Page 1
Getting Started
With Your
www.nuumobile.com
Page 2
3
Front/Back
A4L OverviewIndex
3
4
6
13
17
22
A4L Overview
Setting Up Your Phone
Getting Started
Safety information
Certificate
Warranty information & Registration
Customer Support
23
Top
Earpiece
Back
Home
microUSB
connector
AUX-In/
Headset jack
Recent Speaker
Front
camera
Camera
flash
Rear
camera
Page 3
4 5
Setting Up Your Phone
Follow these step-by-step instructions to set up your A4L.
Power off the phone and remove battery before inserting any cards!
Remove Back Cover
• Remove the back cover by prying the lower left corner
of your device.
Insert microSD™ Memory Card (Optional)
• Remember to power off the phone and remove battery
before inserting memory card..
Insert SIM
• Orient SIM card to match diagram on slot.
• SIM 1 (Standard) and SIM 2 (Micro) both support 4G LTE
connections. However, they do not support simultaneous 4G LTE.
Insert the Battery
• Align the battery contacts, then insert the battery
contact-first.
Replace Back Cover
• After installing the SIM card, memory card, and battery,
align the cover and snap it closed. Be sure to press all
around the edges to ensure a secure fit.
Charge/Sync
• Plug in the microUSB connector to charge the phone
or transfer data.
1
1
3
3
2
2
4
4
5
5
6
6
Warning:
SIM cards are small enough to become a choking
hazard, so please keep them away from children.
SIM cards are also quite delicate. Please be
careful when handling your card.
Page 4
How to use the phone keys
In any screen, tap the back key “ ” to return to previous screen or exit the application.
Tap the home key “ ” to return to the home screen. Tap the recent key “ ” to display
all the programs that are currently in use. Tap the “on/off” button, to turn on or off the
screen and lock the screen. Long press “on/off” to shut down or to restart your mobile
device. Press and hold the “on/off” button and the volume down key at the same time
to take a screen capture.
Language
Tap the settings icon. Scroll down under “Personal” and tap “Language & input”, then
select your preferred language by tapping “Language”.
Calls
Tap the “Phone” icon, then tap on “ ” to select the contact you would like to call. Or,
simply make a call by entering the number after selecting the “ ” icon.
Android™ Messages
Tap the Android Messages icon, then tap “ ” to create a new message. Input a name or
number into the “To” field or choose someone from your contact list, then tap “ ”, and
input your message. Press the paperclip icon if you want to attach a picture, video or other
media. When done, tap “Send”.
Writing and copying a text
The phone will make recommendations as you type. If you want to copy or cut text, long
press the text for a few seconds and use the selecting arrows to select, or use the “select
all” option, then copy or paste your text.
Camera
Tap the “camera” icon to open the camera. The phone supports a variety of picture modes
such as HDR, flash, Face beauty etc. To access these modes, select the “options” icon.
Google Photos
™
Tap the Google Photos icon in the Google™ folder to open the gallery to browse your
photos, tap on a photo to open it. Tap “ ” to enter edit mode. You can add color filter
effects, rotate, crop and so on. Click “save”.
Video camera
Tap the “camera” icon to open the camera and switch to “video” mode by tapping “ ”
to record.
G
mail
™
Tap the Gmail icon in the Google folder. Then select the “ ” icon in the lower right
corner to compose a new message. Use the paperclip to attach files or images. Tap on
“ ” when done. Note: You must set up an email account first.
Google Play Music
™
Tap the Google Play Music icon in the Google Folder. Select the playlist or song you would
like to play. Playlists can be categorized by Artist, Albums, Genre or what you have created.
6 7
Getting Started
FM Radio
Connect earphones to the audio jack, tap the “FM Radio” icon in All Apps “ ” and
select frequency.
Comenzando
¿Cómo usar los Botones del teléfono?
