Oberon 1020-RAB User Manual

Installation Instructions

Model Number 1020-RAB

Assembly Components:

- Right angle wall mount – 1 each

- M4 x 8 screw (for attaching Model 1020-00 enclosure) – 4 each

- Model 1020-00 Assembly with instructions – 1 each

- Installation Instructions – 1 each

If any of these items are missing, contact your Oberon representative.

Find a flat work surface to prep the Model 1020-00 enclosure for installation. Make any modifications before mounting to the
wall.

Step 1 – Place the bracket mount on the wall
where it is to be installed (it is recommended that
you mount directly to a stud if possible) and mark
the screw locations. Use a minimum of two (2) #10
x 2” or larger screws (not included) to secure the
mount in place. However, if there is no stud at the
mounting location, it is recommended that you use
a minimum of 4 suitable anchors to secure the
mount in place (Figure 1).

Step 2 – Cut/Drill any holes needed in the Model
1020-00 enclosure for cable pass through.

Page 2

P/N 2316 – Rev. 01/22/2015 Oberon, Inc. •••• 1315 South Allen Street •••• State College, PA 16801 Copyright 2014

Figure 1

[phone] • www.oberonwireless.com

Step 3 – Fasten the enclosure to the bracket
using the provided M4 screws, so the openings
for the cable align (Figure 2).

Step 4 – Follow the Model 1020-00 installation
instructions for fastening access points and
hardware inside the enclosure.

Figure 3

Step 5 – Attach the data and power cables to the access point. After the access point is secured to the mounting bracket,
attach antennas to the access point if required.

**IMPORTANT** - It is important that the mount is securely fastened to the wall to prevent human injury or

damage to the access point.

Page 3

MODEL 1020-RAB

Installation Instructions

**** WARNING ****

Please thoroughly read the product warning

below before installation to provide for a safe

work environment.

Page 4

1. Always consider the hazard to other people:

a. During installation, use warning signs, etc.
b. Don’t work with people directly below the work area as equipment

could fall and cause an injury

2. Be sure to securely fasten the mount to the wall to prevent the mount
from becoming dislodged.
