Nvidia VCQRTX8000-PB Product Data Sheet

THE WORLD’S FIRST
RAY TRACING GPU

NVIDIA QUADRO RTX 8000

Real time ray tracing
for professionals

Experience unbeatable performance, power, and memory
with the NVIDIA® Quadro RTX™ 8000, the world’s most
powerful graphics card for professional workflows. The
Quadro RTX 8000 is powered by the NVIDIA Turing™
architecture and NVIDIA RTX™ platform to deliver the
latest hardware-accelerated ray tracing, deep learning,
and advanced shading to professionals. Equipped with
4608 NVIDIA CUDA® cores, 576 Tensor cores, and 72 RT
Cores, the Quadro RTX 8000 can render complex models
and scenes with physically accurate shadows, reflections,
and refractions to empower users with instant insight.
Support for NVIDIA NVLink™1 lets applications scale
performance, providing 96 GB of GDDR6 memory with
multi-GPU configurations2. And with the industry’s first
implementation of the new VirtualLink®3 port, the Quadro
RTX 8000 provides simple connectivity to the next­generation of high-resolution VR head-mounted displays
to let designers view their work in the most compelling
virtual environments possible.

Quadro cards are certified with a broad range of
sophisticated professional applications, tested by leading
workstation manufacturers, and backed by a global

FEATURES

> Four DisplayPort 1.4 Connectors
> VirtualLink Connector
> DisplayPort with Audio
> VGA Support
> 3D Stereo Support with Stereo

Connector

> NVIDIA GPUDirect™ Support
> Quadro Sync II5 Compatibility
> NVIDIA nView® Desktop

Management Software

> HDCP 2.2 Support
> NVIDIA Mosaic

PACKAGE CONTENTS

> NVIDIA Quadro RTX 8000
> Quadro RTX Quick Start Guide
> Quadro Support Guide
> 1 DisplayPort to DVI Adapter
> 1 DisplayPort to HDMI Adapter
> 1 Auxiliary Power Cable

(8-pin to dual 6-pin adapter)

WARRANTY AND SUPPORT

> 3-Year Warranty
> Pre- and Post-Sales Technical

Support

> Dedicated Field Application

Engineers

> Direct Tech Support Hot Lines

team of support specialists. This gives you the peace of
mind to focus on doing your best work. Whether you’re
developing revolutionary products or telling spectacularly
vivid visual stories, Quadro gives you the performance to
do it brilliantly.

1

NVIDIA NVLink sold separately | 2 Connecting two RTX 8000 cards with NVLink to scale performance
and memory capacity to 96 GB is only possible if your application supports NVLink technology. Please
contact your application provider to confirm their support for NVLink | 3 In preparation for the
emerging VirtualLink standard, Turing GPUs have implemented hardware support according to the
“VirtualLink Advance Overview”. To learn more about VirtualLink, please see www.virtuallink.org |

4

Via adapter/connector/bracket | 5 Quadro Sync II card sold separately | 6 Windows 7, 8, 8.1, 10 and
Linux | 7 GPU supports DX 12.0 API, Hardware Feature Level 12_1 | 8 Product is based on a published
Khronos Specification, and is expected to pass the Khronos Conformance Testing Process when
available. Current conformance status can be found at www.khronos.org/conformance

© 2019 NVIDIA Corporation and PNY. All rights reserved. NVIDIA, the NVIDIA logo, Quadro, nView,
CUDA, and NVIDIA Turing are trademarks and/or registered trademarks of NVIDIA Corporation in the
U.S. and other countries. The PNY logotype is a registered trademark of PNY Technologies. OpenCL
is a trademark of Apple Inc. used under license to the Khronos Group Inc. All other trademarks and
copyrights are the property of their respective owners. FEB19

3

4

4

PNY PART NUMBER VCQRTX8000PB

EAN CODE 3536403369866

6

SPECIFICATIONS

GPU Memory 48 GB GDDR6

Memory Interface 384-bit

Memory Bandwidth 672 GB/s

ECC Yes

NVIDIA CUDA Cores 4,608

NVIDIA Tensor Cores 576

NVIDIA RT Cores 72

Single-Precision Performance 16.3 TFLOPS

Tensor Performance 130.5 TFLOPS

NVIDIA NVLink Connects 2x RTX 8000 GPUs

NVIDIA NVLink bandwidth 100 GB/s (bidirectional)

System Interface PCI Express 3.0 x 16

Power Consumption Total board power: 295 W

Thermal Solution Active

Form Factor 4.4” H x 10.5” L,

Display Connectors 4xDP 1.4, VirtualLink (1)

Max Simultaneous Displays 4x 3840 x 2160  120 Hz,

Encode / Decode Engines 1X Encode, 1X Decode

VR Ready Yes

Graphics APIs DirectX 12.07, Shader Model 5.17,

PNY Technologies Europe
9 rue Joseph Cugnot, 33708 Mérignac cedex | France
T [phone] | F +33(=0) 5 56 13 75 77

For more information visit: www.pny.eu/quadro

Total graphics power: 260 W

Dual Slot, Full Height

4x 5120x2880  60 Hz,
2x 7680x4320  60 Hz

OpenGL 4.58, Vulkan 1.0

8