En cualquier pantalla pulsa la tecla “ ” para regresar a la pantalla anterior ó para salir
de la aplicación. Pulsa la tecla de inicio “ ” para regresar a la pantalla principal . Pulsa
la tecla más reciente “ ” para mostrar todos los programas que están actualmente en
uso. Pulsa el botón “encender/apagar” para bloquear o desbloquear la pantalla. Mantén
pulsado el botón de “on/off” y luego presiona el botón que baja el volúmen para obtener
una captura de pantalla.
Idioma
Pulsa el icono de configuración. Desliza la pantalla por debajo de “Personal” y pulsa
“Idioma y entrada de texto”, después elige tu idioma de preferencia pulsando “Idioma”.
Llamadas
Pulsa el icono de “Teléfono”, y después presiona en “Contactos” para seleccionar al
contacto que te gustaría marcar. Ó, simplemente haz la llamada al escribir el número
después de elegir la aplicación “Marcar”.
Mensajes
Pulsa el icono de “Mensajes”, depués el de “+” para crear un nuevo mensaje. Escribe un
nombre ó el número dentro del campo de recipiente ó bien elige a alguien de tu lista de
contactos, después escribe tu mensaje. Presiona el botón del clip si quieres agregar una
foto, un video u otro medio. Al terminar, pulsa el botón de “Enviar”.
Escribe y copia un texto
Tu teléfono hará recomendaciones mientras escribes. Si deseas copiar o cortar un texto,
pulsa el texto durante unos segundos y usa la flecha de selección para escoger, o usar la
opción de “eligir todo”, después copia y pega tu texto.
Cámara
Pulsa el icono de “Cámara” para tomar una foto. El teléfono incluye una variedad de
modos tales como el de HDR, Flash, Face Beauty, etc. Para tener acceso a éstos modos,
elige el icono de “Opciones”
Galería
Pulsa el icono de “galería” para abrir y ver tus fotos, pulsa en una foto para abrir. Pulsa
“ ” para entrar al modo de edición. Puedes agregar filtros de color con efectos, rotar,
recortar, etc. Presiona el botón de “guardar”.
Cámara de Video
Pulsa el icono de “Cámara” para abrir la cámara y cambiarlo al modo de “video” pulsando
“ ” para grabar videos.
Correos Electrónicos
Pulsa el icono de “Gmail”. Después selecciona el icono de “pluma” que se encuentra en
la esquina de la parte inferior a la derecha para componer un nuevo mensaje. Usa el clip
para añadir archivos ó imágenes. Pulsa en “Enviar” cuando termines. Nota: Debes crear
primeramente una cuenta electrónica.
Música
Pulsa el icono de “Música”. Elige la lista de canciones que te gustaría escuchar. La lista
de canciones puede ser localizada por medio de Artista, Álbum, Género ó como la hayas
creado
Radio FM
Connect earphones to the audio jack, tap the “FM Radio” icon and select frequency.
EN
SP
Page 5
8 9
Commencer
Comment utiliser les touches du téléphone
Dans tout écran, appuyez sur la touche de retour “ ” pour retourner à l’écran précédent
ou quitter l’application. Appuyez sur la touche d’accueil “ ” pour retourner à la page
d’accueil. Appuyez sur la touche récent “ ” pour afficher toutes les programmes qui
sont actuellement en cours d’utilisation. Appuyez sur la touche “on/off”, pour activer ou
désactiver l’écran et le bloquer.Tenir la touche “on/off” pour fermer ou redémarrer votre
mobile. Appuyez et tenir la touche “on/off” puis appuyez sur la touche “baisser le volume”
pour prendre une capture d’écran.
Langue
Appuyez sur l’icône des paramètres. Descendre vers le bas de la rubrique “Personnel” et
appuyez “Langue et saisie”, puis sélectionnez votre langue préférée en appuyant sur “Langue”.
Appels
Appuyez sur l’icône d’appel, puis cliquez sur “Contacts” pour sélectionner le contact
que vous voulez appeler. Ou simplement faire un appel en entrant le numéro après avoir
sélectionné l’application “Composer”.
