UM10310

P89LPC9321 User manual

Rev. 01 — 1 December 2008 User manual

Document information

Info Content Keywords P89LPC9321 Abstract Technical information for the P89LPC9321 device

NXP Semiconductors

UM10310

P89LPC9321 User manual

Revision history

Rev Date Description

01 20081201 Initial version.

Contact information

For more information, please visit: http://www.nxp.com For sales office addresses, please send an email to: salesaddresses@nxp.com

User manual Rev. 01 — 1 December 2008 2 of 139

NXP Semiconductors

P89LPC9321FDH

002aae104

P2.0/ICB

P2.1/OCD

P0.0/CMP2/KBI0

P1.7/OCC

P1.6/OCB

P1.5/RST

P3.1/XTAL1

P3.0/XTAL2/CLKOUT

P1.4/INT1

P1.3/INT0/SDA

P1.2/T0/SCL

P2.2/MOSI

P2.3/MISO

P2.7/ICA

P2.6/OCA

P0.1/CIN2B/KBI1

P0.2/CIN2A/KBI2

P0.3/CIN1B/KBI3

P0.4/CIN1A/KBI4

P0.5/CMPREF/KBI5

P0.6/CMP1/KBI6

P0.7/T1/KBI7

P1.0/TXD

P1.1/RXD

P2.5/SPICLK

P2.4/SS

1. Introduction

The P89LPC9321 is a single-chip microcontroller designed for applications demanding high-integration, low cost solutions over a wide range of performance requirements. The P89LPC9321 is based on a high performance processor architecture that executes instructions in two to four clocks, six times the rate of standard 80C51 devices. Many system-level functions have been incorporated into the P89LPC9321 in order to reduce component count, board space, and system cost.

1.1 Pin configuration

UM10310

P89LPC9321 User manual

User manual Rev. 01 — 1 December 2008 3 of 139

Fig 1. TSSOP28 pin configuration

NXP Semiconductors

P89LPC9321FA

002aae105

121314

161718

P1.6/OCB

P1.5/RST

P3.1/XTAL1

P3.0/XTAL2/CLKOUT

P1.4/INT1

P1.3/INT0/SDA

P1.7/OCC

P0.0/CMP2/KBI0

P2.1/OCD

P2.0/ICB

P2.7/ICA

P2.6/OCA

P0.1/CIN2B/KBI1

P0.2/CIN2A/KBI2

P0.3/CIN1B/KBI3

P0.4/CIN1A/KBI4

P0.5/CMPREF/KBI5

P0.6/CMP1/KBI6

P0.7/T1/KBI7

P1.2/T0/SCL

P2.2/MOSI

P2.3/MISO

P2.4/SS

P2.5/SPICLK

P1.1/RXD

P1.0/TXD

P89LPC9321FN

002aae106

P2.0/ICB

P2.1/OCD

P0.0/CMP2/KBI0

P1.7/OCC

P1.6/OCB

P1.5/RST

P3.1/XTAL1

P3.0/XTAL2/CLKOUT

P1.4/INT1

P1.3/INT0/SDA

P1.2/T0/SCL

P2.2/MOSI

P2.3/MISO

P2.7/ICA

P2.6/OCA

P0.1/CIN2B/KBI1

P0.2/CIN2A/KBI2

P0.3/CIN1B/KBI3

P0.4/CIN1A/KBI4

P0.5/CMPREF/KBI5

P0.6/CMP1/KBI6

P0.7/T1/KBI7

P1.0/TXD

P1.1/RXD

P2.5/SPICLK

P2.4/SS

UM10310

P89LPC9321 User manual

User manual Rev. 01 — 1 December 2008 4 of 139

Fig 2. PLCC28 pin configuration

Fig 3. DIP28 pin configuration

NXP Semiconductors

UM10310

P89LPC9321 User manual

1.2 Pin description

Table 1. Pin description

Symbol Pin Type Description

P0.0 to P0.7 I/O Port 0: Port 0 is an 8-bit I/O port with a user-configurable output type. During reset

P0.0/CMP2/ KBI0 3 I/O P0.0 — Port 0 bit 0.

P0.1/CIN2B/ KBI1

P0.2/CIN2A/ KBI2

P0.3/CIN1B/ KBI3

P0.4/CIN1A/ KBI4

P0.5/CMPREF/ KBI5

P0.6/CMP1/ KBI6 20 I/O P0.6 — Port 0 bit 6. High current source.

P0.7/T1/KBI7 19 I/O P0.7 — Port 0 bit 7. High current source.

P1.0 to P1.7 I/O, I

Port 0 latches are configured in the input only mode with the internal pull-up disabled. The operation of Port 0 pins as inputs and outputs depends upon the port configuration selected. Each port pin is configured independently. Refer to

Section 4.1 “

The Keypad Interrupt feature operates with Port 0 pins. All pins have Schmitt triggered inputs. Port 0 also provides various special functions as described below:

O CMP2 — Comparator 2 output. I KBI0 — Keyboard input 0.

26 I/O P0.1 — Port 0 bit 1.

I CIN2B — Comparator 2 positive input B. I KBI1 — Keyboard input 1.

25 I/O P0.2 — Port 0 bit 2.

I CIN2A — Comparator 2 positive input A. I KBI2 — Keyboard input 2.

24 I/O P0.3 — Port 0 bit 3. High current source.

I CIN1B — Comparator 1 positive input B. I KBI3 — Keyboard input 3.

23 I/O P0.4 — Port 0 bit 4. High current source.

I CIN1A — Comparator 1 positive input A. I KBI4 — Keyboard input 4. I AD13 — ADC1 channel 3 analog input.

22 I/O P0.5 — Port 0 bit 5. High current source.

I CMPREF — Comparator reference (negative) input. I KBI5 — Keyboard input 5.

O CMP1 — Comparator 1 output. I KBI6 — Keyboard input 6.

I/O T1 — Timer/counter 1 external count input or overflow output. I KBI7 — Keyboard input 7.

Port 1: Port 1 is an 8-bit I/O port with a user-configurable output type, excep t for

[1]

three pins as noted below. During reset Port 1 latches are configured in the input only mode with the internal pull-up disabled. The operation of the configurable Port 1 pins as inputs and outputs depends upon the port configuration selected. Each of the configurable port pins are programmed independently. Refer to

Section 4.1 “

used as outputs. P1.5 is input only. All pins have Schmitt triggered inputs. Port 1 also provides various special functions as described below:

Port configurations” for details.

Port configurations” for details. P1.2 to P1.3 are open drain when

User manual Rev. 01 — 1 December 2008 5 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 1. Pin description

Symbol Pin Type Description

P1.0/TXD 18 I/O P1.0 — Port 1 bit 0.

P1.1/RXD 17 I/O P1.1 — Port 1 bit 1.

P1.2/T0/SCL 12 I/O P1.2 — Port 1 bit 2 (open-drain when used as output).

P1.3/INT0

P1.4/INT1

P1.5/RST

P1.6/OCB 5 I/O P1.6 — Port 1 bit 6. High current source.

P1.7/OCC 4 I/O P1.7 — Port 1 bit 7. High current source.

P2.0 to P2.7 I/O Port 2: Port 2 is an 8-bit I/O port with a user-configurable output type. During reset

P2.0/ICB 1 I/O P2.0 — Port 2 bit 0.

P2.1/OCD 2 I/O P2.1 — Port 2 bit 1.

P2.2/MOSI 13 I/O P2.2 — Port 2 bit 2 .

P2.3/MISO 14 I/O P2.3 — Port 2 bit 3 .

P2.4/SS

/SDA 11 I/O P1.3 — Port 1 bit 3 (open-drain when used as output).

10 I/O P1.4 — Port 1 bit 4. High current source.

6IP1.5 — Port 1 bit 5 (input only).

15 I/O P2.4 — Port 2 bit 4.

…continued

O TXD — Transmitter output for serial port.

I RXD — Receiver input for serial port.

I/O T0 — Timer/counter 0 external count input or overflow output (open-drain when

used as output).

I/O SCL — I

I INT0 I/O SDA — I

I INT1

I RST

functioning as a reset input, a LOW on this pin resets the microcontroller, causing I/O ports and peripherals to take on their default states, and the processor begins execution at address 0. Also used during a power-on sequence to force ISP mode.

O OCB — Output Compare B

O OCC — Output Compare C.

Port 2 latches are configured in the input only mode with the internal pull-up disabled. The operation of Port 2 pins as inputs and outputs depends upon the port configuration selected. Each port pin is configured independently. Refer to

Section 4.1 “

All pins have Schmitt triggered inputs. Port 2 also provides various special functions as described below:

I ICB — Input Capture B.

O OCD — Output Compare D.

I/O MOSI — SPI master out slave in. When configured as master, this pin is output;

when configured as slave, this pin is input.

I/O MISO — When configured as master, this pin is input, when configured as slave,

this pin is output.

I/O SS

C-bus serial clock input/output.

— External interrupt 0 input.

C-bus serial data input/output.

— External interrupt 1 input.

— External Reset input during power-on or if selected via UCFG1. When

Port configurations” for details.

— SPI Slave select.

User manual Rev. 01 — 1 December 2008 6 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 1. Pin description …continued

Symbol Pin Type Description

P2.5/SPICLK 16 I/O P2.5 — Port 2 bit 5.

I/O SPICLK — SPI clock. When configured as master, this pin is output; when

configured as slave, this pin is input.

P2.6/OCA 27 I/O P2.6 — Port 2 bit 6.

O OCA — Output Compare A.

P2.7/ICA 28 I/O P2.7 — Port 2 bit 7.

I ICA — Input Capture A.

P3.0 to P3.1 I/O Port 3: Port 3 is a 2-bit I/O port with a user-configurable output type. During reset

Port 3 latches are configured in the input only mode with the internal pull-up disabled. The operation of Port 3 pins as inputs and outputs depends upon the port configuration selected. Each port pin is configured independently. Refer to

Section 4.1 “

All pins have Schmitt triggered inputs. Port 3 also provides various special functions as described below:

P3.0/XTAL2/ CLKOUT

P3.1/XTAL1 8 I/O P3.1 — Port 3 bit 1.

9I/OP3.0 — Port 3 bit 0.

O XTAL2 — Output from the oscillator amplifier (when a crystal oscillator option is

selected via the flash configuration.

O CLKOUT — CPU clock divided by 2 when enabled via SFR bit (ENCLK -TRIM.6).

It can be used if the CPU clock is the internal RC oscillator, watchdog oscillator or external clock input, except when XTAL1/XTAL2 are used to generate clock source for the RTC/system timer.

I XTAL1 — Input to the oscillator circuit and internal clock generator circuits (when

selected via the flash configuration). It can be a port pin if internal RC oscillator or watchdog oscillator is used as the CPU clock source, and if XTAL1/XTAL2 are not

used to generate the clock for the RTC/system timer. 7IGround: 0 V reference. 21 I Power supply: This is the power supply voltage for normal operation as well as

Idle and Power-down modes.

Port configurations” for details.

[1] Input/output for P1.0 to P1.4, P1.6, P1.7. Input for P1.5.

User manual Rev. 01 — 1 December 2008 7 of 139

NXP Semiconductors

PORT 0

PORT 3

TXD RXD T0 INT0 INT1 RST

SCL SDA

002aae103

CMP2 CIN2B CIN2A CIN1B CIN1A

CMPREF

CMP1

XTAL2

XTAL1

KBI0 KBI1 KBI2 KBI3 KBI4 KBI5 KBI6 KBI7

MOSI MISO SS SPICLK

PORT 1

PORT 2

P89LPC9321

OCB OCC

ICB OCD

OCA ICA

CLKOUT

1.3 Functional diagram

Fig 4. Functional diagram

UM10310

P89LPC9321 User manual

User manual Rev. 01 — 1 December 2008 8 of 139

NXP Semiconductors

ACCELERATED 2-CLOCK 80C51 CPU

8 kB

CODE FLASH

256-BYTE

DATA RAM

PORT 2

CONFIGURABLE I/Os

PORT 1

CONFIGURABLE I/Os

PORT 0

CONFIGURABLE I/Os

KEYPAD

INTERRUPT

PROGRAMMABLE

OSCILLATOR DIVIDER

CPU clock

CONFIGURABLE

OSCILLATOR

ON-CHIP RC

OSCILLATOR

WITH CLOCK

DOUBLER

internal bus

POWER MONITOR (POWER-ON RESET, BROWNOUT RESET)

002aae102

UART

ANALOG

COMPARATORS

512-BYTE

AUXILIARY RAM

I2C-BUS

512-BYTE

DATA EEPROM

PORT 3

CONFIGURABLE I/Os

CCU (CAPTURE/ COMPARE UNIT)

P89LPC9321

WATCHDOG TIMER

AND OSCILLATOR

TIMER 0 TIMER 1

REAL-TIME CLOCK/

SYSTEM TIMER

SPI

P3[1:0]

P2[7:0]

P1[7:0]

P0[7:0]

TXD RXD

SCL SDA

T0 T1

CMP2 CIN2B CIN2A CMP1 CIN1A CIN1B

OCA OCB OCC OCD ICA ICB

SPICLK MOSI MISO SS

CRYSTAL

RESONATOR

XTAL2

XTAL1

1.4 Block diagram

UM10310

P89LPC9321 User manual

Fig 5. Block diagram

User manual Rev. 01 — 1 December 2008 9 of 139

NXP Semiconductors

1.5 Special function registers

Remark: SFR accesses are restricted in the following ways:

• User must not attempt to access any SFR locations not defined.

• Accesses to any defined SFR locations must be strictly for the functions for the SFRs.

• SFR bits labeled ‘-’, ‘0’ or ‘1’ can only be written and read as follows:

UM10310

P89LPC9321 User manual

– ‘-’ Unless otherwise specified, must be written with ‘0’, but can return any value

when read (even if it was written with ‘0’). It is a reserved bit and may be used in future derivatives.

– ‘0’ must be written with ‘0’, and will return a ‘0’ when read. – ‘1’ must be written with ‘1’, and will return a ‘1’ when read.

User manual Rev. 01 — 1 December 2008 10 of 139

xxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxx x x x xxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxx xx xx xxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxx xxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxx x x xxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxx xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxx

User manual Rev. 01 — 1 December 2008 11 of 139

Table 2. Special function registers

* indicates SFRs that are bit addressable.

Name Description SFR

ACC* Accumulator E0H 00 0000 0000 AUXR1 Auxiliary

B* B register F0H 00 0000 0000 BRGR0

BRGR1

BRGCON Baud rate

CCCRA Capture

CCCRB Capture

CCCRC Capture

CCCRD Capture

CMP1 Comparator 1

CMP2 Comparator 2

DEECON Data EEPROM

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

Bit functions and addresses Reset value

addr.

MSB LSB Hex Binary

Bit addressE7E6E5E4E3E2E1E0

A2H CLKLP EBRR ENT1 ENT0 SRST 0 - DPS 00 0000 00x0 function register

Bit addressF7F6F5F4F3F2F1F0

[2]

Baud rate

BEH 00 0000 0000 generator 0 rate low

[2]

Baud rate

BFH 00 0000 0000 generator 0 rate high

BDH------SBRGSBRGEN00 generator 0 control

EAH ICECA2 ICECA1 ICECA0 ICESA ICNFA FCOA OCMA1 OCMA0 00 0000 0000 compare A control register

EBH ICECB2 ICECB1 ICECB0 ICESB ICNFB FCOB OCMB1 OCMB0 00 0000 0000 compare B control register

ECH - - - - - FCOC OCMC1 OCMC0 00 xxxx x000 compare C control register

EDH - - - - - FCOD OCMD1 OCMD0 00 xxxx x000 compare D control register

ACH - - CE1 CP1 CN1 OE1 CO1 CMF1 00 control register

ADH - - CE2 CP2 CN2 OE2 CO2 CMF2 00 control register

F1H EEIF HVERR ECTL1 ECTL0 - EWERR1 EWERR0 EADR8 08 00001000

control register

[2]

[1]

NXP Semiconductors

xxxx xx00

P89LPC9321 User manual

UM10310

xx00 0000

User manual Rev. 01 — 1 December 2008 12 of 139

Table 2. Special function registers

* indicates SFRs that are bit addressable.

Name Description SFR

DEEDA T Data EEPROM

DEEADR Data EEPROM

DIVM CPU clock

DPTR Data pointer

DPH Data pointer

DPL Data pointer

FMADRH Program flash

FMADRL Program flash

FMCON Program flash

FMDATA Program flash

I2ADR I

I2CON* I

I2DAT I

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

data register

address register

divide-by-M control

(2 bytes)

high

low

address high

address low

control (Read) Program flash

control (Write)

data

C-bus slave address register

Bit address DF DE DD DC DB DA D9 D8

C-bus control register

C-bus data register

…continued

Bit functions and addresses Reset value

addr.

F2H 00 0000 0000

F3H 00 0000 0000

95H 00 0000 0000

83H 00 0000 0000

82H 00 0000 0000

E7H 00 0000 0000

E6H 00 0000 0000

E4H BUSY - - - HVA HVE SV OI 70 0111 0000

E4H FMCMD.7 FMCMD.6 FMCMD.5 FMCMD.4 FMCMD.3 FMCMD.2 FMCMD.1 FMCMD.0

E5H 00 0000 0000

DBH I2ADR.6 I2ADR.5 I2ADR.4 I2ADR.3 I2ADR.2 I2ADR.1 I2ADR.0 GC 00 0000 0000

D8H - I2EN STA STO SI AA - CRSEL 00 x000 00x0

DAH

MSB LSB Hex Binary

NXP Semiconductors

P89LPC9321 User manual

UM10310

User manual Rev. 01 — 1 December 2008 13 of 139

Table 2. Special function registers

* indicates SFRs that are bit addressable.

Name Description SFR

I2SCLH Serial clock

I2SCLL Serial clock

I2STAT I

ICRAH Input capture A

ICRAL Input capture A

ICRBH Input capture B

ICRBL Input capture B

IEN0* Interrupt

IEN1* Interrupt

IP0* Interrupt

IP0H Interrupt

IP1* Interrupt

IP1H Interrupt

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

generator/SCL duty cycle register high

generator/SCL duty cycle register low

C-bus status register

Bit address AF AE AD AC AB AA A9 A8

enable 0

Bit address EF EE ED EC EB EA E9 E8

enable 1

Bit address BF BE BD BC BB BA B9 B8

priority 0

priority 0 high

Bit address FF FE FD FC FB FA F9 F8

priority 1

priority 1 high

…continued

Bit functions and addresses Reset value

addr.

MSB LSB Hex Binary

DDH 00 0000 0000

DCH 00 0000 0000

D9H STA.4 STA.3 STA.2 STA.1 STA.0 0 0 0 F8 1111 1000

ABH 00 0000 0000

AAH 00 0000 0000

AFH 00 0000 0000

AEH 00 0000 0000

A8H EA EWDRT EBO ES/ESR ET1 EX1 ET0 EX0 00 0000 0000

[1]

00x0 0000

x000 0000

E8H EIEE EST - ECCU ESPI EC EKBI EI2C 00

B8H - PWDRT PBO PS/PSR PT1 PX1 PT0 PX0 00

B7H - PWDRTH PBOH PSH/

PT1H PX1H PT0H PX0H 00

PSRH

[1]

00x0 0000

F8H PIEE PST - PCCU PSPI PC PKBI PI2C 00

F7H PIEEH PSTH - PCCUH PSPIH PCH PKBIH PI2CH 00

NXP Semiconductors

P89LPC9321 User manual

UM10310

User manual Rev. 01 — 1 December 2008 14 of 139

Table 2. Special function registers

* indicates SFRs that are bit addressable.

Name Description SFR

KBCON Keypad control

KBMASK Keypad

KBPA TN Keypad pattern

OCRAH Output

OCRAL Output

OCRBH Output

OCRBL Output

OCRCH Output

OCRCL Output

OCRDH Output

OCRDL Output

P0* Port 0 80H T1/KB7 CMP1

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

…continued

Bit functions and addresses Reset value

addr.

94H------PATN

86H 00 0000 0000 interrupt mask register

93H FF 1111 1111 register

EFH 00 0000 0000 compare A register high

EEH 00 0000 0000 compare A register low

FBH 00 0000 0000 compare B register high

FAH 00 0000 0000 compare B register low

FDH 00 0000 0000 compare C register high

FCH 00 0000 0000 compare C register low

FFH 00 0000 0000 compare D register high

FEH 00 0000 0000 compare D register low

Bit address8786858483828180

Bit address9796959493929190

MSB LSB Hex Binary

/KB6

CMPREF

/KB5

CIN1A

/KB4

CIN1B

/KB3

CIN2A

/KB2

_SEL

CIN2B

/KB1

KBIF 00

CMP2

/KB0

NXP Semiconductors

[1]

xxxx xx00

P89LPC9321 User manual

UM10310

[1]

User manual Rev. 01 — 1 December 2008 15 of 139

Table 2. Special function registers …continued

* indicates SFRs that are bit addressable.

Name Description SFR

P1* Port 1 90H OCC OCB RST INT1 INT0/SDA T0/SCL RXD TXD

P2* Port 2 A0H ICA OCA SPICLK SS

P3*Port3B0H------XTAL1XTAL2 P0M1 Port 0 output

P0M2 Port 0 output

P1M1 Port 1 output

P1M2 Port 1 output

P2M1 Port 2 output

P2M2 Port 2 output

P3M1 Port 3 output

P3M2 Port 3 output

PCON Power control

PCONA Power control

PSW* Program status

PT0AD Port 0 digital

RSTSRC Reset source

RTCCON RTC control D1H RTCF RTCS1 RTCS0 - - - ERTC RTCEN 60

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

Bit functions and addresses Reset value

addr.

Bit addressA7A6A5A4A3A2A1A0

Bit addressB7B6B5B4B3B2B1B0

84H (P0M1.7) (P0M1.6) (P0M1.5) (P0M1.4) (P0M1.3) (P0M1.2) (P0M1.1) (P0M1.0) FF

mode 1

85H (P0M2.7) (P0M2.6) (P0M2.5) (P0M2.4) (P0M2.3) (P0M2.2) (P0M2.1) (P0M2.0) 00

mode 2

91H (P1M1.7) (P1M1.6) - (P1M1.4) (P1M1.3) (P1M1.2) (P1M1.1) (P1M1.0) D3

mode 1

92H (P1M2.7) (P1M2.6) - (P1M2.4) (P1M2.3) (P1M2.2) (P1M2.1) (P1M2.0) 00

mode 2

A4H (P2M1.7) (P2M1.6) (P2M1.5) (P2M1.4) (P2M1.3) (P2M1.2) (P2M1.1) (P2M1.0) FF mode 1

A5H (P2M2.7) (P2M2.6) (P2M2.5) (P2M2.4) (P2M2.3) (P2M2.2) (P2M2.1) (P2M2.0) 00 mode 2

B1H------(P3M1.1)(P3M1.0)03 mode 1

B2H------(P3M2.1)(P3M2.0)00 mode 2

87H SMOD1 SMOD0 - BOI GF1 GF0 PMOD1 PMOD0 00 0000 0000

B5H RTCPD DEEPD VCPD - I2PD SPPD SPD CCUPD 00 register A

Bit addressD7D6D5D4D3D2D1D0

D0H CY AC F0 RS1 RS0 OV F1 P 00 0000 0000 word

F6H - - PT0AD.5 PT0AD.4 PT0AD.3 PT0AD.2 PT0AD.1 - 00 xx00 000x

input disable

DFH - BOIF BOF POF R_BK R_WD R_SF R_EX register

MSB LSB Hex Binary

MISO MOSI OCD ICB

NXP Semiconductors

[1]

1111 1111

[1]

0000 0000

[1]

11x1 xx11

[1]

00x0 xx00

[1]

1111 1111

[1]

0000 0000

[1]

xxxx xx11

[1]

xxxx xx00

[1]

0000 0000

P89LPC9321 User manual

UM10310

[3]

[1][6]

011x xx00

User manual Rev. 01 — 1 December 2008 16 of 139

Table 2. Special function registers

* indicates SFRs that are bit addressable.

Name Description SFR

RTCH RTC register

RTCL RTC register

SADDR Serial port

SADEN Serial port

SBUF Serial Port data

SCON* Serial port

SSTAT Serial port

SP Stack pointer 81H 07 0000 0111 SPCTL SPI control

SPSTAT SPI status

SPDAT SPI data

TAMOD Timer 0 and 1

TCON* Timer 0 and 1

TCR20* CCU control

TCR21 CCU control

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

…continued

Bit functions and addresses Reset value

addr.

D2H 00 high

D3H 00 low

A9H 00 0000 0000 address register

B9H 00 0000 0000 address enable

99H xx xxxx xxxx

buffer register

Bit address 9F 9E 9D 9C 9B 9A 99 98

98H SM0/FE SM1 SM2 REN TB8 RB8 TI RI 00 0000 0000

control

BAH DBMOD INTLO CIDIS DBISEL FE BR OE STINT 00 0000 0000 extended status register

E2H SSIG SPEN DORD MSTR CPOL CPHA SPR1 SPR0 04 0000 0100 register

E1HSPIFWCOL------0000xxxxxx register

E3H 00 0000 0000 register

8FH - - - T1M2 - - - T0M2 00 xxx0 xxx0

auxiliary mode

Bit address 8F 8E 8D 8C 8B 8A 89 88

88H TF1 TR1 TF0 TR0 IE1 IT1 IE0 IT0 00 0000 0000

control

C8H PLEEN HLTRN HLTEN ALTCD ALTAB TDIR2 TMOD21 TMOD20 00 0000 0000 register 0

F9H TCOU2 - - - PLLDV.3 PLLDV.2 PLLDV.1 PLLDV.0 00 0xxx 0000

MSB LSB Hex Binary

[6]

NXP Semiconductors

0000 0000

P89LPC9321 User manual

UM10310

User manual Rev. 01 — 1 December 2008 17 of 139

Table 2. Special function registers …continued

* indicates SFRs that are bit addressable.

