NXP A71CL Data sheet

1. Introduction

A71CL

Plug & Trust Secure Element

Rev. 3.1 — 10 September 2020 512331

The A71CL is a ready-to-use solution providing a root of trust at the IC level and proven, chip-to-cloud security right out of the box. It is a platform capable of securely storing and provisioning credentials, securely connecting IoT devices to cloud services and performing cryptographic node authentication.

The A71CL solution provides security measures protecting the IC against physical and logical attacks. The solution is meant to be integrated with a host platform and running operating systems adding a chain of trust for a broad range of applications. The product is delivered with a manual and documents to provide guidance on its integration.

Product short data sheet

COMPANY PUBLIC

NXP Semiconductors

2. General description

2.1 A71CL naming conventions

The following table explains the naming conventions of the commercial product name of the A71CL products. Every A71CL product gets assigned such a commercial name, which includes also customer and application specific data.

The A71CL basic type names have the following format.

A71CLxagpp(p)

The ‘A71CL’ is a constant, all other letters are variables, which are explained in Table 1.

Table 1. A71CL commercial name format

Variable Meaning Values Description

x IC hardware specification

a embedded operating

g embedded application

pp(p) package type code

code

system code

firmware (applet) code

dd(d)= Delivery Type, TK2= HVSON8 (4x4)

A71CL

Plug & Trust Secure Element

1 standard operational ambient temperature:

−25 °C to +85 °C I2C interface supported

2 standard operational ambient temperature:

−40 °C to +90 °C I2C interface supported

C Java card operating system

L L is a fixed value = IoT security applet pre

installed

2.2 I2C interface

Depending on the interface pins state at boot, see Section 7 “Pinning information” for more details; the default I2C address after power-on-reset is 0x90 for Write, and 0x91 for Read.

2.3 Security licensing

NXP Semiconductors has obtained a patent license for SPA and DPA countermeasures from Cryptography Research Incorporated (CRI). This license covers both hardware and software countermeasures. It is important to customers that countermeasures within the operation system are covered under this license agreement with CRI. Further details can be obtained on request.

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 2 of 24

NXP Semiconductors

3. Features and benefits

3.1 Key benefits

 Secure, zero-touch connectivity  End-to-end security, from chip to edge to cloud  Secure credential injection for IC-level root of trust  Fast design-in with complete product support package  Easy to integrate with different MCU platforms

3.2 Security features

The A71CL security concepts includes many security measures to protect the chip. The A71CL operates fully autonomously based on an integrated Javacard operating

system and applet. Direct memory access is possible by the fixed functionalities of the applet only. With that, the content from the memory is fully isolated from the host system.

Attack protection by integrated design measures in the chip layout, the logic and the functional blocks.

A71CL

Plug & Trust Secure Element

3.3 Cryptography features

 Message digest with SHA1, SHA224, SHA256  Random number generator  Asymmetric key storage type: RSA Standard or RSA CRT  Auto RSA key generator ranges from 512-bit key length to 2048-bit key length. Either

RSA Standard or RSA CRT.

 Symmetric encryption/decryption with DES_CBC_NOPADDING,

DES_ECB_NOPADDING, AES_CBC_NOPADDING, AES_ECB_NOPADDING.

 Symmetric signature/verification with DES_CBC_ISO9797_M1,

DES_CBC_ISO9797_M2, AES_CBC_ISO9797_M1, AES_CBC_ISO9797_M2.

 Asymmetric encryption/decryption with RSA_NOPADDING, RSA_ PKCS1.  Asymmetric signature/verification with RSA_SHA1(PKCS1), RSA_SHA256.  Service data storage: the storage data read and write is protected by SCP.  SCP 02 service with option “i” = ‘55’.

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 3 of 24

NXP Semiconductors

3.4 Functional features

 400 kbit/s I2C Fast-mode interface  −40 °C to +90 °C operational ambient temperature (A7102)  On-chip Javacard operating system  40 µA typical sleep mode current with I2C pads in tristate mode  10 µA max deep sleep mode current with I2C pads in tristate mode  High-performance Public Key Infrastructure (PKI)  EEPROM with min 500,000 cycles endurance and min 25 years retention time  HVSON8 package

A71CL

Plug & Trust Secure Element

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 4 of 24

NXP Semiconductors

4. Applications

4.1 Use Cases and target applications

 A710xCL EXAMPLE USE CASES

 A710xCL TARGET APPLICATIONS

A71CL

Plug & Trust Secure Element

 Secure connection to public/private clouds, edge computing platforms,

infrastructure

 Secure commissioning  Device-to-device authentication  Proof of origin / anti-counterfeiting  Key storage and data protection

 Connected industrial devices  Sensor networks  IP cameras  Home gateways  Home appliances

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 5 of 24

NXP Semiconductors

Plug & Trust Secure Element

5. Ordering information

5.1 Ordering options

Table 2. Ordering information

Type number

A7101agTK2/... HVSON-8 plastic thermal enhanced very thin small outline package; no leads; 8 A7102agTK2/...

