings ...............................................24

4.3.2 TASK 2. Congure the zoom limit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

4.3.3 TASK 3: Set the Day/Night Mode ..................................................25

4.3.4 TASK 4: Set Digital noise reduction ................................................25

4.3.5 TASK 5: Set the sharpness level ...................................................25

4.3.6 Task 6: Set the WDR function .....................................................25

4.3.7 TASK 7. Congure iris, gain and shutter speed .......................................26

4.3.8 TASK 8: Set Exposure compensation function .......................................27

4.3.9 TASK 9: Set White balance .......................................................27

4.3.10 Conguring Privacy Mask ........................................................27

4.3.11 Conguring OSD settings ........................................................29

4.4 Conguring PTZ control parameters ....................................................30

4.4.1 Conguring PTZ parameters ......................................................30

4.5 Conguring Presets .................................................................32

vii

36x PTZ Dome Camera User Manual

TABLE OF CONTENTS

4.5.1 TASK 1: Set a preset. ............................................................32

4.5.2 TASK 2: Call a preset .............................................................32

4.6 Conguring Patrols ..................................................................33

4.6.1 TASK 1: Set a patrol .............................................................33

4.6.2 TASK 2: Preview the patrol .......................................................34

4.6.3 TASK 3: Delete a patrol ..........................................................34

4.6.4 TASK 4: Call the dened patrol ....................................................34

4.7 Conguring Patterns ................................................................34

4.7.1 TASK 1: Set a pattern ............................................................34

4.7.2 TASK 2: Preview a pattern ........................................................36

4.7.3 TASK 3: Delete patterns ..........................................................36

4.7.4 TASK 4: Call the dened pattern. ..................................................36

4.8 Conguring Time Tasks ...............................................................36

4.8.1 TASK 1: Set time tasks ...........................................................36

4.8.2 TASK 2: Preview the task .........................................................38

4.8.3 TASK 3: Delete the task. .........................................................39

4.9 Others .............................................................................39

4.9.1 Restoring default dome setup ....................................................39

4.9.2 Restoring camera default settings .................................................40

4.9.3 Rebooting the camera ...........................................................40

SECTION 5 Specications .....................................................................41

APPENDIX A Lightning and Surge Protection ......................................................43

APPENDIX B RS-485 Bus Connection .............................................................44

APPENDIX C 24 Vac Wire Gauge and Transmission Distance ..........................................47

viii

TABLE OF CONTENTS

36x PTZ Dome Camera User Manual

SECTION 1: INTRODUCTION

SECTION 1

Introduction

The BLACK Line™ 700 TVL 36x zoom outdoor PTZ camera enables you to pan, tilt and zoom in on suspicious activity within the area under observation and capture high resolution video of open spaces such as parking lots, shopping malls and sports facilities.

The BLACK PTZ camera features a 1/4" Sony® 960H CCD image sensor, 36x optical zoom, 16x digital zoom and delivers 700 TV lines of color resolution and 750 TV lines of black and white resolution for crisp, high resolution video. The PTZ camera is also equipped with enhanced imaging features such as digital wide dynamic range (DWDR) and 3D digital noise reduction (3D-DNR) to reduce video noise, as well as true day/night (ICR) to capture sharp detailed images 24 hours a day in both daytime and nighttime conditions.

The PTZ camera features 225 programmable presets, 8 patrols with up to 32 presets per patrol, selectable automatic gain control, plus a 360° endless pan range, -5° ~ 90° tilt range, 0.1°/s ~ 250°/s pan speed and 0.1°/s ~ 150°/s tilt speed. The PTZ camera has a very wide operating temperature range of -22 °F ~ 149 °F that makes it suitable for capturing video in cold climates, along with an IP66 weather-rated housing to withstand a variety of elements and environmental conditions. The PTZ camera also features privacy zone masking, 256x sense up and oers TVS 4,000 V lighting surge protection and voltage transient protection.

1.1 Features

OSD (on-screen display)

The on-screen display is a text image superimposed on video. The text displays status information and conguration menus.

Self-adaptive Protocol

The camera is compatible with PELCO-D, PELCO-P, PRIVATE-Code, etc., and is capable of being self-adaptive to these protocols.

Keyboard Control

The pan/tilt movement and zoom actions of camera can be controlled by the control keyboard, DVR, matrix, etc.

Limit Stops

The dome can be programmed to move within the limit stops (left/right, up/down) which are congurable by the control keyboard, DVR or client application software.

Scan Modes

The dome provides 5 scanning modes: pan scanning, tilt scanning, frame scanning, random scanning and panorama scanning. The scanning speed can be set by OSD menu from level 1 to 40, with the corresponding speed ranging from 1°/second to 40°/second.

SECTION 1: INTRODUCTION

Preset Freeze Frame

This feature freezes the scene on the monitor when moving to a preset. This allows for smooth transition from one preset scene to another and also guarantees that masked areas will not be revealed when moving to a preset.

Presets

Each of the user-denable presets can be programmed to use pan, tilt, camera settings and other settings. When a preset is called, the dome will automatically move to the dened position. The user can add, modify, delete and call each preset.

Label Display

The on-screen label azimuth/elevation, zoom and other operations can be setup by menus and displayed on the monitor.

Auto Flip

In manual tracking mode, when a target object moves directly beneath the dome, the dome will automatically rotate 180 degrees in the horizontal direction to maintain continuity of tracking.

Privacy Mask

The privacy mask allows the user to dene areas of the eld of view that cannot be seen by the operator of the camera. A masked area will move with pan and tilt functions and automatically adjust in size when the lens zoom changes.

Proportional Pan

Proportional pan automatically reduces or increases the pan and tilt speeds in proportion to the amount of zoom. At telephoto zoom settings, the pan and tilt speeds will be slower for a given amount of joystick deection than at wide zoom settings. This keeps the image from moving too fast on the monitor when there is a large amount of zoom.

Auto Focus

Auto focus enables the camera to focus automatically to maintain clear video images.

DAY/NIGHT Auto-switch

The camera provides color images during the day. As light diminishes at night, it switches to night mode and delivers black and white images with high quality. You can also switch it to NIGHT mode manually to increase the sensitivity in low light conditions.

Wide Dynamic Range (WDR)

The wide dynamic range function helps the camera provide clear images even under back light conditions. When there are both very bright and very dark areas simultaneously in the eld of view, WDR balances the brightness level of the entire image and provide clear image detail.

36x PTZ Dome Camera User Manual

White Balance

White balance is the white rendition function of the camera to adjust the color temperature according to the environment automatically. It can remove the unrealistic color casts in the image.

Patrol

The camera provides up to 8 patrols. In each patrol, user is allowed to specify the scanning track by a group of user-dened presets, with the scanning speed between two presets and the dwell time at the preset separately programmable.

Pattern

A pattern is a memorized, repeating series of pan, tilt, zoom, and preset functions that can be recalled with a command from a controller or automatically by a congured function (alarm, park, time task, or power-up). By default the focus and iris are in auto status during the preset is being memorized.