Name Description SFR

TH0 Timer 0 high 8CH 00 0000 0000 TH1 Timer 1 high 8DH 00 0000 0000 TH2 CCU timer high CDH 00 0000 0000 TICR2 CCU interrupt

TIFR2 CCU interrupt

TISE2 CCU interrupt

TL0 Timer 0 low 8AH 00 0000 0000 TL1 Timer 1 low 8BH 00 0000 0000 TL2 CCU timer low CCH 00 0000 0000 TMOD Timer 0 and 1

TOR2H CCU reload

TOR2L CCU reload

TPCR2H Prescaler

TPCR2L Prescaler

TRIM Internal

WDCON Watchdog

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

Bit functions and addresses Reset value

addr.

C9H TOIE2 TOCIE2D TOCIE2C TOCIE2B TOCIE2A - TICIE2B TICIE2A 00 0000 0x00 control register

E9H TOIF2 TOCF2D TOCF2C TOCF2B TOCF2A - TICF2B TICF2A 00 0000 0x00 flag register

DEH - - - - - ENCINT.2 ENCINT.1 ENCINT.0 00 xxxx x000 status encode register

89H T1GATE T1C/T T1M1 T1M0 T0GATE T0C/T T0M1 T0M0 00 0000 0000

mode

CFH 00 0000 0000 register high

CEH 00 0000 0000 register low

CBH------TPCR2H.1TPCR2H.000xxxx xx00 control register high

CAH TPCR2L.7 TPCR2L.6 TPCR2L.5 TPCR2L.4 TPCR2L.3 TPCR2L.2 TPCR2L.1 TPCR2L .0 00 0000 0000 control register low

96H RCCLK ENCLK TRIM.5 TRIM.4 TRIM.3 TRIM.2 TRIM.1 TRIM.0 oscillator trim register

A7H PRE2 PRE1 PRE0 - - WDRUN WDTOF WDCLK

control register

MSB LSB Hex Binary

[5][6]

[4][6]

NXP Semiconductors

P89LPC9321 User manual

UM10310

User manual Rev. 01 — 1 December 2008 18 of 139

Table 2. Special function registers …continued

* indicates SFRs that are bit addressable.

Name Description SFR

WDL Watchdog load C1H FF 1111 1111 WFEED1 Watchdog

WFEED2 Watchdog

[1] All ports are in input only (high-impedance) state after power-up. [2] BRGR1 and BRGR0 must only be written if BRGEN in BRGCON SFR is logic 0. If any are written while BRGEN = 1, the result is unpredictable. [3] The RSTSRC register reflects the cause of the UM10310 reset except BOIF bit. Upon a power-up reset, all reset source flags are cleared except POF and BOF; the power-on

[4] After reset, the value is 1110 01x1, i.e., PRE2 to PRE0 are all logic 1, WDRUN = 1 and WDCLK = 1. WDTOF bit is logic 1 after watchdog reset and is logic 0 after power-on reset.

[5] On power-on reset and watchdog reset, the TRIM SFR is initialized with a factory preprogrammed value. Other resets will not cause initialization of the TRIM register. [6] The only reset sources that affect these SFRs are power-on reset and watchdog reset.

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

Bit functions and addresses Reset value

addr.

C2H

feed 1

C3H

feed 2

reset value is x0110000.

Other resets will not affect WDTOF.

MSB LSB Hex Binary

NXP Semiconductors

P89LPC9321 User manual

UM10310

User manual Rev. 01 — 1 December 2008 19 of 139

Table 3. Extended special function registers

Name Description SFR

BODCFG BOD

CLKCON CLOCK Control

PGACON1 PGA1 control

PGACON1B PGA1 control

PGA1 TRIM8X16X PGA1 trim

PGA1 TRIM2X4X PGA1 trim

RTCDATH Real-time clock

RTCDATL Real-time clock

xxxxxxxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx xxx

configuration register

data register high

data register low

[1]

Bit functions and addresses Reset value

addr.

FFC8H - - - - - - BOICFG1 BOICFG0

FFDEH CLKOK - - XTALWD CLKDBL FOSC2 FOSC1 FOSC0

FFE1H ENPGA1 PGASEL11PGASEL10PGATRIM

MSB LSB Hex Binary

[2]

[3]

1000 0100

- - PGAG11 PGAG10 00 0000 0000

FFE4H - - - - - - - PGAENO

00 0000 0000

FF1

FFE3H 16XTRIM3 16XTRIM2 16XTRIM1 16XTRIM0 8XTRIM3 8XTRIM2 8XTRIM1 8XTRIM0

FFE2H 4XTRIM3 4XTRIM2 4XTRIM1 4XTRIM0 2XTRIM3 2XTRIM2 2XTRIM1 2XTRIM0

[4]

FFBFH 00 0000 0000

FFBEH 00 0000 0000

NXP Semiconductors

[1] Extended SFRs are physically located on-chip but logically located in external data memory address space (XDATA). The MOVX A,@DPTR and MOVX @DPTR,A instructions are

used to access these extended SFRs. [2] The BOICFG1/0 will be copied from UCFG1.5 and UCFG1.3 when power-on reset. [3] CLKCON register reset value comes from UCFG1 and UCFG2. The reset value of CLKCON.2 to CLKCON.0 come from UCFG1.2 to UCFG1.0 and reset value of CLKDBL bit

comes from UCFG2.7. [4] On power-on reset and watchdog reset, the PGAxTRIM8X16X and PGAxTRIM2X4X registers are initialized with a factory preprogrammed value. Other resets will not cause

initialization.

P89LPC9321 User manual

UM10310

NXP Semiconductors

002aae090

0000h

03FFh

0400h

07FFh

0800h

0BFFh

0C00h

0FFFh

SECTOR 0

SECTOR 1

SECTOR 2

SECTOR 3

1000h

13FFh

1400h

17FFh

1800h

1BFFh

1C00h

1E00h

1FFFh

SECTOR 4

SECTOR 5

SECTOR 6

FFEFh

FF00h

IAP entry-

points

SECTOR 7

ISP CODE

(512B)

(1)

SPECIAL FUNCTION

REGISTERS

(DIRECTLY ADDRESSABLE)

128 BYTES ON-CHIP

DATA MEMORY (STACK,

DIRECT AND INDIR. ADDR.)

4 REG. BANKS R[7:0]

data memory

(DATA, IDATA)

data EEPROM

DATA

128 BYTES ON-CHIP

DATA MEMORY (STACK

AND INDIR. ADDR.)

IDATA (incl. DATA)

FFEFh FFh

80h

7Fh

00h

FF1Fh

FF00h

entry points for:

-51 ASM. code

-C code

IDATA routines

1FFFh

1E00h

entry points for:

-UART (auto-baud)

-I2C, SPI, etc.

(1)

ISP serial loader

entry points

read-protected

IAP calls only

DATA EEPROM

(512 BYTES)

[SFR ACCESS]

01FFh

0000h

EXTENDED SFRs

FFFFh

FFB0h

RESERVED

01FFh

XDATA

(512 BYTES)

0000h

1.6 Memory organization

UM10310

P89LPC9321 User manual

Fig 6. P89LPC9321 memory map

The various P89LPC9321 memory spaces are as follows: DATA — 128 bytes of internal data memory space (00h:7Fh) accessed via direct or

indirect addressing, using instruction other than MOVX and MOVC. All or part of the Stack

User manual Rev. 01 — 1 December 2008 20 of 139

may be in this area. IDATA — Indirect Data. 256 bytes of internal data memory space (00h:FFh) accessed via

indirect addressing using instructions other than MOVX and MOVC. All or part of the Stack may be in this area. This area includes the DATA area and the 128 bytes immediately above it.

SFR — Special Function Registers. Sele cted CPU registers and peripheral control and status registers, accessible only via direct addressing.

XDATA — ‘External’ Data or Auxiliary RAM. Duplicates the classic 80C51 64 kB memory space addressed via the MOVX instruction using the DPTR, R0, or R1. All or part of this space could be implemented on-chip. The P89LPC9321 has 512 b ytes of on-chip XDATA memory, plus extended SFRs located in XDATA.

CODE — 64 kB of Code memory space, accessed as part of program execution and via the MOVC instruction. The P89LPC9321 has 8 kB of on-chip Code memory.

The P89LPC9321 also has 512 bytes of on-chip Data EEPROM that is accessed via SFRs (see Section Section 17 “

Data EEPROM”).

NXP Semiconductors

Table 4. Data RAM arrangement

Type Data RAM Size (bytes)

DATA Directly and indirectly addressable memory 128 IDATA Indirectly addressable memory 256 XDATA Auxiliary (‘External Data’) on-chip memory that is accessed using

2. Clocks

2.1 Enhanced CPU

The P89LPC9321 uses an enhanced 80C51 CPU which runs at six times the speed of standard 80C51 devices. A machine cycle consists of two CPU clock cycles, and most instructions execute in one or two machine cycles.

2.2 Clock definitions

UM10310

P89LPC9321 User manual

512

the MOVX instructions

The P89LPC9321 device has several internal clocks as defined below: OSCCLK — Input to the DIVM clock divider. OSCCLK is selected from one of four clock

sources and can also be optionally divided to a slower frequency (see Figure 8

Section 2.10 “

CPU Clock (CCLK) modification: DIVM register”). Note: f

the OSCCLK frequency. CCLK — CPU clock; output of the DIVM clock divider. There are two CCLK cycles per

machine cycle, and most instructions are executed in one to two machine cycles (two or four CCLK cycles).

RCCLK — The internal 7.373 MHz RC oscillator output.The clock doubler option, when enabled, provides an output frequency of 14.746 MHz.

PCLK — Clock for the various peripheral devices and is

2.2.1 Oscillator Clock (OSCCLK)

The P89LPC9351 provides several user-selectable oscillator options in generating the CPU clock. This allows optimization for a range of needs from high precision to lowest possible cost. These options are configured when the flash is programmed and include an on-chip watchdog oscillator, an on-chip RC oscillator, an oscillator using an external crystal, or an external clock source.

2.3 External crystal oscillator option

The external crystal oscillator can be optimized for low, medium, or high frequency crystals covering a range from 20 kHz to 18 MHz. It can be the clock source of OSCCLK, RTC and WDT.

CCLK

and

is defined as

osc

⁄

2.3.1 Low speed oscillator option

This option supports an external crystal in the range of 20 kHz to 100 kHz. Ceramic resonators are also supported in this configuration

User manual Rev. 01 — 1 December 2008 21 of 139

NXP Semiconductors

2.3.2 Medium speed oscillator option

This option supports an external crystal in the range of 100 kHz to 4 MHz. Ceramic resonators are also supported in this configuration.

2.3.3 High speed oscillator option

This option supports an external crystal in the range of 4 MHz to 18 MHz. Ceramic resonators are also supported in this configuration.

2.4 Clock output

The P89LPC9321 supports a user-selectable clock output function on the XTAL2 / CLKOUT pin when the crystal oscillator is not being used. This condition occurs if a different clock source has been selected (on-chip RC oscillator, watchdog oscillator, external clock input on X1) and if the Real-time Clock and Watchdog Timer are not using the crystal oscillator as their clock source. This allows external devices to synchronize to the P89LPC9321. This output is enabled by the ENCLK bit in the TRIM register.

UM10310

P89LPC9321 User manual

The frequency of this clock output is

⁄

that of the CCLK. If the clock output is not needed

in Idle mode, it may be turned off prior to entering Idle, saving additional power. Note: on reset, the TRIM SFR is initialized with a factory preprogrammed value. Therefore when setting or clearing the ENCLK bit, the user should retain the contents of other bits of the TRIM register. This can be done by reading the contents of the TRIM register (into the ACC for example), modifying bit 6, and writing this result back into the TRIM register. Alternatively, the ‘ANL direct’ or ‘ORL direct’ instructions can be used to clear or set bit 6 of the TRIM register.

2.5 On-chip RC oscillator option

The P89LPC9321 has a 6-bit TRIM register that can be used to tune the frequency of the RC oscillator. During reset, the TRIM value is initialized to a factory pre-programmed value to adjust the oscillator frequency to 7.373 MHz ± 1 % at room temperature. (Note: the initial value is better than 1 %; please refer to the P89LPC9321 data sheet for behavior over temperature). End user applications can write to the TRIM register to adjust the on-chip RC oscillator to other frequencies. Increasing the TRIM value will decrease the oscillator frequency. When the clock doubler option is enabled (UCFG2.7 = 1), the output frequency is doubled. If CCLK is 8 MHz or slower, the CLKLP SFR bit (AUXR1.7) can be set to logic 1 to reduce power consumption. On reset, CLKLP is logic 0 allowing highest performance access. This bit can then be se t in software if CCLK is runni ng at 8 MHz or slower. When clock doubler option is enabled, BOE1 bit (UCFG1.5) and BOE0 bit (UCFG1.3) are required to hold the device in reset at power-up until V its specified level.

Table 5. On-chip RC oscillator trim register (TRIM - address 96h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol RCCLK ENCLK TRIM.5 TRIM.4 TRIM.3 TRIM.2 TRIM.1 TRIM.0 Reset 0 0 Bits 5:0 loaded with factory stored value during reset.

has reached

User manual Rev. 01 — 1 December 2008 22 of 139

NXP Semiconductors

002aad364

XTAL1

XTAL2

quartz crystal or

ceramic resonator

(1)

UM10310

P89LPC9321 User manual

Table 6. On-chip RC oscillator trim register (TRIM - address 96h) bit description

Bit Symbol Description

0 TRIM.0 Trim value. Determines the frequency of the internal RC oscillator. During reset, 1TRIM.1 2TRIM.2 3TRIM.3

these bits are loaded with a stored factory calibration value. When writing to either bit 6 or bit 7 of this register, care should be taken to preserve the current TRIM value by reading this register, modifying bits 6 or 7 as required, and writing the result to

this register. 4TRIM.4 5TRIM.5

CCLK

⁄

6 ENCLK when = 1,

is output on the XTAL2 pin provided the crystal oscillator is not

being used. 7 RCCLK when = 1, selects the RC Oscillator output as the CPU clock (CCLK). This allows for

fast switching between any clock source and the internal RC oscillator without

needing to go through a reset cycle.

2.6 Watchdog oscillator option

The watchdog has a separate oscillator which has a frequency of 400 kHz, calibrated to ± 5 % at room temperature. This oscillator can be used to save power when a high clock frequency is not needed.

2.7 External clock input option

In this configuration, the processor clock is derived from an external source driving the XT AL1 / P3.1 pin. The rate may be from 0 Hz up to 18 MHz. The XTAL2 / P3 .0 pin may be used as a standard port pin or a clock output. When using an oscillator frequency above 12 Mhz, BOE1 bit (UCFG1.5) and BOE0 bit (UCFG1.3) are required to hold the device in reset at power-up until V

Note: The oscillator must be configured in one of the following modes: Low frequency crystal, medium frequency crystal, or high frequency crystal.

(1) A series resistor may be required to limit crystal drive levels. This is especially important for low

frequency crystals (see text).

Fig 7. Using the crystal oscillator.

has reached its specified level.

User manual Rev. 01 — 1 December 2008 23 of 139

NXP Semiconductors

÷2

002aae108

RTC

CPU

WDT

DIVM

CCLK

UART

OSCCLK

I2C-BUS

PCLK

TIMER 0 AND

TIMER 1

HIGH FREQUENCY

MEDIUM FREQUENCY

LOW FREQUENCY

XTAL1

XTAL2

RC OSCILLATOR

WITH CLOCK DOUBLER

WATCHDOG

OSCILLATOR

(7.3728 MHz/14.7456 MHz ± 1 %)

PCLK

RCCLK

SPI

CCU

32 × PLL

(400 kHz ± 5 %)

UM10310

P89LPC9321 User manual

Note: The oscillator must be configured in one of the following modes: Low frequency crystal, medium frequency crystal, or high frequency crystal.

(1) A series resistor may be required to limit crystal drive levels. This is especially important for low frequency crystals (see text).

Fig 8. Block diagram of oscillator control.

Table 7. Clock control register (CLKCON - address FFDEh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol CLKOK - - XTALWD CLKDBL FOSC2 FOSC1 FOSC0 Reset1000xxxx

Table 8. Clock control register (CLKCON - address FFDEh) bit description

Bit Symbol Description

2:0 FOSC2, FOSC1,

3 CLKDBL Clock doubler option for clock switch. When set, doubles the output frequency of the

4 XTALWD external crystal oscillator as the clock source of watchdog timer. When =0, disable

6:5 - reserved 7 CLKOK Clock switch completed flag. When = 1, clock switch is completed. When =0, clock

User manual Rev. 01 — 1 December 2008 24 of 139

2.8 Clock sources switch on the fly

P89LPC9321 can implement clock source switch in any sources of watchdog oscillator, 7/14MHz IRC oscillator, external crystal oscillator and external clock input during code is running. CLKOK bit in register CLKCON is read only and used to indicate the clock switch status. When CLKOK is ‘0’, clock switch is processing, not completed. When CLKOK is ‘1’, clock switch is completed. When start new clock source switch, CLKOK is cleared automatically. Notice that when CLKOK is ‘0’, Writing to CLKCON register is not allowed. During reset, CLKCON register value comes from UCFG1 and UCFG2. Th e reset value of CLKCON.2 to CLKCON.0 come from UCFG1.2 to UCFG1.0 and reset value of CLKDBL bit comes from UCFG2.7.

CPU oscillator type selection for clock switch. See Section 2

FOSC0

information. Combinations other than those shown in Table 9

use should not be used.

internal RC oscillator.

external crystal oscillator as the clock source of watchdog timer.

switch is processing and writing to register CLKCON is not allowed.

for additional are reserved for future

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 9. Oscillator type selection for clock switch

FOSC[2:0] Oscillator configuration

111 External clock input on XTAL1. 100 Watchdog Oscillator, 400 kHz ± 5 %. 011 Internal RC oscillator, 7.373 MHz ± 1 %. 010 Low frequency crystal, 20 kHz to 100 kHz. 001 Medium frequency crystal or resonator, 100 kHz to 4 MHz. 000 High frequency crystal or resonator, 4 MHz to 18 MHz.

2.9 Oscillator Clock (OSCCLK) wake-up delay

The P89LPC9321 has an internal wake-up timer that delays the clock until it stabilizes depending on the clock source used. If the clock source is any of the three crystal selections (low, medium and high frequencies) the delay is 1024 OSCCLK cycles plus 60 μsto100μs. If the clock source is the internal RC oscillator, the delay is 200 μsto300μs. If the clock source is watchdog oscillator or external clock, the delay is 32 OSCCLK cycles.

2.10 CPU Clock (CCLK) modification: DIVM register

The OSCCLK frequency can be divided down, by an integer, up to 510 times by configuring a dividing register, DIVM, to provide CCLK. This produces the CCLK frequency using the following formula:

2.1 1 Low power select

3. Interrupts

CCLK frequency = f

Where: f

is the frequency of OSCCLK, N is the value of DIVM.

osc

Since N ranges from 0 to 255, the CCLK frequency can be in the range of f (for N = 0, CCLK = f

osc

/ (2N)

osc

to f

osc

/510.

This feature makes it possible to temporarily run the CPU at a lower rate, reducing power consumption. By dividing the clock, the CPU can retain the ability to respond to events other than those that can cause interrupts (i.e. events that allow exiting the Idle mode) by executing its normal program at a lower rate. This can often result in lower power consumption than in Idle mode. This can allow bypassing the oscillator start-up time in cases where Power-down mode would otherwise be used. The value of DIVM may be changed by the program at any time without interrupting code execution.

The P89LPC9321 is designed to run at 18 MHz (CCLK) maximum. However, if CCLK is 8 MHz or slower, the CLKLP SFR bit (AUXR1.7) can be set to a logic 1 to lower the power consumption further. On any reset, CLKLP is logic 0 allowing highest performance. This bit can then be set in software if CCLK is running at 8 MHz or slower.

The P89LPC9321 uses a four priority level interrupt structure. This allows great flexibility in controlling the handling of the P89LPC9321’s 15 interrupt sources.

User manual Rev. 01 — 1 December 2008 25 of 139

NXP Semiconductors

Each interrupt source can be individually enabled or disabled by setting or clearing a bit in the interrupt enable registers IEN0 or IEN1. The IEN0 register also contains a glo bal enable bit, EA, which enables all interrupts.

Each interrupt source can be individually programmed to one of four priority levels by setting or clearing bits in the interrupt priority registers IP0, IP0H, IP1, and IP1H. An interrupt service routine in progress can be interrupted by a higher priority interrupt, but not by another interrupt of the same or lower priority. The highest priority interrupt service cannot be interrupted by any other interrupt source. If two requests of different priority levels are received simultaneously, the request of higher priority level is serviced.

If requests of the same priority level are pending at the start of an instruction cycle, an internal polling sequence determines which request is serviced. This is called the arbitration ranking. Note that the arbit ra tio n ra nk ing is only us ed for pen din g req ue sts of the same priority level. Table 11 addresses, enable bits, priority bits, arbitration ranking, and whether each interrupt may wake-up the CPU from a Power-down mode.

3.1 Interrupt priority structure

Table 10. Interrupt priority level

Priority bits IPxH IPx Interrupt priority level

0 0 Level 0 (lowest priority) 0 1 Level 1 1 0 Level 2 1 1 Level 3

UM10310

P89LPC9321 User manual

summarizes the interrupt sources, flag bits, vector

There are four SFRs associated with the four interrupt levels: IP0, IP0H, IP1, IP1H. Every interrupt has two bits in IPx and IPxH (x = 0, 1) and can therefore be assigned to one of four levels, as shown in Table 11

The P89LPC9321 has two external interrupt inputs in addition to the Keypad Interrupt function. The two interrupt inputs are identical to those present on the standard 80C51 microcontrollers.

These external interrupts can be programmed to be level-triggered or edge-triggered by clearing or setting bit IT1 or IT0 in Register TCON. If ITn = 0, external interrupt n is triggered by a low level detected at the INTn triggered. In this mode if consecutive samples of the INTn

pin. If ITn = 1, external interrupt n is edge

pin show a high level in one cycle and a low level in the next cycle, interrupt request flag IEn in TCON is set, causing an interrupt request.

Since the external interrupt pins are sample d once each machine cycle, an input high or low level should be held for at least one machine cycle to ensure proper sampling. If the external interrupt is edge-triggered, the external source has to hold the request pin high for at least one machine cycle, and then hold it low for at least one machine cycle. This is to ensure that the transition is detected and that interrupt request flag IEn is set. IEn is automatically cleared by the CPU when the service routine is called.

User manual Rev. 01 — 1 December 2008 26 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

If the external interrupt is level-triggered, the external source must h old the re quest a ctive until the requested interrupt is generated. If the external interrupt is still asserted when the interrupt service routine is completed, another interrupt will be generated. It is not necessary to clear the interrupt flag IEn when the interrupt is level sensitive, it simply tracks the input pin level.

If an external interrupt has been programmed as level-triggered and is enabled when the P89LPC9321 is put into Power-down mode or Idle mode, the interrupt occurrence will cause the processor to wake-up and resume operation. Refer to Section 5.3 “

Power reduction modes” for details. Note: the external interrupt must be programmed as

level-triggered to wake-up from Power-down mode.

3.2 External Interrupt pin glitch suppression

Most of the P89LPC9321 pins have glitch suppression circuits to reject short glitches (please refer to the P89LPC9321 data sheet, Dynamic characteristics for glitch filter specifications). However, pins SDA/INT0 suppression circuits. Therefore, INT1

Table 11. Summary of interrupts

Description Interrupt flag

External interrupt 0 IE0 0003h EX0 (IEN0.0) IP0H.0, IP0.0 1 (highest) Yes Timer 0 interrupt TF0 000Bh ET0 (IEN0.1) IP0H.1, IP0.1 4 No External interrupt 1 IE1 0013h EX1 (IEN0.2) IP0H.2, IP0.2 7 Yes Timer 1 interrupt TF1 001Bh ET1 (IEN0.3) IP0H.3, IP0.3 10 No Serial port Tx and Rx TI and RI 0023h ES/ESR (IEN0.4) IP0H.4, IP0.4 13 No Serial port Rx RI Brownout detect BOIF 002Bh EBO (IEN0.5) IP0H.5, IP0.5 2 Yes Watchdog timer/Real-time

clock

C interrupt SI 0033h EI2C (IEN1.0) IP0H.0, IP0.0 5 No

I KBI interrupt KBIF 003Bh EKBI (IEN1.1) IP0H.0, IP0.0 8 Yes Comparators 1 and 2

interrupts SPI interrupt SPIF 004Bh ESPI (IEN1.3) IP1H.3, IP1.3 14 No Capture/Compare Unit 005Bh ECCU(IEN1.4) IP1H.4, IP1.4 6 No Serial port Tx TI 006Bh EST (IEN1.6) IP0H.0, IP0.0 12 No Data EEPROM write

complete

Vector

bit(s)

WDOVF/RTCF 0053h EWDRT (IEN0.6) IP0H.6, IP0.6 3 Yes

CMF1/CMF2 0043h EC (IEN1.2) IP0H.0, IP0.0 11 Yes

address

0073h EAD (IEN1.7) IP1H.7, IP1.7 15 (lowest) No

Interrupt enable bit(s)

/P1.3 and SCL/T0/P1.2 do not have the glitch

has glitch suppression while INT0 does not.

Interrupt priority

Arbitration ranking

Powerdown wake-up

User manual Rev. 01 — 1 December 2008 27 of 139

NXP Semiconductors

002aae160

IE0

EX0

IE1

EX1

BOIF

EBO

KBIF

EKBI

interrupt to CPU

wake-up (if in power-down)

EWDRT

CMF2 CMF1

EA (IE0.7)

TF1 ET1

TI & RI/RI

ES/ESR

EST

EI2C

SPIF

ESPI

RTCF ERTC

(RTCCON.1)

WDOVF

TF0 ET0

any CCU interrupt

ECCU

EEIF EIEE

UM10310

P89LPC9321 User manual

Fig 9. Interrupt sources, interrupt enables, and power-down wake-up sources.