[1] a = A or C, g = G, C or A, according to the A71CL type classification see Section 2.1 “A71CL naming conventions”

Table 3. A71CL feature table

Product type

A7101CLpp(p) −25 °C to +85 °C I2C A7102CLpp(p) −40 °C to +90 °C

[1]

Package Name Description Version

terminals; body 4 × 4 × 0.85 mm

Table 3 gives an overview of available A71CL product types.

[1]

Operational ambient temperature Interface option

A71CL

SOT909-1

[1] HN1, according the A71CL type classification see Section 2.1 “A71CL naming conventions”

Table 4. A71CL type description

Orderable type Product type number 12NC Operational

ambient temperature

A7101CLTK2/T0BC2— A7101CLTK2/T0BC27J A7101CLTK2/T0BC27F 935372576118 −25 °C to +85 °C Baidu Cloud credential A7102CLTK2/T0BC2AJ

[1] product can be made available, please consult our sales for more details

[1]

A7101CLTK2/T0BC2BY 935380944118 −25 °C to +85 °C Customer Programmable

[1]

A7102CLTK2/T0BC2XQ 935379153118 −40 °C to +90 °C

Description

5.1.1 Ordering A71CL samples

Samples can be ordered from NXP Semiconductors from the NXP website. Note that NXP Semiconductors can provide up to 5 pieces free of charge. Larger

quantities have to be ordered separately.

[1]

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 6 of 24

NXP Semiconductors

6. Functional description

6.1 I2C Interface

The A71CL uses I2C as communication interface as described in the following section. The A71CL commands are wrapped using the Smartcard I2 protocol (SCI2C). The detailed documentation for the A71CL commands in the APDU Specification and SCI2C encapsulation (Ref. 3) is available in NXP DocStore.

The A71CL has an I2C interface in slave mode, supporting data rates up to 400 kbit/s operating in Fast-Mode (FM). The I2C interface is using the Smartcard I2C protocol as defined in Ref. 3 which is based on SMBus. Depending on the interface pins state at boot, see Section 7 for more details. The default I2C address after power-on-reset depends on the bootup condition as shown in Table 5.

6.2 Automatic Communication Mode detection at Power on

The IC configures its interface according to the pin state as shown in the table below. The host system must keep the voltage levels stable at these pins for at least 500 µs after power-on-reset.

A71CL

Plug & Trust Secure Element

Table 5. I2C address

Value at startup I2C address

IF0 IF1 I2C_SCL I2C_SDA Write Read

0 x 0 0 n.a. n.a. 1 0 1 1 0x90 0x91 1 1 1 1 0x92 0x93

6.3 Power-saving modes

The device provides two power-saving operation modes, the SLEEP mode and the DEEP SLEEP mode. These modes are activated via pad RST_N (DEEP SLEEP mode) or by the device.

6.3.1 SLEEP mode

The SLEEP mode has the following properties:

• all internal clocks are frozen,

• CPU enters power saving mode with program execution being stopped,

• CPU registers keep their contents,

• RAM keeps its contents,

The A71CL enters automatically into SLEEP mode and also wakes up automatically from SLEEP mode. In SLEEP mode, all internal clocks are stopped. The IOs hold the logical states they had at the time IDLE was activated. During SLEEP mode security sensors HVS, LVS, LTS, HTS, Light Sensors, Glitch Sensors and Active Shielding are disabled.

There are two ways to exit from the SLEEP mode:

• A reset signal on RST_N

• An External Interrupt edge triggered by a falling edge on I2C_SDA

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 7 of 24

NXP Semiconductors

6.3.2 DEEP SLEEP mode

The A71CLx provides a special sleep mode offering maximum power saving. It is reached by pulling RST_N to a logic zero level for more than 500 µs.

While in deep sleep mode the internal power is completely switched off and only the IO pads stay supplied. All digital pads will stay in high-Z mode.

To leave the DEEP SLEEP mode RST_N has to be released and set to a logic „1“ level.