Power-o Memory

This feature causes the dome to resume its previous position or status after power is restored. By default setting, the dome supports the power-o memory capability with the dwell time of 3 minutes.

Time Task

A time task is a precongured action that can be performed automatically at a specic date and time. The programmable actions include: preset 1-8, pattern 1-4, patrol 1-4, pan scan, tilt scan, random scan, frame scan, panorama scan, day/night mode or none.

1.2 Accessories

The following accessories are available for the BLK-PTZ36X camera. Mounting bracket detail is shown below.

Model Type

BLK- PTZCL Ceiling Mount Bracket

BLK- PTZWB Wall Mount B racket

BLK- PTZPM Pole Mount PTZ Br acket

BLK- PTZCM Corner Mount PT Z Bracket

BLK-PTZCNTRL 3D Joystick PT Z Controller (Pelco-P/D)

SECTION 1: INTRODUCTION

BLK-PTZCL: Ceiling Mount Bracket

The Ceiling Mount Bracket is suitable for outdoor ceiling mounting.

3.52" dia.

0.39" dia. (4)

2.24"

4.57" dia.

SECTION 1: INTRODUCTION

36x PTZ Dome Camera User Manual

SECTION 1: INTRODUCTION

BLK-PTZWB: Wall Mount Bracket

The Wall Mount Bracket is suitable for indoor and outdoor wall mounting.

0.33" dia. (4)

G 1.5"

6.30"

7.6 4 "

2.95"

3.82"

12.2"

SECTION 1: INTRODUCTION

BLK-PTZPM: Pole Mount PTZ Bracket

The Pole Mount Bracket is suitable for outdoor pole mounting. The straps can attach to a 2.64" ~ 5.00" diameter pole.

2.68"2.68"

7.6 4 "

5.63"

3.94" dia.

G 1.5"

12.2" 4.61"

36x PTZ Dome Camera User Manual

SECTION 1: INTRODUCTION

BLK-PTZCM: Corner Mount PTZ Bracket

7.6 4 "

6.96"

G 1.5"

16. 52"

SECTION 2: INSTALLATION

SECTION 2

Installation

Before you start, check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. Included are:

• AC power supply

• Installation guide (this user manual)

• Mounting brackets (sold separately)

This section includes camera installation using a wall mount bracket (see “2.2 Camera wall mount installation” on page 11) and ceiling mounting bracket (see “2.3 Ceiling mounting” on page 14). For other bracket types, use the procedures included here as guidelines.

2.1 Setup the camera address and baud rate DIP switches

DIP switches inside the camera are used to manually congure the RS-485 device address and network baud rate. The device address and baud rate can also be congured remotely through the OSD (on-screen display) using a control console, DVR or DVS. See “SECTION 3 Getting Started” on page 16 and “SECTION 4 Using the OSD Menus” on page 19 for more information.

There are two DIP switch groups, SW1 switches 1 .. 8 (sets the RS-485 network address) and SW2 switches 1 and 2 (sets the RS-485 network baud rate). The address setup for the camera must be unique for each device on the RS-485 network. However, the baud rate switched must be congured to the same baud rate used by the other devices on the network. These switches are accessible when the dome cover is removed. To setup the DIP switches, do the following:

1. Loosen the two lock screws as shown in the following gure.

Lock

screw

Back

box

Lower

dome

Lock screw

Camera assembly

2. Remove the lower dome and remove the protective foam and sticker shown below. Be very careful not to touch the camera

lens.

36x PTZ Dome Camera User Manual

SECTION 2: INSTALLATION

Protective foam

Protective sticker

Remove protective foam

3. Locate the DIP switches inside the camera.

NOTE

There are two DIP switch groups, SW1 (for RS-485 network address) and SW2 (for RS-485 network baud rate). The address setup for the camera must be unique for each device on the RS-485 network. However, the baud rate switched must be congured to the same baud rate used by the other devices on the network.

DIP switches

SW1: 1 .. 8

address switches

SW2: 1, 2 baud rate switches

DIP switches

5. Set the device address DIP switches 1 through 8 using the following table. Each device on the RS-485 network must have a

dierent address. You can congure up to 256 devices (address 0 .. 255) on the RS-485 network. When the switch is pushed up (see the drawing above) it is ON.

Table 1. DIP address switch settings

Dome Address

SW1 (address) switch number

1 2 3 4 5 6 7 8

0 OFF OFF OFF OFF OFF OFF OFF OFF

1 ON OFF OFF OFF OFF OFF OFF OFF

2 OFF ON OFF OFF OFF OFF OFF OFF

3 ON ON OFF OFF OFF OFF OFF OFF

4 OFF OFF ON OFF OFF OFF OFF OFF

5 ON OFF ON OFF OFF OFF OFF OFF

6 OFF ON ON OFF OFF OFF OFF OFF

… … … … … … … … …

255 ON ON ON ON ON ON ON ON

6. Set the network baud rate DIP switches 1 and 2 using the following table. Each device on the RS-485 network must use the

same baud rate. By default, the baud rate is set to 2400 baud (1 g OFF, 2 g OFF).

Baud rate

SW2 switches

1 2

240 0 OFF OFF

4800 ON OFF

9600 OFF ON

1920 0 ON ON

7. Ensure that the camera lens and the inside of the lower dome is clean, then reinstall the lower dome. Position the dome onto

the back box, then tighten the two lock screws.

NOTE

Do not put the protective foam back inside the dome. Save the foam and other packaging for possible use at a later time.

SECTION 2: INSTALLATION

36x PTZ Dome Camera User Manual

SECTION 2: INSTALLATION

2.2 Camera wall mount installation

Following the instructions below to install the camera using the BLK-PTZWB Wall Mount Bracket.

Instructions for mounting the camera with a BLK-PTZPM Pole Mount PTZ Bracket or BLK-PTZCM Corner Mount PTZ Bracket are very similar. For these brackets, use the instructions below as a guide.

1. If you did not setup the camera DIP switches using “2.1 Setup the camera address and baud rate DIP switches” on page 8,

remove the camera dome cover, remove the protective foam, then reinstall the cover. See Section 2.1 steps 1, 2 and 7 above.

2. Determine the best mounting screws and hardware to anchor the mounting bracket with the camera to the mounting

surface. Use the following guidelines:

— For cement wall mounting, use the expansion screw to anchor the bracket. — For wooden wall mounting, use self-tapping screw to anchor the bracket. — Make sure that the wall is strong enough to withstand more than 8 times the weight of the camera and the bracket.

3. Using the mounting bracket as a template, mark the location of the mounting screw holes on the mounting surface. Also

mark the location of a hole for the camera drop cable. The drop cable will be routed through the mounting bracket and through the mounting surface.

4. Drill holes in the mounting screws and hardware. Also, drill a 1 1/4" diameter hole in the mounting surface for the drop cable.