4. I/O ports

User manual Rev. 01 — 1 December 2008 28 of 139

The P89LPC9321 has four I/O ports: Port 0, Port 1, Port 2, and Port 3. Ports 0, 1,and 2 are 8-bit ports, and Port 3 is a 2-bit port. The exact number of I/O pins available depends upon the clock and reset options chosen (see Table 12

Table 12. Number of I/O pins available

Clock source Reset option Number of I/O

On-chip oscillator or watchdog oscillator

External clock input No external reset (except during power up) 25

Low/medium/high speed oscillator (external crystal or resonator)

No external reset (except during power up) 26 External RST

External RST No external reset (except during power up) 24 External RST

pins

pin supported 25

pin supported 24

pin supported 23

NXP Semiconductors

4.1 Port configurations

All but three I/O port pins on the P89LPC9321 may be configured by software to one of four types on a pin-by-pin basis, as shown in Table 13 (standard 80C51 port outputs), push-pull, open drain, and input-only. Two configuration registers for each port select the output type for each port pin.

UM10310

P89LPC9321 User manual

. These are: quasi-bidirectional

P1.5 (RST P1.2 (SCL/T0) and P1.3 (SDA/INT0

) can only be an input and cannot be configured.

) may only be configured to be either input-only or

open drain.

Table 13. Port output configuration settings

PxM1.y PxM2.y Port output mode

0 0 Quasi-bidirectional 0 1 Push-pull 1 0 Input only (high-impedance) 1 1 Open drain

4.2 Quasi-bidirectional output configuration

Quasi-bidirectional outputs can be used both as an input and output without the need to reconfigure the port. This is possible because when the port outputs a logic high, it is weakly driven, allowing an external device to pull the pin low . When the pin is driven low, it is driven strongly and able to sink a large current. There are three pull-up transistors in the quasi-bidirectional output that serve different purposes.

One of these pull-ups, called the ‘very weak’ pull-up, is turned on whenever the port latch for the pin contains a logic 1. This very weak pull-up sources a very small current that will pull the pin high if it is left floating.

A second pull-up, called the ‘weak’ pull-up, is turned on when the port latch for the pin contains a logic 1 and the pin itself is also at a logic 1 level. This pull-up provides the primary source current for a quasi-bidirectional pin that is outputting a 1. If this pin is pulled low by an external device, the weak pull-up turns of f, and only the very weak pu ll-up remains on. In order to pull the pin low under these conditions, the external device has to sink enough current to overpower the weak pull-up and pull the port pin below its input threshold voltage.

The third pull-up is referred to as the ‘strong’ pull-up. This pull-up is used to speed up low-to-high transitions on a quasi-bidirectional port pin when the port latch cha nges from a logic 0 to a logic 1. When this occurs, the strong pull-up turns on for two CPU clocks quickly pulling the port pin high.

The quasi-bidirectional port configuration is shown in Figure 10

Although the P89LPC9321 is a 3 V device most of the pins are 5 V-tolerant. If 5 V is applied to a pin configured in quasi-bidirectional mode, there will be a current flowing from the pin to V

causing extra power consumption. Therefore, applying 5 V to pins

configured in quasi-bidirectional mode is discouraged. A quasi-bidirectional port pin has a Schmitt-triggered input that also has a glitch

suppression circuit

User manual Rev. 01 — 1 December 2008 29 of 139

NXP Semiconductors

002aaa914

2 CPU

CLOCK DELAY

port latch

data

weakstrong

input

data

very

weak

PP P

port

glitch rejection

002aaa915

port latch

data

input data

glitch rejection

port

(Please refer to the P89LPC9321 data sheet, Dynamic characteristics for glitch filter specifications).

UM10310

P89LPC9321 User manual

Fig 10. Quasi-bidirectional output.

4.3 Open drain output configuration

The open drain output configuration turns off all pull-ups and only drives the pull-down transistor of the port pin when the port latch contains a logic 0. To be used as a logic output, a port configured in this manner must have an external pull-up, typically a resistor tied to V

The open drain port configuration is shown in Figure 11 An open drain port pin has a Schmitt-triggered input that also has a glitch suppression

circuit. Please refer to the P89LPC9321 data sheet, Dynamic characteristics for glitch filter

specifications.

. The pull-down for this mode is the same as for the quasi-bidirectional mode.

Fig 11. Open drain output.

User manual Rev. 01 — 1 December 2008 30 of 139

NXP Semiconductors

002aaa916

input

data

port

glitch rejection

002aaa917

port latch

data

input data

port

strong

glitch rejection

4.4 Input-only configuration

The input port configuration is shown in Figure 12. It is a Schmitt-triggered input that also has a glitch suppression circuit.

(Please refer to the P89LPC9321 data sheet, Dynamic characteristics for glitch filter specifications).

Fig 12. Input only.

4.5 Push-pull output configuration

The push-pull output configuration has the same pull-down structure as both the open drain and the quasi-bidirectional output modes, but provides a continuous strong pull-up when the port latch contains a logic 1. The push-pull mode may be used when more source current is needed from a port output.

UM10310

P89LPC9321 User manual

The push-pull port configuration is shown in Figure 13

. A push-pull port pin has a Schmitt-triggered inpu t that also has a glitch suppression circuit. (Please refer to the P89LPC9321 data sheet, Dynamic characteristics for glitch filter

specifications).

Fig 13. Push-pull output.

4.6 Port 0 and Analog Comparator functions

The P89LPC9321 incorporates two Analog Comp arators. In or der to give the best ana log performance and minimize power consumption, pins that are being used for analog functions must have both the digital outputs and digital inputs disabled.

User manual Rev. 01 — 1 December 2008 31 of 139

NXP Semiconductors

Digital outputs are disabled by putting the port pins into the input-only mode as describe d in the Port Configurations section (see Figure 12

Digital inputs on Port 0 may be disabled through the use of the PT0AD register. Bits 1 through 5 in this register correspond to pins P0.1 through P0.5 of Port 0, respectively. Setting the corresponding bit in PT0AD disabl es tha t pin’ s digit a l input. Port bits that have their digital inputs disabled will be read as 0 by any instruction that accesses the port.

On any reset, PT0AD bits 1 through 5 default to logi c 0s to enable the digital functions.

4.7 Additional port features

After power-up, all pins are in Input-Only mode. Please note that this is different from the LPC76x series of devices.

• After power-up, all I/O pins except P1.5, may be configured by software.

• Pin P1.5 is input only. Pins P1.2 and P1.3 are configurable for either input-only or

Every output on the P89LPC9321 has been designed to sink typical LED drive current. However, there is a maximum total output current for all ports which must not be exceeded. Please refer to the P89LPC9321 data sheet for detailed specifications.

UM10310

P89LPC9321 User manual

open drain.

All ports pins that can function as an output have slew rate controlled outputs to limit noise generated by quickly switching output signals. The slew rate is factory-set to approximately 10 ns rise and fall times.

Table 14. Port output configuration

Port pin Configuration SFR bits

PxM1.y PxM2.y Alternate usage Notes

P0.0 P0M1.0 P0M2.0 KBIO, CMP2 P0.1 P0M1.1 P0M2.1 KBI1, CIN2B Refer to Section 4.6 “ P0.2 P0M1.2 P0M2.2 KBI2, CIN2A P0.3 P0M1.3 P0M2.3 KBI3, CIN1B P0.4 P0M1.4 P0M2.4 KBI4, CIN1A P0.5 P0M1.5 P0M2.5 KBI5, CMPREF P0.6 P0M1.6 P0M2.6 KBI6, CMP1 P0.7 P0M1.7 P0M2.7 KBI7, T1 P1.0 P1M1.0 P1M2.0 TXD P1.1 P1M1.1 P1M2.1 RXD P1.2 P1M1.2 P1M2.2 T0, SCL Input-only or open-drain P1.3 P1M1.3 P1M2.3 INTO P1.4 P1M1.4 P1M2.4 INT1 P1.5 P1M1.5 P1M2.5 RST P1.6 P1M1.6 P1M2.6 OCB P1.7 P1M1.7 P1M2.7 OCC P2.0 P2M1.0 P2M2.0 ICB P2.1 P2M1.1 P2M2.1 OCD P2.2 P2M1.2 P2M2.2 MOSI

, SDA input-only or open-drain

Analog Comparator functions” for

usage as analog inputs.

Port 0 and

User manual Rev. 01 — 1 December 2008 32 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 14. Port output configuration

Port pin Configuration SFR bits

PxM1.y PxM2.y Alternate usage Notes

P2.3 P2M1.3 P2M2.3 MISO P2.4 P2M1.4 P2M2.4 SS P2.5 P2M1.5 P2M2.5 SPICLK P2.6 P2M1.6 P2M2.6 OCA P2.7 P2M1.7 P2M2.7 ICA P3.0 P3M1.0 P3M2.0 CLKOUT, XTAL2 P3.1 P3M1.1 P3M2.1 XTAL1

5. Power monitoring functions

The P89LPC9321 incorporates power monitoring functions designed to prevent incorrect operation during initial power-on and power loss or reduction during operation. This is accomplished with two hardware functions: Power-on Detect and Brownout Detect.

5.1 Brownout detection

The brownout detect function determines if the power supply voltage drops below a certain level. Enhanced BOD has 3 indepen dent functions: BOD rese t, BOD interrupt and BOD EEPROM/FLASH.

…continued

BOD reset will cause a processor reset and it is always on, except in total power-down mode. It could not be disabled in software. BOD interrupt will generate an interrupt and could be enabled or disabled in software.

BOD reset and BOD interrupt, each has 4 trip voltage levels. BOE1 bit (UCFG1.5) and BOE0 bit (UCFG1.3) are used as trip point configuration bits of BOD reset. BOICFG1 bit and BOICFG0 bit in register BODCFG are used as trip point configuration bits of BOD interrupt. BOD reset voltage should be lower than BOD interrupt trip point. Table 15

gives

BOD trip points configuration. In total power-down mode (PMOD1/PMOD0 = '11'), the circuitry for the Brownout

Detection is disabled for lowest power consumption. When PMOD1/PMOD0 not equal to '11', BOD reset is always on and BOD interrupt is enabled by setting BOI (PCON.4) bit. Please refer Table 16

for BOD reset and BOD interrupt configuration. BOF bit (RSTSRC.5), BOD reset flag is default as '0' and is set when BOD reset is tripped. BOIF bit (RSTSRC.6), BOD interrupt flag is default as '0' and is set when BOD interrupt is tripped.

BOD EEPROM/FLASH is used for flash/Data EEPROM program/erase protection. BOD EEPROM/FLASH is always on, except in power-down or total power down mode (PCON.1=1). It can not be disabled in software. BOD EEPROM/FLASH has only 1 trip voltage level of 2.4 V. When voltage supply is lower than 2.4 V, the BOD EEPROM/FLASH is tripped and flash/Data EEPROM program/erase is blocked.

If brownout detection is enabled the brownout condition occurs when V brownout trip voltage and is negated when V

rises above the brownout trip voltage.

falls below the

User manual Rev. 01 — 1 December 2008 33 of 139

NXP Semiconductors

For correct activation of Brownout Detect, certain VDD rise and fall times must be observed. Please see the data sheet for specifications.

Table 15. BOD Trip points configuration

BOE1 (UCFG1.5)

00 0 0 Reserved 00 0 1 00 1 0 00 1 1 01 0 0 0 1 0 1 2.2V 2.4V 0 1 1 0 2.2V 2.6V 0 1 1 1 2.2V 3.2V 10 0 0 Reserved 10 0 1 1 0 1 0 2.4V 2.6V 1 0 1 1 2.4V 3.2V 11 0 0 Reserved 11 0 1 11 1 0 1 1 1 1 3.0V 3.2V

BOE0 (UCFG1.3)

BOICFG1 (BOICFG.1)

BOICFG0 (BOICFG.0)

UM10310

P89LPC9321 User manual

BOD Reset

BOD Interrupt

Table 16. BOD Reset and BOD Interrupt configuration

PMOD1/PMOD0(PCON[1:0]) BOI

(PCON.4)

1 1 (total power-down) X X X N N ≠ 11 (any mode other than total

power down)

0XXYN 10XYN

EBO (IEN0.5)

X0YN 11YY

EA (IEN0.7)

BOD Reset

5.2 Power-on detection

The Power-On Detect has a function similar to the Brownout Detect, but is designed to work as power initially comes up, before the power supply voltage reaches a level where the Brownout Detect can function. The POF flag (RSTSRC.4) is set to indicate an initial power-on condition. The POF flag will remain set until cleared by software by writing a logic 0 to the bit. BOF (RSTSRC.5) will be set when POF is set.

5.3 Power reduction modes

The P89LPC9321 supports three d ifferent power reduction modes as d etermine d by SFR bits PCON[1:0] (see Table 17

BOD Interrupt

User manual Rev. 01 — 1 December 2008 34 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 17. Power reduction modes

PMOD1 (PCON.1)

0 0 Normal mode (default) - no power reduction. 0 1 Idle mode. The Idle mode lea v es peripherals running in order to allow them to activate the

1 0 Power-down mode:

PMOD0 (PCON.0)

Description

processor when an interrupt is generated. Any enabled interrupt source or reset may terminate Idle mode.

The Power-down mode stops the oscillator in order to minimize power consumption. The P89LPC9321 exits Power-down mode via any reset, or certain interrupts - external pins

INT0/INT1, brownout Interrupt, keyboard, Real-time Clock/System Timer), watchdog, and comparator trips. Waking up by reset is only enabled if the corresponding reset is enabled, and waking up by interrupt is only enabled if the corresponding interrupt is enabled and the EA SFR bit (IEN0.7) is set. External interrupts should be programmed to level-triggered mode to be used to exit Power-down mode.

In Power-down mode the internal RC oscillator is disabled unless both the RC oscillator has been selected as the system clock AND the RTC is enabled.

In Power-down mode, the power supply voltage may be reduced to the RAM keep-alive voltage VRAM. This retains the RAM contents at the point where Power-down mode was entered. SFR contents are not guaranteed after V wake-up the processor via Reset in this situation. V before the Power-down mode is exited.

When the processor wakes up from Power-down mode, it will start the oscillator immediately and begin execution when the oscillator is stable. Oscillator stability is determined by counting 1024 CPU clocks after start-up when one of the crystal oscillator configurations is used, or 200ms to 300ms after start-up for the internal RC, or 32 OSCCLK cycles after start-up for external clock input.

Some chip functions continue to operate and draw power during Power-down mode, increasing the total power used during power-down. These include:

has been lowered to VRAM, therefore it is recommended to

must be raised to within the operating range

• Brownout Detect

• Watchdog Timer if WDCLK (WDCON.0) is logic 1.

• Comparators (Note: Comparators can be powered down separately with PCONA.5 set to

logic 1 and comparators disabled);

• Real-time Clock/System Timer (and the crystal oscillator circuitry if this block is using it, unless

RTCPD, i.e., PCONA.7 is logic 1).

1 1 Total Power-down mode: This is the same as Power-down mode except that the Brownout

Detection circuitry and the voltage comparators are also disabled to conserve additional power. Note that a brownout reset or interrupt will not occur. V oltage comparator interrupts and Brownout interrupt cannot be used as a wake-up source. The internal RC oscillator is disabled unless both the RC oscillator has been selected as the system clock AND the RTC is enabled.

The following are the wake-up options supported:

• Watchdog Timer if WDCLK (WDCON.0) is logic 1. Could generate Interrupt or Reset, either

one can wake up the device

• External interrupts INTO/INT1 (when programmed to level-triggered mode).

• Keyboard Interrupt

• Real-time Clock/System Timer (and the crystal oscillator circuitry if this block is using it, unless

RTCPD, i.e., PCONA.7 is logic 1).

Note: Using the internal RC-oscillator to clock the RTC during power-down may result in relatively high power consumption. Lower power consumption can be achieved by using an external lo w frequency clock when the Real-time Clock or watchdog timer is running during power-down.

User manual Rev. 01 — 1 December 2008 35 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 18. Power Control register (PCON - address 87h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol SMOD1 SMOD0 - BOI GF1 GF0 PMOD1 PMOD0 Reset00- 00000

Table 19. Power Control registe r (PCON - address 87h) bit description

Bit Symbol Description

0 PMOD0 Power Reduction Mode (see Section 5.3

) 1PMOD1 2 GF0 General Purpose Flag 0. May be read or written by user software, but has no effect

on operation

3 GF1 General Purpose Flag 1. May be read or written by user software, but has no effect

on operation

4 BOI Brownout Detect Interrupt Enable. When logic 1, Brownout Detection will generate a

interrupt. 5 - Reserved. 6 SMOD0 Framing Error Location:

• When logic 0, bit 7 of SCON is accessed as SM0 for the UART.

• When logic 1, bit 7 of SCON is accessed as the framing error status (FE) for the

UART

7 SMOD1 Double Baud Rate bit for the serial port (UART) when Timer 1 is used as the baud

rate source. When logic 1, the Timer 1 overflow rate is supplied to the UART. When

logic 0, the Timer 1 overflow rate is divided by two before being supplied to the

UART. (See Section 9

)

Table 20. Power Control register A (PCONA - address B5h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol RTCPD DEEPD VCPD - I2PD SPPD SPD CCUPD Reset00000000

Table 21. Power Control register A (PCONA - address B5h) bit description

Bit Symbol Description

0 CCUPD Compare/Capture Unit (CCU) power-down: When logic 1, the internal clock to the

CCU is disabled. Note that in either Power-down mode or Total Power-down mode,

the CCU clock will be disabled regardless of this bit. (Note: This bit is overridden by

the CCUDIS bit in FCFG1. If CCUDIS = 1, CCU is powered down.) 1 SPD Serial Port (UART) power-down: When logic 1, the internal clock to the UART is

disabled. Note that in either Power-down mode or T otal Power-down mode, the

UART clock will be disabled regardless of this bit. 2 SPPD SPI power-down: When logic 1, the internal clock to the SPI is disabled. Note that in

either Power-down mode or T otal Power-down mode, the SPI clock will be disabled

regardless of this bit.

3I2PDI

C power-down: When logic 1, the internal clock to the I2C-bus is disabled. Note

that in either Power-down mode or Total Power-down mode, the I

C clock will be

disabled regardless of this bit. 4 - reserved

User manual Rev. 01 — 1 December 2008 36 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 21. Power Control register A (PCONA - address B5h) bit description

Bit Symbol Description

5 VCPD Analog Voltage Comparators power-down: When logic 1, the voltage comparators

are powered down. User must disable the voltage comparators prior to setting this

bit. 6 DEEPD Data EEPROM power-down: When logic 1, the Data EEPROM is powered down.

Note that in either Power-down mode or Total Power-down mode, the Data

EEPROM will be powered down regardless of this bit. 7 RTCPD Real-time Clock power-down: When logic 1, the internal clock to the Real-time

Clock is disabled.

…continued

6. Reset

The P1.5/RST pin can function as either an active low reset input or as a digital input, P1.5. The RPE (Reset Pin Enable) bit in UCFG1, when set to 1, enables the external reset input function on P1.5. When cleared, P1.5 may be used as an input pin.

Remark: During a power-on sequence, The RPE selection is overridden and this pin will always functions as a reset input. An external circuit connected to this pin should not hold this pin low during a Power-on sequence as this will keep the device in reset. After power-on this input will function either as an external reset input or as a digital input as defined by the RPE bit. Only a power-on reset will temporarily override the selection defined by RPE bit. Other sources of reset will not override the RPE bit.

Note: During a power cycle, V Static characteristics) before power is reapplied, in order to ensure a power-on reset.

Reset can be triggered from the following sources:

must fall below V

(see P89LPC9321 data sheet,

POR

• External reset pin (during power-on or if user configured via UCFG1) ;

• Power-on detect;

• Brownout detect;

• Watchdog timer;

• Software reset;

• UART break character detect reset.

For every reset source, there is a flag in the Reset Register, RSTSRC. The user can read this register to determine the most recent reset source. These flag bits can be cleared in software by writing a ‘0’ to the corresponding bit. More than one flag bit may be set:

• During a power-on reset, both POF and BOF ar e set but the ot he r fla g bits are

cleared.

• A watchdog reset is similar to a power-on reset, both POF and BOF are set but the

other flag bits are cleared.

• For any other reset, previously set flag bits that have not been cleared will remain set.

User manual Rev. 01 — 1 December 2008 37 of 139

NXP Semiconductors

RPE (UCFG1.6)

RST pin

WDTE (UCFG1.7)

watchdog timer reset

software reset SRST (AUXR1.3)

power-on detect

UART break detect

EBRR (AUXR1.6)

brownout detect reset

chip reset

002aae129

Fig 14. Block diagram of reset

UM10310

P89LPC9321 User manual

Table 22. Reset Sources reg ister (RSTSRC - address DFh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol - BOIF BOF POF R_BK R_WD R_SF R_EX

[1]

Reset

[1] The value shown is for a power-on reset. Other reset sources will set their corresponding bits.

Table 23. Reset Sources register (RSTSRC - address DFh) bit description

Bit Symbol Description

0 R_EX external reset Flag. When this bit is logic 1, it indicates external pin reset. Cleared by software by writing a

1 R_SF software reset Flag. Cleared by software by writing a logic 0 to the bit or a Power-on reset 2 R_WD Watchdog Timer reset flag. Cleared by software by writing a logic 0 to the bit or a Power-on reset.(NOTE:

3 R_BK break detect reset. If a break detect occurs and EBRR (AUXR1.6) is set to logic 1, a system reset will occur.

4 POF Power-on Detect Flag. When Power-on Detect is activated, the POF flag is set to indicate an initial power-up

5 BOF BOD Reset Flag. When BOD Reset is activated, this bit is set. It will remain set until cleared by software by

6 BOIF BOD Interrupt Flag. When BOD Interrupt is activated, this bit is set. It will remain set until cleared by software

7 - reserved

User manual Rev. 01 — 1 December 2008 38 of 139

x0110000

logic 0 to the bit or a Power-on reset. If RST

is still asserted after the Power-on reset is over, R_EX will be set.

UCFG1.7 must be = 1)

This bit is set to indicate that the system reset is caused by a break detect. Cleared by software by writing a logic 0 to the bit or on a Power-on reset.

condition. The POF flag will remain set until cleared by software by writing a logic 0 to the bit. (Note: On a Power-on reset, both BOF and this bit will be set while the other flag bits are cleared.)

writing a logic 0 to the bit. (Note: On a Power-on reset, both POF and this bit will be set while the other flag bits are cleared.)

by writing a logic 0 to the bit.

6.1 Reset vector

Following reset, the P89LPC9321 will fetch instructions from either address 0000h or the Boot address. The Boot address is formed by us ing the Boot V ector as the high byte of the address and the low byte of the address = 00h. The Boot address will be used if a UART

NXP Semiconductors

break reset occurs or the non-volatile Boot Status bit (BOOTSTAT.0) = 1, or the device has been forced into ISP mode. Otherwise, instructions will be fetched from address 0000H.

7. Timers 0 and 1

The P89LPC9321 has two general-purpose counter/timers which are upward compatible with the 80C51 Timer 0 and T ime r 1. Both can be configured to ope rate either as timers or event counters (see Table 25 overflow has been added.

In the ‘Timer’ function, the timer is incremented every PCLK. In the ‘Counter’ function, the register is incremented in response to a 1-to-0 transition on

its corresponding external input pin (T0 or T1). The external input is samp led o nce during every machine cycle. When the pin is high during one cycle and low in the next cycle, the count is incremented. The new count value appears in the register during the cycle following the one in which the transition was detected. Since it takes two machine cycles (four CPU clocks) to recognize a 1-to-0 transition, the maximum count rate is CPU clock frequency. There are no restrictions on the duty cycle of the external input signal, but to ensure that a given level is sampled at least once before it changes, it should be held for at least one full machine cycle.

UM10310

P89LPC9321 User manual

). An option to automatically toggle the Tx pin upon timer

⁄

of the

The ‘Timer’ or ‘Counter’ function is selected by control bits TnC/T

(x = 0 and 1 for Timers 0 and 1 respectively) in the Special Function Register TMOD. T imer 0 and Timer 1 have five operating modes (modes 0, 1, 2, 3 and 6), which are selected by bit-pa irs (TnM1, TnM0) in TMOD and TnM2 in TAMOD. Modes 0, 1, 2 and 6 are the same for both Timers/Counters. Mode 3 is different. The operating modes are described later in this section.

Table 24. Timer/Counter Mode register (TMOD - address 89h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol T1GATE T1C/T Reset00000000

Table 25. Timer/Counter Mode register (TMOD - address 89h) bit description

Bit Symbol Description

0 T0M0 Mode Select for Timer 0. These bits are used with the T0M2 bit in the TAMOD register to determine the 1T0M1 2T0C/T

3 T0GATE Gating control for Timer 0. When set, Timer/Counter is enabled only while the INT0

4 T1M0 Mode Select for Timer 1. These bits are used with the T1M2 bit in the TAMOD register to determine the 5T1M1 6T1C/T

7 T1GATE Gating control for Timer 1. When set, Timer/Counter is enabled only while the INT1

Timer 0 mode (see Table 27 Timer or Counter selector for Timer 0. Cleared for Timer operation (input from CCLK). Set for Counter

operation (input from T0 input pin).

control pin is set. When cleared, Timer 0 is enabled when the TR0 control bit is set.

Timer 1 mode (see Table 27 Timer or Counter Selector for Timer 1. Cleared for Timer operation (input from CCLK). Set for Counter

operation (input from T1 input pin).

control pin is set. When cleared, Timer 1 is enabled when the TR1 control bit is set.

