Page 1

PICEM62.5

Countertop Ice Maker

Portable Kitchen Ice Cube Machine,

Questions? Issues?

We are here to help!

Phone: (1) 718-535-1800

Email: [email protected]

Stainless Steel (3 Sizes of Ice Cubes)

Page 2

Make sure you have read this manual before using. Use properly the appliance in accordance with the instructions. Please well keep this instruction manual.

SELFCLEAN MODE OPERATING INSTRUCTIONS

The self-clean mode should be put into operation before you use your ice maker for the rst time and/or if there has been a long period without use.

Three Icons as Large, Medium and Small Icons will be on at the same time when the ice maker is in self-clean mode.

BASIC INTRODUCTION

PICEM62.5 Ice maker is a professional product used to make ice cubes.

With a luxurious appearance, antiseptic internal material, it is suitable for long-term use. Automatically ice-making system works in high speed and it always process the ice cubes in standard shape stably. The ice cubes will not agglomerate, it is always easy-working and in good looking. Three dierent modes of ice cubes could be processed according to your personal setting. In order to keep the ice maker working eciently and smoothly, please always follow our instructions to operate ice maker.

Stage 1

1. Add equal parts of water and vinegar (1:1) to the ice maker’s reservoir.

2. With the stand-by mode, keep pressing ON/OFF button at least 5 seconds to activate the self-clean mode. Please note that self-clean mode will start automatically after “Beep” sound.

3. During the SELF CLEAN mode, the upper water bucket is lled and dumped. The pump will remain in continuous operation as it feeds water to the bucket and evaporator coils. This cycle will continuous for ve times.

4. Upon completion, the unit automatically changes to stand-by mode.

Stage 2

1. Drain the cleaning solution from the internal reservoir by removing the rear drain cap and plug.

2. Add fresh water to the Max. permit water volume line.

3. With the stand-by mode, keep pressing ON/OFF button at least 5 seconds to activate the self-clean mode again which will now act as a rinse.

4. Upon completion of this nal stage of the self clean process, the unit automatically changes to stand-by mode. Proceed to drain the water from the internal reservoir by removing the rear drain cap and plug. Leave the lid on the ice maker open to allow it to air dry.

I. PRODUCT FEATURES

1. Adopting compressor refrigerating technology, the ice maker process ice cubes very eciently.

2. This Ice maker is widely used in various places, household, saloon, restaurant, etc.

3. Ice making status is watched through the transparent window.

4. Push-button operation. LCD indicator light indicates the working status dynamically.

5. Automatically reminding for water shortage and ice cubes fullness, ice making status is always represented on the display panel.

II. COMPONENTS NAMES

Please note if there is a water shortage during Self-cleaning mode, the unit will automatically go into stand-by mode; If water bucket is fail to turn over, icon will be on, you need to long press ON/OFF button for more than 5 seconds to release self-cleaning mode to change for other operations.

www.NutriChefKitchen.com

Page 3

1. Transparent window

9. Unplug the cable before moving Ice maker, so as to avoid the damage

2. Cover

3. Operation panel

4. Air outlet

5. Air inlet

6. Power cord

7. Water outlet

8. Ice storage box

9. Evaporator

10. Ice making box

III. SAFETY PRECAUTIONS

1. Power source must be suitable for the standards of the Ice maker. If the

voltage uctuation range is big (Out of the rated voltage ± 10%), the ice

maker may not work smoothly. In such conditions, please use the ice

maker with a voltage regulator.

2. Hazardous articles which are explosive and ammable are prohibited to

put inside ice maker. As well as highly corrosive acid and alkali.

3. While the power cord is damaged or the plug is in fault, stop use ice

to refrigerating system.

10. Without professional people, do not break down Ice maker, so as to avoid human hurt.

11. Only use the appliance for its intended purpose. The Appliance is not intended for use by persons (including Children) whose physical and mental ability is awed, or those who lack of experience and electrics knowledge, including the children. Unless they have been given supervision or instructions concerning the use of the appliance by a person responsible for their safety.

12. Never let children operate the appliance alone.

This appliance is intended to be used in household and similar applications such as:

• Staﬀ kitchen areas in shops, oces and other working environments

• Farm houses and by clients in hotels, motels and other residential type

environments

• Bed and breakfast type environments

• Catering and similar non-retail applications.

Maker. Cable and plug should be replaced by professional people.

4. Catch the plug to unplug it from the socket; do not pull the cable for

unplugging.

5. Do not use ice maker in a place with coal gas or other ammable gas

leakage.

6. Before cleaning or maintenance e, remember to unplug.

7. Ice maker is special for making ice cubes; do not use it to refrigerate

food or beverages, so as to avoid machine damage.

8. Do not use or store gasoline or other ammable materials besides Ice

maker, so as to avoid re disaster.

www.NutriChefKitchen.com

IV. PLACE ENVIRONMENT

1. Place the Ice Maker securely onto a sturdy and even surface.

2. Away from heating source and avoid direct sunlight, so as not to impact the ice-making performance.

3. Ice maker should work in a place with well ventilations. Ensure that a minimum space of 20cm from Ice maker’s air outlet and inlet is not obstructed.

4. Ambient temperature for Ice maker could not be less than 5°C or 41°F

5. Ice maker should not be used outdoor.

www.NutriChefKitchen.com

Page 4

V. PREPARATION BEFORE USE

1. Break down all the package components.

2. Make an inventory accessories and instructions.

3. Place the ice maker in a suitable position.

4. It is better to clean the machine before use.

VI. START TO USE

1. Switch ON the power source. Do not turn on the Ice maker within 30

minutes after moving the ice maker.

