SONGO™ LINK (BR30)
INSTRUCTION MANUAL
MANUEL D’INSTRUCTION
Wireless Bluetooth® Music Receiver
Récepteur de musique Bluetooth® sans l
NYRIUS.COM/SUPPORT
FCC STATEMENT
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
This class B digital apparatus complies with Canadian ICES-003.
WARNING:
This equipment has been tested and is found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
WARNING:
Changes or modications not expressly approved by the party responsible for
compliance with the FCC Rules could void the user’s authority to operate
this equipment.
IC STATEMENT
Industry Canada Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
- 2 -
SAFETY INFORMATION
1. Read all instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
9. Disconnect this apparatus during lightning storms or when unused for long
periods of time.
10. Refer all servicing to qualied service personnel. Servicing is required when
the apparatus has been damaged in any way, such as the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
11. Apparatus shall not be exposed to dripping or splashing, and ensure that no
objects lled with liquids, such as vases, shall be placed on the apparatus.
12. WARNING: To reduce the risk of re or electric shock, do not expose this
apparatus to rain or moisture.
This marking indicates that this product should not be disposed with
other household wastes throughout North America. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return
and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
- 3 -
TABLE OF CONTENTS
FCC Statement .............................................................................................................................. 2
IC Statement .................................................................................................................................. 2
Safety Information ........................................................................................................................ 3
What’s Included ............................................................................................................................ 4
Buttons and Connections ........................................................................................................... 5
Setup ................................................................................................................................................ 5
Pairing ............................................................................................................................................. 7
Troubleshooting ............................................................................................................................ 9
Specications ................................................................................................................................ 9
Nyrius Warranty ........................................................................................................................... 10
Connecting your Songo™ Link ................................................................................... 5
Pair & Connect ................................................................................................................ 7
To Disconnect ................................................................................................................. 7
Pairing multiple devices ............................................................................................... 8
Reconnecting your device ........................................................................................... 8
Understanding the LEDs ............................................................................................... 8
Out of Range or Lost Signal ........................................................................................ 8
WHAT’S INCLUDED
• Wireless Bluetooth® Music Receiver
• Quick Start Guide
• 1 Year Warranty
• Lifetime Customer Support
DISCLAIMERS
Maximum line of sight for Bluetooth® transmission range is 33 feet. When transmitting
through walls, oors, or ceilings the range will decrease depending on the environment.
Certain Bluetooth® features, including those listed, may not be supported by all compatible
Bluetooth-enabled devices, and/or the functionality of such features may be limited in certain
devices, or by certain wireless carriers.
We reserve the right to change models, conguration, or specications without notice or
liability. Product may not be exactly as shown.
©2014 NYRIUS®. All rights reserved. NYRIUS®, the NYRIUS® logo, SONGO™ and any other
NYRIUS® marks may be registered. All other Trademarks are the property of their
respective owners.
- 4 -
BUTTONS & CONNECTIONS
FRONT
1
2
SETUP
CONNECT THE SONGO™ LINK TO
YOUR 30-PIN MUSIC DOCK*
BOTTOM
21
LED indicator
Female 30-Pin Connection
*May not be compatible with specic docking stations with digital audio. See
specications for compatibility.
- 5 -
SETUP
TURN ON THE MUSIC DOCK
& SET IT TO IPOD / IPHONE
BLUETOOTH® PAIRING
BLUETOOT H ON
iPod / iPhone
NYRIUS BR30
CONNECTION OK
iPod / iPhone
* NYRIUS LED FLASHES WHEN SEARCHING FOR SIGNAL.
LED DIMS AFTER 60 SECONDS UNTIL A SIGNAL IS RECEIVED.
FOR BEST SIGNAL
MAXIMUM LINE OF SIGHT FOR BLUETOOTH TRANSMISSION RANGE IS 33 FEET
* OBSTACLES MAY DECREASE TRANSMISSION DISTANCE.
- 6 -
PAIRING
Play any Smartphone or Bluetooth® enabled device wirelessly through any 30-Pin
music dock*.
