NXP BAS 21 NXP Datasheet

DATA SH EET

ook, halfpage

DISCRETE SEMICONDUCTORS

M3D088

BAS19; BAS20; BAS21

General purpose diodes

Product data sheet
Supersedes data of 1999 May 26

2003 Mar 20

NXP Semiconductors Product data sheet

General purpose diodes BAS19; BAS20; BAS21

FEATURES

• Small plastic SMD package

• Switching speed: max. 50 ns

• General application

• Continuous reverse voltage: max. 100 V; 150 V; 200 V

• Repetitive peak reverse voltage: max. 120 V; 200 V;

V

250

• Repetitive peak forward current: max. 625 mA.

APPLICATIONS

• General purpose switching in e.g. surface mounted
circuits.

DESCRIPTION

The BAS19, BAS20 and BAS21 are general purpose
diodes fabricated in planar technology, and encapsulated
in a small SOT23 plastic SMD package.

MARKING

T YPE NUMBER MARKING CODE

(1)

BAS19 JP∗
BAS20 JR∗
BAS21 JS∗

PINNING

PIN DESCRIPTION

1 anode
2 not connected
3 cathode

handbook, halfpage

21

2

n.c.

3

Fig.1 Simplified outline (SOT23) and symbol.

1

3

MAM185

Note

1. ∗ = p: Made in Hong Kong.

∗ = t: Made in Malaysia.
∗ = W: Made in China.

2003 Mar 20 2

NXP Semiconductors Product data sheet

General purpose diodes BAS19; BAS20; BAS21

LIMITING VALUES

In accordance with the Absolu te Maximum Rating System (IEC 60134).

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

V

V

I

F

I

FRM

I

FSM

P
T
T

RRM

R

tot
stg
j

repetitive peak reverse voltage

BAS19 − 120 V
BAS20 − 200 V
BAS21 − 250 V

continuous reverse voltage

BAS19 − 100 V
BAS20 − 150 V

BAS21 − 200 V
continuous forward current see Fig.2; note 1 − 200 mA
repetitive peak forward current − 625 mA
non-repetitive peak forward current square wave; Tj = 25 °C prior to

surge; see

Fig.4
t = 1 µs − 9 A
t = 100 µs − 3 A
t = 10 ms − 1.7 A

total power dissipation T

= 25 °C; note 1 − 250 mW

amb

storage temperature −65 +150 °C
junction temperature − 150 °C

Note

1. Device mounted on an FR4 printed-circuit board.

2003 Mar 20 3

NXP Semiconductors Product data sheet

General purpose diodes BAS19; BAS20; BAS21

ELECTRICAL CHARACTERISTICS

Tj = 25 °C unless otherwise specified.

SYMBOL PARAMETER CONDITIONS MAX. UNIT

V

F

I

R

C

d

t

rr

forward voltage see Fig.3

IF = 100 mA 1 V
IF = 200 mA 1.25 V

reverse current see Fig.5

BAS19 VR = 100 V 100 nA

VR = 100 V; Tj = 150 °C 100 µA

BAS20 VR = 150 V 100 nA

VR = 150 V; Tj = 150 °C 100 µA

BAS21 VR = 200 V 100 nA

VR = 200 V; Tj = 150 °C 100 µA

diode capacitance f = 1 MHz; VR = 0; see Fig.6 5 pF
reverse recovery time when switched from IF = 30 mA to

= 30 mA; RL = 100 Ω; measured at

I

R

= 3 mA; see Fig.8

I

R

50 ns

THERMAL CHARACTERISTICS

SYMBOL PARAMETER CONDITIONS VALUE UNIT

R
R

th j-tp
th j-a

thermal resistance from junction to tie-point 330 K/W
thermal resistance from junction to ambient note 1 500 K/W

Note

1. Device mounted on an FR4 printed-circuit board.

2003 Mar 20 4

NXP Semiconductors Product data sheet

General purpose diodes BAS19; BAS20; BAS21

GRAPHICAL DATA

amb

MBG442

(oC)

300

handbook, halfpage

I

F

(mA)

200

100

0

0 100 200

Device mounted on an FR4 printed-circuit board.

T

Fig.2 Maximum permissible continuous forward

current as a function of ambient
temperature.

600

handbook, halfpage

I

F

(mA)

400

200

0

02

(1) Tj = 150 °C; typical values.
(2) Tj = 25 °C; typical values.
(3) Tj = 25 °C; maximum values.

(1) (3)(2)

1

MBG384

VF (V)

Fig.3 Forward current as a function of forward

voltage.

2

10

handbook, full pagewidth

I

FSM

(A)

10

1

−1

10

1

Based on square wave currents.
T

= 25 °C prior to surge.

j

Fig.4 Maximum permissible non-repetitive peak forward current as a function of pulse duration.

MBG703

10

2

10

3

10

tp (µs)

4

10

2003 Mar 20 5

NXP Semiconductors Product data sheet

General purpose diodes BAS19; BAS20; BAS21

2

10

handbook, halfpage

I

R

(µA)

10

1

1

10

2

10

0

(1) VR = V
(2) VR = V

(1) (2)

; maximum values.

Rmax

; typical values.

Rmax

100

Tj (

MBG381

o

C)

Fig.5 Reverse current as a function of junction

temperature.

200

1.0

handbook, halfpage

C

d

(pF)

0.8

0.6

0.4

0.2
04862

f = 1 MHz; Tj = 25 °C.

MBG447

VR (V)

Fig.6 Diode capacitance as a function of reverse

voltage; typical values.

amb

MBG445

(oC)

300

handbook, halfpage

V

R

(V)

200

100

0

0 100 200

(1) BAS21.
(2) BAS20.
(3) BAS19.

(1)

(2)

(3)

T

Fig.7 Maximum permissible continuous reverse

voltage as a function of the ambient
temperature.

2003 Mar 20 6

NXP Semiconductors Product data sheet

General purpose diodes BAS19; BAS20; BAS21

handbook, full pagewidth

R = 50

Ω

S

V = V I x R

RF S

(1) IR = 3 mA.

I

F

D.U.T.

SAMPLING

OSCILLOSCOPE

Ω

R = 50

i

MGA881

t

r

10%

V

R

90%

t

p

input signal

Fig.8 Reverse recovery voltage test circuit and waveforms.

t

I

F

t

rr

t

(1)

output signal

2003 Mar 20 7

NXP Semiconductors Product data sheet

3

General purpose diodes BAS19; BAS20; BAS21

PACKAGE OUTLINE

Plastic surface mounted package; 3 leads SOT2

D

3

A

A

1

12

e

1

b

p

e

w M

B

E

H

E

detail X

AB

Q

L

p

X

v M

A

c

0 1 2 mm

scale

DIMENSIONS (mm are the original dimensions)

A

UNIT

1.1

mm

0.9

OUTLINE

VERSION

SOT23 TO-236AB

1

A

max.

0.48

0.1

0.38

cD

b

p

0.15

0.09

IEC JEDEC EIAJ

3.0

2.8

E

1.4

1.2

REFERENCES

1.9

e

e

1

0.95

H

2.5

2.1

L

Qwv

p

E

0.55

0.45

0.15

0.45

0.2

0.1

EUROPEAN

PROJECTION

ISSUE DATE

97-02-28
99-09-13

2003 Mar 20 8