5. Apply two wrap of the thread tape provided onto the treads of the pendant adapter (see below)

Wrap with thread tape

Bracket

Pendant adapter

Pendant adapter set screw

Lock screw (2)

Loop for safety rope

Attach pendant adapter to mounting bracket

6. Screw the pendant adapter onto the end of the mounting bracket. Tighten the set screw to secure the adapter to the bracket.

7. Route the camera drop cable through the mounting bracket, then clip the safety rope onto the loop in the mounting bracket.

SECTION 2: INSTALLATION

Drop cable

Pendant adapter

Align

marks

Safety rope

Coupling

Pendant adapter

Back box

8. Fit the camera coupling into the pendant adapter, then twist the camera to align the marks on the pendant adapter and the

camera back box. See the gure above.

9. Tighten the two lock screws on the pendant adapter to secure the camera to the mounting bracket.

10. Feed the camera drop cable through hole drilled at the mounting location, then anchor the mounting bracket to the wall.

11. Continue installation with “2.4 Connecting the cables” on page 13.

2.3 Ceiling mounting

Following the instructions below to install the camera using the BLK-PTCL Ceiling Mount Bracket.

1. If you did not setup the camera DIP switches using “2.1 Setup the camera address and baud rate DIP switches” on page 8,

remove the camera dome cover, remove the protective foam, then reinstall the cover. See Section 2.1 steps 1, 2 and 7 above.

2. Determine the best mounting screws and hardware to anchor the mounting bracket with the camera to the mounting

surface. Use the following guidelines:

— For cement ceiling mounting, use the expansion screw to anchor the bracket. — For wooden ceiling mounting, use self-tapping screw to anchor the bracket. — Make sure that the ceiling is strong enough to withstand more than 8 times the weight of the camera and the bracket.

3. Using the mounting bracket as a template, mark the location of the mounting screw holes on the ceiling.

36x PTZ Dome Camera User Manual

4. If the camera drop cable will be routed through the ceiling, mark the location of a hole for the camera drop cable. The drop

cable will be routed through the mounting bracket and can be routed either through the mounting surface or out the side of the mounting bracket.

5. Drill holes in the mounting screws and hardware. Also, drill a 1 1/4" diameter hole in the mounting surface for the drop cable.

6. Route the camera drop cable through the mounting bracket, then clip the safety rope onto the loop in the mounting bracket.

Bracket

Ceiling

Coupling

Drop cable

Safety rope

Align

marks

Back box

Lock screw

7. Fit the camera coupling into the ceiling mounting bracket, then twist the bracket to align the marks on the bracket and the

camera back box. See the gure above.

8. Tighten the two lock screws on the ceiling bracket to secure the camera to the mounting bracket.

9. Feed the camera drop cable through hole drilled at the mounting location, then anchor the mounting bracket to the ceiling.

10. Continue installation with “2.4 Connecting the cables” on page 13.

2.4 Connecting the cables

1. Route network cables for video, 24 Vac power and ground, and RS-485 between the remote control device and power source

and your camera. Do not apply power to the 24 Vac cables before connecting them to your camera.

SECTION 2: INSTALLATION

Remote control device (DVR)Camera Monitor

Network cabling

2. Connect the network power and ground, RS-485, and video cables to the camera drop cable connectors.

RS-485 – RS-485 +

24 Vac Ground 24 Vac

Camera drop cable

Video output

Drop cable connections

3. Connect the network power and ground, RS-485, and video cables to the remote control device and 24 Vac power source.

4. Connect the video output and RS-485 and video output cables to your network extension cables. Connect the other end of

these cables to a remote control device, such as a DVR.

5. When power is applied to the camera, a system information display will appear for 2 minutes on top of the live video image

from the camera. Verify that the information on the display is intelligible.

36x PTZ Dome Camera User Manual

SECTION 2: INSTALLATION

Typical System Information display

6. Verify that the live video from the camera is clear.

7. Go to “SECTION 3 Getting Started” on page 16 to continue with camera setup using the OSD.

SECTION 3: GETTING STARTED

SECTION 3

Getting Started

3.1 Power-up initial display

After the power is applied, the camera will perform a series of self-tests including lens functions, the panning movement and tilting movement. After the power-up self-tests complete, the system information screen is displayed for 2 minutes on top of the live view screen. An example is shown below.

Typical System Information display

Important information about the camera settings is shown in the system information display. See below.

System Information Description

TYPE The mod el of the camera

SN The ser ial number of the c amera.

ADDRESS The def ault communication addres s of the camera.

COM FORMAT The communication se ttings of the RS- 485 interf ace: baud rate (4 digits), data bit (1 digit) and stop bit (1 digit).

PROTOCOL Protocol conguration for communicating with other devices.

VERSION The version of the rmware.

HARDVERSI The version of t he hardware.

BUILD DATE The date when the software was compiled.

If the address of your camera is the same as another camera on the RS-485 network, one of them has to change. Also, if the communication parameters (COM FORMAT) are not the same as the settings on RS-485 network, they must be congured to match. Use the features with your control keyboard, DVR, or DVS to congure these parameters.

36x PTZ Dome Camera User Manual

SECTION 3: GETTING STARTED

3.1.1 Basic operations

You can control the camera using a device such as a control keyboard, DVR, or DVS. In this and the following chapters, operation of the camera by the IE browser connected to a DVR will be used.

NOTE

Ensure that the communication settings and address for the camera are congured properly in the controlling device.

Panning and tilting: Click the direction buttons to control the movement of the camera.

Zooming: Click the ZOOM in/out buttons to control the zooming.

Focusing: Click the FOCUS+ and FOCUS- buttons to adjust the focus.

Iris: Click the IRIS+ and IRIS- buttons to adjust the iris.

3.2 System-dened Presets

The camera system includes special functions that can be initiated by calling a preset number through a control device such as a DVS. These presets are xed and cannot be edited. To call the system-dened presets remotely, you can choose the preset number from the list in the PTZ control panel. For instance, preset 99 is the Start auto scan. If you call preset 99, the camera starts the auto scan function. The table below lists the preset numbers and functions dened for the system.

Table 2. System-dened presets

Preset No. Function Preset No. Function

33 Auto-ip 93 Set manual limit s tops

34 Return to home position 94 Remote reboot

35 Patrol 1 95 Access main menu

36 Patrol 2 96 Stop scanning

37 Patrol 3 97 Start random scanning

38 Patrol 4 98 Start frame scanning

39 IR cut lter in 99 Star t auto scanning

40 IR cu t lter out 100 Start tilt scanning

41 Pat tern 1 101 Start panorama scanning

42 Pattern 2 102 Patrol 5

43 Patter n 3 103 Patrol 6

44 Pat tern 4 104 Patrol 7

92 Enable limit stops 105 Patrol 8

SECTION 3: GETTING STARTED

3.3 On Screen Displays

The camera supports following on screen displays:

Zoom: Identies the amount of magnication. The format is ZXXX. where “XXX” is the zoom amount.

Direction: Displays panning and tilting direction, with the format of NEXXX TYYY, where “XXX” indicates the degrees in

north east (NE) direction, and “YYY” indicates the degrees in tilt position.