Message
Appuyez sur l’icône “Messages”, puis “+” pour créer un nouveau message. Entrer un nom
ou numéro dans le récepteur ou choisir quelqu’un dans votre liste de contacts, puis entrer
votre message. Appuyez sur le bouton de trombone si vous souhaitez d’attacher une
photo, une vidéo ou d’autres médias. Lorsque vous avez terminé, cliquer sur “Envoyer”.
Écrire et copier du texte
Ce téléphone fera des recommandations quand vous tapez. Si vous voulez copier ou
couper du texte, Faire un appui long sur le texte pour quelques secondes et utiliser les
flèches de sélection pour sélectionner, ou utiliser l’option “select all “Sélectionner tout”,
Enfin, copier ou coller votre texte.
Caméra
Appuyez sur l’icône “Caméra” pour ouvrir le camera. Ce téléphone supporte une variété
de mode d’images telles que HDR, le frêne, le visage de beauté, etc. Pour accéder à ces
modes, sélectionner l’icône “options”.
Galerie
Appuyez sur l’icône “Galerie” pour ouvrir la galerie afin de parcourir vos photos, appuyez sur
une photo pour l’ouvrir. Appuyez “ ” pour entrer le mode d’édition. Vous pouvez ajouter les
effets par rapport à la couleur, la rotation, la recadrage et ainsi de suite. Cliquer “Enregistrer”.
Caméra vidéo
Appuyez sur l’icône “Caméra” pour l’ouvrir et changer au mode “vidéo” en tapant “ ”
pour enregistrer.
Courriel
Appuyez sur l’icône “Gmail”. Ensuite, sélectionner l’icône “stylo” en bas à droite pour
composer un nouveau message. Utiliser le trombone pour attacher les fichiers ou les
imagines. Appuyez sur “envoyer” quand vous avez terminé. Note: Vous devez d’abord
créer un compte du courriel électronique.
Musique
Appuyez l’icône “Musique”. Sélectionner playlist ou chanson que vous voulez écouter. Les
Playlists peut être catégorisés par les artistes, les albums, les genres ou ce que vous avez créé.
Radio FM
Connecter les écouteurs à la prise audio, appuyez sur l’icône “Radio FM” et sélectionner
la fréquence.
Getting Started
(DE)
FR
DE
Grundlegende Funktionen
Page 6
10 11
IT
NL
Iniziare Van start gaan
Getting Started
(IT)
Getting Started
(NL)
Page 7
12 13
BA
Getting Started
(BA)
Safety information
• This section contains important information about the operation of your device, it also
contains information about how to use the device safely. Read this information carefully
before using your device.
Electronic device
Do not use your device if using the device is prohibited.
Do not use the device if doing so causes danger or interference with other electronic devices.
Interference with medical equipment
• Follow rules and regulations set forth by hospitals and health care facilities. Do not use your
device where prohibited.
• Some wireless devices may affect the performance of hearing aids or pacemakers. Consult
your service provider for more information.
• Pacemaker manufacturers recommend that a minimum distance of 15 cm be maintained
between a device and a pacemaker to prevent potential interference with the pacemaker. If
using a pacemaker, hold the device on the side opposite the pacemaker and do not carry
the device in your front pocket.
Protecting your hearing when using a headset
• To prevent possible hearing damage, do not listen at high volume levels for long periods.
• Using a headset at high volumes may damage your hearing. To reduce this risk, lower the
headset volume to a safe and comfortable level.
• Exposure to high volumes while driving may cause distraction and increase your risk of an
accident.
Areas with flammables and explosives
•
Do not use the device where flammables or explosives are stored (in a gas station, oil depot,
or chemical plant, for example). Using your device in these environments increases the risk of
explosion or fire. In addition, follow theinstructions indicated in text or symbols.
• Do not store or transport the device in containers with flammable liquids, gases, or explosives.
Traffic security
• Observe local laws and regulations while using the device. To reduce the risk of accidents, do
not use your wireless device while driving.
• Concentrate on driving. Your first responsibility is to drive safely.
