Nutek NTRLC User Manual
LIMITED LIFETIME WARRANTY
Products manufactured and sold by OMEGA RESEARCH
& DEVELOPMENT (the Company), are warranted to be free
from defects in materials and workmanship under normal use.
If a product sold by the Company proves to be defective, the
Company will repair or replace it free of charge within the first
year and thereafter all parts to be repaired will be free with only
a nominal charge for Omega Research and Development’s labor
and return shipping, to the original owner during the lifetime of the
car in which it was originally installed.
All products for warranty repair must be sent postage
prepaid to Omega Research & Development, 981 N. Burnt
Hickory Road, Douglasville, GA 30134, with bill of sale or other
dated proof of purchase. This warranty is nontransferable and
does not apply to any product damaged by accident, physical or
electrical misuse or abuse, improper installation, alteration, any
use contrary to its intended function, unauthorized service, fire,
flood, lightning, or other acts of God.
This warranty limits the Company’s liability to the repair or
replacement of the product. The Company shall not be responsible
for removal and/or reinstallation charges, damage to or theft of
the vehicle or its contents, or any incidental or consequential
damages caused by any failure or alleged failure of the product
to function properly. Under No Circumstances Should This
Warranty, Or The Product Covered By It, Be Construed As A
Guarantee Or Insurance Policy Against Loss. The Company
neither assumes nor authorizes any person or organization to
make any Warranties or assume any liability in connection with
the sale, installation, or use of this product.
Please treat the 2-Way Controller with
care; as with all LCD devices, it is
vulnerable to mishandling damage
such as impacts or dropping. Damage
such as scratches, chips and normal
“wear and tear”, are not a factory
defect and are not covered under
warranty.
www.caralarm.com
AL-1850-EDPB
Deluxe 2-way Alarm & Remote Start
July 12, 2012
Operation Guide
Temporary cover. Color cover is in a separate le.
2
Table Of Contents
Controller & Transmitter Overview................................................................................ 3
The 2-Way Controller ............................................................................................... 3
The 1-Way Transmitter ............................................................................................. 3
Controller & Transmitter Functions ............................................................................... 3
Other Remote Start Features ....................................................................................... 7
Low Battery/Low Temp Automatic Starting ............................................................... 7
Turbo Timer Feature ................................................................................................. 8
Pit-Stop Feature ....................................................................................................... 8
Manual Transmission Starting .................................................................................. 8
Security System Features ............................................................................................ 8
Last Door Arming ...................................................................................................... 8
Automatic Rearming ................................................................................................. 9
Pre-Warn Detection .................................................................................................. 9
When The System Triggers ...................................................................................... 9
Using The Valet Switch ................................................................................................. 9
Emergency Override ................................................................................................ 9
Valet Modes ............................................................................................................ 10
SecureCode ........................................................................................................... 10
The Status Light ..........................................................................................................11
Multi-Car Operation .................................................................................................... 12
Selecting CAR #1 or CAR #2 ................................................................................. 12
Controller Options....................................................................................................... 12
LCD Screen Icons .................................................................................................. 12
In-Range Indicator .................................................................................................. 12
Setting The Clock ................................................................................................... 13
Changing remote start melodies ............................................................................ 13
Selecting Melody & Vibrate modes......................................................................... 13
Parking Timer & Remote Start Timer ...................................................................... 13
Button Lock ............................................................................................................ 13
Anti-Carjacking Protection .......................................................................................... 14
Programming Controllers/Transmitters ....................................................................... 15
Programming Features ............................................................................................... 15
User Programmable Features .................................................................................... 16
Installer Programmable Features ............................................................................... 19
Programmable Features Matrix .................................................................................. 23
3
THE 2-WAY CONTROLLER
Controller & Transmitter Overview
Controller part number: 154-03
1) Antenna: Sends commands to the
system and receives conrmations for 2-way
functions.
2) LCD Display: Displays all controller functions as well as the status of your system.
3) Lock Button
4) Unlock Button
5) Trunk Button
6) Start Button
7) Programming Button: This is used for
setting controller features.
Battery Type: CR2032 (two required)
7
1
5
2
“lock”
button
“trunk”
button
“unlock”
button
“start”
button
Transmitter part number: 148-03
Call your dealer or visit
www.caralarm.com to order replacement
transmitters.
Transmitter battery replacement:
Remove the small screw from the lower
back case, and separate the transmitter
halves. Replace the two CR2016 batteries
and reassemble the transmitter case.
THE 1-WAY TRANSMITTER
LOCK / ARM: Press and release the “LOCK” button.
THE SIREN WILL CHIRP & THE PARKING LIGHTS WILL •
FLASH ONCE.
UPON RECEIVING CONFIRMATION FROM YOUR SYS-•
TEM, THE CONTROLLER WILL SHOW THE LOCK/ARM
ICON AND BEEP ONCE
NOTE: PRESSING LOCK TWICE IN 5 SECONDS STARTS
THE PARKING TIMER. THE CLOCK WILL CHANGE TO
0:00 AND START COUNTING IN MINUTES & HOURS.
