1 Safety
The intended audience of this User’s Manual is system integrators and hardware/software
engineers.
1.1 Safety Symbols used in this document
Hazardous voltage!
This is the electrical hazard symbol. It indicates that there are dangerous voltages inside the
Shelf.
Caution!
This is the user caution symbol. It indicates a condition where damage of the equipment or
injury of the service personnel could occur. To reduce the risk of damage or injury, follow all
steps or procedures as instructed.
Danger of electrostatic discharge!
The Shelf contains static sensitive devices. To prevent static damage you must wear an ESD
wrist strap.
1.2 General Safety Precautions
Warning!
Voltages over 60 VDC can be present in this equipment. As defined in the PICMG 3.0 Specification, this equipment is intended to be acce
qualified and trained service personnel only.
• Use of this product in a manner not specified by the manufacturer may impair the safety protection of this equipment.
• Service personnel must know the necessary electrical sa
installing this equipment.
• Install this equipment only in
• For additional information about this equipmen
Specification (
www.picmg.com).
ssed, to be installed and maintained by
fety, wiring and connection practices for
compliance with local and national electrical codes.
t, see the PICMG MicroTCA
1.3 References and Architecture Specifications
•PICMG® MTCA.0 Specification
(
www.picmg.com)
•PICMG
®
AMC® Base Specification
(
www.picmg.com)
R1.0, February 2016 Safe
ty 1
2 Hardware Platform
The Schroff 11850-016 is an 1 U/2slot MicroTCA Shelf with EMCH (Embedded MicroTCA
Carrier Hub) for AMC Single Full-size or Mid-size modules (with 2 HP filler panel).
Features:
• Shielded steel case
• 2 AMC single Full-size slots
• MicroTCA Backplane
• EMCH (Embedded MicroTCA Carrier Hub) with basic MicroTCA functionality for switching
and ma
• Power management controller on the backplane
• Active cooling through:
4 fans for cooling the AMC modules
1 fan for cooling the power supply
• Easy removable air inlet filter
• Integrated 150 W AC Power Supply with wide range AC input and 12 V DC output.
naging two AMCs (Advanced Mezzanine Cards)
11850-016
• AC mains/line module with IEC 320-C14 connector, integrated mains/line fuses and line
fi
lt
er
2 Hardware Platform R1.0, February 2016
11850-016
2.1 Front and Rear View
Figure 1: Front and RearView
1 ESD Wrist Strap Terminal 5 EMCH interfaces
2 2 HP Filler panel 6 Ground Terminal (Equipotential bonding)
3 AC input 7 PSU
4 Mains/line switch 8 EMCH
2.2 ESD Wrist Strap Terminal
Danger of electrostatic discharge!
The Shelf contains static sensitive devices. To prevent static damage you must wear an ESD
wrist strap.
The ESD Wrist Strap Terminal (4 mm banana jack) is located left to the card cage.
R1.0, February 2016 Hardwa
re Platform 3
3 Backplane
AMC1
AMC2
Fabric 1/A (1000Base-BX)
Clocks - FCLKA AMC
(1:1 connection)
Clocks - TCLKB AMC (Output)
Clocks - TCLKC AMC
Clocks - TCLKD AMC (Output)
Clocks - TCLKA AMC
IPMB_L
DC/DC
Converter
+3,3V
HotSwap
AMC Port 2 (SATA)
AMC Port 3 (SATA)
MCH
AMC Port 4-7
(FAT PIPE)
Port 0
Port 1
Fabric 2/A (1000Base-BX)
Common Options
Port 2
Port 3
A
4
Port 4-7
A
B
B
C
C
D
D
FAN 1
FAN 2
FAN 3
FAN 4
FAN 5
+12V
FAN _C ontr ol
PPWR_2
PPWR_1
PPWR
MP_2
PRESENT_1
MP
I²C
Carrier Number
+12V
FAN_Tacho
5
EN_HSC_1
Current
Sense
EEPROM
FRU
PRESENT_2
EN_AMC1
MP_1
EN_AMC2
IR_HotSwap
4
AMC Port 8-11
(EXT.FAT PIPE)
Port 8-11
• 3.3 V management power generation on the backplane
• Hot-Swap circuitry for enabling the management power and payload power by the EMCH
• Fan connectors on the backplane (4-pin fan connectors)
3.1 Backplane Topology
Figure 2: Backplane Topology
11850-016
4 Backplane R1.0, February 2016
11850-016
3.2 Fabric Interface
3.2.1 Common Options
MCH Fabric Port 1 is routed to AMC 1 Port 0.
MCH Fabric Port 2 is routed to AMC 2 Port
MCH Fabric Port 3 is routed to AMC 1 Port
MCH Fabric Port 4 is routed to AMC 2 Port
AMC Ports 2 and 3 are direct slot to slot connectio
0.
1.
1.
3.2.2 Fat Pipe
AMC slots Port [4:7] are direct slot to slot connections between both AMC slots.