PAIR & CONNEC T
Once you connect the Songo™ Link to your 30 -Pin Docking Station, the Nyrius LED
will ash indicating it is in PAIRING mode searching for a signal.
1. Select the Bluetooth function on your device. Select "Nyrius BR30" on your
device to connect. If a pairing code is required, please use "0000".
2. Once successfully connected, the Nyrius LED will stop ashing & remain ON .
3. After inital connection, the Songo™ Link will seek the last device it was
connected to. If the device is turned on and in range, it will automatically
connect to it.
You can now control your music using your Bluetooth Device. The "Bluetooth
Active" icon will appear on the main screen when connected.
*May not be compatible with specic docking stations with digital audio. See
specications for compatibility.
How you access your Bluetooth® Settings may vary from one device to another.
Certain Bluetooth® features, including those listed, may not be supported by all
compatible Bluetooth-enabled devices, and/or the functionality of such features may
be limited in certain devices, or by certain wireless carriers.
TO DISCONNECT
1. Select the Bluetooth function on your device. Select
"Nyrius BR30" on your device to disconnect.
2. Select YES if asked to disconnect. The Nyrius LED on
the Songo™ Link will ash slowly once disconnected.
The "Bluetooth Active" icon will disappear from the main screen once disconnected.
- 7 -
PAIRING
PAIRING MULTIPLE DEVICES
Although the Songo™ Link can only play music from one device at a time, it can
memorize up to 4 device proles.
Switching from one device to another:
1. Select the Bluetooth function on your device and turn Bluetooth OFF.
2. The Songo™ Link can now be connected to a different device.
3. Follow the "PAIR & CONNECT" instructions to pair a new device.
RECONNECTING YOUR DEVICE
If you move out of range or turn off
the Bluetooth feature on your device,
the Songo™ Link will disconnect from
your device. To reconnect, simply turn
the Bluetooth feature back on or move
within 33 feet (line of sight) of the
Songo™ Link.
Note: Unit will auto-pair if it was the last device connected. If not, please refer to the
"PAIR & CONNECT" instructions.
iPod / iPhone
UNDERSTANDING THE LEDS
Flashing slowly / dim • Power is ON or
• Pairing in progress
Solid white light • Connected to
Bluetooth® device
Out of Range or Lost Signal
If the Bluetooth device is out of range (beyond 33 feet) of the Songo™ Link or if
there is something blocking the Bluetooth signal, the LED light will ash slowly to
indicate that the Bluetooth connection with the music device has been lost. To avoid
a lost connection:
1. Move the Bluetooth device back into range (within 33 feet), and/or make sure
there’s a clear line of sight and that there are no obstructions between the
Songo™ Link and the Bluetooth device.
2. Within 15 seconds, the connection will automatically be reestablished and the
LED light will stop ashing.
3. If the connection is lost for more than 15 seconds, the connection will need to
be reestablished. Follow the "RECONNECTING YOUR DEVICE" instructions.
- 8 -
• Waiting for connection
• Bluetooth® device
and Songo™ Link
are connected
TROUBLESHOOTING
Issue Bluetooth® Device Songo™ Link
No music
from music
dock
• Conrm that Bluetooth®
function is ON
• Conrm you are connected
via Bluetooth® with the
Songo™ Link (BR30)
• Conrm you are playing
music from your device
• Conrm you are within
range of the Songo™ Link
• Conrm Songo™ Link is properly
seated in the 30-pin music dock
• Conrm that the stereo
volume is set to a comfortable
listening level
• Conrm you are within range of
the Songo™ Link
• Conrm that the audio source
selection of your music dock is
set to iPod/iPhone
SPECIFICATIONS
Bluetooth® Prole 3.0 A2DP EDR (Enhanced Data Rate)
Codec SBC
Outputs Female 30-pin
Range 33 feet (line of sight)
Number of Devices Memorized 4
Frequency 2,402 ~ 2,480MHz
Autopairing Yes
Analog Docking Systems such as Fluance
Compatible Devices
Dimensions
Weight 0.03 lbs
FiSDK500/FiTSD600, Bose SoundDock
Portable, SoundDock I and II, SoundDock
10, iHome iP90, Logitech S715i, Geneva
S/M/L
1.4 x 0.5 x 1.9 inches, (L x W x H)
36 x 12 x 48.5 mm (L x W x H)
Support & Online live web chat
- 9 -
NYRIUS.COM/SUPPORT
WARRANTYWARRANTY
Thank you for choosing NYRIUS® Consumer Electronics Products!