A71CL

Plug & Trust Secure Element

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 8 of 24

NXP Semiconductors

7. Pinning information

7.1 Pinning

7.1.1 Pinning HVSON8

Fig 1. Pin configuration for HVSON-8 (SOT909-1)

A71CL

Plug & Trust Secure Element

Table 6. Pin description HVSON8

Symbol Pin Description

I2C_SCL 1 I2C clock VSS 2 ground IF0 3 interface activation, apply high on startup n.c. 4 not connected IF1 5 I2C address selection RST_N 6 reset input, active LOW VCC 7 power supply voltage input I2C_SDA 8 I2C data

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 9 of 24

NXP Semiconductors

8. Package outline

A71CL

Plug & Trust Secure Element

Fig 2. Package outline SOT909-1

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 10 of 24

NXP Semiconductors

9. Packing information

9.1 Reel packing

The A71CL product is available on 7” tape on reel and 13” tape on reel. Details are provided in Table 7.

Table 7. Reel packing options

Package type Reel type Minimum packing quantity

HVSON8 7” tape on reel 1500 HVSON8 13” tape on reel

[1] For details about packing method, product orientation, tape dimensions and labeling for A71 parts in

HVSON8 package having an ordering code (12NC) ending 118 refer to Ref. 2.

[1]

10. Electrical and timing characteristics

A71CL

Plug & Trust Secure Element

6000

The electrical interface characteristics of static (DC) and dynamic (AC) parameters for pads and functions used for I2C are in accordance with the NXP I2C specification (see

Ref. 1).

11. Limiting values

Table 8. Limiting values

In accordance with the Absolute Maximum Rating System (IEC 60134). Voltages are referenced to VSS (ground = 0 V).

Symbol Parameter Conditions Min Max Unit

esd_hbm

esd_cdm

tot

stg

[1] MILStandard 883-D method 3015; human body model; C = 100 pF, R = 1.5 kΩ; T [2] Depending on appropriate thermal resistance of the package. [3] JESD22-C101, JEDEC Standard Field induced charge device model test method.

supply voltage -0.3 +4.6 V input voltage any signal pad -0.3 +4.6 V input current pad I2C_SDA,

- 10 mA

I2C_SCL

output current pad I2C_SDA,

- 10 mA

I2C_SCL latch-up current VI< 0 V or VI> V electrostatic discharge

voltage (Human Body Model)

electrostatic discharge voltage (Charge Device Model)

pads VCC, VSS,

RST_N, I2C_SDA,

I2C_SCL

pads VCC, VSS,

RST_N, I2C_SDA,

I2C_SCL Total power dissipation

- 100 mA

[1]

[3]

[2]

- 1 W

± 2.0 kV

± 500 V

Storage temperature -55 +125 °C

= −25 °C to +85 °C.

amb

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 11 of 24

NXP Semiconductors

12. Recommended operating conditions

The A71CL offers two operation modes, the so-called 1V8 mode and the 3V3 mode targeted for battery supplied applications.

Table 9. Recommended operating conditions

Symbol Parameter Conditions Min Typ Max Unit

amb

supply voltage range 3V3 mode range

DC input voltage on digital I/O pads I2C_SCL, I2C_SDA

DC input voltage on digital input pad RST_N

Operating ambient temperature

A71CL

Plug & Trust Secure Element

2.50 3.3 3.6 V CPU in free runing mode

1V8 mode 1.62 1.8 1.98 V 3V3 mode 0 3.6 V 1V8 mode 0 3.6 V 3V3 mode 0 3.6 V 1V8 mode 0 3.6 V A7101 -25 +85 °C A7102 -40 +90 °C

Fig 3. Recommended operating conditions over voltage range

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 12 of 24

NXP Semiconductors

A71CL

Plug & Trust Secure Element

13. Characteristics

13.1 DC characteristics

Measurement conventions

Testing measurements are performed at the contact pads of the device under test. All voltages are defined with respect to the ground contact pad VSS. All currents flowing into the device are considered positive.

