EasyView™ Lite Series
5.16” (131)
R25,0
R44,0
3.54” (90)
2.09” (53)
12
°
5.16” (131)
High Resolution, 550 TV Lines, Vandalproof Dome Camera
CV-H2N • CV-H39N
CV-H2N
CV-H39N
KEY FEATURES
• 1/3” CCD Sensor
• 550 TV Lines
• 2.9mm Fixed Lens, or 3.8mm~9.5mm, DC Auto Iris Lens
• 0.1 Lux
• 12VDC or 12VDC/24VAC Dual Voltage
TECHNICAL SPECIFICATIONS
Technical Specications
Video Format
Image Sensor
Horizontal Resolution
Day/Night Functionality
Lens Type
Angle of View
Sync System
Effective Pixels
Scanning System
Electronic Shutter
Main Video Output
Service Monitor Output
Minimum Illumination
S/N Ratio
General Information
Operating Temperature
Operating Humidity
Power Consumption
Input Voltage
CV-H2N
NTSC/PAL
1/3” CCD
550 TV Lines
No
Fixed 2.9mm
120°
Internal
768(H) x 494(V)
525 Lines. 2:1 Interlaced
1/60 ~ 1/100,000 sec.
1.0 Vp-p Composite, 75 ohm
1.0 Vp-p Composite, 75 ohm
0.1 Lux
More than 48dB (AGC Off)
CV-H2N
23ºF ~ 113ºF
Within 90% RH
500 mA
12VDC
*specications are subject to change without any prior notice.
NTSC
CV-H39N
Vari-focal 3.8mm-9.5mm
95.5°(W) ~ 37.3°(T)
1/60 sec.
CV-H39N
12VDC/24VAC Dual Voltage
LENS OPTION
• 2.9mm Fixed Lens - CV-H2N (12VDC)
• 3.8~9.5mm, DC Auto Iris Lens - CV-H39N (12VDC/24VAC Dual Voltage)
CONSTRUCTION
• 3” Polycarbonate Bubble
• 3-Axis Gimbal
• Impact Resistant Dome w/ Aluminum Housing
• Compact Size
AVAILABLE MODELS
• CV-H2N (Ivory Housing Only) - 2.9mm Fixed Lens
• CV-H39N (Ivory Housing Only) - 3.8mm~9.5mm, DC Auto Iris Lens
3-AXIS GIMBAL, SIMPLY MOUNT AND POINT
All EasyView™ Lite dome camera gimbal has the ability to rotate, tilt, and pan for easy camera placement. Simply
mount the camera to the ceiling, wall, or under the eaves on the exterior of building or a house and point the
camera to the area you want to surveillance.
1
Rotation 355°
2
Tilting 90°
3
Panning 355°
1
Rotation 355°
2
Tilting 90°
3
Panning 355°
DIMENSIONS
Unit: Inches (mm)