T1M1 T1M0 T0GA TE T0C/T T0M1 T0M0

pin is high and the TR0

pin is high and the TR1

User manual Rev. 01 — 1 December 2008 39 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 26. Timer/Counter Auxiliary Mode register (TAMOD - address 8Fh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol----T1M2---T0M2 Resetxxx0xxx0

Table 27. Timer/Counter Auxiliary Mode register (TAMOD - address 8Fh) bit description

Bit Symbol Description

0 T0M2 Mode Select for Timer 0. These bits are used with the T0M2 bit in the TAMOD register to determine the

Timer 0 mode (see Table 27 1:3 - reserved 4 T1M2 Mode Select for Timer 1. These bits are used with the T1M2 bit in the TAMOD register to determine the

Timer 1 mode (see Table 27

The following timer modes are selected by timer mode bits TnM[2:0]:

000 — 8048 Timer ‘TLn’ serves as 5-bit prescaler. (Mode 0)

001 — 16-bit Timer/Counter ‘THn’ and ‘TLn’ are cascaded; there is no prescaler.(Mode 1)

010 — 8-bit auto-reload Timer/Counter. THn holds a value which is loaded into TLn when it overflows.

(Mode 2)

011 — Timer 0 is a dual 8-bit Timer/Counter in this mode. TL0 is an 8-bit Timer/Counter controlled by the

standard Timer 0 control bits. TH0 is an 8-bit timer only, controlled by the Timer 1 control bits (see text).

Timer 1 in this mode is stopped. (Mode 3)

100 — Reserved. User must not configure to this mode.

101 — Reserved. User must not configure to this mode.

110 — PWM mode (see Section 7.5

111 — Reserved. User must not configure to this mode.

5:7 - reserved

7.1 Mode 0

Putting either Timer into Mode 0 makes it look like an 8048 Timer, which is an 8-bit Counter with a divide-by-32 prescaler. Figure 15

shows Mode 0 operation.

In this mode, the Timer register is configured as a 13-bit register. As the count rolls over from all 1s to all 0s, it sets the Timer interrupt flag TFn. The count input is enabled to the Timer when TRn = 1 and either TnGATE = 0 or INTn Timer to be controlled by external input INTn

, to facilitate pulse width measurements).

TRn is a control bit in the Special Function Register TCON (Table 29

= 1. (Setting TnGATE = 1 allows the

). The TnGATE bit is

in the TMOD register. The 13-bit register consists of all 8 bits of THn and the lower 5 bits of TLn. The upper 3

bits of TLn are indeterminate and should be ignored . Setting the run flag (TRn) does not clear the registers.

Mode 0 operation is the same for Timer 0 and Timer 1. See Figure 15

. There are two

different GATE bits, one for Timer 1 (TMOD.7) and one for Timer 0 (TMOD.3).

7.2 Mode 1

Mode 1 is the same as Mode 0, except that all 16 bits of the timer register (THn and TLn) are used. See Figure 16

User manual Rev. 01 — 1 December 2008 40 of 139

NXP Semiconductors

7.3 Mode 2

Mode 2 configures the Timer re gister as an 8-bit Counter (TLn) with automatic reload, as shown in Figure 17 contents of THn, which must be preset by software. The reload leaves THn unchanged. Mode 2 operation is the same for Timer 0 and Timer 1.

7.4 Mode 3

When Timer 1 is in Mode 3 it is stopped. The effect is the same as setting TR1 = 0. Timer 0 in Mode 3 establishes TL0 and TH0 as two separate 8-bit counters. The logic for

Mode 3 on Timer 0 is shown in Figure 18 T0GATE, TR0, INT0 cycles) and takes over the use of TR1 and TF1 from Timer 1. Thus, TH0 now controls the ‘Timer 1’ interrupt.

Mode 3 is provided for applications that require an extra 8-bit timer. With Timer 0 in Mode 3, an P89LPC9321 device can look like it has three Timer/Counters.

Note: When Timer 0 is in Mode 3, Timer 1 can be turned on and off by switching it into and out of its own Mode 3. It can still be used by the serial port as a baud rate generator, or in any application not requiring an interrupt.

UM10310

P89LPC9321 User manual

. Overflow from TLn not only sets TFn, but also reloads TLn with the

. TL0 uses the Timer 0 control bits: T0C/T,

, and TF0. TH0 is locked into a timer function (counting machine

7.5 Mode 6

In this mode, the corresponding timer can be changed to a PWM with a full period of 256 timer clocks (see Figure 19

). Its structure is similar to mode 2, except that:

• TFn (n = 0 and 1 for Timers 0 and 1 respectively) is set and cleared in hardware;

• The low period of the TFn is in THn, and should be between 1 and 254, and;

• The high period of the TFn is always 256−THn.

• Loading THn with 00h will force the Tx pin high, loading THn with FFh will force the Tx

pin low.

Note that interrupt can still be enabled on the low to high transition of TFn, and that TFn can still be cleared in software like in any other modes.

Table 28. Timer/Counter Control register (TCON) - address 88h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol TF1 TR1 TF0 TR0 IE1 IT1 IE0 IT0 Reset00000000

Table 29. Timer/Counter Control register (TCON - addres s 88h) bit description

Bit Symbol Description

0 IT0 Interrupt 0 Type control bit. Set/cleared by software to specify falling edge/low level triggered external

interrupts. 1 IE0 Interrupt 0 Edge flag. Set by hardware when external interrupt 0 edge is detected. Cleared by hardware

when the interrupt is processed, or by software. 2 IT1 Interrupt 1 Type control bit. Set/cleared by software to specify falling edge/low level triggered external

interrupts.

User manual Rev. 01 — 1 December 2008 41 of 139

NXP Semiconductors

002aaa919

PCLK

Tn pin

TRn

Gate

INTn pin

C/T = 0

C/T = 1

TLn

(5-bits)

THn

(8-bits)

TFn

control

ENTn

Tn pin

toggle

overflow

interrupt

002aaa920

PCLK

Tn pin

TRn

Gate

INTn pin

C/T = 0

C/T = 1

TLn

(8-bits)

THn

(8-bits)

TFn

control

ENTn

Tn pin

toggle

overflow

interrupt

002aaa921

PCLK

Tn pin

TRn

Gate

INTn pin

C/T = 0

C/T = 1

TLn

(8-bits)

THn

(8-bits)

TFn

control

ENTn

Tn pin

toggle

overflow

interrupt

reload

UM10310

P89LPC9321 User manual

Table 29. Timer/Counter Control register (TCON - addres s 88h) bit description

…continued

Bit Symbol Description

3 IE1 Interrupt 1 Edge flag. Set by hardware when external interrupt 1 edge is detected. Cleared by hardware

when the interrupt is processed, or by software. 4 TR0 Timer 0 Run control bit. Set/cleared by software to turn Timer/Counter 0 on/off. 5 TF0 Timer 0 overflow flag. Set by hardware on Timer/Counter overflow. Cleared by hardware when the

processor vectors to the interrupt routin e, or by sof tw are. (except in mode 6, where it is cleared in hardware) 6 TR1 Timer 1 Run control bit. Set/cleared by software to turn Timer/Counter 1 on/off 7 TF1 Timer 1 overflow flag. Set by hardware on Timer/Counter overflow. Cleared by hardware when the interrupt

is processed, or by software (except in mode 6, see above, when it is cleared in hardware).

Fig 15. Timer/counter 0 or 1 in Mode 0 (13-bit counter).

Fig 16. Timer/counter 0 or 1 in mode 1 (16-bit counter).

Fig 17. Timer/counter 0 or 1 in Mode 2 (8-bit auto-reload).

User manual Rev. 01 — 1 December 2008 42 of 139

NXP Semiconductors

002aaa922

PCLK

Osc/2

T0 pin

TR0

TR1

Gate

INT0 pin

C/T = 0

C/T = 1

TL0

(8-bits)

TF0

control

ENT0

(AUXR1.4)

T0 pin

(P1.2 open drain)

toggle

overflow

interrupt

TH0

(8-bits)

TF1

control

ENT1

(AUXR1.5)

T1 pin (P0.7)

toggle

overflow

interrupt

002aaa923

PCLK

TRn

Gate

INTn pin

C/T = 0

TLn

(8-bits)

THn

(8-bits)

TFn

control

ENTn

Tn pin

toggle

overflow

interrupt

reload THn on falling transition

and (256-THn) on rising transition

Fig 18. Timer/counter 0 Mode 3 (two 8-bit counters).

UM10310

P89LPC9321 User manual

Fig 19. Timer/counter 0 or 1 in mode 6 (PWM auto-reload).

7.6 Timer overflow toggle output

Timers 0 and 1 can be configured to automatically toggle a port output whenever a timer overflow occurs. The same device pins that are used for the T0 and T1 count inputs and PWM outputs are also used for the timer toggle outputs. This function is enabled by control bits ENT0 and ENT1 in the AUXR1 register, and apply to Timer 0 and Timer 1

8. Real-time clock system timer

User manual Rev. 01 — 1 December 2008 43 of 139

respectively. The port outputs will be a logic 1 prior to the first timer overflow when this mode is turned on. In order for this mode to functio n, the C/T bit must be cleared selecting PCLK as the clock source for the timer.

The P89LPC9321 has a simple Real-time Clock/System Timer that allo ws a user to continue running an accurate timer while the rest of the device is powered down. The Real-time Clock can be an interrupt or a wake-up source (see Figure 20

NXP Semiconductors

RTCH RTCL

RTCDATH RTCDATL

RTC Reset

Power-on

reset

Reload on underflow

MSB LSB

÷128

23-bit down counter

Wake-up from power-down

Interrupt if enabled (shared with WDT)

002aae091

ERTC

RTCF

RTC underflow flag

RTCEN

RTC enable

7-bit prescaler

RTCS1 RTCS2

RTC clk select

CCLK

internal

oscillators

LOW FREQ. MED. FREQ. HIGH FREQ.

XTAL2 XTAL1

The Real-time Clock is a 23-bit down counter. The clock source for this counter can be either the CPU clock (CCLK) or the XTAL1-2 oscillator. There are five SFRs used for the RTC:

RTCCON — Real-time Clock control. RTCH — Real-time Clock counter reload high (bits 22 to 15). RTCL — Real-time Clock counter reload low (bits 14 to 7). RTCDATH — Real-time clock data register high. RTCDATL — Real-time Clock data register low.

The Real-time clock system timer can be enabled by settin g th e R TCEN (RTCCON.0) bit. The Real-time Clock is a 23-bit down counter (initialized to all 0’ s when R TCEN = 0) that is comprised of a 7-bit prescaler and a 16-bit loadable down counter. When RTCEN is written with logic 1, the counter is first loaded with (RTCH, RTCL, ‘1 111111’) and will count down. When it reaches all 0’s, the counter will be reloaded again with (RTCH, RTCL, ‘11 11111’) and a flag - RTCF (RTCCON.7) - will be set.

The 16-bit counter portion of the RTC is readable by reading the RTCDATH and RTCDATL registers.

UM10310

P89LPC9321 User manual

Fig 20. Real-time clock/system timer block diagram.

User manual Rev. 01 — 1 December 2008 44 of 139

8.1 Real-time clock source

RTCS1/RTCS0 (RTCCON[6:5]) are used to select the clock source for the RTC if either the Internal RC oscillator or the internal WD oscillator is used as the CPU clock. If the internal crystal oscillator or the external clock input on XTAL1 is used as the CPU clock, then the RTC will use CCLK as its clock source.

NXP Semiconductors

8.2 Changing RTCS1/RTCS0

RTCS1/RTCS0 cannot be changed if the RTC is currently enabled (RTCCON.0 = 1). Setting RTCEN and updating RTCS1/RTCS0 may be done in a single write to RTCCON. However, if RTCEN = 1, this bit must first be cleared before updating RTCS1/RTCS0.

8.3 Real-time clock interrupt/wake-up

If ERTC (RTCCON.1), EWDRT (IEN1.0.6) and EA (IEN0.7) are set to logic 1, RTCF can be used as an interrupt source. This interrupt vector is shared with the watchdog timer. It can also be a source to wake-up the device.

8.3.1 Real-time clock read back

Users can read RTCDATH and RTCDATL registers and get the 16-bit counter portion of the RTC.

8.4 Reset sources affecting the Real-time clock

Only power-on reset and watchdog reset will reset the Real-time Clock and its associated SFRs to their default state.

Table 30. Real-time Clock/System Timer clock sources

FOSC2:0 RCCLK RTCS1:0 RTC clock source CPU clock source

000 0 00 High frequency crystal High frequency crystal

001 0 00 Medium frequency crystal Medium frequency crystal

UM10310

P89LPC9321 User manual

01 10 11 High frequency crystal

/DIVM

1 00 High frequency crystal Internal RC oscillator

01 10 11 Internal RC oscillator

01 10 11 Medium frequency crystal

/DIVM

1 00 Medium frequency crystal Internal RC oscillator

01 10 11 Internal RC oscillator

/DIVM

User manual Rev. 01 — 1 December 2008 45 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 30. Real-time Clock/System Timer clock sources

FOSC2:0 RCCLK RTCS1:0 RTC clock source CPU clock source

010 0 00 Low frequency crystal Low frequency crystal

01 10 11 Low frequency crystal

/DIV

1 00 Low frequency crystal Internal RC oscillator

01 10 11 Internal RC oscillator

011 0 00 High frequency crystal Internal RC oscillator

01 Medium frequency crystal 10 Low frequency crystal 11 Internal RC oscillator

/DIVM

1 00 High frequency crystal Internal RC oscillator

01 Medium frequency crystal 10 Low frequency crystal 11 Internal RC oscillator

100 0 00 High frequency crystal Watchdog oscillator

01 Medium frequency crystal 10 Low frequency crystal 11 Watchdog oscillator /DIVM

1 00 High frequency crystal Internal RC oscillator

01 Medium frequency crystal 10 Low frequency crystal

11 Internal RC oscillator 101 x xx undefined undefined 1 10 x xx undefined undefined 111 0 00 External clock input External clock input

11 External clock input /DIVM

1 00 External clock input Internal RC oscillator

11 Internal RC oscillator

…continued

/DIVM

Table 31. Real-time Clock Control register (RTCCON - address D1h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol RTCF RTCS1 RTCS0 - - - ERTC RTCEN Reset011xxx00

User manual Rev. 01 — 1 December 2008 46 of 139

NXP Semiconductors

Table 32. Real-time Clock Control register (RTCCON - address D1h) bit description

Bit Symbol Description

0 RTCEN Real-time Clock enable. The Real-time Clock will be enabled if this bit is logic 1.

Note that this bit will not power-down the Real-time Clock. The RTCPD bit (PCONA.7) if set, will power-down and disable this block regardless of RTCEN.

1 ERTC Real-time Clock interrupt enable. The Real-time Clock shares the same

interrupt as the watchdog timer. Note that if the user configuration bit WDTE (UCFG1.7) is logic 0, the watchdog timer can be enabled to generate an interrupt. Users can read the RTCF (RTCCON.7) bit to determine whether the

Real-time Clock caused the interrupt. 2:4 - reserved 5 RTCS0 Real-time Clock source select (see Table 30 6RTCS1 7 RTCF Real-time Clock Flag. This bit is set to logic 1 when the 23-bit Real-time Clock

reaches a count of logic 0. It can be cleared in software.

9. Capture/Compare Unit (CCU)

UM10310

P89LPC9321 User manual

This unit features:

• A 16-bit timer with 16-bit reload on overflow

• Selectable clock (CCUCLK), with a prescaler to divide the clock source by any integer

between 1 and 1024.

• Four Compare / PWM outputs with selectable polarity

• Symmetrical / Asymmetrical PWM selection

• Seven interrupts with common interrupt vector (one Overflow, 2xCapture,

4xCompare), safe 16-bit read/write via shadow registers.

• Two Capture inputs with event counter and digital noise rejection filter.

9.1 CCU Clock (CCUCLK)

The CCU runs on the CCUCLK, which can be either PCLK in basic timer mode or the output of a PLL (see Figure 21

0.5 MHz to 1 MHz that is multiplied by 32 to produce a CCUCLK between 16 MHz and 32 MHz in PWM mode (asymmetrical or symmetrical). The PLL contains a 4-bit divider (PLLDV3:0 bits in the TCR21 register) to help divide PCLK into a frequency between

0.5 MHz and 1 MHz.

). The PLL is designed to use a clock source between

9.2 CCU Clock prescaling

This CCUCLK can further be divided down by a prescaler. The prescaler is implemented as a 10-bit free-running counter with programmable relo ad at overflow. Writing a value to the prescaler will cause the prescaler to restart.

User manual Rev. 01 — 1 December 2008 47 of 139

NXP Semiconductors

16-BIT SHADOW REGISTER

TOR2H TO TOR2L

16-BIT SHADOW REGISTER

OCRxH TO OCRxL

16-BIT CAPTURE

INTERRUPT FLAG

TICF2x SET

EVENT

COUNTER

NOISE

FILTER

ICNFx

EDGE

SELECT

ICESx

16-BIT COMPARE

VALUE

TIMER > COMPARE

16-BIT TIMER RELOAD

16-BIT UP/DOWN TIMER

WITH RELOAD

FCOx

OCA

ICA

ICB

OCB

OVERFLOW/

UNDERFLOW

OCC

OCD

COMPARE CHANNELS A TO D

CAPTURE CHANNELS A, B

002aab009

10-BIT DIVIDER

32 × PLL

4-BIT

DIVIDER

UM10310

P89LPC9321 User manual

Fig 21. Capture Compare Unit block diagram.

User manual Rev. 01 — 1 December 2008 48 of 139

9.3 Basic timer operation

The Timer is a free-running up/down counter counting at the pace determined by th e prescaler. The timer is started by setting the CCU Mode Select bits TMOD21 and TMOD20 in the CCU Control Register 0 (TCR20) as shown in the table in the TCR20 register description (Table 37

The CCU direction control bit, TDIR2, determines the direction of the count. TDIR2 = 0: Count up, TDIR2 = 1: Count down. If the timer counting direction is changed while the counter is running, the count sequence will be reversed in the CCUCLK cycle following the write of TDIR2. The timer can be written or read at any time and newly-written values will take effect when the prescaler overflows. The timer is accessible through two SFRs, TL2(low byte) and TH2(high byte). A third 16-bit SFR, TOR2H:TOR2L, determines the overflow reload value. TL2, TH2 and TOR2H, TOR2L will be 0 after a reset

Up-counting: When the timer contents are FFFFH, the next CCUCLK cycle will set the counter value to the contents of TOR2H:TOR2L.

Down-counting: When the timer contents are 0000H, the next CCUCLK cycle will set the counter value to the contents of TOR2H:TOR2L. During the CCUCLK cycle when the reload is performed, the CCU Timer Overflow Interrupt Flag (TOIF2) in the CCU Interrupt Flag Register (TIFR2) will be set, and, if the EA bit in the IEN0 register and ECCU bit in the IEN1 register (IEN1.4) are set, program execution will vector to the overflow interrupt. The user has to clear the interrupt flag in software by writing a logic 0 to it.

When writing to the reload registers, TOR2H and TOR2L, the values written are stored in two 8-bit shadow registers. In order to latch the contents of the shadow registers into TOR2H and TOR2L, the user must write a logic 1 to the CCU Timer Compare/Overflow Update bit TCOU2, in CCU Timer Control Register 1 (TCR21). The function of this bit

NXP Semiconductors

depends on whether the timer is running in PWM mode or in basic timer mode. In basic timer mode, writing a one to TCOU2 will cause the values to be latched immediately and the value of TCOU2 will always read as zero. In PWM mode, writing a one to TCOU2 will cause the contents of the shadow registers to be updated on the next CCU Timer overflow. As long as the latch is pending, TCOU2 will read as one and will return to zero when the latching takes place. TCOU2 also controls the latching of the Output Compare registers OCR2A, OCR2B and OCR2C.

When writing to timer high byte, TH2, the value written is stored in a shadow register. When TL2 is written, the contents of TH2’s shadow register is transferred to TH2 at the same time that TL2 gets updated. Thus, TH2 should be written prior to writing to TL2. If a write to TL2 is followed by another write to TL2, without TH2 being written in between, the value of TH2 will be transferred directly to the high byte of the timer.

If the 16-bit CCU Timer is to be used as an 8-bit timer, the user can write FFh (for upcounting) or 00h (for downcounting) to TH2. When TL2 is written, FFh:TH2 (for upcounting) and 00h (for downcounting) will be loaded to CCU Timer. The user will not need to rewrite TH2 again for an 8-bit timer operation unless there is a change in count direction

UM10310

P89LPC9321 User manual

When reading the timer, TL2 must be read first. When TL2 is read, the contents of the timer high byte are transferred to a shad ow register in th e same PCLK cycle as the read is performed. When TH2 is read, the contents of the shadow register are read instead. If a read from TL2 is followed by another read from TL2 without TH2 being read in between, the high byte of the timer will be transferred directly to TH2.

Table 33. CCU prescaler contr ol register, high byte (TPCR2H - address CBh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol------TPCR2H.1TPCR2H.0 Resetxxxxxx00

Table 34. CCU prescaler contr ol register, high byte (TPCR2H - address CBh) bit description

Bit Symbol Description

0 TPCR2H.0 Prescaler bit 8 1 TPCR2H.1 Prescaler bit 9

Table 35. CCU prescaler contr ol registe r, low byte (TPCR2L - address CAh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol TPCR2L.7 TPCR2L.6 TPCR2L.5 TPCR2L.4 TPCR2L.3 TPCR2L.2 TPCR2L.1 TPCR2L.0 Reset00000000

Table 36. CCU prescaler control register, low byte (TPCR2L - address CAh) bit description

Bit Symbol Description

0 TPCR2L.0 Prescaler bit 0 1 TPCR2L.1 Prescaler bit 1 2 TPCR2L.2 Prescaler bit 2 3 TPCR2L.3 Prescaler bit 3 4 TPCR2L.4 Prescaler bit 4

User manual Rev. 01 — 1 December 2008 49 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 36. CCU prescaler control register, low byte (TPCR2L - address CAh) bit description

Bit Symbol Description

5 TPCR2L.5 Prescaler bit 5 6 TPCR2L.6 Prescaler bit 6 7 TPCR2L.7 Prescaler bit 7

Table 37. CCU control register 0 (TCR20 - address C8h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol PLLEN HLTRN HLTEN ALTCD ALTAB TDIR2 TMOD21 TMOD20 Reset00000000

Table 38. CCU control register 0 (TCR20 - address C8h) bit description

Bit Symbol Description

1:2 TMOD20/21 CCU Timer mode (TMOD21, TMO D 20 ):

2 TDIR2 Count direction of the CCU Timer. When logic 0, count up, When logic 1, count down. 3 ALTAB PWM channel A/B alternately output enable. When this bit is set, the output of PWM channel A and B

4 ALTCD PWM channel C/D alternately output enable. When this bit is set, the output of PWM channel C and D

5 HLTEN PWM Ha lt Enable. When logic 1, a capture event as enabled for Input Capture A pin will immediately

6 HLTRN PWM Halt. When set indicates a halt took place. In order to re-activate the PWM, the user must clear

7 PLLEN Phase Locked Loop Enable. When set to logic 1, starts PLL operation. After the PLL is in lock this bit it

00 — Timer is stopped 01 — Basic timer function 10 — Asymmetrical PWM (uses PLL as clock source) 11 — Symmetrical PWM (uses PLL as clock source)

are alternately gated on every counter cycle.

stop all activity on the PWM pins and set them to a predetermined state.

the HLTRN bit.

will read back a one.

9.4 Output compare

The four output compare channels A, B, C and D are contr olled thro ugh four 16- bit SFRs, OCRAH:OCRAL, OCRBH:OCRBL, OCRCH:OCRCL, OCRDH: OCRDL. Each output compare channel needs to be enabled in order to operate. The channel is enabled by selecting a Compare Output Action by setting the OCMx1:0 bits in the Capture Compare x Control Register - CCCRx (x = A, B, C, D). When a compare channel is enabled, the user will have to set the associated I/O pin to the desired output mode to connect the pin. (Note: The SFR bits for port pins P2.6, P1.6, P1.7, P2.1 must be set to logic 1 in order for the compare channel outputs to be visible at the port pins.) When the contents of TH2:TL2 match that of OCRxH:OCRxL, the Timer Output Compar e Interrupt Flag - T OCFx is set in TIFR2. This happens in the CCUCLK cycle after the compare takes place. If EA and the Timer Output Compare Interrupt Enable bit - TOCIE2x (in TICR2 register), as well as ECCU bit in IEN1 are all set, the program counter will be vectored to the corresponding interrupt. The user must manually clear the bit by writing a logic 0 to it.

Two bits in OCCRx, the Output Compare x Mode bits OCMx1 and OCMx0 select what action is taken when a compare match occurs. Enable d compare actions take place even if the interrupt is disabled.

User manual Rev. 01 — 1 December 2008 50 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

In order for a Compare Output Action to occur, the compare values must be within the counting range of the CCU timer.

When the compare channel is enabled, the I/O pin (which must be configured as an output) will be connected to an internal latch controlled by the com pare log ic. The value of this latch is zero from reset and can be changed by invoking a forced compare. A forced compare is generated by writing a logic 1 to the Force Compare x Output bi t - FCOx bi t in OCCRx. Writing a one to this bit generates a transition o n the corresponding I/O pin as set up by OCMx1/OCMx0 without causing an interrupt. In basic timer operating mode the FCOx bits always read zero. (Note: This bit has a different function in PWM mode.) When an output compare pin is enabled and connected to the compar e latch, the state of the compare pin remains unchanged until a compare event or forced compare occurs.