Time: Support for time display.

Preset Title: Identies preset being called.

Temperature: Displays the temperature of the camera.

36x PTZ Dome Camera User Manual

SECTION 4: USING THE OSD MENUS

SECTION 4

Using the OSD Menus

The menu structure of the on-screen display (OSD) is shown below.

You can control the camera using the on-screen display menu remotely by connecting to a DVR or a DVS (encoder). Examples of entering camera menu include:

• Enter the menu by pressing buttons: PTZ g REC g 9 g 5 on the front panel of the DVR.

• Enter the menu by pressing buttons: CALL g 9 g 5 g ENTER on the keyboard.

• Enter the menu via the IE browser of a DVR/DVS.

Menu operations via the IE browser of a DVR will be used for the example in this chapter.

SECTION 4: USING THE OSD MENUS

4.1 Accessing and operating the menus

To open the Main Menus:

1. Connect the video and RS-485 cables from the camera to a DVR.

2. Access the DVR with an internet browser.

3. View the live video from the camera.

4. Call preset 95 from the preset list in the PTZ control panel of the DVR.

Main Menus

To move the cursor and operate the menu:

• Move the cursor up/down: On control panel of the live view interface of the DVR, click the UP and DOWN direction buttons

or FOCUS+ and FOCUS- buttons to move the cursor up and down in the menu.

• Enter / Exit: On control panel of the live view interface of the DVR:

— Click IRIS+ to enter a submenu — Move the cursor to BACK in the menu — Click IRIS+ to return to the previous menu, or move the cursor to EXIT the menu and then click IRIS+ to exit the menu.

• Page up / page down: There is no RETURN or NEXT menu items for turning a page up or down. On control panel of the live

view interface of the DVR, you can click the left and right direction buttons to turn the page up or down.

To change the value of a parameter:

1. Move the cursor to the target item and then click IRIS+. The cursor (diamond mark) will change to be hollow.

2. Click the up/down or left/right buttons in the PTZ control panel to choose the value from the selectable value list.

36x PTZ Dome Camera User Manual

SECTION 4: USING THE OSD MENUS

3. Click IRIS+ to conrm the change or click IRIS- to cancel and restore the original value. The diamond mark will change back

to be stued or half stued icon.

4.2 Conguring System Information

4.2.1 Checking System Information

System information menu displays the current system information of the camera including the model, address, protocol, etc. The information shown on this submenu is similar to the system information shown after camera power-up.

To open the system information display menu, go to MAIN MENUS g SYS INFO

Typical System Information display

NOTE

The SYS INFO display is presented for Information only. It cannot be edited directly.

4.2.2 Conguring system parameters

You can check and edit the system information including software address, baud rate, system time, etc. on the system information settings menu.

To enter the system information settings menu, go to MAIN MENUS g DOME SETUP g SYS PARAMETER SETUP

SECTION 4: USING THE OSD MENUS

System Parameter Setup

NOTE

Using an internet browser connected to a DVR, click the lef t and right direction buttons in the PTZ control panel to page up or page down when more than one page is available.

Descriptions of system parameter conguration:

• Dome address settings

TASK 1: Set the soft address of the camera.

If the SOFT ADDR ACTIVE is set ON, the soft address is the valid address for connecting the camera. The SOFT ADDRESS ranges from 1 to 255.

If the SOFT ADDR ACTIVE is set as OFF, the hard address set by the DIP switch is the valid address of the camera.

TASK 2: Set the broadcast address of the camera.

When the BROADCAST ADDRESS is set to ON, the control devices with address 0 can control the camera remotely regardless of the address of the camera.

With this function on, a control device with address 0 can control all PTZ cameras connected to it. This function is usually used for debugging.

• PELCO checksum

If the camera uses PELCO-P or PELCO-D protocol, you can set the PELCO CHECKSUM as ON for improving the controlling eect.

36x PTZ Dome Camera User Manual

SECTION 4: USING THE OSD MENUS

• System time conguration

a. Move the cursor to SYSTEM TIME using the direction buttons, then click IRIS+ to enter.

b. Click the left or right direction buttons to position the cursor on the specic item (year/month/day or hour/minute/

second) of which you want to change the value.

c. Click the up or down direction buttons to increase or decrease the value.

d. Click IRIS+ button to conrm and exit.

Set System Time

• Pan Zero angle (initial position) conguration. You can dene the initial position of the camera on the PAN ZERO SETUP

submenu.

a. Move the cursor to PAN ZERO SETUP using the direction buttons, then click IRIS+ to enter.

b. Click the left or right or up or down direction buttons to adjust the view angle.

c. Click IRIS+ button to conrm and exit.

4.3 Conguring Image Parameters

You can set the camera parameters including focus, shutter speed, iris, etc. Conguring image parameters for the camera includes several tasks (see below). To enter the camera parameters settings menu, go to MAIN MENUS g DOME SETUP g CAMERA

SETUP

SECTION 4: USING THE OSD MENUS

Camera Setup

4.3.1 TASK 1. Congure the focus settings

• Setting the focus mode

a. Move the cursor to FOCUS using the direction buttons and click IRIS+ to change the cursor to totally hollow.

b. Click up/down direction buttons to choose the focus mode as AF, MF or HAF.

AF (Auto-focus): The lens remains in focus during PTZ movements.

MF (Manual Focus): You need to adjust the focus with FOCUS+ and FOCUS- buttons manually.

HAF (Half-auto Focus): The camera focuses automatically only once after panning, tilting and zooming.

c. Click IRIS+ button to save the settings.

• Setting the focus limit. This function is used to limit the minimum focus distance. You can congure the focus limit to a

longer distance when the target is at a distance to prevent the camera from focusing on the objects close to it; or congure the focus limit to a shorter distance when the target is near the camera to prevent it from focusing on objects father away. You can set the FOCUS LIMIT to 1CM, 30CM, 1M, 3M, 5M, 20M, or AUTO.

4.3.2 TASK 2. Congure the zoom limit

• Setting the zoom limit. Zoom limit is a user-dened limitation of the zoom amount.

a. Move the cursor to ZOOM LIMIT using the direction buttons and click IRIS+ to open the submenu.

b. Click the up or down direction buttons to choose the limit.

36x PTZ Dome Camera User Manual

SECTION 4: USING THE OSD MENUS

c. Click IRIS+ to conrm your settings.

4.3.3 TASK 3: Set the Day/Night Mode

• IR cut lter. This lter It can be congured as AUTO, DAY or NIGHT.

AUTO: The camera switches automatically from Black and White mode (NIGHT) and Color mode (DAY) in response to lightening conditions (default).

NIGHT (B/W): The IR cut lter will switch to NIGHT mode to increase the sensitivity in low light conditions.

DAY (Color): The IR cut lter will perform in DAY mode (normal lighting conditions).

NOTE

You can also call preset 39 to set the IR cut lter mode to DAY mode and call preset 40 to set it as NIGHT mode.