• Do not hold the device while driving. Use hands-free accessories.
• When you must make or answer a call, pull off the road safely and park the vehicle first.
• RF signals may affect the electronic systems of motor vehicles. For more information, consult
the vehicle manufacturer.
• Do not place the device over the air bag or in the air bag deployment area in a motor vehicle.
Doing so may hurt you because of the strong force when the air bag inflates.
• Wireless devices may interfere with the airplane’s flight system. Do not use your device where
wireless devices are not allowed according to the airplane company’s regulations.
Page 8
14 15
Operating environment
• Avoid dusty, damp, or dirty environments. Avoid magnetic fields. Using the device in these
environments may result in circuit malfunctions. Do not use your device during thunderstorms
to protect your device against any danger caused by lightning.
• Ideal operating temperatures are 0 °C to 35 °C. Ideal storage temperatures are -20 °C to
45 °C. Extreme heat or cold may damage your device or accessories.
• Do not expose your device to direct sunlight (such as on a car dashboard) for prolonged
periods.
• To protect your device or accessories from fire or electrical shock hazards, avoid rain and
moisture.
• Keep the device away from sources of heat and fire, such as a heater, microwave oven, stove,
water heater, radiator, or candle.
• Do not place sharp metal objects, such as pins, near the earpiece or speaker. The earpiece
may attract these objects and result in injury.
• Stop using your device or applications for a while if the device is overheated. If skin is exposed
to an overheated device for an extended period, low temperature burn symptoms, such as
red spots and darker pigmentation, may occur.
• Do not use your device’s camera flash directly in the eyes of people or pets. Otherwise
temporary loss of vision or damage to the eyes may occur.
• Do not touch the device’s antenna. Otherwise, communication quality may be reduced.
• Do not allow children or pets to bite or suck the device or accessories. Doing so may result
in damage or explosion.
• Observe local laws and regulations, and respect the privacy and legal rights of others.
Child’s safety
• Comply with all precautions with regard to child’s safety. Letting children play with the device
or its accessories may be dangerous. The device includes detachable parts that may present
a choking hazard. Keep away from children.
• The device and its accessories are not intended for use by children. Children should only use
the device with adult supervision.
Accessories
• Using an unapproved or incompatible power adapter, charger or battery may cause fire,
explosion or other hazards.
• Choose only accessories approved for use with this model by the device manufacturer. The
use of any other types of accessories may void the warranty, may violate local regulations and
laws, and may be dangerous.
• If the power cable is damaged (for example, the cord is exposed or broken), or the plug
loosens, stop using it at once. Continued use may lead to electric shocks, short circuits,
or fire.
• Do not touch the power cord with wet hands or pull the power cord to disconnect the
charger.
• Do not touch the device or the charger with wet hands. Doing so may lead to short circuits,
malfunctions, or electric shocks.
• If your charger has been exposed to water, other liquids, or excessive moisture, only an
authorized service center has the right to inspect.
Battery safety
• Do not connect battery poles with conductors, such as keys, jewelry, or other metal materials.
Doing so may short-circuit the battery and cause injuries or burns.
• Keep the battery away from excessive heat and direct sunlight. Do not place it on or in heating
devices, such as microwave ovens, stoves, or radiators. Batteries may explode if overheated.
• Do not attempt to modify or remanufacture the battery, insert foreign objects into it, or
immerse or expose it to water or other liquids. Doing so may lead to fire, explosion, or other
hazards.
• If the battery leaks, ensure that the electrolyte does not make direct contact with your skins or
eyes. If the electrolyte touches your skins or splashes into your eyes, immediately flush with
clean water and consult a doctor.
• In case of battery deformation, color change, or overheating while charging or storing,
immediately stop using the device and remove the battery. Continued use may lead to battery
leakage, fire, or explosion.
• Do not put batteries in fire as they may explode. Damaged batteries may also explode.
• Dispose of used batteries in accordance with local regulations. Improper battery use may lead
to fire, explosion, or other hazards.