(1-WAY TRANSMITTER: PRESS THE LOCK BUTTON)
3
Controller & Transmitter Functions
4
6
4
Controller & Transmitter Functions (cont’d)
UNLOCK / DISARM: Press and release the “UNLOCK” button.
THE SIREN WILL CHIRP TWICE & THE PARKING •
LIGHTS WILL FLASH TWICE THEN ILLUMINATE FOR 30
SECONDS.
UPON RECEIVING CONFIRMATION FROM YOUR •
SYSTEM, THE CONTROLLER WILL SHOW THE UNLOCK/
DISARM ICON AND BEEP TWICE.
(1-WAY TRANSMITTER: PRESS THE UNLOCK BUTTON)
TRUNK RELEASE / CHANNEL 2: Press the “TRUNK” button for 3
seconds.
THE SYSTEM WILL DISARM AND THE TRUNK WILL •
OPEN (IF EQUIPPED).
UPON RECEIVING CONFIRMATION FROM YOUR •
SYSTEM, THE CONTROLLER WILL PLAY THE TRUNK
RELEASE ANIMATION AND BEEP TWICE
(1-WAY TRANSMITTER: PRESS AND HOLD THE “||” BUTTON FOR 3 SECONDS)
REMOTE START: Press and release the “ ” button twice within 5
seconds. (see user feature #17 for additional options)
THE PARKING LIGHTS WILL FLASH ONCE AND THE •
STATUS LIGHT WILL FLASH RAPID GREEN.
THE SYSTEM WILL TURN ON THE IGNITIONS AND •
PROCEED TO START THE ENGINE.
ONCE THE ENGINE IS RUNNING, THE PARKING •
LIGHTS WILL TURN ON AND STAY ON AND THE STATUS
LIGHTS WILL FLASH SLOW GREEN.
UPON RECEIVING CONFIRMATION FROM YOUR •
SYSTEM, THE CONTROLLER WILL PLAY THE REMOTE
MELODY AND SHOW THE REMOTE START ICON.
THE CLOCK WILL CHANGE TO 0:00 TO START THE •
REMOTE START TIMER. IT WILL TIME HOW LONG THE
ENGINE RUNS IN MINUTES & HOURS.
(1-WAY TRANSMITTER: PRESS THE “|||” BUTTON TWICE
IN 5 SECONDS)
If the engine stalls, the system will make up to 3 more attempts.•
Each time you park, set the climate controls to give you the desired interior •
temperature when you use the remote start. •
(continued on pg 5)
x2
*
5
Controller & Transmitter Functions (cont’d)
CHANNEL 3: Press and hold the “TRUNK” & “ “ buttons for 3
seconds.
YOUR SYSTEM WILL ACTIVATE THE CHANNEL 3 •
OUTPUT.
UPON RECEIVING CONFIRMATION FROM YOUR •
SYSTEM, THE CONTROLLER WILL SHOW THE CHANNEL 3 ICON.
(1-WAY TRANSMITTER: PRESS AND HOLD THE “||” & “|||”
BUTTONS FOR 3 SECONDS)
CHANNEL 4: Press and hold the “LOCK” & “TRUNK” buttons for 3
seconds.
YOUR SYSTEM WILL ACTIVATE THE CHANNEL 4 •
OUTPUT.
THERE IS NO 2-WAY CONFIRMATION FOR THIS •
FUNCTION.
(1-WAY TRANSMITTER: PRESS AND HOLD THE LOCK &
“||” BUTTONS FOR 3 SECONDS)
The engine will run for the preset run time (see user feature #17).
Run Time Extender• : Press the “ ” button one time during remote start to
restart the engine run timer. The timer will restart at “0:00”.
NOTE: This can only be used once per remote start cycle. The controller will also give you
“run time expiration” warning (2 chirps) 1 minute before the remote start cycle ends.
If you decide not to drive your vehicle, you can turn off the remote start using •
the same method to turn it on (Default = press “ ” twice in 5 seconds)
NOTE: If user feature #17 is programmed for 1 press, the 1st press = Run Time Extender so
an additional press is required.
Upon entering the vehicle during remote start mode, turn the ignition key to •
the “ON/RUN” position (NOT START!!). When you press the brake pedal, the
remote start will turn off allowing the ignition key to take over.
*
*
*
CHANNEL 5: Press and hold the “UNLOCK” & “ “ buttons for 3
seconds
YOUR SYSTEM WILL ACTIVATE THE CHANNEL 5 •
OUTPUT.
THERE IS NO 2-WAY CONFIRMATION FOR THIS •
FUNCTION.
(1-WAY TRANSMITTER: PRESS AND HOLD THE UNLOCK & “|||” BUTTONS FOR 3 SECONDS)
*
6
Controller & Transmitter Functions (cont’d)
PANIC: Press and hold the “LOCK” or “UNLOCK” button for 3
seconds.