4.3.4 TASK 4: Set Digital noise reduction

To reduce the image noise, you can set the NOISE REDUCE function OFF or ON.

4.3.5 TASK 5: Set the sharpness level

The sharpness function can increase the gain of the image and sharpen the edges in the picture to enhance the picture details. You can set the SHARPNESS level from 0 to 15.

4.3.6 Task 6: Set the WDR function

To set the WDR, open the ADVANCED SETUP menu. Go to MAIN MENUS g DOME SETUP g CAMERA SETUP g ADVANCED SETUP

SECTION 4: USING THE OSD MENUS

Advanced Setup settings

You can set the WDR (Wide Dynamic Range) to ON or OFF to enable or disable the function. When both very bright and very dark areas appear simultaneously in the eld of view, the WDR function can balance the brightness level of the entire image and provide clear images with details.

4.3.7 TASK 7. Congure iris, gain and shutter speed

• Setting the AE mode. AE mode denes the priority of the iris, shutter and gain when the camera adjusts the brightness of

the video. The options in AE MODE are as follows:

AUTO: Auto iris, auto shutter and auto gain. The camera adjusts these values automatically responding to the lighting conditions. This is the default mode.

MANUAL: In MANUAL mode, you can adjust the shutter, iris and gain values.

• Setting the iris value. To adjust the iris size for light entering the lens, you can set the IRIS value manually according to light

conditions. The iris value ranges from 0 (closed) to 17 (fully open).

• Setting the gain. The value of gain indicates the degree of amplication of the original light signal. You can set the value

from 0 to 15.

• Setting the shutter speed. The speed of the electronic shutter controls the amount of light entering the lens in a unit

of time (a second). You can manually congure the shutter speed for the camera, and you can also enable the slow shutter function for low lighting circumstances.

If you set the SHUTTER value larger, the shutter speed is faster. The value indicates the inverse of the shutter speed (1/value seconds). At faster speeds, the amount of light entering the lens is less causing the image to be darker. You can set the shutter value to 1, 2, 4, 8, 15, 30, 50, 125, 180, 250, 500, 1000, 2000, 4000 or 10000.

36x PTZ Dome Camera User Manual

4.3.8 TASK 8: Set Exposure compensation function

Adjust this value to increase the brightness of the image. You can set the EXPOSURE COMP value from 0 to 14. The default value is 7.

4.3.9 TASK 9: Set White balance

Set WHITE BALANCE mode to AUTO, INDOOR, OUTDOOR, SELFDEF (self-dened), ATW (auto-tracking) or HAUTO (half-auto)..

AUTO: In Auto mode, the camera adjusts the color balance according to the current color temperature.

INDOOR, OUTDOOR: These modes are for indoor use and outdoor use respectively.

SELFDEF: In SELFDEF you can adjust the color temperature, the RED and BLUE values, manually.

ATW: In auto-tracking mode, white balance is adjusted continuously to accord with the color temperature of the scene

illumination.

HAUTO: Selecting this mode, the viewed image retains color balance automatically according to the current color temperature.

4.3.10 Conguring Privacy Mask

Privacy mask enables you to cover specic areas on the live video to prevent these from appearing in live view and recorded video. The masked areas can move with the panning/tilting movements and automatically adjust their size when the lens zoom changes.

1. Open the privacy mask conguration submenu. Go to MAIN MENUS g DOME SETUP g PRIVACY SETUP

Privacy Blank conguration menu

2. Choose the privacy mask number:

SECTION 4: USING THE OSD MENUS

a. Move the cursor to BLANK NUM and click IRIS+ to enter the editing mode.

b. Click the up and down direction buttons to select a mask number for conguration.

c. Click IRIS+ again to conrm and exit the editing mode.

3. Congure the position and size of the privacy mask.

a. Move the cursor to SET BLANK and click IRIS+ button to enter the editing mode as shown in the following gure.

You can see a privacy mask on the live window.

Set the Privacy Mask

b. When the ADJUST BLANK POS message appears, use the direction buttons to shift the position of the privacy mask.

c. When you click the FOCUS+ button, the ADJUST BLANK SIZE message will appear. Click the up/down buttons to

increase/decrease the height of the mask, and click right/left buttons to increase/decrease the width of the mask. Click IRIS+ button to save the settings and return to the previous menu and you can see the mask turn to gray.

d. To modify the mask, click IRIS+ button to enter the SET BLANK menu, then click IRIS+ button again to recongure

the mask.

NOTE

The tilt range for conguring the privacy masks is from 0° to 70°.

4. Enable or disable the privacy mask function: Open the BLANK STATUS submenu, then click the up and down

direction buttons to set it ON or OFF. If no privacy mask is congured, you cannot set the status as ON.

5. Delete the privacy mask: You can enter the DELE BLANK menu to delete the current privacy mask.

36x PTZ Dome Camera User Manual

SECTION 4: USING THE OSD MENUS

4.3.11 Conguring OSD settings

The on-screen display of the PTZ movements, temperature, system time, etc. can be enabled or disabled.

1. Open the display settings menu: Go to: MAIN MENUS g DOME SETUP g SYS PARAMETER SETUP g DISPLAY

SETUP

Display settings

2. Move the cursor to DISPLAY SETUP using the direction buttons and click IRIS+ to enter.

3. Move the cursor to the target item and click IRIS+ and click up/down direction buttons to choose each display mode as ON

or OFF, and dene each display time as 2 seconds, 5 seconds or 10 seconds.

4. Click IRIS+ button to conrm.

Display the viewing direction

The camera displays a viewing direction code when you manually rotate the camera. Codes are shown in the table below.

Display N NE E SE S SW W NW

Indication* North Northeast East Southeast South Southwest West Northwe st

* The nor th direct ion refers to the 0º angle (init ial position).

The temperature display refers to the internal temperature of the camera.

SECTION 4: USING THE OSD MENUS

4.4 Conguring PTZ control parameters

You can congure panning, tilting and zooming movements, and congure PTZ control functions including presets, patrols, patterns, etc. for the camera.

4.4.1 Conguring PTZ parameters

Open the PTZ conguration menu. Go to MAIN MENUS g DOME SETUP g MOTION PARAMETER SETUP

PTZ PARAMETER SETUP menus

Descriptions of PTZ parameter conguration:

• Auto-ip. In manual tracking mode, when a target object moves directly beneath the camera, the camera automatically

rotates 90 degrees horizontally (ips) for tracking. The default setting of AUTO-FLIP is ON for this camera model.

• Proportional Panning / Tilting. When this function is enabled, the pan/tilt speed changes according to the amount of

zoom. If using high zoom, the pan/tilt speed is slowed to keep the image from moving too fast on the live view display. You can set PROPORTIONAL PAN to ON or OFF to enable/disable the function. This function is enabled automatically while setting patterns.

Park time and actions

This feature allows the camera to start a predened action (park action: scan, preset, pattern, etc.) automatically after a period of inactivity (park time).