• Do not allow children or pets to bite or suck the battery. Doing so may result in damage
or explosion.
• Do not smash or pierce the battery, or expose it to high external pressure. Doing so may lead
to a short circuit or overheating.
• Do not drop the device or battery. If the device or battery is dropped, especially on a hard
surface, it may be damaged.
• If the device standby time shortens significantly, replace the battery.
Cleaning and maintenance
• Keep the device and accessories dry. Do not attempt to dry it with an external heat source,
such as a microwave oven or hair dryer.
• Do not expose your device or accessories to extreme heat or cold. These environments may
interfere with proper function and may lead to fire or explosion.
• Avoid collision, which may lead to device malfunctions, overheating, fire, or explosion.
• Before you clean or maintain the device, stop using it, stop all applications, and disconnect
all cables connected to it.
• Do not use any chemical detergent, powder, or other chemical agents (such as alcohol and
benzene) to clean the device oraccessories. These substances may cause damage to parts
or present a fire hazard. Use a clean, soft, and dry cloth to clean the device and accessories.
• Do not place magnetic stripe cards, such as credit cards and phone cards, near the device for
extended periods of time. Otherwise the magnetic stripe cards may be damaged.
• Do not dismantle or remanufacture the device and its accessories. This voids the warranty
and releases the manufacturer from liability for damage. In case of damage, contact an
authorized service center for assistance or repair.
Page 9
16 17
• If the device screen is broken in a collision, immediately stop using the device. Do not touch or
attempt to remove the broken parts. Promptly contact an authorized service center.
Emergency calls
• The availability of emergency calls is subject to your cellular network quality, service
provider policy, and local laws and regulations. Never rely solely on your device for critical
communications like medical emergencies.
Environmental protection
• The device and its accessories (if included), such as the power adapter, headset, and battery
should not be disposed of with household garbage.
• Disposal of the device and its accessories is subject to local regulations. Support proper
collection and recycling.
Safety precautions
• Use of wireless hands-free system (headphone, headset) with a low power Bluetooth emitter.
• Make sure the cell phone has a low SAR.
• Keep your calls short or send a text message (SMS) instead. This advice applies especially to
children, adolescents and pregnant women.
• Use cell phone when the signal quality is good.
• People having active medical implants should preferably keep the cell phone at least 15 cm
away from the implant.
Disposal and recycling information
This symbol on the device or on its packaging indicates that the device
(including its electrical accessories) should not be disposed of as normal
household garbage. Do not dispose of your device as unsorted municipal
waste. The device should be handed over to an authorized collection center
for recycling or proper disposal at the end of its life.
FCC Information
FCC STATEMENT
This device complies with Part 15 of the
FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may
cause undesired operation. Changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more
of the following measures: Reorient or relocate the receiving antenna. Increase the
separation between the equipment and receiver. Connect the equipment into an outlet
on a circuit different www.nuumobile.com from that to which the receiver is connected.
Consult the dealer or experienced radio/TV technician for help.
FCC RF Warning Statement: The device has been evaluated to meet general RF
exposure requirement. The device can be used in portable exposure condition without
restriction.
Page 10
18 19
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radiofrequency (RF)
energy set by the Federal Communications Commission of the U.S. Government.
These limits are part of comprehensive guidelines and establish permitted levels
of RF energy for the general population. The guidelines are based on standards
that were developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is
1.6 W/kg. * Tests for SAR are conducted with the phone transmitting at its highest
certified power level in all tested frequency bands. Although the SAR is determined
at the highest certified power level, the actual SAR level of the phone while operating
can be well below the maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base station antenna, the lower
the power output. Before a phone model is available for sale to the public, it must
be tested and certified to the FCC that it does not exceed the limit established by
the government adopted requirement for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body) as required by the FCC
for each model. The highest SAR value for this model phone when tested for use at
the ear is 0.601W/Kg and when worn on the body, as described in this user guide, is
0.981W/Kg(Body-worn measurements differ among phone models, depending upon
available accessories and FCC requirements). The maximum scaled SAR in hotspot
mode is 0.981W/Kg. While there may be differences between the SAR levels of various
phones and at various positions, they all meet the government requirement for safe
exposure. The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC RFexposure
guidelines. SAR information on this model phone is on file with the FCC and can be
found under the Display Grant section of http://www.fcc.gov/ oet/fccid after searching
on FCC ID:2ADINNUUA4L Additional information on Specific Absorption Rates (SAR)
can be found on the Cellular Telecommunications Industry Asso-ciation (CTIA) website at http://www.wow-com.com. * In the United States and Canada, the SAR limit
for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram
of tissue. The standard incorporates a sub-stantial margin of safety to give additional
protection for the public and to account for any variations in measurements.