13.1.1 General and I2C I/O interface

Table 10. Electrical DC characteristics of I2C_SCL, I2C_SDA and RST_N

Symbol Parameter Conditions Min Typ Max Unit

Input/Output: I2C_SCL, I2C_SDA in push-pull mode

HIGH level input voltage 0.7 V LOW level input voltage -0.5 0.3V HIGH level input current in input

IHmin

< VI< V

mode

LOW level input current V

ILmin

< VI< V

HIGH level output voltage IOH= −3.0 mA;

3V3 mode IOH= −3.0 mA;

1V8 mode

LOW level output voltage IOL= 3.0 mA

3V3 mode IOL= 2.0 mA 1V8 mode

Input/Output: I2C_SCL, I2C_SDA in open-drain mode

HIGH level input voltage 0.7 V LOW level input voltage -0.5 0.3V HIGH level input current in input

IHmin

< VI< V

mode

LOW level input current V

ILmin

< VI< V

LOW level output voltage IOL= 3.0 mA

3V3 mode IOL= 2.0 mA 1V8 mode

Input: RST_N

IH1

IL1

IH1

IL1

HIGH level input voltage 0.7 V LOW level input voltage -0.3 0.3V HIGH level RST_N input current V

IH1min

≤ VI≤ V

LOW level RST_N input current 0 V ≤ VI≤ V

IHmax

ILmax

IHmax

ILmax

IL1max

[2]

[3]

;

[3]

0.7 V

[1]

Imax

V V

± 10 µA

0.4 V

0.2 V

Imax

[1]

V V

± 10 µA

0.4 V

0.2 V

Imax

[1]

V V

± 20 µA ± 20 µA

[1] Maximum value according to Table 9 “Recommended operating conditions”

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 13 of 24

NXP Semiconductors

A71CL

Plug & Trust Secure Element

[2] : External pull-up resistor 20 kΩ to VDD. The worst case test condition for parameter VOH is present at minimum VDD. For class A supply

voltage conditions VDD= 4.5 V is the worst case with respect to the fix specification limit V related limit “0.7 VDD“is a stricter requirement than the fix value 3.8 V at high VDD (0.7 VDD= 3.85 V at VDD= 5.5 V). So, in the V range 4.5 V to 5.5 V, V

[3] The active low RST_N input internally has a resistive pull-down device to VSS. Accordingly a current is flowing into the pad voltages

above 0 V. Figure 4 shows the RST_N input characteristic.

is specified as “the larger value of 0.7 VDD and 3.8 V, respectively”.

OHmin

= 3.8 V (0.844 VDD). The supply voltage

OHmin

Fig 4. Input characteristic of RST_N

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 14 of 24

NXP Semiconductors

A71CL

Plug & Trust Secure Element

13.1.2 I2C interface at 3V3 mode operation

Table 11. Electrical characteristics of IC supply voltage VDD; VSS= 0 V; T

[1]

= -40 to +90 °C

amb

Symbol Parameter Conditions Min Typ Max Unit

Supply

supply voltage range 3V3 mode range

2.50 3.3 3.6 V

CPU in free running mode

no coprocessor active CPU in free running mode 6.3 7.0 mA EPROM programming in progress CPU in free running mode 7.3 8.0 mA AES coprocessor active CPU in free running mode 9.3 10.3 mA ECC coprocessor active CPU in free running mode 13.7 15.1 mA

DD(SLP)

DD(DSLP)

[1] All appropriately marked values are typical values and only referenced for information. They are subject to change without notice.

supply current SLEEP mode T

= 25 °C 45 150 µA

amb

supply current deep sleep mode RST_N at 0V, T

RST_N at 0V, T

= 25°C 10 µA

amb

= 90°C 10 µA

amb

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 15 of 24

NXP Semiconductors

A71CL

Plug & Trust Secure Element

13.1.3 I2C interface at 1V8 mode operation

Table 12. Electrical characteristics of IC supply voltage VDD; VSS= 0 V; T

[1]

= -40 to +90 °C

amb

Symbol Parameter Conditions Min Typ Max Unit

Supply

supply voltage range 1V8 mode range 1.62 1.8 1.98 V no coprocessor active CPU in free running mode 2.45 mA AES coprocessor active CPU in free running mode 2.7 mA ECC coprocessor active CPU in free running mode 7.5 mA

DD(SLP)

DD(DSLP)

[1] All appropriately marked values are typical values and only referenced for information. They are subject to change without notice.

supply current SLEEP mode T

= 25 °C 40 80 µA

amb

supply current deep sleep mode RST_N at 0V, T

RST_N at 0V, T

= 25°C 10 µA

amb

= 90°C 10 µA

amb

13.2 AC characteristics

Table 13. Non-volatile memory timing characteristics; VDD= 1.8 V ± 10% or 3 V ± 10% V; VSS= 0 V;

= -40 to 90 °C

amb

Symbol Parameter Conditions Min Typ Max Unit

EEP

EEE

EEW

EER

EEC

EEPROM erase + program time 2.7 ms EEPROM erase time 1.7 ms EEPROM program time 1.0 ms EEPROM data retention time T EEPROM endurance