You can set PARK TIME from 5 to 720 seconds and set the park action (PARK ACT) as preset 1 to 8, pattern 1 to 4, patrol 1 to 8, pan scan, tilt scan, random scan, frame scan, panoramic scan, day mode, night mode or none.

36x PTZ Dome Camera User Manual

SECTION 4: USING THE OSD MENUS

Image freeze

This feature enables the live view to switch directly from one scene dened by a preset to another, without showing the middle areas between these two, to ensure the surveillance eciency. It can also reduce the use of bandwidth in a digital network system.

To enable this function, set IMAGE FREEZE to ON.

PTZ speed

You can dene the speed of the dome movements in the SPEED SETUP submenu.

DOME SPEED: the manual movement speed can be set to HIGH, MID or LOW.

SCAN SPEED: scan speed denes the scan degree per second of a panning scan, tilting scan, frame scan, random scan and

panoramic scan. Scan speed is adjustable from 1 to 40 degrees per second.

PRESET SPEED: the speed of calling a preset can be set from level 1 to 8. The higher levels will call a preset faster.

Limit stops

The camera can be programmed to move within the congurable limit stops (left/right, up/down). To set these limits:

1. Move the cursor to LIMIT SETUP in PTZ PARAMETER SETUP menu, then click IRIS+ to open the submenu.

Limit Setup menu

2. Move the cursor to LIMIT STATUS, click IRIS+ to set it ON to enable the feature.

SECTION 4: USING THE OSD MENUS

3. Move the cursor to <LIMIT SETUP> in the LIMIT SETUP submenu, then click IRIS+. The message SET LEFT LIMIT will

appear.

4. Click the direction buttons in the PTZ control panel to position the left limit stop, then click IRIS+ to conrm.

5. Follow the steps above to congure the right, up and down limit stops on the menu. The new limit stops will overwrite the

existed ones.

6. You can clear the dened limit stops. Click IRIS+ to enter CLEAR STOPS, then click IRIS+ again to clear the stops.

4.5 Conguring Presets

A preset is a predened direction. For the dened preset, you can click the calling button to move the camera to that direction. There is no preset menu in the OSD. You can set presets with the PTZ panel of the control device or the keyboard.

4.5.1 TASK 1: Set a preset.

To set a preset direction:

1. In the PTZ control panel, select a preset number from the preset list.

Click to

select a preset

Click to call a preset Click to nish setting a preset

Presets conguration men

2. Use the PTZ control buttons to move the lens to the desired position.

3. Click the “nish” icon (see above) the set the preset.

4.5.2 TASK 2: Call a preset

Through a web browser connected to your DVR, select the preset number from the preset list in the control panel of the DVR, then click the icon to call the preset.

36x PTZ Dome Camera User Manual

SECTION 4: USING THE OSD MENUS

4.6 Conguring Patrols

A patrol is a memorized series of preset function. It can be set and previewed on the patrol settings interface.

4.6.1 TASK 1: Set a patrol

You can congure up to 8 patrol numbers.

1. Open the patrol conguration submenu. Go to MAIN MENUS g DOME SETUP g PATROLS SETUP

Patrol Setup menu

2. Edit a patrol:

a. Move the cursor to PATROL SETUP, then lick IRIS+ to enter edit mode.

b. Click the up and down direction buttons to select the number of the patrol which is to be edited.

SECTION 4: USING THE OSD MENUS

c. Click the left/right direction buttons to position the cursor to PRESET, DWELL TIME and SPEED of a preset. Click the up

and down direction buttons to set each value.

— The preset you select for the patrol should be a dened preset. — The dwell time is the time the camera will pause on a preset. — The speed of the patrol is the speed the camera will switch between presets.

3. Follow above steps to dene other presets for the selected patrol. You can congure up to 32 presets in sequence for a patrol.

Click IRIS+ to save the current settings, or click IRIS- to cancel and return to the previous menu.

4.6.2 TASK 2: Preview the patrol

Move the cursor to <PREVIEW PATROL>, then click IRIS+ to preview the current patrol and enable the camera to scan among the presets.

4.6.3 TASK 3: Delete a patrol

You can move the cursor to <DELE PATROL>, then click IRIS+ to delete the current patrol.

4.6.4 TASK 4: Call the dened patrol

To call a patrol, use a web browser connected to your DVR to select the corresponding preset number from the drop-down list in the control panel, then click the icon to call the related patrol. For example, you might call preset 35 to call patrol 1. Refer to “4.6 Conguring Patrols” on page 33 for more information.

4.7 Conguring Patterns

A pattern is a repeatable series of panning, tilting, zooming and preset movements that can be recalled by a command or automatically performed by a congured function (alarm, park, time task, and power-up).

4.7.1 TASK 1: Set a pattern

You can congure up to 4 patterns. To set a pattern:

1. Open the PATTERNS submenu. Go to MAIN MENUS g DOME SETUP g PATTERN SETUP

36x PTZ Dome Camera User Manual

SECTION 4: USING THE OSD MENUS

Patterns conguration menu

2. Choose the pattern number:

a. Move the cursor to PATTERN NUM and click IRIS+ to enter edit mode.

b. Click the up and down direction buttons to select the number of the pattern you want to congure.

c. Click IRIS+ again to conrm.

3. Edit the pattern.

a. Move the cursor to <PATTERN SETUP> and click IRIS+ to enter edit mode.

Edit pattern

b. Click the PTZ control buttons and direction buttons to pan, tilt, or zoom in/out the camera to draw a movement path.

The camera can automatically memorize the path you enter as a pattern.

SECTION 4: USING THE OSD MENUS

c. Click IRIS+ again to save the pattern and exit edit mode.

NOTE

• REMAIN MEMO RY indicate s the remaining memory of th e camera for conguring patterns. When it reaches 0, no mo re patterns can be

congured. You can a lso see the remaining me mory shown under PATTERNS menu as REMAINING.

• Panning/tilting movements and lens operations cannot be memorized simultaneously.

4.7.2 TASK 2: Preview a pattern

To preview a pattern, open the <PREVIEW PATTERN> menu to see the current pattern.

4.7.3 TASK 3: Delete patterns

• To delete a selected pattern, click IRIS+ to enter <PATTERN SETUP>. When you see DEL PATH ABOVE, click IRIS+ to

delete the pattern.

• To clear all the patterns, open the <DELE PATTERN> menu, then click IRIS+ to delete all the dened patterns.

4.7.4 TASK 4: Call the dened pattern.

Through a web browser connected to a DVR, select the corresponding preset number from the drop-down preset list in the control panel, then click the arrow to call the related pattern. For example, call preset 41 to call pattern 1.

4.8 Conguring Time Tasks

A time task is a scheduled camera action congured to perform automatically at the specic time.

4.8.1 TASK 1: Set time tasks

You can congure up to 8 time tasks. To congure a time task:

1. Open the TIME TASK submenu: Go to MAIN MENUS g DOME SETUP g TASK SETUP

36x PTZ Dome Camera User Manual

SECTION 4: USING THE OSD MENUS

Time Task conguration menu

2. Choose the task number.

a. Move the cursor to TASK NUM and click IRIS+ to enter edit mode.

b. Click the up and down direction buttons to select the task number you want to congure.

c. Click IRIS+ again to conrm and exit edit mode.