Table 39. Capture compare control register (CCRx - address Exh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol ICECx2 ICECx1 ICECx0 ICESx ICNFx FCOx OCMx1 OCMx0 Reset00000000

Table 40. Capture compare control register (CCRx - address Exh) bit description

Bit Symbol Description

0 OCMx0 Output Compare x Mode. See Table 42 “ 1OCMx1 2 FCOx Force Compare X Output Bit. When set, invoke a force compare. 3 ICNFx Input Capture x Noise Filter Enable Bit. When logic 1, the capture logic needs to see four consecutive

4 ICESx Input Capture x Edge Select Bit. When logic 0: Negative edge triggers a capture, When logic 1: Positive

5 ICECx0 Capture Delay Setting Bit 0. See Table 41 6 ICECx1 Capture Delay Setting Bit 1. See Table 41 7 ICECx2 Capture Delay Setting Bit 2. See Table 41

Output compare pin behavior.”

samples of the same value in order to recognize an edge as a capture event. The inputs are sampled every two CCLK periods regardless of the speed of the timer.

edge triggers a capture.

for details. for details. for details.

When the user writes to change the output compare value, the values written to OCRH2x and OCRL2x are transferred to two 8-bit shadow registers. In order to latch the contents of the shadow registers into the capture compare register, the user must write a logic 1 to the CCU Timer Compare/Overflow Update bit TCOU2, in the CCU Control Register 1 TCR21. The function of this bit depends on whether the timer is running in PWM mode or in basic timer mode. In basic timer mode, writing a one to TCOU2 will cause the values to be latched immediately and the value of TCOU2 will always read as zero. In PWM mode, writing a one to TCOU2 will cause the contents of the shadow registers to be updated on the next CCU Timer overflow . As long as the latch is pending, TCOU2 will read as one and will return to zero when the latch takes place. TCOU2 also controls the latching of all the Output Compare registers as well as the Timer Overflow Reload registers - TOR2.

9.5 Input capture

Input capture is always enabled. Each time a capture event o ccurs on one of the two inpu t capture pins, the contents of the timer is transferred to the corresponding 16-bit input capture register ICRAH:ICRAL or ICRBH:ICRBL. The capture event is defined by the

User manual Rev. 01 — 1 December 2008 51 of 139

NXP Semiconductors

Input Capture Edge Select - ICESx bit (x being A or B) in the CCCRx register. The user will have to configure the associated I/O pin as an input in order for an external event to trigger a capture.

A simple noise filter can be enabled on the input capture input. When the Input Capture Noise Filter ICNFx bit is set, the capture logic needs to see four consecutive samples of the same value in order to recognize an edge as a capture event. The input s are sampled every two CCLK periods regardless of the speed of the timer.

An event counter can be set to delay a capture by a number of capture events. The three bits ICECx2, ICECx1 and ICECx0 in the CCCRx register determine the number of edges the capture logic has to see before an input capture occurs.

When a capture event is detected, the Timer Input Capture x (x is A or B) Interrupt Flag TICF2x (TIFR2.1 or TIFR2.0) is set. If EA and the Timer Input Capture x Enable bit TICIE2x (TICR2.1 or TICR2.0) is set as well as the ECCU (IEN1.4) bit is set, the program counter will be vectored to the corresponding interrupt. The interrupt flag must be cleared manually by writing a logic 0 to it.

When reading the input capture register, ICRxL must be read first. When ICRxL is read, the contents of the capture register high byte are transferred to a shadow register. When ICRxH is read, the contents of the shadow register are read inste ad. (If a read from ICRxL is followed by another read from ICRxL without ICRxH being read in between, the new value of the capture register high byte (from the last ICRxL read) will be in the shadow register).

Table 41. Event delay counter for input ca pture

ICECx2 ICECx1 ICECx0 Delay (numbers of edges)

0000 0011 0102 0113 1004 1015 1107 11115

UM10310

P89LPC9321 User manual

9.6 PWM operation

PWM Operation has two main modes, asymmetrical and symmetrical. These modes of timer operation are selected by writing 10H or 11H to TMOD21:TMOD20 as shown in

Section 9.3 “

In asymmetrical PWM operation, the CCU Timer operates in do wncounting mode regardless of the setting of TDIR2. In this case, TDIR2 will always read 1.

In symmetrical mode, the timer counts up/down alternately an d the value of TDIR2 has no effect. The main difference from basic timer operation is the operation of the compare module, which in PWM mode is used for PWM waveform generation. Table 42 behavior of the compare pins in PWM mode.

User manual Rev. 01 — 1 December 2008 52 of 139

Basic timer operation”.

shows the

NXP Semiconductors

TOR2

compare value

timer value

non-inverted

inverted

0x0000

002aaa893

TOR2

compare value

timer value

non-inverted

inverted

002aaa894

The user will have to configure the output compare pins as outputs in order to enable the PWM output. As with basic timer operation, when the PWM (compare) p ins are connecte d to the compare logic, their logic state remains unchanged. However, since the bit FCO is used to hold the halt value, only a compare event can change the state of the pin.

Fig 22. Asymmetrical PWM, downcounting.

UM10310

P89LPC9321 User manual

Fig 23. Symmetrical PWM.

The CCU Timer Overflow interrupt flag is set when the counter changes direction at the top. For example, if TOR contains 01FFH, CCU Timer will count: ‚Ä¶01FEH, 01FFH, 01FEH,‚Ä¶ The flag is set in the counter cycle after the change from TOR to TOR-1.

When the timer changes direction at the bottom, in this example, it counts ‚Ä¶,0001H, 0000H, 0001H,‚Ä¶ The CCU Timer overflow interrupt flag is set in the counter CCUCLK cycle after the transition from 0001H to 0000H.

The status of the TDIR2 bit in TCR20 reflects the current counting direction. Writing to this bit while operating in symmetrical mode has no effect.

9.7 Alternating output mode

In asymmetrical mode, the user can program PWM channels A/B and C/D as alternating pairs for bridge drive control. By setting ALTAB or ALTCD bits in TCR20, the output of

User manual Rev. 01 — 1 December 2008 53 of 139

these PWM channels are alternately gated on every counter cycle. This is shown in the following figure:

NXP Semiconductors

TIMER VALUE

002aaa895

TOR2

COMPARE VALUE A (or C)

COMPARE VALUE B (or D)

PWM OUTPUT A (or C) (P2.6)

PWM OUTPUT B (or D) (P1.6)

Fig 24. Alternate output mode.

T able 42. Output compare pin behavior.

OCMx1

0 0 Output compare disabled. On power-on, this is the default state, and pins

0 1 Set when compare in

1 0 invalid configuration 1 1 Toggles on compare

[1]

OCMx0

UM10310

P89LPC9321 User manual

[1]

Output Compare pin behavior Basic timer mode Asy mmetrical PWM Symmetrical PWM

are configured as inputs.

operation. Cleared on compare match.

[2]

match

[2]

Non-Inverted PWM. Set on compare match. Cleared on CCU Timer underflow.

Inverted PWM. Cleared on compare match. Set on CCU Timer underflow.

[2]

Non-Inverted PWM. Cleared on compare match, upcounting. Set on compare match, downcounting.

Inverted PWM. Set on compare match, upcounting. Cleared on compare match, downcounting.

[2]

[1] x = A, B, C, D [2] ‘ON’ means in the CCUCLK cycle after the event takes place.

9.8 Synchronized PWM register update

When the OCRx registers are written, a built in mechanism ensures that the value is not updated in the middle of a PWM pulse. This could result in an odd-length pulse. Whe n the registers are written, the values are placed in two shadow registers, as is the case in basic timer operation mode. Writing to TCOU2 will cause the contents of the shadow registers to be updated on the next CCU Timer overflow. If OCRxH and/or OCRxL are read before the value is updated, the most currently written value is read.

9.9 HALT

Setting the HLTEN bit in TCR20 enables the PWM Halt Function. When halt function is enabled, a capture event as enabled for the Input Capture A pin will immediately stop all activity on the PWM pins and set them to a predetermined state defined by FCOx bit. In PWM Mode, the FCOx bits in the CCCRx register hold the value the pin is forced to during halt. The value of the setting can be read back. The capture function and the interrupt will

User manual Rev. 01 — 1 December 2008 54 of 139

NXP Semiconductors

still operate as normal even if it has this added functionality enabled. When the PWM unit is halted, the timer will still run as normal. The HLTRN bit in TCR20 will be set to indicate that a halt took place. In order to re-activate the PWM, the user must clear the HLTRN bit. The user can force the PWM unit into halt by writing a logic 1 to HLTRN bit.

9.10 PLL operation

The PWM module features a Phase Locked Loop that can be used to generate a CCUCLK frequency between 16 MHz and 32 MHz. At this frequency the PWM module provides ultrasonic PWM frequency with 10-bit resolution provided that the crystal frequency is 1 MHz or higher (The PWM resolution is programmable up to 16 bits by writing to TOR2H:TOR2L). The PLL is fed an input signal of 0.5 MHz to 1 MHz and generates an output signal of 32 times the input fr equency. This signal is used to clock the timer. The user will have to set a divider that scales PCLK by a factor of 1 to 16. This divider is found in the SFR register TCR21. The PLL frequency can be expressed as follows:

PLL frequency = PCLK / (N+1)

Where: N is the value of PLLDV3:0.

UM10310

P89LPC9321 User manual

Since N ranges in 0 to 15, the CCLK frequency can be in the range of PCLK to

Table 43. CCU control registe r 1 (TCR21 - address F9h) bit allocation

Bit 7 6 5 4 3 2 1 0

SymbolTCOU2---PLLDV.3PLLDV.2PLLDV.1PLLDV.0 Reset0xxx0000

Table 44. CCU control registe r 1 (TCR21 - address F9h) bit description

Bit Symbol Description

0:3 PLLDV .3:0 PLL frequency divider. 4:6 - Reserved. 7 TCOU2 In basic timer mode, writing a logic 1 to TCOU2 will cause the values to be latched immediately and the

value of TCOU2 will always read as logic 0. In PWM mode, writing a logic 1 to TCOU2 will cause the contents of the shadow registers to be updated on the next CCU Timer overflow. As long as the latch is pending, TCOU2 will read as logic 1 and will return to logic 0 when the latching takes place. TCOU2 also controls the latching of the Output Compare registers OCRAx, OCRBx and OCRCx.

PCLK

⁄

Setting the PLLEN bit in TCR20 starts the PLL. When PLLEN is set, it will not read back a one until the PLL is in lock. At this time, the PWM unit is ready to operate and the timer can be enabled. The following start-up sequence is recommended:

1. Set up the PWM module without starting the timer.

2. Calculate the right division factor so that the PLL receives an input clock signal of 500 kHz - 1 MHz. Write this value to PLLDV.

3. Set PLLEN. Wait until the bit reads one

4. Start the timer by writing a value to bits TMOD21, TMOD20

When the timer runs from the PLL, the timer operates asynchronously to the rest of the microcontroller. Some restrictions apply:

User manual Rev. 01 — 1 December 2008 55 of 139

NXP Semiconductors

• The user is discouraged from writing or reading the timer in asynchronous mode. The

• Interrupts and flags are asynchronous. There will be delay as the event may not

9.11 CCU interrupt structure

There are seven independent sources of interrupts in the CCU: timer overflow, captured input events on Input Capture blocks A/B, and compare m atch event s on Output Co mpare blocks A through D. One common interrupt vector is used for the CCU service routine and interrupts can occur simultaneously in system usage. To resolve this situation, a priority encode function of the seven interrupt bits in TIFR2 SFR is implemented (after each bit is AND-ed with the corresponding interrupt enable bit in the TICR2 register). The order of priority is fixed as follows, from highest to lowest:

• TOIF2

• TICF2A

• TICF2B

• TOCF2A

• TOCF2B

• TOCF2C

• TOCF2D

UM10310

P89LPC9321 User manual

results may be unpredictable

actually be recognized until some CCLK cycles later (for interrupts and reads)

An interrupt service routine for the CCU can be as follows:

1. Read the priority-encoded value from the TISE2 register to determine the interrupt source to be handled.

2. After the current (highest priority) event is serviced, write a logic 0 to the corresponding interrupt flag bit in the TIFR2 register to clear the flag.

3. Read the TISE2 register. If the priority-encoded interrupt source is ‘000’, all CCU interrupts are serviced and a retu rn from interrupt can occur. Otherwise, return to step

List item 2

for the next interrupt.

User manual Rev. 01 — 1 December 2008 56 of 139

NXP Semiconductors

002aaa896

interrupt to CPU

TOIE2 (TICR2.7)

TOIF2 (TIFR2.7)

TICIE2A (TICR2.0)

TICF2A (TIFR2.0)

TICIE2B (TICR2.1)

TICF2B (TIFR2.1)

TOCIE2A (TICR2.3)

TOCF2A (TIFR2.3)

TOCIE2B (TICR2.4)

TOCF2B (TIFR2.4)

TOCIE2C (TICR2.5)

TOCF2C (TIFR2.5)

TOCIE2D (TICR2.6)

TOCF2D (TIFR2.6)

EA (IEN0.7)

ECCU (IEN1.4)

PRIORITY

ENCODER

other

interrupt

sources

ENCINT.0

ENCINT.1

ENCINT.2

UM10310

P89LPC9321 User manual

Fig 25. Capture/compare unit interrupts.

Table 45. CCU interrupt status encode register (TISE2 - address DEh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol-----ENCINT.2ENCINT.1ENCINT.0 Resetxxxxx000

Table 46. CCU interrupt status encode register (TISE2 - address DEh) bit description

Bit Symbol Description

2:0 ENCINT.2:0 CCU Interrupt Encode output. When multiple interrupts happen, more than one interrupt flag is set in

CCU Interrupt Flag Register (TIFR2). The encoder output can be read to determine which interrupt is to be serviced. The user must write a logic 0 to clear the corresponding interrupt flag bit in the TIFR2 register after the corresponding interrupt has been serviced. Refer to Table 48

for TIFR2 description.

000 — No interrupt pending. 001 — Output Compare Event D interrupt (lowest priority) 010 — Output Compare Event C interrupt. 011 — Output Compare Event B interrupt. 100 — Output Compare Event A interrupt. 101 — Input Capture Event B interrupt. 110 — Input Capture Event A interrupt. 111 — CCU Timer Overflow interrupt (highest priority).

3:7 - Reserved.

User manual Rev. 01 — 1 December 2008 57 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 47. CCU interrupt flag regis t er (TIFR2 - address E9h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol TOIF2 TOCF2D TOCF2C TOCF2B TOCF2A - TICF2B TICF2A Reset00000x00

Table 48. CCU interrupt flag register (TIFR2 - address E9h) bit description

Bit Symbol Description

0 TICF2A Input Capture Channel A Interrupt Flag Bit. Set by hardware when an input capture event is detected.

Cleared by software.

1 TICF2B Input Capture Channel B Interrupt Flag Bit. Set by hardware when an input capture event is detected.

Cleared by software. 2 - Reserved for future use. Should not be set to logic 1 by user program. 3 TOCF2A Output Compare Channel A Interrupt Flag Bit. Set by hardware when the contents of TH2:TL2 match that

of OCRHA:OCRLA. Compare channel A must be enabled in order to generate this interrupt. If EA bit in

IEN0, ECCU bit in IEN1 and TOCIE2A bit are all set, the program counter will vectored to the

corresponding interrupt. Cleared by software. 4 TOCF2B Output Compare Channel B Interrupt Flag Bit. Set by hardware when the contents of TH2:TL2 match that

of OCRHB:OCRLB. Compare channel B must be enabled in order to generate this interrupt. If EA bit in

IEN0, ECCU bit in IEN1 and TOCIE2B bit are set, the program counter will vectored to the corresponding

interrupt. Cleared by software. 5 TOCF2C Output Compare Channel C Interrupt Flag Bit. Set by hardware when the contents of TH2:TL2 match that

of OCRHC:OCRLC. Compare channel C must be enabled in order to generate this interrupt. If EA bit in

IEN0, ECCU bit in IEN1 and TOCIE2C bit are all set, the program counter will vectored to the

corresponding interrupt. Cleared by software. 6 TOCF2D Output Compare Channel D Interrupt Flag Bit. Set by hardware when the contents of TH2:TL2 match that

of OCRHD:OCRLD. Compare channel D must be enabled in order to generate this interrupt. If EA bit in

IEN0, ECCU bit in IEN1 and TOCIE2D bit are all set, the program counter will vectored to the

corresponding interrupt. Cleared by software. 7 TOIF2 CCU Timer Overflow Interrupt Flag bit. Set by hardware on CCU T i me r ove r f lo w. Cleared by software.

Table 49. CCU interrupt control register (TICR2 - address C9h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol TOIE2 TOCIE2D TOCIE2C TOCIE2B TOCIE2A - TICIE2B TICIE2A Reset00000x00

Table 50. CCU interrupt control register (TICR2 - address C9h) bit description

Bit Symbol Description

0 TICIE2A Input Capture Channel A Interrupt Enable Bit. If EA bit and this bit all be set, when a capture event is

detected, the program counter will vectored to the corresponding interrupt. 1 TICIE2B Input Capture Channel B Interrupt Enable Bit. If EA bit and this bit all be set, when a capture event is

detected, the program counter will vectored to the corresponding interrupt. 2 - Reserved for future use. Should not be set to logic 1 by user program. 3 TOCIE2A Output Compare Channel A Interrupt Enable Bit. If EA bit and this bit are set to 1, when compare channel

is enabled and the contents of TH2:TL2 match that of OCRHA:OCRLA, the program counter will vectored

to the corresponding interrupt. 4 TOCIE2B Output Compare Channel B Interrupt Enable Bit. If EA bit and this bit are set to 1, when compare channel

B is enabled and the contents of TH2:TL2 match that of OCRHB:OCRLB, the program counter will

vectored to the corresponding interrupt.

User manual Rev. 01 — 1 December 2008 58 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 50. CCU interrupt control register (TICR2 - address C9h) bit description

Bit Symbol Description

5 TOCIE2C Output Compare Channel C Interrupt Enable Bit. If EA bit and this bit are set to 1, when compare channel

C is enabled and the contents of TH2:TL2 match that of OCRHC:OCRLC, the program counter will

vectored to the corresponding interrupt. 6 TOCIE2D Output Compare Channel D Interrupt Enable Bit. If EA bit and this bit are set to 1, when compare channel

D is enabled and the contents of TH2:TL2 match that of OCRHD:OCRLD, the program counter will

vectored to the corresponding interrupt. 7 TOIE2 CCU Timer Overflow Interrupt Enable bit.

…continued

10. UART

The P89LPC9321 has an enhanced UAR T that is com patible with the conventional 80C51 UART except that Timer 2 overflow cannot be used as a baud rate source. The P89LPC9321 does include an independent Baud Rate Generator. The baud rate can be selected from the oscillator (divided by a constant), Timer 1 overflow, or the independent Baud Rate Generator. In addition to the baud rate generation, enhancements over the standard 80C51 UART include Framing Error detection, break detect, automatic address recognition, selectable double buffering and several interrupt options.

The UART can be operated in 4 modes, as described in the following sections.

10.1 Mode 0

Serial data enters and exits through RXD. TXD outputs the shift clock. 8 bits are transmitted or received, LSB first. The baud rate is fixed at frequency.

10.2 Mode 1

10 bits are transmitted (through TXD) or received (through RXD): a start bit (logic 0), 8 data bits (LSB first), and a stop bit (logic 1). When data is received, the stop bit is stored in RB8 in Special Function Register SCON. The baud rate is variable and is determined by the Timer 1 overflow rate or the Baud Rate Generator (see Section 10.6 “

generator and selection”).

10.3 Mode 2

11 bits are transmitted (through TXD) or received (through RXD): start bit (logic 0), 8 data bits (LSB first), a programmable 9th data bit, and a stop bit (logic 1). When data is transmitted, the 9th data bit (TB8 in SCON) can be assigned the value of 0 or 1. Or, for example, the parity bit (P, in the PSW) could be moved into TB8. When data is received, the 9th data bit goes into RB8 in Special Function Register SCON and the stop bit is not saved. The baud rate is programmable to either determined by the SMOD1 bit in PCON.

⁄

of the CPU clock

Baud Rate

⁄

of the CCLK frequency, as

User manual Rev. 01 — 1 December 2008 59 of 139

NXP Semiconductors

10.4 Mode 3

11 bits are transmitted (through TXD) or received (through RXD): a start bit (logic 0), 8 data bits (LSB first), a programmable 9th data bit, and a stop bit (logic 1). Mode 3 is the same as Mode 2 in all respects e xcept baud rate. The baud rate in Mode 3 is va riable and is determined by the Timer 1 overflow rate or the Baud Rate Generator (see Section 10.6

“Baud Rate generator and selection”).

In all four modes, transmission is initiated by any instruction that uses SBUF as a destination register. Reception is initiated in Mode 0 by the cond itio n RI = 0 and REN = 1. Reception is initiated in the other modes by the incoming start bit if REN = 1.

10.5 SFR space

The UART SFRs are at the following locations:

Table 51. UART SFR addresses

PCON Power Control 87H SCON Serial Port (UART) Control 98H SBUF Serial Port (UART) Data Buffer 99H SADDR Serial Port (UART) Address A9H SADEN Serial Port (UART) Address Enable B9H SSTAT Serial Port (UART) Status BAH BRGR1 Baud Rate Generator Rate High Byte BFH BRGR0 Baud Rate Generator Rate Low Byte BEH BRGCON Baud Rate Generator Control BDH

UM10310

P89LPC9321 User manual

10.6 Baud Rate generator and selection

The P89LPC9321 enhanced UART has an independent Baud Rate Generator. The baud rate is determined by a value programmed into the BRGR1 and BRGR0 SFRs. The UART can use either Timer 1 or th e baud r ate gener ator output as determined by BRGCON[2:1] (see Figure 26

). Note that Timer T1 is further divided by 2 if the SMOD1 bit (PCON.7) is

set. The independent Baud Rate Generator uses CCLK.

10.7 Updating the BRGR1 and BRGR0 SFRs

The baud rate SFRs, BRGR1 and BRGR0 must only be loaded when the Baud Rate Generator is disabled (the BRGEN bit in the BRGCON register is logic 0). This avoids the loading of an interim value to the baud rate generator. (CAUTION: If either BRGR0 or

BRGR1 is written when BRGEN = 1, the result is unpredictable.)

Table 52. UART baud rate generation

SCON.7 (SM0)

00XX 0100

User manual Rev. 01 — 1 December 2008 60 of 139

SCON.6 (SM1)

PCON.7 (SMOD1)

10 X1

BRGCON.1 (SBRGS)

Receive/transmit baud rate for UART

CCLK

⁄

CCLK

⁄

(256-TH1)64

CCLK

⁄

(256-TH1)32

CCLK

⁄

((BRGR1,BRGR0)+16)

NXP Semiconductors

baud rate modes 1 and 3

SBRGS = 1

SBRGS = 0

SMOD1 = 0

SMOD1 = 1

timer 1 overflow

(PCLK-based)

baud rate generator

(CCLK-based)

002aaa897

÷2

UM10310

P89LPC9321 User manual

Table 52. UART baud rate generation

SCON.7 (SM0)

SCON.6 (SM1)

PCON.7 (SMOD1)

100X

1100

10 X1

Table 53. Baud Rate Generator Control register (BRGCON - address BDh) bit allocation

…continued

BRGCON.1 (SBRGS)

Receive/transmit baud rate for UART

CCLK

⁄

CCLK

⁄

CCLK

⁄

(256-TH1)64

CCLK

⁄

(256-TH1)32

CCLK

⁄

((BRGR1,BRGR0)+16)

Bit 7 6 5 4 3 2 1 0

Symbol-------SBRGSBRGEN Resetxxxxxx0 0

Table 54. Baud Rate Generator Control re gister (BRGCON - address BDh) bit description

Bit Symbol Description

0 BRGEN Baud Rate Generator Enable. Enables the baud rate generator. BRGR1 and

BRGR0 can only be written when BRGEN = 0.

1 SBRGS Select Baud Rate Generator as the source for baud rates to UART in modes 1 and

3 (see Table 52

for details)

2:7 - reserved

Fig 26. Baud rate generation for UART (Modes 1, 3)

10.8 Framing error

A Framing error occurs when the stop bit is sensed as a logic 0. A Framing error is reported in the status register (SSTAT). In addition, if SMOD0 (PCON.6) is 1, framing errors can be made available in SCON.7. If SMOD0 is 0, SCON.7 is SM0. It is recommended that SM0 and SM1 (SCON[7:6]) are programmed when SMOD0 is logic 0.

10.9 Break detect

A break detect is reported in the status register (SSTAT). A break is detected when any 11 consecutive bits are sensed low. Since a break condition also satisfies the requirements for a framing error, a break condition will also result in reporting a framing error. Once a break condition has been detected, the UART will go into an idle state and remain in this idle state until a stop bit has been received. The break detect can be used to reset the device and force the device into ISP mode by setting the EBRR bit (AUXR1.6)

User manual Rev. 01 — 1 December 2008 61 of 139

NXP Semiconductors

Table 55. Serial Port Control register (SCON - address 98h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol SM0/FE SM1 SM2 REN TB8 RB8 TI RI Resetxxxxxx00

Table 56. Serial Port Control register (SCON - address 98h) bit description

Bit Symbol Description

0 RI Receive interrupt flag. Set by hardware at the end of the 8th bit time in Mode 0, or

1 TI Transmit interrupt flag. Set by hardware at the end of the 8th bit time in Mode 0, or

2 RB8 The 9th data bit that was received in Modes 2 and 3. In Mode 1 (SM2 must be 0),

3 TB8 The 9th data bit that will be transmitted in Modes 2 and 3. Set or clear by software

4 REN Enables serial reception. Set by software to enable reception. Clear by software to

5 SM2 Enables the multiprocessor communication feature in Modes 2 and 3. In Mode 2 or

6 SM1 With SM0 defines the serial port mode, see Table 57 7 SM0/FE The use of this bit is determined by SMOD0 in the PCON register. If SMOD0 = 0,

UM10310

P89LPC9321 User manual

approximately halfway through the stop bit time in Mode 1. For Mode 2 or Mode 3, if SMOD0, it is set near the middle of the 9th data bit (bit 8). If SMOD0 = 1, it is set near the middle of the stop bit (see SM2 - SCON.5 - for exceptions). Must be cleared by software.

at the stop bit (see description of INTLO bit in SSTAT register) in the other modes. Must be cleared by software.