= +55 °C 25 years

amb

5 × 10

cycles

(number of programming cycles)

Table 14. Electrical AC characteristics of I2C_SDA, I2C_SCL, and RST_N

VDD= 1.8 V ± 10% or 3 V ± 10% V; VSS= 0 V; T

= -40 to 90 °C

amb

[1]

;

Symbol Parameter Conditions Min Typ Max Unit

Input/Output: I2C_SDA, I2C_SCL in open-drain mode

OIO

I/O Input rise time Input/reception mode I/O Input fall time Input/reception mode I/O Output fall time Output/transmission mode;

[4] [4] [4]

1 µs 1 µs

0.3 µs

CL= 30 pF

CLK

CLKW

External clock frequency in I2C applications

Clock pulse width i.r.t. clock

, T

CLKW

amb

spec'd limits

and VDD in their

- 400 kHz

[3]

40 60 % period (positive pulse duty cycle of CLK)

Inputs: RST_N

Reset pulse width (RST_N low)

40 400 µs without entering deep sleep mode

RDSLP

Reset pulse width (RST_N low)

500 µs to enter deep sleep mode

WKP

Wake-up time from SLEEP

CLKmin

< f

CLK

< f

CLKmax

- 8 10 µs

mode

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 16 of 24

NXP Semiconductors

A71CL

Plug & Trust Secure Element

Table 14. Electrical AC characteristics of I2C_SDA, I2C_SCL, and RST_N

VDD= 1.8 V ± 10% or 3 V ± 10% V; VSS= 0 V; T

= -40 to 90 °C

amb

[1]

;

Symbol Parameter Conditions Min Typ Max Unit

WKPIO

WKPRST

Pad LOW time for wake-up from SLEEP mode

RST_N LOW time for wake-up

level triggered ext.int. - 8 10 µs edge triggered ext.int. - 8 10 µs

40 - µs from SLEEP mode

WKWT

Time from SLEEP mode

50 100 ns wake/up event to I2C_SDA valid

[1] All appropriately marked values are typical values and only referenced for information. They are subject to change without notice. [2] tris defined as rise time between 20% and 80% of the signal amplitude.

[3] During AC testing the inputs RST_N, I2C_SDA, I2C_SCL are driven at 0 V to +0.3 V for a LOW input level and at VDD−0.3 V to VDD for

[4] tris defined as rise time between 30% and 70% of the signal amplitude.

Pin capacitances RST_N, I2C_SDA, /I2C_SCL

tfis defined as fall time between 80% and 20% of the signal amplitude.

a HIGH input level. Clock period and signal pulse (duty cycle) timing is measured at 50% of VDD.

tfis defined as fall time between 70% and 30% of the signal amplitude.

Test frequency = 1 MHz; T

= 25 °C

amb

- 10 pF

Fig 5. External clock drive and AC test timing reference points of I2C_SDA, I2C_SCL, and RST_N (see Table

note [3] and Table note [4]) in open drain mode

13.3 EMC/EMI

EMC and EMI resistance according to IEC 61967-4.

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 17 of 24

NXP Semiconductors

14. Abbreviations

Table 15. Abbreviations

Acronym Description

AES Advanced Encryption Standard CRC Cyclic Redundancy Check DES Digital Encryption Standard DPA Differential Power Analysis DSS Digital Signature Standard ECC Elliptic Curve Cryptography EEPROM Electrically Erasable Programmable Read-Only Memory I/O Input/Output MAC Message Authentication Code OS Operating System PKI Public Key Infrastructure SFI Single Fault Injection SHA Secure Hash Algorithm

A71CL

Plug & Trust Secure Element

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 18 of 24

NXP Semiconductors

15. References

[1] I2C-bus specification and user manual, Rev. 3.0 — June-19-2007, NXP

[2] SOT909-1; HVSON8; Reel pack; Ordering code (12NC) ending 118; Packing

[3] Application note SCIIC Protocol Specification, Application note, Rev 1.5, an195015

[4] Application note A71CL Secure Module - APDU Specification, Application note,

A71CL

Plug & Trust Secure Element

Semiconductors

Information; Rev. 2 — 19 April 2013

— 31 January 2017

A71CL Secure Module - APDU Specification an515411

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 19 of 24

NXP Semiconductors

Plug & Trust Secure Element

16. Revision history

Table 16. Revision history

Document ID Release date Data sheet status Change notice Supersedes

512331 2020-09-10 Short data sheet 512330 Modifications Added footnote to

table 4

512330 2018-11-27 Short data sheet Modifications: • Initial version

A71CL

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 20 of 24

NXP Semiconductors

17. Legal information

17.1 Data sheet status

A71CL

Plug & Trust Secure Element

Document status

Objective [short] data sheet Development This document contains data from the objective specification for product development. Preliminary [short] data sheet Qualification This document contains data from the preliminary specification. Product [short] data sheet Production This document contains the product specification.