SAR Information Statement
IC STATEMENT
This device complies with Industry Canada licence-exempt RSS standard(s)
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. End user must follow the specific operating instructions for satisfying RF
exposure compliance. This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
These requirements set a SAR limit of 1.6 W/kg averaged over one gram of tissue. The
highest SAR value for this model phone when tested for use at the ear is 0.605W/Kg
and when worn on the body is 0.981W/Kg. The maximum scaled SAR in hotspot mode
is 0.981W/Kg.This device was tested for typical body-worn operations. To comply with
RF exposurerequirements, a minimum separation distance of 10mm must be maintained
between the user’s body and the handset, including the antenna. Third-party belt-clips,
holsters, and similar accessories used by this device should not contain any metallic
components. Body-worn accessories that do not meet these requirements may not
comply with RF exposure requirements and should be avoided. Use only the supplied
or an approved antenna.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence.
Ce dispositif est conforme aux normes autoriser-exemptes du Canada RSS d’industrie
L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
Cet équipement est conforme avec l’exposition aux radiations IC définies pour
un
environnement non contrôlé. L’utilisateur final doit respecter les instructions de
fonctionnement spécifiques pour satisfaire la conformité aux expositions RF. Cet émetteur
ne doit pas être co-localisées ou opérant en conjonction avec une autre antenne ou
transmetteur.Ces exigences définissent la valeur SAR limite à 1.6 W / kg en moyenne par
gramme de tissu. La valeur SAR la plus élevée pour ce modèle de téléphone testé à l’oreille
est 0.605W/Kg et lorsque porté sur le corps est 0.981W/Kg. l’échelle maximale sar en
mode hotspot est de 0.981W kg Cet appareil a été testé pour des opérations portés sur
le corps typiques. Pour se conformer aux exigences d’exposition aux radiofréquences,
une distance minimale de 15 mm doit être maintenue entre le corps de l’utilisateur et
Body-Worn Operation
This device was tested for typical body-worn operations. To comply with RF exposure
requirements, a minimum separation distance of 10mm must be maintained between
the user’s body and the handset, including the antenna. Third-party belt-clips,
holsters, and similar accessories used by this device should not contain any metallic
components. Body-worn accessories that do not meet these requirements may not
comply with RF exposure requirements and should be avoided. Use only the supplied
or an approved antenna.
Page 11
20 21
le combiné, y compris l’antenne. Les pinces de ceinture, les étuis et autres accessoires
similaires utilisés par cet appareil ne doivent pas contenir de composants métalliques. Les
accessoires portatifs qui ne répondent pas à ces exigences peuvent ne pas se conformer
aux exigences d’exposition RF et doit être évitée. Utilisez uniquement l’antenne fournie
ou une antenne approuvée
Certification information (SAR)
Your device is a low-power radio transmitter and receiver.
As recommended by international guidelines, the device is
designed not to exceed the limits for exposure to radio waves, and should include safety
measures designed to ensure the safety of all users, regardless of age and health.
