Oasis M8CREE User Manual
UNIVERSAL RADII™
BI-LEVEL MODULAR
M8CREE
Shall deliver 8.0 gph of 50° F degree water at 90° F ambient
and 80° F inlet water. Model M8CREE shall include one infrared
sensor to activate the of water. The fountain shall be
designed to eliminate splashing and standing water. Bubbler
shall have a guard and operate between 20 and
120 psi. Chiller unit shall use R-134a refrigerant. Shall be
listed by Underwriters’ Laboratories by Canadian
Standards Association. Shall comply with ANSI A117.1 and
ADA. Shall comply with the Safe Drinking Water Act and Lead
Contamination Control Act. Shall comply with ANSI/NSF 61.
™
Modular Bi-Level Water Cooler meets the needs of the
RADII
physically challenged and the able-bodied.
Model
M8CREE A light beam activates the fountain when
the user approaches. No touching or pushing is needed. The
system features a time delay to avoid unwanted activation and
a shut off if the user does not move away in 30 seconds. The
secondary fountain has a manually operated vandal resistant
button that requires no electricity to activate.
Standard Features
> Built-in 100 micron strainer stops particles before they enter
the waterway
> Flexible bubbler guard
> Brushed Stainless Steel Finish
> Refrigerant R-134a
> Heavy duty galvanized steel wall mounting frame
> High
cooling system
> Limited 5-Year Warranty
> Waterways are Lead-Free in Materials & Construction
Finishes
> Standard Finish: Stainless Steel
> Optional Finish (at additional cost): Regency Bronze
Installation
> Prior to roughing-in, consult local, state and federal codes for
proper mounting height.
> Wall mounting frame is furnished for easy installation
Universal Mount: high right or high left.
Options (at additional cost)
□ One Piece Tamperproof, Chrome Plated Brass Bubbler
(036700-001)
Limited 5-Year Warranty (Continental limits of the United
States and Canada): Five years on the sealed refrigeration
system and most component parts. Detailed warranty
enclosed with each water cooler; sample available upon
request.
Export Warranty: One year on the sealed refrigeration system
and most components parts. Detailed warranty
enclosed with each cooler; sample copy available upon request.
Product
to NSF/ANSI Standard 61, Annex G (weighted
average lead content of <=0.25%) and is in compliance with
California’s Health & Safety Code Section 116875 (commonly
known as AB1953).
Models covered by this
comply with all known
Plumbing Codes. Listed by Underwriters’ Laboratories to U.S.
and Canadian standards and European Directives.
ADA Compliant when installed in an alcove or with
right and left wing walls.
Components in this fountain are lead free as
by the Safe Drinking Water Act Amendments of 1986,
and the Lead Contamination Control Act of 1988.
50° F Drinking Water
90° F Ambient Air Temp*
Model
M8CREE 8.0 8.0 No No 1/4 4.8 550 No Yes 135 Lbs.
*Industry Standard Rating Condition 80° F inlet water temperature.
Rated Capacity
GPH
Base Rate
GPH Pre-Cooler
Hot’N Cold™
Model**
Compr.
HP
115 Volts, 60 HZ
Full Load
Amps
Rated
Watts
Glass Filler
Acc. Option
Cabinet
Color Finish
Net Wt.
Approx.
Form 3931 | Rev. 06/11
Oasis International • 222 East Campus View Blvd • Columbus, OH 43235
For Customer Service and Technical Helpline assistance call: 800.950.3226
OASIS
®
RADII
™
BARRIER-FREE BI-LEVEL MODULAR WATER COOLER MODEL M8CREE
www.oasiscoolers.com
A WBENC - Certied Women’s Business Enterprise
OASIS is a registered trademark of LVD Acquisition, LLC dba Oasis International
© 2011 LVD Acquisition, LLC