3.2.3 Extended Fat Pipe
AMC slots Port [8:11] are direct slot to slot connections between both AMC slots.
3.3 Intelligent Platform Management Bus (IPMB)
MicroTCA uses an Intelligent Platform Management Bus (IPMB) for management
communications.
3.3.1 IPMB-L
ns between both AMC slots.
Radial IPMB from MCH to both AMCs.
3.4 Power Management
The integrated power management circuitry on the backplane provides 12 V payload power
distribution branches to the AMC Slots. It also generates the 3.3 V management power and
distributes it to all slots.
The current to the AMC slots is limited to:
•8 A (Payload Power)
• 250 mA (Management Power)
R1.0, February 2016 Backp
lane 5
4 Cooling
4.1 Air Filter
11850-016
Figure 3: Air Filter
1 Air Filter
4.2 Air filter swap
The system provides a replaceable air filter. The air filter can be pulled out after removing the top
cover. The filter meets the requirements of the Telcordia Technologies Generic Requirements GR-78CORE specification.
4.3 Cooling
Figure 4: Airflow
The MicroTCA Shelf is equipped with four 12 VDC fans for cooling the AMC modules and one 12 VDC
fan for cooling the power supply. The fans are controlled as a group by the EMCH.
e
6 Cooling R1.0, February 2016
11850-016
4.4 Power Supply
Hazardous voltage!
Parts of the power supply may be exposed with hazardous voltage.
Always remove mains/line connector before carry out any assembly work.
Caution!
The unit is designed in accordance with protection class 1! It must therefore be operated with protective earth/GND connection. Use only a
conductor that meets the IEC safety standards!
Caution!
There is a ground terminal at the right side. This ground terminal is only for equipotential bonding.
Grounding is achieved through the protective earth conductor of the power cable!
The system has a 150 W open frame AC power supply with wide range AC input and 12 V DC output.
The DC output is connected directly to the power management
three conductor AC power cable with a protective earth
circuitry on the backplane.
The power input is provided by an AC mains/line module
mains/line fuses, line filter and a mains/line switch.
Fuse value is T2AH250V.
Figure 5: AC Input
with IEC 320-C14 connector, integrated
1 AC Input 3 Equipotential bonding
2 Mains switch 4 Fuse holder
Table 1 : Data AC Power Supply
e
Input voltage 100 - 240 VAC
Mains Frequency 50 / 60 Hz
Output (max.) 150 W
Output voltage 12 V DC
Output voltage ripple and noise 120 mVpp
Operating Temperature -5° C - +55° C
R1.0, February 2016 Cooling 7
5 EMCH (Embedded MicroTCA Carrier Hub)
Microcontroller
1000Base
-BX#2
MII
1000Base-BX#1
1000
Base-
T
(
Uplink)
IPMB-L
#
2
IPMB
-L#1
Gigabit-
Ethernet-
Switch
FAN Tacho/PWM
PS1#[0,1]
EN#[
0,1]
Hot-Swap
Controller
Current
Sensor
I2C
I²C
Backplane
USB-Serial
Port
HSC_CTL
AMC#2
1000Base-BX
IPMB-L
EN# / PS#
AMC#1
1000Base-BX
IPMB-L
EN# / PS#
Power
Supply
FANs
FAN Tacho/PWM
12V
eMCH
FRU
EEPROM
1000Base
-BX#2
1000Base-BX#1
1000Base-BX
1000Base-BX
MP
Generaon
Status-
LEDs
MP
PP
Frontpanel
The EMCH (Embedded MicroTCA Carrier Hub) is intended to provide basic MicroTCA
functionality for switching and managing two AMC (Advanced Mezzanine Card) modules.
It delivers switching and hub functionality for the system
defined in the AMC.0 standard series.
Furthermore it supports the typical hot swap management and
(M0 to M6) for each AMC module. In addition to that, the embedded MCH monitors and
verifies local sensor data of the chassis and installed FRU devices and supplies MicroTCA
power and cooling concepts by accessing the chassis integrated power supply and fan
coolers.
Remote administration can be done locally over the CLI (Command Line Interface)
the front USB port.
Figure 6: EMMC Block Diagram
11850-016
fabric gigabit ethernet (GbE) as
its transition state machine
served by
8 EMCH (Embedded MicroTCA Carrier Hub) R1.0, February 2016
11850-016
OK
FAIL
12
AMC
5.1 Front Panel and LEDs
The EMCH front panel consists of two status LEDs for the AMCs, and each one LED (OK, FAIL)
for the system’s operation status. In addition to the LEDs, you can find sockets for a RJ45 plug
and a micro USB cable.