RB8 is the stop bit that was received. In Mode 0, RB8 is undefined.

as desired.

disable reception.

3, if SM2 is set to 1, then Rl will not be activated if the received 9th data bit (RB8) is 0. In Mode 0, SM2 should be 0. In Mode 1, SM2 must be 0.

this bit is read and written as SM0, which with SM1, defines the serial port mode. If SMOD0 = 1, this bit is read and written as FE (Framing Error). FE is set by the receiver when an invalid stop bit is detected. Once set, this bit cannot be cleared by valid frames but is cleared by software. (Note: UART mode bits SM0 and SM1 should be programmed when SMOD0 is logic 0 - default mode on any reset.)

Table 57. Serial Port modes

SM0, SM1 UART mode UART baud rate

CCLK

⁄

00 Mode 0: shift register 01 Mode 1: 8-bit UART Variable (see Table 52 10 Mode 2: 9-bit UART

(default mode on any reset)

CCLK

⁄

)

1 1 Mode 3: 9-bit UART Variable (see Table 52)

Table 58. Serial Port Status register (SSTAT - address BAh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol DBMOD INTLO CIDISDBISELFE BR OE STINT Resetxxxxxx00

User manual Rev. 01 — 1 December 2008 62 of 139

NXP Semiconductors

Table 59. Serial Port Status register (SSTAT - address BAh) bit description

Bit Symbol Description

0 STINT Status Interrupt Enable. When set = 1, FE, BR, or OE can cause an interrupt. The

1 OE Overrun Error flag is set if a new character is received in the receiver buffer while it

2 BR Break Detect flag. A break is detected when any 11 consecutive bits are sensed

3 FE Framing error flag is set when the receiver fails to see a valid STOP bit at the end

4 DBISEL Double buffering transmit interrupt select. Used only if double buffering is enabled.

5 CIDIS Combined Interrupt Disable. When set = 1, Rx and Tx interrupts are separate.

6 INTLO Transmit interrupt position. When cleared = 0, the Tx interrupt is issued at the

7 DBMOD Double buffering mode. When set = 1 enables double buffering. Must be logic 0 for

UM10310

P89LPC9321 User manual

interrupt used (vector address 0023h) is shared with RI (CIDIS = 1) or the combined TI/RI (CIDIS = 0). When cleared = 0, FE, BR, OE cannot cause an interrupt. (Note: FE, BR, or OE is often accompanied by a RI, which will generate an interrupt regardless of the state of STINT). Note that BR can cause a break detect reset if EBRR (AUXR1.6) is set to logic 1.

is still full (before the software has read th e pre vi o us character from the buffer), i.e., when bit 8 of a new byte is received while RI in SCON is still set. Cleared by software.

low. Cleared by software.

of the frame. Cleared by software.

This bit controls the number of interrupts that can occur when double buffering is enabled. When set, one transmit interrupt is generated after each character written to SBUF, and there is also one more transmit interrupt generated at the beginning (INTLO = 0) or the end (INTLO = 1) of the STOP bit of the last character sent (i.e., no more data in buffer). This last interrupt can be used to indicate that all transmit operations are over. When cleared = 0, only one transmit interrupt is generated per character written to SBUF . Must be logic 0 when double buffering is disabled. Note that except for the first character written (when buffer is empty), the location of the transmit interrupt is determined by INTLO. When the first character is written, the transmit interrupt is generated immediately after SBUF is written.

When cleared = 0, the UART uses a combined Tx/Rx interrupt (like a conventional 80C51 UART). This bit is reset to logic 0 to select combined interrupts.

beginning of the stop bit. When set = 1, the Tx interrupt is issued at end of the stop bit. Must be logic 0 for mode 0. Note that in the case of single buffering, if the Tx interrupt occurs at the end of a STOP bit, a gap may exist before the next start bit.

UART mode 0. In order to be compatible with existing 80C51 devices, this bit is reset to logic 0 to disable double buffering.

10.10 More about UART Mode 0

In Mode 0, a write to SBUF will initiate a transmission. At the end of the transmission, TI (SCON.1) is set, which must be cleared in software. Double buffering must be disabled in this mode.

Reception is initiated by clearing RI (SCON.0). Synchronous serial transfer occurs and RI will be set again at the end of the transfer. When RI is cleared, the reception of the next character will begin. Refer to Figure 27

User manual Rev. 01 — 1 December 2008 63 of 139

NXP Semiconductors

002aaa925

transmit

RXD (data out)

RXD

(data in)

D0 D1 D5D2 D6D3 D4 D7

TXD (shift clock)

shift

S1 ... S16 S1 ... S16 S1 ... S16 S1 ... S16S1 ... S16S1 ... S16 S1 ... S16 S1 ... S16 S1 ... S16 S1 ... S16S1 ... S16S1 ... S16 S1 ... S16

write to

SBUF

receive

D0 D1 D5D2 D6D3 D4 D7

TXD (shift clock)

shift

WRITE to SCON

(clear RI)

UM10310

P89LPC9321 User manual

Fig 27. Serial Port Mode 0 (double buffering must be disabled)

10.11 More about UART Mode 1

Reception is initiated by detecting a 1-to-0 transition on RxD. RxD is sampled at a rate 16 times the programmed baud rate. When a transition is detected, the divide-by-16 counter is immediately reset. Each bit time is thus divided into 16 counter states. At the 7th, 8th, and 9th counter states, the bit detector samples the value of RxD. The value accepted is the value that was seen in at least 2 of the 3 samples. This is done for noise rejection. If the value accepted during the first bit time is not 0, the receive circuits are reset and the receiver goes back to looking for another 1-to-0 transition. This provides rejection of false start bits. If the start bit proves valid, it is shifted into the input shift register , and reception of the rest of the frame will proceed.

The signal to load SBUF and RB8, and to set RI, will be generated if, and only if, the following conditions are met at the time the final shift pulse is gen erated: RI = 0 and eith er SM2 = 0 or the received stop bit = 1. If either of these two conditions is not met, the received frame is lost. If both conditions are met, the stop bit goes into RB8, the 8 data bits go into SBUF, and RI is activated.

User manual Rev. 01 — 1 December 2008 64 of 139

NXP Semiconductors

transmit

start

bit

stop bit

INTLO = 0

TX clock

write to

SBUF

shift

TXD

D0 D1 D5D2 D6D3 D4 D7

receive

clock

shift

start

bit

stop bit

RXD

D0 D1 D5D2 D6D3 D4 D7

002aaa926

÷16 reset

INTLO = 1

transmit

start

bit

stop bit

TX clock

write to

SBUF

shift

TXD

D0 D1 D5D2 D6D3 D4 D7

receive

clock

shift

start

bit

RXD

D0 D1 D5D2 D6D3 D4 D7

002aaa927

TB8

RB8

÷16 reset

INTLO = 0 INTLO = 1

SMOD0 = 0 SMOD0 = 1

Fig 28. Serial Port Mode 1 (only single transmit buffering case is shown)

UM10310

P89LPC9321 User manual

10.12 More about UART Modes 2 and 3

Reception is the same as in Mode 1. The signal to load SBUF and RB8, and to set RI, will be generated if, and only if, the

following conditions are met at the time the final shift pulse is generated. (a) RI = 0, and (b) Either SM2 = 0, or the received 9th data bit = 1. If either of these conditions is not me t, the received frame is lost, and RI is not set. If both conditions are met, the received 9th data bit goes into RB8, and the first 8 data bits go into SBUF.

Fig 29. Serial Port Mode 2 or 3 (only single transmit buffering case is sho wn)

User manual Rev. 01 — 1 December 2008 65 of 139

10.13 Framing error and RI in Modes 2 and 3 with SM2 = 1

If SM2 = 1 in modes 2 and 3, RI and FE behaves as in the following table.

NXP Semiconductors

Table 60. FE and RI when SM2 = 1 in Modes 2 and 3

Mode PCON.6

2 0 0 No RI when RB8 = 0 Occurs during STOP

3 1 0 No RI when RB8 = 0 Will NOT occur

10.14 Break detect

A break is detected when 11 consecutive bits are sensed low and is reported in the status register (SSTAT). For Mode 1, this consists of the start bit, 8 data bits, and two stop bit times. For Modes 2 and 3, this consists of the start bit, 9 data bits, and one stop bit. The break detect bit is cleared in software or by a reset. The break detect can be used to reset the device and force the device into ISP mode. This occurs if th e UART is enabled and the the EBRR bit (AUXR1.6) is set and a break occurs.

(SMOD0)

P89LPC9321 User manual

RB8 RI FE

bit

1 Similar to Figure 29

occurs during RB8, one bit before FE

1 Similar to Figure 29

occurs during STOP bit

, with SMOD0 = 0, RI

, with SMOD0 = 1, RI

Occurs during STOP bit

UM10310

10.15 Double buffering

The UART has a transmit double buffer that allows buffering of the next character to be written to SBUF while the first character is being transmitted. Double buffering allows transmission of a string of characters with only one stop bit between any two characters, provided the next character is written between the start bit and the stop bit of the previous character.

Double buffering can be disabled. If disabled (DBMOD, i.e. SSTAT.7 = 0), the UART is compatible with the conventional 80C51 UART. If enabled, the UART allows writing to SnBUF while the previous data is being shifted out.

10.16 Double buffering in different modes

Double buffering is only allowed in Modes 1, 2 and 3. When operated in Mode 0, double buffering must be disabled (DBMOD = 0).

10.17 Transmit interrupts with double buffering enabled (Modes 1, 2, and 3)

Unlike the conventional UART, when double buffering is enabled, the Tx interrupt is generated when the double buffer is ready to receive new data. The following occurs during a transmission (assuming eight data bits):

1. The double buffer is empty initially.

2. The CPU writes to SBUF.

3. The SBUF data is loaded to the shift register and a Tx interrupt is generated immediately.

4. If there is more data, go to 6, else continue.

5. If there is no more data, then: – If DBISEL is logic 0, no more interrupts will occur.

User manual Rev. 01 — 1 December 2008 66 of 139

NXP Semiconductors

TXD

write to

SBUF

TX interrupt

single buffering (DBMOD/SSTAT.7 = 0), early interrupt (INTLO/SSTAT.6 = 0) is shown

TXD

write to

SBUF

TX interrupt

double buffering (DBMOD/SSTAT.7 = 1), early interrupt (INTLO/SSTAT.6 = 0) is shown,

no ending TX interrupt (DBISEL/SSTAT.4 = 0)

TXD

write to

SBUF

TX interrupt

double buffering (DBMOD/SSTAT.7 = 1), early interrupt (INTLO/SSTAT.6 = 0) is shown,

with ending TX interrupt (DBISEL/SSTAT.4 = 1)

002aaa928

6. If there is more data, the CPU writes to SBUF again. Then:

UM10310

P89LPC9321 User manual

– If DBISEL is logic 1 and INTLO is logic 0, a Tx interrupt will occur at the beginning

of the STOP bit of the data currently in the shifter (which is also the last data).

– If DBISEL is logic 1 and INTLO is logic 1, a Tx interrupt will occur at the end of the

STOP bit of the data currently in the shifter (which is also the last data).

– Note that if DBISEL is logic 1 and the CPU is writing to SBUF when the STOP bit of

the last data is shifted out, there can be an uncertainty of whether a Tx interrupt is generated already with the UART not knowing whether there is any more data following.

– If INTLO is logic 0, the new data will be loaded and a Tx interrupt will occur at the

beginning of the STOP bit of the data currently in the shifter.

– If INTLO is logic 1, the new data will be loaded and a Tx interrupt will occur at the

end of the STOP bit of the data currently in the shifter.

– Go to 3.

Fig 30. Transmission with and without double buffering

10.18 The 9th bit (bit 8) in double buffering (Modes 1, 2, and 3)

If double buffering is disabled (DBMOD, i.e. SSTAT.7 = 0), TB8 can be written before or

User manual Rev. 01 — 1 December 2008 67 of 139

after SBUF is written, provided TB8 is updated before that TB8 is shifted out. TB8 must not be changed again until after TB8 shifting has been completed, as indicated by the Tx interrupt.

NXP Semiconductors

If double buffering is enabled, TB8 MUST be updated before SBUF is written, as TB8 will be double-buffered together with SBUF data. The operation described in the Section

10.17 “Transmit interrupt s with double buf fering enabled (Modes 1, 2, and 3)” becomes as

follows:

1. The double buffer is empty initially.

2. The CPU writes to TB8.

3. The CPU writes to SBUF.

4. The SBUF/TB8 data is loaded to the shift register and a Tx interrupt is generated

5. If there is more data, go to 7, else continue on 6.

6. If there is no more data, then:

7. If there is more data, the CPU writes to TB8 again.

8. The CPU writes to SBUF again. Then:

9. Go to 4.

10. Note that if DBISEL is logic 1 and the CPU is writing to SBUF when the STOP bit of

UM10310

P89LPC9321 User manual

immediately.

– If DBISEL is logic 0, no more interrupt will occur. – If DBISEL is logic 1 and INTLO is logic 0, a Tx interrupt will occur at the beginning

of the STOP bit of the data currently in the shifter (which is also the last data).

– If DBISEL is logic 1 and INTLO is logic 1, a Tx interrupt will occur at the end of the

STOP bit of the data currently in the shifter (which is also the last data).

– If INTLO is logic 0, the new data will be loaded and a Tx interrupt will occur at the

beginning of the STOP bit of the data currently in the shifter.

– If INTLO is logic 1, the new data will be loaded and a Tx interrupt will occur at the

end of the STOP bit of the data currently in the shifter.

the last data is shifted out, there can be an uncertainty of whether a Tx interrupt is generated already with the UART not knowing whether there is any more data following.

10.19 Multiprocessor communications

UART modes 2 and 3 have a special provision for multiprocessor communications. In these modes, 9 data bits are received or transmitted. When data is received, the 9th bit is stored in RB8. The UART can be programmed such that when the stop bit is received, the serial port interrupt will be activated only if RB8 = 1. This feature is enabled by setting bit SM2 in SCON. One way to use this feature in multiprocessor systems is as follows:

When the master processor wants to transmit a block of data to one of several slaves, it first sends out an address byte which identifies the target slave. An address byte differs from a data byte in that the 9th bit is 1 in an address byte and 0 in a data byte. With SM2 = 1, no slave will be interrupted by a data byte. An address byte, however, will interrupt all slaves, so that each slave can examine the received byte and see if it is being addressed. The addressed slave will clear its SM2 bit and prepare to receive the data bytes that follow. The slaves that we ren’t being addre ssed leave th eir SM2 bit s set a nd go on about their business, ignoring the subsequent data bytes.

Note that SM2 has no effect in Mode 0, and must be logic 0 in Mode 1.

User manual Rev. 01 — 1 December 2008 68 of 139

NXP Semiconductors

10.20 Automatic address recognition

Automatic address recognition is a feature which allows the UART to recognize certain addresses in the serial bit stream by using hardware to make the comparisons. This feature saves a great deal of software overhead by eliminating the need for the software to examine every serial address which passes by the serial port. This feature is enabled by setting the SM2 bit in SCON. In the 9 bit UART modes (mode 2 and mode 3), the Receive Interrupt flag (RI) will be automatically set when the received byte contains either the ‘Given’ address or the ‘Broadcast’ address. The 9 bit mode requires that the 9th information bit is a 1 to indicate that the received information is an address and not data.

Using the Automatic Address Recognition feature allows a master to selectively communicate with one or more slaves by invoking the Given slave address or addresses. All of the slaves may be contacted by using the Broadcast address. Two special Function Registers are used to define the slave’s address, SADDR, and the address mask, SADEN. SADEN is used to define which bits in the SADDR are to be used and which bits are ‘don’t care’. The SADEN mask can be logically ANDed with the SADDR to create the ‘Given’ address which the master will use for addressing each of the slaves. Use of the Given address allows multiple slaves to be recognized while excluding others. The following examples will help to show the versatility of this scheme:

Table 61. Slave 0/1 examples

Example 1 Example 2

Slave 0 SADDR = 1100 0000 Slave 1 SADDR = 1100 0000

UM10310

P89LPC9321 User manual

SADEN = 1111 1101 SADEN = 1111 1110 Given = 1100 00X0 Given = 1100 000X

In the above example SADDR is the same and the SADEN data is used to differentiate between the two slaves. Slave 0 requires a 0 in bit 0 and it ignores bit 1. Slave 1 requires a 0 in bit 1 and bit 0 is ignored. A unique address for Slave 0 would be 1100 0010 since slave 1 requires a 0 in bit 1. A unique address for slave 1 would be 1100 0001 since a 1 in bit 0 will exclude slave 0. Both slaves can be selected at the same time by an address which has bit 0 = 0 (for slave 0) and bit 1 = 0 (for slave 1). Thus, both could be addressed with 1100 0000.

In a more complex system the following could be used to select slaves 1 and 2 while excluding slave 0:

Table 62. Slave 0/1/2 examples

Example 1 Example 2 Example 3

Slave 0 SADDR = 1100 0000 Slave 1 SADDR = 1110 0000 Slave 2 SADDR = 1100 0000

SADEN = 1111 1001 SADEN = 1111 1010 SADEN = 1111 1100 Given = 1100 0XX0 Given = 1110 0X0X Given = 1110 00XX

In the above example the differentiation among the 3 slaves is in the lower 3 address bits. Slave 0 requires that bit 0 = 0 and it can be uniquely addres se d by 1110 0110. Slave 1 requires that bit 1 = 0 and it can be uniquely addressed by 1110 and 0101. Slave 2 requires that bit 2 = 0 and its unique address is 1110 0011. To select Slaves 0 and 1 and exclude Slave 2 use address 1110 0100, sin ce it is nece ssary to make bit 2 = 1 to exclude slave 2. The Broadcast Address for each slave is created by taking the logical OR of SADDR and SADEN. Zeros in this result are treated as don’t-cares. In most cases, interpreting the don’t-cares as ones, the broadcast address will be FF hexadecimal. Upon

User manual Rev. 01 — 1 December 2008 69 of 139

NXP Semiconductors

reset SADDR and SADEN are loaded with 0s. This produces a given address of all ‘don’t cares’ as well as a Broadcast address of all ‘don’t cares’. This effectively disables the Automatic Addressing mode and allows the microcontroller to use standar d UAR T dr ivers which do not make use of this feature.

11. I2C interface

The I2C-bus uses two wires, serial clock (SCL) and serial data (SDA) to transfer information between devices connected to the bus, and has the following features:

• Bidirectional data transfer between masters and slaves

• Multimaster bus (no central master)

• Arbitration between simultaneously transmitting masters without corruption of serial

• Serial clock synchronization allows devices with different bit rates to communicate via

• Serial clock synchronization can be used as a handshake mechanism to suspend and

• The I

data on the bus

one serial bus

resume serial transfer

C-bus may be used for test and diagnostic purposes

UM10310

P89LPC9321 User manual

A typical I direction bit (R/W), two types of data transfers are possible on the I

C-bus configuration is shown in Figure 31. Depending on the state of the

C-bus:

• Data transfer from a master transmitter to a slave receiver. The first byte transmitted

by the master is the slave address. Next follows a number of data bytes. The slave returns an acknowledge bit after each received byte.

• Data transfer from a slave transmitter to a master receiver. The first byte (the slave

address) is transmitted by the master. The slave then returns an acknowledge bit. Next follows the data bytes transmitted by th e slave to the master. The master returns an acknowledge bit after all received bytes other than the last byte. At the end of the last received byte, a ‘not acknowledge’ is returned. The master device generates all of the serial clock pulses and the START and STOP conditions. A transfer is ended with a STOP condition or with a repeated START condition. Since a repeated START condition is also the beginning of the next serial transfer, the I released.

The P89LPC9321 device provides a byte-oriented I modes: Master Transmitter Mode, Master Receiver Mode, Slave Transmitter Mode and Slave Receiver Mode.

C interface. It has four operation

C-bus will not be

User manual Rev. 01 — 1 December 2008 70 of 139

NXP Semiconductors

OTHER DEVICE

WITH I

C-BUS

INTERFACE

SDA

SCL

OTHER DEVICE

WITH I

C-BUS

INTERFACE

P1.3/SDA P1.2/SCL

I2C MCU

C-bus

002aac130

Fig 31. I2C-bus configuration.

UM10310

P89LPC9321 User manual

The P89LPC9321 CPU interfaces with the I2C-bus through six Special Function Registe rs (SFRs): I2CON (I Register), I2ADR (I

C Control Register), I2DAT (I2C Data Register), I2STAT (I2C Status

C Slave Address Register), I2SCLH (SCL Duty Cycle Register High

Byte), and I2SCLL (SCL Duty Cycle Register Low Byte).

11.1 I2C data register

I2DA T register contains the dat a to be transmitted or the data received. The CPU can read and write to this 8-bit register while it is not in the process of shifting a byte. Thus this register should only be accessed when the SI bit is set. Data in I2DAT remains stable as long as the SI bit is set. Data in I2DAT is always shifted from right to left: the first bit to be transmitted is the MSB (bit 7), and after a byte has been received , the first bit of re ce ived data is located at the MSB of I2DAT.

Table 63. I2C data register (I2DAT - address DAh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol I2DAT.7 I2DAT.6 I2DAT.5 I2DAT.4 I2DAT.3 I2DAT.2 I2DAT.1 I2DAT.0 Reset00000000

11.2 I2C slave address register

I2ADR register is readable and writable, and is only used when the I2C interface is set to slave mode. In master mode, this register has no effect. The LSB of I2ADR is general call bit. When this bit is set, the general call address (00h) is recognized.

Table 64. I2C slave address register (I2ADR - address DBh) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol I2ADR.6 I2ADR.5 I2ADR.4 I2ADR.3 I2ADR.2 I2ADR.1 I2ADR.0 GC Reset00000000

Table 65. I

C slave address register (I2ADR - address DBh) bit description

Bit Symbol Description

0 GC General call bit. When set, the general call address (00H) is recognized,

otherwise it is ignored.

1:7 I2ADR1:7 7 bit own slave address. When in master mode, the contents of this register has

no effect.

User manual Rev. 01 — 1 December 2008 71 of 139

NXP Semiconductors

11.3 I2C control register

The CPU can read and write this register. There are two bits are affected by hardware: th e SI bit and the STO bit. The SI bit is set by hardware and the STO bit is cleared by hardware.

CRSEL determines the SCL source when the I this bit is ignored and the bus will automatically synchronize with any clock frequency up to 400 kHz from the master I Timer 1 overflow rate divided by 2 for the I by the user in 8 bit auto-reload mode (Mode 2).

UM10310

P89LPC9321 User manual

C-bus is in master mode. In slave mode

C device. When CRSEL = 1, the I2C interface uses the

C clock rate. Timer 1 should be programmed

Data rate of I If f

= 12 MHz, reload value is 0 to 255, so I2C data rate range is 11.72 Kbit/sec to

osc

C-bus = Timer overflow rate / 2 = PCLK / (2*(256-reload value)).

3000 Kbit/sec. When CRSEL = 0, the I

C interface uses the internal clock generator based on the value

of I2SCLL and I2CSCLH register. The duty cycle does not need to be 50 %. The STA bit is START flag. Setting this bit causes the I

C interface to enter master mode and attempt transmitting a START condition or transmitting a repeated START condition when it is already in master mode.

The STO bit is STOP flag. Setting this bit causes the I

C interface to transmit a STOP

condition in master mode, or recovering from an error condition in slave mode.

If the ST A and STO are both se t, then a STOP condition is transmitted to the I

C-bus if it is in master mode, and transmits a START condition afterwards. If it is in slave mode, an internal STOP condition will be generated, bu t it is not transmitted to the bus.

Table 66. I2C Control register (I2CON - address D8h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol - I2EN STA STO SI AA - CRSEL Resetx00000x0

Table 67. I

Bit Symbol Description

0 CRSEL SCL clock selection. When set = 1, Timer 1 overflow generates SCL, when cleared

1 - reserved 2 AA The Assert Acknowledge Flag. When set to 1, an acknowledge (low level to SDA)

C Control register (I2CON - address D8h) bit description

= 0, the internal SCL generator is used base on values of I2SCLH and I2SCLL.

will be returned during the acknowledge clock pulse on the SCL line on the following situations:

(1)The ‘own slave address’ has been received. (2)The general call address has been received while the general call bit (GC) in I2ADR is set. (3) A data byte has been received while the I byte has been received while the I Mode. When cleared to 0, an not acknowledge (high level to SDA) will be returned during the acknowledge clock pulse on the SCL line on the following situations: (1) A data byte has been received while the I Mode. (2) A data byte has been received while the I addressed Slave Receiver Mode.

C interface is in the Master Receiver Mode. (4)A data

C interface is in the addressed Slave Receiver

C interface is in the Master Receiver

C interface is in the

User manual Rev. 01 — 1 December 2008 72 of 139

NXP Semiconductors

Table 67. I

Bit Symbol Description

3SI I2C Interrupt Flag. This bit is set when one of the 25 possible I2C states is entered.

4 STO STOP Flag. STO = 1: In master mode, a STOP condition is transmitted to the

5 STA Start Flag. STA = 1: I

6I2EN I

7 - reserved

UM10310

P89LPC9321 User manual

C Control register (I2CON - address D8h) bit description …continued

When EA bit and EI2C (IEN1.0) bit are both set, an interrupt is requested when SI is set. Must be cleared by software by writing 0 to this bit.

