Page 1
NCFPG9
Multifunction Food Processor
Ultra Quiet Powerful Motor,
Includes 6 Attachment Blades, Up to 2L Capacity
Page 2
Read This Instruction Manual Carefully Before Using This Equipment.
FOR HOUSEHOLD USE ONLY!
IMPORTANT SAFEGUARDS
1. This appliance is not intended for use by persons with reduced physical sensory
or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instructions concerning use of the appliance in a safe
way and understand the hazards involved.
2. Blades are sharp. Care should be taken when handling the sharp cutting blades,
emptying the bowl and during cleaning.
3. Unplug from the outlet when not in use, before putting on or taking o parts,
and before cleaning.
4. Do not operate any appliance with damaged cord or plug, or after appliance has
been dropped or damaged in any way. Return the appliance to the nearest
authorized service facility for examination, repair or electrical or mechanical
adjustment.
5. To protect against the risk of electrical shock, do not put cord, plug, base, or
motor in water or other liquid.
6. Make sure motor has completely stopped before removing cover.
7. Make sure that the cover and feed tube are securely locked in a place before
operating food processor.
8. The unauthorized use may cause re, electrical shock or damage to your food
processor.
9. Indoor use only, do not expose to rain, snow or other bad environments.
10. Please put it beyond reach of children.
11. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
12. Do not use the machine continuously for more than 1 minute.
13. If the motor stop when in normal use, it mean the motor protect has worked,
please turn o the switch and wait about 20-30minutes, then to use again.
14. Always unplug from outlet when not in use, before removing food and before
cleaning.
15. Care shall be taken when handling the sharp cutting blades, emptying the
bowl and during test.
www.NutriChefKitchen.com
2
Page 3
PRODUCT CONFIGURATION
Pusher
Bowl and cover
Main Body
Masher
Shredder Slicer
Spindle
Citrus Juicer
Emulsor
Chopper Blade
& Protective cover
Flour Blade
OPERATING GUIDE
Function Food Time Processing produce
Masher Nuts 1 min
Slicer
& Shredder
Chopper
Flour
Emulsor
Citrus
Juicer
Vegetables or any
fresh fruits
Meat (350g) 30 seconds
300g Flour
with water
Egg or any cream 30 seconds Pour some water
Citrus and orange 1min Cut the round one into half
1 min
1min
Cut the nuts into
small pieces
Choose the correct
disc blades
Cut the meat into
small cubes
Make sure theres
enough water
www.NutriChefKitchen.com
3
Page 4
FOR MASHER & SLICER & SHREDDER
These accessories are used for mashing nuts, slice and shred the carrot, potato,
tomato, and any vegetables and fruit.
1. Put the spindle into bowl
2. Put the blade disc in the spindle in bowl and x well
3. Cover it in space and turn it until locked and in same
level.
4. Install the bowl to unit base, turn it by clockwise and
locked.
5. Plug in power, turn on the switch and put the food
into feed hole. Use the food pusher to press into.
Please cut the food into small piece if it is very big
6. When work nished, turn o the switch and take o
the plug. Open the cover and take out blade disc,
then you can get the food.
7. Masher, Slicer, shredder have the same operation.
Note: Slicer and Shredder use same blade disc:
one side for slicer, opposite side for shredder.
FOR CHOPPER, FLOUR & EMULSOR
1. Fix the chopper blade into bowl.
Note: Sharp blade, do not touch the edge of blade.
2. Cut the meat into suitable pieces and put into the
bowl, and cover it.
Note: Please take o the bone from the meat.
3. Install the bowl on the unit base, turn on by clockwise and lock it.
4. Plug in power and turn on the switch.
Note: If the food makes the machine shake, please stop the machine and open
the cover, and separate the food equality. This bowl is not use for liquid food.
5. When work nished, turn o the switch, and take o the plug, then take out the
bowl from the base, open the cover and take out the blade. You can get the
meat soon.
6. Chopper, Flour, Emulsor have the same operation.
www.NutriChefKitchen.com
4
Page 5
FOR CITRUS JUICER
Note: Align and lock it one by one as illustrated
Citrus Head
Citrus Basket
Citrus Spindle
Bowl
CAUTION
1. DO NOT use the machine continuously for more than 1 minute.
Always take a 1 minute rest.
2. Take o the bone from the meat.
3. DO NOT put large quantity of meat and our into bowl.
MAINTENANCE/CLEANING METHOD
1. You should always take o the plug when not in use.
2. Unplug the appliance from the electrical outlet when not in use for a long time.
Store the unit in a cool dry place.
3. Clean the accessories in water except the motor base.
4. Always unplug the appliance before you remove accessories or clean the motor
unit. Wipe the motor base, always use the dry cloth to clean, never ush or dip in
water.
www.NutriChefKitchen.com
5
Page 6
TROUBLESHOOTING
Malfunction Analysis Solution
1. Power plug is not plugged
in properly
Motor not
working
Safety switch
is not working
Food jam Too much food Turn o the machine, reduce the food
Abnormal smell
from motor base
Leakage under
the blade seat
2. Bowl or cover is not
properly aligned and locked
3. Motor protector is working.
Jammed Switch
Overheat
Blade seal is broken for
blender cup.
Too much water in the bowl
1. Check to make sure the Food
Processor is plugged in.
2. Make sure the cup and cover are
properly aligned and locked in
place
3. Wait for about 20-30 minutes
and use again.
Do not repair by yourself and contact
a qualied professional repair service
Do not operate for more than
1 minute
Turn o the machine and take out
the food, check the screw, seal and
install again.
ENVIRONMENT
Do not dispose of electrical appliances as unsorted municipal waste,
use separate collection facilities.
Contact you local government for information regarding the collection
systems available. If electrical appliances are disposed of in landlls or
dumps, hazardous substances can leak into the groundwater and get
into the food chain, damaging your health and well-being.
When replacing old appliances with new ones, the retailer is legally obligated to
take back your old appliance for disposals at least free of charge.
www.NutriChefKitchen.com
6
Page 7
Features:
· Ultra Quiet Powerful Motor
· Includes 6 Attachment Blades: Slicer/Shredder Blade Disc, Masher Blade Disc,
Chopper Blade, Knead Dough Blade, Emulsifying Blade, and Citrus Juicer
· Quick to Put Together
· Silent Strength, Ultra-Quiet
· Energy Ecient with Low Power Consumption
· Pre-set Speed Function
· Compact Design
· Easy to Store and Clean
· Electronic Overload Protection
· Every Part (except the base with the motor, cup & gearbox) is Dishwasher Safe
· Silicone rubber bottom suctions in order to hold strong on countertops while in use
What's in the Box:
· (1) Shredding/Slicing
· (1) Masher Blade Disc
· (1) Top-rated S blade
· (1) Emulsifying
· (1) Kneading
· (1) Citrus juicer attachment
· Power Cable
Technical Specs:
· Construction Material: ABS Housing, AS Cup
· Voltage: AC120V, 60Hz.
· Power Output: 600W
· Load Capacity: 12 Cups for Dry Ingredients, 9 Cups for Liquid Ingredients
· Continuous Use: ≤1min
· Power Cable Length: 3.28’ ft.
· Product Dimension (L x H): 13.78’’ x 7.48’’ x 13.58’’ -inches
www.NutriChefKitchen.com
7