Figure 7: EMMC Front Panel
Table 2 : EMCH front panel
Type
LED AMC1 Blink Short: Reading FRU information (M1)
LED AMC2 Blink Short: Reading FRU information (M1)
LED OK Blink Slow: -
LED FAIL Blink Slow: -
Micro USB Type A Used for virtual COM-Port. Direct connection to PC
RJ45 Gigabit-Ethernet 1000Base-T Uplink for remote control
Function
Blink Slow: Waiting for HS-Handle being closed (M1)
ON: FRU operating state (M4)
OFF: No Module installed
Blink Slow: Waiting for HS-Handle being closed (M1)
ON: FRU operating state (M4)
OFF: No Module installed
Blink Short: Test Mode
ON: Normal operating status. No error
OFF:-
Blink Short: ON: Hard fault
OFF: -
- Note: When executing the bootloader, all LEDs will be put on.
R1.0, February 2016 EM
CH (Embedded MicroTCA Carrier Hub) 9
5.2 Comand Line Interface (CLI)
The EMCH is providing a low level command line interface (CLI) which allows to set certain
operational parameters and to display run time information from the MCH and the system.
5.2.1 COM-Settings
The CLI can be accessed over the front MicroUSB port. To establish a connection to a host PC,
use a serial terminal program e.g. Terra-Term, HTerm, Putty, e.g.
Configure the COM port settings as followed:
Table 3 : COM port settings
Baudrate 115200
Data 8 bit
Parity None
Stop 1 bit
Flow control None
COM The devices COM address defined by host
11850-016
If the terminal is opened, press enter to see if the connection is established successfully.
You can now type “help” to see the list of available commands. Press enter to
call the
previous command again.
NOTE: Depending on your operating system, you need to download and install the FTDI-chi
driver manually. Drivers can be downloaded at http://www.ftdichip.com/FTDrivers.htm.
Installing the driver automatically by the windows update may take up to a few minutes.
Table 4 : CLI Commands
Command
bi Board Information
ip <ip>
ni Print network configuration
ti Print task information
bl Starts the bootloader
show_localsensors Show local sensor information of the chassis
show_fru Show all FRU’s
show_fruinfo <fru_id> FRU contents
show_sensorinfo <fru_id> Shows the sensor values of the selected FRU
show_pm Power Module Status
reboot Reboot the eMCH
password <old_password>
Parameter Description
Prints the vital product information record (i.e. Serial number, Hardware revision and release codes).
IP configuration
<netmask>
<gateway>
<new_password>
Configures IP addresses, net mask, broadcast address and
y. Parameters have to be in dotted representation
gatewa
<x.x.x.x>
Shows the contents of a FRU device selected by <fru_id>.
F
r valid FRU numbers please refer to MTCA R1.0 table 3-3
o
Shows the actual power allocation status for all AMC modules
Changes the web password for accessing the update service
p
10 EMCH (Embedded MicroTCA Carrier Hub) R1.0, February 2016
11850-016
5.3 Firmware Update
The EMCH serves a web based front end to easily upgrade the devices firmware in field. To
use this utility, first establish an ethernet link over the EMCH uplink port. If not changed, the
standard interface config is as followed:
Table 5 : Standard interface configuration
IP address: 192.168.1.138
Netmask: 255.255.255.0
Gateway: 0.0.0.0
Type http://192.168.1.138/ in your web browser or type “bl” in the command line interface
to call the bootloader. Your browser should show the index page with a button “call
bootloader”. By clicking on this button, a software reset will be triggered and the system will
boot into the bootloader. Wait a few seconds and call http://192.168.1.138/ again. The page
should have changed slightly and will prompt you to enter a password. By default, the
password is “nat”. To leave the bootloader without touching anything, just click on “Leave
Bootloader”.
By clicking on “submint” the upload page should open.
Now select a proper firmware image with the file extension “.srec”.
Click upload to flash the
image into the device memory.
NOTE: The upload process will take a few seconds, please don’t interrupt or close
the browser
while upgrading.
If succeed, the Message “File Upload Done” is shown. Click on “Reset MCU”
to trigger a
software reset. The device should now boot into the new firmware.
NOTE: If something went wrong during the firmware upgrade (e.g. lost of power or
communication during file transfe
r), the device will boot into the bootloader again instead of
loading the firmware. In this case you can easily repeat the firmware upgrade.
R1.0, February 2016 EM
CH (Embedded MicroTCA Carrier Hub) 11
6 Technical Data
Table 6 : Technical Data
Physical Dimensions
Height 43.60 mm (1 U)
Width 265 mm
11850-016
Depth
approx. 302 mm
Weight
Weight completely assembled approx. 2.7 Kg
Power Supply
Input Voltage 100 VAC to 240 VAC
Mains Frequency 50 Hz to 60 Hz
Input Current 1,2 A at 100 VAC; 0,5 A at 240 VAC
Input Fuse (2x)
T2AH250V
Environmental
Ambient temperature -5°C…+45°C (long term)
Ambient temperature -5°C…+55°C (short term)
Humidity +5%...+85%, non-condensing
12 Technical Data R1.0, February 2016
Schroff GmbH
Langenalber Str. 96 - 100
75334 Straubenhardt, Germany
Tel +49.7082.794.0
Fax +49.7082.794.200
Doc-No: 63972-350_R1.0
Loading...