THE SIREN/HORN WILL SOUND, THE PARKING •
LIGHTS WILL FLASH, AND THE DOORS WILL LOCK OR
UNLOCK DEPENDING WHICH BUTTON IS PRESSED.
(1-WAY TRANSMITTER: PRESS AND HOLD THE LOCK
OR UNLOCK BUTTON FOR 3 SECONDS)
OR
SILENT ARM / DISARM: Press and release the “TRUNK” button
twice in 5 seconds.
THE PARKING LIGHTS WILL FLASH, AND THE •
DOORS WILL LOCK/ARM OR UNLOCK/DISARM DEPENDING ON THE CURRENT SYSTEM STATUS.
UPON RECEIVING CONFIRMATION FROM YOUR •
SYSTEM, THE CONTROLLER WILL SHOW THE LOCK/
ARM OR UNLOCK/DISARM ICON.
(1-WAY TRANSMITTER: PRESS RELEASE THE “||” BUTTON TWICE IN 5 SECONDS)
x2
SENSOR BYPASS: Press and release the “TRUNK” button within 5
seconds of locking/arming the alarm system.
THE SYSTEM WILL GIVE ONE CHIRP TO INDICATE •
THE SENSOR IS BYPASSED.
UPON RECEIVING CONFIRMATION FROM YOUR •
SYSTEM, THE CONTROLLER WILL ALSO CHIRP ONCE
& DISPLAY THE SENSOR ICON.
(1-WAY TRANSMITTER: PRESS AND RELEASE THE
“||” BUTTON WITHIN 5 SECONDS OF ARMING THE
SYSTEM)
2
1
LOW VOLTAGE/TEMP AUTO START: Press and release the “ ”
button within 5 seconds of locking/arming the system.
THE SYSTEM WILL GIVE ONE CHIRP TO INDICATE •
THE LOW VOLT/LOW TEMP(15 DEGREE ONLY) AUTOSTART IS ACTIVATED. SEE PAGE 7 FOR MORE INFO.
UPON RECEIVING CONFIRMATION, THE CONTROL-•
LER WILL CHIRP ONCE AND THE CLOCK WILL READ
“RS AUTO” EVERY 5 SECONDS.
(1-WAY TRANSMITTER: PRESS AND RELEASE THE
“START” BUTTON WITHIN 5 SECONDS OF ARMING THE
SYSTEM)
2
1
*
7
Controller & Transmitter Functions (cont’d)
AUXILIARY FUNCTIONS 1-4:
The actual operation of these functions will vary from car to car. They are designed
to operate extra vehicle functions like automatic sliding doors or motorized hatches.
Aux 1-4 are virtual outputs only available on certain vehicles when this system is
integrated with the vehicle’s data network. Consult with your installer to nd out if any
of these functions are available for your vehicle. If so, conrm each operation with the
controller and write each function in the blank spaces provided below.
- Auxiliary 1 Function (___________________): To activate this function, press
and release the “trunk” and “start” buttons simultaneously).
- Auxiliary 2 Function (___________________): To activate this function, press
and release the “lock” and “trunk” buttons simultaneously).
- Auxiliary 3 Function (___________________): To activate this function, press
and release the “unlock” and “start” buttons simultaneously).
- Auxiliary 4 Function (___________________): To activate this function, press
and release the “unlock” and “trunk” buttons simultaneously).
LOW BATTERY/LOW TEMP AUTOMATIC STARTING
Other Remote Start Features
REMOTE VALET: Press and release the “ ” button within 5 sec-
onds of unlocking/disarming the alarm system.
THE SYSTEM WILL ENTER ALARM VALET MODE. •
SEE PAGE 10 FOR MORE INFO ON VALET MODES.
(1-WAY TRANSMITTER: PRESS AND RELEASE THE
“START” BUTTON WITHIN 5 SECONDS OF DISARMING
THE SYSTEM)
1
2
*
This feature will automatically start the engine if the vehicle battery drops below 11
volts or the interior temperature drop to 15 (or 32) degrees fahrenheit. You must activate these features each time you park your car to use them. They can be activated
one of two ways:
Method 1 - Valet Switch
• Turn the ignition switch “on”, then “off” (engine not running), and within 7 seconds
press the valet switch twice. If there is a 2 second delay without additional valet but-
ton presses, the horn will honk 3 times activating low voltage start mode.
• To activate low temp starting, enter low voltage start mode as described above
but, before the horn honks, press the valet switch 1 time (15 degrees) or 2 times (32
degrees) within 5 seconds. The horn will honk to conrm your selection.
Method 2 - With The Controller (Low Volt + Low Temp - 15 Degrees Only)
• Within 5 seconds of pressing LOCK, press the START button. You will get one chirp
and the 2-way controller will alternate between “ARM” and “RS AUTO”.
NOTE: When low temp start mode is activated, low voltage start is also activated.
These features will operate once every two hours until the ignition key is
turned “ON”.
Loading...