3. Set the task status.

a. Move the cursor to TASK STATUS and click IRIS+ to enter edit mode.

b. Click the up and down direction buttons to set the task status to ON.

c. Click IRIS+ again to conrm and exit edit mode of this column.

4. Congure the task action.

a. Move the cursor to TASK ACTION and click the IRIS+ to enter edit mode.

b. Click the up and down direction buttons to select the task action from preset 1 to 8, pattern 1 to 4, patrol 1 to 8,

panning scan, tilting scan, random scan, frame scan, panoramic scan, day mode, night mode or none.

c. Click IRIS+ again to conrm and exit edit mode of this column.

5. Set the task time.

a. Move the cursor to TASK TIME and click IRIS+ to enter edit mode.

SECTION 4: USING THE OSD MENUS

Set the Time Task

b. Click the left and right direction buttons to position the cursor to WEEK, START (H-M) or END (H-M).

c. Click the up and down direction buttons to select the specic day and time. The weekday can be set to be from

Monday to Sunday or All Week.

d. Click IRIS+ to conrm and exit.

Set the Time Task

4.8.2 TASK 2: Preview the task

To preview a time task, move the cursor to <TASK PREVIEW>, then click IRIS+ to view the time, action and status of the scheduled task.

36x PTZ Dome Camera User Manual

SECTION 4: USING THE OSD MENUS

Preview the time task

4.8.3 TASK 3: Delete the task.

To delete a task, move the cursor to CLEAN TASK and click IRIS+ to delete the time and action of the current task.

4.9 Others

4.9.1 Restoring default dome setup

You can reset all dome settings to factory default parameters as shown in the table below. Dome settings include mostly PTZ parameters and some system settings, for example, the dome address.

1. Open the default dome settings menu. Go to MAIN MENUS g RESTORE DEFAULTS

2. Click IRIS+ to restore the dome settings to the values shown in the table below, or click IRIS- to exit.

Table 3. Default dome settings

Parameters Default Value

Dome address 0

Baud rate 240 0 bps

Soft address O

Initial Position Zero angle

Auto-focus On

Zoom limit Max. Optical Zoom

Zoom speed High

SECTION 4: USING THE OSD MENUS

Parameters Default Value

AE mode Auto

Exposure compensation On

White balance Auto

Auto-ip O

Proportional pan On

Park time 5 seconds

Park ac tion None

Scan speed Level 23

Preset image freeze O

Limit stops O

Time display O

Zoom and prese t label display Display for 2 seconds

4.9.2 Restoring camera default settings

Camera settings include the image parameters, lens settings and display settings. To restore the default settings in the camera:

1. Open the menu: MAIN MENUS g RESTORE CAMERA

2. Click IRIS+ to restore the camera settings to the default value, or click IRIS- to exit.

4.9.3 Rebooting the camera

Open the MAIN MENUS g REBOOT DOME menu, then click IRIS+ to reboot the camera remotely.

36x PTZ Dome Camera User Manual

SECTION 5: SPECIFICATIONS

SECTION 5

Specications

Table 4. Table of Specications

Area Parameter Specication

Camera Image sensor 1/4" Sony® 960H CCD

Eective pixel 976(H) × 582(V)

Horizontal resolution Color: 700 TVL; B/W: 750 TVL

Signal system NTSC

Minimum illumination Color: 0.02 lux / (F1.6, AGC ON), 0.0 008 lux / (F1.6, AGC ON, sen sitivity × 2 56)

B&W: 0.002 lux / (F1.6, AGC ON), 0.00 008 lux / (F1.6, AGC ON, sensitivity × 256)

White balance Auto / One touch WB / ATW / Indoor / Ou tdoor

AGC Auto / Manual

S / N Ratio ≥ 50 dB

DNR High / Medium / Low / o

WDR 128x (On / O / Auto)

Shutter Time 1 ~ 1/10,000 s

Day and Night IR Cut Filter

Digital zoom 16x

Privacy mask 8 privac y masks programmable; a max imum of 8 zones can be maske d simultaneously on the same

video screen

Focus mode Auto / Semiau tomatic / Manual

Lens Focal length 3.3-119 mm, 36X

Zoom speed 6 s (Optical Wide-Tele) approx..

Angle of view 57.1 ~ 1.7 degree (Wide-Tele)

Minimum working distance 10 ~ 1000 mm (Wide-Tele)

Aperture range F1.4 ~ F3.7

Pan and Tilt Pan range 360° endless

Pan speed Pan Manual Speed: 0.1°/s ~ 250°/s, Pan Preset Speed: 300°/s

Tilt range -5° ~ 90° (auto ip )

Tilt speed Tilt Manual Spee d: 0.1°/s ~ 150°/s, Tilt Preset Speed: 200°/s

Proportional zoom Rotation spe ed can be adjus ted automatically according to zoom multiples

Number of Presets 255

Patrol 8 patrols, up to 32 presets per pat rol

SECTION 5: SPECIFICATIONS

Area Parameter Specication

Pan and Tilt (con t.)

Pattern 4 patterns, w ith a total recording time not le ss than 10 minutes

Power-o Memory Support

Park Ac tion Prese t / Patrol / Pattern / Pan / Tilt / Auto / Random / Frame / Panorama s can

PTZ Posi tion Display On / O 

Compass Support , north direc tion can be set

Scheduled Task Preset / Patrol / Pattern / Pan / Tilt / Auto / Rando m / Frame / Panorama scan

Input / Output Monitor Output 1.0 Vp-p / 75 Ω, composi te, BNC

General Menu Language English/Chinese

RS-485 Protocols Pelco-P, Pelco-D, self-adaptive

Power 24 Vac (outdoor dom e): 20 W max. (heater on), 12 W max. (heater o), Indoor d ome: 12 W max.

Working temper ature / humidity

-22 °F ~ 149 °F (-30 °C ~ 65 ° C)(outdoor dome); 14 °F ~ 122 °F (-10 °C ~ 50 °C) (indoor dome ) / 90% or less

Protection level IP6 6 standard (outdoor dome), TVS 4,0 00 V lightning protec tion, surge protec tion

Mounting Various mounting modes optional

Dimensions Φ8.6 6" × 12.00" (Φ220 × 305 mm )(outdoor),

Φ7.22" × 9.56" (Φ183.4 × 243 mm) (indoor), Φ9.65" × 9.29" (Φ245 × 236 mm) (in-ceiling)

Weight (approx.) 11.02 Ibs (5 Kg)

Mount option (only suitable for outdoor dome)

Ceiling Mount Bracket: BLK-PTZCL Wall Mount: BLK-PTZWB Pole Mount PTZ Br acket: BLK-PT ZPM Corner Mount PT Z Bracket: BL K-PTZCM

36x PTZ Dome Camera User Manual

APPENDIX A: LIGHTENING AND SURGE PROTECTION

APPENDIX A

Lightning and Surge Protection

This product includes TVS plate lightning protection technology to prevent damage caused by a pulse signal that is below 3000 watts from sources such as lighting, surging, etc. Protection measures must be taken to ensure electrical safety.