C-bus. When the bus detects the STOP condition, it will clear STO bit

I automatically. In slave mode, setting this bit can recover from an error condition. In this case, no STOP condition is transmitted to the bus. The hardware behaves as if a STOP condition has been received and it switches to ‘not addressed’ Slave Receiver Mode. The STO flag is cleared by hardware automatically.

C-bus enters master mode, checks the bus and generates a ST ART condition if the bus is free. If the bus is not free, it waits for a STOP condition (which will free the bus) and generates a START condition after a delay of a half clock period of the internal clock generator. When the I already in master mode and some data is transmitted or received, it transmits a repeated START condition. STA may be set at any time, it may also be set when

C interface is in an addressed slave mode. STA = 0: no START condition or

the I repeated START condition will be generated.

C Interface Enable. When set, enables the I2C interface. When clear, the I2C

function is disabled.

C interface is

11.4 I2C Status register

This is a read-only register. It contains the status code of the I2C interface. The least three bits are always 0. There are 26 possible status codes. When the code is F8H, there is no relevant information available and SI bit is not set. All other 25 st atus co des correspon d to defined I

Table 73

Table 68. I2C Status register (I2STAT - address D9h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol STA.4 STA.3 STA.2 STA.1 STA.0 0 0 0 Reset00000000

Table 69. I

Bit Symbol Description

0:2 - Reserved, are al w a ys set to 0. 3:7 STA[0:4] I

C states. When any of these states entered, the SI bit will be set. Refer to

to Table 76 for details.

C Status register (I2STAT - address D9h) bit description

C Status code.

11.5 I2C SCL duty cycle registers I2SCLH and I2SCLL

When the internal SCL generator is selected for the I2C interface by setting CRSEL = 0 in the I2CON register, the user must set values for registers I2SCLL and I2SCLH to select the data rate. I2SCLH defines the number of PCLK cycles for SCL = high, I2SCLL defines the number of PCLK cycles for SCL = low. The frequency is determined by the following formula:

Bit Frequency = f

Where f

User manual Rev. 01 — 1 December 2008 73 of 139

is the frequency of PCLK.

PCLK

/ (2*(I2SCLH + I2SCLL))

PCLK

NXP Semiconductors

The values for I2SCLL and I2SCLH do not have to be the same; the user can give different duty cycles for SCL by setting these two registers. However, the value of the register must ensure that the data rate is in the I the values of I2SCLL and I2SCLH have some restrictions and values for both registers greater than three PCLKs are recommended.

Table 70. I2C clock rates selection

I2SCLL+ I2SCLH

6 0 - 307 154 - 7 0 - 263 132 - 8 0 - 230 115 - 375 9 0 - 205 102 - 333 10 0 369 184 92 - 300 15 0 246 123 61 400 200 25 0 147 74 37 240 120 30 0 123 61 31 200 100 50 0 74 37 18 120 60 60 0 61 31 15 100 50 100 0 37 18 9 60 30 150 0 25 12 6 40 20 200 0 18 9 5 30 15

- 1 3.6 Kbps to

UM10310

P89LPC9321 User manual

C data rate range of 0 to 400 kHz. Thus

Bit data rate (Kbit/sec) at f

CRSEL 7.373 MHz 3.6865 MHz 1.8433 MHz 12 MHz 6 MHz

1.8 Kbps to 922 Kbps Timer 1 in mode 2

461 Kbps Timer 1 in mode 2

osc

0.9 Kbps to 230 Kbps Timer 1 in mode 2

5.86 Kbps to 1500 Kbps Timer 1 in mode 2

2.93 Kbps to 750 Kbps Timer 1 in mode 2

11.6 I2C operation modes

11.6.1 Master Transmitter mode

In this mode data is transmitted from master to slave. Before the Master Transmitter mode can be entered, I2CON must be initialized as follows:

Table 71. I2C Control register (I2CON - address D8h)

Bit 7 6 5 4 3 2 1 0

- I2EN STA STO SI AA - CRSEL

value- 1000x- bit rate

CRSEL defines the bit rate. I2EN must be set to 1 to enable the I2C function. If the AA bit is 0, it will not acknowledge its own slave address or the general call address in the event of another device becoming master of the bus and it ca n not enter slave mode. STA, STO, and SI bits must be cleared to 0.

User manual Rev. 01 — 1 December 2008 74 of 139

NXP Semiconductors

S R/W A DATA DATA

data transferred

(n Bytes + acknowledge)

A A/A Pslave address

logic 0 = write logic 1 = read

from Master to Slave from Slave to Master

A = acknowledge (SDA LOW) A = not acknowledge (SDA HIGH) S = START condition P = STOP condition

002aaa929

The first byte transmitted contains the slave address of the receiving device (7 bits) and the data direction bit. In this case, the data direction bit (R/W) will be logic 0 indicating a write. Data is transmitted 8 bits at a time. After each byte is transmitted, an acknowledge bit is received. START and STOP conditions are output to indicate the beginning and the end of a serial transfer.

The I send the START condition as soon as the bus is free. After the START condition is transmitted, the SI bit is set, and the status code in I2STAT should be 08h. This status code must be used to vector to an interrupt service routine where the user should load the slave address to I2DAT (Data Register) and data direction bit (SLA+W). The SI bit must be cleared before the data transfer can continue.

When the slave address and R/W bit have been transmitted and an acknowledgment bit has been received, the SI bit is set again, and the possible status codes are 18h, 20h, or 38h for the master mode or 68h, 78h, or 0B0h if the slave mode was enabled (setting AA = Logic 1). The appropriate action to be taken for each of these status codes is shown in Table 73

UM10310

P89LPC9321 User manual

C-bus will enter Master Transmitter Mode by setting the STA bit. The I2C logic will

Fig 32. Format in the Master Transmitter mode.

11.6.2 Master Receiver mode

In the Master Receiver Mode, data is received from a slave transmitter. The transfer started in the same manner as in the Master Transmitter Mode. When the START condition has been transmitted, the interrupt service routine must load the slave address and the data direction bit to I the data transfer can continue.

When the slave address and data direction bit have been transmitted and an acknowledge bit has been received, the SI bit is set, and the Status Register will show the status code. For master mode, the possible status codes ar e 40H, 48 H, or 38H. For slave mode, the possible status codes are 68H, 78H, or B0H. Refer to Table 75

User manual Rev. 01 — 1 December 2008 75 of 139

C Data Register (I2DAT). The SI bit must be cleared before

for details.

NXP Semiconductors

S R Aslave address

logic 0 = write logic 1 = read

from Master to Slave from Slave to Master

A = acknowledge (SDA LOW) A = not acknowledge (SDA HIGH) S = START condition

002aaa930

DATA DATA

data transferred

(n Bytes + acknowledge)

A A P

S R ASLA

logic 0 = write logic 1 = read

from Master to Slave from Slave to Master

002aaa931

DATA DATA

data transferred

(n Bytes + acknowledge)

A W ASLA DATA A PA RS

A = acknowledge (SDA LOW) A = not acknowledge (SDA HIGH) S = START condition P = STOP condition SLA = slave address RS = repeat START condition

Fig 33. Format of Master Receiver mode.

After a repeated START condition, I2C-bus may switch to the Master Transmitter Mode.

UM10310

P89LPC9321 User manual

Fig 34. A Master Receiver switches to Master Transmitter after sending Repeated Start.

11.6.3 Slave Receiver mode

In the Slave Receiver Mode, data bytes are received from a master transmitter. To initialize the Slave Receiver Mode, the user should write the slave address to the Slave Address Register (I2ADR) and the I follows:

Table 72. I2C Control register (I2CON - address D8h)

Bit 7 6 5 4 3 2 1 0

value- 10001- -

CRSEL is not used for slave mode. I2EN must be set = 1 to enable I2C function. AA bit must be set = 1 to acknowledge its own slave address or the general call address. STA, STO and SI are cleared to 0.

After I2ADR and I2CON are initialized, the interface waits until it is addressed by its own address or general address followed by the data dir ection bit which is 0(W). If the direction bit is 1(R), it will enter Slave Transmitter Mode. After the address and the direction bit have been received, the SI bit is set and a valid status code can be read from the Status Register(I2STAT). Refer to Table 76

- I2EN STA STO SI AA - CRSEL

C Control Register (I2CON) should be configured as

for the status codes and actions.

User manual Rev. 01 — 1 December 2008 76 of 139

NXP Semiconductors

S W Aslave address

logic 0 = write logic 1 = read

from Master to Slave from Slave to Master

A = acknowledge (SDA LOW) A = not acknowledge (SDA HIGH) S = START condition P = STOP condition RS = repeated START condition

002aaa932

DATA DATA

data transferred

(n Bytes + acknowledge)

A A/A P/RS

S R Aslave address

logic 0 = write logic 1 = read

from Master to Slave from Slave to Master

A = acknowledge (SDA LOW) A = not acknowledge (SDA HIGH) S = START condition P = STOP condition

002aaa933

DATA DATA

data transferred

(n Bytes + acknowledge)

A A P

Fig 35. Format of Slave Receiver mode.

11.6.4 Slave Transmitter mode

The first byte is received and handled as in the Slave Receiv er Mode . Howe ve r, in this mode, the direction bit will indicate that the transfer direction is reversed. Serial data is transmitted via P1.3/SDA while the serial clock is input through P1.2/SCL. START and STOP conditions are recognized as the beginning and end of a serial transfer. In a given application, the I

C hardware looks for its own slave address a nd the gener al call address. If one of these addresses is detected, an interrupt is requested. When the microcontrollers wishes to become the bus master , the hardware waits until the bus is free be fore the master mode is entered so that a possible slave action is not interrupted. If bus arbitration is lost in the master mode, the I slave address in the same serial transfer.

UM10310

P89LPC9321 User manual

C-bus may operate as a master and as a slave. In the slave mode, the

C-bus switches to the slave mode immediately and can detect its own

User manual Rev. 01 — 1 December 2008 77 of 139

Fig 36. Format of Slave Transmitter mode.

NXP Semiconductors

INTERNAL BUS

002aaa899

ADDRESS REGISTER

COMPARATOR

SHIFT REGISTER

I2ADR

ACK

BIT COUNTER /

ARBITRATION &

SYNC LOGIC

I2DAT

TIMING

AND

CONTROL

LOGIC

SERIAL CLOCK

GENERATOR

CCLK

interrupt

INPUT

FILTER

OUTPUT

STAGE

INPUT

FILTER

OUTPUT

STAGE

P1.3

P1.3/SDA

P1.2/SCL

P1.2

timer 1

overflow

CONTROL REGISTERS &

SCL DUTY CYCLE REGISTERS

I2CON

I2SCLH

I2SCLL

STATUS

DECODER

status bus

STATUS REGISTER

I2STAT

UM10310

P89LPC9321 User manual

Fig 37. I2C serial interface block diagram.

User manual Rev. 01 — 1 December 2008 78 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 73. Master Transmitter mode

Status code (I2STAT)

08H A START

10H A repeat START

18h SLA+W has been

20h SLA+W has been

28h Data byte in

Status of the I2C hardware

condition has been transmitted

transmitted; ACK has been received

transmitted; NOT-ACK has been received

I2DAT has been transmitted; ACK has been received

Application software response Next action taken by I2C to/from I2DAT to I2CON

STA STO SI AA

Load SLA+W x 0 0 x SLA+W will be transmitted;

Load SLA+W or Load SLA+R

Load data byte or000xData byte will be transmitted;

no I2DAT action or100xRepeated START will be

no I2DAT action or010xSTOP condition will be

no I2DAT action 110xSTOP condition followed by a

Load data byte or000xData byte will be transmitted;

no I2DAT action or100xRepeated START will be

no I2DAT action or010xSTOP condition will be

no I2DAT action 110xSTOP condition followed by a

Load data byte or000xData byte will be transmitted;

no I2DAT action or100xRepeated START will be

no I2DAT action or010xSTOP condition will be

no I2DAT action 110xSTOP condition followed by a

x 0 0 x As above; SLA+W will be

hardware

ACK bit will be received

transmitted; I to Master Receiver Mode

ACK bit will be received

transmitted;

transmitted; STO flag will be reset

START condition will be transmitted; STO flag will be reset.

ACK bit will be received

transmitted;

transmitted; STO flag will be reset

START condition will be transmitted; STO flag will be reset

ACK bit will be received

transmitted;

transmitted; STO flag will be reset

START condition will be transmitted; STO flag will be reset

C-bus switches

User manual Rev. 01 — 1 December 2008 79 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 73. Master Transmitter mode

Status code (I2STAT)

Status of the I2C hardware

30h Data byte in

I2DAT has been transmitted, NOT ACK has been received

38H Arbitration lost in

SLA+R/W or data bytes

Table 74. Master Receiver mode

Status code (I2STAT)

Status of the I2C hardware

08H A START

condition has been transmitted

10H A repeat START

condition has been transmitted

38H Arbitration lost in

NOT ACK bit

40h SLA+R has been

transmitted; ACK has been received

48h SLA+R has been

transmitted; NOT ACK has been received

…continued

Application software response Next action taken by I2C to/from I2DAT to I2CON

hardware

STA STO SI AA

Load data byte or000xData byte will be transmitted;

ACK bit will be received

no I2DAT action or100xRepeated START will be

transmitted;

no I2DAT action or010xSTOP condition will be

transmitted; STO flag will be reset

no I2DAT action110xSTOP condition followed by a

START condition will be transmitted. STO flag will be reset.

No I2DAT action or000xI

C-bus will be released; not addressed slave will be entered

No I2DAT action 100xA START condition will be

transmitted when the bus becomes free.

Application software response Next action taken by I2C hardware to/from I2DAT to I2CON

STA STO SI STA

Load SLA+R x 0 0 x SLA+R will be transmitted ; ACK bit

will be received

Load SLA+R or x 0 0 x As above

Load SLA+W SLA+W will be transmitted; I

C-bus will be switched to Master Transmitter Mode

no I2DAT action or000xI

C-bus will be released; it will enter

a slave mode

no I2DAT action 1 0 0 x A START condition will be

transmitted when the bus becomes free

no I2DAT action or0 0 0 0 Data byte will be received; NOT ACK

bit will be returned

no I2DAT action or0 0 0 1 Data byte will be received; ACK bit

will be returned

No I2DAT action or1 0 0 x Repeated START will be transmitted

no I2DAT action or0 1 0 x STOP condition will be transmitted;

STO flag will be reset

no I2DAT action or1 1 0 x STOP condition followed by a START

condition will be transmitted; STO flag will be reset

User manual Rev. 01 — 1 December 2008 80 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 74. Master Receiver mode

Status code (I2STAT)

50h Data byte has

58h Data byte has

Table 75. Slave Receiver mode

Status code (I2STAT)

60H Own SLA+W has

68H Arbitration lost in

70H General call

78H Arbitration lost in

80H Previously

Status of the I2C hardware

been received; ACK has been returned

been received; NACK has been returned

Status of the I2C hardware

been received; ACK has been received

SLA+R/Was master; Own SLA+W has been received, ACK returned

address(00H) has been received, ACK has been returned

SLA+R/W as master; General call address has been received, ACK bit has been returned

addressed with own SLA address; Data has been received; ACK has been returned

…continued

Application software response Next action taken by I2C hardware to/from I2DAT to I2CON

STA STO SI STA

Read data byte 0 0 0 0 Data byte will be received; NOT ACK

bit will be returned

read data byte 0 0 0 1 Data byte will be received; ACK bit

will be returned

Read data byte or 1 0 0 x R epeated START will be transmitted; read data byte or 0 1 0 x STOP condition will be transmitted;

STO flag will be reset

read data byte 1 1 0 x STOP condition followed by a ST ART

condition will be transmitted; STO flag will be reset

Application software response Next action taken by I2C to/from I2DAT to I2CON

STA STO SI AA

no I2DAT action orx000Data byte will be received and NOT

no I2DAT action x001Data byte will be received and ACK

No I2DAT action orx000Data byte will be received and NOT

no I2DAT action x001Data byte will be received and ACK

No I2DAT action orx000Data byte will be received and NOT

no I2DAT action x001Data byte will be received and ACK

no I2DAT action orx000Data byte will be received and NOT

no I2DAT action x001Data byte will be received and ACK

Read data byte orx000Data byte will be received and NOT

read data bytex001Data byte will be received; ACK bit

hardware

ACK will be returned

will be returned

ACK will be returned

will be returned

ACK will be returned

will be returned

ACK will be returned

will be returned

ACK will be returned

will be returned

User manual Rev. 01 — 1 December 2008 81 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 75. Slave Receiver mode

Status code (I2STAT)

88H Previously

90H Previously

98H Previously

Status of the I2C hardware

addressed with own SLA address; Data has been received; NACK has been returned

addressed with General call; Data has been received; ACK has been returned

addressed with General call; Data has been received; NACK has been returned

…continued

Application software response Next action taken by I2C to/from I2DAT to I2CON

STA STO SI AA

Read data byte or0000Switched to not addressed SLA

read data byte or

read data byte1001Switched to not addressed SLA

Read data byte orx000Data byte will be received and NOT

read data bytex001Data byte will be received and ACK

Read data byte0000Switched to not addressed SLA

read data byte0001Switched to not addressed SLA

read data byte1000Switched to not addressed SLA

read data byte1001Switched to not addressed SLA

0001Switched to not addressed SLA

1000Switched to not addressed SLA

hardware

mode; no recognition of own SLA or general address

mode; Own SLA will be recognized; general call address will be recognized if I2ADR.0 = 1

mode; no recognition of own SLA or General call address. A START condition will be transmitted when the bus becomes free

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1. A START condition will be transmitted when the bus becomes free.

ACK will be returned

will be returned

mode; no recognition of own SLA or General call address

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1.

mode; no recognition of own SLA or General call address. A START condition will be transmitted when the bus becomes free.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1. A START condition will be transmitted when the bus becomes free.

User manual Rev. 01 — 1 December 2008 82 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 75. Slave Receiver mode

Status code (I2STAT)

A0H A STOP condition

Table 76. Slave Transmitter mode

Status code (I2STAT)

A8h Own SLA+R has

B0h Arbitration lost in

B8H Data byte in

Status of the I2C hardware

or repeated START condition has been received while still addressed as SLA/REC or SLA/TRX

Status of the I2C hardware

been received; ACK has been returned

SLA+R/W as master; Own SLA+R has been received, ACK has been returned

I2DAT has been transmitted; ACK has been received

…continued

Application software response Next action taken by I2C to/from I2DAT to I2CON

STA STO SI AA

No I2DAT action0000Switched to not addressed SLA

no I2DAT action0001Switched to not addressed SLA

no I2DAT action1000Switched to not addressed SLA

no I2DAT action1001Switched to not addressed SLA

Application software response Next action taken by I2C to/from I2DAT to I2CON

STA STO SI AA

Load data byte orx000Last data byte will be transmitted

load data bytex001Data byte will be transmitted; ACK

Load data byte orx000Last data byte will be transmitted

load data bytex001Data byte will be transmitted; ACK

Load data byte orx000Last data byte will be transmitted

load data bytex001Data byte will be transmitted; ACK

hardware

mode; no recognition of own SLA or General call address

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1.

mode; no recognition of own SLA or General call address. A START condition will be transmitted when the bus becomes free.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1. A START condition will be transmitted when the bus becomes free.

hardware

and ACK bit will be received

will be received

and ACK bit will be received

bit will be received

and ACK bit will be received

will be received

User manual Rev. 01 — 1 December 2008 83 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 76. Slave Transmitter mode

Status code (I2STAT)

C0H Data byte in

C8H Last data byte in

Status of the I2C hardware

I2DAT has been transmitted; NACK has been received

I2DAT has been transmitted (AA = 0); ACK has been received

…continued

Application software response Next action taken by I2C to/from I2DAT to I2CON

STA STO SI AA

No I2DAT action or0000Switched to not addressed SLA

no I2DAT action or0001Switched to not addressed SLA

no I2DAT action or1000Switched to not addressed SLA

no I2DAT action 1001Switched to not addressed SLA

No I2DAT action or0000Switched to not addressed SLA

no I2DAT action or0001Switched to not addressed SLA

no I2DAT action or1000Switched to not addressed SLA

no I2DAT action 1001Switched to not addressed SLA

hardware

mode; no recognition of own SLA or General call address.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1.

mode; no recognition of own SLA or General call address. A START condition will be transmitted when the bus becomes free.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1. A STAR T condition will be transmitted when the bus becomes free.

mode; no recognition of own SLA or General call address.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1.

mode; no recognition of own SLA or General call address. A START condition will be transmitted when the bus becomes free.

mode; Own slave address will be recognized; General call address will be recognized if I2ADR.0 = 1. A STAR T condition will be transmitted when the bus becomes free.

12. Serial Peripheral Interface (SPI)

The P89LPC9321 provides another high-speed serial communication interface, the SPI interface. SPI is a full-duplex, high-speed, synchronous communication bus with two operation modes: Master mode and Slave mode. Up to 3 Mbit/s can be supported in either Master or Slave mode. It has a Transfer Completion Flag and Write Collision Flag Protection.

User manual Rev. 01 — 1 December 2008 84 of 139

NXP Semiconductors

002aaa900

CPU clock

DIVIDER

BY 4, 16, 64, 128

SELECT

CLOCK LOGIC

SPI CONTROL REGISTER

READ DATA BUFFER

8-BIT SHIFT REGISTER

SPI CONTROL

SPI STATUS REGISTER

SPR1

SPIF

WCOL

SPR0

SPI clock (master)

CONTROL

LOGIC

MISO P2.3

MOSI P2.2

SPICLK P2.5

SS P2.4

SPI

interrupt

request

internal

data

bus

SSIG

SPEN

MSTR

DORD

MSTR

CPHA

CPOL

SPR1

SPR0

MSTR

SPEN

clock

UM10310

P89LPC9321 User manual

Fig 38. SPI block diagram.

User manual Rev. 01 — 1 December 2008 85 of 139

The SPI interface has four pins: SPICLK, MOSI, MISO and SS:

• SPICLK, MOSI and MISO are typically tied together between two or more SPI

devices. Data flows from master to slave on the MOSI (Master Out Slave In) pin and flows from slave to master on the MISO (Master In Slave Out) pin. The SPICLK signal is output in the master mode and is input in the slave mode. If the SPI system is disabled, i.e. SPEN (SPCTL.6) = 0 (reset value), these pins are configured for port functions.

• SS is the optional slave select pin. In a typical configuration, an SPI master asserts

one of its port pins to select one SPI devi ce as the curr ent sla ve. An SPI slave device uses its SS following conditions are true:

– If the SPI system is disabled, i.e. SPEN (SPCTL.6) = 0 (reset value) – If the SPI is configured as a master, i.e., MSTR (SPCTL.4) = 1, and P2.4 is

configured as an output (via the P2M1.4 and P2M2.4 SFR bits);

– If the SS

functions.

Note that even if the SPI is configured as a master (MSTR = 1), it can still be converted to a slave by driving the SS happen, the SPIF bit (SPSTAT.7) will be set (see Section 12.4 “

Typical connections are shown in Figure 39

T able 77. SPI Control register (SPCTL - address E2h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol SSIG SPEN DORD MSTR CPOL CPHA SPR1 SPR0 Reset00000100

pin to determine whether it is selected. The SS is ignored if any of the

pin is ignored, i.e. SSIG (SPCTL.7) bit = 1, this pin is configured for port

pin low (if P2.4 is configured as input and SSIG = 0) . Should this

to Figure 41.

Mode change on SS”)

NXP Semiconductors

Table 78. SPI Control register (SPCTL - address E2h) bit description

Bit Symbol Description

0 SPR0 SPI Clock Rate Select 1 SPR1

2 CPHA SPI Clock PHAse select (see Figure 42 to Figure 45):

3 CPOL SPI Clock POLarity (see Figure 42

4 MSTR Master/Slave mode Select (see Table 82). 5 DORD SPI Data ORDer.

6 SPEN SPI Enable.

7 SSIG SS IGnore.

UM10310

P89LPC9321 User manual

SPR1, SPR0:

CCLK

00 — 01 — 10 — 11 —

1 — Data is driven on the leading edge of SPICLK, and is sampled on the trailing

edge. 0 — Data is driven when SS

SPICLK, and is sampled on the leading edge. (Note: If SSIG = 1, the operation is not defined.

1 — SPICLK is high when idle. The leading edge of SPICLK is the falling edge and the trailing edge is the rising edge.

0 — SPICLK is low when idle. The leading edge of SPICLK is the rising edge and the trailing edge is the falling edge.

1 — The LSB of the data word is transmitted first. 0 — The MSB of the data word is transmitted first.

1 — The SPI is enabled. 0 — The SPI is disabled and all SPI pins will be port pins.

1 — MSTR (bit 4) decides whether the device is a master or slave. 0 — The SS

used as a port pin (see Table 82

⁄

CCLK

⁄

CCLK

⁄

CCLK

⁄

128

is low (SSIG = 0) and changes on the trailing edge of

to Figure 45):

pin decides whether the device is master or slave. The SS pin can be

Table 79. SPI Status register (SPSTAT - address E1h) bit allocation

Bit 7 6 5 4 3 2 1 0

SymbolSPIFWCOL-----Reset00xxxxxx

Table 80. SPI Status register (SPSTAT - address E1h) bit description

Bit Symbol Description

0:5 - reserved 6 WCOL SPI Write Collision Flag. The WCOL bit is set if the SPI data register, SPDA T, is

written during a data transfer (see Section 12.5 “

Write collision”). The WCOL flag

is cleared in software by writing a logic 1 to this bit.

7 SPIF SPI Transfer Completion Flag. When a serial transfer finishes, the SPIF bit is set

and an interrupt is generated if both the ESPI (IEN1.3) bit and the EA bit are set. If

is an input and is driven low when SPI is in master mode, and SSIG = 0, this bit

SS will also be set (see Section 12.4 “

Mode change on SS”). The SPIF flag is cleared

in software by writing a logic 1 to this bit.