[1] Please consult the most recently issued document before initiating or completing a design. [2] The term ‘short data sheet’ is explained in section “Definitions”. [3] The product status of device(s) described in this document may have changed since this document was published and may differ in case of multiple devices. The latest product status

information is available on the Internet at URL http://www.nxp.com.

[1][2]

Product status

17.2 Definitions

Draft — A draft status on a document indicates that the content is still under

internal review and subject to formal approval, which may result in modifications or additions. NXP Semiconductors does not give any representations or warranties as to the accuracy or completeness of information included in a draft version of a document and shall have no liability for the consequences of use of such information.

Short data sheet — A short data sheet is an extract from a full data sheet with the same product type number(s) and title. A short data sheet is intended for quick reference only and should not be relied upon to contain detailed and full information. For detailed and full information see the relevant full data sheet, which is available on request via the local NXP Semiconductors sales office. In case of any inconsistency or conflict with

the short data sheet, the full data sheet shall prevail. Product specification — The information and data provided in a Product

data sheet shall define the specification of the product as agreed between NXP Semiconductors and its customer, unless NXP Semiconductors and customer have explicitly agreed otherwise in writing. In no event however, shall an agreement be valid in which the NXP Semiconductors product is deemed to offer functions and qualities beyond those described in the Product data sheet.

17.3 Disclaimers

Limited warranty and liability — Information in this document is believed to

be accurate and reliable. However, NXP Semiconductors does not give any representations or warranties, expressed or implied, as to the accuracy or completeness of such information and shall have no liability for the consequences of use of such information. NXP Semiconductors takes no responsibility for the content in this document if provided by an information source outside of NXP Semiconductors. In no event shall NXP Semiconductors be liable for any indirect, incidental, punitive, special or consequential damages (including - without limitation - lost profits, lost savings, business interruption, costs related to the removal or replacement of any products or rework charges) whether or not such damages are based on tort (including negligence), warranty, breach of contract or any other legal theory. Notwithstanding any damages that customer might incur for any reason whatsoever, NXP Semiconductors’ aggregate and cumulative liability towards customer for the products described herein shall be limited in accordance with the Terms and conditions of commercial sale of NXP Semiconductors

[3]

Definition

Right to make changes — NXP Semiconductors reserves the right to make

changes to information published in this document, including without limitation specifications and product descriptions, at any time and without notice. This document supersedes and replaces all information supplied prior to the publication here. — Suitability for use — NXP Semiconductors products are not designed, authorized or warranted to be suitable for use in life support, life-critical or safety-critical systems or equipment, nor in applications where failure or malfunction of an NXP Semiconductors product can reasonably be expected to result in personal injury, death or severe property or environmental damage. NXP Semiconductors and its suppliers accept no liability for inclusion and/or use of NXP Semiconductors products in such equipment or applications and therefore such inclusion and/or use is at the customer’s own risk. — Applications — Applications that are described herein for any of these products are for illustrative purposes only. NXP Semiconductors makes no representation or warranty that such applications will be suitable for the specified use without further testing or modification. Customers are responsible for the design and operation of their applications and products using NXP Semiconductors products, and NXP Semiconductors accepts no liability for any assistance with applications or customer product design. It is customer’s sole responsibility to determine whether the NXP Semiconductors product is suitable and fit for the customer’s applications and products planned, as well as for the planned application and use of customer’s third party customer(s). Customers should provide appropriate design and operating safeguards to minimize the risks associated with their applications and products. NXP Semiconductors does not accept any liability related to any default, damage, costs or problem which is based on any weakness or default in the customer’s applications or products, or the application or use by customer’s third party customer(s). Customer is responsible for doing all necessary testing for the customer’s applications and products using NXP Semiconductors products in order to avoid a default of the applications and the products or of the application or use by customer’s third party customer(s). NXP does not accept any liability in this respect. — Limiting values — Stress above one or more limiting values (as defined in the Absolute Maximum Ratings System of IEC 60134) will cause permanent damage to the device. Limiting values are stress ratings only and (proper) operation of the device at these or any other conditions above those given in the Recommended operating conditions section (if present) or the Characteristics sections of this document is not warranted. Constant or repeated exposure to limiting values will permanently and irreversibly affect the quality and reliability of the device. — Terms and conditions of commercial sale — NXP Semiconductors products are sold subject to the general terms and conditions of commercial sale, as published at http://www.nxp.com/profile/terms, unless otherwise agreed in a valid written individual agreement. In case an individual agreement is concluded only the terms and conditions of the respective agreement shall apply. NXP