The Specific Absorption Rate (SAR) is the unit of measurement for the amount of radio
frequency energy absorbed by the body when using a device. The SAR value is determined
at the highest certified power level in laboratory conditions, but the actual SAR level during
operation can be well below the value. This is because the device is designed to use the
minimum power required to reach the network. The SAR limit adopted by India is 1.6
watts/kilogram (W/kg) averaged over one gram of tissue. The highest SAR value for this
device is 1.321W/kg
CAUTION
1. Use careful with the earphone maybe possible excessive sound pressure from
earphones and headphones can cause hearing loss
2. CAUTION : RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
3. The product shall only be connected to a USB interface of version USB2.0
4. Adapter shall be installed near the equipment and shall be easily accessible
5. Operation temperature:-10ºC~35ºC
6. The plug considered as disconnect device of adapter
7. The device complies with RF specifications when the device used at 1.5cm form your body
8. Use the AC adapter provided
Sun Cupid (Shen Zhen) Electronic Ltd
hereby declares that this Mobile Phone is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC.
Battery Caution
1) Use only NUU approved batteries, chargers, and cables to charge your phone.
Unapproved chargers or cables can cause the battery to explode or damage the device.
2) Use only NUU approved batteries, chargers and cables. Use unapproved batteries,
chargers and cables may cause safety issue and the warranty will be lost.
3) You can recharge your battery many times, but all batteries have a limited lifespan. If you
notice a significant deterioration in your phone’s battery life, you will need to purchase
a replacement battery for replacement. If the battery is built-in in the phone, do not
attempt to remove built-in batteries and contact an authorized NUU service center for
a replacement.
4) Your phone may become warm after prolonged use or when exposed to high ambient
temperatures. If your phone becomes hot to the touch, unplug the USB cable, disable
non-essential features, and avoid prolonged skin contact. Place your phone in a cool
location and allow it to cool down to room temperature.
5) Charging times may vary depending on the ambient temperature and the remaining
battery level.
6) Avoid using your phone when it is charging. Do not cover your phone or the charger
when it is charging.
Page 12
22 23
Please visit our website for details on warranty information.
Warranty Registration
Warranty information
Register Your Device
Thank you for choosing NUU mobile. To receive helpful tips and faster tech support,
register your device online at
Hong Kong:
intl.nuumobile.com/product-registration
US:
us.nuumobile.com/my-account/product-registration
UK and Europe:
uk.nuumobile.com/product-registration
Indonesia:
Please fill up the warranty card in the package, and call for the warranty to begin.
India:
Customer Support
Questions? Let us help. We’re here to support you.
Hong Kong:
Service Center: 16F, CEO Tower, 77 Wing Hong St. Kowloon, Hong Kong.
Phone: (852) 2725-0161
HK hours: M-F 9:00am-5:30pm CT
Email: [email protected]
US:
Service Center: 3111 19th Street NW Rochester, MN 55901-6606 USA
Phone: Toll Free: 844-NUU-3365
U.S. hours: M-F 8:00am-4:30pm CT
Email: [email protected]
UK and Europe:
Phone: 0333 121 0239
UK hours: M-F 8:00am - 7:00pm
Sat 10:00am - 4:00pm
Indonesia:
Service Center: Area Jakarta
Mangga Dua Square, lantai 1 blok C no.39
Phone: 0812 8242 3444
Area Bandung
Jl. Leuwi Panjang No 101 B, Dekat Terminal Leuwi Panjang
Phone: 022 42822704
Operasional: Hari Senin-Jum’at, Jam 10-5 sore
Hari Sabtu, Jam 10-1 siang
Hari Minggu & hari libur nasional tutup
India:
Service Center: 201,Quantum Tower, Rambaug Lane, Off S. V. Road, (Malad) West,
Mumbai, Maharashtra, India, 400064.
Phone: 1800-121-0688
Mon-Sat 10:00am-7:00pm
Email: [email protected]
R-41064661
IS 13252 (Part 1)/
IEC 60950-1
© 2017 NUU Limited.
Android is a trademark of Google Inc.
Made in China
Page 13
Learn more about NUU Mobile products,
features and accessories at
www.nuumobile.com
©2017 Google Inc., used with permission.
Android, Google Play, Gmail, Google and other marks are trademarks of Google Inc.
Loading...
