X300 Pro3 User Manual
X300 Pro3 User Manual
Statement
This handbook is the manual of X300 Pro3. Without the written permission from the manufacturer,
any company or individual shall not copy or backup it in any form (electronic, mechanical,
photocopying, recording or otherwise).This manual is only operating instructions for X300 Pro3. If
any result caused by using it on other equipment, the company does not assume any
responsibility for it.
If not quality problems of X300 Pro3，such as eq uipment failure caused by user abuse or misuse,
unauthorized disassembly, repair equipment yourself, not operate or maintain by the instructions,
lose it, the repair will not be free. Other product names mentioned in this manual are in order to
describe how to use X300 Pro3, and their copyrights are still observed by the original company.
X300 Pro3 and files are used for normal vehicles maintenance. If used for illegal purposes, the
company does not assume legal responsibility.
www.carkeydeals.com
X300 Pro3 User Manual
Content
Chapter 1 : Summary…………………………………………………………………………………………………………………1
1.1 Features…………………………………………………………………………………………………………………………1
1.1.1 Advantages…………………………………………………………………………………….1
1.1.2 Durability………………………………………………………………………………………..1
1.2 Introduction of the device……………………………………………………………………....2
1.2.1 The main unit and accessories………………………………………………………….2
1.3 Hardware technical specification………………………………………………………………3
1.4 Functions Setting……………………………………………………………………………………..3
1.4.1 Functions Selection…………………………………………………………………………4
1.4.2 System Setting……………………………………………………………………………….4
1.4.2.1 Language Selection……………………………………………………………. 4
1.4.2.2 Contrast Adjustment……………………………………………………………5
1.4.2.3 Font Setting………………………………………………………………………5
1.4.2.4 Metric/Inch………………………………………………………………………..
1.4.2.5 Data Logging……………………………………………………………………..
1.4.3 System Information………………………………………………………………………5
1.4.4 Device Self-test………………………………………………………………………6
Chapter 2: How to update software for X300 PRO3……………………………………………6
2.1 Update Tool software Installation………………………………………………………….7
2.2 Software Updating……………………………………………………………………………….8
www.carkeydeals.com
X300 Pro3 User Manual
Chapter 1: Summary
1.1.Features
1.1.1. Advantages
●Multi-language environment can be applied in different countries and
regions.
●The main unit system adopts ARM high speed chip to keep it running
fast, stable and anti-jamming.
●Updating via SD card at any moment.
●Modern design and high-definition true color screen realize the
integration of automotive industry and electronic information technologies and make
auto diagnosis and key programming easier, practical and economical.
1.1.2 Durability
●Integrity structure design makes it crack resistance, shock resistance
and durable.
●Industrial design ensures the tool work stably under tough environment,
such as high and low temperatures.
www.carkeydeals.com
X300 Pro3 User Manual
1.2 Introduction of the device
1.2.1 The main unit and accessories(Picture as below)
Name Instruction
Testing cable port Connect to the main test cable for auto
key programming
Display Screen Show information
F1 Keyboard inpu
t
option key
F2 Keyboard inpu
t
option key
Enter OK
ESC Exi
tor
g
ive up
Up Up
Ri
ght
T
origh
t
Down Down
Left To left
TF card slot To keep diagnostic program or data
www.carkeydeals.com
X300 Pro3 User Manual
1.3 Hardware technical specification
★Dimension: 23.9cm(L)*12cm(W)*3.6cm(H)
★CPU :ARM7
★Power Supply:DC12V
★Operation Power:DC12V
★Operation Temperature: -20~60℃
★Display Screen:320*240 TFT Screen
1.4 Functions Setting
Power on， and then press ENTER on the screen， then go to the function setting,
setting information as shown below:
1.4.1 Function Selection