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 21 of 24

NXP Semiconductors

A71CL

Plug & Trust Secure Element

Semiconductors hereby expressly objects to applying the customer’s general terms and conditions with regard to the purchase of NXP Semiconductors products by customer. — No offer to sell or license — Nothing in this document may be interpreted or construed as an offer to sell products that is open for acceptance or the grant, conveyance or implication of any license under any copyrights, patents or other industrial or intellectual property rights. — Export control — This document as well as the item(s) described herein may be subject to export control regulations. Export might require a prior authorization from competent authorities — Non-automotive qualified products — Unless this data sheet expressly states that this specific NXP Semiconductors product is automotive qualified, the product is not suitable for automotive use. It is neither qualified nor tested in accordance with automotive testing or application requirements. NXP Semiconductors accepts no liability for inclusion and/or use of non-automotive qualified products in automotive equipment or applications. In the event that customer uses the product for design-in and use in automotive applications to automotive specifications and standards, customer (a) shall use the product without NXP Semiconductors’ warranty of the product for such automotive applications, use and specifications, and (b) whenever customer uses the product for automotive applications beyond NXP Semiconductors’ specifications such use shall be solely at customer’s own risk, and (c) customer fully indemnifies NXP Semiconductors for any liability, damages or failed product claims resulting from customer design and use of the product for automotive applications beyond NXP Semiconductors’ standard warranty and NXP Semiconductors’ product specifications. — Translations — A non-English (translated) version of a document is for reference only. The English version shall prevail in case of any discrepancy between the translated and English versions. — Security — While NXP Semiconductors has implemented advanced security features, all products may be subject to unidentified vulnerabilities. Customers are responsible for the design and operation of their applications and products to reduce the effect of these vulnerabilities on customer’s applications and products, and NXP Semiconductors accepts no liability for any vulnerability

that is discovered. Customers should implement appropriate design and operating safeguards to minimize the risks associated with their applications

and products. — 17.4 Licenses

ICs with DPA Countermeasures functionality

NXP ICs containing functionality implementing countermeasures to Differential Power Analysis and Simple Power Analysis are produced and sold under applicable license from Cryptography Research, Inc.

17.5 Trademarks

Notice: All referenced brands, product names, service names and trademarks are the property of their respective owners.

FabKey — is a trademark of NXP B.V. I2C-bus — logo is a trademark of NXP B.V.

18. Contact information

For more information, please visit: http://www.nxp.com For sales office addresses, please send an email to: salesaddresses@nxp.com

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 22 of 24

NXP Semiconductors

19. Tables

A71CL

Plug & Trust Secure Element

Table 1. A71CL commercial name format . . . . . . . . . . . .2

Table 2. Ordering information. . . . . . . . . . . . . . . . . . . . . .6

Table 3. A71CL feature table . . . . . . . . . . . . . . . . . . . . . .6

Table 4. A71CL type description. . . . . . . . . . . . . . . . . . . .6

Table 5. I2C address. . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Table 6. Pin description HVSON8 . . . . . . . . . . . . . . . . . .9

Table 7. Reel packing options . . . . . . . . . . . . . . . . . . . .11

Table 8. Limiting values . . . . . . . . . . . . . . . . . . . . . . . . .11

Table 9. Recommended operating conditions . . . . . . . .12

Table 10. Electrical DC characteristics of I2C_SCL,

I2C_SDA and RST_N . . . . . . . . . . . . . . . . . . .13

Table 11. Electrical characteristics of IC supply voltage VDD;

20. Figures

Fig 1. Pin configuration for HVSON-8 (SOT909-1) . . . . .9

Fig 2. Package outline SOT909-1 . . . . . . . . . . . . . . . . .10

Fig 3. Recommended operating conditions over voltage

range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Fig 4. Input characteristic of RST_N . . . . . . . . . . . . . . .14

21. Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2 General description. . . . . . . . . . . . . . . . . . . . . . 2

2.1 A71CL naming conventions . . . . . . . . . . . . . . . 2

2.2 I2C interface . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2.3 Security licensing . . . . . . . . . . . . . . . . . . . . . . . 2

