Page 1
•
No Hammer Assembled
38104
¼ Turn, ASTM F1807, No Hammer, Assembled, Standa r d Pack
12
38153
¼ Turn, CPVC, No Hammer, Assembled, Contractor Pack
12
Hammer Assembled
38154
¼ Turn, Copper, Hammer, Assembled, Contractor Pack
12
38156
¼ Turn, ASTM F1960, Hammer, Assembled, Contractor Pack
12
CENTRO II WASHING MACHINE
OUTLET BOX
TECHNICAL SPECIFICATION: Oatey’s Centro II Washing Machine Box is used for commercial and residential washing
machine applications. Oatey’s Centro WMOB can be mounted with the valves on the top or bottom. Oatey’s WMOB comes
with two support brackets and two piece uninstalled valves.
[Type a quote from the doc ument or the
summary of an inte re st ing po in t. Y ou ca n
position the tex t box an ywh e re in t he
document. Use the Drawing Tools ta b to
change the formatting of the pull quote text
box.]
PRODUCT NUMBER DESCRIPTION CTN.
38100 ¼ Turn, Copper, No Hammer, Assembled, Standard Pack 12
38102 ¼ Turn, CPVC, No Hammer, Assembled, Standard Pack 12
38106 ¼ Turn, ASTM F1960, No Hammer, Assembled, Standard Pack 12
38150 ¼ Turn, Copper, No Hammer, Assembled, Contractor Pack 12
38151 ¼ Turn, ASTM F1807, No Hammer, Assembled, Contractor Pack 12
38152 ¼ Turn, ASTM F1960, No Hammer, Assembled, Contractor Pack 12
38101 ¼ Turn, Copper, Hammer, Assembled, Standard Pack 12
38103 ¼ Turn, CPVC, Hammer, Assembled, Standard Pack 12
38105 ¼ Turn, ASTM F1807, Hammer, Assembled, Standard Pack 12
38107 ¼ Turn, ASTM F1960, Hammer, Assembled, Standard Pack 12
38157 ¼ Turn, CPVC, Hammer, Assembled, Contractor Pack 12
38155 ¼ Turn, ASTM F1807, Hammer, Assembled, Contractor Pack 12
Takes up less space and will fit almost
anywhere
• WMOB made of PVC
• Brackets and Faceplate made of HIPS
• 2 knockout drain caps
• 2” Socket Hubs
• Mountable with valves on top or bottom
• 2 piece valves come uninstalled or
installed
• Two support brackets
• Available in a wide variety of tailpiece
configurations and packaging options
• Dimensions:
o WMOB-8”W x 4-3/4”H x 3”D
o Faceplate- 10”W x 6-3/4”H
QTY.
Visit www.oatey.com for updates
02/2014
Page 2
No Hammer Unassembled
38112
¼ Turn, ASTM F1807, No Hammer, Unassembled, Standard Pack
12
38109
¼ Turn, Copper, Hammer, Unassembled, Standard Pack
12
38113
¼ Turn, ASTM F1807, Hammer, Unassembled, Standard Pack
12
38120
Plain Box, Display Pack
4
Accessories
38383
Brackets 12" Long Plastic
12
CENTRO II WASHING MACHINE
OUTLET BOX
38108 ¼ Turn, Copper, No Hammer, Unassembled, Standard Pack 12
38110 ¼ Turn, CPVC, No Hammer, Unassembled, Standard Pack 12
38114 ¼ Turn, ASTM F1960, No Hammer, Unassembled, Standard Pack 12
Hammer Unassembled
38111 ¼ Turn, CPVC, Hammer, Unassembled, Standard Pack 12
38115 ¼ Turn, ASTM F1960, Hammer, Unassembled, Standard Pack 12
Plain Boxes
[Type a quote from the doc ument or the
summary of an inte re st ing po in t. Y ou ca n
38121 Plain Box, Standard Pack 12
position the tex t box an yw he re in t he
document. Use the Drawing Tools tab to
38381 Centro II, Plastic Faceplate 12
38382 Brackets 4" Long Plastic 12
change the formatting of the pull quote text
38294 Hot/Cold Temperature Indicator Clips for Supply Valves (12 Red, 12
box.]
Blue)
24
Visit www.oatey.com for updates
02/2014
