NXG Technology NX-RM820 User Manual
NX-RM820
Operating Manual
PC Programmable
Professional
Home Entertainment
and System Control
NX-RM820_Remote_Manual 10/6/08 2:09 PM Page 1
This remote control was Custom Programmed for you by:
__________________________________________________
For questions about your Custom Programming call:
__________________________________________________
Custom Programming of a complex home theater and/or a multiroom system is one of the most challenging tasks within an
audio/video installation. It involves an intimate knowledge of how
the components interact and exact details on the proper sequences
of control.
Only a professional custom installation company has the requisite
experience and training to quickly and effectively customize a
remote control for true automated operation.
Congratulations on your choice!
OPERATING YOUR SYSTEM WITH THE NX-RM820
© 2008 NXG Technology All rights reserved.
The information in this manual is copyright protected. No part of
this manual may be copied or reproduced in any form without prior
written consent from NXG Technology. NXG Technology SHALL
NOT BE LIABLE FOR OPERATIONAL, TECHNICAL OR EDITORIAL
ERRORS/OMISSIONS MADE IN THIS MANUAL.
The information in this manual may be subject to change without
prior notice. All other brand or product names are trademarks or
registered trademarks of their respective companies or
organizations.
NXG Technology
16648 North 94th Street, Scottsdale, AZ 85260
Phone: 800-733-0008 | www.nxgtech.com
NX-RM820
NX-RM820_Remote_Manual 10/6/08 2:09 PM Page 2
Table of Contents
No More Pointing 1
Finding the MAIN Menu 2
Turn On the System 3
Using the MAIN Menu 4
Select a New ACTIVITY 4
Select a DEVICE Only 5
Controlling the Volume 6
Operating Any Device 6
Using FAV - Favorites 8
Backlighting 10
Changing CONTRAST 10
Batteries 11
Cleaning the Screen 11
Warranty 12
Specifications 12
NX-RM820
NX-RM820_Remote_Manual 10/6/08 2:09 PM Page 3
No More Pointing!
The combination of the NX-RM820 with it’s companion NX-RF200
base station will enable you to place your audio/video components
out of sight behind closed doors and/or in another room of your
house. The NX-RM820 sends radio signals to the NX-RF200
through walls and closed doors (50 – 100' away, indoors or
outdoors). The NX-RF200 converts your commands to the
infrared signals that control your A/V components.
1. The NX-RM820 remote
control sends radio waves
in every direction, so you
don’t have to point the
remote anymore!
2. Self-adhesive ‘Flashers’ affixed to the front
panels of components relay commands to
components out of ‘line-of-sight’ with the
NX-RF200.
3. The built-in Front Blaster sends commands to components in the
same cabinet space as the NX-RF200.
NX-RM820
1
NX-RM820
The NX-RF200
NX-RM820_Remote_Manual 10/6/08 2:09 PM Page 4
Finding the MAIN Menu
The MAIN Button always takes you to the MAIN Menu which may
be named for the room the NX-RM820 controls.
The PAGE button switches between two MAIN Menu pages IF you
have more than ten remote controls. When the top title bar says
MAIN or the name of a Room, you are on the MAIN Menu.
The lower title bar displays PAGE 1 or PAGE 2 as you switch. Each
of the remote controls the NX-RM820 replaces are represented by a
button next to the corresponding screen label.
NX-RM820
2
NX-RM820_Remote_Manual 10/6/08 2:09 PM Page 5
Turn On Your Entire System
Power on/off your entire system with the MAIN Menu
by following these steps:
1. Touch the MAIN Button to make sure that you are on the
MAIN Menu. It doesn’t matter which page of the
MAIN Menu is displayed.
2.Touch the On or Off button as desired. Wait until all components
are correctly powered on or off. Turning on the system may take
ten to twenty seconds.
3.If one component does not turn on/off, simply touch the
button again.
TIP – The remote control will not respond to a new button push while
it is still issuing commands. While busy, this indicator flashes
at the top of the screen next to the screen title.
NX-RM820
3
NX-RM820_Remote_Manual 10/6/08 2:09 PM Page 6
