The Controller ������������������������������������������������������������������������������������������������ 3
Controller Functions ������������������������������������������������������������������������������������������ 3
Other Remote Start Features ���������������������������������������������������������������������������� 8
Manual Transmission Starting ����������������������������������������������������������������������� 9
Security System Features ��������������������������������������������������������������������������������� 9
Last Door Arming ������������������������������������������������������������������������������������������� 9
When The System Triggers ������������������������������������������������������������������������� 10
Using The Valet Button ������������������������������������������������������������������������������������ 10
Valet Mode ����������������������������������������������������������������������������������������������������11
The Status Light �����������������������������������������������������������������������������������������������11
Anti-Carjacking Protection ������������������������������������������������������������������������������� 12
Programming Controllers/Transmitters ������������������������������������������������������������ 13
Programming Features ������������������������������������������������������������������������������������ 13
User Programmable Features ������������������������������������������������������������������������� 14
Installer Programmable Features �������������������������������������������������������������������� 19
2
Controller Overview
THE CONTROLLER
LOCK
button
UNLOCK
button
START
button
TRUNK
button
SystemController(s)Battery
AL-1670-B1415-03 (x2)CR-2016 (2 per controller)
RS-375-3DB1412-03 (x2)CR-2032 (1 per controller)
RS-370-3D1412-03 (x2)CR-2032 (1 per controller)
RS-3701415-031416-07CR-2016 (x2) CR-2032 (x1)
Transmitter battery replacement:
Remove the small screw from the lower back case, and separate the transmitter
halves� Replace the batteries and reassemble the transmitter case�
Call your dealer or visit www.caralarm.com to order replacement controllers.
IF YOUR ANTENNA HAS THE ECHO 2-WAY READY
LOGO, YOU CAN UPGRADE TO 2-WAY JUST BY ADDING
A 2-WAY CONTROLLER. ASK YOUR DEALER ABOUT:
MODEL 1510-03 (LCD 2-WAY)
MODEL 1511-03 (LED 2-WAY)
Controller Functions
LOCK / ARM: Press and release the LOCK button�
• THE SIREN WILL CHIRP & THE PARKING LIGHTS WILL
FLASH ONCE�
3
Controller Functions (cont’d)
UNLOCK / DISARM: Press and release the UNLOCK button�
• THE SIREN WILL CHIRP TWICE & THE PARKING LIGHTS
WILL FLASH TWICE�
TRUNK RELEASE / CHANNEL 2: Press the TRUNK button for 3
seconds�
• THE SYSTEM WILL UNLOCK/DISARM AND THE TRUNK
WILL OPEN (IF EQUIPPED)�
REMOTE START: Press and release the START button twice within 5
seconds (see user feature #8 to change)�
• THE PARKING LIGHTS WILL FLASH ONCE AND THE STATUS
LIGHT WILL FLASH RAPIDLY�
• THE SYSTEM WILL PROCEED TO START THE ENGINE�
• ONCE THE ENGINE IS RUNNING, THE PARKING LIGHTS WILL
TURN ON AND THE STATUS LIGHT WILL FLASH SLOWLY�
x2
• If the engine stalls, the system will make up to 3 more attempts�
• Each time you park, set the climate controls to give you the desired interior
temperature when you use the remote start�
• The engine will run for the preset run time (see user feature #1)�
(continued on p. 5)
4
Controller Functions (cont’d)
• Run Time Extender: Press the START button one time during remote start to
restart the engine run timer� The timer will restart�
NOTE: This can only be used once per remote start cycle.
• If you decide not to drive your vehicle, you can turn off the remote start using the
same method to turn it on (Default = press START twice in 5 seconds)�
NOTE: If user feature #8 is programmed for 1 press, the 1st press = Run Time Extender so an
additional press is required.
• Upon entering the vehicle during remote start mode, turn the ignition key to the
“ON/RUN” position (NOT START!!)� When you press the brake pedal, the remote
start will turn off allowing the ignition key to take over�
CHANNEL 3: Press and hold the TRUNK & START buttons for 2
seconds�
• YOUR SYSTEM WILL ACTIVATE THE CH� 3 OUTPUT�
CHANNEL 4: Press and hold the LOCK & TRUNK buttons for 2
seconds�
• YOUR SYSTEM WILL ACTIVATE THE CHANNEL 4
OUTPUT�
CHANNEL 5: Press and hold the UNLOCK & START buttons for 3
seconds
• YOUR SYSTEM WILL ACTIVATE THE CHANNEL 5
OUTPUT�
5
Controller Functions (cont’d)
PANIC: Press and hold the LOCK or UNLOCK button for 3 seconds�
• THE SIREN/HORN WILL SOUND, THE PARKING LIGHTS
OR
WILL FLASH, AND THE DOORS WILL LOCK OR UNLOCK
DEPENDING WHICH BUTTON IS PRESSED�
SILENT ARM / DISARM: Press and release the TRUNK button twice
in 5 seconds�
x2
• THE PARKING LIGHTS WILL FLASH, AND THE DOORS
WILL LOCK/ARM OR UNLOCK/DISARM DEPENDING ON
THE CURRENT SYSTEM STATUS�
SENSOR BYPASS: Press and release the TRUNK button within 5
seconds of locking/arming the alarm system�
2
• THE SYSTEM WILL GIVE ONE CHIRP, AFTER LOCKING,
TO INDICATE THE SENSOR IS BYPASSED�
1
LOW VOLTAGE/TEMP AUTO START: Press and release UNLOCK,
LOCK, START within 5 seconds�
• THE SYSTEM WILL GIVE ONE CHIRP TO INDICATE
THE LOW VOLT/LOW TEMP(15° F ONLY) AUTOSTART
2
IS ACTIVATED� SEE PAGE 7 FOR MORE INFO�
3
1
REMOTE VALET: Press LOCK then UNLOCK then TRUNK + START
within 5 seconds�
1
6
3
• THE SYSTEM WILL ENTER VALET MODE�
SEE PAGE 10 FOR MORE INFO ON VALET MODES�
2
TO EXIT VALET VIA REMOTE, REPEAT THESE STEPS
Controller Functions (cont’d)
AUXILIARY FUNCTIONS 1-4:
The actual operation of these functions will vary from car to car� They are designed to
operate extra vehicle functions like automatic sliding doors or motorized hatches� Aux
1-4 are virtual outputs only available on certain vehicles when this system is integrated
with the vehicle’s data network. Consult with your installer to nd out if any of these
functions are available for your vehicle. If so, conrm each operation with the controller
and write each function in the blank spaces provided below�
- Auxiliary 1 Function (___________________): To activate this function, press and
release the TRUNK and START buttons simultaneously)�
- Auxiliary 2 Function (___________________): To activate this function, press and
release the LOCK and TRUNK buttons simultaneously)�
- Auxiliary 3 Function (___________________): To activate this function, press and
release the UNLOCK and START buttons simultaneously)�
- Auxiliary 4 Function (___________________): To activate this function, press and
release the UNLOCK and TRUNK buttons simultaneously)�
IF YOUR ANTENNA HAS THE ECHO 2-WAY READY
LOGO, YOU CAN UPGRADE TO 2-WAY JUST BY ADDING
A 2-WAY CONTROLLER. ASK YOUR DEALER ABOUT:
MODEL 1510-03 (LCD 2-WAY)
MODEL 1511-03 (LED 2-WAY)
7