3 Features and benefits . . . . . . . . . . . . . . . . . . . . 3

3.1 Key benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

3.2 Security features. . . . . . . . . . . . . . . . . . . . . . . . 3

3.3 Cryptography features . . . . . . . . . . . . . . . . . . . 3

3.4 Functional features. . . . . . . . . . . . . . . . . . . . . . 4

4 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

4.1 Use Cases and target applications. . . . . . . . . . 5

5 Ordering information. . . . . . . . . . . . . . . . . . . . . 6

5.1 Ordering options. . . . . . . . . . . . . . . . . . . . . . . . 6

5.1.1 Ordering A71CL samples . . . . . . . . . . . . . . . . . 6

6 Functional description . . . . . . . . . . . . . . . . . . . 7

6.1 I2C Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

6.2 Automatic Communication Mode detection at

Power on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

6.3 Power-saving modes. . . . . . . . . . . . . . . . . . . . 7

6.3.1 SLEEP mode . . . . . . . . . . . . . . . . . . . . . . . . . . 7

6.3.2 DEEP SLEEP mode. . . . . . . . . . . . . . . . . . . . . 8

VSS= 0 V; T

Table 12. Electrical characteristics of IC supply voltage VDD;

VSS= 0 V; T

Table 13. Non-volatile memory timing characteristics;

VDD= 1.8 V ± 10% or 3 V ± 10% V; VSS= 0 V; T

= -40 to 90 °C . . . . . . . . . . . . . . . . . . . . .16

Table 14. Electrical AC characteristics of I2C_SDA,

Table 15. Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . 18

Table 16. Revision history . . . . . . . . . . . . . . . . . . . . . . . . 20

Fig 5. External clock drive and AC test timing reference

7 Pinning information . . . . . . . . . . . . . . . . . . . . . 9

7.1 Pinning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

7.1.1 Pinning HVSON8. . . . . . . . . . . . . . . . . . . . . . . 9

8 Package outline. . . . . . . . . . . . . . . . . . . . . . . . 10

9 Packing information . . . . . . . . . . . . . . . . . . . . . 11

9.1 Reel packing . . . . . . . . . . . . . . . . . . . . . . . . . . 11

10 Electrical and timing characteristics. . . . . . . . 11

11 Limiting values . . . . . . . . . . . . . . . . . . . . . . . . . 11

12 Recommended operating conditions . . . . . . 12

13 Characteristics . . . . . . . . . . . . . . . . . . . . . . . . 13

13.1 DC characteristics . . . . . . . . . . . . . . . . . . . . . 13

13.1.1 General and I2C I/O interface . . . . . . . . . . . . 13

13.1.2 I2C interface at 3V3 mode operation

13.1.3 I2C interface at 1V8 mode operation

13.2 AC characteristics . . . . . . . . . . . . . . . . . . . . . 16

13.3 EMC/EMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

14 Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . 18

15 References. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

16 Revision history . . . . . . . . . . . . . . . . . . . . . . . 20

17 Legal information . . . . . . . . . . . . . . . . . . . . . . 21

17.1 Data sheet status. . . . . . . . . . . . . . . . . . . . . . 21

amb

I2C_SCL, and RST_N VDD= 1.8 V ± 10% or 3 V ± 10% V; VSS= 0 V; T

= -40 to 90 °C . . . . . . . . . . . . . . . . . . . . .16

amb

points of I2C_SDA, I2C_SCL, and RST_N (see

Table note [3] and Table note [4]) in open drain

mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

= -40 to +90 °C . . . . . . . . . . . 15

amb

= -40 to +90 °C . . . . . . . . . . . 16

amb

[1]

;

[1]

. . . . . 15

[1]

. . . . . 16

continued >>

Product short data sheet COMPANY PUBLIC

Rev. 3.1 — 10 September 2020

512331 23 of 24

NXP Semiconductors

17.2 Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

17.3 Disclaimers. . . . . . . . . . . . . . . . . . . . . . . . . . . 21

17.4 Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

17.5 Trademarks. . . . . . . . . . . . . . . . . . . . . . . . . . . 22

18 Contact information. . . . . . . . . . . . . . . . . . . . . 22

19 Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

20 Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

21 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

A71CL

Plug & Trust Secure Element

Please be aware that important notices concerning this document and the product(s) described herein, have been included in section ‘Legal information’.

For more information, please visit: http://www.nxp.com For sales office addresses, please send an email to: salesaddresses@nxp.com

Date of release: 10 September 2020

512331

NXP A71CL Data sheet

Specifications and Main Features

Frequently Asked Questions

User Manual