NYRIUS gives the following express warranty to the original consumer purchaser or
gift recipient for this NYRIUS product, when shipped in its original container and sold
or distributed by NYRIUS or by an Authorized NYRIUS Dealer: NYRIUS warrants that
this product is free, under normal use and maintenance, from any defects in material
and workmanship. If any such defects should be found in this product within the
applicable warranty period, NYRIUS shall, at its option, repair or replace the product
as specied herein. Replacement parts furnished in connection with this warranty
shall be warranted for a period equal to the unexpired portion of the original
equipment warranty.
This warranty shall not apply to:
A. Any defects caused or repairs required as a result of abusive operation,
negligence, accident, improper installation or inappropriate use as outlined in the
owner’s manual.
B. Any NYRIUS product tampered with, modied, adjusted or repaired by any party
other than NYRIUS or NYRIUS’s Authorized Service Centres.
C. Damage caused or repairs required as a result of the use with items not specied
or approved by NYRIUS including but not limited to head cleaning tapes and
chemical cleaning agents.
D. Any replacement of accessories, glassware, consumable or peripheral items
required through normal use of the product including but not limited to
earphones, remote controls, AC adapters, batteries, stylus, trays, lters, cables,
paper, cabinet, cabinet parts, knobs, buttons, baskets, stands and shelves.
E. Any cosmetic damage to the surface or exterior that has been defaced or caused
by normal wear and tear.
F. Any damage caused by external or environmental conditions, including but not
limited to transmission line/power line voltage or liquid spillage.
G. Any product received without appropriate model, serial number and CSA /cUL /
cULus /cETL /cETLus markings.
H. Any products used for rental or commercial purposes.
I. Any installation, setup and/or programming charges.
Should this NYRIUS product fail to operate during the warranty period, warranty
service may be obtained upon delivery of the NYRIUS product together with proof of
purchase and a copy of this LIMITED WARRANTY statement to an Authorized NYRIUS
Service Centre. In-home warranty service may be provided at NYRIUS discretion on
any NYRIUS television with the screen size of 40” or larger. This warranty constitutes
the entire express warranty granted by NYRIUS and no other dealer, service centre or
their agent or employee is authorized to extend, enlarge or transfer this warranty on
behalf of NYRIUS. To the extent the law permits, NYRIUS disclaims any and all liability
for direct or indirect damages or losses or for any incidental, special or consequential
damages or loss of prots resulting from a defect in material or workmanship
relating to the product, including damages for the loss of time or use of this NYRIUS
product or the loss of information. The purchaser will be responsible for any removal,
reinstallation, transportation and insurance costs incurred. Correction of defects, in
the manner and period of time described herein, constitute complete fulllment of all
obligations and responsibilities of NYRIUS Electronics to the purchaser with respect
to the product and shall constitute full satisfaction of all claims, whether based on
contract, negligence, strict liability or otherwise.
1 YEAR PARTS & LABOUR WARRANTY PERIOD
TO OBTAIN THE NAME AND ADDRESS OF THE NEAREST AUTHORIZED NYRIUS
SERVICE CENTRE OR FOR MORE INFORMATION ON THIS WARRANTY CONTACT
NYRIUS SUPPORT:
• Support: nyrius.com/support
• Website: nyrius.com
NYRIUS is a registered trade-mark of Circus World Displays Limited 03.2014
4080 Montrose Road, Niagara Falls, ON, L2H 1J9
• By mail: NYRIUS Customer Service,
- 10 -
Loading...