User manual Rev. 01 — 1 December 2008 86 of 139

NXP Semiconductors

002aaa901

master slave

8-BIT SHIFT

SPI CLOCK

GENERATOR

8-BIT SHIFT

MISO

MOSI

SPICLK

PORT

MISO

MOSI

SPICLK

002aaa902

master slave

8-BIT SHIFT

SPI CLOCK

GENERATOR

SPI CLOCK

GENERATOR

8-BIT SHIFT

MISO

MOSI

SPICLK

MISO

MOSI

SPICLK

Table 81. SPI Data register (SPDAT - address E3h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol MSB LSB Reset00000000

UM10310

P89LPC9321 User manual

Fig 39. SPI single master single slave configuration.

In Figure 39, SSIG (SPCTL.7) for the slave is logic 0, and SS is used to select the slave. The SPI master can use any port pin (including P2.4/SS

Fig 40. SPI dual device configuration, where either can be a master or a slave.

Figure 40 shows a case where two devices are connected to each other and either device

can be a master or a slave. When no SPI operation is occurring, both can be configured as masters (MSTR = 1) with SSIG cleared to 0 and P2.4 (SS quasi-bidirectional mode. When a device initiates a transfer, it can configure P2.4 as an output and drive it low, forcing a mode change in the other device (see Section 12.4

“Mode change on SS”) to slave.

User manual Rev. 01 — 1 December 2008 87 of 139

) to drive the SS pin.

) configured in

NXP Semiconductors

002aaa903

master slave

8-BIT SHIFT

SPI CLOCK

GENERATOR

8-BIT SHIFT

MISO

MOSI

SPICLK

port

MISO

MOSI

SPICLK

slave

8-BIT SHIFT

MISO

MOSI

SPICLK

UM10310

P89LPC9321 User manual

Fig 41. SPI single master multiple slaves configuration.

In Figure 41, SSIG (SPCTL.7) bits for the slaves are logic 0, and the slaves are selected by the corresponding SS P2.4/SS

) to drive the SS pins.

signals. The SPI master can use any port pin (including

12.1 Configuring the SPI

Table 82 shows configuration for the master/slave modes as well as usages and

directions for the modes.

Table 82. SPI master and slave selection

SPEN SSIG SS Pin MSTR Master

0xP2.4

1 0 0 0 Slave output input input Selected as slave. 1 0 1 0 Slave Hi-Z input input Not selected. MISO is high-impedance to avoid

1001 (->

or Slave Mode

[1]

xSPI

Disabled

Slave output input input P2.4/SS is configured as an input or

[2]

MISO MOSI SPICLK Remarks

[1]

P2.3

[1]

P2.2

P2.5

[1]

SPI disabled. P2.2, P2.3, P2.4, P2.5 are used as port pins.

bus contention.

quasi-bidirectional pin. SSIG is 0. Selected externally as slave if SS is selected and is driven low. The MSTR bit will be cleared to logic 0 when SS

becomes low.

User manual Rev. 01 — 1 December 2008 88 of 139

NXP Semiconductors

Table 82. SPI master and slave selection …continued

SPEN SSIG SS Pin MSTR Master

or Slave Mode

1011 Master

(idle)

Master (active)

[1]

11P2.4 11P2.4

[1] Selected as a port function [2] The MSTR bit changes to logic 0 automatically when SS

0 Slave output input input

[1]

1 Master input output output

MISO MOSI SPICLK Remarks

input Hi-Z Hi-Z MOSI and SPICLK are at high-impedance to

12.2 Additional considerations for a slave

UM10310

P89LPC9321 User manual

avoid bus contention when the MAster is idle. The application must pull-up or pull-down SPICLK (depending on CPOL - SPCTL.3) to avoid a floating SPICLK.

output ou tp ut MOSI and SPICLK are push-pull when the

Master is active.

becomes low in input mode and SSIG is logic 0.

When CPHA equals zero, SSIG must be logic 0 and the SS pin must be negated and reasserted between each successive serial byte. If the SPDA T register is wr itten while SS is active (low), a write collision error results. The operation is undefined if CPHA is logic 0 and SSIG is logic 1.

When CPHA equals one, SSIG may be set to logic 1. If SSIG = 0, the SS active low between successive transfers (can be tied low at all times). This format is sometimes preferred in systems having a single fixed master and a single slave driving the MISO data line.

12.3 Additional considerations for a master

In SPI, transfers are always initiated by the master. If the SPI is enabled (SPEN = 1) and selected as master, writing to the SPI data register by the master starts the SPI clock generator and data transfer. The data will start to appear on MOSI about one half SPI bit-time to one SPI bit-time after data is written to SPDAT.

Note that the master can select a slave by driving the SS low. Data written to the SPDAT register of the master is shifted out of the MOSI pin of the master to the MOSI pin of the slave, at the same time the data in SPDAT register in slave side is shifted out on MISO pin to the MISO pin of the master.

After shifting one byte, the SPI clock generator stop s, setting the transfer completion flag (SPIF) and an interrupt will be created if the SPI interrupt is enabled (ESPI, or IEN1.3 = 1). The two shift registers in the master CPU and slave CPU can be considered as one distributed 16-bit circular shift register. When data is shifted from the master to the slave, data is also shifted in the opposite direction simultaneously. This means that during one shift cycle, data in the master and the slave are interchanged.

pin may remain

pin of the corresponding device

12.4 Mode change on SS

If SPEN = 1, SSIG = 0 and MSTR = 1, the SPI is enabled in master mode. The SS pin can be configured as an input (P2M2.4, P2M1.4 = 00) or q uasi-bidi rectional (P2M2 .4, P2M1.4 = 01). In this case, another master can drive this pin low to select this device as an SPI

User manual Rev. 01 — 1 December 2008 89 of 139

NXP Semiconductors

slave and start sending data to it. To avoid bus contention, the SPI becomes a slave . As a result of the SPI becoming a slave, the MOSI and SPICLK pins are forced to be an input and MISO becomes an output.

The SPIF flag in SPSTAT is set, and if the SPI interrupt is enabled, an SPI interrupt will occur.

User software should always check the MSTR bit. If this bit is cleared by a slave select and the user wants to continue to use the SPI as a master , the user must set the MSTR bit again, otherwise it will stay in slave mode.

12.5 Write collision

The SPI is single buffered in the transmit direction and double buffered in the receive direction. New data for transmission can not be written to the shift register until the previous transaction is complete. The WCOL (SPSTAT.6) bit is set to indicate data collision when the data register is written during transmission. In this case, the data currently being transmitted will continue to be transmitted, but the new data, i.e., the one causing the collision, will be lost.

UM10310

P89LPC9321 User manual

While write collision is detected for both a master or a slave, it is uncommon for a master because the master has full control of the transfer in progress. The slave, however , has no control over when the master will initiate a transfer and therefore collision can occur.

For receiving data, received data is transferred into a parallel read data buffer so that the shift register is free to accept a second character. However, the received character must be read from the Data Register before the next character has been completely shifted in. Otherwise. the previous data is lost.

WCOL can be cleared in software by writing a logic 1 to the bit.

12.6 Data mode

Clock Phase Bit (CPHA) allows the user to set the edges for sampling and changing data. The Clock Polarity bit, CPOL, allows the user to set the clock polarity. Figure 42

Figure 45

show the different settings of Clock Phase bit CPHA.

User manual Rev. 01 — 1 December 2008 90 of 139

NXP Semiconductors

1 2 3 4 5 6 7 8

MSB

LSB

DORD = 0

DORD = 1

LSB

MSB

LSB

DORD = 0

DORD = 1

LSB

MSB

(1)

002aaa934

Clock cycle

SPICLK (CPOL = 0)

SPICLK (CPOL = 1)

MOSI (input)

MISO (output)

SS (if SSIG bit = 0)

UM10310

P89LPC9321 User manual

(1) Not defined

Fig 42. SPI slave transfer format with CPHA = 0.

User manual Rev. 01 — 1 December 2008 91 of 139

NXP Semiconductors

1 2 3 4 5 6 7 8

MSB

LSB

DORD = 0

DORD = 1

LSB

MSB

LSB

DORD = 0

DORD = 1

LSB

MSB

002aaa935

Clock cycle

SPICLK (CPOL = 0)

SPICLK (CPOL = 1)

MOSI (input)

MISO (output)

SS (if SSIG bit = 0)

(1)

UM10310

P89LPC9321 User manual

(1) Not defined

Fig 43. SPI slave transfer format with CPHA = 1.

User manual Rev. 01 — 1 December 2008 92 of 139

NXP Semiconductors

1 2 3 4 5 6 7 8

MSB

LSB

MSB

LSB

DORD = 0

DORD = 1

LSB

MSB

002aaa936

Clock cycle

SPICLK (CPOL = 0)

SPICLK (CPOL = 1)

MOSI (input)

MISO (output)

SS (if SSIG bit = 0)

DORD = 0

DORD = 1

UM10310

P89LPC9321 User manual

(1) Not defined

Fig 44. SPI master transfer format with CPHA = 0.

User manual Rev. 01 — 1 December 2008 93 of 139

NXP Semiconductors

1 2 3 4 5 6 7 8

MSB

LSB

MSB

LSB

DORD = 0

DORD = 1

LSB

MSB

002aaa937

Clock cycle

SPICLK (CPOL = 0)

SPICLK (CPOL = 1)

MOSI (input)

MISO (output)

SS (if SSIG bit = 0)

DORD = 0

DORD = 1

UM10310

P89LPC9321 User manual

(1) Not defined

Fig 45. SPI master transfer format with CPHA = 1.

12.7 SPI clock prescaler select

The SPI clock prescaler selection uses the SPR1-SPR0 bits in the SPCTL register (see

Table 78

13. Analog comparators

13.1 Comparator configuration

Two analog comparators are provided on the P89LPC9321. Input and output options allow use of the comparators in a number of different configurations. Comparator operation is such that the output is a logic 1 (which may be read in a register and/or routed to a pin) when the positive input (one of two selectable pins) is greater than the negative input (selectable from a pin or an internal reference voltage). Otherwise the output is a zero. Each comparator may be configured to cause an interrupt when the output value changes.

The comparators inputs can be amplified by using PGA1 module. The PGA1 can supply gain factors of 2x, 4x, 8x, or 16x, eliminating the need for external opamps in the end application. Refer to Section 13.7 “

Each comparator has a control register , CMP1 for comp arator 1 and CMP2 for comparator

2. The control registers are identical and are shown in Table 84

Programmable Gain Amplifier (PGA)” for PGA details.

User manual Rev. 01 — 1 December 2008 94 of 139

NXP Semiconductors

The overall connections to both comparators are shown in Figure 46. There are eight possible configurations for each comparator, as determined by the control bits in the corresponding CMPn register: CPn, CNn, and OEn. These configurations are shown in

Figure 47

When each comparator is first enabled, the comparat or outp u t an d in te r ru pt flag ar e no t guaranteed to be stable for 10 microseconds. The corresponding comparator interrupt should not be enabled during that time, and the comparator inter rupt flag mu st be cl eared before the interrupt is enabled in order to prevent an immediate interrupt service.

T able 83. Comparator Control register (CMP1 - address ACh, CMP2 - address ADh) bit

Bit 7 6 5 4 3 2 1 0

Symbol - - CEn CPn CNn OEn COn CMFn Resetxx000000

T able 84. Comparator Control register (CMP1 - address ACh, CMP2 - address ADh) bit

Bit Symbol Description

0 CMFn Comparator interrupt flag. This bit is set by hardware whenever the comparator

1 COn Comparator output, synchronized to the CPU clock to allow reading by software. 2 OEn Output enable. When logic 1, the comparator output is connected to the CMPn pin

3 CNn Comparator negative input select. When logic 0, the comparator reference pin

4 CPn Comparator positive input select. When logic 0, CINnA is selected as the positive

5 CEn Comparator enable. When set, the corresponding comparator function is enabled.

6:7 - reserved

UM10310

P89LPC9321 User manual

allocation

description

output COn changes state. This bit will cause a hardware interrupt if enabled. Cleared by software.

if the comparator is enabled (CEn = 1). This output is asynchronous to the CPU clock.

CMPREF is selected as the negative comparator input. When logic 1, the internal comparator reference, V

comparator input. When logic 1, CINnB is selected as the positive comparator input.

Comparator output is stable 10 microseconds after CEn is set.

, is selected as the negative comparator input.

REF

User manual Rev. 01 — 1 December 2008 95 of 139

NXP Semiconductors

comparator 1

CP1

CN1

(P0.4) CIN1A

(P0.3) CIN1B

(P0.5) CMPREF

ref(bg)

OE1

change detect

CO1

CMF1

002aad561

CMP1 (P0.6)

change detect

CMF2

comparator 2

OE2

CO2

CMP2 (P0.0)

CP2

CN2

(P0.2) CIN2A

(P0.1) CIN2B

PGA1

Fig 46. Comparator input and output connections.

UM10310

P89LPC9321 User manual

13.2 Internal reference voltage

An internal reference voltage, V comparator input pin is used. Please refer to the P89LPC9321 data sheet for specifications.

13.3 Comparator input pins

Comparator input and reference pins maybe be used as either digital I/O or as inputs to the comparator. When used as digital I/O these pins are 5 V tolerant. However, when selected as comparator input signals in CMPn lower voltage limits apply. Please refer to the P89LPC9321 data sheet for specifications.

13.4 Comparator interrupt

Each comparator has an interrupt flag CMFn cont ained in its configuration register. This flag is set whenever the comparator output changes state. The flag may be polled by software or may be used to generate an interrupt. The two comparators use one common interrupt vector. The interrupt will be generated when the interrupt enable bit EC in the IEN1 register is set and the interrupt system is enabled via the EA bit in the IEN0 register. If both comparators enable interrupts, after entering the interrupt service routine, the user will need to read the flags to determine which comparator caused the interrupt.

When a comparator is disabled the comparator’s output, COx, goes high. If the comparator output was low and then is disabled, the resulting transition of the comparator output from a low to high state will set the comparator flag, CMFx. This will cause an interrupt if the comparator interrupt is enabled. The user should therefore disable the comparator interrupt prior to disabling the comparator. Additionally, the user should clear the comparator flag, CMFx, after disabling the comparator.

, may supply a default reference when a single

ref(bg)

User manual Rev. 01 — 1 December 2008 96 of 139

NXP Semiconductors

CINnA

CMPREF

002aaa618

COn

CINnA

CMPREF

002aaa620

COn

CMPn

CINnA

REF

(1.23 V)

002aaa621

COn

CINnA

REF

(1.23 V)

002aaa622

COn

CMPn

CINnB

CMPREF

002aaa623

COn

CINnB

CMPREF

002aaa624

COn

CMPn

CINnB

REF

(1.23 V)

002aaa625

COn

CINnB

REF

(1.23 V)

002aaa626

COn

CMPn

13.5 Comparators and power reduction modes

Either or both comparators may remain enabled when Power-down mode or Idle mode is activated, but both comparators are disabled automatically in Total Power-down mode.

If a comparator interrupt is enabled (except in Total Power-down mode), a change of the comparator output state will generate an interrupt and wake-up the processor. If the comparator output to a pin is enabled, the p in should be conf igured in the push-pull m ode in order to obtain fast switching times while in Power-down mode. The reason is that with the oscillator stopped, the temporary strong pull-up that normally occurs during switching on a quasi-bidirectional port pin does not take place.

Comparators consume power in Power-down mode and Idle mode, as well as in the normal operating mode. This should be taken into consideration when system power consumption is an issue. To minimize power consumption, the user can power-down the comparators by disabling the comparators and setting PCONA.5 to logic 1, or simply putting the device in Total Power-down mode.

UM10310

P89LPC9321 User manual

a. CPn, CNn, OEn = 0 0 0 b. CPn, CNn, OEn = 0 0 1

c. CPn, CNn, OEn = 0 1 0 d. CPn, CNn, OEn = 0 1 1

e. CPn, CNn, OEn = 1 0 0 f. CPn, CNn, OEn = 1 0 1

g. CPn, CNn, OEn = 1 1 0 h. CPn, CNn, OEn = 1 1 1

Fig 47. Comparator configurations. (Suppose PGA1 is disabled, or gain = 1)

13.6 Comparators configuration example

The code shown below is an example of initializing one comparator. Comparator 1 is configured to use the CIN1A and CMPREF inputs, outputs the comparator result to the CMP1 pin, and generates an interrupt when the comparator output changes.

CMPINIT:

MOV PT0AD,#030h ;Disable digital INPUTS on CIN1A, CMPREF. ANL P0M2,#0CFh ;Disable digital OUTPUTS on pins that are used ORL P0M1,#030h ;for analog functions: CIN1A, CMPREF. MOV CMP1,#024h ;Turn on comparator 1 and set up for:

User manual Rev. 01 — 1 December 2008 97 of 139

NXP Semiconductors

002aae212

CIN2B CIN2A CIN1B CIN1A

PGA1 TRIM

REGISTERS

MUX

PGASEL11,

PGASEL10

PGA11, PGA10

PGA1 GAIN

PGATRIM1

The interrupt routine used for the comparator must clear the interrupt flag (CMF1 in this case) before returning.

13.7 Programmable Gain Amplifier (PGA)

PGA1 is integrated to amplify the comparators inputs. A single channel can be selected for amplification. The block diagram of PGA1 is shown in Figure 48

UM10310

P89LPC9321 User manual

;Positive input on CIN1A. ;Negative input from CMPREF

pin.

;Output to CMP1 pin enabled. CALL delay10us ;The comparator needs at least 10 microseconds before use. ANL CMP1,#0FEh ;Clear comparator 1 interrupt flag. SETB EC ;Enable the comparator interrupt, SETB EA ;Enable the interrupt system (if needed).

RET ;Return to caller.

Fig 48. PGA1 block diagram

Register PGACON1 and PGACON1B are used for PGA1 configuration. The gain of PGA1 can be programmable to 2, 4, 8 or 16 by configuring PGAG11 and PGAG10 bits. PGA is enabled by setting ENPGA1 bit. If ENPGA1 is cleared, PGA1 is disabled and bypassed, which means the PGA1 gain value is 1.

Four external input signals are selected by configuring PGASEL11 and PGASEL10 bits. PGA offset voltage is used to guarantee the linearity of PGA output. When enable

PGAENOFFx bit in register PGACONxB, PGA output will be the PGA input plus offset voltage. PGA input can be grounded by setting PGATRIMx bit.

4-bit trim value is used to provide the PGA offset voltage in PGA trim registers PGAxTRIM2X4X and PGAxTRIM8X16X. End users application can write to PGA trim registers to adjust PGA offset voltage. Increasing 4-bit trim value will increase the corresponding PGA offset voltage. During reset, 4-bits trim value is initialized to a factory pre-programmed value. To guarantee the linearity of PGA output, it is recommended not to change the PGA trim registers.

User manual Rev. 01 — 1 December 2008 98 of 139

NXP Semiconductors

UM10310

P89LPC9321 User manual

Table 85. PGA trim register

PGAxTRIM2X4X[3:0] trim value for 2x gain value PGAxTRIM2X4X[7:4] trim value for 4x gain value PGAxTRIM8X16X[3:0] trim value for 8x gain value PGAxTRIM8X16X[7:4] trim value for16x gain value

If PGA is enabled, it will consume power. Power can be reduced by disabling the PGA. PGA can be disabled via clearing ENPGAx bit.

In Power-down mode or Total Power-down mode, PGA does not function.

Table 86. PGA1 Control register (PGACON1 - address FFE1h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol ENPGA1 PGASEL11 PGASEL10 PGATRIM1 - - PGAG11 PGAG10 Reset00000000

Table 87. PGA1 Control reg ister (PGACON1 - address FFE1h) bit description

Bit Symbol Description

1:0 PGAG11, PGAG10 PGA Gain selection bits.

00 : Gain = 2 01 : Gain = 4 10 : Gain = 8

11 : Gain = 16 3:2 - reserved 4 PGATRIM1 If set, PGA1 is grounded. If cleared, normal operation mode. 6:5 PGASEL11,

PGA input channel selection

PGASEL10

00 : CIN2B using PGA

01 : CIN2A using PGA

10 : CIN1B using PGA

11 : CIN1A using PGA 7 ENPGA1 PGA1 enable. If set, enable PGA1. If cleared, disable PGA1.

Table 88. PGA1 Control register B (PGACON1B - address FFE4h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol-------PGAENOF

Reset00000000

Table 89. PGA1 Control regi ster B (PGACON1B - address FFE4h) bit description

Bit Symbol Description

0 PGAENOFF1 PGA offset voltage enable bit. When set, enable the offset voltage on the PGA. 1:7 - Reserved

User manual Rev. 01 — 1 December 2008 99 of 139

NXP Semiconductors

14. Keypad interrupt (KBI)

The Keypad Interrupt function is intended primarily to allow a single interrupt to be generated when Port 0 is equal to or not equal to a certain pattern. This function can be used for bus address recognition or keypad recognition. The user can configure the port via SFRs for different tasks.

There are three SFRs used for this function. The Keypad Interrupt Mask Register (KBMASK) is used to define which input pins connected to Port 0 are enabled to trigger the interrupt. The Keypad Pattern Register (KBPATN) is used to define a pattern that is compared to the value of Port 0. The Keypad Interrupt Flag (KBIF) in the Keypad Interrupt Control Register (KBCON) is set when the condition is matched while the Keypad Interrupt function is active. An interrupt will be generated if it has been enabled by setting the EKBI bit in IEN1 register and EA = 1. The PATN_SEL bit in the Keypad Interrupt Control Register (KBCON) is used to define equal or not-equal for the comparison.

In order to use the Keypad Interrupt as an original KBI function like in the 87LPC76x series, the user needs to set KBPATN = 0FFH and PATN_SEL = 0 (not equal), th en any key connected to Port0 which is enabled by KBMASK register is will cause the hardware to set KBIF = 1 and generate an interrupt if it has been enabled. The interrupt may be used to wake-up the CPU from Idle or Power-down modes. This feature is particularly useful in handheld, battery powered systems that need to carefully manage power consumption yet also need to be convenient to use.

UM10310

P89LPC9321 User manual

In order to set the flag and cause an interrupt, the pattern on Port 0 must be held longer than 6 CCLKs

Table 90. Keypad Pattern register (KBPATN - address 93h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol KBPATN.7 KBPATN.6 KBPATN.5 KBPATN.4 KBPATN.3 KBPATN.2 KBPATN.1 KBPATN.0 Reset11111111

Table 91. Keypad Pattern register (KBPATN - address 93h ) bit description

Bit Symbol Access Description

0:7 KBPATN.7:0 R/W Pattern bit 0 - bit 7

Table 92. Keypad Control register (KBCON - address 94h) bit allocation

Bit 7 6 5 4 3 2 1 0

Symbol------PATN_SELKBIF Resetxxxxxx00

Table 93. Keypad Control register (KBCON - address 94h) bit description

Bit Symbol Access Description

0 KBIF R/W Keypad Interrupt Flag. Set when Port 0 matches user defined conditions specified in KBP ATN,

1 PATN_SEL R/W Pattern Matching Polarity selection. When set, Port 0 has to be equal to the user-defined

2:7 - - reserved

KBMASK, and PATN_SEL. Needs to be cleared by software by writing logic 0.

Pattern in KBPATN to generate the interrupt. When clear, Port 0 has to be not equal to the value of KBPATN register to generate the interrupt.

User manual Rev. 01 — 1 December 2008 100 of 139

NXP Semiconductors P89LPC932 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1. Introduction

1.1 Pin configuration

1.2 Pin description

1.3 Functional diagram

1.4 Block diagram

1.5 Special function registers

1.6 Memory organization

2. Clocks

2.1 Enhanced CPU

2.2 Clock definitions

2.2.1 Oscillator Clock (OSCCLK)

2.3 External crystal oscillator option

2.3.1 Low speed oscillator option

2.3.2 Medium speed oscillator option

2.3.3 High speed oscillator option

2.4 Clock output

2.5 On-chip RC oscillator option

2.6 Watchdog oscillator option

2.7 External clock input option

2.8 Clock sources switch on the fly

2.9 Oscillator Clock (OSCCLK) wake-up delay

2.10 CPU Clock (CCLK) modification: DIVM register

2.1 1 Low power select

3. Interrupts

3.1 Interrupt priority structure

3.2 External Interrupt pin glitch suppression

4. I/O ports

4.1 Port configurations

4.2 Quasi-bidirectional output configuration

4.3 Open drain output configuration

4.4 Input-only configuration

4.5 Push-pull output configuration

4.6 Port 0 and Analog Comparator functions

4.7 Additional port features

5. Power monitoring functions

5.1 Brownout detection

5.2 Power-on detection

5.3 Power reduction modes

6. Reset

6.1 Reset vector

7. Timers 0 and 1

7.1 Mode 0

7.2 Mode 1

7.3 Mode 2

7.4 Mode 3

7.5 Mode 6

7.6 Timer overflow toggle output

8. Real-time clock system timer

8.1 Real-time clock source

8.2 Changing RTCS1/RTCS0

8.3 Real-time clock interrupt/wake-up

8.3.1 Real-time clock read back

8.4 Reset sources affecting the Real-time clock

9. Capture/Compare Unit (CCU)

9.1 CCU Clock (CCUCLK)

9.2 CCU Clock prescaling

9.3 Basic timer operation

9.4 Output compare

9.5 Input capture

9.6 PWM operation

9.7 Alternating output mode

9.8 Synchronized PWM register update

9.9 HALT

9.10 PLL operation

9.11 CCU interrupt structure

10. UART

10.1 Mode 0

10.2 Mode 1

10.3 Mode 2

10.4 Mode 3

10.5 SFR space

10.6 Baud Rate generator and selection

10.7 Updating the BRGR1 and BRGR0 SFRs

10.8 Framing error

10.9 Break detect

10.10 More about UART Mode 0