2. Pour water into the water tank. Please use drinking water for making ice.

3. Press again key to start making ice.

Buttons and Icon Functions

Power ON/OFF, Making Ice, Standby,

Button

SELECT Button

Eliminating faults.

Selecting Ice cube size:L, M, S three sizes.

Time setting ON or OFF;

Key

three states setting switch

Clock-time setting, power OFF time setting,

SET key

Icon

power ON or OFF time setting switch

Ice dropping fault indication, trouble-free ashing

Icon Water absence fault indication, fault-free ashing

VII. OPERATION PANEL

Icon

the default medium

Icon Ice full instruction

Icon Real-time indicator icon

Icon Power on time setting function indicator

Clock icon indicates real time(24 hour system), set real time, regular time, in hours and minutes

Large, medium, small size ice size instructions,

Icon

respectively blinking, no time setting display real-time, the default time display 12:00

Ice working status indicator ashing while ice

Icon

making, in standby.

www.NutriChefKitchen.com

Page 5

1. Real Time Setting: Press the SET button one time, hour blinking, press the button to set hour, press the SET button one time, minutes ash, press the button to set minutes.

2. The timing for the machine start on time setting: Press the SET button 3 times, hour blinking, press the button to set hour, press the SET button one time, minutes ash, press the button to set minutes

3. Set the machine power o time: Press the SET button 5 times, hour blinking, press the button to set hour, press the SET button one time, minutes ash, press the button to set minutes

4. The timer functions take on use: Press to set timer, set the cycle timer function mode: time power on time power o time o power on and o, power on default time is 8:00, power o default time is 12:00.

VIII. FAULTS AND TREATMENTS

Problem SolutionPossible Causes

1. Ensure that the source voltage

POWER indicator light is not turning on

Power Source is not switched ON

matches the rated supply voltage

2. Check the power cord if correctly connected

3. Internal components are damaged. Refer all servicing to qualied service personnel.

1. Ice Storage

1. Remove ice from Ice storage basket

2. Move the Ice maker to a warmer place, where the ambient temperature is higher than 41°F.

1. Check whether any foreign body got stuck in the ice making box.

2. Internal components are damaged.

Refer all servicing to qualied

ICE FULL indicator is lit

Malfunction indicator light ashes

Basket is full.

2. Low temperature protection (temperature is lower than 41°F)

Ice making box reset in bad condition

service personnel.

Problem SolutionPossible Causes

1. Water reservoir

ADD WATER Indicator Light is on

is empty.

2. Water supply system is

1. Add clean water.

2. Call Customer Service.

damaged.

1. Air Inlet/Outlet is blocked

1. Clean the Air Inlet/Outlet

2. Fill with room temperature water

3. Move the Portable Ice Maker to a cooler place, where the ambient temperature is lower than 95°F or 35°C

4. Call Customer Service

Call Customer Service

Ice making performance is poor

Portable Ice Maker is noisy

2. Water tempe rature is too high

3. Ambient tem perature is too high.

4. Refrigerant is leaking and/or refrigerating system is damaged.

Fan or pump is damaged

IX. PROPER CARE AND CLEANING

1. Make sure to unplug the appliance before cleaning and if it will not be used for a long time.

2. Use a damp cloth to clean both the interior and exterior of the appliance.

3. Water tank cleaning

• Unscrew the nut of water outlet, drain o the water.

• Pour clean water into the water tank, use a clean cloth to wipe water

tank around. Pour clean water again until the owing out water is clean, and then drain o water and grip the nut.

• Do not use organic solvents, boiling water, cleaning agents, strong acids, strong acid and Alkali etc substances for cleaning.

www.NutriChefKitchen.com

Page 6

• If ice machine will be o and will not be used for a long time, you should

unplug the appliance, drain o the water and dry the appliance with a

clean cloth, store the ice maker in a clean place.

Kind Reminder:

1. Above data are for reference only. Please check the Rating Label as

Standard datum. We will advise you timely while our appliance is

upgraded.

2. For the technical questions, please contact the after sale service

departments.

Features:

• Freestanding Kitchen Countertop Ice Maker

• Just Add Water for Automatic Ice Making

• Simple Electric Plug-in Design

• Hassle-Free Button Controls

• Compact & Portable Style

• Front Panel Digital LCD Display

• Quick Ice Cubes: Ready-to-Serve in 10 Minutes

• (3) Selectable Ice Cube Sizes: Small, Medium, Large

• 'Add Water' and 'Ice Tray Full' Indicators

• Ultra Quiet Operation

• Self-Cleaning Function

• High-Powered Freezing Element

• Convenient Top Panel See-Through Window

• Easy-to-Clean & Stain Resistant Housing

• Perfect for Placement on Any Kitchen Table or Countertop

What's in the Box:

www.NutriChefKitchen.com

• Ice Maker

• Mini Ice Scooper

Technical Specs:

• Makes up to 33 lbs. of Ice Per Day

• Ice Collection Tray Capacity: 1.8 lbs.

• Water Reservoir Capacity: 2.2 Liter

• Time Format: 24 Hour

• Construction Material: Stainless Steel, Engineered ABS

• Power Cable Length: 5.9' ft.

• Power Supply: 120V

• Ice Maker Size: 14.2'' x 9.8'' x 12.9'' -inches
