SD Series

PTZ Speed Dome Camera

SD-Z35 / 35X Optical Zoom • WDR • Day/Night

Key Features

35X

•

i

g

o

•

•

h

ct

o

•

•

in

•

•

n

r

o

•

w

g

•

r

r

c

o

sts

(

l

le)

•

A/F Optical Zoom

•

•

•

•

r

l

WDR

Day/Night

See through the light !

See in the dark !

NUVICO INC.

53 Smith Street, Englewood, NJ 07631 USA

Phone [phone] Toll Free 866-523-1700 Fax [phone]

[email protected] www.nuvico.com

NUVICO reserves the right to alter product offers and specification at any time without notice.
© Copyright 2006, NUVICO. All rights reserved.

om

Construction

System Configuration

Communication

DVR

Sensor 1-16 MemoryStick Alarm External Modem

IR Remote Controller

Connecting Video Anywhere

u

....

1

99

Controller

Speed Dome Camera

Video In

Video In

LAN

PSTN

RS-485 RS-485

Max. 16 Camera

Standard CCD Camera

Audio Out

Audio In 1-16

Remote Site

™

99

.

.

.

.

1

SD Series

PTZ Speed Dome Camera

SD-Z35 / 35X Optical Zoom • WDR • Day/Night

Specifications

Camera

Video Formats
Scanning System
Image Sensor
Effective Pixels
Horizontal Resolution
Sync System
Minimum Illumination
S/N Ratio
BLC
WDR
Electronic Images Stabilization
Focus
White Balance
Iris Control
Gain Control
Electronic Shutter Speed
Video Output

Lens

Zoom Ratio
Focal Length
Angle of View

Pan/Tilt Functions

Pan Travel Range
Manual Pan Speed
Manual Turbo Pan Speed
Preset Pan Speed
Tilt Travel Range
Manual Tilt Speed
Preset Tilt Speed
Proportional Pan & Tilt
Preset Accuracy
Preset
Area Title
Privacy Zone
Title Character
Tour
Pattern
Auto Pan
Automatic Flip(180º)
Alarm(Input/Output)

General

PTZ Dome Power Requirement
Fan & Heater Power Requirement
Housing
Operating Temperature

Model No.

Pendant Housing w/ Wall Mount
Flush Mount Housing
Fan & Heater Option

Accessories

Smoked Bubble
Pedestal Mount
Parapet Mount
Corner Mount Bracket
Pole Mount Bracket
I-Beam Mount Bracket

SD-Z35N

NTSC PAL
2:1 Interlace
1/4" Progressive Scan CCD
768(H) X 494(V) 752(H) X 582(V)
540 TV Lines 540 TV Lines
Internal / External (V-Lock)

1.0 Lux(Normal), 0.1 Lux(ICR On, DSS On)
50 dB
On / Off
On / Off
On / Off
Auto with manual override
Auto with manual override
Auto with manual override
Auto with manual override
1/2 ~ 1/30,000 1/1.5 ~ 1/30,000

1.0 Vp-p, 75 ohm

SD-Z35N

35X A/F Optical Zoom, 12X Digi tal Zoom(Total: 420X)

3.4~119mm

1.7º(TELE) ~ 55.8º(WIDE)

SD-Z35N

360º Continuous

0.1º ~ 90º/sec
360º/sec
360º/sec

-5º~185º

0.1º ~ 90º/sec
360º/sec
Yes

0.2º
248 Position
24
8
16
8
4(240sec)
16 Scan, 1 Auto Pan
Instant Digital Flip
8/2

SD-Z35N

24VAC / 40VA
24VAC / 50VA
Weatherproof - IP66
0ºC ~ 45ºC(Normal)

-45ºC ~ 60ºC(w/ Fan & Heater)

SD-Z35N

SD-Z35N-PHW
SD-Z35N-FMH
SD-FH

SD-SB
SD-PM
SD-PPM
SD-CMB
SD-PMB
SD-IMB

SD-Z35P

SD-Z35P

SD-Z35P

SD-Z35P

SD-Z35P

SD-Z35P-PHW
SD-Z35P-FMH
SD-FH

Dimensions (UNIT: mm)

Pendant Housing w/ Wall Mount

Ceiling Tile Cutout - 200mm

Flush Mount Housing

Mounting Accessories

Parapet MountPedestal Mount

Corner Mount BracketPole Mount Bracket