• The distance between signal transmission line and high-voltage equipment or high-voltage cable is at least 50 m.

• Outdoor wiring should better be along the eaves as much as possible.

• In the open eld, wiring should be buried underground in sealed steel pipe with one-point grounding. Overhead routing

method is not acceptable.

• In regions with thunderstorms or where high induction voltage are present (such as high-voltage transformer substation),

high power lightning protection apparatus and lightning conductor are necessary.

• The design for installation and wiring with lightning protection and grounding should be combined with the lightning

protection consideration of the building, and conform to the relevant national and industry standards.

• The system should ensure equi-potential grounding. Grounding equipment must satisfy both system anti-jamming and

electric safety. It must not allow short circuit and open circuit with the zero conductor of strong grid. When the system is singularly ground, the resistance must be no more than 4 Ω and the cross-sectional area of the grounding cable must be no less than 25 mm

. For grounding instructions, refer to local electrical codes and this manual.

Lightening rod

Communicate arrester

Video arrester

Power arrester

45° conical envelope

The resistance of

earthing conductor must

be smaller than 4 Ω.

The camera should be within a 45° envelope under the lightening rod.

Steel jacket

Lightning & Surge Protection

APPENDIX B: RS485 BUS CONNECTION

APPENDIX B

RS-485 Bus Connection

General Property of RS-485 Bus

RS-485 is a half-duplex communication bus that has a 120 Ω characteristic impendence. The maximum load ability is 32 payloads (including controller device and controlled device).

RS-485 Bus Transmission Distance

For 0.56 mm (24AWG) twisted-pair wire, the maximum transmission distance for dierent baud rates is shown as below:

Max. Distance of RS-485 transmission with 24AWG wire

Baud rate Maximum distance

240 0 bps 5900 f t (1800 m)

4800 bps 3900 ft (1200 m)

9600 bps 2600 ft (800 m)

The transmission distance is decreased for thinner cable, when the wire is exposed to strong electromagnetic interference. If many devices are installed on the bus, the transmission distance is increased.

Connection Methods

RS-485 industry bus standard requires a daisy-chain connection method between any devices, both sides have to connect a 120 Ω terminal resistance (see the diagram Connection 1 below). The simplied connection method is shown as diagram 2; the distance of “D” should be short.

120 Ω 120 Ω

#3#1 #4 #32#2

RS-485 Connection 1 diagram

36x PTZ Dome Camera User Manual

APPENDIX B: RS485 BUS CONNECTION

120 Ω 120 Ω

A+

B–

#3#1 #31#2Controller

RS-485 Connection 2 diagram

Problems in the practical application - star-shaped architecture

Although the star-shape connection method is commonly used, it does not satisfy the requirement of the RS-485 industry. This architecture can lead to problems such as signal reection, uncontrollable or self-running cameras, and anti-jamming inability with devices that are far away. In the star-shaped connection, the termination resistors are usually placed in the two devices that are farthest apart (see gures below).

120 Ω

#32

#15

Controller

Star-shaped connection

Signal transmission in the star-shaped architecture can be greatly improved by adding an RS-485 distributor. This product eectively changes the star-shape connection to one that satises the requirement of the RS-485 industry standard. See the diagram below.

APPENDIX B: RS485 BUS CONNECTION

A+

B–

120 Ω

#16

Star-shaped network with an RS-485 Distributor

FAQ of RS-485 Bus

Fault Probable Cause Solutions

The camera will perform a s elf check but cannot be controlled.

The address or b aud rate is not congured approp riately in the camera or controller.

Congure the camera ad dress and baud r ate to match in the controller an d the camera.

RS-485 +/- are connec ted incorrectly. Correc t the RS-4 85 wiring connections.

Wiring is disconnected Fastening the wire

RS-485 wire is broken Change the RS-485 wires

The camera can be controlled but does not operate smoothly.

Loose wire connections Fasten the RS -485 wires correctly

One RS-485 wire is broken Change or repair the broken wire

Controller and c amera are too far away Add terminal matched resistance

Too many devices are connec ted to the net work Add an RS-485 distributor.

36x PTZ Dome Camera User Manual

APPENDIX C: 24 VAC WIRE GAUGE AND TRANSMISSION DISTANCE

APPENDIX C

24 Vac Wire Gauge and Transmission Distance

The following table shows the recommended maximum distance adopted for the dierent wire sizes when the 24 Vac voltage loss is less than 10%. For the AC driven device, the maximum voltage loss rate allowable is 10%. For example, for a device with the rating power of 80 VA which is installed 35 feet (10 m) from the transformer, the minimum wire gauge required is 0.8000 mm.

Table 5. Table of wire gauge standards

Dist ance: ft (m) Wire Gauge (mm)

Powe r (VA) 0.8000 1.000 1. 250 2.000

10 283 (86) 451 (137) 716 (218) 1811 (551)

20 141 (42) 225 (68) 358 (109) 905 (275)

30 94 (28) 150 (45) 238 (72) 603 (183)

40 70 (21) 112 (34) 179 (54) 452 (137)

50 56 (17) 90 (27) 143 (43) 362 (110)

60 47 (14) 75 (22) 119 (36) 301 (91)

70 40 (12) 6 4 (19) 102 (31) 258 (78)

80 35 (10) 56 (17) 89 (27) 226 (68)

90 31 (9) 50 (15) 79 (24) 201 (61)

100 28 (8) 45 (13) 71 (21) 181 (55)

110 25 (7) 41 (12) 65 (19) 164 (49)

120 23 (7) 37 (11) 59 (17) 150 (45)

130 21 (6) 34 (10) 55 (16) 139 (42)

140 20 (6) 32 (9) 51 (15) 129 (39)

150 18 (5) 30 (9) 47 (14) 120 (36)

160 17 (5) 28 (8) 4 4 (13) 113 (34)

170 16 (4) 26 (7) 42 (12) 106 (32)

180 15 (4) 25 (7) 39 (11) 10 0 (30)

190 14 (4) 23 (7) 37 (11) 95 (28)

200 14 (4) 22 (6) 35 (10) 90 (27)

APPENDIX C: 24 VAC WIRE GAUGE AND TRANSMISSION DISTANCE

Table 6. Wire Gauge Standards

Bare Wire Gauge (mm)

American Wire Gauge

AWG

Cross-sectional Area of

Bare Wire (mm

)

0.750 21 0.4 417

0.800 20 0.5027

0.900 19 0.6362

1.000 18 0.7854

1.25 0 16 1.226 6

1.50 0 15 1.7663

2.000 12 3.14 20

2.500 4.9080

3.000 7.0 68 3

Observint The BLACK Line BLK-PTZ36X User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
